User_Guide_v1.0_draft_Part8
![](/img.php?id=3081107&img=bg1.png)
244
!
APPLE CONFIDENTIAL
Bypass your Bluetooth device. To use the iPhone receiver or speaker for phone calls:
Answer a call by tapping the iPhone screen.
During a call, tap Audio, then choose iPhone or Speaker Phone.
Turn off the Bluetooth device, unpair it, or move out of range.
Turn off Bluetooth in Settings > Bluetooth.
Unpair a device. Go to Settings > Bluetooth, tap
next to the device, then tap Forget
this Device. If you don’t see the Devices list, make sure Bluetooth is on.
Continuity
Continuity connects iPhone with your iPad, iPod touch, and Mac so they work together
as one. You can use Handoff to start an email or document on iPhone, for example, then
pick up where you left off on your iPad or Mac. You can use Continuity to make phone
calls and send SMS and MMS text messages from your other iOS devices or Mac
computer. You can use Instant Hotspot to provide Internet access to your other iOS
devices or Mac computer. And if you shop on your Mac at a site that supports
Apple Pay, you can quickly pay with your iPhone.
Continuity requires iOS 8 or later, or OS X v10.10 or later, and works with the following:
iPhone 5 and later
iPod touch (5th generation) and later
DRAFT
![](/img.php?id=3081107&img=bg2.png)
245
!
iPad Pro
APPLE CONFIDENTIAL
iPad (4th generation) and later
iPad mini and later
Supported Mac computers
For more information, go to the Use Continuity to connect your iPhone, iPad,
iPod touch, and Mac website.
Handoff
Pick up on one device where you left off on another. You can use Handoff with Mail,
Safari, Pages, Numbers, Keynote, Maps, Messages, Reminders, Calendar, Contacts, and
even some third-party apps. For Handoff to work, you must be signed in to iCloud using
the same Apple ID on all your devices, and they must be within Bluetooth range of one
another (about 33 feet or 10 meters).
Switch devices. Swipe up from the bottom-left edge of the Lock screen (where you see
the app’s activity icon), or go to the multitasking screen, then tap the app. On your Mac,
open the app you were using on your iOS device.
Tip: If you have Handoff set up, you can cut or copy something, (a word or an image,
for example), on one Apple device and paste it on another.
Disable Handoff on your devices. Go to Settings > General > Handoff & Suggested
Apps.
Disable Handoff on your Mac. Go to System Preferences > General, then turn off “Allow
Handoff between this Mac and your iCloud devices.”
Universal Clipboard
Cut or copy content (a word or an image, for example) on your iPhone, then paste it on
another iOS device or Mac computer.
For Universal Clipboard to work, you must be signed into iCloud using the same
Apple ID on all your devices and you must cut, copy, and paste your content within a
short period of time. All your devices must be connected to the same Wi-Fi network,
within Bluetooth range of one another (about 33 feet or 10 meters), and have Bluetooth
turned on.
Cut or copy. Touch and hold a word or image to display the selection options, then
choose Copy or Cut.
DRAFT
![](/img.php?id=3081107&img=bg3.png)
246
!
APPLE CONFIDENTIAL
Paste. Double tap to place an insertion point and display the selection options, then
choose Paste.
For more information about selecting text or placing the insertion point see Edit text.
Instant Hotspot
You can use Instant Hotspot to provide Internet access to your other iOS devices (iOS 8
or later) and Mac computers (OS X v10.10 or later) where you’re signed in to iCloud
using the same Apple ID. Instant Hotspot uses your iPhone Personal Hotspot, without
you having to enter a password or even turn on Personal Hotspot.
Use Instant Hotspot. Go to Settings > Wi-Fi on your other iOS device, then simply
choose your iPhone network under Personal Hotspots. On your Mac, choose your iPhone
network from your Wi-Fi settings.
When you’re not using using the hotspot, your devices disconnect to save battery life.
For more information see Personal Hotspot.
Note: This feature may not be available with all carriers. Additional fees may apply.
Contact your carrier for more information.
Personal Hotspot
Use Personal Hotspot to share your iPhone Internet connection. Computers can share
your Internet connection using Wi-Fi, Bluetooth, or a USB cable. Other iOS devices can
share the connection using Wi-Fi. Personal Hotspot works only if iPhone is connected to
the Internet over the cellular data network.
Note: This feature may not be available with all carriers. Additional fees may apply.
Contact your carrier for more information.
Share an Internet connection. Go to Settings > Cellular, then tap Personal Hotspot—if it
appears—to set up the service with your carrier.
After you turn on Personal Hotspot, other devices can connect in the following ways:
Wi-Fi: On the device, choose your iPhone from the list of available Wi-Fi networks.
USB: Connect iPhone to your computer using the cable that came with it. In your
computer’s Network preferences, choose iPhone and configure the network settings.
Bluetooth: On iPhone, go to Settings > Bluetooth, then turn on Bluetooth. To pair and
connect iPhone with your Bluetooth device, refer to the documentation that came
with your device.
DRAFT
![](/img.php?id=3081107&img=bg4.png)
247
!
APPLE CONFIDENTIAL
Note: When a device is connected, a blue band appears at the top of the iPhone screen.
The Personal Hotspot icon
appears in the status bar of iOS devices using Personal
Hotspot.
Change the Wi-Fi password for iPhone. Go to Settings > Personal Hotspot > Wi-Fi
Password, then enter a password of at least eight characters.
Change the name of your Personal Hotspot. You can change the name of your
Personal Hotspot by changing the name of your iPhone. Go to Settings > General >
About > Name.
Monitor your cellular data network usage. Go to Settings > Cellular. See Cellular data
settings.
Use iTunes to transfer files
You can transfer files between iPhone and your computer or other iOS devices with
iCloud Drive, AirDrop, or by connecting iPhone to your computer and using iTunes.
Transfer files using iTunes. Connect iPhone to your computer using the included cable.
In iTunes on your computer, select iPhone, then click Apps. Use the File Sharing section
to transfer documents between iPhone and your computer.
Apps that support file sharing appear in the File Sharing Apps list in iTunes. To delete a
file, select it in the Documents list on your computer, then press the Delete key. For
more information, go to the Apple support article About File Sharing.
You can also view files received as email attachments. See Attachments.
With some apps, you can transfer files using AirDrop. See Share files with AirDrop.
DRAFT
![](/img.php?id=3081107&img=bg5.png)
248
!
APPLE CONFIDENTIAL
CarPlay
About CarPlay
CarPlay puts key iPhone apps on your car’s built-in display. With CarPlay and your
iPhone, you can get turn-by-turn directions, make phone calls, exchange text messages,
listen to music, and more. CarPlay uses the contacts on your iPhone to help you make
calls, send texts, and find destinations.
CarPlay is available on select automobiles (go to the CarPlay available models website)
and on select after-market navigation systems. CarPlay works with iPhone 5 and later.
Note: CarPlay is available only in certain areas (go to the iOS 9 Feature Availability
website). Siri must be enabled on your iPhone. Go to Settings > General > Siri.
WARNING: For important information about avoiding distractions that could lead to
dangerous situations, see Important safety information.
You operate CarPlay using your car’s built-in controls—a touchscreen, a rotary knob
controller, or both. To learn how to operate your display, see the owner’s guide that came
with your car.
Or just use Siri voice control to tell CarPlay what you want. Without looking at or touching
iPhone, you can ask Siri to call people, select and play music, hear and compose text
messages, get directions, read your notifications, find calendar information, add
reminders, and more. (Siri often steps in automatically to help you, depending on the app
you’re using.)
Get started
If your car supports wireless CarPlay, press and hold the voice control button on your
steering wheel to start the CarPlay setup. To connect iPhone to your car’s USB port, use
an Apple-approved Lightning to USB cable. It may be labeled with the CarPlay logo, the
word CarPlay, or an image of a smartphone.
Depending on your car, the CarPlay Home screen may appear automatically.
TK New screenshot to refresh content
DRAFT
![](/img.php?id=3081107&img=bg6.png)
249
!
APPLE CONFIDENTIAL
If the CarPlay Home screen doesn’t appear, select the CarPlay logo on your car’s display.
Connect wirelessly to CarPlay. First, make sure your car supports wireless CarPlay
and is in wireless or Bluetooth pairing mode (see the owner’s guide). Then on iPhone,
go to Settings > General > CarPlay > Available Cars, and choose your car.
Speak to Siri. Press and hold the voice control button on the steering wheel, or touch
and hold the Home button on the CarPlay Home screen, until Siri beeps. Then make your
request.
Open an app. Tap the app on the touchscreen. Or twist the rotary knob to select the
app, then press down on the knob.
Return to the CarPlay Home screen. Tap the Home button on the touchscreen. Or
twist the rotary knob to select Home, then press down on the knob.
You can also press the “back” button near the rotary knob—or press and hold the
“back” button—until you get back to the Home screen.
Return to your car’s Home screen. Tap the gray icon with your car’s logo if it appears,
or press the physical Home button on your radio if your car has one.
View additional apps. If you have more than eight apps, some apps may appear on
another page of the Home screen. Swipe left on the touchscreen, or twist the rotary
knob.
Return to a phone call or to turn-by-turn directions. Tap the icon in the upper-left
corner of the touchscreen. Or twist the rotary knob to the icon, then press down on the
knob.
Scroll quickly through a list. Slide or tap the letters along the list at the right side of
the touchscreen. Or twist the rotary knob.
DRAFT
![](/img.php?id=3081107&img=bg7.png)
250
!
APPLE CONFIDENTIAL
View and control the current audio source. Select Now Playing to see the current
audio app.
Rearrange the icons on the CarPlay Home screen. When you’re not operating your car,
go to Settings > General > CarPlay on your iPhone, then select your car. Touch and hold
any icon, then drag it. To remove an icon, tap it. To add it back, tap it again. (An icon that
can be removed appears with a gray circle in its upper-left corner.)
Your icon changes appear on the CarPlay Home screen the next time you connect to
CarPlay.
Maps
Use Siri or open Maps to get turn-by-turn directions, traffic conditions, and estimated
travel time. CarPlay generates likely destinations using addresses from your email, text
messages, contacts, and calendars—as well as places you frequent. You can also search
for a location, use locations you bookmarked, and find nearby attractions and services.
You can use other apps even when getting directions. CarPlay lets you know when it’s
time to make a turn.
Ask Siri. Say something like:
“Take me home”
“Get directions to the nearest coffee shop”
“What’s my ETA?”
“Find a gas station”
Display likely destinations. Open Maps, then select Destinations. Select a destination
in the list to get directions. To get directions to a nearby service, select a category
(such as Gas, Parking, or Coffee), then select a destination. (For availability of nearby
suggestions, go to the Maps: Nearby website.)
TK New screenshot to refresh content
DRAFT
![](/img.php?id=3081107&img=bg8.png)
251
!
APPLE CONFIDENTIAL
Phone
Use Siri to help you make calls, or open Phone, then select Show Contacts to bring up
your favorites, recent calls, voicemail, a list of contacts, or a keypad.
Ask Siri. Say something like:
“Call Emily”
“Return my last call”
“What voicemails have I gotten?”
Messages
Use Siri to help you send, hear, and reply to text messages. Or, open Messages, then
select Show Messages to see a list of past conversations. Select a conversation to hear
unread messages or respond to a thread. Select
to start a new conversation.
Ask Siri. Say something like:
“Text my wife”
“Tell Emily I’m in traffic and I’ll be 15 minutes late to the meeting”
“Read my text messages”
Music
Use Siri or open Music to access your Apple Music membership, For You, New, and the
music on your iPhone—including songs, artists, albums, and playlists. Or tune in to
Radio.
TK New screenshot to refresh content
DRAFT
![](/img.php?id=3081107&img=bg9.png)
252
!
APPLE CONFIDENTIAL
Ask Siri. Say something like:
“Play,” followed by the name of the artist, album, song, playlist, or station that you
want to play. If Siri doesn’t find what you asked for, be more specific. For example,
say “play the radio station ‘Pure Pop’” rather than saying “play ‘Pure Pop.’”
“Let’s hear the Acoustic playlist”
“Play more songs like this one”
“Skip this song”
“Create a radio station based on this song”
On some systems, Music displays only a partial list of choices while you’re driving. To
choose among options not in the list, use Siri by selecting More at the bottom of the list,
or by pressing and holding the voice control button on your steering wheel.
To control playback, use Siri, the Now Playing screen, or the controls on your car’s
steering wheel.
Podcasts
Use Siri or open Podcasts to find a podcast on your iPhone and play it with CarPlay.
Ask Siri. Say something like:
“Play the Freakonomics Radio podcast”
“Skip ahead 45 seconds”
Other apps
CarPlay works with select third-party audio apps that you download to your iPhone, as
well as apps made by your car maker. Compatible apps show up automatically on the
CarPlay Home screen.
You can also use Siri with CarPlay to access many of the apps on iPhone, including
Calendar, Reminders, Clock, and more.
DRAFT
![](/img.php?id=3081107&img=bga.png)
253
!
APPLE CONFIDENTIAL
Ask Siri. Say something like:
“What’s my next meeting?”
“Remind me to pack an umbrella when
I
get home”
“Add milk to my grocery list”
“Set my alarm for 6:00 AM tomorrow”
DRAFT
![](/img.php?id=3081107&img=bgb.png)
254
!
APPLE CONFIDENTIAL
Privacy and security
Privacy
Privacy settings let you see and control which apps and system services have access to
Location Services, and to contacts, calendars, reminders, and photos.
Location Services lets location-based apps such as Reminders, Maps, Camera, and
Wallet gather and use data indicating your location. Your approximate location is
determined using available information from cellular network data, local Wi-Fi networks
(if you have Wi-Fi turned on), and GPS (may not be available in all areas). The location
data collected by Apple isn’t collected in a form that personally identifies you. When an
app is using Location Services,
appears in the status bar.
Turn Location Services on or off. Go to Settings > Privacy > Location Services. You can
turn it off for some or for all apps and services. If you turn off Location Services, you’re
asked to turn it on again the next time an app or service tries to use it.
Turn Location Services off for system services. Several system services, such as
compass calibration and location-based ads, use Location Services. To see their status,
turn them on or off, or show
in the status bar when these services use your location,
go to Settings > Privacy > Location Services > System Services.
Turn off access to private information. Go to Settings > Privacy. You can see which
apps and features have requested, and you have granted, access to private information.
You can turn off each app’s access to each of these categories of information:
Contacts
Calendars
Reminders
Photos
Bluetooth Sharing
Microphone
Camera
Health
HomeKit
DRAFT
![](/img.php?id=3081107&img=bgc.png)
255
!
Media Library
APPLE CONFIDENTIAL
Motion & Fitness
Twitter
Facebook
Review the terms and privacy policy for each third-party app to understand how it uses
the data it’s requesting. For more information, see the Apple Support article About
privacy and Location Services.
DRAFT
![](/img.php?id=3081107&img=bgd.png)
256
!
APPLE CONFIDENTIAL
Security
Use a passcode with data protection
For better security, you can set a passcode that must be entered each time you turn on
or wake up iPhone.
Set, change, or turn off the passcode. Go to Settings > Touch ID & Passcode
(iPhone 5s and later) or Settings > Passcode (other models).
To adjust when iPhone automatically locks (and then requires the passcode to unlock),
go to Settings > Display & Brightness > Auto-Lock.
