555 Wireless Blvd., HAUPPAUGE, NY 11788
OPERATING INSTRUCTIONS
XXXXXXXX PRINTED IN JAPAN
Issue date XX-XX
GSM900/1900MHz FREQUENCY
DUAL BAND SYSTEM MOBILE PHONE WITH
BATTERY AND CHARGER
![](/img.php?id=141224&img=bg2.png)
GDU-325
Handheld Mobile
Telephone
Thank you very much for choosing the Audiovox GDU-325 mobile
telephone. Your Audiovox mobile telephone has been designed to
the highest standards of quality and manufacturing excellence to
fulfill both your personal and business requirements.
The Audiovox GDU-325 is packed with advanced features such as
Phone Book, Missed Calls Review and Call, PIN Code Lock, and
International Roaming for 900/1900 MHz frequency dual band
GSM system (network dependent).
Your new Audiovox GDU-325 comes with something only an
Audiovox phone can provide: the proven reliability that has made
Audiovox one of the world’s leading suppliers of mobile
communications equipment.
The following pages describe the functions of your phone
and will help you make the most efficient use of this wonderful
communications tool.
NOTE:
- The English display text in this manual is based upon the
English language selection in the display language
setting.
“T9 (R) Text Input is patented under the following U.S. Pat.
5,818,437, U.S. Pat. 5,953,541, U.S. Pat. 6,011,554 and other
patents pending.”
“T9 (R) Text Input is patented under the following Euro. Pat. No.
0 842 463 (9692760.8) DE/DK, FI, FR, IT, NT, PT, ES, SE, GB and
other patents pending.”
Index
Alarm Clock Setting ................................................................. 43
Any Key Answering .................................................................. 50
Auto Shut Down Selection ....................................................... 50
Backlight Adjustment ............................................................... 49
Battery Operation .................................................................... 12
Call Barring .............................................................................. 56
Call Cost Review ...................................................................... 31
Call Diverting ........................................................................... 41
Call Waiting ............................................................................. 50
Daylight Saving Adjustment ...................................................... 45
Dialled Calls Review and Call .................................................... 30
Display Language Selection ...................................................... 49
DTMF Sending ......................................................................... 15
Earpiece Volume Setting ........................................................... 47
Emergency Call ........................................................................ 15
Fixed Dialling ........................................................................... 58
Greeting Message Display ........................................................ 49
Information message ................................................................ 38
International Call ..................................................................... 15
International Roaming Service .................................................. 51
Key Lock Function .................................................................... 16
Key Tone Volume Setting .......................................................... 47
Keys ........................................................................................ 46
Memory Space Review ............................................................. 28
Microphone Mute .................................................................... 17
Missed Calls Review and Call .................................................... 29
Multiparty Call ......................................................................... 19
Network Settings ..................................................................... 52
Own Number ........................................................................... 49
Phone Book Operation ............................................................. 25
Placing Calls ............................................................................ 14
Recieved Calls Review and Call ................................................. 29
Receiving Calls ......................................................................... 16
Ringing Tone Selection ............................................................. 47
Scratch Pad Memory ................................................................ 18
Short Message Service .............................................................. 33
SIM Card ................................................................................. 10
SIM Card Lock ......................................................................... 54
Speed Dialling .......................................................................... 28
Time Zone Setting .................................................................... 45
Using T9 Predictive Text Input ................................................... 36
Voicemail Settings .................................................................... 38
CEL GDU325 (Cov.2-3) Eng.pm6 8/2/01, 10:06 AM1
![](/img.php?id=141224&img=bg3.png)
1
Table of Contents
1. Introduction........................................................ 4
Important Information ................................................. 4
2. Your Phone ......................................................... 8
Keypad Names and Funcwcons ...................................... 8
LCD Display ................................................................. 9
Wrist Strap Attachment ............................................... 9
3. Getting Started ................................................ 10
SIM Card ................................................................... 10
Battery Operation ...................................................... 12
4. Basic Operation ................................................ 14
Turning your Phone On and Off ................................. 14
Selecting a Mode ....................................................... 14
Placing Calls .............................................................. 14
Receiving Calls ........................................................... 16
Key Lock Function ( + ) .................................... 16
Useful Information During Calls ................................. 17
Multiparty Call ........................................................... 19
5. Using the Menu ............................................... 21
Accessing a Menu Function by Scrolling ..................... 21
Accessing a Menu Function by Shortcut ..................... 22
Exiting a Menu Function ............................................ 22
Using the Soft Keys ................................................... 22
List of Menu Map ...................................................... 23
6. Phone Book Operation (MENU 1) ................... 25
Dialling From Your Phone Book (MENU 1-1 / ) ... 25
Editing Your Phone Book (MENU 1-1 / ) ............ 26
Deleting an Entry From Your Phone Book
(MENU 1-1 / ) ............................................................
