STAREX-IS BSM Manual Page:629(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-83 CAN Rack FAN Fail 5.1.1.2. BSC Occurrence Alarm Message 5.1.1.2.1. CCSB 5.1.1.2.1.1. CCP Processor 1) When A-Side of the duplicated CCP is normal and functional problems occur on the B-Side board Fig. 5.1-84 CCSB CCP Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated CCP has a functional problem Fig. 5.1-85 CCSB CCP Dual Function Fail 3) When A-Side of the duplicated CCP is normal and B-Side board is removed
STAREX-IS BSM Manual Page:630(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-86 CCSB CCP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated CCP is removed Fig. 5.1-87 CCSB CCP Dual Board Open Fail 5.1.1.2.1.2. SCP Processor 1) When A-Side of the duplicated SCP is normal and functional problems occur on the B-Side board Fig. 5.1-88 CCSB SCP Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated SCP has a functional problem
STAREX-IS BSM Manual Page:631(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-89 CCSB SCP Dual Function Fail 3) When A-Side of the duplicated SCP is normal and B-Side board is removed Fig. 5.1-90 CCSB SCP Single Board Open Fail 4) When A-Side is removed entire B-Side of the duplicated SCP is removed Fig. 5.1-91 CCSB SCP Dual Board Open Fail 5.1.1.2.1.3. STIA Board 1) When functional faults occur on STIA board
STAREX-IS BSM Manual Page:632(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-92 CCSB STIA Function Fail 2) When STIA board is removed Fig. 5.1-93 CCSB STIA Board Open Fail 5.1.1.2.1.4. PRI Board 1) When A-Side of the duplicated PRI is normal and functional problems occur on the B-Side board Fig. 5.1-94 CCSB PRI Single Power Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated PRI has a functional problem
STAREX-IS BSM Manual Page:633(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-95 CCSB PRI Dual Power Fail 3) When A-Side of the duplicated PRI is normal and B-Side board is removed Fig. 5.1-96 CCSB PRI Single Power Open Fail 4) When A-Side is removed after B-Side of the duplicated PRI is removed Fig. 5.1-97 CCSB PRI Dual Power Open Fail 5.1.1.2.1.5. Others 1) When ABID board is removed
STAREX-IS BSM Manual Page:634(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-98 CCSB ABID Board Open 2) When CCP does not receive 1pps Clock from GPSD normally Fig. 5.1-99 CCSB 1PPS Clock Fail 3) When CCP does not receive 10MHz Clock from GPSD normally Fig. 5.1-100 CCSB 10MHz Clock Fail 4) When faults occur in SubHiway Cable between STIA and VLIA
STAREX-IS BSM Manual Page:635(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-101 CCSB STIA SHW Link Fail 5) When faults occur in CCBU Alarm Cable Fig. 5.1-102 CCSB Alarm Cable Open 5.1.1.2.2. ASMB 5.1.1.2.2.1. NCP Processor 1) When A-Side of the duplicated NCP is normal and functional problems occur on B-Side board Fig. 5.1-103 ASMB NCP Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated NCP has a functional problem Fig. 5.1-104 ASMB NCP Dual Function Fail
STAREX-IS BSM Manual Page:636(877)Issue:1.0SMD-011-PMA210 3) When A-Side of the duplicated NCP is normal and B-Side board is removed Fig. 5.1-105 ASMB NCP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated NCP is removed Fig. 5.1-106 ASMB NCP Dual Board Open Fail 5.1.1.2.2.2. ASCA Board 1) When A-Side of the duplicated ASCA is normal and functional problems occur on the B-Side board Fig. 5.1-107 ASMB ASCA Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated ASCA has a functional problem
STAREX-IS BSM Manual Page:637(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-108 ASMB ASCA Dual Function Fail 3) When A-Side of the duplicated ASCA is normal and B-Side board is removed Fig. 5.1-109 ASMB ASCA Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated ASCA is removed Fig. 5.1-110 ASMB ASCA Dual Board Open Fail 5.1.1.2.2.3. ASIA Board 1) When A-Side of the duplicated ASIA is normal and functional problems occur on the B-Side board
STAREX-IS BSM Manual Page:638(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-111 ASMB ASIA Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated ASIA has a functional problem Fig. 5.1-112 ASMB ASIA Dual Function Fail 3) When A-Side of the duplicated ASIA is normal and B-Side board is removed Fig. 5.1-113 ASMB ASIA Single Board Fail 4) When A-Side is removed after B-Side of the duplicated ASIA is removed
STAREX-IS BSM Manual Page:639(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-114 ASMB ASIA Dual Board Open Fail 5.1.1.2.2.4. ATSA Board 6) When functional problems occur on ATSA board Fig. 5.1-115 ASMB ATSA Function Fail 7) When ATSA board is removed Fig. 5.1-116 ASMB ATSA Board Open Fail 5.1.1.2.2.5. PRI Board 1) When A-Side of the duplicated PRI is normal and functional problems occur on the B-Side board
STAREX-IS BSM Manual Page:640(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-117 ASMB PRI Single Power Fail 2) When functional problems occur on the A-Side and B-Side of the duplicated PRI has a functional problem Fig. 5.1-118 ASMB PRI Dual Power Fail 3) When A-Side of the duplicated PRI is normal and B-Side board is removed Fig. 5.1-119 ASMB PRI Single Power Open Fail 4) When A-Side is removed after B-Side of the duplicated PRI is removed
STAREX-IS BSM Manual Page:641(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-120 ASMB PRI Dual Power Open Fail 5.1.1.2.2.6. Others 1) When ASMB Alarm Cable opens Fig. 5.1-121 ASMB Alarm Cable Open 5.1.1.2.3. ALSB 5.1.1.2.3.1. ALP Processor 1) When A-Side of the duplicated ALP is normal and functional problems occur on the B-Side board Fig. 5.1-122 ASLB ALP Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated ALP has a functional problem
STAREX-IS BSM Manual Page:642(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-123 ASLB ALP Dual Function Fail 3) When A-Side of the duplicated ALP is normal and B-Side board is removed Fig. 5.1-124 ASLB ALP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated ALP is removed Fig. 5.1-125 ASLB ALP Dual Board Open Fail 5.1.1.2.3.2. ALMA Board 1) When A-Side of the duplicated ALMA is normal and functional problems occur on the B-Side board
STAREX-IS BSM Manual Page:643(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-126 ASLB ALMA Single Function Fail 2) When functional problems occur A-Side after B-Side of the duplicated ALMA has a functional problem Fig. 5.1-127 ASLB ALP Dual Function Fail 3) When A-Side of the duplicated ALMA is normal and B-Side board is removed Fig. 5.1-128 ASLB ALP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated ALMA is removed
STAREX-IS BSM Manual Page:644(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-129 ASLB ALP Dual Board Open Fail 5.1.1.2.3.3. ALPA Board 1) When functional faults occur on ALPA board Fig. 5.1-130 ASLB ALPA Function Fail 2) When ALPA board is removed Fig. 5.1-131 ASLB ALPA Board Open Fail 5.1.1.2.3.4. PRI Board 1) When A-Side of the duplicated PRI is normal and functional problems occur on the B-Side board
STAREX-IS BSM Manual Page:645(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-132 ASLB PRI Single Power Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated PRI has a functional problem Fig. 5.1-133 ASLB PRI Dual Power Fail 3) When A-Side of the duplicated PRI is normal and B-Side board is removed Fig. 5.1-134 ASLB PRI Single Power Open Fail 4) When A-Side is removed after B–Side of the duplicated PRI is removed
STAREX-IS BSM Manual Page:646(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-135 ASLB PRI Dual Power Open Fail 5.1.1.2.3.5. Others 1) When ALSB Shelf Alarm Cable is removed Fig. 5.1-136 ASLB Alarm Cable Open 2) When Loss Of Signal Error occurs in ALPA link Fig. 5.1-137 ASLB ALPA Link Fail((LOS) 3) When Out Of Frame Error occurs in ALPA link
STAREX-IS BSM Manual Page:647(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-138 ASLB ALPA Link Fail((OOF) 4) When Alarm Indication Signal Error occurs in ALPA link Fig. 5.1-139 ASLB ALPA Link Fail((AIS) 5) When Remote Alarm Indication Error occurs in ALPA link Fig. 5.1-140 ASLB ALPA Link Fail((RAI) 5.1.1.2.4. SLB 5.1.1.2.4.1. SMP(SLMA) Processor 1) When functional faults occur on SLMA board
STAREX-IS BSM Manual Page:648(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-141 SLB SMP Function Fail 2) When SLMA board is removed Fig. 5.1-142 SLB SMP Board Open Fail 5.1.1.2.4.2. SLPA Board 1) When functional faults occur on SLPA board Fig. 5.1-143 SLB SLPA Function Fail 2) When SLPA board is removed
STAREX-IS BSM Manual Page:649(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-144 SLB SLPA Board Open Fail 5.1.1.2.4.3. PRI 1) When functional faults occur on PRI board Fig. 5.1-145 SLB PRI Power Fail 2) When PRI board is removed Fig. 5.1-146 SLB PRI Power Open Fail 5.1.1.2.4.4. Others 1) When SLB Shelf Alarm Cable is removed
STAREX-IS BSM Manual Page:650(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-147 SLB Alarm Cable Open 2) When Clock Cable is removed from CCP Fig. 5.1-148 SLB SMP Clock Fail 3) When SAID board is removed Fig. 5.1-149 SLB SMP SAID Open Fail 5.1.1.2.5. VCB 5.1.1.2.5.1. VMP(VCMA) Processor 1) When functional problems occur on VCMA board
STAREX-IS BSM Manual Page:651(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-150 VCB VMP Function Fail 2) When VCMA board is removed Fig. 5.1-151 VCB VMP Board Open Fail 5.1.1.2.5.2. VCPA Board 1) When functional faults occur on VCPA board Fig. 5.1-152 VCB VCPA Function Fail 2) When VCPA board is removed
STAREX-IS BSM Manual Page:652(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-153 VCB VCPA Board Open Fail 5.1.1.2.5.3. VLIA Board 1) When a functional board occurs on VLIA board Fig. 5.1-154 VCB VLIA Function Fail 2) When VLIA board is removed Fig. 5.1-155 VCB VLIA Board Open Fail 3) When Remote Error occurs in the link between VLIA and MSC
STAREX-IS BSM Manual Page:653(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-156 VCB VLIA Link Fail(Remote Error) 4) When Local Error occurs in the link between VLIA and MSC Fig. 5.1-157 VCB VLIA Link Fail(Local Error) 5) When SLIP Error occurs in the link between VLIA and MSC Fig. 5.1-158 VCB VLIA Link Fail(SLIP Error) 6) When BIT Error occurs in the link between VLIA and MSC
STAREX-IS BSM Manual Page:654(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-159 VCB VLIA Link Fail(BIT Error) 5.1.1.2.5.4. PRI 1) When functional faults occur on PRI board Fig. 5.1-160 VCB PRI Power Fail 2) When PRI board is removed Fig. 5.1-161 VCB PRI Power Open Fail 5.1.1.2.5.5. Others 1) When VCB Shelf Alarm Cable is removed Fig. 5.1-162 VCB Alarm Cable Open 2) When Clock Cable is removed from CCP
STAREX-IS BSM Manual Page:655(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-163 VCB VMP Clock Cable Open Fail 3) When SAID board is removed Fig. 5.1-164 VCB SAID Board Open 5.1.1.2.6. FAN and Others 1) When a problem occurs in BSC FAN Fig. 5.1-165 VCB Rack FAN Fail 5.1.1.3. BTS Occurrence Alarm Message 5.1.1.3.1. BSPB 5.1.1.3.1.1. BSP Processor 1) When A-Side of the duplicated BSP is normal and functional problems occur on the B-Side board
STAREX-IS BSM Manual Page:656(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-166 BSPB BSP Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated BSP has a functional problem Fig. 5.1-167 BSPB BSP Dual Function Fail 3) When A-Side of the duplicated BSP is normal and B-Side board is removed Fig. 5.1-168 BSPB BSP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated BSP is removed
STAREX-IS BSM Manual Page:657(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-169 BSPB BSP Dual Board Open Fail 5.1.1.3.1.2. PRI within BSPB, BANB Unit 1) When A-Side of the duplicated PRI is normal and functional problems occur on the B-Side board Fig. 5.1-170 BSPB PRI Single Power Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated PRI has a functional problem Fig. 5.1-171 BSPB PRI Dual Power Fail 3) When A-Side of the duplicated PRI is normal and B –Side board is removed
STAREX-IS BSM Manual Page:658(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-172 BSPB PRI Single Power Open Fail 4) When A-Side is removed after B-Side of the duplicated PRI is removed Fig. 5.1-173 BSPB PRI Dual Power Open Fail 5.1.1.3.1.3. Others 1) When BSP does not receive 1pps Clock from GPSD normally Fig. 5.1-174 BSPB BSP 1PPS Clock Fail 2) When BSP does not receive 10MHz Clock from GPSD normally
STAREX-IS BSM Manual Page:659(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-175 BSPB BSP 10MHz Clock Fail 5.1.1.3.2. BANB 5.1.1.3.2.1. ARIA Board 1) When functional faults occur on ARIA board Fig, 5.1-176 BANB ARIA Function Fail 2) When ARIA board is removed Fig. 5.1-177 BANB ARIA Board Open Fail 5.1.1.3.2.2. BPPA Board 1) When functional faults occur on BPPA board
STAREX-IS BSM Manual Page:660(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-178 BANB BPPA Function Fail 2) When BPPA board is removed Fig. 5.1-179 BANB BPPA Board Open Fail 5.1.1.3.2.3. BCRA Board 1) When A-Side of the duplicated BCRA is normal and functional problems occur on the B-Side board Fig. 5.1-180 BANB BCRA Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated BCRA has a functional problem
STAREX-IS BSM Manual Page:661(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-181 BANB BCRA Dual Function Fail 3) When A-Side of the duplicated BCRA is normal and B-Side board is removed Fig. 5.1-182 BANB BCRA Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated BCRA is removed. Fig. 5.1-183 BANB BCRA Dual Board Open Fail 5.1.1.3.2.4. LICA Board 1) When functional faults occur on LICA board
STAREX-IS BSM Manual Page:662(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-184 BANB LICA Function Fail 2) When LICA board is removed Fig. 5.1-185 BANB LICA Board Fail 5.1.1.3.3. BSTB 5.1.1.3.3.1. BADA Board 1) When BADA Board Alarm Cable is removed Fig. 5.1-186 BSTB BADA Alarm Cable Open 2) When a problem occurs in BADA Board power
STAREX-IS BSM Manual Page:663(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-187 BSTB BADA Power Fail 3) When functional faults occur on BADA board Fig. 5.1-188 BSTB BADA Function Fail 5.1.1.3.4. RISB 5.1.1.3.4.1. RISA Board 1) When RISA Board Alarm Cable is removed Fig. 5.1-189 RISB RISA Alarm Cable Open 2) When a problem occurs in RISA board power
STAREX-IS BSM Manual Page:664(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-190 RISB RISA Power Fail 3) When functional faults occur on RISA board Fig. 5.1-191 RISB RISA Function Fail 5.1.1.3.5. BOTB 5.1.1.3.5.1. BOTA Board 1) When BOTA Board Alarm Cable is removed Fig. 5.1-192 BOTB BOTA Alarm Cable Open 2) When a problem occurs in BOTA board power
STAREX-IS BSM Manual Page:665(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-193 BOTB BOTA Power Fail 3) When functional faults occur on BOTA board Fig. 5.1-194 BOTB BOTA Board Open Fail 5.1.1.3.6. BTGB 5.1.1.3.6.1. GPS-R Board 1) When A-Side of the duplicated GPSR is normal and functional problems occur on B –Side board Fig. 5.1-195 BTGB GPS Single Function Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated GPSR has a functional problem
STAREX-IS BSM Manual Page:666(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-196 BTGB GPS Dual Function Fail 3) When A-Side of the duplicated GPSR is normal and faults occur in B-Side power Fig. 5.1-197 BTGB GPS Single Power Fail 4) When a problem occurs in A-Side power after B-Side power of the duplicated GPSR has a problem Fig. 5.1-198 BTGB GPS Dual Power Fail 5) When A-Side of the duplicated GPSR is normal and B-Side board is removed
STAREX-IS BSM Manual Page:667(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-199 BTGB GPS Single Board Open Fail 6) When A-Side is removed after B-Side of the duplicated GPSR is removed Fig. 5.1-200 BTGB GPS Dual Board Open Fail 7) When GPSR Control Cable is removed Fig. 5.1-201 BTGB GPS Control Cable Open 8) When GPSR Alarm Cable is removed
STAREX-IS BSM Manual Page:668(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-202 BTGB GPS Alarm Cable Open 5.1.1.3.7. DBPB 5.1.1.3.7.1. DBPA Board 1) When functional faults occur on DBPA board Fig. 5.1-203 DBPB DBPA Function Fail 2) When DBPA board is removed Fig. 5.1-204 DBPB DBPA Board Open Fail 5.1.1.3.8. RCCB 5.1.1.3.8.1. RCP Processor 1) When A-Side of the duplicated RCP is normal and functional problems occur on the B-Side board Fig. 5.1-205 RCCB RCP Single Function Fail
STAREX-IS BSM Manual Page:669(877)Issue:1.0SMD-011-PMA210 2) When functional problems occur on the A-Side after B-Side of the duplicated RCP has a functional problem Fig. 5.1-206 RCCB RCP Dual Function Fail 3) When A-Side of the duplicated RCP is normal and B-Side board is removed Fig. 5.1-207 RCCB RCP Single Board Open Fail 4) When A-Side is removed after B-Side of the duplicated RCP is removed Fig. 5.1-208 RCCB RCP Dual Board Open Fail 5.1.1.3.8.2. BUDA Board 1) When functional faults occur on BUDA board
STAREX-IS BSM Manual Page:670(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-209 RCCB BUDA Function Fail 2) When BUDA board is removed Fig. 5.1-210 RCCB BUDA Board Open Fail 5.1.1.3.8.3. PACA Board 1) When functional faults occur on PACA board Fig. 5.1-211 RCCB PACA Function Fail 2) When PACA board is removed
STAREX-IS BSM Manual Page:671(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-212 RCCB PACA Board Open Fail 5.1.1.3.8.4. PRI Board for Providing DBPB/RCCB UNIT Power 1) When A-Side of the duplicated PRI is normal and functional problems occur on the B-Side board Fig. 5.1-213 DBPB/RCCB PRI Single Power Fail 2) When functional problems occur on the A-Side after B-Side of the duplicated PRI has a functional problem Fig. 5.1-214 DBPB/RCCB PRI Dual Power Fail 3) When A-Side of the duplicated PRI is normal and B-Side board is removed
STAREX-IS BSM Manual Page:672(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-215 DBPB/RCCB PRI Single Power Open Fail 4) When A-Side is removed after B-Side of the duplicated PRI is removed Fig. 5.1-216 DBPB/RCCB PRI Dual Power Open Fail 5.1.1.3.8.5. Others 1) When DBPB/RCCB UNIT Alarm Cable is removed Fig. 5.1-217 DBPB/RCCB Alarm Cable Open 5.1.1.3.9. LPAB 5.1.1.3.9.1. LPAU Board 1) When LPAB Alarm Cable is removed