Setting a passcode turns on data protection, using your passcode as a key to encrypt
Mail messages and attachments stored on iPhone, using 256-bit AES encryption. (Other
apps may also use data protection.)
Add fingerprints and set options for the Touch ID sensor. (iPhone models with
Touch ID) Go to Settings > Touch ID & Passcode. See Touch ID.
Allow access to features when iPhone is locked. Go to Settings > Touch ID &
Passcode (iPhone models with Touch ID) or Settings > Passcode (other models).
Optional features include:
Today (see Notifications)
Notifications View (see Notifications)
Reply with Message (see Messages at a glance)
Siri (if enabled; see Make requests)
Wallet (see Wallet at a glance)
Allow access to Control Center when iPhone is locked. Go to Settings > Control
Center. See Control Center.
Erase data after ten failed passcode attempts. Go to Settings > Touch ID & Passcode
(iPhone models with Touch ID) or Settings > Passcode (other models), then tap Erase
Data. After ten failed passcode attempts, all settings are reset, all your information and
media are erased, and you must restore your device from a backup or
new .
set it up again as
DRAFT
![](/img.php?id=3081107&img=bge.png)
257
!
APPLE CONFIDENTIAL
Use two-factor authentication for security
Two-factor authentication is an extra layer of security for your Apple ID designed to
ensure that all the photos, documents, and other important data you store with Apple
can be accessed only by you, and only with your devices. It’s built into iOS 9 and later,
and OS X v10.11 and later.
If your account meets all the requirements for two-factor authentication, you are
prompted to turn it on when you set up iPhone with iOS 10. If you are signed in to
iCloud, you can also turn it on by going to Settings > iCloud. Tap your account at the
top of the screen, then tap Password & Security. For more information, see the Apple
Support article Availability of two-factor authentication.
Once enrolled, when you enter your Apple ID and password for the first time on a new
device, you’re asked to verify your identity with a six-digit verification code. This code is
displayed automatically on your other devices or sent to a phone number you trust. Just
enter the code to sign in and access your information on your new device.
You won’t be asked for a verification code again on that device unless you sign out
completely, erase your device, or need to change your password for security reasons.
For more help with two-factor authentication, see the Apple Support article Two-factor
authentication for Apple ID.
Touch ID
On iPhone 5s and later, you can unlock iPhone by placing a finger on the Home button.
Touch ID also lets you:
Use your Apple ID password to make purchases in the iTunes Store, App Store, or
iBooks Store.
Authorize credit or debit card payments using Apple Pay.
Provide debit and credit card info, billing and shipping addresses, and contact info
when paying in an app that offers Apple Pay as a method of payment.
Set up the Touch ID sensor. Go to Settings > Touch ID & Passcode. Set whether you
want to use a fingerprint to unlock iPhone, and to make purchases. Tap Add a
Fingerprint, then follow the onscreen instructions. You can add multiple fingerprints
(both of your thumbs and forefingers, for example, and one for your spouse).
Note: If you turn iPhone off after setting up the Touch ID sensor, you’ll be asked to
confirm your passcode when you turn iPhone back on and unlock it the first time. You’ll
also be asked for your Apple ID password for the first purchase you make in the
iTunes Store, App Store, or iBooks Store.
DRAFT
![](/img.php?id=3081107&img=bgf.png)
258
!
APPLE CONFIDENTIAL
Delete a fingerprint. Tap the fingerprint, then tap Delete Fingerprint. If you have more
than one fingerprint, place a finger on the Home button to find out which fingerprint it is.
Name a fingerprint. Tap the fingerprint, then enter a name, such as “Thumb.”
Use the Touch ID sensor to make a payment in the iTunes Store, App Store, or
iBooks Store. When purchasing from the iTunes Store, App Store, or iBooks Store, follow
the instructions to enable purchases with your fingerprint. Or go to Settings > Touch ID &
Passcode, then turn on iTunes & App Store.
Use Touch ID for Apple Pay. Go to Settings > Touch ID & Passcode to ensure that
Apple Pay is enabled with your Touch ID. For more information about Apple Pay, go to
the Apple Pay website.
iCloud Keychain
iCloud Keychain keeps your Safari website user names and passwords, credit card
information, and Wi-Fi network information up to date across all of your approved
devices (iOS 7 or later) and Mac computers (OS X v10.9 or later). iCloud Keychain is
secured with 256-bit AES encryption during storage and transmission, and cannot be
read by Apple.
iCloud Keychain works with Safari Password Generator and AutoFill. When you’re
setting up a new account, Safari Password Generator suggests unique, hard-to-guess
passwords. You can use AutoFill to have iPhone enter your user name, password, and
credit card info automatically. To protect your personal information, set a passcode if
you turn on iCloud Keychain and AutoFill.
Note: Some websites do not support AutoFill.
iCloud Keychain can also keep the accounts you use in Mail, Contacts, Calendar, and
Messages up to date across all of your Mac computers. If you sign in to Facebook,
Twitter, Linked In, or any other accounts in Internet Accounts on OS X v10.9 or later,
iCloud can push those accounts to your Mac computers as well.
To learn more about iCloud Keychain, see the Apple Support article Frequently asked
questions website.
Set up iCloud Keychain. Go to Settings > iCloud > Keychain. Turn on iCloud Keychain,
then follow the onscreen instructions.
When you set up iCloud Keychain, you create an iCloud Security Code. You can use your
iCloud Security Code to authorize additional devices to use your iCloud Keychain. It’s
also used to verify your identity so that you can perform other iCloud Keychain actions,
such as recovering your iCloud Keychain if you lose all your devices.
DRAFT
![](/img.php?id=3081107&img=bg10.png)
259
!
APPLE CONFIDENTIAL
Set up iCloud Keychain on additional devices. Set up iCloud Keychain for each device
that you want to add. When you turn on iCloud Keychain on an additional device, your
other devices that use iCloud Keychain receive a notification requesting approval for the
additional device. After you approve the additional device, your iCloud Keychain
automatically begins updating on that device.
To approve iCloud Keychain on an additional device when you don’t have access to your
other devices, follow the onscreen instructions to use your iCloud Security Code.
Forgot your iCloud Security Code? If you enter your iCloud Security Code incorrectly
too many times, you can’t use that iCloud Keychain. You can go to the iCloud Support
website for help verifying your identity so that you can try to enter your iCloud Security
Code again. After a number of incorrect attempts, your iCloud Keychain is removed
from Apple’s servers. However, you can set up iCloud Keychain again and create a new
iCloud Security Code.
Advertising
Turn off location-based ads and offers. Go to Settings > Privacy > Location Services >
System Services, then turn off Location-Based iAds.
Reset or limit Ad Tracking. Go to Settings > Privacy > Advertising (at the bottom of the
screen). To clear the data used to determine which ads might be relevant to you, tap
Reset Advertising Identifier. To opt out of targeted advertising, turn on Limit Ad Tracking.
Note: If you turn on Limit Ad Tracking, you may still receive the same number of ads,
but they may be less relevant to you.
View the information Apple uses to deliver targeted ads. Go to Settings > Privacy >
Advertising > View Ad information. The information is used by Apple to deliver more
relevant ads in Apple News, the App Store, and Wallet. Your personal data is not provided
to other parties.
For more information, go to Settings > Privacy > Advertising > About Advertising &
Privacy.
Find My iPhone
If you misplace your iPhone, Find My iPhone can help you locate it and protect your
data. Use the Find My iPhone app on another iPhone, iPad, iPod touch, or Mac or go to
the Find My iPhone web app to locate your iPhone on a map, lock it remotely, play a
sound, display a message, or erase all its data.
Note: For more information about Find My iPhone, please refer to the Help in the app.
DRAFT
![](/img.php?id=3081107&img=bg11.png)
260
!
APPLE CONFIDENTIAL
Turn Find My iPhone on or off. Go to Settings > iCloud > Find My iPhone. (See iCloud
if you need help setting up iCloud.)
Important: To use these features, Find My iPhone must be turned on before your iPhone
is lost. iPhone must be able to connect to the Internet for you to locate and secure the
device. iPhone sends its last location prior to the battery running out when Send Last
Location is turned on in Settings > iCloud > Find My iPhone.
Use Find My iPhone. Open Find My iPhone on an iOS device, or go to the Find My
iPhone web app on your computer. Sign in, then select your device.
Play Sound: Play a sound at full volume for two minutes, even if the ringer is set to
silent.
Lost Mode: Immediately lock your missing iPhone with a passcode and display a
custom message on the screen with a contact number. Find My iPhone tracks and
reports the location of your iPhone, so you can see where it’s been.
When iPhone is in Lost Mode on devices that support Apple Pay, Find My iPhone
attempts to suspend the ability to pay with credit and debit cards used for
Apple Pay. See About Apple Pay.
Erase iPhone: Protect your privacy by erasing all the information and media on your
iPhone and restoring it to its original factory settings. On devices that support Apple
Pay, erasing iPhone also removes the ability to pay with credit and debit cards used
for Apple Pay.
Note: Before you sell or give away your iPhone, you should erase it and turn off Find My
iPhone. The next owner can then activate and use the device normally. See the Apple
Support article Sell or give away iPhone.
DRAFT
![](/img.php?id=3081107&img=bg12.png)
261
!
APPLE CONFIDENTIAL
Restart, update, reset, and restore
Restart an app or iPhone
If something isn’t working right, try restarting the problem app or iPhone.
Restart an app. If an app isn’t working properly, you can force it to quit, then try to
reopen it. (Typically, there is no reason to quit an app; quitting it doesn’t save battery
power, for example.) Double-click the Home button, then drag the app up from the app
switcher display to quit the app. Opening it again may resolve the problem.
Restart iPhone. Hold down the
Sleep/Wake button
until the slider appears. Slide your
finger across the slider to turn off iPhone. To turn iPhone back on, hold down the
Sleep/Wake button until the Apple logo appears.
Force restart iPhone. If iPhone isn’t responding, hold down the Sleep/Wake button and
the Home button at the same time for at least ten seconds, until the Apple logo
appears.
If iPhone still doesn’t respond or turn on, see the Apple Support article If your device
doesn’t respond or won’t turn on.
Update iOS software
You can update the iOS software in Settings or by using iTunes. Your data and settings
remain unchanged.
Update wirelessly on iPhone. Go to Settings > General > Software Update. iPhone
checks for available software updates.
Update software in iTunes. iTunes checks for available software updates each time
you sync your device using iTunes.
For more information, see the Apple Support articles Update the iOS software and If
you can’t update or restore your device.
Reset iPhone settings
Without erasing your content, you can return iPhone settings to their defaults. If you
want to save your settings, make a backup in iCloud or make a back up with iTunes
before resetting them.
DRAFT
![](/img.php?id=3081107&img=bg13.png)
262
!
APPLE CONFIDENTIAL
Return settings to their defaults. Go to Settings > General > Reset, then choose an
option:
Reset All Settings: All settings are reset.
Reset Network Settings: Only network settings are removed.
When you reset network settings, previously used networks and VPN settings that
weren’t installed by a configuration profile are removed. (To remove VPN settings
installed by a configuration profile, go to Settings > General > Profile, select the
profile, then tap Remove. This also removes other settings and accounts provided
by the profile.) Wi-Fi is turned off and then back on, disconnecting you from any
network you’re on. The Wi-Fi and “Ask to Join Networks” settings remain turned on.
Reset Keyboard Dictionary: You add words to the keyboard dictionary by rejecting
words iPhone suggests as you type. Resetting the keyboard dictionary erases only
the words you’ve added.
Reset Home Screen Layout: Returns the built-in apps to their original layout on the
Home screen.
Reset Location & Privacy: Resets the location services and privacy settings to their
defaults.
WARNING: If you choose the Erase All Content and Settings option, all of your content
is removed. See Erase iPhone.
Restore iPhone
Before restoring iPhone, you must create a backup of your content and settings. See
Back up iPhone with iCloud Backup and Back up iPhone with iTunes. (To reset iPhone
without restoring from a backup, see Erase iPhone.)
Erase then restore iPhone from a backup. Go to Settings > General > Reset, then tap
Erase All Content and Settings. After iPhone restarts, follow the setup assistant to
restore iPhone from an iCloud or iTunes backup.
Restore iPhone from an iTunes backup.
Connect your device to the computer you
normally sync with, then in iTunes choose File > Devices > Restore from Backup.
For more information, see the Apple Support articles Restore your device from an
iCloud or iTunes backup and If you can’t update or restore your device.
DRAFT
![](/img.php?id=3081107&img=bg14.png)
263
!
APPLE CONFIDENTIAL
Restore purchased items
You can download items purchased from the App Store, iTunes Store, and iBooks Store
again, free of charge. If you see
next to an item, you’ve already purchased it, and you
can download it again.
Restore an app. See Purchase, redeem, and download.
Restore an item from the iTunes Store. See Purchase, rent, or redeem.
Restore a book from the iBooks Store. See Organize books.
Restore an audiobook from the iBooks Store. You can download an audiobook again,
free of charge, from the Purchased list in the iBooks Store. See Listen to an audiobook.
Erase iPhone
When you delete data, it’s no longer accessible through the iPhone interface, but it isn’t
erased from iPhone. To remove all of your content and settings, such as when you sell
or give away iPhone, erase iPhone. If you want to save your content and settings, back
up your device with iCloud or back up with iTunes before erasing.
Erase iPhone (from Settings). Go to Settings > General > Reset, then tap Erase All
Content and Settings. After iPhone restarts, follow the setup assistant to set up iPhone
again as new. (From the setup assistant, you can also choose to restore iPhone from an
iCloud or iTunes backup.)
Erase iPhone using iTunes. Connect your device to a Mac or PC, open iTunes on the
computer, select iPhone in the iTunes window, then click Restore iPhone in the
Summary pane. iTunes erases all of the content and settings on iPhone and installs the
latest iOS software. After iPhone restarts, follow the setup assistant to set up iPhone as
new. (From the setup assistant, you can also choose to restore iPhone from an iCloud or
iTunes backup.)
DRAFT
![](/img.php?id=3081107&img=bg15.png)
264
!
APPLE CONFIDENTIAL
Accessibility
Accessibility features
iPhone offers many accessibility features:
Vision
VoiceOver
Support for braille displays
Zoom
Magnifier
Set display accommodations
Speak Selection
Speak Screen
Typing feedback
Large, bold, and high-contrast text
Button Shapes
Reduce screen motion
On/off switch labels
Assignable ringtones and vibrations
Audio Descriptions
DRAFT
![](/img.php?id=3081107&img=bg16.png)
265
!
Hearing
Hearing aids
APPLE CONFIDENTIAL
Built-in TTY software
Call audio routing
Phone noise cancelation
LED Flash for Alerts
Mono audio and balance
Subtitles and closed captions
Interaction
Siri
3D Touch
Reachability
Widescreen keyboards
Guided Access
Switch Control
AssistiveTouch
Touch Accommodations
Software and hardware keyboards
Turn on accessibility features. You can turn on many accessibility features just by
asking Siri (“turn on VoiceOver,” for example). See Siri and Make requests. Or go to
Settings > General > Accessibility, or use the Accessibility Shortcut. See Accessibility
Shortcut.
