Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
Deleting a Program will completely remove the
Program from the Stimulator. Once the Program
is deleted, it cannot be recovered. Programs that
were configured by your healthcare provider cannot
be deleted and do not appear on the “Delete”
Program list. Only Programs that were created using
the “Copy To…” feature can be deleted.
1
From the Main Menu
, press to
select Programs
P
.
Programs
P
Stimulation Areas
Main Menu
System Settings
SelectBack
Delete a Program
PROGRAMS Page 33
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
Restore to
Clinic Settings
Programs
Change Program
Save
Copy to ...
Delete
SelectBack
1Delete
Program3
SelectBack
1
3
2 3
Navigate to Delete
and press .
Navigate to the
Program you wish to
delete and press .
Delete
Yes
No
SelectBack
Delete?
Program3
3
4
Navigate to Yes
to confirm or No
to cancel, then
press .
Page 34
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
This page intentionally left blank.
What is a Stimulation Area? ......................................36
Change a Stimulation Area Parameter .......................37
Save and Restore an Area in a Program .....................40
Confi guring Stimulation Areas
Page 36
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
A Stimulation Area is the building block
of a Program
P
. Each Program can include
settings for up to 4 Stimulation Areas. Each
Stimulation Area is identified by a letter and
a name, such as
A B
... “Area A”.
These Stimulation Areas control parameters
that can affect your stimulation therapy.
These parameters are Amplitude ,
Pulse Width , and Rate . If your
healthcare provider has configured these
parameters to be adjustable, they can be
changed and balanced for each individual
Stimulation Area.
Stimulation Areas
Area B
Area C
Area D
SelectBack
Area A
A
B
C
D
1
Pulse Width
Amplitude
Area A
Rate
SelectBack
A
1
What is a Stimulation Area?
AREAS Page 37
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
Stimulation Areas
Area B
Area C
Area D
SelectBack
Area A
A
B
C
D
1
Pulse Width
Amplitude
Area A
Rate
SelectBack
A
1
1 3
Programs
P
Stimulation Areas
Main Menu
System Settings
SelectBack
From the Main Menu
press to navigate to
Stimulation Areas , then
press to select it.
Navigate to the Area
that you want to adjust
and press .
Navigate to the
parameter that you want
to adjust and press .
2
continued to next page
Change a Stimulation Area Parameter
Page 38
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
Stimulation Areas
Area B
Area C
Area D
SelectBack
Area A
A
B
C
D
1
Pulse Width
Amplitude
Area A
Rate
SelectBack
A
1
4
A
1
Amplitude
4.6
mA
Area A
Back
A
1
5
Press the and
buttons to decrease and
increase the value for
the selected parameter.
To change another parameter, press the left
Navigation button to return to the Area parameter
menu. Repeat steps 3 - 4. To change a parameter in
a different Area, return to the Area list in step 2.
AREAS Page 39
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
6
When all desired changes
have been made, press
repeatedly until you return
to the Home Screen.
1
Program 1
Main Menu
52.1
%
Note
Increasing the values
for these parameters,
especially Rate , may
significantly increase
the energy required for
stimulation. This may
lead to longer or more
frequent recharging of
the Stimulator.
Page 40
Precision Spectra™ Remote Control Handbook, 90668562-01, Rev C
To save any Area parameter changes so that they are the default parameters,
you must save the Program
P
. This will save all changes to any Area
within that Program. You cannot save the changes for each individual Area
independently of changes for other Areas in the same Program. See
Save a Program
page 26
.
If, after saving changes to a Stimulation Area in a Program, you decide that you
want to revert the Stimulation Area back to the way it was configured by your
healthcare provider, you can do so by restoring the Program
P
. Restoring the
Program will restore all of the Stimulation Areas of that Program. See
Restore a Program
page 28
.
Save and Restore an Area in a Program