26
New Entry In Your Phone Book (MENU 1-2) ............... 26
Additional Entry In Your Phone Book (MENU 1-2) ...... 27
Setting (MENU 1-3) ................................................... 27
Speed Dialling ........................................................... 28
7. Recent Calls Menu Operation (MENU 2) ........ 29
Missed Calls Review and Call (MENU 2-1) .................. 29
Received Calls Review and Call (MENU 2-2) ............... 29
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:09 AM1
![](/img.php?id=141224&img=bg4.png)
2
Dialled Calls Review and Call (MENU 2-3) .................. 30
Deleting Stored Numbers (MENU 2-4) ........................ 31
Call Timer Review (MENU 2-5) ................................... 31
Call Cost Review (MENU 2-6) ..................................... 31
8. Messages (MENU 3) ......................................... 33
Short Message Service ............................................... 33
Reading Messages (MENU 3-1) .................................. 33
Editing Incoming Messages (MENU 3-1 / ) ......... 33
Deleting Incoming Messages (MENU 3-1 / ) ...... 34
Forwarding Incoming Messages (MENU 3-1 / )..34
Text Reply (MENU 3-1 / ) ................................... 34
Voice Call (MENU 3-1 / ) ................................... 34
Extracting Numbers from Incoming Messages
(MENU 3-1 / ) .................................................. 35
Reviewing Outgoing Messages (MENU 3-2 / ) ... 35
Editing Outgoing Messages (MENU 3-2 / ) ........ 35
Deleting Outgoing Messages (MENU 3-2 / ) ...... 35
Forwarding Outgoing Messages (MENU 3-2 / ).. 35
Extracting Numbers from Outgoing Messages
(MENU 3-2 / ) .................................................. 35
Using T9 Predictive Text Input .................................... 36
Creating a Short Message (MENU 3-3) ....................... 37
Message Settings (MENU 3-4) .................................... 37
Voicemail (MENU 3-5)................................................ 38
Information message (MENU 3-6) .............................. 38
9. Call Diverting (MENU 4) .................................. 41
Divert All Calls (MENU 4-1) ........................................ 41
Divert when your phone is busy (MENU 4-2) .............. 42
Divert when you do not answer (MENU 4-3) .............. 42
Divert when your phone is out of range (MENU 4-4).. 42
Cancel All (MENU 4-5) ............................................... 42
10. Clock (MENU 5) ................................................ 43
Alarm Clock Settings (MENU 5-1) .............................. 43
Clock and Date Settings (MENU 5-2) ......................... 44
Time and Date Settings (MENU 5-3/5-4) .................... 45
Time Zone Setting (MENU 5-5) .................................. 45
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM2
![](/img.php?id=141224&img=bg5.png)
3
11. Audio Settings (MENU 6) ................................ 47
Ringing Tone Selection (MENU 6-1) ............................ 47
Ringing Volume Setting (MENU 6-2) .......................... 47
Earpiece Volume Setting (MENU 6-3) ......................... 47
Key Tone Volume Setting (MENU 6-4) ........................ 47
Warning Tones Selection (MENU 6-5) ......................... 47
DTMF Tones Selection (MENU 6-6) ............................. 47
Vibrating Alert Setting (MENU 6-7) ............................ 48
12. Settings (MENU 7) ............................................ 49
Phone Settings (MENU 7-1) ....................................... 49
Call Settings (MENU 7-2) ........................................... 50
Network Settings (MENU 7-3) .................................... 52
Restoring to Original Settings (MENU 7-4) ................. 53
13. Security Settings (MENU 8) ............................. 54
SIM Card Lock Settings (MENU 8-1) ........................... 54
Handset Lock Settings (MENU 8-2) ............................ 55
Handset Call Barring (MENU 8-3) ............................... 56
Network Call Barring (MENU 8-4) .............................. 56
Fixed Dialling (MENU 8-5) .......................................... 58
14. SIM Services (MENU 9) .................................... 59
15. General Specifications ..................................... 60
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM3
![](/img.php?id=141224&img=bg6.png)
4
1. Introduction
Important Information
Read this information before using your handheld portable cellular
telephone.
Exposure to Radio Frequency Signals
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals.
In August, 1996, the Federal Communications Commission (FCC)
adopted RF exposure guidelines with safety levels for hand-held
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
ANSI C95.1 (1992)*
NCRP Report 86 (1986)
ICNIRP (1996)
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. Over 120 scientists,
engineers, and physicians from universities, government health
agencies, and industry reviewed the available body of research to
develop the ANSI Standard (C95.1).
The design of your phone complies with the FCC guidelines and
those standards.
* American National Standards Institute; National Council on
Radiation Protection and Measurements; International
Commission on Non-Ionizing Radiation Protection
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
TIPS ON EFFICIENT OPERATION : For your phone to operate most
efficiently:
• Extend your antenna fully.
• Do not touch the antenna unnecessarily when the phone is in
use. Contact with the antenna affects call quality and may cause
the phone to operate at a higher power level than otherwise
needed.
1. Introduction
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM4
![](/img.php?id=141224&img=bg7.png)
5
Driving
Check the laws and regulations on the use of wireless telephones in
the areas where you drive. Always obey them. Also, if using your
phone while driving, please:
• Give full attention to driving - - driving safely is your first
responsibility.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call if
driving conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against
the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6") inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations
of Wireless Technology Research.
Persons with pacemakers:
• Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON.
• Should not carry the phone in a breast pocket.
• Should use the ear opposite the pacemaker to minimize the
potential for interference.
• If you have any reason to suspect that interference is taking
place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids.
In the events of such interference, you may want to consult your
service provider or call the customer service line to discuss
alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so.
1. Introduction
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM5
![](/img.php?id=141224&img=bg8.png)
6
Hospitals or health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer
or its representative regarding your vehicle. You should also consult
the manufacturer of any equipment that has been added to your
vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air.
Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in areas posted: “Turn off two-way
radio”. Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or
even death.
Areas with a potentially explosive atmosphere are often but not
always clearly marked. They include fueling areas such as gasoline
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust or metal powders; and any other area where you would
normally be advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects,
including both installed or portable wireless equipment, in the area
over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates,
serious injury could result.
1. Introduction
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM6
![](/img.php?id=141224&img=bg9.png)
7
Other Restrictions
Your mobile telephone is designed for use at ambient temperatures
between –10°C and +55°C. Please note that higher or lower
temperatures can affect the proper functioning of the telephone.
1. Introduction
CEL GDU325 (p.01-20) Eng.pm6 8/2/01, 10:10 AM7