Use iTunes on your computer to configure accessibility on iPhone. In iTunes you can
enable a limited number of accessibility features, including VoiceOver, zoom, invert
colors, speak auto-text, mono audio, and show closed captions where available. Click
Summary, then click Configure Accessibility at the bottom of the Summary screen.
For more information about iPhone accessibility features, go to the Apple Accessibility
website.
DRAFT
![](/img.php?id=3081107&img=bg17.png)
266
!
APPLE CONFIDENTIAL
Accessibility Shortcut
Enable the Accessibility Shortcut. Go to Settings > General > Accessibility, tap
Accessibility Shortcut, then choose a shortcut.
After setting up an accessibility shortcut, triple-click the Home button to engage the
associated feature. Features include:
Touch Accommodations
VoiceOver
Invert Colors
Zoom
Color Filters
Magnifier
Switch Control
AssistiveTouch
Guided Access (The shortcut starts Guided Access if it’s already turned on. See .)
Hearing Aid Control (if you have paired Made for iPhone hearing aids)
Slow down the double-click or triple-click speed for the Home button. Go to
Settings > General > Accessibility > Home Button.
Adjust the click sensitivity for the Home button. (2016 IPHONE and 2016
IPHONE PLUS) Go to
Settings > General > Accessibility > Home Button. You can adjust the force needed to
click the Home button.
DRAFT
![](/img.php?id=3081107&img=bg18.png)
267
!
APPLE CONFIDENTIAL
VoiceOver
VoiceOver
VoiceOver describes aloud what appears onscreen, so that you can use iPhone without
seeing its screen.
VoiceOver tells you about each item you select. The VoiceOver cursor (a black outline)
encloses the item and VoiceOver speaks its name or describes it.
Touch the screen or drag your finger over it to hear the items on the screen. When you
select text, VoiceOver reads the text. If you turn on Speak Hints, VoiceOver may tell you
the name of the item and provide instructions—for example, “double-tap to open.” To
interact with items, such as buttons and links, use the gestures described in Learn
VoiceOver gestures.
When you go to a new screen, VoiceOver plays a sound, then selects and speaks the first
item on the screen (typically in the upper-left corner). It lets you know when the display
changes to landscape or portrait orientation, when the screen becomes dimmed or
locked, and is active on the Lock screen when you wake iPhone.
Note: VoiceOver is available in many languages. Go to Settings > General > Language &
Region to choose a language.
Use iPhone with VoiceOver
Turn VoiceOver on or off. Press and hold the Home button and tell Siri “turn VoiceOver
on.” To turn VoiceOver off, tell Siri “turn VoiceOver off.” You can also go to Settings >
General > Accessibility > VoiceOver, or use the Accessibility Shortcut. See Accessibility
Shortcut.
Unlock iPhone. Press either the Sleep/Wake or Home button, tap the slider to focus on
it, then double-tap the screen. On iPhone 5s and later, you can unlock iPhone by placing
your finger on the Home button if you set up Touch ID. See Home button.
Enter your passcode silently. To avoid having your passcode spoken as you enter it,
use handwriting; see Write with your finger.
Open an app, toggle a switch, or tap an item. Select the item, then double-tap the
screen.
Double-tap the selected item. To invoke a command normally executed by tapping
twice on the screen—selecting a word or zooming an image, for example—tap three
times.
DRAFT
![](/img.php?id=3081107&img=bg19.png)
268
!
APPLE CONFIDENTIAL
Adjust a slider. Select the slider, then swipe up or down with one finger.
Use a standard gesture. Double-tap and hold your finger on the screen until you hear
three rising tones, then make the gesture. When you lift your finger, VoiceOver gestures
resume. For example, to drag a volume slider with your finger instead of swiping up and
down, select the slider, double-tap and hold, wait for the three tones, then slide left or
right.
Scroll a list or area of the screen. Swipe up or down with three fingers.
Scroll continuously through a list: Double-tap and hold until you hear three rising
tones, then drag up or down.
Use the list index: Some lists have an alphabetical table index along the right side.
Select the index, then swipe up or down to move through the index. You can also
double-tap, hold, then slide your finger up or down.
Reorder a list: You can change the order of items in some lists, such as the Rotor
items in Accessibility settings. Select the reorder icon ( ) to the right of an item,
double-tap and hold until you hear three rising tones, then drag up or down.
Open Notification Center. Select any item in the status bar, then swipe down with three
fingers. To dismiss Notification Center, do a two-finger scrub (move two fingers back and
forth three times quickly, making a “z”) or press the Home button.
Open Control Center. Select any item in the status bar, then swipe up with three fingers.
To dismiss Control Center, do a two-finger scrub or press the Home button.
Switch apps. Double-click the Home button to display open apps, swipe left or right
with one finger to select an app, then double-tap to switch to it. Or, set the rotor to
Actions while viewing open apps, then swipe up or down.
Rearrange your Home screen. Select an icon on the Home screen, double-tap and hold
your finger on the screen until you hear three rising tones. The item’s relative location is
described as you drag. Lift your finger when the icon is in its new location. Drag an icon
to the edge of the screen to move it to another Home screen. You can continue to select
and move items until you press the Home button.
Speak iPhone status information. Tap the status bar at the top of the screen, then
swipe left or right to hear information about the time, battery state, Wi-Fi signal strength,
and more.
Speak notifications. Go to Settings > General > Accessibility > VoiceOver, then turn on
Always Speak Notifications. Notifications, including the text of incoming text messages,
are spoken as they occur, even if iPhone is locked. Unacknowledged notifications are
repeated when you unlock iPhone.
DRAFT
![](/img.php?id=3081107&img=bg1a.png)
269
!
APPLE CONFIDENTIAL
Turn the screen curtain on or off. Triple-tap with three fingers. When the screen
curtain is on, the screen contents are active even though the display is turned off.
Set audio routing options. Go to Settings > General > Accessibility > VoiceOver >
Audio. Device-specific options are shown if you connect additional devices.
Learn VoiceOver gestures
Important: VoiceOver changes the gestures you use to control iPhone. When VoiceOver
is on, you must use VoiceOver gestures to operate iPhone—even to turn VoiceOver off.
When VoiceOver is on, standard touchscreen gestures have different effects, and
additional gestures let you move around the screen and control individual items.
VoiceOver gestures include two-, three-, and four-finger taps and swipes. For best
results using multifinger gestures, let your fingers touch the screen with some space
between them.
You can use different techniques to perform VoiceOver gestures. For example, you can
perform a two-finger tap using two fingers on one hand, or one finger on each hand. You
can even use your thumbs. Some people use a split-tap gesture: instead of selecting an
item and double-tapping, touch and hold an item with one finger, then tap the screen
with another finger. If your iPhone supports it, you can use 3D Touch to perform
gestures. See 3D Touch.
Try different techniques to discover which works best for you. If a gesture doesn’t work,
try a quicker movement, especially for a double-tap or swipe gesture. To swipe, try
brushing the screen quickly with your finger or fingers.
In VoiceOver settings, you can enter a special area where you can practice VoiceOver
gestures without affecting iPhone or its settings.
Practice VoiceOver gestures. Go to Settings > General > Accessibility > VoiceOver,
then tap VoiceOver Practice. When you finish practicing, tap Done. If you don’t see the
VoiceOver Practice button, make sure VoiceOver is turned on.
Here are some key VoiceOver gestures:
DRAFT
![](/img.php?id=3081107&img=bg1b.png)
270
!
APPLE CONFIDENTIAL
Navigate and read
Tap: Select and speak the item.
Swipe right or left: Select the next or previous item.
Swipe up or down: Depends on the rotor setting. See Use the VoiceOver rotor.
Two-finger swipe up: Read all from the top of the screen.
Two-finger swipe down: Read all from the current position.
Two-finger tap: Stop or resume speaking.
Two-finger scrub: Move two fingers back and forth three times quickly (making a “z”)
to dismiss an alert or go back to the previous screen.
Three-finger swipe up or down: Scroll one page at a time.
Three-finger swipe right or left: Go to the next or previous page (on the Home
screen, for example).
Three-finger tap: Speak additional information, such as position within a list or
whether text is selected.
Four-finger tap at top of screen: Select the first item on the page.
Four-finger tap at bottom of screen: Select the last item on the page.
DRAFT
![](/img.php?id=3081107&img=bg1c.png)
271
!
Activate
APPLE CONFIDENTIAL
Double-tap: Activate the selected item.
Triple-tap: Double-tap an item.
Split-tap: As an alternative to selecting an item and double-tapping to activate it,
touch an item with one finger, then tap the screen with another.
Double-tap and hold (1 second) + standard gesture: Use a standard gesture. The
double-tap and hold gesture tells iPhone to interpret the next gesture as standard.
For example, you can double-tap and hold your finger on the screen until you hear
three rising tones, and then without lifting your finger, drag your finger to slide a
switch.
Two-finger double-tap: This gesture initiates an action or halts or pauses an action in
progress. For example, you can:
Answer or end a call.
Play or pause in Music, Videos, Voice Memos, or Photos (slideshows).
Take a photo in Camera.
Start or pause recording in Camera or Voice Memos.
Start or stop the stopwatch.
Two-finger double-tap and hold: Change an item’s label to make it easier to find.
Two-finger triple-tap: Open the Item Chooser.
Three-finger double-tap: Mute or unmute VoiceOver.
Three-finger triple-tap: Turn the screen curtain on or off.
Use the VoiceOver rotor
Use the rotor to choose what happens when you swipe up or down with VoiceOver
turned on, or to select special input methods such as Braille Screen Input or Handwriting.
Operate the rotor. Rotate two fingers on the screen around a point between them.
DRAFT
![](/img.php?id=3081107&img=bg1d.png)
272
!
APPLE CONFIDENTIAL
Choose your rotor options. Go to Settings > General > Accessibility > VoiceOver >
Rotor, then select the options you want to include in the rotor.
The available rotor options and their effects depend on what you’re doing. For example, if
you’re reading an email, you can use the rotor to switch between hearing text spoken
word-by-word or character-by-character when you swipe up or down. If you’re browsing
a webpage, you can set the rotor to speak all the text (either word-by-word or character-
by-character), or to jump from one item to another of a certain type, such as headers or
links.
When you use an Apple Wireless Keyboard to control VoiceOver, the rotor lets you adjust
settings such as volume, speech rate, use of pitch or phonetics, typing echo, and reading
of punctuation. See Use VoiceOver with an Apple Wireless Keyboard.
VoiceOver basics
Explore. Drag your finger over the screen. VoiceOver speaks each item you touch. Lift
your finger to leave an item selected.
Select an item: Tap once to select an item, double-tap to invoke it.
Select the next or previous item: Swipe right or left with one finger. Item order is left-
to-right, top-to-bottom.
Select the item above or below: Set the rotor to Vertical Navigation, then swipe up or
down with one finger. If you don’t find Vertical Navigation in the rotor, you can add it;
see Use the VoiceOver rotor.
Select the first or last item on the screen: Tap with four fingers at the top or bottom
of the screen.
Select an item by name: Triple-tap with two fingers anywhere on the screen to open
the Item Chooser. Then type a name in the search field, or swipe right or left to move
through the list alphabetically, or tap the table index to the right of the list and swipe
up or down to move quickly through the list of items. You can also use handwriting to
select an item by writing its name; see Write with your finger. To dismiss the Item
Chooser without making a selection, double-tap.
Change an item’s name so it’s easier to find: Select the item, then double-tap and
hold with two fingers anywhere on the screen.
Speak the text of the selected item: Set the rotor to characters or words, then swipe
down or up with one finger. See Use the VoiceOver rotor.
Hear additional detail about using a button or feature: Go to Settings > General >
Accessibility > VoiceOver, then turn Speak Hints on or off.
DRAFT
![](/img.php?id=3081107&img=bg1e.png)
273
!
APPLE CONFIDENTIAL
Use phonetic spelling: Go to Settings > General > Accessibility > VoiceOver >
Phonetic Feedback.
Speak the entire screen, from the top: Swipe up with two fingers.
Speak from the current item to the bottom of the screen: Swipe down with two
fingers.
Pause speaking: Tap once with two fingers. Tap again with two fingers to resume, or
select another item.
Mute VoiceOver: Double-tap with three fingers; repeat to unmute. If you’re using an
external keyboard, press the Control key.
Silence sound effects: Go to Settings > General > Accessibility > VoiceOver, then turn
off Use Sound Effects.
Use a larger VoiceOver cursor. Go to Settings > General > Accessibility > VoiceOver,
then turn on Large Cursor.
Adjust the speaking voice. You can adjust the VoiceOver speaking voice:
Change the volume: Use the volume buttons on iPhone. You can also add volume to
the rotor, then swipe up and down to adjust; see Use the VoiceOver rotor.
Change the speech rate: Go to Settings > General > Accessibility > VoiceOver, then
drag the Speaking Rate slider. You can also set the rotor to Speech Rate, then swipe
up or down to adjust.
Use pitch change: VoiceOver uses a higher pitch when speaking the first item of a
group (such as a list or table) and a lower pitch when speaking the last item of a
group. Go to Settings > General > Accessibility > VoiceOver.
Speak punctuation: Set the rotor to Punctuation, then swipe up or down to select how
much you want to hear.
Control audio ducking: To choose whether audio that’s playing is turned down while
VoiceOver speaks, set the rotor to Audio Ducking, then swipe up or down.
Change the language for iPhone: Go to Settings > General > Language & Region.
VoiceOver pronunciation of some languages is affected by the Region Format you
choose there.
Change pronunciation: Set the rotor to Language, then swipe up or down. Language
is available in the rotor only if you select more than one pronunciation in Settings >
General > Accessibility > VoiceOver > Speech > Rotor Languages.
DRAFT
![](/img.php?id=3081107&img=bg1f.png)
274
!
APPLE CONFIDENTIAL
Choose which dialects are available in the rotor: Go to Settings > General >
Accessibility > VoiceOver > Speech > Rotor Languages. To adjust voice quality or
speaking rate, tap a language. To remove languages from the rotor or change their
order, tap Edit, tap the Delete button or drag ( ) up or down, then tap Done.
Set the default voice for the current iPhone language: Go to Settings > General >
Accessibility > VoiceOver > Speech.
Download an enhanced quality reading voice: Go to Settings > General >
Accessibility > VoiceOver > Speech, tap a language, then choose an enhanced voice.
By default, VoiceOver uses the Siri voice. If you’re using English, you can choose to
download Alex (869 MB), the same high-quality U.S. English voice used for
VoiceOver on Mac computers.
Specify the pronunciation of certain words: Go to Settings > General > Accessibility >
VoiceOver > Speech > Pronunciations. Tap , enter a phrase, then dictate or spell
out how you want the phrase to be pronounced.
Use the onscreen keyboard
When you activate an editable text field, the onscreen keyboard appears (unless you
have an Apple Wireless Keyboard attached).
Activate a text field. Select the text field, then double-tap. The insertion point and the
onscreen keyboard appear.
Choose a typing style. Go to Settings > General > Accessibility > VoiceOver > Typing
Style. Or, set the rotor to Typing Mode, then swipe up or down.
Enter text. Type characters using the onscreen keyboard:
Standard typing: Select a key on the keyboard by swiping left or right, then double-
tap to enter the character. Or move your finger around the keyboard to select a key
and, while continuing to touch the key with one finger, tap the screen with another
finger. VoiceOver speaks the key when it’s selected, and again when the character is
entered.
