Toshiba Pocket PC e740 User’s Guide
How to Prolong Battery Life
Use the Toshiba Pocket PC with the AC adapter.
When you use the Toshiba Pocket PC under the following conditions,
the power consumption will be large. Please use the AC adapter when:
The Toshiba Pocket PC is operated while connected to your com-
puter.
The Toshiba Pocket PC is operated with storage card or with any
other optional equipment.
Select the short power-off time in the setting menu. This will shorten
the time the unit will remain on if not used. For more information, see
“Customize Your Toshiba Pocket PC” in Chapter 2.
Turn off the front light.
Set the screen brightness to power saving mode. Also shorten the
light turn-off time. For more information, see “Customize Your Toshiba
Pocket PC” in Chapter 2.
Use the Toshiba Pocket PC with an ambient temperature between
59°F and 77°F. This temperature range is the most effective for the
built-in battery.
When you use the Toshiba Pocket PC in high or low temperature en-
vironments, the operable time is shortened due to the decrease of the
built-in battery capacity.
Battery Life
The built-in battery has a limited life. Repeated charging/discharging of the
built-in battery gradually decreases operable time. When the operable time
has been extremely shortened, it is time to replace the built-in battery with
a new one.
Do not leave the Toshiba Pocket PC in a place of high or low tempera-
ture. It may shorten battery life.
2-9
Chapter 2: Basic Skills
Battery Charge Level and Stored Data Protection
If the battery charge level becomes extremely low, or is completely dis-
charged, the memory data stored in the Toshiba Pocket PC will be de-
leted.
When the low battery status icon or the alarm message appears, immedi-
ately connect the AC adapter to the Toshiba Pocket PC and charge the
built-in battery.
The built-in battery gradually discharges even if the device is not be-
ing used. When the Toshiba Pocket PC is left for a long time, the built-
in battery of the Toshiba Pocket PC may completely discharge.
It is recommended to save the Toshiba Pocket PC’s memory data to
your computer or to a storage card.
The manufacturer is not responsible for data change or clearance due
to battery discharge. Please acknowledge that.
2-10
Toshiba Pocket PC e740 User’s Guide
Initial Setup
When using the Toshiba Pocket PC for the first time, carry out initial setup
according to the procedures below after a built-in battery has been charged.
1. Press the power button to turn the power on. The Welcome screen
appears. Tap the screen to start the following setup.
2. Execute touch screen correction.
When the align screen appears, tap the center of the cross target with
the stylus. The next target position changes upon tapping the target.
Five taps completes the positioning correction. The screen then
changes to the Stylus screen.
If a finger or any other object touches the screen during correc-
tion, the correction will be cancelled. Repeat the correction proce-
dure.
3. Read how to use the stylus.
Read and understand the stylus operation, and then tap NEXT.
For more information on stylus operation, see “How to Use the Sty-
lus” in Chapter 2.
4. Learn the pop-up menu operation.
Read the on-screen explanation and then follow the instructions.
Display the pop-up menu, and cut and paste the data according to
the screen instructions.
After you finish the paste operation, this stage is completed. Tap
NEXT.
5. Set the ZONE.
When tapping the right q mark, the city and the time zone lists
appear. Tap the desired city and time zone.
When the setup is completed, tap NEXT.
6. To complete the initial setup.
When the Complete screen appears, the initial setup is completed.
After tapping the screen, you can use the Toshiba Pocket PC.
When you tap the Complete screen, the Today screen appears. For
more information on the Today screen, see “Today screen” in Chap-
ter 2.
2-11
Chapter 2: Basic Skills
Setup Method of Options
Method of Setting Card into CF Card Slot
To insert a card:
1. Turn off the power.
2. Open the card cover.
3. Insert the card with its contact surface (metal contact surface) facing
the back of the Toshiba Pocket PC.
2-12
Toshiba Pocket PC e740 User’s Guide
To remove a card:
1. Turn off the power.
2. Open the card cover.
3. Lightly press down the card until a clicking sound is heard. The card
will pop out slightly from the slot.
4. Pull the card straight up to remove.
2-13
Chapter 2: Basic Skills
Method of Setting Card into SD Card Slot
To insert a card:
1. Turn off the power.
2. Open the card cover.
3. Insert the card with its contact surface (metal contact surface) facing
the back of the Toshiba Pocket PC.
2-14
Toshiba Pocket PC e740 User’s Guide
To remove a card:
1. Turn off the power.
2. Open the card cover.
3. Lightly press down the card until a clicking sound is heard. The card
will pop out slightly from the slot.
4. Pull the card straight up to remove.
When storage cards are inserted in both the CF and SD card slots,
one of them may only be accessible depending on the application or
the Settings operation (typically, the first storage card inserted is ac-
cessed).
Typical examples:
- Notes of Pocket Outlook.
- Saving the destination selection of the Options item of the Tools
menu of Pocket Word.
