APPENDIX C
SPECIFCATIONS
ESTeem Command Error Message Table
Revised: 11 Feb 99 APX C-1
Listed below are the ESTeem Command Error Messages and their definitions. To receive these messages, TYPSYSTEM must
be ON (See Appendix D, Definitions). All System Status Message have a bell (O7H or CTRL G) preceding the message except
when Messform is ON. If MESSFORM = OFF Line A will be displayed. If MESSFORM = ON Line B will be displayed.
1. A "TOO MANY CHARACTERS FOR COMMAND"
BEMO1
This message will be displayed if more than the allocated
number of characters are typed for a command. This is
because some commands are truncated at a length of 8
characters.
2. A "AMBIGUOUS COMMAND"
BEMO2
This is the case of not enough characters being entered to
uniquely identify a command.
3. A "INVALID ARGUMENT"
BEM03
This is displayed when a non valid value is given to a
Command. Example; a value of O cannot be given to
FRACK because the only valid values are 1-255.
APPENDIX C
SPECIFCATIONS
ESTeem System Status Message Table
Revised: 11 Feb 99 APX C-2
Listed below are the ESTeem System Status Messages and their definitions. To receive these messages, TYPSYSTEM must be
ON (See APPENDIX D, DEFINITIONS). All System Status Messages have a bell (O7H or CTRL G) preceding the message
except when Messform is ON. If Messform = OFF Line A will be displayed. If Messform = ON Line B will be displayed.
1. A "CONNECTED TO XX"
B SSO1-xx
This message is caused by either receiving a reply from
a Log On Packet, receiving a Log On Packet, or by
typing LINK when connected and in the COMMAND
MODE. XX is the address of the modem connected to.
2. A "DISCONNECTED FROM XX"
B SSO2-xx
Tells that you have been disconnected from the device
you were originally connected to (xx is unit address).
3. A "LINK DOWN"
B SSO3
This message occurs after sending the last retry data
packet and receiving no response from the destination
node. This message usually indicates a hard failure
-i.e. destination node not energized, wrong baud rate,
(not compatible between units) improper
transmit/receive frequency between nodes, etc.
4. A "CURRENTLY NOT CONNECTED!"
B SSO4
The Disconnect was issued while the modem was not
connected to another modem or when LINK is typed in
the COMMAND MODE when you are not connected.
This message is displayed when the modem is configured in
the monitor mode.
5. A "FAILED TO CONNECT!"
B SS05
This message occurs if the modem fails to connect.
6. A "FAILED TO DISCONNECT!"
B SS06
This message occurs if the modems are connected and
are unable to disconnect.
7. A "USING FACTORY DEFAULTS"
B SS07
This command states when factory defaults have been
enabled.
8. A "REMOTE PROGRAMMING"
B SS08
This message is displayed when the ESTeem has been
placed in the remote programming mode.
9. A "PHONE MODEM CONNECTED.
INFRARED PORT DISABLED"
B SS09
This message is displayed when the ESTeem phone
port has received an in-coming call.
10. A "PHONE MODEM DISCONNECTED.
INFRARED PORT ENABLED"
B SS10
This message is displayed when the ESTeem port has
been disconnected.
APPENDIX C
SPECIFCATIONS
ESTeem System Error Message Table
Revised: 11 Feb 99 APX C-3
Listed below are the ESTeem System Error Messages and their definitions. To receive these messages, TYPSYSTEM must be
ON (See APPENDIX D, DEFINITIONS). All System Status Messages have a bell (O7H or CTRL G) preceding the message
except when Messform is ON. If Messform = OFF Line A will be displayed. If Messform = ON Line B will be displayed.
1. A "NOVRAM FAILED"
B SEO1
If this response is received after a save, there is a
hardware problem with the ESTeem's NOVRAM
Circuitry.
2. A "ROM FAILED"
B SEO2
If this response is received after a save, there is a
hardware problem with the ESTeem's ROM Circuitry.
3. A “BASE BAND FAILED”
B SEO3
This indicates that the Base Band Processor is not
operating correctly.