Touch typing: Touch a key on the keyboard to select it, then lift your finger to enter
the character. If you touch the wrong key, slide your finger to the key you want.
VoiceOver speaks the character for each key as you touch it, but doesn’t enter a
character until you lift your finger.
Direct Touch typing: VoiceOver is disabled for the keyboard only, so you can type just
as you do when VoiceOver is off.
DRAFT
![](/img.php?id=3081107&img=bg20.png)
275
!
APPLE CONFIDENTIAL
Move the insertion point. Swipe up or down to move the insertion point forward or
backward in the text. Use the rotor to choose whether you want to move the insertion
point by character, by word, or by line. To jump to the beginning or end, double-tap the
text.
VoiceOver makes a sound when the insertion point moves, and speaks the character,
word, or line that the insertion point moves across. When moving forward by words, the
insertion point is placed at the end of each word, before the space or punctuation that
follows. When moving backward, the insertion point is placed at the end of the preceding
word, before the space or punctuation that follows it.
Move the insertion point past the punctuation at the end of a word or sentence. Use
the rotor to switch back to character mode.
When moving the insertion point by line, VoiceOver speaks each line as you move across
it. When moving forward, the insertion point is placed at the beginning of the next line
(except when you reach the last line of a paragraph, when the insertion point is moved to
the end of the line just spoken). When moving backward, the insertion point is placed at
the beginning of the line that’s spoken.
Change typing feedback. By default, VoiceOver speaks characters as well as words
when you type. To hear no feedback, hear characters only, or hear words only, go to
Settings > General > Accessibility > VoiceOver > Typing Feedback, then choose an
option.
Use phonetics in typing feedback. Go to Settings > General > Accessibility >
VoiceOver > Phonetic Feedback. Text is read character by character. VoiceOver first
speaks the character, then its phonetic equivalent—for example, “f” and then “foxtrot.”
Delete a character. Use
with any of the VoiceOver typing styles. VoiceOver speaks
each character as it’s deleted. If Use Pitch Change is turned on, VoiceOver speaks
deleted characters in a lower pitch.
Select text. Set the rotor to Edit, swipe up or down to choose Select or Select All, then
double-tap. If you choose Select, the word closest to the insertion point is selected when
you double-tap. To increase or decrease the selection, do a two-finger scrub to dismiss
the pop-up menu, then pinch.
Cut, copy, or paste. Set the rotor to Edit, select the text, swipe up or down to choose
Cut, Copy, or Paste, then double-tap.
Undo. Shake iPhone, swipe left or right to choose the action to undo, then double-tap.
Enter an accented character. In standard typing style, select the plain character, then
double-tap and hold until you hear a sound indicating alternate characters have
appeared. Drag left or right to select and hear the choices. Release your finger to enter
DRAFT
276
!
APPLE CONFIDENTIAL
the current selection. In touch typing style, touch and hold a character until the alternate
characters appear.
Change the keyboard language. Set the rotor to Language, then swipe up or down.
Choose “default language” to use the language specified in Language & Region settings.
The Language rotor item appears only if you select more than one language in Settings >
General > Accessibility > VoiceOver > Speech.
Write with your finger
Handwriting mode lets you enter text by writing characters on the screen with your
finger. In addition to normal text entry, use handwriting mode to enter your iPhone
passcode silently or open apps from the Home screen.
Enter handwriting mode. Use the rotor to select Handwriting. If Handwriting isn’t in the
rotor, go to Settings > General > Accessibility > VoiceOver > Rotor, then add it.
Choose a character type. Swipe up or down with three fingers to choose lowercase,
numbers, uppercase, or punctuation.
Hear the currently selected character type. Tap with three fingers.
Enter a character. Trace the character on the screen with your finger.
Enter an alternate character. To use an alternate character (a character with an accent
or umlaut, for example), write the character, then swipe up or down with two fingers until
you hear the type of character you want.
Enter a space. Swipe right with two fingers.
Go to a new line. Swipe right with three fingers.
Delete the character before the insertion point. Swipe left with two fingers.
Select an item on the Home screen. Start writing the name of the item. If there are
multiple matches, continue to spell the name until it’s unique, or swipe up or down with
two fingers to choose from the current matches.
Enter your passcode silently. Set the rotor to Handwriting on the passcode screen,
then write the characters of your passcode.
Use a table index to skip through a long list. Select the table index to the right of the
table (for example, next to your Contacts list or in the VoiceOver Item Chooser), then
write the letter.
DRAFT
277
!
APPLE CONFIDENTIAL
Set the rotor to a web browsing element type. Write the first letter of a page element
type. For example, write “l” to have up or down swipes skip to links, or “h” to skip to
headings.
Exit handwriting mode. Do a two-finger scrub, or set the rotor to a different selection.
Type onscreen braille
With Braille Screen Input enabled, you can use your fingers to enter 6-dot or contracted
braille directly on the iPhone screen. Enter braille with iPhone laying flat in front of you
(tabletop mode), or hold iPhone with the screen facing away so your fingers curl back to
tap the screen (screen away mode).
Turn on Braille Screen Input. Use the rotor to select Braille Screen Input. If you don’t
find it in the rotor, go to Settings > General > Accessibility > VoiceOver > Rotor, then add
it.
Enter braille. Place iPhone flat in front of you or hold it with the screen facing away, then
tap the screen with one or several fingers at the same time.
Adjust entry dot positions. To move the entry dots to match your natural finger
positions, tap and lift your right three fingers all at once to position dots 4, 5, and 6,
followed immediately by your left three fingers for dots 1, 2, and 3.
Switch between 6-dot and contracted braille. Swipe to the right with three fingers. To
set the default, go to Settings > General > Accessibility > VoiceOver > Braille > Braille
Screen Input.
Enter a space. Swipe right with one finger. (In screen away mode, swipe to your right.)
Delete the previous character. Swipe left with one finger.
Move to a new line (typing). Swipe right with two fingers.
Cycle through spelling suggestions. Swipe up or down with one finger.
Select an item on the Home screen. Start entering the name of the item. If there are
multiple matches, continue to spell the name until it is unique, or swipe up or down with
one finger to select a partial match.
Open the selected app. Swipe right with two fingers.
Turn braille contractions on or off. Swipe to the right with three fingers.
Translate immediately (when contractions are enabled). Swipe down with two
fingers.
Stop entering braille. Do a two-finger scrub, or set the rotor to another setting.
DRAFT
![](/img.php?id=3081107&img=bg23.png)
278
!
APPLE CONFIDENTIAL
Use VoiceOver with an Apple Wireless Keyboard
You can control VoiceOver using an Apple Wireless Keyboard paired with iPhone. See
Use an Apple Wireless Keyboard.
Use the following VoiceOver keyboard commands to navigate the screen, select items,
read screen contents, adjust the rotor, and perform other VoiceOver actions. For the
commands, you can use the Control-Option key combination or the Caps Lock key,
abbreviated in the list that follows as “VO.” (To choose a modifier key, go to Settings >
General > Accessibility > VoiceOver > Modifier Keys.)
You can use VoiceOver Help to learn the keyboard layout and the actions associated with
various key combinations. VoiceOver Help speaks keys and keyboard commands as you
type them, without performing the associated action.
VoiceOver keyboard commands
VO = Control-Option
Turn on VoiceOver Help: VO–K
Turn off VoiceOver Help: Escape
Select the next or previous item: VO–Right Arrow or VO–Left Arrow
Double-tap to activate the selected item: VO–Space bar
Press the Home button: VO–H
Touch and hold the selected item: VO–Shift–M
Move to the status bar: VO–M
Read from the current position: VO–A
Read from the top: VO–B
Pause or resume reading: Control
Copy the last spoken text to the clipboard: VO–Shift–C
Search for text: VO–F
Mute or unmute VoiceOver: VO–S
Open Notification Center: Fn–VO–Up Arrow
Open Control Center: Fn–VO–Down Arrow
Open the Item Chooser: VO–I
DRAFT
![](/img.php?id=3081107&img=bg24.png)
279
!
APPLE CONFIDENTIAL
Change the label of the selected item: VO–/
Double-tap with two fingers: VO–”-”
Adjust the rotor: Use Quick Nav (see below)
Swipe up or down: VO–Up Arrow or VO–Down Arrow
Adjust the speech rotor: VO–Command–Left Arrow or VO–Command–Right Arrow
Adjust the setting specified by the speech rotor: VO–Command–Up Arrow or VO–
Command–Down Arrow
Turn the screen curtain on or off: VO–Shift–S
Return to the previous screen: Escape
Switch apps: Command–Tab or Command–Shift–Tab
Quick Nav
Turn on Quick Nav to control VoiceOver using the arrow keys.
Turn Quick Nav on or off: Left Arrow–Right Arrow
Select the next or previous item: Right Arrow or Left Arrow
Select the next or previous item specified by the rotor: Up Arrow or Down Arrow
Select the first or last item: Control–Up Arrow or Control–Down Arrow
Tap an item: Up Arrow–Down Arrow
Scroll up, down, left, or right: Option–Up Arrow, Option–Down Arrow, Option–Left
Arrow, or Option–Right Arrow
Adjust the rotor: Up Arrow–Left Arrow or Up Arrow–Right Arrow
You can also use the number keys on an Apple Wireless Keyboard to dial a phone number
in Phone or enter numbers in Calculator.
Single-key Quick Nav for web browsing
When you view a webpage with Quick Nav on, you can use the following keys on the
keyboard to navigate the page quickly. Typing the key moves to the next item of the
indicated type. To move to the previous item, hold the Shift key as you type the letter.
Turn on Single-key Quick Nav: VO-Q
Heading: H
DRAFT
![](/img.php?id=3081107&img=bg25.png)
289
!
Link: L
APPLE CONFIDENTIAL
Text field: R
Button: B
Form control: C
Image: I
Table: T
Static text: S
ARIA landmark: W
List: X
Item of the same type: M
Level 1 heading: 1
Level 2 heading: 2
Level 3 heading: 3
Level 4 heading: 4
Level 5 heading: 5
Level 6 heading: 6
Text editing
Use these commands (with Quick Nav turned off) to work with text. VoiceOver reads the
text as you move the insertion point.
Go forward or back one character: Right Arrow or Left Arrow
Go forward or back one word: Option–Right Arrow or Option–Left Arrow
Go up or down one line: Up Arrow or Down Arrow
Go to the beginning or end of the line: Command–Left Arrow or Command–Down
Arrow
Go to the beginning or end of the paragraph: Option–Up Arrow or Option–Down
Arrow
Go to the previous or next paragraph: Option–Up Arrow or Option–Down Arrow
DRAFT
![](/img.php?id=3081107&img=bg26.png)
281
!
APPLE CONFIDENTIAL
Go to the top or bottom of the text field: Command–Up Arrow or Command–Down
Arrow
Select text as you move: Shift + any of the insertion point movement commands
above
Select all text: Command–A
Copy, cut, or paste the selected text: Command–C, Command–X, or Command–V
Undo or redo last change: Command–Z or Shift–Command–Z
Support for braille displays
You can use a Bluetooth braille display to read VoiceOver output, and you can use a
braille display with input keys and other controls to control iPhone when VoiceOver is
turned on. For a list of supported braille displays, go to the Braille Displays for iOS
website.
Connect a braille display. Turn on the display, then go to Settings > Bluetooth and turn
on Bluetooth. Then, go to Settings > General > Accessibility > VoiceOver > Braille and
choose the display.
Adjust Braille settings. Go to Settings > General > Accessibility > VoiceOver > Braille,
where you can:
Choose contracted, uncontracted 8-dot, or uncontracted 6-dot braille input or
output
Turn on the status cell and choose its location
Turn on Nemeth code for equations
Display the onscreen keyboard
Choose to have the page turned automatically when panning
Change the braille translation from Unified English
Change the alert display duration
For information about common braille commands for VoiceOver navigation, and for
information specific to certain displays, see the Apple Support article Common braille
commands for VoiceOver navigation using iPhone, iPad, and iPod touch.
Set the language for VoiceOver. Go to Settings > General > Language & Region.
DRAFT
![](/img.php?id=3081107&img=bg27.png)
282
!
APPLE CONFIDENTIAL
If you change the language for iPhone, you may need to reset the language for VoiceOver
and your braille display.
You can set the leftmost or rightmost cell of your braille display to provide system status
and other information. For example:
Announcement History contains an unread message
The current Announcement History message hasn’t been read
VoiceOver speech is muted
The iPhone battery is low (less than 20% charge)
iPhone is in landscape orientation
The screen display is turned off
The current line contains additional text to the left
The current line contains additional text to the right
Set the leftmost or rightmost cell to display status information. Go to Settings >
General > Accessibility > VoiceOver > Braille > Status Cell, then tap Left or Right.
See an expanded description of the status cell. On your braille display, press the
status cell’s router button.
Make phone calls with VoiceOver
Answer or end a call. Double-tap the screen with two fingers.
When a phone call is established with VoiceOver on, the screen displays the numeric
keypad by default, instead of showing call options.
Display call options. Select the Hide Keypad button in the lower-right corner and
double-tap.
Display the numeric keypad again. Select the Keypad button near the center of the
screen and double-tap.
Note: You may find it easier to use Siri. Tell Siri the phone number you want to call (“Call
555-555-1212”) or ask to call a contact (“Call John Appleseed”).
Read math equations
VoiceOver can read aloud math equations encoded using:
DRAFT
![](/img.php?id=3081107&img=bg28.png)
283
!
APPLE CONFIDENTIAL
MathML on the web
MathML or LaTeX in iBooks Author
Hear an equation. Have VoiceOver read the text as usual. VoiceOver says “math” before
it starts reading an equation.
Explore the equation. Double-tap the selected equation to display it full screen and
move through it one element at a time. Swipe left or right to read elements of the
equation. Use the rotor to select Symbols, Small Expressions, Medium Expressions, or
Large Expressions, then swipe up or down to hear the next element of that size. You can
continue to double-tap the selected element to “drill down” into the equation to focus on
the selected element, then swipe left or right, up or down to read one part at a time.
Equations read by VoiceOver can also be output to a braille device using Nemeth code,
as well as the codes used by Unified English Braille, British English, French, and Greek.
See Support for braille displays.
Use VoiceOver with Safari
Search the web. Select the search field, double-tap to invoke the keyboard, enter your
search, then swipe right or left to move down or up the list of suggested search phrases.
Then double-tap the screen to search the web using the selected phrase.
Skip to the next page element of a particular type. Set the rotor to the element type—
such as headings, links, and form controls—then swipe up or down.
Set the rotor options for web browsing. Go to Settings > General > Accessibility >
VoiceOver > Rotor. Tap to select or deselect options, or drag the reorder icon ( ) up or
down to reposition an item.
Skip images while navigating. Go to Settings > General > Accessibility > VoiceOver >
Navigate Images. You can choose to skip all images or only those without descriptions.
Reduce page clutter for easier reading and navigation. Select the Reader item in the
Safari address field (not available for all pages).
If you pair an Apple Wireless Keyboard with iPhone, you can use single-key Quick Nav
commands to navigate webpages. See Use VoiceOver with an Apple Wireless Keyboard.
Use VoiceOver with Maps
You can use VoiceOver to explore a region, browse points of interest, follow roads, zoom
in or out, select a pin, or get information about a location.
DRAFT
284
!