STAREX-IS BSM Manual Page:673(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-218 LPAB Alarm Cable Open 2) When functional faults occur in LPAB Combiner Fig. 5.1-219 LPAB LPA Combiner Fail 3) When faults occur in LPAB Combiner FAN Fig. 5.1-220 LPAB LPA Combiner FAN Fail 4) When LPA board is removed
STAREX-IS BSM Manual Page:674(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-221 LPAB LPA Board Open Fail 5) When functional faults occur on LPA board Fig. 5.1-222 LPAB LPA Board Function Fail 6) When DC power of LPA board is unstable Fig. 5.1-223 LPAB LPA DC/DC Alarm 7) When much RF power is reflected in output end of LPA board Fig. 5.1-224 LPAB LPA VSWR Alarm 8) When LPA board is disabled
STAREX-IS BSM Manual Page:675(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-225 LPAB LPA Disable Alarm 9) When input power level of LPA board is high Fig. 5.1-226 LPAB LPA Over Power Warning 10) When LPA board temperature is high Fig. 5.1-227 LPAB LPA Over Temperature Alarm 11) When input Power level of LPA board is high
STAREX-IS BSM Manual Page:676(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-228 LPAB LPA Over Power Alarm 5.1.1.3.10. HPAB 5.1.1.3.10.1. HPA Board 1) When HPAB Alarm Cable is removed Fig. 5.1-229 HPAB HPA Alarm Cable Open 2) When HPA board is removed Fig. 5.1-230 HPAB HPA Board Open Fail 3) When functional faults occur on HPA board Fig. 5.1-231 HPAB HPA Power Fail 4) When faults occur in HPA Board Power Supply
STAREX-IS BSM Manual Page:677(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-232 HPAB HPA Power Supply Alarm 5) When much RF power is reflected in HPA output end Fig. 5.1-233 HPAB HPA VSWR Alarm 6) When HPA board is disabled Fig. 5.1-234 HPAB HPA Disable Alarm 7) When HPA board temperature is high Fig. 5.1-235 HPAB HPA Over Temperature Alarm 8) When input Power level of HPA board is high
STAREX-IS BSM Manual Page:678(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-236 HPAB HPA Over Power Alarm 5.1.1.3.11. CFEB 5.1.1.3.11.1. LNA Board 1) When LNA Alarm Cable board is removed Fig. 5.1-237 CFEB LNA Alarm Cable Open Fail 2) When LNA board is removed Fig. 5.1-238 CFEB LNA Board Open Fail 3) When functional faults occur on LNA board Fig. 5.1-239 CFEB LNA Function Fail 5.1.1.3.12. Environment Alarm 1) When outdoor BTS Environment Alarm Cable is removed
STAREX-IS BSM Manual Page:679(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-240 Outdoor BTS ENV Alarm Cable Open 2) When outdoor BTS Rectifier Alarm Cable is removed Fig. 5.1-241 Outdoor BTS ENV Rectifier Unit Alarm Cable Open 3) When outdoor BTS Cold Starter fails Fig. 5.1-242 Outdoor BTS ENV Cold Starter Fail 4) When outdoor BTS Rectifier Unit fails
STAREX-IS BSM Manual Page:680(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-243 Outdoor BTS ENV Rectifier Unit Fail 5) Outdoor BTS Voltage High Alarm Fig. 5.1-244 Outdoor BTS ENV Voltage High Alarm 6) Outdoor BTS Voltage Low Alarm Fig. 5.1-245 Outdoor BTS ENV Voltage Low Alarm 7) When outdoor BTS AC fails Fig. 5.1-246 Outdoor BTS AC Fail 8) Outdoor BTS Battery Voltage Low Alarm
STAREX-IS BSM Manual Page:681(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-247 Outdoor BTS ENV Battery Low Voltage Alarm 9) Outdoor BTS Fuse/Relay Loss Alarm Fig. 5.1-248 Outdoor BTS ENV Fuse/Relay Loss Alarm 10) When outdoor BTS DMC-14 fails Fig. 5.1-249 Outdoor BTS ENV DMC-14 Fail 11) Outdoor BTS Power Cut Alarm
STAREX-IS BSM Manual Page:682(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-250 Outdoor BTS ENV Power Cut Alarm 12) Outdoor BTS Temperature High Alarm Fig. 5.1-251 Outdoor BTS ENV Temperature High Alarm 13) Outdoor BTS Temperature Low Alarm Fig. 5.1-252 Outdoor BTS ENV Temperature Low Alarm 14) Outdoor BTS Water High Alarm Fig. 5.1-253 Outdoor BTS ENV Water High Alarm 15) Outdoor BTS Water Low Alarm
STAREX-IS BSM Manual Page:683(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-254 Outdoor BTS ENV Water Low Alarm 16) Outdoor BTS Fire Alarm Fig. 5.1-255 Outdoor BTS ENV Fire Alarm 17) Outdoor BTS Humidity High Alarm Fig. 5.1-256 Outdoor BTS ENV Humidity High Alarm 18) When outdoor BTS ACU Module fails
STAREX-IS BSM Manual Page:684(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-257 Outdoor BTS ENV ACU Module Fail 19) When outdoor BTS Heat Exchanger Power fails Fig. 5.1-258 Outdoor BTS ENV Heat Exchanger Power Fail 20) When outdoor BTS Heat Exchanger fails Fig. 5.1-259 Outdoor BTS ENV Heat Exchanger Fail 21) When outdoor BTS LPA FAN fails Fig. 5.1-260 Outdoor BTS ENV LPA FAN Fail 22) When outdoor BTS AC Equipment Heater fails
STAREX-IS BSM Manual Page:685(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-261 Outdoor BTS ENV AC Equipment Heater Fail 23) Outdoor BTS Front/Rear Door Open Alarm Fig. 5.1-262 Outdoor BTS ENV Front/Rear Door Open Alarm 24) Outdoor BTS Side Door Open Alarm Fig. 5.1-263 Outdoor BTS ENV Side Door Open Alarm 25) When outdoor BTS FAN fails
STAREX-IS BSM Manual Page:686(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-264 Outdoor BTS ENV FAN Fail 26) When outdoor BTS AC Battery Heater fails Fig. 5.1-265 Outdoor BTS ENV AC Battery Heater Fail 27) Indoor BTS Temperature High Alarm Fig. 5.1-266 Indoor BTS ENV Temperature High Alarm 28) Indoor BTS Temperature Low Alarm Fig. 5.1-267 Indoor BTS ENV Temperature Low Alarm 30) Indoor BTS Flood Alarm
STAREX-IS BSM Manual Page:687(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-268 Indoor BTS ENV Flood Alarm 31) Indoor BTS Door #1 Open Alarm Fig. 5.1-269 Indoor BTS ENV Door #1 Open Alarm 32) Indoor BTS Door #2 Open Alarm Fig. 5.1-270 Indoor BTS ENV Door #2 Open Alarm 33) Indoor BTS Fire Alarm
STAREX-IS BSM Manual Page:688(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-271 Indoor BTS ENV Fire Alarm 34) When indoor BTS Rectifier #1 fails Fig. 5.1-272 Indoor BTS ENV Rectifier #1 fails 35) When indoor BTS Rectifier #2 fails Fig. 5.1-273 Indoor BTS ENV Rectifier #2 Fail 36) When indoor BTS Aircon #1 fails Fig. 5.1-274 Indoor BTS ENV Aircon #1 Fail 37) When indoor BTS Aircon #2 fails
STAREX-IS BSM Manual Page:689(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-275 Indoor BTS ENV Aircon #2 Fail 38) Indoor BTS Water Leakage Alarm Fig. 5.1-276 Indoor BTS ENV Water Leakage Alarm 5.1.1.3.13. Others 1) If a problem occurs in BTS FAN Fig. 5.1-277 BTS Rack FAN Fail 5.1.2. Fault Message 5.1.2.1. Keep-Alive-related Fault Keep-Alive Fault occurs by two reasons. One in Tx section
STAREX-IS BSM Manual Page:690(877)Issue:1.0SMD-011-PMA210 5.1.2.1.1.1. CNP Report 1) CNP  NCP section Fig. 5.1-278 Keep-Alive Fault between CNP and NCP 5.1.2.1.1.2. PNP Report 1) PNP  NCP section Fig. 5.1-279 Keep-Alive Fault between PNP and NCP 2) PNP  PCP section Fig. 5.1-280 Keep-Alive Fault between PNP and PCP 5.1.2.1.1.3. PCP Report 1) PCP  CCP section
STAREX-IS BSM Manual Page:691(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-281 Keep-Alive Fault between PCP and CCP 2) PCP  PNP section Fig. 5.1-282 Keep-Alive Fault between PCP and PNP 5.1.2.1.1.4. CCP Report 1) CCP  NCP section Fig. 5.1-283 Keep-Alive Fault between CCP and NCP 2) CCP  PCP section
STAREX-IS BSM Manual Page:692(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-284 Keep-Alive Fault between CCP and PCP 3) CCP  BSP section Fig. 5.1-285 Keep-Alive Fault between CCP and BSP 4) CCP  SCP section Fig. 5.1-286 Keep-Alive Fault between CCP and SCP 5) CCP  SMP section
STAREX-IS BSM Manual Page:693(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-287 Keep-Alive Fault between CCP and SMP 6) CCP  VMP section Fig. 5.1-288 Keep-Alive Fault between CCP and VMP 5.1.2.1.1.5. NCP Report 1) NCP  CNP section Fig. 5.1-289 Keep-Alive Fault between NCP and CNP 2) NCP  CCP section
STAREX-IS BSM Manual Page:694(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-290 Keep-Alive Fault between NCP and CCP 3) NCP  PNP section Fig. 5.1-291 Keep-Alive Fault between NCP and PNP 4) NCP  CRP section Fig. 5.1-292 Keep-Alive Fault between NCP and CRP 5.1.2.1.1.6. SCP Report 1) SCP  CCP section
STAREX-IS BSM Manual Page:695(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-293 Keep-Alive Fault between SCP and CCP 2) SCP  STIA section Fig. 5.1-294 Keep-Alive Fault between SCP and STIA 5.1.2.1.1.7. BSP Report 1) BSP  CCP section Fig. 5.1-295 Keep-Alive Fault between BSP and CCP 2) BSP  RCP section
STAREX-IS BSM Manual Page:696(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-296 Keep-Alive Fault between BSP and RCP 3) BSP  BPP section Fig. 5.1-297 Keep-Alive Fault between BSP and BPP 4) RCP  DBPA section Fig. 5.1-298 Keep-Alive Fault between RCP and DBPA 5.1.2.2. CCP Processing-related Fault 5.1.2.2.1. VCE Qcelp Algorithm Test Fault 1) Vocoder Clock Fault
STAREX-IS BSM Manual Page:697(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-299 Vocoder Clock Fault 2) QCELP0 Algorithm Fault Fig. 5.1-300 QCELP0 Algorithm Fault 3) QCELP1 Algorithm Fault Fig. 5.1-301 QCELP1 Algorithm Fault 4) QCELP2 Algorithm Fault
STAREX-IS BSM Manual Page:698(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-302 QCELP2 Algorithm Fault 5) QCELP3 Algorithm Fault Fig. 5.1-303 QCELP3 Algorithm Fault 6) VCPA LoopBack Test Fault Fig. 5.1-304 VCPA Loop-Back Test Fault 5.1.2.2.2. VCE DSP Test Fault 1) When faults occur upon DSP ROM TEST
STAREX-IS BSM Manual Page:699(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-305 Vocoder DSP ROM TEST Fault 2) When faults occur upon DSP RAM TEST Fig. 5.1-306 Vocoder DSP RAM TEST Fault 3) When faults occur upon DSP ROM/RAM TEST Fig. 5.1-307 Vocoder DSP ROM/RAM TEST Fault 4) When faults occur upon DSP ALU TEST
STAREX-IS BSM Manual Page:700(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-308 Vocoder DSP ALU TEST Fault 5) When faults occur DSP ROM/ALU TEST Fig. 5.1-309 Vocoder DSP ROM/ALU TEST Fault 6) When faults occur upon DSP RAM/ALU TEST Fig. 5.1-310 Vocoder DSP RAM/ALU TEST Fault 7) When faults occur upon DSP ROM/RAM/ALU TEST
STAREX-IS BSM Manual Page:701(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-311 Vocoder DSP ROM/RAM/ALU TEST Fault 5.1.2.2.3. VLIA T1/E1 Trunk Time Slot Fault 1) When faults occur upon VLIA E1/T1 Trunk Time-Slot TEST Fig. 5.1-312 VLIA E1/T1 Trunk Time-Slot Test Fault 5.1.2.2.4. Call Fail 1) SCI Fault Fig. 5.1-313 SCI Fault 2) BASE ID Fault
STAREX-IS BSM Manual Page:702(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-314 Base ID Fault 3) BTS ID Fault Fig. 5.1-315 BTS ID Fault 4) Sector ID Fault Fig. 5.1-316 Sector ID Fault 5) Neighbor List Fault
STAREX-IS BSM Manual Page:703(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-317 Neighbor List Fault 6) MSC Overload Fault Fig. 5.1-318 MSC Overload Fault 7) CCP Overload Fault Fig. 5.1-319 CCP Overload Fault 8) BSP Overload Fault
STAREX-IS BSM Manual Page:704(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-320 BSP Overload Fault 9) Get Task Function Fault Fig. 5.1-321 Get Task Function Fault 10) Free Task Function Fault Fig. 5.1-322 Free Task Function Fault 11) Get Buffer Function Fault
STAREX-IS BSM Manual Page:705(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-323 Get Buffer Function Fault 12) Authentication Fault Fig. 5.1-324 Authentication Fault 5.1.2.3. RCP Processing-related Fault 1) When a problem occurs in STM SYSTEM TIME Fig. 5.1-325 STM System Time Fault 2) CDM TX Parity Fault
STAREX-IS BSM Manual Page:706(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-326 CDM TX Parity Fault 3) CDM RX Parity Fault Fig. 5.1-327 CDM RX Parity Fault 4) CDM TX Over-Flow Fault Fig. 5.1-328 CDM TX Over-Flow Fault 5) CDM TX M2R DATA Error
STAREX-IS BSM Manual Page:707(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-329 CDM TX M2R DATA Error 6) CDM TX R2B DATA Error Fig. 5.1-330 CDM TX R2B DATA Error 7) CDM RX B2R DATA Error Fig. 5.1-331 CDM RX B2R DATA Error 8) OverHead Channel Config No Received Fault Fig. 5.1-332 OverHead Channel Config No Received Fault 9) OverHead Channel Config Invalid Fault
STAREX-IS BSM Manual Page:708(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-333 OverHead Channel Config Invalid Fault 5.1.2.4. DBPA Processing-related Fault 1) When faults occur in DBPA Internal Even Clock Fig. 5.1-334 DBPA Internal Even Clock Fault 2) When faults occur in DBPA External System Clock Fig. 5.1-335 DBPA External System Clock Fault 3) When DBPA Channel Card can not receive TOD within 10 seconds
STAREX-IS BSM Manual Page:709(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-336 DBPA TOD Not Active Fault 4) DBPA Common Channel No Free Queue Fail Fig. 5.1-337 DBPA CMC No Free Queue Fault 5) When faults occur in DBPA Internal System Clock Fig. 5.1-338 DBPA Internal Sync Clock Fault 6) DBPA Core No Free Queue Fail
STAREX-IS BSM Manual Page:710(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-339 DBPA Core No Free Queue Fault 7) DBPA Queue Put Fail Fig. 5.1-340 DBPA Queue Put Fault 8) DBPA Queue Get Fail Fig. 5.1-341 DBPA Queue Get Fault 9) DPBA S/W WatchDog TimeOut Fail Fig. 5.1-342 DBPA S/W Watchdog Timeout Fault 10) DBPA Fatal Fault
STAREX-IS BSM Manual Page:711(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-343 DBPA Fatal Fault 11) When DBPA Clock and Modem Control are bad Fig. 5.1-344 DBPA Bad Channel Modem Fault 12) When DBPA has a false TOD information Fig. 5.1-345 DBPA External TOD Fault 13) DBPA Internal OS Clock Fail
STAREX-IS BSM Manual Page:712(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-346 DBPA Internal OS Clock Fault 14) DBPA BIT Chip Fail Fig. 5.1-347 DBPA BIT Fail 5.1.2.5. Channel-related Fault 1) When messages cannot be transferred to SVC because Message Queue for messages to be delivered to SVC is empty Fig. 5.1-348 DBPA TC No SVC Free Queue Fail 2) When Queue resources that save messages from BSP and RCP are used up Fig. 5.1-349 DBPA TC No Normal Free Queue Fail 3) When a problem occurs during Built-In Test
STAREX-IS BSM Manual Page:713(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-350 DBPA TC Tx FWHENO Full Fail 4) When Queue resources that save messages to be sent to BSP are used up Fig. 5.1-351 DBPA ACH No Free Queue Fail 5) When Encoder Queue resources are used up Fig. 5.1-352 DBPA PC No Encoder Free Queue Fail 6) When Queue resources that save page messages except General Page messages are used up
STAREX-IS BSM Manual Page:714(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-353 DBPA PC No Page Free Queue Fail 7) When Queue resources that save Quick Page messages are used up Fig. 5.1-354 DBPA PC No Quick Page Free Queue Fail 8) When Queue resources that save Reply Message are consumed as Reply is requested for the messages from BSP Fig. 5.1-355 DBPA PC No Reply Free Queue Fail 9) When Write errors occur more than 20 times continuously as Paging Channel performs Write Frame every 20ms
STAREX-IS BSM Manual Page:715(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-356 DBPA PC Write Frame Fail 10) When Queue resources that save General Page messages from BSP are consumed Fig. 5.1-357 DBPA PC No General Page Free Queue Fail 5.1.2.6. BUDA Processing-related Fault 1) BUDA CHIPx16 Fault Fig. 5.1-358 BUDA CHIPx16 Fault 2) BUDA Forward Sync Fault
STAREX-IS BSM Manual Page:716(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-359 BUDA Forward Sync Fault 3) BUDA Tx Saturation Fault Fig. 5.1-360 BUDA Tx Saturation Fault 4) BUDA Frame Error Fault Fig. 5.1-361 BUDA Frame Error Fault 5.1.2.7. BOTA Processing-related Fault 1) BOTA TOD Error Fault
STAREX-IS BSM Manual Page:717(877)Issue:1.0SMD-011-PMA210 Fig. 5.1-362 BOTA TOD Error Fault 2) BOTA TOD Not Active Fault Fig. 5.1-363 BOTA TOD Not Active Fault 5.2. Status Command 5.2.1. Processor Status Change Report When processor status is changed in state block, the status change report messages are displayed on Console Window. This function can allow or inhibit messages display as a function that allows/inhibits the status message display.. 5.2.1.1. CNP Status Change Report When CNP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block.
STAREX-IS BSM Manual Page:718(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-1 CNP Processor Status Change Report 5.2.1.2. PNP Status Change Report When PNP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block. Fig. 5.2-2 PNP Processor Status Change Report 5.2.1.3. PCP Status Change Report When PCP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block.
STAREX-IS BSM Manual Page:719(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-3 PCP Processor Status Change Report 5.2.1.4. PMP Status Change Report When PMP processor status is changed, the messages are displayed on Console Window. It is the processor that PCP keeps Alive and reports the messages to the upper level BSM, judging from the PCP status block. Fig. 5.2-4 PMP Processor Status Change Report 5.2.1.5. CCP Status Change Report When CCP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block.
STAREX-IS BSM Manual Page:720(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-5 CCP Processor Status Change Report 5.2.1.6. NCP Status Change Report When NCP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block. Fig. 5.2-6 NCP Processor Status Change Report 5.2.1.7. SCP Status Change Report When SCP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSM keeps Alive and displays the messages, judging from the BSM status block.
STAREX-IS BSM Manual Page:721(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-7 SCP Processor Status Change Report 5.2.1.8. SMP Status Change Report When SMP processor status is changed, the messages are displayed on Console Window. It is the processor that the CCP keeps Alive and reports the messages to the upper level BSM, judging from the CCP status block. Fig. 5.2-8 SMP Processor Status Change Report 5.2.1.9. VMP Status Change Report When VMP processor status is changed, the messages are displayed on Console Window. It is the processor that the CCP keeps Alive and reports the messages to the upper level BSM, judging from the CCP status block.
