3-12
3.2.2.5 UPC-EAN Add on 2/5
A. UPC-E, UPC-A, EAN-13 / ISBN and EAN-8 / JAN-8 may all include an
additional barcode to the right of the main barcode.
B. This barcode will show primary & additional code together.
C. So the UPC-EAN Add-ON 2/5 code is unable to use alone, must operate in
UPC-E or UPC-A or EAN-13 / ISBN or EAN-8 / JAN-8.
Figure 3-10 UPC-EAN Add on 2/5
Table 3-9 UPC-EAN Add-On 2/5 Explaining
Item Explaining
Only read the code with Addon 2/5
Only reads the codes that have addenda.
![](/img.php?id=731694&img=bg2.png)
3-13
3.2.2.6 Industrial 2 of 5 / IATA
Figure 3-11 Industrial 2 of 5 / IATA
Table 3-10 Industrial 2 of 5 / IATA Explaining
Item Explaining
Send Check Digit Whether send check digit by barcode.
Enable IATA Code Whether use this IATA Code.
Checksum Verify Whether verify checksum by barcode.
Min Length can be set from 2 to 48
Min-Max
(Default: 2 / 48) Max Length can be set from 2 to 48
Length 1 can be set from 2 to 48
Length 2 can be set from 2 to 48
Length
Fixed
Length 3 can be set from 2 to 48
![](/img.php?id=731694&img=bg3.png)
3-14
3.2.2.7 Interleaved 2 of 5
Figure 3-12 Interleaved 2 of 5
Table 3-11 Interleaved 2 of 5 Explaining
Item Explaining
Send Check Digit Whether send check digit by barcode.
Checksum Verify Whether verify checksum by barcode.
Min Length can be set from 4 to 48
Min / Max
(Default: 4 / 48) Max Length can be set from 4 to 48
Length 1 can be set from 4 to 48
Length 2 can be set from 4 to 48
Length
Fixed
Length 3 can be set from 4 to 48
![](/img.php?id=731694&img=bg4.png)
3-15
3.2.2.8 Plessey / MSI
Figure 3-13 Plessey / MSI
Table 3-12 Plessey / MSI Explaining
Item Explaining
Mode 10
Mode 10-10
Format
Mode 11-10
Checksum mode for this barcode.
Send Check Digit Whether send check digit by barcode.
1 Digit Check 1 digit & send by checksum.
2 Digits Check 2 digits & send by checksum.
![](/img.php?id=731694&img=bg5.png)
3-16
3.2.2.9 Code11
Figure 3-14 Code 11
Table 3-13 Code 11 Explaining
Item Explaining
Send Check Digit Whether send check digit by barcode.
1 Digit Check 1 digit & send by checksum.
2 Digits Check 2 digits & send by checksum.
