Zebra Technologies FX7500 FX7500 RFID FIXED READER User Manual MN000070A04b TC
Zebra Technologies Corporation FX7500 RFID FIXED READER MN000070A04b TC
Contents
User Manual
FX7500
RFID READER
QUICK START
Zebra reserves the right to make changes to any product to improve reliability,
function, or design.
Zebra does not assume any product liability arising out of, or in connection with,
the application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise
under any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which Zebra products might
be used. An implied license exists only for equipment, circuits, and subsystems
contained in Zebra products.
Zebra Technologies Corporation
Lincolnshire, IL U.S.A.
http://www.zebra.com
Zebra and the stylized Zebra head are trademarks of ZIH Corp. registered in
many jurisdictions worldwide. All other trademarks are the property of their
respective owners..
© 2016 Symbol Technologies LLC, a subsidiary of Zebra Technologies Corporation. All
rights reserved.
MN000070A04 Revision B — July 2016
123
Introduction
FX7500 Series readers provide real time, seamless tag processing for EPC
Class1 Gen2 compliant tags. This Quick Start Guide provides information
about installing and connecting the reader. For more information refer to the
FX Series RFID Readers Integrator Guide, available at:
http://www.zebra.com/support.
Reader Installation
1. Unpack the reader.
2. Set up the reader and tags on a desktop.
3. Connect the antenna to antenna Port 1.
4. Connect the Ethernet cable to the Ethernet port.
Connecting the reader to a subnet that supports DHCP is recommended.
This installation procedure is not guaranteed to work if DHCP is disabled
in the reader and if the reader is connected directly to a PC.
5. Connect the AC power supply to a power outlet and connect to the power
port.
The green power LED remains lit after successful installation.
Connecting to the Reader
To connect via host name:
1. Open a browser. Recommended browsers are IE10 (disabling
Compatibility View is recommended), Chrome v29, and FireFox 24.
2. Enter the host name, provided on a label on the reader, in the browser
(e.g., http://fx7500cd3b0d) and press Enter. The User Login window
appears and the reader is ready.
Additional Information
Following are links to additional information and software:
•
Product Manuals:
http://www.zebra.com/support
This page includes the following guides:
-FX7500 RFID Reader Quick Start Guide (p/n MN000070xxx)
-FX7500 RFID Reader Integrator Guide (p/n MN000026xxx)
-RFID Reader Software Interface Control Guide (p/n 72E-131718-xx)
-RFID Demo Applications User Guide (p/n 72E-160038-xx)
•
Data Sheet: http://www.zebra.com/FX7500.
•
PowerSession and other related software:
http://www.zebra.com/support.
Regulatory Information
This provides information for the Zebra, FX series RFID Reader products,
Regulatory Model No: FX7500. For information on setting up and using the reader, refer
to the FX Series RFID Reader Integration Guide at
http://www.zebra.com/support.
All Zebra devices are designed to be compliant with rules and regulations in locations
they are sold and will be labeled as required. Local language translations are available
at the following website: http://www.zebra.com/support.
Zebra devices must be professionally installed. The Radio Frequency Output Power will
not exceed the maximum allowable limit for the country of operation. Any changes or
modifications to Zebra equipment, not expressly approved by Zebra, could void the
authority to operate the equipment.
Regulatory Certification
The device is compliant with the following values and antenna characteristics:
Antennas
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could cause damage and may violate regulations.
Health and Safety Recommendations
Warning for Use of Wireless Devices
Please observe all warning notices with regard to the usage of wireless devices.
Potentially Hazardous Atmospheres
You are reminded of the need to observe restrictions on the use of radio devices in fuel
depots, chemical plants etc. and areas where the air contains chemicals or particles
(such as grain, dust, or metal powders).
Safety in Hospitals
Wireless devices transmit radio frequency energy and may affect medical
electrical equipment. When installed adjacent to other equipment, it is
advised to verify that the adjacent equipment is not adversely affected.
Use With Hearing Aids
When some wireless devices are used near some hearing devices (hearing aids and
cochlear implants), users may detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this interference noise, and wireless
devices also vary in the amount of interference they generate. In the event of
interference you may want to consult your hearing aid supplier to discuss solutions.
Other Medical Devices
Please consult your physician or the manufacturer of the medical device, to determine if
the operation of your wireless product may interfere with the medical device.
FCC / EU RF Exposure Guidelines
Safety Information
Reducing RF Exposure - Use Properly
Only operate the device in accordance with the instructions supplied.
International
The device complies with internationally recognized standards covering human
exposure to electromagnetic fields from radio devices. For information on "International"
human exposure to electromagnetic fields refer to the Zebra Declaration of Conformity
(DoC) at http://www.zebra.com/doc.
