User Manual

WLAN - Computer
Hardware Reference
Preliminary Information
90002116_A
1/21/2011
©2010 Digi International Inc.
All rights reserved.
Digi, Digi International, the Digi logo, a Digi International Company, Digi JumpStart Kit, ConnectCore, NET+,
NET+OS and NET+Works are trademarks or registered trademarks of Digi International, Inc. in the United States
and other countries worldwide. All other trademarks are the property of their respective owners.
All other trademarks mentioned in this document are the property of their respective owners.
Information in this document is subject to change without notice and does not represent a commitment on the
part of Digi International.
Digi provides this document “as is,” without warranty of any kind, either expressed or implied, including, but
not limited to, the implied warranties of fitness or merchantability for a particular purpose. Digi may make
improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual
at any time.
This product could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes may be incorporated in new editions of the publication.
Contents
©2011DigiInternational,Inc. 3
Appendix A: Specifications ............ 4
WLAN ................................................................4
WLAN ............................................................. 4
Module Specifications ............................................4
Environmental Specifications .................................4
Network Interface .............................................. 4
WLAN ............................................................. 5
Appendix B: Certifications ............. 9
FCC Part 15 Class B ...............................................9
Radio Frequency Interface (RFI) (FCC 15.105) .............9
Labeling Requirements (FCC 15.19) .........................9
RF Exposure ...................................................... 10
Indoor/Outdoor .................................................10
Modifications (FCC 15.21) ..................................... 10
Industry Canada .................................................10
©2011DigiInternational,Inc. 4
Specifications
APPENDIX A
WLAN
WLAN
The WLAN - Computer module provide an 802.11a/b/g/n WLAN interface with up to 54Mbps
on the a/b/g band and up to 65 Mbps on the n band. The module has an on board chip
antenna for 802.11a/b/g/n.
Module Specifications
This appendix provides the WLAN - Computer module specifications.
Environmental Specifications
Operating temperature 0°C to +70°C
Storage temperature -20°C to +85°C
Network Interface
Antenna specifications: 802.11a/b/g antenna
WLAN‐Computer
©2011DigiInternational,Inc. 5
Attributes
WLAN
Standard
IEEE 802.11a/b/g/e/i/h/j standards
Single-stream IEEE 802.11n
Frequency Band
2.400 - 2.500 GHz ( Low Band )
4.900 - 5.850 GHz ( High Band )
Data Rates
802.11n :6.5, 13, 19.5, 26, 39,52 , 58.5, 65 Mbps
802.11a/g :6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b :1, 2, 5.5, 11 Mbps
Media Access Control
Dynamic selection of fragment threshold, data rate and antenna depending on the
channel statistics
WPA, WPA2 and WMM support
Attribute Band 1 Band 2
Frequency 2.45 GHz 5 ~ 6 GHz
Bandwidth 70MHz 500MHz
Impedance 50 Ohm 50 Ohm
VSWR 2.0 (max) 2.0 (max)
Polarization Linear Linear
Peak Gain 1dBi 1dBi
Dimension 10.3mm * 3.0mm * 1.6mm
Part Number AN1003
WLAN‐Computer
©2011DigiInternational,Inc. 6
Wireless Medium
802.11b/g : Direct Sequence-Spread Spectrum ( DSSS ) and Orthogonal Frequency
Divisional Multiplexing ( OFDM )
802.11a/n : OFDM
DFS Client
This module supports the DFS Client only between 5.25 and 5.35GHz bands. It does not
support being DFS Master, or can it be connected to an Ad hoc network in these bands.