STAREX-IS BSM Manual Page:722(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-9 VMP Processor Status Change Report 5.2.1.10. ALP Status Change Report When ALP processor status is changed, the messages are displayed on Console Window. It is the processor that the CCP keeps Alive and reports the messages to the upper level BSM, judging from the CCP status block. Fig. 5.2-10 ALP Processor Status Change Report 5.2.1.11. BSP Status Change Report When BSP processor status is changed, the messages are displayed on Console Window. It is the processor that the CCP keeps Alive and reports the messages to the upper level BSM, judging from the CCP status block.
STAREX-IS BSM Manual Page:723(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-11 BSP Processor Status Change Report 5.2.1.12. CRP Status Change Report When CRP processor status is changed, the messages are displayed on Console Window. It is the processor that the NCP keeps Alive and reports the messages to the upper level BSM, judging from the NCP status block. Fig. 5.2-12 CRP Processor Status Change Report 5.2.1.13. RCP Status Change Report When RCP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSP keeps Alive and reports the messages to the upper level BSM, judging from the BSP status block.
STAREX-IS BSM Manual Page:724(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-13 RCP Processor Status Change Report 5.2.1.14. BPP Status Change Report When BPP processor status is changed, the messages are displayed on Console Window. It is the processor that the BSP keeps Alive and reports the messages to the upper level BSM, judging from the BSP status block. Fig. 5.2-14 BPP Processor Status Change Report 5.2.2. Overload Status Change Report Function When overload occurs/is changed/is released in CCP or BSP processor, it is displayed on Console Window. This function can allow or inhibit message display as a function that allows/inhibits the status message display.
STAREX-IS BSM Manual Page:725(877)Issue:1.0SMD-011-PMA210 5.2.2.1. Overload Status Occurred Message When overload occurs in CCP or BSP processor, it is reported to upper level BSM. Overload occurs when Level is 12. Fig. 5.2-15 Overload Status Occurred Message 5.2.2.2. Overload Status Change Message After overload occurs in CCP or BSP processor, when overload status is changed, it is reported to upper level BSM. Fig. 5.2-16 Overload Status Change Message 5.2.2.3. Overload Status Released Message When overload is released in CCP or BSP processor, it is reported to upper level BSM.
STAREX-IS BSM Manual Page:726(877)Issue:1.0SMD-011-PMA210 Fig. 5.2-17 Overload Status Released Message 5.3. Loading Message 5.3.1. Processor Initialization Start Message Processor initialization start message is displayed when a target processor starts initialization. The following messages are displayed depending on the initialization type. Classification Message Type Initial Loading S2002 PROCESSOR INITIALIZATION START Standby Loading S2002 PROCESSOR STANDBY INITIALIZATION START Fig. 5.3-1 Processor Initialization Start Message 5.3.2. Processor Initialization End Message
STAREX-IS BSM Manual Page:727(877)Issue:1.0SMD-011-PMA210 Processor initialization end message is displayed when a target processor ends initialization. The following messages are displayed depending on the initialization type. Classification Message Type Initial Loading S2100 PROCESSOR INITIALIZATION END Standby Loading S2100 PROCESSOR STANDBY INITIALIZATION END Fig. 5.3-2 Processor Initialization End Message 5.3.3. Loading Start Message Processor loading start message is a message that reports loading start of each block upon loading target processor. The following messages are displayed depending on the loading type. Classification Message Type General Loading S2000 PROCESSOR LOADING START Block Loading S2000 PROCESSOR BLOCK LOADING START Activation Loading S2000 PROCESSOR ACTIVATION LOADING START Standby Loading S2000 PROCESSOR STANDBY LOADING START Firmware Loading S2000 PROCESSOR FIRMWARE LOADING START
STAREX-IS BSM Manual Page:728(877)Issue:1.0SMD-011-PMA210 Fig. 5.3-3 Loading Start Message 5.3.4. Loading Completion Message Processor loading completion message is a message that reports loading completion of each block upon loading target processor. The following messages are displayed depending on the loading type. Classification Message Type General Loading S2001 PROCESSOR LOADING COMPLETE Block Loading S2001 PROCESSOR BLOCK LOADING COMPLETE Activation Loading S2001 PROCESSOR ACTIVATION LOADING COMPLETE Standby Loading S2001 PROCESSOR STANDBY LOADING COMPLETE Firmware Loading S2001 PROCESSOR FIRMWARE LOADING COMPLETE Fig. 5.3-4 Loading Completion Message
STAREX-IS BSM Manual Page:729(877)Issue:1.0SMD-011-PMA210 5.3.5. Loading Failure Message Processor loading failure message is a message displayed when block fails in loading upon loading target processor. The following messages are displayed depending on the loading type. Classification Message Type General Loading S2105 PROCESSOR LOADING FAIL Block Loading S2105 PROCESSOR BLOCK LOADING FAIL Activation Loading S2105 PROCESSOR ACTIVATION LOADING FAIL Standby Loading S2105 PROCESSOR STANDBY LOADING FAIL Fig. 5.3-5 Loading Failure Message 5.3.6. Firmware Update Report Message Firmware update report message is a message that reports if the update succeeds when firmware update is completed.
STAREX-IS BSM Manual Page:730(877)Issue:1.0SMD-011-PMA210 6. Trouble Shoot This chapter describes problems caused by operating and solution to them. 6.1. If BSM is not operated 6.1.1. If BSM is not initialized 6.1.1.1. Shared Memory or Queue Problem 6.1.1.1.1. IPC Initialization Problem  If the following messages are displayed start of MMI_server program [mmi] mmi is already in service. You can remove a file "IPCHEAD" and try again... sorry!!! The above cases can occur when BSM is already initialized and used or when the formerly executed BSM ends abnormally or by force. When these cases occur, it is possible to delete them compulsorily using rmipc command provided by BSM. However, when initializing IPC by force, perform the work after checking if it is currently in operation. (See “ Overlapped Use Problem of IPC” if UNIX ID which operated BSM previously is different from the ID currently logged in. 6.1.1.1.2. Overlapped Use Problem of IPC  BSM initialization and operation can be performed by logging in as one UNIX ID. But after executing BSM by logging in as other UNIX IDs, none can reoperate BSM except the operated ID. Therefore, check Queue and Shared Memory currently in use by using UNIX command called “/usr/bin/ipcs –a” to see if other IDs operated BSM. In this case, remove the generated IPC Header and the assigned IPC by performing “rmipc” command with ID or UNIX Root authorization that operates BSM
STAREX-IS BSM Manual Page:731(877)Issue:1.0SMD-011-PMA210 6.1.1.1.3. If IPC is not deleted  If IPC is not deleted by “rmipc” command to operate BSM, delete it by force through the following command. ipcrm [ -m shmid ] [ -q msqid ] [ -s semid ] [ -M shmkey ] [ -Q msgkey ] [ -S semkey ] Description of each factor -m shmid Remove the shared memory identWhenier shmid from the system. The shared memory segment and data struc- ture associated with it are destroyed after the last detach. -q msqid Remove the message queue identWhenier msqid from the system and destroy the message queue and data structure associated with it. -s semid Remove the semaphore identWhenier semid from the system and destroy the set of semaphores and data structure associated with it. -M shmkey Removes the shared memory identWhenier, created with key shmkey, from the system. The shared memory segment and data structure associated with it are destroyed after the last detach. -Q msgkey Remove the message queue identWhenier, created with key msgkey, from the system and destroy the mes- sage queue and data structure associated with it. -S semkey Remove the semaphore identWhenier, created with key semkey, from the system and destroy the set of
STAREX-IS BSM Manual Page:732(877)Issue:1.0SMD-011-PMA210 semaphores and data structure associated with it. 6.1.2. It can not function normally despite of its initialization 6.1.2.1. Informix Problem BSM Applications are saved as temporary data and data for reference in other blocks using Informix Database. Therefore, if Informix does not operate, BMS Applications cannot be run or run abnormally. 6.1.2.1.1. Informix Initialization Check to see if Informix Database is normally operated by using the following command: “onstat –“ Normal if messages similar to the following are displayed. Informix Dynamic Server Version 7.31.UD1 -- On-Line -- Up 1 days 22:53:08 -- 133904 Kbytes If error messages are displayed, refer to the item “ Informix Installation” of BSM environmental configuration. 6.1.2.1.2. Informix Database Error Informix DB errors occur in the following cases: 1) when Database is damaged while operating the BSM; 2) when Applications are not normally run after normal initialization of Informix and 3) when a part of all Applications cannot be run. In this case, it is able to run Applications normally by dropping DB Table of Informix Database artificially. 6.2. If Graphic Application is not run BSM inputs a command in the user-friendly environment and provides a variety of GUIs to monitor the system. However, the user should check the environment to run GUI. The following describes causes for errors and its solution when environment variables are wrongly set up or the files needed for operating GUI do not exist.
STAREX-IS BSM Manual Page:733(877)Issue:1.0SMD-011-PMA210 6.2.1. Environment Variables 6.2.1.1. Display Setup Problem Register the system that corresponds to /etc/host files to protect BSM from external Access and allow to use the authenticated system. Make the format consistent with the following contents: 6.2.1.1.1. Main Server Name 150.150.62.100 zen.lgic.co.kr zen loghost In the above example, it is /etc/hosts file to operate the host called “zen” as a main server. If the following is registered, the BSM causes segmentation fault and stops operation. 150.150.62.100 zen zen.lgic.co.kr loghost 6.2.1.1.2. Remote Server Even if PC/Workstation to be operated in remote area is the same as the above item, register the following contents in /etc/hosts file. 150.150.62.102 feel.lgic.co.kr feel The above example is the contents that register the system called “feel” to access the Main Server. Register the following contents in a /etc/hosts file of the Main Server. 6.2.1.2. GUI Library When GUI is operated, the following messages are displayed on xterm window that runs mmi. If GUI is not operated, it can be regarded as GUI without library. ld.so.1: stmGUI: fatal: libXpm.so.4.10: open failed: No such file or directory Killed
STAREX-IS BSM Manual Page:734(877)Issue:1.0SMD-011-PMA210 The above is an example when GUI is not operated in spite of the attempt to operate GUI called “stmGUI”. It means that libXpm.so.x.xx file does not exist as shown above. In this case, two problems can be taken into consideration. 6.2.1.2.1. LD_LIBRARY_PATH Setup Setting up GUI Library is to change the system environment variables called LD_LIBRARY_PATH. The following is an example of how to set up variables. setenv LD_LIBRARY_PATH “paths” The above path would be composed of the following contents: /home/informix/lib:/home/informix/lib/esql:/opt/TclPro1.5/solaris-sparc/lib:/usr/openwin/lib:/usr/lib:/usr/ucblib:/usr/dt/lib:../DATA/LIB GUI Libraries are generally installed in “/usr/dt/lib” or “/usr/openwin/lib”. However, add “:your_lib_path_dir” upon using them additionally. 6.2.1.2.2. libXpm File Absence Even though OS is normally installed, XPM Library is not provided as a basic. Therefore, it is possible to set up by duplicating XPM Library provided by BSM and by adding Library to variables. Refer to the above item “LD_LIBRARY_PATH” for setting up. 6.2.2. If Manager in Remote Area is not operated For safety, BSM does not allow to use two managers in one system remotely. Therefore, check to see if it corresponds to the following cases: 6.2.2.1. If the same name is already used Check to see if the system attempting a remote operation uses the name already. It is possible to check if it is registered by operating controller on Main BSM Server. In this case, if the current system does not use the name, it means that it was abnormally terminated during the previous use. Therefore, it will be possible to reuse it if Main BSM controller deletes the corresponding host name.
STAREX-IS BSM Manual Page:735(877)Issue:1.0SMD-011-PMA210 6.2.2.2. If it is not registered in /etc/hosts file It is when registration is not allowed for security reasons. In this case, refer to how to compile /etc/hosts file of BSM environment variables setting among the above items and then add remote server name.
STAREX-IS BSM Manual Page:736(877)Issue:1.0SMD-011-PMA210 7. CHG- Appendix 7.1. Alarm/Fault Message Description and List 7.1.1. Alarm Message Description and List 7.1.1.1. CAN Generated Alarm Message Table 7.1-1 CAN Generated Alarm Message List Alarm Code Alarm Description A7500 CAN GPSR CONTROL CABLE OPEN A7600 CAN ALARM CABLE OPEN A7800 CAN RACK FAN FAIL A8000 CAN GPSR SINGLE ABNORMAL A8001 CAN GPSR DUAL ABNORMAL A8050 CAN GPSD SINGLE ABNORMAL A8051 CAN GPSD DUAL ABNORMAL A8100 CAN RAPU ABNORMAL A8110 CAN RAPU LINK_OR_POWER FAIL A8500 CAN CNPA SINGLE ABNORMAL A8501 CAN CNPA DUAL ABNORMAL A8550 CAN ASCA(CAMU) SINGLE ABNORMAL A8551 CAN ASCA(CAMU) DUAL ABNORMAL A8560 CAN FERA SINGLE ABNORMAL A8561 CAN FERA DUAL ABNORMAL A8570 CAN ASCA(CPNU) SINGLE ABNORMAL A8571 CAN ASCA(CPNU) DUAL ABNORMAL A8600 CAN PNPA SINGLE ABNORMAL A8601 CAN PNPA DUAL ABNORMAL A8700 CAN AMPA ABNORMAL A8710 CAN PCPA SINGLE ABNORMAL A8711 CAN PCPA DUAL ABNORMAL A8720 CAN PMPA SINGLE ABNORMAL
STAREX-IS BSM Manual Page:737(877)Issue:1.0SMD-011-PMA210 A8721 CAN PMPA DUAL ABNORMAL A8730 CAN ENPA SINGLE ABNORMAL A8731 CAN ENPA DUAL ABNORMAL A8740 CAN BCRA SINGLE ABNORMAL A8741 CAN BCRA DUAL ABNORMAL A8800 CAN PCPA 1PPS CLOCK FAIL A8810 CAN PCPA 10MHz CLOCK FAIL A8820 CAN FERA LINK FAIL A8840 CAN FERA PDSN LINK FAIL A9000 CAN CAMU SINGLE POWER FAIL A9001 CAN CAMU DUAL POWER FAIL A9010 CAN PCFU(PCP) SINGLE POWER FAIL A9011 CAN PCFU(PCP) DUAL POWER FAIL A9020 CAN PCFU(PMP) SINGLE POWER FAIL A9021 CAN PCFU(PMP) DUAL POWER FAIL A9030 CAN ATSU SINGLE POWER FAIL A9031 CAN ATSU DUAL POWER FAIL A9040 CAN CPNU SINGLE POWER FAIL A9041 CAN CPNU DUAL POWER FAIL A9220 CAN ASIA(CAMU) SINGLE ABNORMAL A9221 CAN ASIA(CAMU) DUAL ABNORMAL A9230 CAN ASIA(CPNU) SINGLE ABNORMAL A9231 CAN ASIA(CPNU) DUAL ABNORMAL A9240 CAN AOTA BOARD DELETION A9250 CAN AOTA FUNCTION FAIL A9260 CAN ATSA(ASMU) BOARD DELETION A9270 CAN ATSA(ASMU) FUNCTION FAIL A9300 CAN PIPA BOARD DELETION A9310 CAN PIPA FUNCTION FAIL A9320 CAN FETA BOARD DELETION A9330 CAN FETA FUNCTION FAIL A9400 CAN ATSA(ATSU) BOARD DELETION A9410 CAN ATSA(ATSU) FUNCTION FAIL
STAREX-IS BSM Manual Page:738(877)Issue:1.0SMD-011-PMA210 7.1.1.2. BSC Generated Alarm Message Table 7.1-2 BSC Generated Alarm Message List Alarm Code Alarm Description A4600 BSC ALARM CABLE OPEN A4800 BSC RACK FAN FAIL A5500 BSC NCPA SINGLE ABNORMAL A5501 BSC NCPA DUAL ABNORMAL A5510 BSC ALP SINGLE ABNORMAL A5511 BSC ALP DUAL ABNORMAL A5550 BSC ALMA SINGLE ABNORMAL A5551 BSC ALMA DUAL ABNORMAL A5560 BSC ASCA SINGLE ABNORMAL A5561 BSC ASCA DUAL ABNORMAL A5700 BSC CCPA SINGLE ABNORMAL A5701 BSC CCPA DUAL ABNORMAL A5710 BSC SCPA SINGLE ABNORMAL A5711 BSC SCPA DUAL ABNORMAL A5720 BSC SLMA ABNORMAL A5730 BSC VCMA ABNORMAL A5800 BSC CCPA 1PPS CLOCK FAIL A5810 BSC CCPA 10MHz CLOCK FAIL A6000 BSC CCPU SINGLE POWER FAIL A6001 BSC CCPU DUAL POWER FAIL A6010 BSC ASMU SINGLE POWER FAIL A6011 BSC ASMU DUAL POWER FAIL A6020 BSC ALBU SINGLE POWER FAIL A6021 BSC ALBU DUAL POWER FAIL A6030 BSC SLBU POWER FAIL A6040 BSC VCBU POWER FAIL
STAREX-IS BSM Manual Page:739(877)Issue:1.0SMD-011-PMA210 A6220 BSC ASIA SINGLE ABNORMAL A6221 BSC ASIA DUAL ABNORMAL A6240 BSC AOTA BOARD DELETION A6250 BSC AOTA FUNCTION FAIL A6260 BSC ATSA BOARD DELETION A6270 BSC ATSA FUNCTION FAIL A6280 BSC ALPA BOARD DELETION A6290 BSC ALPA FUNCTION FAIL A6300 BSC STIA BOARD DELETION A6310 BSC STIA FUNCTION FAIL A6350 BSC STIA SHW LINK FAIL A6400 BSC SLPA BOARD DELETION A6410 BSC SLPA FUNCTION FAIL A6500 BSC VCPA BOARD DELETION A6510 BSC VCPA FUNCTION FAIL A6520 BSC VLIA BOARD DELETION A6530 BSC VLIA FUNCTION FAIL A6540 BSC VLIA T1(E1) #x REMOTE ERROR A6541 BSC VLIA T1(E1) #x LOCAL ERROR A6542 BSC VLIA T1(E1) #x SLIP ERROR A6543 BSC VLIA T1(E1) #x BIT ERROR A6610 BSC CCP ABID BOARD DELETION A6611 BSC NCP ABID BOARD DELETION A6620 BSC SMP SAID BOARD DELETION A6630 BSC SMP SINGLE CLOCK FAIL A6631 BSC SMP DUAL CLOCK FAIL A6640 BSC VMP SAID BOARD DELETION A6650 BSC VMP SINGLE CLOCK FAIL A6651 BSC VMP DUAL CLOCK FAIL A6900 BSC ALPA E1/T1 LINK NODE FAIL A6910 BSC ALPA STM1 LINK NODE FAIL