For further information on the safety of RF energy from wireless devices, see
http://responsibility.zebra.com/index.php/downloads/, which is located under Wireless
Communications and Health.
US and Canada
To comply with FCC RF exposure requirements, antennas that are mounted externally
at remote locations or operating near users at stand-alone desktop or similar
configurations must operate with a minimum separation distance of 34 cm from all
persons.
EU
To comply with EU RF exposure requirements, antennas that are mounted externally at
remote locations or operating near users at stand-alone desktop or similar
configurations must operate with a minimum separation distance of 34 cm from all
persons.
Power Supply
This device must be powered from an 802.3af or 802.3at compliant power source which
has been certified by the appropriate agencies, or by a Zebra approved UL LISTED ITE
(IEC/EN60950-1) power supply with electrical ratings: Output 24Vdc, min 3.25A, with a
recommended ambient temperature of at least 40 degrees C. Use of alternative power
supply will invalidate any approvals given to this unit and may be dangerous.
Air Handling Space Applications
This device is suitable for use in Environmental Air Handling Space (EAHS) in
accordance with Section 300-22(c) of the National Electric Code, and Sections 2-128,
12-010(3) and 12-100 of the Canadian Electrical Code, Part 21, CSA C22.1.
All Cables intended for interconnecting the FX7500 to other devices shall be suitable
rated for use in Environmental Air Handling Space per UL 2043.
Devices such as Power Adapters, PoE (Power Injectors), antennas shall not be installed
in the Environmental Air Handling Space unless they are suitable for use in the EAHS
per UL 2043.
Wireless Devices Country Approvals
Regulatory markings, subject to certification, are applied to the device signifying the
radio is approved for use in the following countries: United States, Canada, Japan,
China, South Korea, Australia, and Europe1
Please refer to the Zebra Declaration of Conformity (DoC) for details of other country
markings. This is available at http://www.zebra.com/doc.
Operation of the device without regulatory approval is illegal.
Note1: Europe includes, Austria, Belgium, Bulgaria, Croatia, Czech Republic, Cyprus,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy,
Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland,
Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland and the
United Kingdom.
Country Selection - Worldwide Version Only
Select only the country in which you are using the device. Any other selection will make
the operation of this device illegal.
NOTE This step is not required for networks supporting
Power-over-Ethernet (POE).
NOTE Connect the reader to a network that supports host
name registration and lookup to ensure the network can
access the reader using the host name. For instance,
some networks can register host names through DHCP.
When first connecting to the reader, it is recommended to
keep DHCP enabled in both the PC and in the reader,
although it is not guaranteed that host name will work all
the time.
As an alternative to using the host name on the reader
label, construct it using the reader MAC address on the
bottom of the reader. To do this, enter the prefix FX7500,
followed by the last six characters of the MAC address.
For example, for a MAC address of 0023683BA63A, use
the prefix FX7500, followed by 3BA63A.
Enter http://FX75003BA63A in the browser address bar
to access the reader.
Port 1 Port 2 Port 3 Port 4 GPI
Antenna Port 1
Port 4 GPIO 24 VDC
Power
10/100BaseT Ethernet Port
(with POE)
FX7500 US and Canada EU Taiwan
Max Conducted RF
Power at Antenna
Input
+ 30.0dBm with +
6.0dBiL max gain
antenna or +
29.36dBm with +
6.6dBiL max gain
antenna
+29.2 dBm + 29.79dBm with +
6.0dBiL max gain
antenna or +
29.36dBm with +
6.6dBiL max gain
antenna
Max Antenna Gain
Allowed
+ 6.6dBiL +5.5 dBiL + 6.6dBiL
Max Radiated Power
Allowed
4W EIRP 2W ERP 4W EIRP
Antenna Type Circularly Polarized
Plate
N/A Circularly Polarized
Plate
Draft 2
5 6 74
Frequency of Operation – USA (FCC) and Canada
The range of channels is limited by firmware.
Radio Frequency Interference Requirements - FCC
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is
no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna
•
Increase the separation between the equipment and receiver
•
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
•
Consult the dealer or an experienced radio/TV technician for help
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Radio Frequency Interference Requirements - Canada
CAN ICES-3 (B)/NMB-3(B)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Transmitters
This device is in compliance with the NRC for Industry Canada applicable to license-
exempt radios. Use is allowed with the following two conditions: (1) the device must not
produce interference, and (2) the device must accept any interference to the radio even
if the interference is likely to compromise operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radio électrique subi même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Label Marking: The Term "IC:" before the radio certification only signifies that Industry
Canada technical specifications were met.