Modulation DSSS
Differential Binary Shift Keying ( DBPSK ) @ 1 Mbps
Differential Quadrature Phase Shift Keying ( DQPSK ) @2 Mbps
Complementary Code Keying ( CCK ) @ 5.5 Mbps and 11 Mbps
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-Quadrature Amplitude Modulation ( QAM ) @24 and 36 Mbps
64-QAM @ 48 and 54 Mbps
Frequency Bands
2.412 to 2.472 GHz ( ETSI )
2.412 to 2.462 GHz ( FCC )
5.150 to 5.250 GHz ( ETSI ) ISM Band 1
5.250 to 5.350 GHz ( ETSI ) ISM Band 2 excluding TPC and DFS Client
5.470 to 5.725 GHz ( ETSI ) ISM Band 3 excluding TPC and DFS Client
5.150 to 5.250 GHz ( U-NII-1 )
5.250 to 5.350 GHz ( U-NII-2 )
5.470 to 5.725 GHz ( U-NII Worldwide )
5.725 to 5.825 GHz ( U-NII-3 )
WLAN‐Computer
©2011DigiInternational,Inc. 7
Available Transmit Power Settings ( Typical +- ( 2 dBm )@25°C)
( Maximum power settings will vary according to individual country regulations. )
IEEE 802.11b ( ~16mW ETSI ) ( ~37mW FCC 15.247 )
@ 1, 2, 5.5 and 11 Mbps
IEEE 802.11g ( ~ 10mW ETSI ) ( ~72mW FCC 15.247 )
@ 6, 12, 18, 24, 36 and 54Mbps
IEEE 802.11n 2.4GHz Band ( ~12.5mW ETSI ) ( ~83mW FCC 15.247 )
IEEE 802.11a & IEEE 802.11n
( ~15mW ETSI )
( 5.150 to 5.250 GHz ~17mW FCC 15.407 )
( 5.250 to 5.350 GHz ~17mW FCC 15.407 )
( 5.470 to 5.725 GHz ~22mW FCC 15.407 )
( 5.725 to 5.850 GHz ~28mW FCC 15.247 )
@ 6, 12, 18, 24, 36 and 54Mbps and
@ 6.5, 13, 19.5, 26, 39,52 , 58.5, 65 Mbps
WLAN‐Computer
©2011DigiInternational,Inc. 8
Receive Sensitivity
Data Rate (bg Mode) Typical Sensitivity (+ / - 1.5 dBm)
1 Mbps -94.0 dBm (< 8% PER)
2 Mbps -89.0 dBm (< 8% PER)
11 Mbps -86.0 dBm (< 8% PER)
6 Mbps -89.0 dBm (< 10% PER)
54 Mbps -74.0 dBm (< 10% PER)
645Mbps -71.0 dBm (< 10% PER)
Data Rate (a Mode) Typical Sensitivity ( + / - 1.5 dBm)
6 Mbps -88.0 dBm (< 10% PER)
54 Mbps -72.0 dBm (< 10% PER)
Data Rate (bg Mode) Typical Sensitivity (+ / - 1.5 dBm)
65 Mbps -69.0 dBm (< 10% PER)
©2011DigiInternational,Inc. 9
Certifications
APPENDIX B
The WLAN - Computer product complies with the following standards.
FCC Part 15 Class B
Radio Frequency Interface (RFI) (FCC 15.105)
The WLAN - Computer module has been tested and found to comply with the limits for Class
B digital devices pursuant to Part 15 Subpart B, of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential environment.
This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try and correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Labeling Requirements (FCC 15.19)
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
If the FCC ID is not visible when installed inside another device, then the outside of the
device into which the module is installed must also display a label referring to the enclosed
WLAN‐Computer
©2011DigiInternational,Inc.. 10
module FCC ID. THis exterior label can use wording such as the following: “Contains
Transmitter Module FCC ID: MCQ-50M1699/ IC: 1846A-50M1699”.
RF Exposure
RF Exposure considerations require that a 20 cm separation distance between users and the
installed antenna location shall be maintained at all times when the module is energized.
OEM installers must consider suitable module and antenna installation locations in order to
assure this in 20cm separation, and end users be also be advised to the requirement.
Indoor/Outdoor
When the WLAN - Computer module is installed in devices that can be used outdoors, the
channels in the band 5150 - 5250 MHz must be disabled to comply with US and Canadian
regulatory requirements. OEM users are encouraged to inform end users of this restriction as
well.
Modifications (FCC 15.21)
Changes or modifications to this equipment not expressly approved by Digi may void the
user’s authority to operate this equipment.
Industry Canada
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les limites
applicables aux appareils numeriques de la class B prescrites dans le Reglement sur le
brouillage radioelectrique edicte par le ministere des Communications du Canada.
The maximum antenna gain permitted in the band 5150-5250MHz to comply with the e.i.r.p
limit is, according to RSS-210 section A9.2(2)
50mW conducted power
200mW max EIRP
The maximum antenna gain permitted in the bands 5250-5350 MHz and 5470-5725 MHz to
comply with the e.i.r.p limit is, according to RSS-210 section A9.2(2)
250mW conducted power
1.0W max EIRP
This limit is met with the highest gain antenna listed, antenna factor AN1003.
WLAN‐Computer
©2011DigiInternational,Inc.. 11
The maximum antenna gain permitted in the band 5725-5825 MHz to comply with the e.i.r.p
limit specified for non point-to-point operation is, according to RSS-210 section A9.2(3):
1W conducted power
4.0W max EIRP
This limit is met with the highest gain antenna listed,antenna factor AN1003.
OEM installers and users are cautioned to take note that high-power radars are allocated as
primary users (meaning they have priority) of the bands 5250-5330 MHz and 5650-5850 MHz
and these radars could cause interference and /or damage to devices operating in these
frequency bands.