STAREX-IS BSM Manual Page:740(877)Issue:1.0SMD-011-PMA210 7.1.1.3. BTS Generated Alarm Message Table 7.1-3 BTS Generated Alarm Message List Alarm Code Alarm Description A0100 BTS TEMPERATURE HIGH ALARM A0110 BTS TEMPERATURE LOW ALARM A0120 BTS WATER HIGH ALARM A0130 BTS WATER LOW ALARM A0140 BTS FIRE ALARM A0150 BTS HUMIDITY HIGH ALARM A0160 BTS FRONT/REAR DOOR OPEN ALARM A0170 BTS SIDE DOOR OPEN ALARM A0200 BTS ACU MODULE FAIL A0210 BTS LPA FAN FAIL A0220 BTS FAN FAIL A0300 BTS COLD START ALARM A0310 BTS RECTIFIER UNIT FAIL A0320 BTS VOLTAGE HIGH ALARM A0321 BTS VOLTAGE LOW ALARM A0330 BTS AC FAIL A0340 BTS BATTERY LOW VOLTAGE ALARM A0350 BTS FUSE/RELAY LOSS ALARM A0360 BTS DMC-14 FAIL A0370 BTS POWER CUT ALARM A0380 BTS HEAT EXCHANGER POWER FAIL A0381 BTS HEAT EXCHANGER FAIL A0390 BTS AC EQUIPMENT HEATER FAIL A0391 BTS AC BATTERY HEATER FAIL A0400 BTS FLOOD ALARM A0410 BTS DOOR #1 OPEN FAIL A0411 BTS DOOR #2 OPEN FAIL
STAREX-IS BSM Manual Page:741(877)Issue:1.0SMD-011-PMA210 A0420 BTS RECTIFIER #1 FAIL A0421 BTS RECTIFIER #2 FAIL A0430 BTS AIRCON #1 FAIL A0431 BTS AIRCON #2 FAIL A0440 BTS WATER LEAKAGE ALARM A0500 BTS GPSR CONTROL CABLE OPEN A0600 BTS ALARM CABLE OPEN A0610 BTS FAN CABLE OPEN A0620 BTS ENVIRONMENT ALARM CABLE OPEN A0800 BTS RACK FAN FAIL A1000 BTS GPS SINGLE ABNORMAL A1001 BTS GPS DUAL ABNORMAL A1500 BTS BCRA SINGLE ABNORMAL A1501 BTS BCRA DUAL ABNORMAL A1550 BTS DRAN POWER FAIL A1560 BTS DRAN FUNCTION FAIL A1700 BTS BSPA SINGLE ABNORMAL A1701 BTS BSPA DUAL ABNORMAL A1750 BTS RCPA SINGLE ABNORMAL A1751 BTS RCPA DUAL ABNORMAL A1760 BTS BPPA BOARD DELETION A1770 BTS BPPA FUNCTION FAIL A1800 BTS BSPA 1PPS CLOCK FAIL A1810 BTS BSPA 10MHz CLOCK FAIL A1850 BTS RCMD BOARD DELETION A1860 BTS RCMD FUNCTION FAIL A2000 BTS BSPU SINGLE POWER FAIL A2001 BTS BSPU DUAL POWER FAIL A2010 BTS RCBU SINGLE POWER FAIL A2011 BTS RCBU DUAL POWER FAIL A2300 BTS DBPA BOARD DELETION A2310 BTS DBPA FUNCTION FAIL A2320 BTS BUDA BOARD DELETION
STAREX-IS BSM Manual Page:742(877)Issue:1.0SMD-011-PMA210 A2330 BTS BUDA FUNCTION FAIL A2340 BTS PACA BOARD DELETION A2350 BTS PACA FUNCTION FAIL A2400 BTS BADA POWER FAIL A2410 BTS BADA FUNCTION FAIL A2420 BTS LICA BOARD DELETION A2430 BTS LICA FUNCTION FAIL A2440 BTS ARIA BOARD DELETION A2450 BTS ARIA FUNCTION FAIL A2470 BTS BOTA POWER FAIL A2480 BTS BOTA FUNCTION FAIL A2490 BTS RISA FUNCTION FAIL A2491 BTS RISA POWER FAIL A2500 BTS LPA BOARD DELETION A2510 BTS LPA FUNCTION FAIL A2520 BTS LPA CONBINER FAIL A2530 BTS LPA CONBINER FAN FAIL A2540 BTS LPA DC/DC ALARM A2550 BTS LPA VSWR ALARM A2560 BTS LPA DISABLE ALARM A2570 BTS LPA OVER POWER WARNING A2580 BTS LPA OVER TEMPERATURE ALARM A2590 BTS LPA OVER POWER ALARM A2600 BTS LNA BOARD DELETION A2610 BTS LNA FUNCTION FAIL A2700 BTS HPA BOARD DELETION A2710 BTS HPA POWER FAIL A2720 BTS HPA POWER SUPPLY FAIL A2730 BTS HPA VSWR ALARM A2740 BTS HPA DISABLE ALARM
STAREX-IS BSM Manual Page:743(877)Issue:1.0SMD-011-PMA210 7.1.2. Fault Message Description and List Table 7.1-4 Fault Message List Alarm Code Alarm Description F1000 BTS PROCESSOR KEEP-ALIVE FAULT F1100 BTS STM SYSTEM TIME FAULT F1110 BTS CDM TX PARITY FAULT F1120 BTS CDM RX PARITY FAULT F1130 BTS CDM TX OVF FAULT F1140 BTS CDM TX M2R DATA ERROR F1150 BTS CDM TX R2B DATA ERROR F1160 BTS CDM RX B2R DATA ERROR F1170 BTS CHANNEL CONFIG NO RECEIVED ERROR F1180 BTS CHANNEL CONFIG DATA INVALID ERROR F1300 BTS DBPA INTERNAL EVEN SEC ERROR F1301 BTS DBPA EXTERNAL SYSTEM CLOCK ERROR F1302 BTS DBPA TOD NOT ACTIVE F1303 BTS DBPA NO BTSC FREE Q Error F1304 BTS DBPA INTERNAL 80ms CLOCK Error F1305 BTS DBPA DIAG NO FREE Q FAULT F1306 BTS DBPA QUEUE PUT FAULT F1307 BTS DBPA QUEUE GET FAULT F1308 BTS DBPA S/W WATCHDOG TIMEOUT FAULT F1309 BTS DBPA FATAL FAULT F1310 BTS DBPA BAD CHANNEL MODEM FAULT F1311 BTS DBPA TOD Error F1312 BTS DBPA INTERNAL OS CLOCK Error F1313 BTS DBPA BIT CHIP FAULT F1400 BTS DBPA TC NO SI OUT FREE Q ERROR F1410 BTS DBPA TC NO NORMAL FREE Q ERROR F1420 BTS DBPA TC TX FIFO ERROR F1510 BTS DBPA ACH NO FREE QUEUE ERROR
STAREX-IS BSM Manual Page:744(877)Issue:1.0SMD-011-PMA210 F1600 BTS DBPA NO PC ENCODER BUFFER ERROR F1610 BTS DBPA PC NO PAGE FREE QUEUE ERROR F1620 BTS DBPA PC NO QUICK PAGE FREE QUEUE ERROR F1630 BTS DBPA PC NO REPLY FREE QUEUE ERROR F1640 BTS DBPA PC WRITE FRAME FAIL F1650 BTS DBPA PC NO GEN PAGE FREE QUEUE ERROR F1700 BTS BUDA CHIPx16 FAULT F1710 BTS BUDA FORWARD SYNC FAULT F1720 BTS BUDA TX SATURATION FAULT F1730 BTS BUDA FRAME ERROR FAULT F2000 BTS BPPA TOD ERROR F2010 BTS BPPA TOD NOT ACTIVE FAULT F3000 BSC PROCESSOR KEEP-ALIVE FAULT F3020 BSC VCE QCELP ALGORITHM TEST FAULT F3030 BSC VCE DSP TEST FAULT F3040 BSC VLIA E1/T1 TRUNK TIME SLOT FAULT F3050 BSC CALL FAIL F4000 BSC PROCESSOR KEEP-ALIVE FAULT F5000 BSC PROCESSOR KEEP-ALIVE FAULT F7000 CAN PROCESSOR KEEP-ALIVE FAULT F8000 CAN PROCESSOR KEEP-ALIVE FAULT F9000 CAN PROCESSOR KEEP-ALIVE FAULT 7.1.3. Measures for Alarm Message Table 7.1-5 Measures for Alarm Message ALM CODE Description Measures A0100 (BTS) Generated when temperature in BTS is far above the basic level, or sensor and ACU are abnormal If temperature is normal, replace sensor and ACU, and if temperature is high, check if FAN, Air Conditioner. Heat exchanger, etc. are normal.
STAREX-IS BSM Manual Page:745(877)Issue:1.0SMD-011-PMA210 A0110 (BTS) Generated when temperature in BTS is below the basic level, or sensor and ACU are abnormal Upon low temperature, check if heater(Heating PAD) is normal, and upon normal temperature, replace sensor and ACU. A0120 (BTS) Generated when BTS is submerged owing to natural disaster and other reasons, or sensor and ACU are abnormal As it does not operate normally even after water subsides, activate BTS through ACU OFF/ON. A0130 (BTS) Generated right before BTS is submerged owing to natural disaster and other reason, or sensor and ACU are abnormal. As this alarm reports critical situation of BTS, take necessary measures, and replace sensor and ACU if they are not actually submerged. A0140 (BTS) Generated when fire occurs in BTS, or sensor and ACU are abnormal. When sensor and ACU are abnormal, replace sensor and ACU. A0150 (BTS) Generated when humidity in BTS is higher or lower than the basic level, or sensor and ACU are abnormal. When humidity is normal, replace sensor and ACU. A0160 (BTS) Generated when the entrance of BTS is open and closed, or sensor and cable are abnormal. If the entrance is not open, replace sensor and cable. A0170 (BTS) Generated when side entrance of BTS is open and closed, or sensor and cable are abnormal. If the entrance is not open, replace sensor and cable. A0200 (BTS) Generated when ACU-I4 module is abnormal. After checking it is normally positioned and power is normal, replace ACU if normal. A0210 (BTS) Generated when cooling FAN of LPA/HPA is abnormal Check the power of FAN and replace FAN when power is normal. A0220 (BTS) Generated when BTS FAN is abnormal Check the power of FAN and replace FAN when power is normal. A0300 (BTS) Generated when initial power is applied at a very low temperature (below -5℃) Release that at more than +5℃. A0310 (BTS) Generated when rectifier of BTS, AC/DC(MDR30), AC, and power are Generated when rectifier of BTS, AC/DC(MDR30), AC, and power are
STAREX-IS BSM Manual Page:746(877)Issue:1.0SMD-011-PMA210 abnormal abnormal A0320 (BTS) If normal, DC 27V is abnormal, but it is generated when voltage of more than 28.5V is supplied. Replace rectifier if the status continues upon restart. A0321 (BTS) Generated when BTS rectifier voltage is below 24V (AC- commercial power fail) If it continues while AC is normal, replace rectifier. A0330 (BTS) Generated when AC (220V/60Hz) input power is abnormal Check if power is normally inlet, and check, upon normal inlet, if voltage is within 170V~270V. A0340 (BTS) Generated when battery voltage is below 22.5V, which is similar to low voltage alarm Charge battery after recovery of commercial power. Final alarm is generated before shutdown at 20.5V. A0350 (BTS) Upon initial power application, battery is not connected, or fuse damage of battery power supply circuit. When upon AC Fail, switchover is not made, replace rectifier. A0360 (BTS) DMC-I4 fault If problem continues, replace DMC-I4. A0370 (BTS) Generated 10 seconds before rectifier shutdown after major fault When major fault is cleared, recover the rectifier for auto clear. A0380 (BTS) Heat Exchanger Power Fault A0381 (BTS) Heat Exchanger Fault Check cable, replace FAN, and replace devices. A0390 (BTS) Internal Heater Fault Check cable, replace FAN, and replace devices. A0391 (BTS) Heating Pad Fault Replace power cable and heater. A0400 (BTS) BTS submersion As it does not automatically operate even after water subsides, activate BTS by ACU OFF/ON. A0410 (BTS) BTS Door #1 Open Check BTS Door and close the open door. A0411 (BTS) BTS Door #2 Open Check BTS Door and close the open door.
STAREX-IS BSM Manual Page:747(877)Issue:1.0SMD-011-PMA210 A0420 (BTS) Rectifier #1 Fault Replace rectifier. A0421 (BTS) Rectifier #2 Fault Replace rectifier. A0430 (BTS) Aircon #1 fault Check if AirCon operates, and replace that upon non-operation. A0431 (BTS) Aircon #2 fault Check if AirCon operates, and replace that upon non-operation. A0440 (BTS) Water leakage Prevent A/C water leakage from its affecting BTS operation. Replace sensor and ACU. A0500 (BTS) Generated when GPS Control Cable of corresponding rack, shelf is open. Check if Control Cable is normal. After checking BackBoard Cable, replace that if abnormal. If not connected, take quick measure. A0600 (BTS) Generated when alarm cable of corresponding rack, shelf is open. Check if Alarm Cable is normal. After checking BackBoard Cable, replace that if abnormal. If not connected, take quick measure. A0610 (BTS) Generated when Rack FAN Alarm Cable is Open. After checking BackBoard Cable, replace that if abnormal. If not connected, take quick measure. A0620 (BTS) Generated when alarm cable of environmental sensor is open Check cable connection, and replace that if normally connected. A0800 (BTS) Generated when Rack FAN Alarm Cable is Open. After checking BackBoard Cable, replace that if abnormal. If not connected, take quick measure. A1000 (BTS) Generated when the status of the other board is abnormal while one side of dual GPS-R is normal. As alarm generated from GPS-R may be generated owing to board deletion, GPS-R Antenna Cable Failure , OSC failure, etc., check up that. Replace power output module. A1001 (BTS) Generated when both sides of dual GPS-R are abnormal. As alarm generated from GPS-R may be generated owing to board deletion, GPS-R Antenna Cable Failure , OSC failure, etc., check up that. Replace power output module. A1500 Generated when the status of the BCRA HW mounting check or INIT
STAREX-IS BSM Manual Page:748(877)Issue:1.0SMD-011-PMA210 (BTS) other board is abnormal while one side of dual BCRA is normal LED red or OFF, BCRA non-operation/ BCRA HW check A1501 (BTS) Generated when both sides of dual BCRA are abnormal. BCRA HW mounting check or INIT LED red or OFF, BCRA non-operation/ BCRA HW check A1700 (BTS) Generated when the other side is abnormal while one side of dual BSP(UCPA) is normal Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A1701 (BTS) Generated when both sides of dual BSP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A1750 (BTS) Generated when the other side is abnormal while one side of dual RCP(RCCA) is normal.( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A1751 (BTS) Generated when both sides of dual RCP(RCCA) are abnormal. ( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A1760 (BTS) Generated when BPPA is removed Check the status of BPPA by status check command. Check BPPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A1770 (BTS) Generated when BPPA application falls into free running loop, thus generating watchdog, and Fault -address/bus error- occurs by BPPA application malfunction, and hardware is reset by Low Power warning Check the status of BPPA by status check command. Check BPPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board A1800 (BTS) Generated when 1pps clock reception from GPS-R fails, or received clock is wrong. Check power, 1pps cable and UCPA H/W. A1810 (BTS) Generated when 10MHz Clock reception from GPS-R fails, or received clock is wrong Check power, 10MHz cable and UCPA H/W. A1850 Generated when BTS RCMD board is Check if RCMD board is removed
STAREX-IS BSM Manual Page:749(877)Issue:1.0SMD-011-PMA210 (BTS) deleted. and mount that if removed. A1860 (BTS) Generated when CPU or FPGA Fail occurs in RCMD board. Check the following as to RCMD.( check FAIL LED ON/R.C execution/R.C result) A2000 (BTS) Generated when one side of dual PRI boards of BSPB, BANB is abnormal. Check power and replace that if abnormal. A2001 (BTS) Generated when both sides of dual PRI boards of BSPB, BANB are abnormal. Check power and replace that if abnormal. A2010 (BTS) Generated when one side of dual PRI boards of RCCB, DBPB is abnormal. Check power and replace that if abnormal. A2011 (BTS) Generated when both sides of dual PRI boards of BSPU, BANU are abnormal. Check power and replace that if abnormal. A2300 (BTS) Generated when DBPA is removed Check DBPA Slot, and if normal, check Backboard Pin, and if abnormal, replace board. A2310 (BTS) Generated when DBPA is removed or abnormal owing to other cause Check DBPA Slot, and if normal, check Backboard Pin, and if abnormal, replace board A2320 (BTS) Generated when BUDA is removed. Check BUDA Slot, and if normal, and if normal, check Backboard Pin, and if abnormal, replace board. A2330 (BTS) Generated 10MHz or PLL(IF,RF, 7.2(DCN case)) or DC power (5Vd, +/-12Va, 5Va) fail, or reset. - REF(10MHz) : Check 10M Cable, and if normal, replace BUDA. - SYNT1(RF PLL) : Replace BUDA. - SYNT2(IF PLL) : Replace BUDA. - SYNT3(7.2MHz) : Replace BUDA. A2340 (BTS) PACA removal (active high). Check PACA Slot, and if normal, check Backboard Pin, and if abnormal, replace board. A2350 (BTS) - power fail : TTL - H/W, S/W Reset - PLL LOCK Fail (TTL) - GPS 10MHz Reference Signal Fail(TTL) - H/W, S/W Reset : auto recovery - PLL Lock Fail : Check RCCA status or replace board. - GPS Signal Fail : Check PACA GPS Input Cable.
STAREX-IS BSM Manual Page:750(877)Issue:1.0SMD-011-PMA210 - shunt port open (enable)/Short(disable). - Aging Fail : Backboard shunt open A2400 (BTS) Generated +27V status is abnormal. PWR_FAIL : Check up+27V status supplied from BUS BAR. A2410 (BTS) MS_OPEN, MAT_OPEN, DPDT_OPEN or CTL_OPEN(BDCD) DC power (27V, +/-12V, 5V) or Reset - MS_OPEN : check MS status. - MAT_OPEN : check BRMD status. - DPDT_OPEN: check DPDT status. - CTL_OPEN : check BDCD status. A2420 (BTS) LICA deletion Check LICA Slot, and if normal, check Backboard Pin, and if abnormal, replace board. A2430 (BTS) CPU fail, SW reset, HW reset, remote reset, power fail INIT LED red or OFF, ALPA non-operation/ LICA HW check A2440 (BTS) ARIA deletion (active high). By status check command, check the status of ARIA. Check ARIA Slot, and if normal, check BackBoard Pin, and if abnormal, replace board. A2450 (BTS) When ARIA Application falls into free running loop, thus generating watchdog, and Fault -address/bus error- occurs owing to ARIA application malfunction, and hardware is reset by Low Power warning Check ARIA status and ARIA Slot, and if normal, check Backboard Pin and if abnormal, replace board. A2470 (BTS) Power failure (active high) RUN LED off, BOTA non-operation/BOTA power fail message/ power cable check and BOTA HW check A2480 (BTS) Reference signal cable open(A AND B) or system clock(A AND B) or even clock(A AND B) or 10M or reset or PLL unlock(A or B or G) or CPU faile Function Fail LED red, BOTA non-operation/ MMC for fail cause analysis /clock and 10M cable connection check, BOTA HW check A2490 - H/W, S/W, PWR Reset : TTL High - H/W, S/W Reset : auto recovery
STAREX-IS BSM Manual Page:751(877)Issue:1.0SMD-011-PMA210 (BTS) - PLL LOCK Fail : TTL High - PLL Lock Fail : RISA status check or board replacement A2491 (BTS) - Power Fail : TTL High Power +12V, -12V, +5V, -5V Power Short : H/W replacement and repair A2500 (BTS) LPA reportsd the status of insertion and deletion to combiner. Check if LPA is normally installed in combiner. A2510 (BTS) DC Power off, or switch off, or Major alarm and Disable, or H/W reset. Check if LPA DC switch is ON / check if DC power is normally applied while LPA is installed / check if major alarm was generated. A2520 (BTS) Combiner DC power off or Combiner H/W reset. Check if DC is connected to Combiner #N / check is H/W is reset. A2530 (BTS) Combiner Alpha FAN fail report. Check FAN power cable connection/ bad FAN?  FAN replacement A2540 (BTS) Generated when LPA DC power is unstable. Check if DC voltage operates within operating voltage(21~30V). A2550 (BTS) A lot of RF power reflected on LPA output port Check LPA and combiner RF connection/ check combiner RF output cable connection. A2560 (BTS) LPA disabled Send RF enable command. A2570 (BTS) high input power level. As it is generated owing to high LPA RF input power level, check RF input power level. A2580 (BTS) High LPA temperature. Check if Shelf FAN is normal. A2590 (BTS) High input Power level. Drop LPA output level, and send Status request or reset command to enable LPA. A2600 (BTS) - monitors status monitor line cable open. - connects pin assigned to internal Front End to GROUND. Check and connect cable. A2610 Apply power to LNA inside of Front FEU(LNA) replacement.
