APPENDIX A
Specifications
NOTE: Specifications are subject to change without any prior notices.
Parts Specifications
CPU Pentium III / Celeron series microprocessors, µPGA2 or BGA2
package
Cache Memory 128 KB on-die (integrated with Celeron CPU)
256 KB on-die (integrated with Pentium III CPU)
ROM BIOS 256 KB Flash EEPROM
System 64 MB or 128 MB SDRAM SO-DIMM RAM
Video 4 MB (built-in on VGA chip)
Panel 10.4-inch TFT XVGA LCD, resolution up to 1024×768, 18-bit color
Video controller Integrated into ATI 3D RAGE Mobility-M or M1, hardware 2D/3D
video/graphics accelerator
Display
Video port VGA port via optional Port Replicator module
Keyboard (external/wireless) –
optional Standard keys, numeric keypad, 12 function keys, and Windows keys
Pointing device Touchscreen pen or wireless keyboard/mouse
Floppy disk drive 3.5-inch, 1.44 MB (via optional USB FDD module on Expansion port)
Hard disk drive 2.5-inch, IDE, Ultra DMA33 supported
Storage
device
CD/DVD drive 24X CD-ROM or above
8X DVD-ROM or above
(both via optional CD/DVD-ROM module on Expansion port)
Audio controller Integrated into Crystal codec CS4299, 20-bit stereo digital-to-analog
and 18-bit stereo analog-to-digital converter, Windows Sound System
compatibility and full-duplex capability
Audio
Audio port Two audio ports for Mic-in / Line-out
PC Card Type II x 1, PCMCIA 2.1 compliant, ZV Port and CardBus support
A-2 Specifications
Parts Specifications
On front panel IR port for wireless keyboard/mouse
On left side HP-SIR port, RJ-11 fax/modem port
On right side Serial port, Mic-in, Line-out
On underside CCD port (USB-type)
X-Bay interface
(option) IEEE 1394, serial ports, RJ-45
I/O ports
Expansion port
(option) USB port (supports USB FDD boot-up function), serial port, ECP/EPP
parallel port, PS/2 port, Mic-in/Line-in/Line-out, CD-audio
Modem 56 Kbps internal Fax Modem
LAN Fast Ethernet, 10/100 Mbps auto-negotiation
AC adapter 100∼240 V AC, 50∼60 Hz auto-switching
Car adapter 10.7~32 V DC
Primary
battery Li-ion battery, 4 cells
Power
Secondary
battery
(option)
Li-ion battery, 6 cells
Dimension (W×D×H) 11.6×9.3×1.65 inch (295×236×42 mm)
Weight 4.84 lb (2.2 kg) – without secondary battery pack
Temperature Operating: 0°C (32°F) to 45°C (113°F)
Storage: –40°C (–40°F) to 70°C (158°F)
Environment
Humidity Operating: 5% to 95% RH, non-condensing
