6 Checking the LED Indicators
When the access point is connected to power, LEDs indicate activity as follows (solid LED indicates
connection; blinking LED indicates activity):
Troubleshooting
Refer to the Mobility System Configuration Guide or to the 3Com Wireless LAN Switch Reference
Manual to obtain the access point status.
LED Color Indicates
Power Green
Off
The access point is powered up
and operating normally.
The access point is not receiving
power or there is a fault with the
power supply.
11a Green
Off
The access point has WLAN
frame transmission over the
802.11a 5.3 GHz radio band.
No link is present.
11b/g Green
Off
The access point has WLAN
frame transmission over the
802.11g 2.4 GHz radio band.
No link is present.
100 Green
Off
The access point has a 100 Mbps
Fast Ethernet connection.
No link is present.
10 Green
Off
The access point has a 10 Mbps
Ethernet connection.
No link is present.
11b/g
11a
POWER
100
10