STAREX-IS BSM Manual Page:752(877)Issue:1.0SMD-011-PMA210 (BTS) End or detect the status of supplied voltage and RF device, and composite them for provision at TTL Active High upon fail with one pin. A2700 (BTS) Reports the status of HPA insertion/deletion. Check if HPA cable is normal. A2710 (BTS) HPA DC power off or power failure. Check if HPA DC power is normally supplied. A2720 (BTS) A2730 (BTS) A lot of RF power reflected on HPA output port. Check if HPA RF output cable connection is normal / replace RF output cable. A2740 (BTS) HPA disables. Send HPA enable command. A2750 (BTS) High HPA temperature Check if fan that provides ait flow to HPA is normal. A2760 (BTS) High input Power level / disable alarm along with Over Power warning alarm is defined as over power alarm. Check if RF input power level is high, which is applied to HPA. A4600 (BSC) Generated if alarm cable connected to CCSB, ASMB, ALSB, SLB, VCB Shelf is deleted. Check the status of Alarm Cable, and replace that if normal. A4800 (BSC) Abnormal FAN in BSC. Check FAN Alarm Cable, and replace FAN if normal. A5500 (BSC) Generated when the other side is abnormal while one side of dual NCP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5501 (BSC) Generated when both sides of dual NCP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5510 Generated when the other side is abnormal while one side of dual Reinstall board upon deletion, or check FAIL LED ON/R.C
STAREX-IS BSM Manual Page:753(877)Issue:1.0SMD-011-PMA210 ALP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) execution/R.C result. A5511 Generated when both sides of dual ALP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5550 Generated when the other side is abnormal while one side of dual ALMA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check ALMA HW status. - INIT LED red or OFF, ALMA non-operation / ALMA HW check A5551 Generated when both sides of dual ALMA are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ALMA HW status. - INIT LED red or OFF, ALMA non-operation/ ALMA HW check A5560 Generated when the other side is abnormal while one side of dual ASCA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ASCA HW status. - INIT LED red or OFF, ASIA-E non-operation/ Check ASCA HW. A5561 Generated when both sides of dual ASCA are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ASCA HW status. - INIT LED red or OFF, ASIA-E non-operation/ ASCA HW check A5700 Generated when the other side is abnormal while one side of dual CCP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5701 (BSC) Generated when both sides of dual CCP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5710 (BSC) Generated when the other side is abnormal while one side of dual CCP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) Reinstall board upon deletion, or check FAIL LED ON/R.C execution/R.C result. A5711 (BSC) Generated when both sides of dual CCP(UCPA) are abnormal. ( Board Reinstall board upon deletion, or check FAIL LED ON/R.C
STAREX-IS BSM Manual Page:754(877)Issue:1.0SMD-011-PMA210 deletion, CPU or FPGA Fail) execution/R.C result. A5720 (BSC) Generated when SLMA is abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check SLMA HW status. - INIT LED red or OFF, SLMA non-operation/ SLMA HW check A5730 (BSC) Generated when VCMA is abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check VCMA HW status. - INIT LED red or OFF, VCMA non-operation/ VCMA HW check A5800 (BSC) Generated when CCP fails to receive 1pps Clock from GPS-D, or the received clock is wrong. Check power, 1PPS cable and UCPA H/W. A5810 (BSC) Generated when CCP fails to receive 10MHz Clock from GPS-D, or the received clock is wrong. Check power, 10MHz cable and UCPA H/W. A6000 (BSC) Generated when one side of dual PRI board is abnormal. Check power and replace that if abnormal. A6001 (BSC) Generated when both sides of dual PRI board are abnormal. Check power and replace that if abnormal. A6010 (BSC) Generated when one side of dual PRI board is abnormal. Check power and replace that if abnormal. A6011 (BSC) Generated when both sides of dual PRI board are abnormal. Check power and replace that if abnormal. A6020 (BSC) Generated when one side of dual PRI board is abnormal. Check power and replace that if abnormal. A6021 (BSC) Generated when both sides of dual PRI board are abnormal. Check power and replace that if abnormal. A6030 (BSC) When PRI board of SLB is abnormal Check power and replace that if abnormal. A6040 (BSC) When PEI board of VCB is abnormal Check power and replace that if abnormal. A6220 (BSC) Generated when the other side is abnormal while one side of dual ASIA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check ASIA HW status. - INIT LED red or OFF, ASIA HW check
STAREX-IS BSM Manual Page:755(877)Issue:1.0SMD-011-PMA210 A6221 (BSC) Generated when both sides of dual ASIA are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check ASIA HW status. - INIT LED red or OFF, ASIA HW check A6260 (BSC) ATSA Board deletion Check ATSA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6270 (BSC) Generated when ATSA Application falls into free running loop, thus generating watchdog, and Fault -address/bus error occurs owing to ATSA Application malfunction, and hardware is reset Although it attempts recovery automatically, replace the board if Function Fail continuously occurs. A6280 (BSC) ALPA Board Deletion Check ALPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6290 (BSC) CPU fail, SW reset, HW reset, remote reset, power failure INIT LED red or OFF, ALPA non-operation / ALPA HW check A6300 (BSC) STIA Board deletion By state check command, check the status of STIA. Check the status of STIA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6310 (BSC) Generated when STIA Application falls into free running loop, thus generating watchdog, and Fault -address/bus error occurs owing to STIA Application malfunction, and hardware is reset By status check command, check the status of STIA. Generally, auto recovery is attempted, but if Function Fail continues, replace the board. A6350 (BSC) Generated subhighway cable open from STIA to VLIA. Check the cable, and if normal, replace STIA. A6400 (BSC) Generated if SLPA is deleted. Check SLPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6410 (BSC) Generated when SLPA Application falls into free running loop, thus Although it attempts recovery automatically, replace the board if
STAREX-IS BSM Manual Page:756(877)Issue:1.0SMD-011-PMA210 generating watchdog, and Fault -address/bus error occurs owing to SLPA Application malfunction, and hardware is reset Function Fail continuously occurs. A6500 (BSC) VCPA Board deletion Check VCPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6510 (BSC) Generated when SLPA Application falls into free running loop, thus generating watchdog, and Fault -address/bus error occurs owing to SLPA Application malfunction, and hardware is reset Although it attempts recovery automatically, replace the board if Function Fail continuously occurs. A6520 (BSC) VLIA Board deletion Check VLIA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A6530 (BSC) Generated when VLIA Application falls into free running loop, thus generating watchdog, and Fault -address/bus error occurs owing to VLIA Application malfunction, and hardware is reset Although it attempts recovery automatically, replace the board if Function Fail continuously occurs. A6540 (BSC) Generated when link fault of target MSC on the link between VLIA and MSC is detected Check the status of the link on MSC part and the status of trunk board. A6541 (BSC) Local Trunk Error due to Frame Error, Sync Error Check the status of VLIA kink and replace the board if normal. A6542 (BSC) When more than 30 slips occur for 1 hour due to environmental cause concerning the link connected to MSC Check VLIA status and if normal, replace the board. A6543 (BSC) When more than 288 BIT Errors occur for 1 hour due to environmental cause concerning the link connected to MSC Check VLIA status and if normal, replace the board. A6610 Generated if ABID Board of CCSB Check the status of ABID BOARD,
STAREX-IS BSM Manual Page:757(877)Issue:1.0SMD-011-PMA210 (BSC) Shelf is removed. and if fault occurs despite its connection, replace ABID BOARD. A6611 (BSC) Generated when ABID Board of ASMB Shelf is removed. Check the status of ABID BOARD, and if fault occurs despite its connection, replace ABID BOARD. A6620 (BSC) SAID Board of SLB Shelf is removed. Check the status of SAID BOARD, and if fault occurs despite its connection, replace SAID BOARD. A6630 (BSC) When the other clock recept encounters a problem while one side of clock to clock cable of dual SMP is normally received Check corresponding cable status and CCP status. If normal, replace SMP board. A6631 (BSC) When the other clock recept encounters a problem while one side of clock to clock cable of dual SMP is normally received Check corresponding cable status and CCP status. If normal, replace SMP board. A6640 (BSC) Generated when SAID Board of VCB Shelf is deleted. Check if SAID BOARD is equipped, and if a fault occurs despite its connection, replace SAID BOARD. A6650 (BSC) When the other clock receipt encounters a problem while one side of clock to clock cable of dual VMP is normally received Check corresponding cable status and CCP status. If normal, replace SMP board. A6651 (BSC) When the other clock receipt encounters a problem while one side of clock to clock cable of dual VMP is normally received Check corresponding cable status and CCP status. If normal, replace SMP board. A6900 (BSC) Error of E1/T1 link connected to ALPA (LOSS OF SYNC, REMOTE ALARM INDICATION, ALARM INDICATION SIGNAL, OUT OF FRAME) Check E1/T1 link cable and ALPA, LICA, and if abnormal, replace that. A6910 (BSC) Error of STM-1 link connected to ALPA (LOSS OF SYNC, REMOTE ALARM INDICATION, ALARM INDICATION SIGNAL, OUT OF Check STM-1 link cable and ALPA, LICA, and if abnormal, replace that.
STAREX-IS BSM Manual Page:758(877)Issue:1.0SMD-011-PMA210 FRAME) A7500 (CAN) Generated when GPS-R Control Cable is open Check BackBoard Cable, and if abnormal, replace that. A7600 (CAN) Alarm cable connected to CAMB, CPNB, PCFB is open or other fault occurs Check cable status, and if normal, replace cable. A7800 (CAN) CAN Rack FAN failure. Check FAN power status and alarm cable status, and if normal, replace FAN or Cable. A8000 (CAN) Generated when the other side is abnormal while one side of dual GPS-R is normal. As alarms generated by GPS-R may be generated owing to board deletion, GPS-R Antenna Cable open, OSC defect, etc., check up that. Replace power output module. A8001 (CAN) Generated when both sides of dual GPS-R are abnormal. As alarms generated by GPS-R may be generated owing to board deletion, GPS-R Antenna Cable open, OSC defect, etc., check up that. Replace power output module A8050 (CAN) Generated when the internal status of GPSD are abnormal. Generated if power output module is abnormal. As alarms generated from GPSD may be generated owing to GPSD Antenna Cable open, OSC defect, etc., check up that. Replace power output module. A8110 (CAN) Generated if RS422 Cable that connects RAPU(Remote Alarm Panel Unit) to AMPA is open or communication between them is impossible due to fault. Check if RS422 Cable is open, and if it continues, replace cable. A8500 (CAN) Generated when the other side is abnormal while one side of dual CNP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall the board or if not, check FAIL LED ON/R.C execution /R.C result. A8501 When both sides of dual Upon board deletion, reinstall the
STAREX-IS BSM Manual Page:759(877)Issue:1.0SMD-011-PMA210 (CAN) CNP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) board or if not, check FAIL LED ON/R.C execution /R.C result. A8550 (CAN) Generated when the other side is abnormal while one side of dual ASCA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power defect) - check ASCA HW status - INIT LED red or OFF, ASIA-E non-operation / ASCA HW check A8551 (CAN) Generated when the other side is abnormal while one side of dual ASCA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power defect) - check ASCA HW status. - INIT LED red or OFF, ASIA-E non-operation / ASCA HW check A8560 (CAN) Pcgenerated when the other side is abnormal while obe side of dual FERA is normal. Check FERA status and if normal, replace bpard. A8561 (CAN) Generatede when both sides of dual FERA are abnormal. Check FERA status and if normal, replace the board. A8570 (CAN) Generated when the other side is abnormal while one side of dual ASCA is nlormal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check ASCA HW status. - INIT LED red or OFF, ASIA-E non-operation / ASCA HW check. A8571 (CAN) Generated when both sides of dual ASCA are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - check ASCA HW status. - INIT LED red or OFF, ASIA-E non-operation/ ASCA HW check. A8600 (CAN) Generated when the other side is abnormal while one side of dual PNP(UCPA) is abnormal.( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8601 (CAN) Generated when both sides of dual PNP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8700 (CAN) Controlled by communication with AMPA in case AMPA(Remote Alarm Panel Unit) connected to AMPA via If AMPA is normal, check alarm panel status, and if AMPA is abnormal, immediate measure should
STAREX-IS BSM Manual Page:760(877)Issue:1.0SMD-011-PMA210 Ethernet is abnormal. be taken. A8710 (CAN) Generated when the other side is abnormal while one side of dual PCP(UCPA) is normal.( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8711 (CAN) Generated when both sides of dual PCP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8720 (CAN) Generated when the other side is abnormal while one side of dual PMP(UCPA) is normal( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8721 (CAN) Generated when both sides of dual PMP(UCPA) are abnormal. ( Board deletion, CPU or FPGA Fail) Upon board deletion, reinstall that, or check FAIL LED ON/R.C execution/R.C result. A8740 (CAN) generated when the other side is abnormal while one side of dual BCRA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) BCRA HW status checj or INIT LED red or OFF, BCRA non-operation/ BCRA HW check A8741 (CAN) Generated when both sides of dual BCRA are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) BCRA HW status check or INIT LED red or OFF, BCRA non-operation/ BCRA HW check A8800 (CAN) When PCP could not receive 1pps Clock from GPS-D, or the received clock is wrong. power, 1PPS cable and UCPA H/W check A8810 (CAN) When PCP could not receive 10MHz Clock from GPS-D, or the received clock is wrong. power, 10MHz cable and UCPA H/W check A8820 (CAN) While one side of FERA is normal, there occurs a failure on the link between FERA and FETA of the other side. Check the link between FETA and PDSN, and if normally connected, replace FERA, FETA. A8821 (CAN) While one side of FERA is abnormal, there occurs a failure on the link Check the link between FETA and PDSN, and if normally connected,
STAREX-IS BSM Manual Page:761(877)Issue:1.0SMD-011-PMA210 between FERA and FETA of the other side. replace FERA, FETA. A8840 (CAN) Failure in link between FETA and PDSN Check the link between FETA and PDSN, and if normally connected, replace FETA. A9000 (CAN) One side failure of dual PRI board of CAMB. Check up power and replace that if abnormal. A9001 (CAN) Both side failure of dual PRI board of CAMB. Check up power and replace that if abnormal. A9010 (CAN) One side failure of dual PRI board of PCFB(PCP included Shelf). Check up power and replace that if abnormal. A9011 (CAN) Both side failure of dual PRI board of PCFB(PCP included Shelf). Check up power and replace that if abnormal. A9020 (CAN) One side failure of dual PRI board of PCFB(PMP included Shelf). Check up power and replace that if abnormal. A9021 (CAN) Both side failure of dual PRI board of PCFB(PMP included Shelf). Check up power and replace that if abnormal. A9040 (CAN) One side failure of dual PRI board of CPNB. Check up power and replace that if abnormal. A9041 (CAN) One side failure of dual PRI board of CPNB. Check up power and replace that if abnormal. A9220 (CAN) Generated when the other side is abnormal while one side of dual ASIA in CAMB is normal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ASIA HW status. - INIT LED red or OFF, ASIA HW check A9221 (CAN) Bothy sides of dual ASIA in CAMB are abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ASIA HW status. - INIT LED red or OFF, ASIA HW check A9230 (CAN) When the other side is abnormal while one side of dual ASIA is normal.(board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - Check ASIA HW status. - INIT LED red or OFF, ASIA HW check A9231 Both sides of dual ASIA are - Check ASIA HW status.
STAREX-IS BSM Manual Page:762(877)Issue:1.0SMD-011-PMA210 (CAN) abnormal. (board deletion, CPU fail, SW reset, HW reset, remote reset, power failure) - INIT LED red or OFF, ASIA HW check A9240 (CAN) AOTA Board deletion Check AOTA HW status. A9250 (CAN) In-CAMB AOTA Board CPU fail, SW reset, HW reset, remote reset, power failure, etc. INIT LED red or OFF, AOTA non-operation/ AOTA HW check A9260 (CAN) In-CAMB ATSA Board deletion Check ATSA Slot, and if normal, check BackBoard Pin, and if normal, replace the board. A9270 (CAN) When ATSA Application falls into free running loop, thus generating watchdog, and Fault, address/bus error occurs by ATSA Application malfunction, and hardware is reset. Generally, auto recovery is attempted, but if Function Fail continues, replace the board. A9300 (CAN) In-PCFB PIPA Board deletion Check PIPA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A9310 (CAN) When PIPA Application falls into free running loop, thus generating watchdog, and Fault, address/bus error occurs by ATSA Application malfunction, and hardware is reset. Generally, auto recovery is attempted, but if Function Fail continues, replace the board. A9320 (CAN) FETA Board deletion Check FETA Slot, and if normal, check BackBoard Pin, and if abnormal, replace the board. A9330 (CAN) When FETA Application falls into free running loop, thus generating watchdog, and Fault, address/bus error occurs by ATSA Application malfunction, and hardware is reset. Generally, auto recovery is attempted, but if Function Fail continues, replace the board. 7.1.4. Measures for Fault Message
STAREX-IS BSM Manual Page:763(877)Issue:1.0SMD-011-PMA210 FAULT Description Measures F1000 Generated when there is no response after Processor Keep Alive, and link is blocked or there is actual problem in processor. Check Network Link, and if abnormal, check Network Card. F1110 Tx Parity Fault in CDMA Data Combine Module. 1. Check BUDA contact 2. Switch over RCP 3. Replace BUDA F1170 Channel Configuration info receipt failure. Check BSP and network between BSP/RCP, and if normal, switch over or reset RCP. F1180 Wrong Channel Configuration info Switch over BSP. F1300 When there is an error in Even System Clock. Reset CH CARD as interrupt malfunctions or CH S/W malfunctions. F1301 Error in external system clock. Reset Channel Card. F1302 Generated when after CHC activation, it can’t receive TOD info within 10 seconds. Reset Channel Card, and if it continues, check BSP status and IPC PATH. F1303 No FREE_Q for message transfer from Channel to RCP Reset Channel Card. F1304 Generated when internal time of channel is different from the time that increases by 80ms INT, and call setup malfunctions. Reset Channel Card. F1310 Generated upon Clock Error and Modem Control Defect. Reset Channel Card. F1311 Wrong TOD information. Reset Channel Card. F1400 Generated when there is no message to SVC as Message Free Queue to SVC is empty. Reset Channel Card. F1410 Generated when there is no queue resources to store message from BSP or RCP. Reset Channel Card. F1420 If Tx FIFO for Traffic Channel is Full. Reset Channel Card.