In accordance with the regulations of Industry Canada, this radio transmitter can
operate with an antenna of a type and a maximum gain (or lower) approved for the
transmitter by Industry Canada. With the aim of reducing the risk of radio interference to
other users, the chosen antenna type and its gain should be selected so that the
equivalent isotropically radiated power (e.i.r.p.) does not exceed the intensity necessary
for the establishment of a satisfactory connection.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé
pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radio électrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et
son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse
pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
The FX7500 has been approved by Industry Canada to operate with the antenna types
listed below and having a maximum gain allowable and the impedance required for
each type of antenna. The antenna types not included in this list, or whose gain is higher
than the maximum gain indicated, are strictly prohibited for the operation of the
transmitter.
Le FX7500 a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance
requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste ou
dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
Circular polarized plate +6.6dBiL 50ohms
Marking and European Economic Area (EEA)
RFID devices for use throughout the EEA have the following restrictions:
•
Maximum radiated transmit power of 2W ERP in the frequency range 865.6-
867.6MHz.
The use of RFID Devices has varying restrictions for use within the EEA; please refer to
the Zebra Declaration of Conformity (DoC) for details at: http://www.zebra.com/doc.
Statement of Compliance
Zebra hereby declares that this radio equipment is in compliance with Directive 2011/65/
EU and 1999/5/EC or 2014/53/EU (2014/53/EU supersedes 1999/5/EC from 13th June
2017).
The full text of the EU Declaration of Conformity is available at the following internet
address: http://www.zebra.com/doc.
Country Approvals
Brasil
Declarações Regulamentares para FX7500 - Brasil
Nota: A marca de certificação se aplica ao Transceptor, modelo FX7500. Este
equipamento opera em caráter secundário, isto é, não tem direito a proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário.
Para maiores informações sobre ANATEL consulte o site: www.anatel.gov.br
Chile
Este equipo cumple con la Resolución No 403 de 2008, de la Subsecretaria de
telecomunicaciones, relativa a radiaciones electromagnéticas.
China
www.zebra.com/contact
Korea Warning Statement for Class B ITE
Taiwan
臺灣
低功率電波輻射性電機管理辦法
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻
率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立
即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
Operation of the device without regulatory approval is illegal.
Thailand
เครื่ องโทรคมนาคมและอปกรณนี้ มีความสอดคลองตามขอกําหนดของ กทช .
Ukraine
Дане обладнання відповідає вимогам технічного регламенту №1057, № 2008 на
обмеження щодо використання деяких небезпечних речовин в електричних та
електронних пристроях.
Waste Electrical and Electronic Equipment
(WEEE)
English: For EU Customers: All products at the end of their life must be returned to
Zebra for recycling. For information on how to return product, please go to:
http://www.zebra.com/weee.
Bulgarish: За клиенти от ЕС: След края на полезния им живот всички продукти
трябва да се връщат на Zebra за рециклиране. За информация относно
връщането на продукти, моля отидете на адрес: http://www.zebra.com/weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po skonèení jejich životnosti
vrátit spoleènosti Zebra k recyklaci. Informace o zpùsobu vrácení produktu najdete na
webové stránce: http://www.zebra.com/weee.
Dansk: Til kunder i EU: Alle produkter skal returneres til Zebra til recirkulering, når de er
udtjent. Læs oplysningerne om returnering af produkter på:
http://www.zebra.com/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebens-
dauer zum Recycling an Zebra zurückgesandt werden. Informationen zur Rücksendung
von Produkten finden Sie unter http://www.zebra.com/weee.
Ελληνικά: Για πελάτες στην Ε.Ε.: Όλα τα προϊόντα, στο τέλος της διάρκειας ζωής τους,
πρέπει να επιστρέφονται στην Zebra για ανακύκλωση. Για περισσότερες πληροφορίες
σχετικά με την επιστροφή ενός προϊόντος, επισκεφθείτε τη διεύθυνση
http://www.zebra.com/weee στο Διαδίκτυο.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada taaskasutamise
eesmärgil Zebra'ile. Lisainformatsiooni saamiseks toote tagastamise kohta külastage
palun aadressi: http://www.zebra.com/weee.
Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a
Zebra al final de su ciclo de vida para que sean reciclados. Si desea más información
sobre cómo devolver un producto, visite: http://www.zebra.com/weee.