APPLE CONFIDENTIAL
Explore the map. Drag your finger around the screen, or swipe left or right to move to
another item.
Zoom in or out. Select the map, set the rotor to Zoom, then swipe down or up with one
finger.
Pan the map. Swipe with three fingers.
Browse visible points of interest. Set the rotor to Points of Interest, then swipe up or
down with one finger.
Follow a road. Hold your finger down on the road, wait until you hear “pause to follow,”
then move your finger along the road while listening to the guide tone. The pitch
increases when you stray from the road.
Select a pin. Touch a pin, or swipe left or right to select the pin.
Get information about a location. With a pin selected, double-tap to display the
information flag. Swipe left or right to select the More Info button, then double-tap to
display the information page.
Hear location cues as you move about. Turn on Tracking With Heading in Maps to hear
street names and points of interest as you approach them.
Edit videos and voice memos with VoiceOver
You can use VoiceOver gestures to trim Camera videos and Voice Memo recordings.
Trim a video. While viewing a video in Photos, double-tap the screen to display the
video controls, then select the beginning or end of the trim tool. Then swipe up to drag
to the right, or swipe down to drag to the left. VoiceOver announces the amount of time
the current position will trim from the recording. To complete the trim, select Trim, then
double-tap.
Trim a voice memo. Select the memo in Voice Memos, tap Edit, then tap Start Trimming.
Select the beginning or end of the selection, double-tap and hold, then drag to adjust.
VoiceOver announces the amount of time the current position will trim from the
recording. Tap Play to preview the trimmed recording. When you’ve got it the way you
want it, tap Trim.
DRAFT
285
!
Zoom
APPLE CONFIDENTIAL
Many apps let you zoom in or out on specific items. For example, you can double-tap or
pinch to look closer in Photos or expand webpage columns in Safari. There’s also a
general Zoom feature that lets you magnify the screen no matter what you’re doing. You
can zoom the entire screen (Full Screen Zoom) or zoom part of the screen in a resizable
window and leave the rest of the screen unmagnified (Window Zoom). And, you can use
Zoom together with VoiceOver.
Turn Zoom on or off. Go to Settings > General > Accessibility, then turn Zoom on or off.
Or use the Accessibility Shortcut. See Accessibility Shortcut.
Zoom in or out. With Zoom turned on, double-tap the screen with three fingers.
Adjust the magnification. Double-tap with three fingers, then drag up or down. This
gesture is similar to a double-tap, except you don’t lift your fingers after the second tap
—instead, drag your fingers on the screen. You can also triple-tap with three fingers,
then drag the Zoom Level slider in the zoom controls that appear. To limit the maximum
magnification, go to Settings > General > Accessibility > Zoom, then drag the Maximum
Zoom Level slider all the way to the left.
Pan to see more. Drag the screen with three fingers. Or, hold your finger near the edge
of the screen to pan to that side. Move your finger closer to the edge to pan more
quickly.
Switch between Full Screen Zoom and Window Zoom. Triple-tap with three fingers,
then tap Window Zoom or Full Screen Zoom in the zoom controls that appear. To choose
the mode that’s used when you turn on Zoom, go to Settings > General > Accessibility >
Zoom > Zoom Region.
Resize the zoom window (Window Zoom). Triple-tap with three fingers, tap Resize
Lens, then drag any of the round handles that appear.
Move the zoom window (Window Zoom). Drag the handle at the bottom of the zoom
window.
Show the zoom controller. Go to Settings > General > Accessibility > Zoom, then turn
on Show Controller, or triple-tap with three fingers, then choose Show Controller. Then
you can double-tap the floating Zoom Controls button to zoom in or out, single-tap the
button to display the zoom controls, or drag it to pan. To move the Zoom Controls
button, touch and hold the button, then drag it to a new location. To adjust the
transparency of the zoom controller, go to Settings > General > Accessibility > Zoom >
Idle Visibility.
DRAFT
![](/img.php?id=3081107&img=bg2b.png)
286
!
APPLE CONFIDENTIAL
Have Zoom track your selections or the text insertion point. Go to Settings >
General > Accessibility > Zoom, then turn on Follow Focus. Then, for example, if you use
VoiceOver, the zoom window magnifies each element on the screen as you select it.
Zoom in on your typing without magnifying the keyboard. Go to Settings > General >
Accessibility > Zoom, then turn on Follow Focus. When you zoom in while typing (in
Messages or Notes, for example), the area immediately around the text you type is
magnified while all of the keyboard remains visible. Turn on Smart Typing, and the entire
window (except the keyboard) is magnified.
Display the magnified part of the screen in grayscale or inverted color. Go to
Settings > General > Accessibility > Zoom > Zoom Filter, then choose an option. Or
triple-tap with three fingers, then tap Choose Filter in the zoom controls that appear.
While using Zoom with an Apple Wireless Keyboard, the screen image follows the
insertion point, keeping it in the center of the display. See Use an Apple Wireless
Keyboard.
If you have iPhone 6, iPhone 6 Plus, iPhone 6s, or iPhone 6s Plus, you can turn on
Display Zoom to see larger onscreen controls. Go to Settings > Display & Brightness >
View.
Magnifier
Use the magnifier to magnify objects near you.
Enable the magnifier. Go to Settings > General > Accessibility > Magnifier.
Use the magnifier. Triple-click the Home button, then choose Magnifier.
Adjust the magnification level. Drag the Zoom Level slider.
Add more light. Tap
to turn the flashlight on or off.
Lock the focus. Tap . Tap again to unlock the focus.
Freeze the frame. Tap . To adjust the magnification, drag the Zoom Level slider. To
unfreeze the frame, tap
again.
Apply color filters. Tap
. Tap the different color filters to preview their effects. To
adjust the brightness and contrast, drag the sliders. To invert the colors, tap . To
apply the currently selected filter and return to the Magnifier screen, tap
again.
Turn the magnifier off. Click the Home button.
DRAFT
![](/img.php?id=3081107&img=bg2c.png)
287
!
APPLE CONFIDENTIAL
Set display accommodations
You can invert the colors, apply color filters, or reduce the white point to make the screen
easier to read.
Invert the screen colors. Go to Settings > General > Accessibility > Display
Accommodations, then turn on Invert Colors. Or, you can triple-click the Home button,
then choose Invert Colors.
Apply color filters. Go to Settings > General > Accessibility > Display
Accommodations > Color Filters, then turn on Color Filters. Or, you can triple-click the
Home button, then choose Color Filters. Tap a filter to apply it. To adjust the intensity or
hue, drag the sliders.
Reduce the intensity of bright colors. Go to Settings > General > Accessibility >
Display Accommodations, then turn on Reduce White Point.
You can also apply these effects to only the contents of the zoom window. See Zoom.
Speak Selection
Even with VoiceOver turned off, you can have iPhone read aloud any text you select.
iPhone analyzes the text to determine the language, then reads it to you using the
appropriate pronunciation.
Turn on Speak Selection. Go to Settings > General > Accessibility > Speech. There you
can also:
Adjust the speaking rate
Choose to have individual words highlighted as they’re read
Have text read to you. Select the text, then tap Speak.
You can also have iPhone read the entire screen to you. See Speak Screen.
Speak Screen
iPhone can read the contents of the screen to you, even if you don’t use VoiceOver.
Turn on Speak Screen. Go to Settings > General > Accessibility > Speech.
Have iPhone speak the screen. Swipe down from the top of the screen with two fingers.
Use the controls that appear to pause speaking or adjust the rate.
DRAFT
![](/img.php?id=3081107&img=bg2d.png)
288
!
APPLE CONFIDENTIAL
Highlight what’s being spoken. Turn on Highlight Content (a command that appears
when you turn on Speak Screen), and the current word is highlighted as it’s spoken.
Ask Siri. Say “speak screen.”
You can also have iPhone read just text you select—see Speak Selection.
Typing feedback
As you type, iPhone can provide feedback and speak text corrections and suggestions.
You can choose to have iPhone speak each character, entire words, auto-corrections,
and auto-capitalizations. You can also enable typing predictions, where you touch and
hold each word to hear it spoken.
Typing feedback also works with VoiceOver and Zoom.
Turn on and configure typing feedback. Go to Settings > General > Accessibility >
Speech > Typing Feedback.
Large, bold, and high-contrast text
Display larger text in apps such as Settings, Calendar, Contacts, Mail, Messages,
and Notes. Go to Settings > General > Accessibility > Larger Text, then turn on Larger
Accessibility Sizes.
Display bolder text on iPhone. Go to Settings > General > Accessibility, then turn on
Bold Text.
Increase text contrast where possible. Go to Settings > General > Accessibility, then
turn on Increase Contrast.
Button Shapes
iPhone can add a colored background shape or an underline to buttons so they’re easier
to see.
Emphasize buttons. Go to Settings > General > Accessibility, then turn on Button
Shapes.
DRAFT
289
!
APPLE CONFIDENTIAL
Reduce screen motion
You can stop the movement of some screen elements, for example, the parallax effect of
icons and alerts against the wallpaper, or motion transitions.
Reduce motion. Go to Settings > General > Accessibility, then turn on Reduce Motion.
On/off switch labels
To make it easier to distinguish whether a setting is on or off, you can have iPhone show
an additional label on on/off switches.
Add switch-setting labels. Go to Settings > General > Accessibility, then turn on the
On/Off Labels switch.
Assignable ringtones and vibrations
You can assign distinctive ringtones to people in your contacts list for audible caller ID.
You can also assign vibration patterns for notifications from specific apps, for phone
calls, for FaceTime calls or messages from special contacts, and to alert you of a variety
of other events, including new voicemail, new mail, sent mail, Tweet, Facebook Post, and
reminders. Choose from existing patterns, or create new ones. See Sounds and silence.
You can purchase ringtones from the iTunes Store on iPhone. See iTunes Store at a
glance.
Audio Descriptions
Audio Descriptions provides an audible description of video scenes. If you have a video
that includes audio descriptions, iPhone can play them for you.
Hear audio descriptions. Go to Settings > General > Accessibility > Audio Descriptions,
then turn on Prefer Audio Descriptions.
Hearing aids
Made for iPhone hearing aids
If you have Made for iPhone hearing aids, you can use iPhone to adjust their settings,
stream audio, or use iPhone as a remote mic.
DRAFT
![](/img.php?id=3081107&img=bg2f.png)
290
!
APPLE CONFIDENTIAL
Pair with iPhone. If your hearing aids aren’t listed in Settings > General > Accessibility >
Hearing Aids, you need to pair them with iPhone. To start, open the battery door on each
hearing aid. Next, on iPhone, go to Settings > Bluetooth, then make sure Bluetooth is
turned on. Then go to Settings > General > Accessibility > Hearing Aids. Close the
battery doors on your hearing aids and wait until their name appears in the list of devices
(this could take a minute). When the name appears, tap it and respond to the pairing
request.
When pairing is finished, you hear a series of beeps and a tone, and a checkmark
appears next to the hearing aids in the Devices list. Pairing can take as long as 60
seconds—don’t try to stream audio or otherwise use the hearing aids until pairing is
finished.
You should only need to pair once (and your audiologist might do it for you). After that,
each time you turn your hearing aids back on, they reconnect to iPhone.
Adjust hearing aid settings and view status. Go to Settings > General > Accessibility >
Hearing Aids, or choose Hearing Aids from the Accessibility Shortcut. See Accessibility
Shortcut. Hearing aid settings appear only after you pair your hearing aids with iPhone.
For shortcut access from the Lock screen, go to Settings > General > Accessibility >
Hearing Aids, then turn on Control on Lock Screen. Use the settings to:
Check hearing aid battery status.
Adjust ambient microphone volume and equalization.
Choose which hearing aids (left, right, or both) receive streaming audio.
Control Live Listen.
Choose whether call audio and media audio are routed to the hearing aid.
Choose to play ringtones through the hearing aid. (Not all hearing aids support this
feature.)
Stream audio to your hearing aids. Stream audio from Phone, Siri, Music, Videos, and
more by choosing your hearing aids from the AirPlay menu .
Use iPhone as a remote microphone. You can use Live Listen to stream sound from the
microphone in iPhone to your hearing aids. This can help you hear better in some
situations by positioning iPhone nearer the sound source. Triple-click the Home button,
choose Hearing Aids, then tap Start Live Listen.
Use your hearing aids with more than one iOS device. If you pair your hearing aids
with more than one iOS device (both iPhone and iPad, for example), the connection for
your hearing aids automatically switches from one to the other when you do something
that generates audio on the other device, or when you receive a phone call on iPhone.
DRAFT
![](/img.php?id=3081107&img=bg30.png)
291
!
APPLE CONFIDENTIAL
Changes you make to hearing aid settings on one device are automatically sent to your
other iOS devices. To take advantage of this, all of the devices must be on the same Wi-
Fi network and signed in to iCloud using the same Apple ID.
Hearing Aid Mode
iPhone has a Hearing Aid Mode that, when activated, may reduce interference with some
hearing aid models. Hearing Aid Mode reduces the transmission power of the cellular
radio in the GSM 1900 MHz band and may result in decreased 2G cellular coverage.
Turn on Hearing Aid Mode. Go to Settings > General > Accessibility > Hearing Aids.
Hearing aid compatibility
The FCC has adopted hearing aid compatibility (HAC) rules for digital wireless phones.
These rules require certain phones to be tested and rated under the American National
Standard Institute (ANSI) C63.19-2007 or C63.19-2011 hearing aid compatibility
standards.
The ANSI standard for hearing aid compatibility contains two types of ratings:
An “M” rating for reduced radio frequency interference to enable acoustic coupling
with hearing aids that are not operating in telecoil mode
A “T” rating for inductive coupling with hearing aids operating in telecoil mode
These ratings are given on a scale from one to four, where four is the most compatible. A
phone is considered hearing aid compatible under FCC rules if it is rated M3 or M4 for
acoustic coupling and T3 or T4 for inductive coupling.
For iPhone hearing aid compatibility ratings, see the Apple Support article About Hearing
Aid Compatibility (HAC) requirements for iPhone.
Hearing aid compatibility ratings don’t guarantee that a particular hearing aid works with
a particular phone. Some hearing aids may work well with phones that don’t meet
particular ratings. To ensure interoperability between a hearing aid and a phone, try using
them together before purchase.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies it uses. However, there may be some newer wireless technologies used in
this phone that have not been tested yet for use with hearing aids. It is important to try
the different features of this phone thoroughly and in different locations, using your
hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult
your carrier or Apple for information on hearing aid compatibility. If you have questions
about return or exchange policies, consult your carrier or phone retailer.
DRAFT
![](/img.php?id=3081107&img=bg31.png)
292
!
APPLE CONFIDENTIAL
Mono audio and balance
Mono Audio combines the sound from the left and right channels into a mono signal
played on both channels. This way you can hear everything with either ear, or through
both ears with one channel set louder.
Turn on Mono Audio. Go to Settings > General > Accessibility > Mono Audio.
Adjust the balance. Go to Settings > General > Accessibility, then drag the Left Right
Stereo Balance slider.
Subtitles and closed captions
The Videos app includes an Alternate Track button
you can tap to choose subtitles
and captions offered by the video you’re watching. Standard subtitles and captions are
usually listed, but if you prefer special accessible captions, such as subtitles for the deaf
and hard of hearing (SDH), you can set iPhone to list them instead, if they’re available.