STAREX-IS BSM Manual Page:764(877)Issue:1.0SMD-011-PMA210 F1510 Generated when there is no queue resource to store message to be sent to BSP. Reset Channel Card. F1600 When there is no Encoder Queue resource. Reset Channel Card. F1610 No queue resource to store page message except for General Page message. Reset Channel Card. F1620 No queue message to generate and store Quick Page message. Reset Channel Card. F1630 No queue resource to store Reply Message when reply is required regarding message from BSP. Reset Channel Card. F1640 As the case that Paging Channel prroly writes frame every 20ms, it is generated more than 20 times consecutively. Reset Channel Card. F1650 No queue resource to store General Page message from BSP. Reset Channel Card. F3000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card. F3020 Error occurs in the course of testing VCE Generated also if there is no None Zero PCM Frame from TSLU. But, as QAT_F does not conduct vocoder test as to VOC that was once generated, test that by giving load to entire SVC Card. If the problem continues, replace VOC. F3030 Error in the course of testing DSP Check up Checksum, Read/Write, Flag Set, etc. F3040 There is error in time-slot in the course of testing VLIA T1/E1 Trunk. As there is high possibility of physical problem in corresponding trunk itself, check up trunk section
STAREX-IS BSM Manual Page:765(877)Issue:1.0SMD-011-PMA210 and replace that if necessary. F3050 If call is not connected in the course of call processing, this cause is displayed. Check PLD Data and modify wrong DATA. Check Parameter DATA error cause and value and request the person in charge to take measures. F4000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card.. F5000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card.. F6000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card.. F7000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card.. F8000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card. F9000 Generated when there is no response after keeping alive the processor, and link is blocked or the processor itself encounters a problem. Check Network Link, and if there is any error, check Network Card.
STAREX-IS BSM Manual Page:766(877)Issue:1.0SMD-011-PMA210 7.2. Status Message Description and LIST Status Definition and LIST Table 7.2-1 Status Message LIST Code Definition Description S3002 CAN CNP/PNP Status Change Display Displayed upon processor status change S3003 AMP Status Change Display Displayed upon processor status change S3004 ALP Status Change Display Displayed upon processor status change S3005 CCP Status Change Display Displayed upon processor status change S3006 SMP Status Change Display Displayed upon processor status change S3007 VMP Status Change Display Displayed upon processor status change S3008 PCP Status Change Display Displayed upon processor status change S3009 BSC-NCP Status Change Display Displayed upon processor status change S3010 BSP Status Change Display Displayed upon processor status change S3011 SCP Status Change Display Displayed upon processor status change S3012 BPP Status Change Display Displayed upon processor status change S3013 RCP Status Change Display Displayed upon processor status change S3017 CRP Status Change Display Displayed upon processor status change S3020 PMP Status Change Display Displayed upon processor status change S3201 CNP ASIA Status Change Display Displayed upon device status change S3202 CNP ASCA Status Change Display Displayed upon device status change S3205 PNP ASIA Status Change Display Displayed upon device status change S3206 PNP ASCA Status Change Display Displayed upon device status change S3209 PCP BCRA Status Change Display Displayed upon device status change S3210 PMP BCRA Status Change Display Displayed upon device status change
STAREX-IS BSM Manual Page:767(877)Issue:1.0SMD-011-PMA210 S3211 AMP GPSR Status Change Display Displayed upon device status change S3220 NCP ASIA Status Change Display Displayed upon device status change S3221 NCP ASCA Status Change Display Displayed upon device status change S3222 NCP ATSA Status Change Display Displayed upon device status change S3224 ALP ALMA Status Change Display Displayed upon device status change S3230 BSP GPS Status Change Display Displayed upon device status change S3501 CCP Overload State Change Display Displayed when overload status is generated, released and changed owing to load change in CCP S3502 BSP Overload State Change Display Displayed when overload status is generated, released and changed owing to load change in BSP Table7.2-2 Processor Status LIST Status Type Definition NORM NORMAL ABNM Abnormal DCPY Dual Copy LDNG StandBy Loading NORM(OLD) Normal (after StandBy Loading, Old version) NORM(NEW) Normal (after StandBy Loading, New version) ABN_K Abnormal with Keep Alive Fault ABN_I Abnormal with Process Isolation UNDEF Undefined Status Table 7.2-3 Network Node Status LIST Status Type Definition Description NORM Normal Normal NOR_A Normal Act Normal Activation (dual node)
STAREX-IS BSM Manual Page:768(877)Issue:1.0SMD-011-PMA210 NOR_S Normal Standby Normal Standby (dual node) ABN_D Abnormal Deletion Card deltion ABN_F Abnormal Fault Local Fault ABN_M Abnormal MMC Block Abnormal MMC block INIT Initial Despite being equipped in PLD, processor in charge of corresponding device malfunctions from the start to the present. AB_OB Abnormal Online Block Device blocked as normal call is impossible diw to other device fault N_EQP Not Equipped Card type is not defined in PLD Table 7.2-4 Vocoder Channel Element Status LIST Status Type Definition Description IDLE Idle Idle 8K_Qcelp 8k Qcelp Call 8k QCELP call setup 8K_EVRC 8k EVRC Call 8k EVRC call setup 13K_Qcelp 13k Qcelp Call 13k QCELP call setup 13K_EVRC 13k EVRC Call 13k EVRC call setup ABN_M Abnormal MMC Block Abnormal MMC block UNDEF Undefined Status Undefined status Table 7.2-5 Network Node Mode List Mode Type Definition Description ACT Active Normal (ACT LED ON) SBY StandBy Normal (ACT LED OFF) Table7.2-6 DEVICE Status List Status Tyoe Definition NORM Normal ABN_D Abnormal Deletion
STAREX-IS BSM Manual Page:769(877)Issue:1.0SMD-011-PMA210 ABN_F Abnormal Fault (Test: As a result of DSP Chip Hardware test, NOK) ABN_M Abnormal MMC Block INIT Initial AB_OB Abnormal Online Block IDLE Idle (CE, VCE) BUSY Busy (CE, VCE) N_EQP Not Equipped in PLD READY Device mounted although not defined in PLD UNDEF Undefined status ABN_I H/W Reset isolation ABN_B On-demand BER Test status NOR_PB Status until call is disconnected if there is a call when blocking CHC, Chip, Status until call is terminated for vocoder test REDNCY Standby side Redundancy (FETA Only) CB_OPN Faulty Cable Open CLK_F As a result of Timing-Module test, NOK (Test Only) TSW_F As a result of TSLU Loopback test, NOK (Test Only) ABN_AT Auto test of vocoder (Online) (Test Only) ABN_MT Manual test of vocoder (Ondemand) (Test Only) QAT0_F As a result of QCELP Algorithm test, NOK in State0 (Test Only) QAT1_F As a result of QCELP Algorithm test, NOK in State1 (Test Only) QAT2_F As a result of QCELP Algorithm test, NOK in State2 (Test Only) QAT3_F As a result of QCELP Algorithm test, NOK in State3 (Test Only) VPLB_F As a result of VCPA Loopback test result, NOK (Test Only) VMLB_F As a result of VCMA Loopback test result, NOK (Test Only) VLLB_F As a result of VLIA Loopback test, NOK (Test Only) 7.3. DCI Debugger Command 7.3.1. Tx/Rx Message Trace Function This function includes asf, arf command, etc. asf command trances message from BSM to lower processor, and arf command traces message from lower processor to BSM. 7.3.1.1. asf Command
STAREX-IS BSM Manual Page:770(877)Issue:1.0SMD-011-PMA210 7.3.1.1.1. Input asf [all/off] : If a factor is not set in asf command, or as a factor, all is set, it can trace all messages from BSM. It can stop Tx message trace set to asf off command. asf sigid [dstaddr] : It can be used to trace only Tx message to specific IP or specific signal ID value without tracing all messages. To trace specific signal ID to all targets, it is used in the form of asf sigid, and to trace specific signal ID to specific target, it can be used in the form of asf sigid dstaddr. Here, dstaddr can set a factor in the form of hexadecimal 32bit-word value or dotted-decimal. asf ffff dstaddr : It can be used to trace all signals to specific IP. Likewise, IP address is set in the form of 32bit-word or dotted-decimal. 7.3.1.1.2. Output Message traced by asf command has the following output format. The output contents are message Tx time and message header information.
STAREX-IS BSM Manual Page:771(877)Issue:1.0SMD-011-PMA210 Message Tx time => ASF(qid:5101) at Fri Feb 2 10:40:25 2001 Msg_flag [0xF634] Msg_len [0028] Message length Src_IP [0x1DC00001] Dest_IP [0x11400101] Dest(target) Src_TID [000682] Dest_TID [000000] IP & Task ID Remain_conn [FALSE ] Sig_id [0x0A66] signal ID Remain_time [00 sec] Src(BSM) IP and Task ID 7.3.1.2. arf Command 7.3.1.2.1. Input arf [all/off] : This can trace all messages received to BSM if a factor is not set in arf command, or all is set as factor. IT can stop tracing Rx message set as arf off command. arf sigid [srcaddr] : Without tracing all messages, this can be used only to trace specific signal ID value or Rx message from specific IP. To trace specific signal ID from all targets, it is ued in the form of arf sigid, and to trace specific signal ID from specific target, it can be used in the form of arf sigid srcaddr. Here, srcaddr can set a factor in the form of hexademical 32bit-word value or dotted-decimal. asf ffff srcaddr : This is to trace all signals from specific IP. Likewise, IP address is set in the form of 32bit-word or dotted-decimal. 7.3.1.2.2. Output Message traced by arf command has the following output format. The output contents are message Tx time and message header information.
STAREX-IS BSM Manual Page:772(877)Issue:1.0SMD-011-PMA210 Info on App to receive message Message Rx time => ARF[0x0A65](qid:5105/pid:670) at Fri Feb 2 10:40:25 2001 Msg_flag [0xF634] Msg_len [0225] Message length Src_IP [0x11400201] Dest_IP [0x1DC00001] Dest(BSM) Src_TID [000074] Dest_TID [000000] IP & Task ID Remain_conn [FALSE ] Sig_id [0x0A65] Signal ID Remain_time [00 sec] Src(Target) IP & Task ID
STAREX-IS BSM Manual Page:773(877)Issue:1.0SMD-011-PMA210 7.3.2. Function to test Function This function includes sis and ipclog console command. sis command is to send IPC signal message for test to message queue, and ipclog command is to send test message to monitor the status of slave processor. 7.3.2.1. sis Command 7.3.2.1.1. Input If simply inputting sis, the following question is displayed: Message queue key? (HEX) 20B key value of message queue to store message Message type? (DECIMAL) 1920 message type: Sets task ID(or process ID) of processor to receive message. Source IP address? (HEX or DOTTED-DECIMAL) 11400201 message header Src IP value Source Task ID? (DECIMAL) 82 message header Src TID value Destination IP address? (HEX or DOTTED-DECIMAL) 1DC00001 message header Dest IP value Destination Task ID? (DECIMAL) 1920 message header Dest TID value Signal ID? (HEX) A30 message header signal ID value Body Length? (DECIMAL) 8 test message body length Body Message? (8 HEX's) 01 23 45 67 89 AB CD EF test message body To avoid the above procedure, you can set the following factor: sis [Qkey Mtype SrcIP SrcTID DstIP DstTID SigID BodyLen Msg] To create test message the same as the above example, you can enter the following: sis 20B 1920 11400201 82 1DC00001 1920 A30 8 "01 23 45 67 89 AB CD EF” 7.3.2.1.2. Output Display of this command is to display the status of messsssage sending to message queue.
STAREX-IS BSM Manual Page:774(877)Issue:1.0SMD-011-PMA210 COMPLETED! (sis) ERROR! sending IPC message... (sis) 7.3.2.2. ipclog Command 7.3.2.2.1. Input Enter ipclog in DCI console to display a window for ping test on target. To adjust $DISPLAY environmental variable, use display command(see 5.5). Figure 7.3-1 IP Input Request Window in DCI Window Factors to enter are as follows: Target IP?(HEX or DOTTED-DECIMAL) 11400201 IP address of target to send test message Target=17.64.2.1 Packet Size?(byte) 512 test message byte number Test count? 20 test message count to send Test interval?(usec) 10 interval to send test message
STAREX-IS BSM Manual Page:775(877)Issue:1.0SMD-011-PMA210 7.3.2.2.2. Output The result of test message sending is as follows: ### RESULT ### ==================================== TargetIP SEND RECV CORRUPT ------------------------------------ 11400201 0020 0016 0001 message number with ==================================== broken contents message number with test message received target address sent number of messasges sent 7.3.3. Status Display Funciton This function includes ipcs, isig, status, rsock, ssock, etc. ipcs command is to display the status of current IPC message queue in window, and isig command is to display the contents of link table in window, and status displays the status of DCI console in window. rsock command displays the status of socket connection for message receipt in window. ssock command displays the status of socket connection for message sending. ssock command displays only the status of the connection to use connection maintenance function. 7.3.3.1. ipcs Command 7.3.3.1.1. Input ipcs command is to be unput with only ipcs without factor. 7.3.3.1.2. Output ipcs command is displayed in window as follows:
STAREX-IS BSM Manual Page:776(877)Issue:1.0SMD-011-PMA210 ### IPC Status Information ### TX Errors RX Errors txerr_msgq: 000000 rxerr_msgq: 000000 txerr_leng: 000000 rxerr_leng: 000000 txerr_sock: 000028 rxerr_sock: 000000 message Rx message Tx rxerr_udst: 000032 related accumulated related accumulated--------------------------------------------------- error number error number QKEY QID CBYTES QNUM FLUSH RLOST --------------------------------------------------- 0200 00000800 00000000 000000 000000 000000 0201 00000001 00000120 000002 000000 000000 0202 00000002 00000080 000001 000000 000000 … … … … … … 0209 00000009 00000322 000002 000001 000000 020A 00000010 00000000 000000 000000 000000 020B 00000011 00000000 000000 000000 000000 020C 00000012 00000000 000000 000000 000000 020D 00000013 00000000 000000 000000 000000 020E 00000014 00000000 000000 000000 000000 lost message number queue-key queue-id in-queue in-queue queue flush count message message number byte number 7.3.3.2. isig Command 7.3.3.2.1. Input isig command is to be entered only with isig without factor. 7.3.3.2.2. Output Te result of isig command output is as follows:
STAREX-IS BSM Manual Page:777(877)Issue:1.0SMD-011-PMA210 queue key ### Initial Signal ID Information ### [#2561] SID(0x0A01) / QKey(0x020D) / PID(00779) signal ID [#2562] SID(0x0A02) / QKey(0x020D) / PID(00779) application to receive corresponding signal [#2563] SID(0x0A03) / QKey(0x020D) / PID(00779) [#2573] SID(0x0A0D) / QKey(0x020D) / PID(00779) process id [#2656] SID(0x0A60) / QKey(0x0205) / PID(00787) … … … … [#2690] SID(0x0A82) / QKey(0x0207) / PID(00792) [#2691] SID(0x0A83) / QKey(0x0208) / PID(00798) [#2705] SID(0x0A91) / QKey(0x0209) / PID(00829) [#2707] SID(0x0A93) / QKey(0x0209) / PID(00829) 7.3.3.3. status command 7.3.3.3.1. Input Only status is input without factor. 7.3.3.3.2. Output Output type of status command is as follows: Debug flag log flag eprt flag For developer only status(see 5.2) status(see 5.3) ### DCI Console Status ### PRINTF flag [OFF] LOG flag [ON ] EPRT flag [ON ] ASF flag [ON ] ASF SIGID [ALL ] ASF DST.IP [ALL ] asf flag ARF flag [ON ] ARF SIGID [0A00] ARF SRC.IP [11400101] state(see 2.1) arf flag state(see 2.2) 7.3.3.4. rsock command
STAREX-IS BSM Manual Page:778(877)Issue:1.0SMD-011-PMA210 7.3.3.4.1. input Withput factor, rsock should be input. 7.3.3.4.2. Output The output of rsock command is reported in the following format. ### RECEIVE SOCKET TABLE ### [0] FD[4] IP[11400201] READY[0] CREAT[02-26 12:06:11] [1] FD[6] IP[12400501] READY[1] CREAT[02-26 11:03:23] [2] FD[7] IP[11400101] READY[0] CREAT[02-26 11:22:13] … socket target receipt message connection creation time descriptor IP address waiting status 7.3.3.5. ssock command 7.3.3.5.1. Input Only ssock should be input withput factor. 7.3.3.5.2. Output The output of ssock command is reported in the following format: ### SEND SOCKET TABLE ### [0] FD[3] IP[11400201] CREAT[02-26 12:06:11] FINISH[02-26 12:06:28] [1] FD[4] IP[11400101] CREAT[02-26 12:06:15] FINISH[02-26 12:06:32] … socket target connection creation time connection end descriptor IP address time expected
STAREX-IS BSM Manual Page:779(877)Issue:1.0SMD-011-PMA210 7.3.4. Other Supplementary Function ls command can display available command list in window. log command is used to switch on and off the function to store event generated from DCI console and DCI in log file, and eprt command is used to switch on and off the function to display error generated from DCI in window. History related command is used for convenience in the case of repeatedly executing the previous command in DCI console. display command can be used to change $DISPLAY environmental variable necessary for ipclog window display. 7.3.4.1. ls command ls command is used to display the list of commands acailable in current DCI console in window. 7.3.4.2. log command log command can adjust save of DCI related log file. The usage of log command can be done in the format of log [on/off], and the status of current log flag can be checked by status command. The location for log file save is $EXECPATH/DCI_LOGS/dci.logdd, and (dd being current date), log file is stored for one month from the record date. 7.3.4.3. eprt command eprt command can adjust the status of whether to display various error messages generated from DCI in window, and default is on state. The usage of eprt command can be done in the format of eprt [on/off], and the status of current eprt flag can be checked by status command. 7.3.4.4. history, !!, !n command By history command, you can check the list of commands that have been used for 10 times, and by !!, !n command, you can repeat the previous command. History related commands can be used as follows:
STAREX-IS BSM Manual Page:780(877)Issue:1.0SMD-011-PMA210 DCI_CON>> history ### Command History ### 9 : 8 : ls 7 : asf a01 6 : arf a03 11400101 5 : arf off 4 : rsock 3 : ipclog 2 : isig 1 : status 0 : ls DCI_CON>> !2 isig ### Initial Signal ID Information ### [#2690] SID(0x0A82) / QKey(0x0207) / PID(00792) [#2691] SID(0x0A83) / QKey(0x0208) / PID(00798) … 7.3.4.5. display command By display command, you can change the address to display ipclog window. When using DCI console for remote host other than workstation that activates BSM, upon use of ipclog, you should use display command in advance to change the value of $DISPLAY environmental variable. Set IP address of the host for display in the form of display 150.150.62.71.
