Toshiba Pocket PC e740 User’s Guide

Battery Charging

A built-in battery is installed in the Toshiba Pocket PC. When using the

Toshiba Pocket PC for the first time, set the battery switch to the supply

side, and then charge the built-in battery with the supplied AC adapter.

How to Charge the Battery

You can use two charging methods.

When you connect the AC adapter and the Toshiba Pocket PC, turn the

unit off.

1. Connect the supplied AC adapter and the cradle as shown in the figure

below, and then insert the Toshiba Pocket PC into the cradle.

2-7

Chapter 2: Basic Skills

2. Connect the supplied AC adapter and the Toshiba Pocket PC as shown

in the figure below.

For charging the built-in battery, maintain an ambient temperature

from approx. 41°F to 95°F.

When the lamp is lit in orange during the built-in battery charging,

you can use the Toshiba Pocket PC.

When the built-in battery is completely charged, the LED alarm lamp

color will change to green.