Prefer accessible subtitles and closed captions for SDH. Go to Settings > General >
Accessibility > Subtitles & Captioning, then turn on Closed Captions + SDH. This also
turns on subtitles and captions in the Videos app.
Choose from available subtitles and captions. Tap
while watching a video in
Videos.
Customize your subtitles and captions. Go to Settings > General > Accessibility >
Subtitles & Captioning > Style, where you can choose an existing caption style or create
a new style based on your choice of:
Font, size, and color
Background color and opacity
Text opacity, edge style, and highlight
Note: Not all videos include subtitles or closed captions.
Siri
Siri is often the easiest way to start using accessibility features with iPhone. With Siri,
you can open apps, turn many settings on or off (for example, VoiceOver), or use Siri for
what it does best—acting as your assistant. Siri knows when VoiceOver is on, so will
often read more information back to you than appears on the screen. You can also use
VoiceOver to read what Siri shows on the screen. See Make requests.
DRAFT
293
!
3D Touch
APPLE CONFIDENTIAL
On devices that support 3D Touch, you can control the sensitivity of 3D Touch or turn it
off.
Adjust 3D Touch sensitivity. Go to Settings > General > Accessibility, then choose
Light, Medium, or Firm sensitivity to adjust the amount of pressure needed to activate
3D Touch. Light sensitivity reduces the amount of pressure required; Firm sensitivity
increases it.
Turn off 3D Touch. Go to Settings > General > Accessibility, then turn off 3D Touch.
Reachability
Reachability helps you more easily interact with items at the top of the screen on
iPhone 6, iPhone 6 Plus, iPhone 6s, and iPhone 6s Plus.
Bring items within reach. Go to Settings > General > Accessibility, turn on Reachability,
then lightly double-tap the Home button to bring the top of the screen into reach.
Widescreen keyboards
Many apps, including Mail, Safari, Messages, Notes, and Contacts, let you rotate iPhone
when you’re typing, so you can use a larger keyboard.
Large phone keypad
Make phone calls simply by tapping entries in your contacts and favorites lists. When you
need to dial a number, the large numeric keypad on iPhone makes it easy. See Make a
call.
LED Flash for Alerts
If you can’t hear the sounds that announce incoming calls and other alerts, you can have
iPhone flash its LED (next to the camera lens on the back of iPhone). This works only
when iPhone is locked or asleep.
Note: This is a great feature for all users who, when in a loud environment, may miss the
tones associated with calls, texts, and other alerts.
Turn on LED Flash for Alerts. Go to Settings > General > Accessibility > LED Flash for
Alerts.
DRAFT
![](/img.php?id=3081107&img=bg33.png)
294
!
APPLE CONFIDENTIAL
Call audio routing
You can have the audio of incoming or outgoing calls automatically routed through a
headset or speaker phone instead of iPhone.
Reroute audio for calls. Go to Settings > General > Accessibility > Call Audio Routing,
then choose how you want to hear and speak your calls.
You can also have audio from calls routed to your hearing aids; see Hearing aids.
Phone noise cancelation
iPhone uses ambient noise cancelation to reduce background noise.
Turn noise cancelation on or off. Go to Settings > General > Accessibility > Phone
Noise Cancelation.
Guided Access
Guided Access helps an iPhone user stay focused on a task. Guided Access dedicates
iPhone to a single app, and lets you control which app features are available. Use
Guided Access to:
Temporarily restrict iPhone to a particular app
Disable areas of the screen that aren’t relevant to a task, or areas where an
accidental gesture might cause a distraction
Limit how long someone can use an app
Disable the iPhone Sleep/Wake or volume buttons
Use Guided Access. While using an app, tell Siri “turn on Guided Access” or go to
Settings > General > Accessibility > Guided Access, then turn on Guided Access. Within
the Guided Access screen you can:
Turn Guided Access on or off
Tap Passcode Settings to set a passcode that controls the use of Guided Access
(preventing someone from leaving a session), and turn on Touch ID (as a way to end
Guided Access)
Tap Time Limits to set a sound or have the remaining Guided Access time spoken
before time ends
Set whether other accessibility shortcuts are available during a session
DRAFT
![](/img.php?id=3081107&img=bg34.png)
295
!
APPLE CONFIDENTIAL
Start a Guided Access session. After turning on Guided Access, open the app you want
to run, then triple-click the Home button. Adjust settings for the session, then tap Start.
Disable app controls and areas of the app screen: Draw a circle or rectangle around
any part of the screen you want to disable. Drag the mask into position or use the
handles to adjust its size.
Enable the Sleep/Wake or volume buttons: Tap Options below Hardware Buttons.
Keep iPhone from switching from portrait to landscape or from responding to other
motions: Tap Options, then turn off Motion.
Prevent typing: Tap Options, then turn off Keyboards.
Ignore all screen touches: Turn off Touch at the bottom of the screen.
Set a session time limit: Tap Time Limit Options at the bottom of the screen.
End the session. Triple-click the Home button, then enter the Guided Access passcode,
or use Touch ID (if enabled).
DRAFT
![](/img.php?id=3081107&img=bg35.png)
296
!
APPLE CONFIDENTIAL
Switch Control
Switch Control
Switch Control lets you control iPhone using your touchscreen as a switch or using a
connected single switch or multiple switches. Use any of several methods to perform
actions such as selecting, tapping, pressing, dragging, typing, and even free-hand
drawing. Basically, you use a switch to select an item or location on the screen, and then
use the same (or different) switch to choose an action to perform on that item or
location. Three basic methods are:
Item scanning (default), which highlights different items on the screen until you
select one.
Point scanning, which lets you use scanning crosshairs to pick a screen location.
Manual selection, which lets you move from item to item on demand (requires
multiple switches).
Whichever method you use, when you select an individual item (rather than a group), a
menu appears so you can choose how to act on the selected item (tap, press, drag, or
pinch, for example).
If you use multiple switches, you can set up each switch to perform a specific action and
customize your item selection method. For example, instead of automatically scanning
screen items, you can set up switches to move to the next or previous item on demand.
You can adjust the behavior of Switch Control in a variety of ways, to suit your specific
needs and style.
Add a switch and turn on Switch Control
You can use any of these as a switch:
An external adaptive switch: Choose from a variety of popular USB or Bluetooth
switches.
The iPhone screen: Tap the screen to trigger the switch. (Or, on devices that support
3D Touch, press the screen.)
The iPhone FaceTime camera: Move your head to trigger the switch. You can use the
camera as two switches: one switch triggers when you move your head to the left,
and the other when you move your head to the right.
DRAFT
![](/img.php?id=3081107&img=bg36.png)
297
!
APPLE CONFIDENTIAL
Add a switch and choose its action. Go to Settings > General > Accessibility > Switch
Control > Switches. If you use only one switch, it is your Select Item switch by default.
If you’re adding an external switch, you need to connect it to iPhone before it will appear
in the list of available switches. Follow the instructions that came with the switch. If it
connects using Bluetooth, you need to pair it with iPhone—turn on the switch, go to
Settings > Bluetooth, tap the switch, then follow the onscreen instructions. For more
information, see Bluetooth devices.
Turn on Switch Control. Go to Settings > General > Accessibility > Switch Control, then
turn on Switch Control. Or triple-click the Home button. See Accessibility Shortcut.
Turn off Switch Control. Use any scanning method to select and tap Settings >
General > Accessibility > Switch Control, then turn off Switch Control. Or triple-click the
Home button.
Basic techniques
Whether you use item scanning or point scanning, the Switch Control basics are the
same.
Select an item. While the item is highlighted, trigger the switch you’ve set up as your
Select Item switch. If you are using a single switch, it is your Select Item switch by
default.
Perform an action on the selected item. Choose a command from the control menu
that appears when you select the item. The layout of the menu depends on how you
configure tap behavior. (To choose an option, go to Settings > General > Accessibility >
Switch Control > Tap Behavior.)
With Default on: The control menu usually includes only the Tap button and the More
button (two dots at the bottom). If you’re in a scrollable area of the screen, a Scroll
button also appears. To tap the highlighted item, trigger your Select Item button
when Tap is highlighted. To see additional action buttons, choose More at the bottom
of the menu. If you have multiple switches, you can set one up specifically for
tapping.
With Auto Tap on: To tap the item, do nothing—the item is automatically tapped when
the Auto Tap interval expires (0.75 seconds if you haven’t changed it). To see the
control menu, trigger your Select Item button before the Auto Tap interval expires.
The control menu skips the Tap button and goes right to the full set of action
buttons.
With Always Tap on: Tap to select the highlighted item rather than display the control
menu. Wait until the end of the scan cycle, then tap a button to display the control
menu.
DRAFT
![](/img.php?id=3081107&img=bg37.png)
298
!
APPLE CONFIDENTIAL
Note: Always Tap applies only when you choose item scanning. When point scanning,
the default behavior applies.
Work with recipes. A recipe lets you temporarily assign a special action to a switch. For
example, you can choose a recipe to turn pages in iBooks or control a game. To use a
recipe, go to Settings > General > Accessibility > Switch Control > Recipes, then choose
a recipe.
Dismiss the control menu without choosing an action. Tap while the original item is
highlighted and all the icons in the control menu are dimmed. Or choose Escape from the
control menu. The menu goes away after cycling the number of times you specify at
Settings > General > Accessibility > Switch Control > Loops.
Perform screen gestures. Choose Gestures from the control menu.
Scroll the screen. Select an item in a scrollable part of the screen, then:
With Auto Tap off: Choose the Scroll Down button (next to the Tap button) in the
control menu. Or, for more scrolling options, choose More, then choose Scroll.
With Auto Tap on: Choose Scroll from the control menu. If many actions are available,
you might have to choose More first.
Tap the Home button. Choose Home from the control menu.
Perform other hardware actions. Select any item, then choose Device from the menu
that appears. Use the menu to mimic these actions:
Double-click the Home button for multitasking
Open Notification Center or Control Center
Press the Sleep/Wake button to lock iPhone
Rotate iPhone
Flip the Ring/Silent switch
Press the volume buttons
Hold down the Home button to open Siri
Triple-click the Home button
Shake iPhone
Press the Home and Sleep/Wake buttons simultaneously to take a screenshot
Swipe down from the top with two fingers to speak the screen (if you have Speak
Screen turned on)
DRAFT
![](/img.php?id=3081107&img=bg38.png)
299
!
APPLE CONFIDENTIAL
On devices that support 3D Touch, replicate 3D Touch to preview the contents of an
email message
Item scanning
Item scanning alternately highlights each item or group of items on the entire screen until
you trigger your Select Item switch. If there are many items, Switch Control highlights
them in groups. When you select a group, highlighting continues with the items in the
group. When you select a unique item, scanning stops and the control menu appears.
Item scanning is the default when you first turn on Switch Control.
You can choose from three scanning styles—auto scanning, manual scanning, and
single-switch step scanning. Auto scanning automatically highlights items, one after the
other. With manual scanning, you use one switch to highlight an item and another to
activate it. Single-switch step scanning uses a switch to move the highlight from item to
item. If you take no action after a period of time, the highlighted item activates.
Select an item or enter a group. Watch (or listen) as items are highlighted. When the
item you want to control (or the group containing the item) is highlighted, trigger your
Select Item switch. Work your way down in the hierarchy of items until you select the
individual item you want to control.
Back out of a group. Trigger your Select Item switch when the dashed highlight around
the group or item appears.
Dismiss the control menu without performing an action. Trigger your Select Item
switch when the item itself is highlighted. Or choose Escape from the control menu.
Hear the names of items as they are highlighted. Go to Settings > General >
Accessibility > Switch Control, then turn on Speech. Or choose Settings from the control
menu, then choose Speech On.
Slow down or speed up the scanning. Go to Settings > General > Accessibility > Switch
Control > Auto Scanning Time.
Point scanning
Point scanning lets you select an item on the screen by pinpointing it with scanning
crosshairs.
Switch to point scanning. Use item scanning to choose Point Mode from the control
menu. The vertical crosshair appears when you close the menu.
Select an item. Trigger your Select Item switch when the item you want is within the
broad, horizontal scanning band, then trigger again when the fine scanning line is on the
item. Repeat for vertical scanning.
DRAFT
![](/img.php?id=3081107&img=bg39.png)
300
!
APPLE CONFIDENTIAL
Refine your selection point. Choose Refine Selection from the control menu.
Return to item scanning. Choose Item Mode from the control menu.
Settings and adjustments
Adjust basic settings. Go to Settings > General > Accessibility > Switch Control, where
you can:
Add switches and specify their function
Choose, create, and edit recipes
Choose a scanning style
Adjust how rapidly items are scanned
Turn off auto scanning (only if you’ve added a Move to Next Item switch)
Set scanning to pause on the first item in a group
Choose how many times to cycle through the screen before hiding Switch Control
Choose a tap behavior and set the interval for performing a second switch action to
show the control menu
Set whether a movement action is repeated when you hold down a switch, and how
long to wait before repeating
Add another action to a switch by holding down the switch for a long duration
Choose which items appear in menus and the order in which they appear
Set whether and how long you need to hold a switch down before it’s accepted as a
switch action
Have Switch Control ignore accidental repeated switch triggers
Adjust the point scanning speed
Turn on sound effects or have items read aloud as they are scanned
Choose what to include in the Switch Control menu
Set whether items should be grouped while item scanning
Make the selection cursor larger or a different color
Save custom gestures to the control menu (in Gestures > Saved)
DRAFT
![](/img.php?id=3081107&img=bg3a.png)
301
!
APPLE CONFIDENTIAL
Fine-tune Switch Control. Choose Settings from the control menu to:
Adjust scanning speed
Change the location of the control menu
Turn sound or speech accompaniment on or off
Turn off groups to scan items one at a time
AssistiveTouch
AssistiveTouch helps you use iPhone if you have difficulty touching the screen or
pressing the buttons. You can use AssistiveTouch without any accessory to perform
gestures that are difficult for you. You can also use a compatible adaptive accessory
(such as a joystick) together with AssistiveTouch to control iPhone. To configure the
AssistiveTouch menu, go to Settings > General > Accessibility > AssistiveTouch.
The AssistiveTouch menu lets you perform actions such as these by just tapping (or the
equivalent on your accessory):
Press the Home button
Summon Siri
Perform multifinger gestures
Access Control Center or Notification Center
Adjust iPhone volume
Shake iPhone
Capture a screenshot
Add more actions (for a total of eight)
Double-tap
On devices that support 3D Touch, replicate 3D Touch to peek at previews and pop
open items
Turn on AssistiveTouch. Tell Siri “turn on AssistiveTouch,” go to Settings > General >
Accessibility > AssistiveTouch, or use the Accessibility Shortcut. See Accessibility
Shortcut. When AssistiveTouch is on, the floating menu button appears on the screen.
Show or hide the menu. Tap the floating menu button, or click the secondary button on
your accessory.
DRAFT
302
!
APPLE CONFIDENTIAL
Simulate pressing the Home button. Tap the menu button, then tap Home.
Lock or rotate the screen, adjust iPhone volume, or simulate shaking iPhone. Tap
the menu button, then tap Device.
Perform a swipe or drag that uses 2, 3, 4, or 5 fingers. Tap the menu button, tap
Device > More > Gestures, then tap the number of digits needed for the gesture. When
the corresponding circles appear on the screen, swipe or drag in the direction required
by the gesture. When you finish, tap the menu button.