STAREX-IS BSM Manual Page:781(877)Issue:1.0SMD-011-PMA210 7.4. Statistic Message 7.4.1. Traffic Related 7.4.1.1. Traffic Statistics by Service Option 7.4.1.1.1. SERVICE OPTION Table 7.4-1 IS-2000 Service Option Type VOICE Basic Variable Rate (8K Voice) VARI_VOICE Enhanced Variable Rate (8K Voice) ASYNC Asyncronous Data (9.6 Kbps) : To provide Dial Up MODEM function, it provides AT command, and subscriber can use this for end-to-end communication or access public data network. G3FAX Group 3 Facsimile (9.6 Kbps) : By adding the function to process extension AT command for FAX to Dial Up MODEM, subscriber with FAX can use FAX accommodated in PSTN. SMS Short Message (Rate Set 1) : Service to exchange SMS between external device and PCS network or MS and Network PPP_PKT PPP protocol Stack is mounted on Packet Data (Internet/ISO Protocol Stack), MS and IWF. Point-to-Point Packet Data Service 13K_ASYNC Asyncronous Data (14.4 Kbps) 13K_G3FAX Group 3 Facsimile (14.4 Kbps) 13K_SMS Short Message (Rate Set 2) 13K_VOICE 13K VOICE (IS-96) PKT_TYPE1_22 High Speed Packet Data Service - Internet or IOS Protocol Stack (RS1 forward, RS1 reverse) : IS-707A PKT_TYPE2_25 High Speed Packet Data Service - Internet or IOS Protocol Stack (RS2 forward, RS2 reverse) : IS-707A 144K Packet Data 144kbps Packet Data, Internet or IOS Protocol Stack : IS-707A
STAREX-IS BSM Manual Page:782(877)Issue:1.0SMD-011-PMA210 7.4.1.1.2. ORIGINATION Table 7.4-2 Origination Call Traffic Statistics Statistic ITEM Cause ATTEMPT Origination attempt count SEIZURE Count of all procedure completion related to cal between MS-CE-SVC CALL_DROP Call DROP count TRAFFIC Origination call erlang AVG_HOLD Average call holding time of origination call NOR_REL Release by user, release by MS power down BAD_FR Release owing to electronic wave environment defect before normal call MS_SLP_TO Release owing to control message switch failure between MS and SLP ACQFAIL Count of CE having failed in obtaining MS preamble TCE_SLP_TO TimeSync message switch failure between CE and SLP SO_REJ Call release owing to service processing impossible of MS VOC_ERR After vocoder assignment by CCP, call release owing to error in the course of vocoder initialization TC_FAIL TCE assignment impossible owing to no TCE to assign or channel for handoff only residing, and no code channel for TC assignment TC_UNAV Abnormal TC assigned TC_PWR_FAIL No spare TC TOTAL POWER VOC_UNA No vocoder CCP_SMP_TO No response after CCP sends call setup message to SMP ( 10 seconds ) CCP_VMP_TO Timeout between CCP-VMP CCP_NCP_TO Timeout between CCP-VMP NETWORK_FAIL TRM_REL Normal release from MSC BSP_REJ TC assignment rejected, BTS rejection to calls connected owing to abnormal call SCCP_FAIL SCCP connection setup failure between BSC-MSC or call setup failure owing to abnormal SCCP Connection release CCP_PCP_TO Timeout between CCP-PCP(PCF) PCP_FAIL Call setup failure owint to internal PCF error SEL_ERR Call setup failure owint to internal selector error SEL_UNA No selector available
STAREX-IS BSM Manual Page:783(877)Issue:1.0SMD-011-PMA210 7.4.1.1.3. TERMINATION Table 7.4-3 Termination Call Traffic Statistics Statistic ITEM Cause ATTEMPT Paging response count SEIZURE Count of all procedure completion related to cal between MS-CE-SVC ALERT After TC_Link completion, the count that MSC ordered Ring on to termination MS ANSWER Call access count with termination response CALL_DROP Call DROP count ( Bad frame included ) TRAFFIC Termination call erlang AVG_HOLD Average call holding time TRM_REL Release by user, release by MS power down BAD_FR Release owing to electronic wave environment defect before normal call MS_SLP_TO Release owing to control message switch failure between MS and SLP ACQFAIL Count of CE having failed in obtaining MS preamble TCE_SLP_TO TimeSync message switch failure between CE and SLP SO_REJ Call release owing to service processing impossible of MS VOC_ERR After vocoder assignment by CCP, call release owing to error in the course of vocoder initialization TC_FAIL TCE assignment impossible owing to no TCE to assign or channel for handoff only residing, and no code channel for TC assignment TC_UNAV Abnormal TC assigned TC_PWR_FAIL No spare TC TOTAL POWER VOC_UNA No vocoder CCP_SMP_TO No response after CCP sends call setup message to SMP ( 10 seconds ) CCP_VMP_TO Timeout between CCP-VMP CCP_NCP_TO Timeout between CCP-VMP NETWORK_FAIL ORG_REL Normal release from MSC BSP_REJ TC assignment rejected, BTS rejection to calls connected owing to abnormal call SCCP_FAIL SCCP connection setup failure between BSC-MSC or call setup failure owing to abnormal SCCP Connection release CCP_PCP_TO Timeout between CCP-PCP(PCF) PCP_FAIL Call setup failure owint to internal PCF error SEL_ERR Call setup failure owint to internal selector error
STAREX-IS BSM Manual Page:784(877)Issue:1.0SMD-011-PMA210 SEL_UNA No selector available 7.4.2. Handoff Statistic Function 7.4.2.1. Handoff Statistic Type Table 7.4-4 Handoff Statistic Type ITEM Description Softer Handoff Softer ADD handoff Soft Handoff Intra BSC Soft Handoff Soft ADD handoff Inter BSC Soft Handoff Soft ADD handoff between other BSCs Hard Handoff Intra Cell Hard Handoff Hard handoff by frequency change Intra BSC FR Hard Handoff Intra-BSC Hard handoff by frequency change Intra BSC FO Hard Handoff Hard handoff by frame offset change Inter BSC FR Hard Handoff Hard handoff by frequency change Inter BSC FO Hard Handoff Hard handoff by frame offset change between other BSCs Inter-RC Hard Handoff 7.4.2.2. Hand off Statistic Collection ITEM Table 7.4-5 Handoff Statistic Collection ITEM Item Cause ATTEMPT Handoff count SUCCESS Success count NETWORK_FAIL ATM Connection Fail TC_UNAV NO_CDMA_AVAIL, NO_CODE_CH, NO_FRAME_OFFSET, NO_TC_AVAIL received from BSP TC_FAIL TX_ON_TIMEOUT received from BSP BSP_CAPA_FAIL TC_PWR_ALLOC_ERR, EXCESS_CAPACITY_UNAVAIL BSP_REJ Value other than TC_UNAV, TC_FAIL, BSP_CAPA_FAIL A3_CONN_FAIL A3 Connection Fail FO_UNAV For FO Hard Handoff, unavailable to assign changed frame offset to SLP CAI_TO CAI Message Timeout ( i.e. HDM ACK timeout, HCM MSG Timeout ) CCP_NCP_TO Timeout between CCP and NCP CCP_BSP_TO Timeout between CCP and BSP CCP_SMP_TO Timeout between CCP and SMP
STAREX-IS BSM Manual Page:785(877)Issue:1.0SMD-011-PMA210 INTER_CCP_TO Timeout between Source CCP and Target CCP OTHER_FAIL Fail other than #2 ~ 14 7.4.3. Call Related Statistic Function 7.4.3.1. Channel Element Statistics Table 7.4-6 Channel Element Statistics ITEM DESCRIPTION tc_att Traffic Channel Assignment Count tc_suc Traffic Channel Assignment Success Count tc_hold Traffic Channel Assignment Success and total seizure time of used tc resource ho_att Handoff Channel assignment count ho_suc Handoff Channel assignment success count ho_hold Handoff Channel assignment success and total seizure time of used tc resource 7.4.3.2. Vocoder Statistics Table 7.4-7 Vocoder Statistics ITEM DESCRIPTION NUM_SEIZURES Total seizure call count TOTAL_DURATION Total seizure time (second)
STAREX-IS BSM Manual Page:786(877)Issue:1.0SMD-011-PMA210 7.4.3.3. Network Link Statistics 7.4.3.3.1. (ALPA,LICA,ASCA,ASIA) Table 7.4-8 ATM Network Statistics (LINK/PORT statistics) ITEM DESCRIPTION Rx_cnt Cell Counter received from Link Tx_cnt Cell Counter sent from Link 7.4.3.3.2. BSC-MSC Trunk Statistics Table 7.4-9 Trunk Statistic Item between MSC-BSC ITEM DESCRIPTION NORMAL TIME Normal T1/E1 Trunk time (sec) REMOTE ABNORMAL TIME Abnormal MSC time (sec) LOCAL ABNORMAL TIME Abnormal T1/E1 Trunk itself duw to Frame Error, Sync. Error (sec) SLIP ABNORMAL TIME SLIP time due to environmental cause of link connected to MSC (sec) BIT ERROR ABNORMAL TIME AIS(Alarm Indication Signal) – E1 : When alarm with All 1’s Condition (all receipt data are 1) is detected for more than 100ms, T1 : when alaem with All ‘s Condition is detected for more than 60ms RED Alarm – E1 : Out of Frame(Incorrect Frameing Format) for more than 100ms, T1 : Out of Frame(Incorrect Framing Format) for more than 40ms OTHER ABNORMAL TIME Abnormal time other than the above item (sec) 7.4.3.4. Radio Channel Quality Statistics Table 7.4-10 Radio Channel Quality Statistic Item ITEM DESCRIPTION rx_fr_cnt Number of frame from MS by CE tx_fr_cnt Number of frame that CE sent to MS fr_err_cnt Packet error count from MS fr_miss_cnt Error count that CE count not send, to MS, packet
STAREX-IS BSM Manual Page:787(877)Issue:1.0SMD-011-PMA210 7.4.3.5. Processor Statistics Table 7.4-11 Processor Statistic Item ITEM DESCRIPTION CPU_IDLE CPU Load : xx.xx * 100 SEND_IPC_NUM Total IPC Send Number RECEIVE_IPC_NUM Total IPC Receive Number SEND_AVERAGE_LENGTH Average Send IPC Length RECEIVE_AVERGAE_LENGTH Average Receive IPC Length 7.4.3.6. Selector Statistics Table 7.4-12 Selector Statistic Item ITEM DESCRIPTION NUM_SEIZURES Number of total seizure calls TOTAL_DURATION Total seizure time (seconds) NUM_BIT_ERRS Reverse FCH CRC error frame number NUM_ERASURES Reverse FCH Bad frame number FORWARD_SCH_DURATION Forward SCH seizure time (second) REVERSE_SCH_DURATION Reverse SCH seizure time (sec) AVERAGE_FORWARD_SCH_RATE Seized forward SCH’s average rate (OOXX º OO.XX) AVERAGE_REVERSE_SCH_RATE Seized reverse SCH’s average rate (OOXX º OO.XX) 7.4.3.7. BTS Performance Statistics (Call Delay Statistics) Table 7.4-13 BTS Performance Statistics (Call Delay Statistics) Item ITEM DESCRIPTION Origination Call Statistics ms_500_under Under 500ms, origination call setup count ms_500 Under 600ms, origination call setup count ms_600 Under 700ms, origination call setup count ms_700 Under 800ms, origination call setup count ms_800 Under 900ms, origination call setup count ms_900 Under 1000ms, origination call setup count
STAREX-IS BSM Manual Page:788(877)Issue:1.0SMD-011-PMA210 ms_1000 Under 1100ms, origination call setup count ms_1100_over Over 1100ms, origination call setup count s_3_under Under 3SEC, termination call setup count s_3 Under 4SEC, termination call setup count s_40 Under 4.5 SEC, termiknation call setup count s_45 Under 5SEC, termination call setup s_5 Under 6SEC, termination call setup count s_6 Under 7SEC, termination call setup count s_7 Under 8SEC, termination call setup count s_8_over Over 8SEC, termination call setup count 7.4.3.8. Paging Statristics Table 7.4-14 Paging Statistics Item ITEM DESCRIPTION page_cnt(1,2) 1st, 2nd paging attempt count rsps_cnt(1,2) Response count pc_unav(1,2) Failure count owing to pc unavailable tc_unav(1,2) Failure count owing to TC unavailable page_tmo(1,2) Paging Time-out count sys_fail(1,2) Failure count by other reason 7.4.3.9. CAI Signaling Statistics Table 7.4-15 CAI Signaling Statistics Item ITEM DESCRIPTION Access Channel related msg_cnt Message count received to access channel orig_cnt MS Call Origination message count reg_cnt Location registration count order_cnt Count that MS transmitted order message to BTS via access channel page_rsps MS answer count data_burst Count that BTS received Data Burst message Paging Channel reloated msg_cnt Message count transmitted to paging channel paging Subscriber pure paging
STAREX-IS BSM Manual Page:789(877)Issue:1.0SMD-011-PMA210 order Count of having sent various messages to MS through paging channel ch_asign Count of having sent information of forward call channel to MS data_burst Count of having sent data BURST message ser_redir Count of having sent Service Redirection message 7.4.3.10. NO.7Statistics Table 7.4-16 NO7 Statistic Item ITEM Description MTP related SL_NO Signaling Link Number LOSS MSG Missed MSU count ERR_MSG number of Signal Unit in error NACK_NO number of negative ack. Received RTX_OCT Number of MSU octets retransmitted TX_MSG Tx MSU number RX_MSG Rx MSU number TX_OCT Tx MSU octet RX_OCT Rx MSU octet SCCP related TX_UDTS Tx UDT number RX_UDTS Rx UDT number TX_DTL Tx DT1 number RX_DTL Rx DT1 number SCCP_CONN connection count SCCP_REL connection release count CONN_FAIL connection refused count 7.4.3.11. RTD Statistics ITEM Description Origination/termination identical 200 0 ~ 200 M 400 200 ~ 400 M 600 500 ~ 600 M 800 600 ~ 800 M 1.0 K 800 M ~ 1.0 Km
STAREX-IS BSM Manual Page:790(877)Issue:1.0SMD-011-PMA210 1.2 K 1.0 ~ 1.2 Km 1.4 K 1.2 ~ 1.4 Km 1.6 K 1.4 ~ 1.6 Km 1.8 K 1.6 ~ 1.8 Km 2.0 K 1.8 ~ 2.0 Km 2.5 K 2.0 ~ 2.5 Km 3.0 K 2.5 ~ 3.0 Km 3.5 K 3.0 ~ 3.5 Km 4.0 K 3.5 ~ 4.0 Km 5.0 K 4.0 ~ 5.0 Km 6.0 K 5.0 ~ 6.0 Km 7.0 K 6.0 ~ 7.0 Km 8.0 K 7.0 ~ 8.0 Km 9.0 K 8.0 ~ 9.0 Km 10.0K 9.0 ~ 10.0 Km OVER_10K 10.0 Km or above 7.4.3.12. RF MIN/MAX Statistics Table 7.4-17 RF MIN-MAX Statistic Item ITEM Description TX_MIN Minimum Tx RF value(unit:W) TX_MAX Maximum Tx RF value(unit:W) 7.4.4. Packet 7.4.4.1. Packet Data Table 7.4-18 Packet Data Statistic Item ITEM DESCRIPTION PKT_SUCCESS_CNT Active Packet Call Success Count RN_SDB_ATTEMPT SDB attempt count RN_SDB_SUCCESS SDB success count PDSN_SDB_ATTEMPT SDB attempt count PDSN_SDB_SUCCESS SDB success count from CCP TOTAL_SDB_FORWARD_KByte Total bytes of SDB from PDSN to MS in dormant state
STAREX-IS BSM Manual Page:791(877)Issue:1.0SMD-011-PMA210 TOTAL_SDB_FORWARD_Byte TOTAL_SDB_REVERSE_KByte TOTAL_SDB_REVERSE_Byte Total bytes of SDB from MS to PDSN in dormant state TOTAL_ACT_FORWARD_KByte TOTAL_ACT_FORWARD_Byte Total bytes of packet from PDSN to SLP in active state TOTAL_ACT_REVERSE_KByte TOTAL_ACT_REVERSE_Byte Total bytes of packet from SLP to PDSN in active state 7.4.4.2. Packet Control Table 7.4-19 Packet Control Statistic Item ITEM DESCRIPTION PKT_ATTEMPT Packet call origination attempt count PKT_SUCCESS Packet call success count (PIP, ATM resource assignment, R-P setup success) DORMANT_ATTEMPT dormant state transition attempt count by system / MS request DORMANT_SUCCESS Dormant state transition success count PKT_PAGING_ATTEMPT Paging request count from PDSN to MS PKT_PAGING_FAIL_CNT Packet Paging failure count ACTIVE_ATTEMPT Active state transition attempt count ACTIVE_SUCCESS Active state transition success count A10_CONNECTION_REJECT_CNT Call setup failure count due to A10 connection setup failure DCR_FAIL_CNT Call setup failure count due to initialization error of PIP DCR instance PDSN_RELEASE_CNT Call release attempt count by PDSN RN_RELEASE_CNT Call release attempt count by BSC/BTS/MS request TOTAL_PKT_TIME Total time from call setup attempt point to call release point (10msec) (average time = Total Duration/ pkt_succ: all successful call’s Active + Dormant Duration ) TOTAL_ACT_TIME Total time in Active state (10msec) (average time = Total Active Duration/pkt_succ: Total Active Duration only calculates duration in Active state) TOTAL_DOR_TIME Total time in Dormant state (10msec) (average time = Total Dormant Duration/Pkt_succ) 7.4.4.3. Packet Handoff Table 7.4-20 Packet Handoff Statistic Item
STAREX-IS BSM Manual Page:792(877)Issue:1.0SMD-011-PMA210 ITEM DESCRIPTION Dormant_HO_Cnt Dormant HO count Serving_PCF_HO_Cnt Serving PCF HO count Target_PCF_HO_Cnt Target PCF HO count HO_FAIL_CNT HO failure count
STAREX-IS BSM Manual Page:793(877)Issue:1.0SMD-011-PMA210 7.5. PLD Data Structure 7.5.1. BSM layer 7.5.1.1. St_Bsm_Cfg.dg Table 7.5-1 St_Bsm_Cfg Data Type N a m e default Remarks byte ccp_id 0 ~ 12 byte bts_eqp[MAX_BTS] Current BTS equip ( 0: Not_equip 1 : Equip ) byte smp_eqp[MAX_SMP] Current SMP equip ( 0: Not_equip 1 : Equip ) byte vmp_eqp[MAX_VMP] byte msc_id 0 ~ 255 MSC Identification byte pcf_equ[MAX_PCF] 0 ~ 255 CAN PCF equip (0:Not_equip 1 : Equip) MAX_PCF : 3 ccp_id=0 is only valid. byte reserved_byte[35] 0 7.5.2. CNP ONLY 7.5.2.1. St_re_can_node.dg Table 7.5-2 t_re_can_node Type N a m e default Remarks byte card_id key full equip (MAX_ATM_CARD:5) byte link_id key full equip (MAX_ATM_LINK:32) byte equip Depending on the below Node Config, Equip Node status 1:Equip, 0:Not Equip byte link_type 1 ATM Link Type STM-1,STM-4,Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM
STAREX-IS BSM Manual Page:794(877)Issue:1.0SMD-011-PMA210 12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 ATM Link Acktivity Init/Active/Block (LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3)) byte connect_type Node Connection ID: End-User’s own ID (see Appendix Connection ID) byte fabric_no Switch Fabric No. (0: ASCA APC0,1: ASIA0 APC0,2: ASIA0 APC1, 3: ASIA1 APC0, 4: ASIA1 APC1, 5: ASIA2 APC0, 6: ASIA2 APC1, 7: ASIA3 APC0, 8: ASIA3 APC1) byte reserved[7] 7.5.2.2. St_re_can_addr.dg Table 7.5-3 St_re_can_addr Type N a m e Default Remarks byte shelf_id key full equip (MAX_CAN_SHELF: 4) byte slot_id key full equip (MAX_CAN_SLOT: 22) byte equip ‘0’ byte bd_type PBA’s own number (not yet set) byte no_sub Sub Processor Number in case of Sub processor had IP byte reserved word32 addr[MAX_SUB] MAX_SUB: 8 7.5.2.3. St_re_can_pvc.dg Table 7.5-4 St_re_can_pvc Type N a m e Default Remarks byte dummy key word16 no_entry # of Valid Entries, number of defined PVC information (~4096) word16 reserved