Français : Clients de l'Union Européenne : Tous les produits en fin de cycle de vie
doivent être retournés à Zebra pour recyclage. Pour de plus amples informations sur le
retour de produits, consultez : http://www.zebra.com/weee.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine del rispettivo ciclo
di vita devono essere restituiti a Zebra al fine di consentirne il riciclaggio. Per informazi-
oni sulle modalità di restituzione, visitare il seguente sito Web:
http://www.zebra.com/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas mūža beigām ir jānogādā atpa-
kaļ Zebra otrreizējai pārstrādei. Lai iegūtu informāciju par produktu nogādāšanu Zebra,
lūdzu, skatiet: http://www.zebra.com/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų eksploatacijos laikui, turi būti
grąžinti utilizuoti į kompaniją „Zebra“. Daugiau informacijos, kaip grąžinti gaminį, rasite:
http://www.zebra.com/weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Zebra vállalathoz kell
eljuttatni újrahasznosítás céljából. A termék visszajuttatásának módjával kapcsolatos
tudnivalókért látogasson el a http://www.zebra.com/weee weboldalra.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu fl-aħħar tal-ħajja ta' l-użu
tagħhom, iridu jiġu rritornati għand Zebra għar-riċiklaġġ. Għal aktar tagħrif dwar kif
għandek tirritorna l-prodott, jekk jogħġbok żur: http://www.zebra.com/weee.
Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun lev-
ensduur naar Zebra te worden teruggezonden voor recycling. Raadpleeg
http://www.zebra.com/weee voor meer informatie over het terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane z eksploatacji nale¿y
zwróciæ do firmy Zebra w celu ich utylizacji. Informacje na temat zwrotu produktów zna-
jduj¹ siê na stronie internetowej http://www.zebra.com/weee.
Português: Para clientes da UE: todos os produtos no fim de vida devem ser devolvi-
dos à Zebra para reciclagem. Para obter informações sobre como devolver o produto,
visite: http://www.zebra.com/weee.
Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul duratei lor de funcţion-
are, trebuie returnate la Zebra pentru reciclare. Pentru informaţii despre returnarea pro-
dusului, accesaţi: http://www.zebra.com/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky musia byť po uplynutí doby
ich životnosti vrátené spoločnosti Zebra na recykláciu. Bližšie informácie o vrátení
výrobkov nájdete na: http://www.zebra.com/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti pod-
jetju Zebra za reciklažo. Za informacije o vraèilu izdelka obišèite:
http://www.zebra.com/weee.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on palautettava kier-
rätettäväksi Zebra-yhtiöön, kun tuotetta ei enää käytetä. Lisätietoja tuotteen palautta-
misesta on osoitteessa http://www.zebra.com/weee.
Svenska: För kunder inom EU: Alla produkter som uppnått sin livslängd måste return-
eras till Zebra för återvinning. Information om hur du returnerar produkten finns på
http://www.zebra.com/weee.
Türkçe: AB Müşterileri için: Kullanım süresi dolan tüm ürünler geri dönüştürme için
Zebra'ya iade edilmelidir. Ürünlerin nasıl iade edileceği hakkında bilgi için lütfen şu
adresi ziyaret edin: http://www.zebra.com/weee.
TURKISH WEEE Statement of Compliance
EEE Yönetmeligine Uygundur
China RoHS
This table was created to comply with China RoHS requirements.
本表格依据SJ/T 11364 的规定编制。
O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定
的限量要求以下。
X: 表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572
规定的限量要求。( 企业可在此处，根据实际情况对上表中打 “×” 的
技术原因进行进一步说明。）
This table was created to comply with China RoHS requirements.
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems
Support. If there is a problem with the equipment, they will contact Zebra Support at:
http://www.zebra.com/support.
For the latest version of FX7500 guides and software, go to:
http://www.zebra.com/support.
Warranty
For the complete Zebra hardware product warranty statement, go to:
http://www.zebra.com/warranty.
For Australia Only:
For Australia Only. This warranty is given by Zebra Technologies Asia Pacific Pte. Ltd.,
71 Robinson Road, #05-02/03, Singapore 068895, Singapore. Our goods come with
guarantees that cannot be excluded under the Australia Consumer Law. You are enti-
tled to a replacement or refund for a major failure and compensation for any other rea-
sonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Zebra Technologies Corporation Australia’s limited warranty above is in addition to any
rights and remedies you may have under the Australian Consumer Law. If you have any
queries, please call Zebra Technologies Corporation at +65 6858 0722. You may also
visit our website: http://www.zebra.com for the most updated warranty terms.
部件名称
(Parts)
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
金属部件
(Metal Parts)
XOO O O O
电路模块
(Circuit Modules)
XOO O O O
电缆及电缆组件
(Cables and Cable
Assemblies)
OOO O O O
塑料和聚合物部件
(Plastic and Polymeric
Parts)
OOO O O O
光学和光学组件
(Optics and Optical
Components)
OOO O O O
电池
(Batteries)
OOO O O O
•
10
Draft 2