Perform a pinch gesture. Tap the menu button, tap Custom, then tap Pinch. When the
pinch circles appear, touch anywhere on the screen to move the pinch circles, then drag
them in or out to perform a pinch gesture. When you finish, tap the menu button.
Create your own gesture. You can add your own favorite gestures to the control menu
(for example, touch and hold or two-finger rotation). Tap the menu button, tap Custom,
then tap an empty gesture placeholder. Or go to Settings > General > Accessibility >
AssistiveTouch > Create New Gesture.
Example 1: To create the rotation gesture, go to Settings > General > Accessibility >
AssistiveTouch > Create New Gesture. On the gesture recording screen that asks you to
touch to create a gesture, rotate two fingers on the iPhone screen around a point
between them. (You can do this with a single finger or stylus—just create each arc
separately, one after the other.) If it doesn’t turn out quite right, tap Cancel, then try
again. When it looks right, tap Save, then give the gesture a name—maybe “Rotate 90.”
Then, to rotate the view in Maps, for example, open Maps, tap the AssistiveTouch menu
button, and choose Rotate 90 from Custom. When the blue circles representing the
starting finger positions appear, drag them to the point around which you want to rotate
the map, then release. You might want to create several gestures with different degrees
of rotation.
Example 2: Let’s create the touch-and-hold gesture that you use to start rearranging
icons on your Home screen. This time, on the gesture recording screen, hold down your
finger in one spot until the recording progress bar reaches halfway, then lift your finger.
Be careful not to move your finger while recording, or the gesture will be recorded as a
drag. Tap Save, then name the gesture. To use the gesture, tap the AssistiveTouch menu
button, then choose your gesture from Custom. When the blue circle representing your
touch appears, drag it over a Home screen icon and release.
If you record a sequence of taps or drags, they’re all played back at the same time. For
example, using one finger or a stylus to record four separate, sequential taps at four
locations on the screen creates a simultaneous four-finger tap.
Exit a menu without performing a gesture. Tap anywhere outside the menu. To return
to the previous menu, tap the arrow in the middle of the menu.
DRAFT
![](/img.php?id=3081107&img=bg3c.png)
303
!
APPLE CONFIDENTIAL
Move the menu button. Drag it anywhere along the edge of the screen.
Touch Accommodations
If you have trouble using the touchscreen, use Touch Accommodations to change how
the screen responds to touches.
Choose how long you must touch the screen before a touch is recognized. You can
configure iPhone to respond only to touches of a certain duration. Go to
Settings > General > Accessibility > Touch Accommodations, turn on Hold Duration, then
use the Gesture Delay plus and minus buttons to choose a duration (the default is 0.10
seconds).
Choose the duration in which multiple touches are treated as a single touch. If you
have trouble touching the screen just once, turn on Ignore Repeat. Then, if you touch the
screen several times quickly, iPhone treats the touches as one. To change the amount of
time between touches before iPhone treats them as one, go to Settings > General >
Accessibility > Touch Accommodations, turn on Ignore Repeat, then use the Gesture
Delay plus and minus buttons to adjust the timing.
Choose the location where iPhone responds to the first or the last place you touch.
Go to Settings > General > Accessibility > Touch Accommodations, then choose a Tap
Assistance option (Use Initial Touch Location or Use Final Touch Location).
When you choose Use Initial Touch Location, iPhone uses the location of your first tap—
when you tap an app on the Home screen, for example. Choose Use Final Touch
Location, and iPhone registers the tap where you lift your finger. iPhone responds to a
tap when you lift your finger within a certain period of time. Use the Gesture Delay plus
and minus buttons to adjust the timing. Your device can respond to other gestures, like
drags, if you wait longer than the gesture delay.
Software and hardware keyboards
If you have difficulty distinguishing characters on the iPhone keyboard or manipulating a
hardware keyboard, find help by going to Settings > General > Accessibility > Keyboard.
You can adjust settings to:
Show only uppercase keys on the iPhone keyboard.
Adjust the key repeat rate on hardware keyboards.
Use the Sticky Keys feature to hold down modifier keys, such as Command and
Option, as you press another key.
DRAFT
![](/img.php?id=3081107&img=bg3d.png)
304
!
APPLE CONFIDENTIAL
Use Slow Keys to adjust the time between when a key is pressed and when it’s
activated.
Built-in TTY software
iPhone has built-in TTY software, which does not require additional hardware.
Enable and configure TTY software. Go to Settings > Accessibility > TTY. You can
enable software TTY and real-time TTY. You can also choose to answer all calls as TTY.
Support for TTY hardware
You can use the iPhone TTY Adapter cable (sold separately in many areas) to connect
iPhone to a TTY machine. Go to the Apple Accessibility website (may not be available in
all areas) or check with your local Apple retailer.
Connect iPhone to a TTY machine. Go to Settings > Phone, then turn on TTY. Then
connect iPhone to your TTY machine using the iPhone TTY Adapter.
When TTY on iPhone is turned on, the TTY icon
appears in the status bar at the top
of the screen. For information about using a particular TTY machine, see the
documentation that came with the machine.
Note: Continuity features are not available for TTY support.
Visual voicemail
Ask Siri. Say something like:
“Play my voicemail”
“Play the message again”
“Call back that number”
The play and pause controls in visual voicemail let you control the playback of messages.
Drag the playhead on the scrubber bar to repeat a portion of the message that’s hard to
understand. See Visual voicemail.
Voice Control
Voice Control lets you make phone calls and control Music playback using voice
commands. See Make a call, and Siri and Voice Control.
DRAFT
![](/img.php?id=3081107&img=bg3e.png)
305
!
APPLE CONFIDENTIAL
Accessibility in OS X
Take advantage of the accessibility features in OS X when you use iTunes to sync
information and content from your iTunes library to iPhone. In the Finder, choose
Help > Help Center (or Help > Mac Help in OS X v10.11 or later), then search for
“accessibility.”
For more information about iPhone and OS X accessibility features, go to the Apple
Accessibility website.
DRAFT
![](/img.php?id=3081107&img=bg3f.png)
306
!
APPLE CONFIDENTIAL
Safety, handling, and support
Important safety information
WARNING: Failure to follow these safety instructions could result in fire, electric
shock, injury, or damage to iPhone or other property. Read all the safety information
below before using iPhone.
Handling Handle iPhone with care. It is made of metal, glass, and plastic and has
sensitive electronic components inside. iPhone can be damaged if dropped, burned,
punctured, or crushed, or if it comes in contact with liquid. Don’t use a damaged iPhone,
such as one with a cracked screen, as it may cause injury. If you’re concerned about
scratching the surface of iPhone, consider using a case or cover.
Repairing Don’t open iPhone and don’t attempt to repair iPhone yourself.
Disassembling iPhone may damage it, result in loss of water resistance (2016 IPHONE
and 2016 IPHONE PLUS),
or cause injury to you. For example, 2016 IPHONE and
2016 IPHONE PLUS contain a laser that could be damaged
during repair or
disassembly, which could result in hazardous exposure to infrared laser
emissions that
are not visible. This equipment should be serviced by Apple or an
authorized service
provider. You can find more information about getting service at the
iPhone Support
website.
Battery Don’t attempt to replace the iPhone battery yourself—you may damage the
battery, which could cause overheating and injury. The lithium-ion battery in iPhone
should be replaced by Apple or an authorized service provider, and must be recycled or
disposed of separately from household waste. Don’t incinerate the battery. For
information about battery service and recycling, go to the Battery Service and Recycling
website.
Distraction Using iPhone in some circumstances may distract you and might cause a
dangerous situation (for example, avoid using headphones while riding a bicycle and
avoid typing a text message while driving a car). Observe rules that prohibit or restrict
the use of mobile devices or headphones.
Navigation Maps depends on data services. These data services are subject to change
and may not be available in all areas, resulting in maps and location-based information
that may be unavailable, inaccurate, or incomplete. Compare the information provided in
Maps to your surroundings. Use common sense when navigating. Always observe current
road conditions and posted signs to resolve any discrepancies. Some Maps features
require Location Services.
DRAFT
![](/img.php?id=3081107&img=bg40.png)
307
!
APPLE CONFIDENTIAL
Charging Charge iPhone with the included USB cable and power adapter, or with other
third-party “Made for iPhone” cables and power adapters that are compatible with USB
2.0 or later, or power adapters compliant with applicable country regulations and with
one or more of the following standards: EN 301489-34, IEC 62684, YD/T 1591-2009,
CNS 15285, ITU L.1000, or another applicable mobile phone power adapter
interoperability standard.
Using damaged cables or chargers, or charging when moisture is present, can cause fire,
electric shock, injury, or damage to iPhone or other property. When you use the Apple
USB Power Adapter to charge iPhone, make sure the USB cable is fully inserted into the
power adapter before you plug the adapter into a power outlet.
Lightning cable and connector Avoid prolonged skin contact with the connector when
the Lightning to USB Cable is plugged into a power source because it may cause
discomfort or injury. Sleeping or sitting on the Lightning connector should be avoided.
Prolonged heat exposure iPhone and its power adapter comply with applicable surface
temperature standards and limits. However, even within these limits, sustained contact
with warm surfaces for long periods of time may cause discomfort or injury. Use common
sense to avoid situations where your skin is in contact with a device or its power adapter
when it’s operating or plugged into a power source for long periods of time. For example,
don’t sleep on a device or power adapter, or place them under a blanket, pillow, or your
body, when it’s plugged into a power source. It’s important to keep iPhone and its power
adapter in a well-ventilated area when in use or charging. Take special care if you have a
physical condition that affects your ability to detect heat against the body.
Hearing loss Listening to sound at high volumes may damage your hearing.
Background noise, as well as continued exposure to high volume levels, can make
sounds seem quieter than they actually are. Turn on audio playback and check the
volume before inserting anything in your ear. For information about how to set a
maximum volume limit, see Play music. For more information about hearing loss, go to
the Sound and Hearing website.
To avoid hearing damage, use only compatible receivers, earbuds, headphones,
speakerphones, or earpieces with . The headsets sold with iPhone 4s or later in China
(identifiable by dark insulating rings on the plug) are designed to comply with Chinese
standards and are only compatible with iPhone 4s and later, iPad 2 and later, iPad Pro,
iPad mini and later, and iPod touch 5th generation and later.
WARNING: To prevent possible hearing damage, do not listen at high volume levels for
long periods.
Radio frequency exposure iPhone uses radio signals to connect to wireless networks.
For information about radio frequency (RF) energy resulting from radio signals and
steps
you can take to minimize exposure, go to Settings > General > About > Legal > RF
Exposure or go to the RF Exposure website.
DRAFT
308
!
APPLE CONFIDENTIAL
Radio frequency interference Observe signs and notices that prohibit or restrict the
use of electronic devices (for example, in healthcare facilities or blasting areas). Although
iPhone is designed, tested, and manufactured to comply with regulations governing radio
frequency emissions, such emissions from iPhone can negatively affect the operation of
other electronic equipment, causing them to malfunction. Turn off iPhone or use Airplane
Mode to turn off the iPhone wireless transmitters when use is prohibited, such as while
traveling in aircraft, or when asked to do so by authorities.
Medical device interference iPhone contains components and radios that emit
electromagnetic fields. iPhone also contains magnets and the included headphones also
have magnets in the earbuds. These electromagnetic fields and magnets may interfere
with pacemakers, defibrillators, or other medical devices. Maintain a safe distance of
separation between your medical device and iPhone and the earbuds. Consult your
physician and medical device manufacturer for information specific to your medical
device. If you suspect iPhone is interfering with your pacemaker, defibrillator, or any
other medical device, stop using iPhone.
Not a medical device iPhone and the Health app are not designed or intended for use in
the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or
prevention of disease.
Medical conditions If you have any medical condition that you believe could be affected
by iPhone (for example, seizures, blackouts, eyestrain, or headaches), consult with your
physician prior to using iPhone.
Explosive atmospheres Charging or using iPhone in any area with a potentially
explosive atmosphere, such as areas where the air contains high levels of flammable
chemicals, vapors, or particles (such as grain, dust, or metal powders), may be
hazardous. Obey all signs and instructions.
Repetitive motion When you perform repetitive activities such as typing or playing
games on iPhone, you may experience discomfort in your hands, arms, wrists, shoulders,
neck, or other parts of your body. If you experience discomfort, stop using iPhone and
consult a physician.
High-consequence activities This device is not intended for use where the failure of
the device could lead to death, personal injury, or severe environmental damage.
Choking hazard Some iPhone accessories may present a choking hazard to small
children. Keep these accessories away from small children.
Important handling information
Cleaning Clean iPhone immediately if it comes in contact with anything that may cause
stains—such as dirt, ink, makeup, or lotions. To clean:
DRAFT
![](/img.php?id=3081107&img=bg42.png)
309
!
APPLE CONFIDENTIAL
Disconnect all cables and turn iPhone off (press and hold the Sleep/Wake button,
then slide the onscreen slider).
Use a soft, lint-free cloth.
Avoid getting moisture in openings.
Don’t use cleaning products or compressed air.
The front or back cover of iPhone may be made of glass with a fingerprint-resistant
oleophobic (oil repellant) coating. This coating wears over time with normal usage.
Cleaning products and abrasive materials will further diminish the coating, and may
scratch the glass.
Exposure to liquid 2016 IPHONE and 2016 IPHONE PLUS are water resistant but not
waterproof. You may, for
example, use 2016 IPHONE or 2016 IPHONE PLUS in the
rain and with wet hands. If water splashes on to 2016 IPHONE or
2016 IPHONE PLUS,
wipe it off with a nonabrasive, lint-free cloth.
Try to minimize exposing iPhone to these substances, and follow the instructions above
in the “Cleaning” section if iPhone comes into contact with them:
Soap, detergent, acids or acidic foods, and any liquids other than fresh water, such
as salt water, soapy water, pool water, perfume, insect repellent, lotions, sunscreen,
oil, adhesive remover, hair dye, or solvents.
Submerging 2016 IPHONE or 2016 IPHONE PLUS is not recommended. These
devices have a water resistance
rating of IPX7 under IEC standard 60529. Water
resistance is not a permanent
condition, and 2016 IPHONE or 2016 IPHONE PLUS
cannot be rechecked or resealed for water resistance. The
following may affect the
water resistance and should be avoided:
Dropping 2016 IPHONE or 2016 IPHONE PLUS or subjecting it to other impacts.
Submerging 2016 IPHONE or 2016 IPHONE PLUS in water for long periods of time.
Swimming or bathing with 2016 IPHONE or 2016 IPHONE PLUS.
Exposing 2016 IPHONE or 2016 IPHONE PLUS to pressurized water or high
velocity water, such as when
showering, water skiing, wake boarding, surfing, jet
skiing, and so on.
Wearing 2016 IPHONE or 2016 IPHONE PLUS in the sauna or steam room.
Using connectors, ports, and buttons Never force a connector into a port or apply
excessive pressure to a button, because this may cause damage that is not covered
under the warranty. If the connector and port don’t join with reasonable ease, they
probably don’t match. Check for obstructions and make sure that the connector matches
DRAFT
310
!
the port and that you have positioned the connector correctly in relation to the port.
DRAFT
![](/img.php?id=3081107&img=bg44.png)
310
!
APPLE CONFIDENTIAL
Lightning to USB Cable Discoloration of the Lightning connector after regular use is
normal. Dirt, debris, and exposure to moisture may cause discoloration. If your Lightning
cable or connector become warm during use or iPhone won’t charge or sync, disconnect
it from your computer or power adapter and clean the Lightning connector with a soft,
dry, lint-free cloth. Do not use liquids or cleaning products when cleaning the Lightning
connector.
Certain usage patterns can contribute to the fraying or breaking of cables. The Lightning
to USB Cable, like any other metal wire or cable, is subject to becoming weak or brittle if
repeatedly bent in the same spot. Aim for gentle curves instead of angles in the cable.
Regularly inspect the cable and connector for any kinks, breaks, bends, or other damage.
Should you find any such damage, discontinue use of the Lightning to USB Cable.
Operating temperature iPhone is designed to work in ambient temperatures between
32° and 95° F (0° and 35° C) and stored in temperatures between -4° and 113° F (-20°
and 45° C). iPhone can be damaged and battery life shortened if stored or operated
outside of these temperature ranges. Avoid exposing iPhone to dramatic changes in
temperature or humidity. When you’re using iPhone or charging the battery, it is normal
for iPhone to get warm.
If the interior temperature of iPhone exceeds normal operating temperatures (for
example, in a hot car or in direct sunlight for extended periods of time), you may
experience the following as it attempts to regulate its temperature:
iPhone stops charging.
The screen dims.
A temperature warning screen appears.
Some apps may close.
Important: You may not be able to use iPhone while the temperature warning screen is
displayed. If iPhone can’t regulate its internal temperature, it goes into deep sleep mode
until it cools. Move iPhone to a cooler location out of direct sunlight and wait a few
minutes before trying to use iPhone again.
For more information, see the Apple Support article Keeping your device within
acceptable operating temperatures.
Forgot your Apple ID or iPhone passcode?
Recover your Apple ID or reset your Apple ID password. Go to Apple’s
I
Forgot
website.
DRAFT
![](/img.php?id=3081107&img=bg45.png)
311
!
APPLE CONFIDENTIAL
Reset the iPhone passcode. If you enter the wrong passcode six times in a row, you'll
be locked out, and a message will say that iPhone is disabled. If you can’t remember
your passcode, you can erase your device, then set a new passcode. (If you made an
iCloud or iTunes backup before you forgot your passcode, you can restore your data
and settings from the backup.) For more information, see the Apple Support article If
you forgot the passcode or your device is disabled.
iPhone Support site
Comprehensive support information is available online at the iPhone Support website.
To contact Apple for personalized support (not available in all areas), go to the Apple
Support website.
Get information about your iPhone
View overall storage availability and storage used per app. Go to Settings >
General > Storage & iCloud Usage, where you can manage iCloud storage. For more
information, see the Apple Support articles Check your storage on your iPhone, iPad,
and iPod touch and Manage your iCloud storage.
See Battery Usage. Go to Settings > Battery to see the elapsed time since iPhone has
been charged and usage by app. You can also display battery level as a percentage, and
turn Low Power Mode on or off. See also Charge and monitor the battery and Low
Power Mode in this guide.
View call time and cellular usage. Go to Settings > Cellular. See Cellular data settings
in this guide.
See more information about iPhone. Go to Settings > General > About. The items you
can view include:
Name
Network addresses
Number of songs, videos, photos, and apps
Capacity and available storage space
iOS version
Carrier
Model number
DRAFT
![](/img.php?id=3081107&img=bg46.png)
312
!
Serial number
APPLE CONFIDENTIAL
Wi-Fi and Bluetooth addresses
IMEI (International Mobile Equipment Identity)
ICCID (Integrated Circuit Card Identifier, or Smart Card) for GSM networks
MEID (Mobile Equipment Identifier) for CDMA networks
Modem firmware
Legal (including legal notices and license, warranty, and RF exposure information)
To copy the serial number and other identifiers, touch and hold the identifier until Copy
appears.
To see regulatory marks, go to Settings > General > Regulatory.
View or turn off diagnostic information. Go to Settings > Privacy > Diagnostics &
Usage.
To help Apple improve products and services, iPhone sends diagnostic and usage data.
This data doesn’t personally identify you, but may include location information.
Cellular data settings
To turn cellular data and roaming on or off, set which apps and services use cellular data,
see call time and cellular data usage, and set other cellular options, go to Settings >
Cellular.
Note: For help with cellular network services, voicemail, and billing, contact your wireless
service provider.
If iPhone is connected to the Internet via the cellular data network, the LTE, 4G, 3G, E, or
GPRS icon appears in the status bar.
LTE, 4G, and 3G service on GSM cellular networks support simultaneous voice and data
communications. For all other cellular connections, you can’t use Internet services while
you’re talking on the phone unless iPhone also has a Wi-Fi connection to the Internet.
Depending on your network connection, you may not be able to receive calls while
iPhone transfers data over the cellular network—when downloading a webpage, for
example.
GSM networks: On an EDGE or GPRS connection, incoming calls may go directly to
voicemail during data transfers. For incoming calls that you answer, data transfers are
paused.
DRAFT
![](/img.php?id=3081107&img=bg47.png)
313
!
APPLE CONFIDENTIAL
CDMA networks: On EV-DO connections, data transfers are paused when you answer
incoming calls. On 1xRTT connections, incoming calls may go directly to voicemail
during data transfers. For incoming calls that you answer, data transfers are paused.
Data transfer resumes when you end the call.
If Cellular Data is off, all data services use only Wi-Fi—including email, web browsing,
push notifications, and other services. If Cellular Data is on, carrier charges may apply.
For example, using certain features and services that transfer data, such as Siri and
Messages, could result in charges to your data plan.
Turn Cellular Data on or off. Go to Settings > Cellular, then tap Cellular Data. The
following options may also be available:
Turn Voice Roaming on or off (CDMA): Turn Voice Roaming off to avoid charges from
using other carrier’s networks. When your carrier’s network isn’t available, iPhone
won’t have cellular (data or voice) service.
Turn Data Roaming on or off: Data Roaming permits Internet access over a cellular
data network when you’re in an area not covered by your carrier’s network. When
you’re traveling, you can turn off Data Roaming to avoid roaming charges.
Enable or disable 4G/LTE (varies by carrier): Using 4G or LTE loads Internet data
faster in some cases, but may decrease battery performance. If you’re making a lot of
phone calls, you may want to turn 4G/LTE off to extend battery life. This option is not
available in all areas. On iPhone SE, iPhone 6, iPhone 6 Plus, and later, there are
options for turning off 4G/LTE or for selecting Voice & Data (VoLTE) or Data Only.
Voice & Data (some carriers): Choose LTE to load data faster. (This also turns on
VoLTE.) Choose slower speeds to increase battery life.
Set up Personal Hotspot: Personal Hotspot shares the Internet connection on
iPhone with your computer and other iOS devices. See Personal Hotspot.
Turn Wi-Fi Assist on or off: If Wi-Fi connectivity is poor, Wi-Fi Assist uses cellular
data to boost the signal.
Note: Using data over a cellular network may incur additional fees.
Set whether cellular data is used for apps and services. Go to Settings > Cellular,
then turn cellular data on or off for any app that can use cellular data. If a setting is off,
iPhone uses only Wi-Fi for that service. The iTunes setting includes both iTunes Match
and automatic downloads from the iTunes Store and the App Store.
For more information about GSM, CDMA, and LTE cellular data networks, see the Apple
Support article About cellular data networks.
DRAFT
![](/img.php?id=3081107&img=bg48.png)
314
!
APPLE CONFIDENTIAL
VPN settings
A VPN (virtual private network) provides secure access over the Internet to private
networks, such as the network at your organization. You may need to install a VPN app
from the App Store that configures your iPhone to access a network. Contact your
system administrator for information about the app and settings you need.
Sell or give away iPhone
Before you sell or give away your iPhone, see the Apple Support article What to do
before selling or giving away your iPhone, iPad, or iPod touch, and be sure to perform
the following tasks.
If you paired an Apple Watch with your iPhone, unpair your Apple Watch. (See the
Apple Support article Unpair your Apple Watch and iPhone.)
Back up your iPhone.
Erase all content and settings, which includes your personal information. If you
turned on Find My iPhone, you might need to enter your Apple ID and password.
If you replace one iPhone with another, you can use the setup assistant to restore the
older device’s backup to your new iPhone.
Learn more, service, and support
Refer to the following resources to get more iPhone-related safety, software, and service
information.
DRAFT
![](/img.php?id=3081107&img=bg49.png)
315
!
APPLE CONFIDENTIAL
To learn about Do this
Using iPhone safely See Important safety information.
iPhone service and support, tips, forums, and
Apple software downloads
Go to the iPhone Support website.
Service and support from your carrier Contact your carrier or go to your carrier’s
website.
The latest information about iPhone Go to the iPhone website.
Managing your Apple ID account Go to the Apple ID website.
Using iCloud
Go to the iCloud Help website.
Using iTunes Open iTunes, then choose Help > iTunes Help.
For an online iTunes tutorial (may not be
available in all areas), go to the iTunes Support
website.
Using other Apple iOS apps Go to the iOS Apps Support website.
Finding your iPhone serial number, IMEI,
ICCID, or MEID
You can find your iPhone serial number,
International Mobile Equipment Identity (IMEI),
ICCD, or Mobile Equipment Identifier (MEID) on
the iPhone packaging. Or, on iPhone, choose
Settings > General > About. For more
information, go to the Apple Support article
Find the serial number and other information.
Obtaining warranty service First follow the advice in this guide. Then go to
the iPhone Support website.
Viewing iPhone regulatory information On iPhone, go to Settings > General >
Regulatory.
Battery service Go to the Battery Service and Recycling
website.
Using iPhone in an enterprise environment Go to the iPhone in Business website.
FCC regulatory statement
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
DRAFT
![](/img.php?id=3081107&img=bg4a.png)
316
!
APPLE CONFIDENTIAL
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Important: Changes or modifications to this product not authorized by Apple could void
the electromagnetic compatibility (EMC) and wireless compliance and negate your
authority to operate the product. This product has demonstrated EMC compliance under
conditions that included the use of compliant peripheral devices and shielded cables
between system components. It is important that you use compliant peripheral devices
and shielded cables between system components to reduce the possibility of causing
interference to radios, televisions, and other electronic devices.
Responsible party (contact for FCC matters only):
Apple Inc. Corporate Compliance
1 Infinite Loop, MS 91-1EMC
Cupertino, CA 95014
Canadian regulatory statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems.
DRAFT
![](/img.php?id=3081107&img=bg4b.png)
317
!
APPLE CONFIDENTIAL
Users are advised that high-power radars are allocated as primary users (i.e., priority
users) of the bands 5250–5350 MHz and 5650–5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
La bande 5 150 – 5 250 MHz est réservée uniquement pour une utilisation à l’intérieur
afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux.
Les utilisateurs êtes avisés que les utilisateurs de radars de haute puissance sont
désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250 – 5
350 MHz et 5 650 – 5 850 MHz et que ces radars pourraient causer du brouillage et/ou
des dommages aux dispositifs LAN-EL.
CAN ICES-3 (B)/NMB-3(B)
Class 1 Laser Information
2016 IPHONE and 2016 IPHONE PLUS are classified as Class 1 Laser products per
IEC60825-1:2007 and
IEC60825-1:2014. These devices comply with 21 CFR 1040.10 and
1040.11 except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
These devices contain
a laser that could be damaged during repair or disassembly, which
could result in
hazardous exposure to infrared laser emissions that are not visible. This
equipment
should be serviced by Apple or an authorized service provider.
Apple and the environment
At Apple, we recognize our responsibility to minimize the environmental impacts of our
operations and products. For more information, go to the Apple and the Environment
website.
DRAFT
![](/img.php?id=3081107&img=bg4c.png)
318
!
APPLE CONFIDENTIAL
Disposal and recycling information
Apple Recycling Program (available in some areas): For free recycling of your old
device, a prepaid shipping label, and instructions, go to the Recycling website.
iPhone disposal and recycling: You must dispose of iPhone properly according to
local laws and regulations. Because iPhone contains electronic components and a
battery, iPhone must be disposed of separately from household waste. When iPhone
reaches its end of life, contact local authorities to learn about disposal and recycling
options, or simply drop it off at your local Apple retail store or return it to Apple. The
battery will be removed and recycled in an environmentally friendly manner. For more
information, go to the Recycling website.
Battery service: The lithium-ion battery in iPhone should be serviced by Apple or an
authorized service provider, and must be recycled or disposed of separately from
household waste. For more information about battery service and recycling, go to the
Battery Service and Recycling website.
Dispose of batteries according to your local environmental laws and guidelines.
Brasil—Informações sobre descarte e reciclagem
O símbolo acima indica que este produto e/ou sua bateria não devem ser descartados no
lixo doméstico. Quando decidir descartar este produto e/ou sua bateria, faça-o de
acordo com as leis e diretrizes ambientais locais. Para informações sobre substâncias de
uso restrito, o programa de reciclagem da Apple, pontos de coleta e telefone de
informações, visite Meio ambiente.
Información sobre eliminación de residuos y reciclaje
El símbolo de arriba indica que este producto y/o su batería no debe desecharse con los
residuos domésticos. Cuando decida desechar este producto y/o su batería, hágalo de
conformidad con las leyes y directrices ambientales locales. Para obtener información
sobre el programa de reciclaje de Apple, puntos de recolección para reciclaje, sustancias
restringidas y otras iniciativas ambientales, visite Medio ambiente.
California battery charger energy efficiency
Turkey environmental information
DRAFT
![](/img.php?id=3081107&img=bg4d.png)
319
!
APPLE CONFIDENTIAL
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
Taiwan battery statement
China battery statement
Apple Inc.
© 2016 Apple Inc. All rights reserved.
Apple, the Apple logo, AirDrop, AirPlay, AirPort, AirPrint, Apple CarPlay, Apple Pay, Apple TV, Apple Watch,
EarPods, FaceTime, Finder, Flyover, GarageBand, Guided Access, Handoff, iBooks, iMessage, iPad, iPhone,
iPod, iPod touch, iSight, iTunes, iTunes Pass, iTunes U, Keychain, Keynote, Lightning, Mac, the Made for
iPhone logo, Numbers, OS X, Pages, the Podcast logo, Safari, Siri, Spotlight, Touch ID, and the Works with
iPhone logo are trademarks of Apple Inc., registered in the U.S. and other countries.
Apple Music, iPad mini, iPad Pro, and Multi-Touch are trademarks of Apple Inc.
Apple Store, App Store, Genius, iCloud, iCloud Keychain, iTunes Extras, iTunes Match, and iTunes Store are
service marks of Apple Inc., registered in the U.S. and other countries.
iBooks Store and iTunes Plus are service marks of Apple Inc.
Apple
1 Infinite Loop
Cupertino, CA 95014-2084
408-996-1010
www.apple.com
Beats 1 is a service mark of Beats Electronics, LLC.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Apple Inc. is under license.
Other company and product names mentioned herein may be trademarks of their respective companies.
Every effort has been made to ensure that the information in this manual is accurate. Apple is not responsible
for printing or clerical errors.
Some apps are not available in all areas. App availability is subject to change.
DRAFT