STAREX-IS BSM Manual Page:795(877)Issue:1.0SMD-011-PMA210 byte equipage[4096] byte node_a[4096] Peer1 connection ID byte sub_a[4096] Peer1 Logical Info byte node_b[4096] Peer2 Connection ID byte sub_b[4096] Peer2 Logical info byte no_vc[4096] Number of VC to be used between Allocated VC Number Peers byte link_type[4096] Link Usage AAL1/2/5, Test (LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2)) word16 link_bw[4096] 0x100 VC Link Bandwidth (Cell Bandwidth(~0x40) to be assigned to Link) word32 vpci_a[4096] Peer1 VPI/VCI(Ingress VPCI) word32 vpci_b[4096] Peer2 VPI/VCI(Egress VPCI) 7.5.2.4. St_re_can_svc.dg Table 7.5-5 St_re_can_svc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~4096) byte no_hdr Header Address Length Upper ATM Address length byte reserved byte addr_hdr[20] Higher ATM address byte equipage[512] byte a_mask1[512][10] First address mask to be connected byte addr1[512][10] First address to be connected byte a_mask2[512][10] Second address mask to be connected byte addr2[512][10] Second address to be connected byte no_vc[512] Number of VC to be used between peers word32 atm_id1[512] vc id of the first node (VPI:VCI) word32 atm_id2[512] vc id of the second node (VPI:VCI) byte link_type[512] Link Usage(AAL1/2/5,Test)
STAREX-IS BSM Manual Page:796(877)Issue:1.0SMD-011-PMA210 ( LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2)) word16 link_bw[512] VC Link BandWidth (Cell Bandwidth(~0x40) to be assigned to Link) 7.5.2.5. St_re_can_net_cfg.dg Table 7.5-6 St_re_can_net_cfg Type N a m e default Remarks byte can_net_shelf_id key full equip (MAX_CAN_NET_SHELF: 2) byte can_net_slot_id key full equip (MAX_CAN_SLOT: 22) byte equip ‘0’ byte bd_type Network Board Type byte no_sub # of Sub Device byte no_link # of Physical Link byte hw_ctrl HW Reset : 0(Init), 1, 2, 3 added byte link_type[MAX_LINK] 1 Physical Link Type : STM1, E1,...(MAX_LINK: 64) LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5) byte sub_type[MAX_SUB] Sub Device Type (MAX_SUB : 16) SBTYPE_NONE(0), SBTYPE_APC(1), SBTYPE_APPD(2) byte sub_id[MAX_SUB] Sub Device ID (MAX_SUB : 16) 7.5.2.6. St_re_can_net_data.dg Table 7.5-7 St_re_can_net_data Type N a m e default Remarks byte dummy key byte cn_id msc_no Core Network ID
STAREX-IS BSM Manual Page:797(877)Issue:1.0SMD-011-PMA210 byte no_addr_hdr ATM Address Header Len byte reserved[2] byte rnc_equip[MAX_RNC] rnc_eqp RNC Equipage byte atm_addr_hdr[20] ATM Address Header byte rnc_conn_type[MAX_RNC] RNC Connectino ID byte atsa_conn_type[12] ATSA Connection ID word32 rnc_addr[MAX_RNC] RNC NCP Network Address word32 camu_addr[16] CAMU Device Network Addr. (0 : ASCA_A, 1 : ASCA_B, 2 : ASIA0_A, 3 : ASIA0_B, 4 : ASIA1_A, 5 : ASIA1_B 6 : ASIA2_A, 7 : ASIA2_B, 8 : ASIA3_A, 9 : ASIA3_B, 10 : AOTA0, 11 : AOTA1, 12 : AOTA2, 13 : AOTA3, 14 : ATSA0, 15 : ATSA1) byte reserved[8] 7.5.2.7. St_re_can_iur_con.dg Table 7.5-8 St_re_can_iur_con Type N a m e default Remarks byte rnc_id key full equip word32 start_aal2_vc_id[MAX_RNC] See *1 AAL2 Start VC Id word16 no_aal2_vc 32 Number of AAL2 VCs word16 reserved 7.5.2.8. St_re_can_rnc5_con.dg Table 7.5-9 St_re_can_rnc5_con Data Type N a m e default Remarks byte dummy key word32 start_aal5_vc_id[2] [10/32] = 0xA0020 [12/32] = 0xC0020 AAL5 Start VC Id word16 no_aal5_vc 8192 Number of AAL5 VCs word16 reserved
STAREX-IS BSM Manual Page:798(877)Issue:1.0SMD-011-PMA210 7.5.3. PNP ONLY 7.5.3.1. St_re_cand_node.dg Table 7.5-10 St_re_cand_node Data Type N a m e default Remarks byte card_id key full equip (MAX_ATM_CARD:5) byte link_id key full equip (MAX_ATM_LINK:32) byte equip LINK_NOT_EQUIP(0), LINK_EQUIP(1) byte link_type 1 ATM Link Type STM-1,STM-4,Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1), LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 ATM Link Acktivity Init/Active/Block (LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3)) byte connect_type End-User’s own ID connected to Link (see Appendix Connection ID) byte fabric_no Switch Fabric No.( Index(0~8) of all APCs) (0:ASCA APC0, 1:ASIA0 APC0, 2:ASIA0 APC1, 3:ASIA1 APC0, 4:ASIA1 APC1, 5:ASIA2 APC0, 6: ASIA2 APC1, 7:ASIA3 APC0, 8 : ASIA3 APC1) byte reserved[7] 7.5.3.2. St_re_pcf_node.dg Table 7.5-11 St_re_pcf_node Type N a m e Default Remarks byte pcf_id key full equip (MAX_PCF_BLK:6)
STAREX-IS BSM Manual Page:799(877)Issue:1.0SMD-011-PMA210 byte link_id key full equip (MAX_SUB_LINK:32) byte equip Number of pcf Equip as below LINK_NOT_EQUIP(0), LINK_EQUIP(1) byte link_type 1 ATM Link Type STM-1,STM-4,Cell Bus LINK_TYPE_NONE(0), LINK_TYPE_STM1(1), LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5) byte link_status 1 ATM Link Acktivity Init/Active/Block LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3) byte connect_type Default 1 below. Node Connection ID: End-User’s own ID connected to Link byte fabric_no 0 Switch Fabric No. Index(0~8) of all APCs 0 : BCRA APC0 byte reserved[7] 7.5.3.3. St_re_cand_addr.dg Table 7.5-12 St_re_cand_addr Type N a m e Default Remarks byte shelf_id key full equip (MAX_CAN_SHELF: 4) byte slot_id key full equip (MAX_CAN_SLOT: 22) byte equip ‘0’ byte bd_type Processor/Device Board Type PBA’s own number (not yet set) byte no_sub Sub Processor Number In case of Sub processor had IP Nu,ber of processors mounted byte reserved word32 addr[MAX_SUB] MAX_SUB: 8
STAREX-IS BSM Manual Page:800(877)Issue:1.0SMD-011-PMA210 7.5.3.4. St_re_cand_pvc.dg Table 7.5-13 St_re_cand_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, number of defined PVC information (~4096) word16 reserved byte equipage[4096] cand_pvc.inf byte node_a[4096] Peer1 connection ID byte sub_a[4096] Peer1 Logical Info byte node_b[4096] Peer2 Connection ID byte sub_b[4096] Peer2 Logical info byte no_vc[4096] Number of VX to be used between Allocated VC Number Peers byte link_type[4096] Link Usage AAL1/2/5, Test (LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2)) word16 link_bw[4096] 0x100 VC Link Bandwidth (Cell Bandwidth(~0x40) to be assigned to Link) word32 vpci_a[4096] Peer1 VPI/VCI(Ingress VPCI) word32 vpci_b[4096] Peer2 VPI/VCI(Egress VPCI) 7.5.3.5. St_re_pcf_pvc.dg Table 7.5-14 St_re_pcf_pvc Type N a m e Default Remarks byte dummy key word16 no_entry # of Valid Entries, number of defined PVC information (~4096) word16 reserved byte equipage[512] pcf_pvc.inf byte node_a[512] Peer1 connection ID byte sub_a[512] Peer1 Logical Info
STAREX-IS BSM Manual Page:801(877)Issue:1.0SMD-011-PMA210 byte node_b[512] Peer2 Connection ID byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VCs to be used between Allocated VC Number Peers byte link_type[512] Link Usage AAL1/2/5, Test LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[512] 0x100 Cell Bandwidth(~0x40) to be assigned to VC Link Bandwidth-Link word32 vpci_a[512] Peer1 VPI/VCI(Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI(Egress VPCI) 7.5.3.6. St_re_cand_svc.dg Table 7.5-15 St_re_cand_svc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, number of defined PVC info (~4096) byte no_hdr Header Address Length Upper ATM Address length byte reserved byte addr_hdr[20] Higher ATM address byte equipage[512] byte a_mask1[512][10] First address mask to be connected byte addr1[512][10] First address to be connected byte a_mask2[512][10] Second address mask to be connected byte addr2[512][10] Second address to be connected byte no_vc[512] Number of VCs to be used between peers word32 atm_id1[512] vc id of first node (VPI:VCI) word32 atm_id2[512] vc id of second node (VPI:VCI) byte link_type[512] Link Usage(AAL1/2/5,Test) ( LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2)) word16 link_bw[512] VC Link BandWidth (Cell Bandwidth(~0x40) to be assigned to
STAREX-IS BSM Manual Page:802(877)Issue:1.0SMD-011-PMA210 Link) 7.5.3.7. St_re_cand_net_cfg.dg Table 7.5-16 St_re_cand_net_cfg Type N a m e default Remarks byte can_net_shelf_id key full equip (MAX_CAN_NET_SHELF: 2) byte can_net_slot_id key full equip (MAX_CAN_SLOT: 22) byte equip ‘0’ byte bd_type Network Board Type byte no_sub # of Sub Device byte no_link # of Physical Link byte hw_ctrl HW Reset : 0(Init), 1, 2, 3 added byte link_type[MAX_LINK] 1 Physical Link Type : STM1, E1,...(MAX_LINK: 64) LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5) byte sub_type[MAX_SUB] Sub Device Type (MAX_SUB : 16) SBTYPE_NONE(0), SBTYPE_APC(1), SBTYPE_APPD(2) byte sub_id[MAX_SUB] Sub Device ID (MAX_SUB : 16) 7.5.3.8. St_re_cand_net_data.dg Table 7.5-17 St_re_cand_net_data Type N a m e default Remarks byte dummy key byte msc_id msc_no:0 MSC ID byte reserved byte pcf_equip[6] Number of pcf equip PCF Equipage byte rnc_equip[MAX_RNC] Number of RNC equipage Header
STAREX-IS BSM Manual Page:803(877)Issue:1.0SMD-011-PMA210 rnc equip byte pcf_conn_type[6][2] PCF Connectino ID byte rnc_conn_type[MAX_RNC] RNC Connection ID word32 pcp_addr[6] word32 ncp_addr[MAX_RNC] RNC NCP Network Address word32 camdu_addr[16] CAMD Device Network Addr. (0 : ASCA_A, 1 : ASCA_B, 2 : ASIA0_A, 3 : ASIA0_B, 4 : ASIA1_A, 5 : ASIA1_B 6 : ASIA2_A, 7 : ASIA2_B, 8 : ASIA3_A, 9 : ASIA3_B, 10 : AOTA0, 11 : AOTA1, 12 : AOTA2, 13 : AOTA3, 14 : ATSA0, 15 : ATSA1) 7.5.3.9. St_re_cand_data5_con.dg Table 7.5-18 St_re_cand_data5_con Type N a m e Default Remarks byte dummy key word32 start_aal5_vc_id[MAX_RNC] [10/32] = 0xA0020 AAL5 Start VC Id. word16 no_aal5_vc 8192 # of AAL5 VCs word16 reserved 7.5.3.10. St_re_cand_pif5_con.dg Table 7.5-19 St_re_cand_pif5_con Type N a m e default Remakrs byte Dummy key word32 start_aal5_vc_id[11][2] AAL5 Start VC Id. (22 VPs) word16 no_aal5_vc 512 # of AAL5 VCs word16 Reserved
STAREX-IS BSM Manual Page:804(877)Issue:1.0SMD-011-PMA210 7.5.4. PCP ONLY 7.5.4.1. St_pdsn_addr_data_type Table 7.5-20 St_pdsn_addr_data_type Type Name default Remarks byte dummy byte no_of_pdsn 1 Number of equipped PDSN. Of MAX_PDSN_NO, the number of correct PDSN should be checked. word32 pdsn_ip[MAX_PDSN_NO] PDSN IP MAX_PDSN_NO = 2 (temporal) IP used by PDSN for Public Networkinterface. Home Agent IP. As several PDSNs can be interfaced, extendibility is considered. If this value is “0”, regard each RPP IP as PDSN IP. byte no_of_pdsn_node[MAX_PDSN_NO] RPP number mounted in PDSN STP configurqation includes 16 RPPs in PDSN. It must include the number of correct RPP in PDSN. word32 pdsn_node_ip[MAX_PDSN_NO][MAX_NODE_NO] RPP IPs MAX_NODE_NO = 20 PDSN RPP IP. Insert IP of mounted RPP in order, and insert the rest with 0. byte ssk_value[MAX_PDSN_NO][MAX_NODE_NO][16] 0 ssk value of PDSN_NODE that interfaces with PCF. Should be set per PDSN_NODE. byte ssk_len[MAX_PDSN_NO][MAX_NODE_NO]; 0 ssk_val length ssk_value[] length As value required for data call, upon ssk_vale change, the length should be calculated. byte reserved[32] 0 7.5.4.2. St_PCF_timer_type Table 7.5-21 St_PCF_timer_type
STAREX-IS BSM Manual Page:805(877)Issue:1.0SMD-011-PMA210 Type Name default Remarks byte dummy word16 Trp_lifetime 1800 PCF timer. Range : 0 ~ 65,535 unit : 60sec 0x0000 = Release 0xFFFF = Infinite word16 Tbsreq9 5000 PCF timer. Range : 0 ~ 5000 Unit : 1msec word16 Tdiscon9 5000 PCF timer. Range : 0 ~ 5000 unit : 1msec word16 Twaitho9 10000 PCF timer. Range : 0 ~ 10000 Unit : 1msec word16 Tregreq 5000 PCF timer. Range : 0 ~ 5000 Unit : 1msec word16 regreq_retry_cnt 2 Registration Request message retransfer count that PCF sends to PDSN. Range : 0 ~ 20 Unit : frequency. If no response from PDSN, a maximum of this value should be resent. byte reserved[32] 7.5.4.3. St_PCF_info_data_type Table 7.5-22 St_PCF_info_data_type TYPE Name default Remarks byte dummy byte identification_type 0 Upon A11 Signaling, identification field type is determined. 0 : Time Stamp
STAREX-IS BSM Manual Page:806(877)Issue:1.0SMD-011-PMA210 1 : Nonce word32 pcp_ip[MAX_PCF_SHELF][MAX_PCP_NO] PCP IP, PMP IP MAX_PCF_SHELF = 2 MAX_PCP_NO = 2 PCP/PMP IP executing F/E interface. [0][0] : PCP (Active) [0][1] : PCP (Standby) [1][0] : PMP (Active) [1][1] : PMP (Standby) word32 pip_ip[MAX_PCF_SHELF][MAX_PIP_NO] PIP IPs MAX_PCF_SHELF = 2 MAX_PIP_NO = 11 PIP IP executing F/E interface. word32 net_mask[MAX_PCF_SHELF][MAX_PIP_NO] 0 To be judged. PLD add. word32 default_gw[MAX_PCF_SHELF][MAX_PIP_NO] 0 Default Gateway. To be determined. PLD added. byte aaa_server_type 0 AAA server type word16 sid System ID. word16 nid Network ID. Int32 ltm_off 18 Offset of local time from System time. Thatis, local time offset from UTC. Current local time = SYS_TIME - LP_SEC + ltm_off ltm_off = 18 ( 30 minutes per unit, that is, 9 hour difference) * LP_SEC : Number of Leap seconds that occurred since the start of System Time. boolean day_lt 0 Daylight saving time flag (Summer time) 1 : day lighting saving time 0 : standard time byte gre_seq_flag 0 1 : Used SEQ 0 : Not Used SEQ word16 seq_cntl_timer 0 Upon PCF Sequence Control, timer that waitsspecific seq_num ( buffering time ) unit ( msec )
STAREX-IS BSM Manual Page:807(877)Issue:1.0SMD-011-PMA210 byte pkt_zone_id 0 byte UDR_MSID_TYPE 0 MSID Type in UDR that PDSN sends to AAA Server 1 : IMSI 0 : MIN byte reserved[32] 0 7.5.4.4. St_pifu_HW_Reset_data_type Table 7.5-23 St_pifu_HW_Reset_data_type Type Name default Remarks byte shelf_id 0~1 key byte pcp_isolation[11] 0 0: not isolation 1:isolation byte bcra_isolation[2] 0 0: not isolation 1:isolation byte fera_isolation[2] 0,1 0: not isolation.................................................byte feta_isolation 0 0: not isolation 1:isolation byte reserved[32] 0 7.5.5. CCP ONLY 7.5.5.1. St_fwdpwr_data_type.dg Table 7.5-24 St_fwdpwr_data_type Type N a m e default Remarks byte bts_id full full equip byte fer_id 0 ~ 1 Always Full equip word16 slow_down_time 1600 (msec) Gain down time. Applied during slow down mode. (0 ~ 20000) word16 fast_down_time 1600 (msec) Gain down time. Applied during fast down mode. (0 ~ 20000) byte steps_till_fast 0 Number of slow down before switching to fast down mode. (0 ~ 100) byte slow_down_delta 1 Gain down delta. Applied during slow down
STAREX-IS BSM Manual Page:808(877)Issue:1.0SMD-011-PMA210 mode. (0 ~ 100) byte fast_down_delta 1 Gain down delta. Applied during gast down mode. (0 ~ 100) byte nominal_gain 50 Nominal tx gain of primary/secondary traffic. (0 ~ 127) byte max_tx_gain 80 Max.tx gain of primary/secondary traffic byte min_tx_gain 40 Min.tx gain of primary/secondary traffic. byte fer_threshold 6 % Frame Error Rate threshold determines the gain increase amount.(0 ~ 20) byte big_up_delta 10 Gain increase delta. Applied when the forward frame error rate contained in a PMRM exceeds ‘fer_threshold’.(0 ~ 100) byte small_up_delta 5 Gain increase delta. Applied when the forward frame error rate contained in a PMRM is less than ‘fer_threshold’(0 ~ 100) byte signal_delta_gain 96 Gain scaling factor of signaling traffic. ( 0 ~ 200 ) byte pcsc_delta_gain1 64 Gain scaling factor of PCSC bit.(1-cell) byte pcsc_delta_gain2 96 Gain scaling factor of PCSC bit.(2-cell) byte pcsc_delta_gain3 112 Gain scaling factor of PCSC bit.(3-cell) byte reserved_byte[33] 0 7.5.5.2. St_13_fwdpwr_data_type.dg Table 7.5-25 St_13_fwdpwr_data_type Type N a m e default Remarks byte bts_id full Full equip byte fer_id 0 ~ 1 Always Full equip word16 init_down_time 1000 Initial gain down time.(0 ~ 20000) word16 max_down_time 4000 Maximum gain down time.(0 ~ 20000) word16 min_down_time 200 Minimum gain down time.(0 ~ 20000) word16 time_down_delta 200 Gain down time down delta. Applied in good run state.(0 ~ 20000) word16 time_up_delta 400 Gain down time up delta. Applied in erasure run state.(0 ~ 20000)
STAREX-IS BSM Manual Page:809(877)Issue:1.0SMD-011-PMA210 word16 state_chg_thresh 250 Number of consecutive good frames brings about good run state.(0 ~ 10000) word16 erase_meas_frames 250 Cumulative erasure measuring period.(0 ~ 65535) byte cont_erase_eftv 2 Number of consecutive erasures brings about tx gain increase. If 0, burst erasures have no effect.(0 ~ 127) byte cumul_erase_eftv 4 Number of cumulative erasures brings about tx gain increase. If 0, non-burst erasures have no effect.(0 ~ 127) byte nominal_gain 50 Nominal tx gain of primary/secondary traffic.(0 ~ 127) byte max_tx_gain 100 Max.tx gain of primary/secondary traffic. (0 ~ 127) byte min_tx_gain 40 Min.tx gain of primary/secondary traffic. (0 ~ 127) byte gain_down_delta 1 Gain decrease delta (0 ~ 127) byte big_up_delta 10 Gain increase delta. Applied when a gain-up condition is encountered during ERASURE-STATE. (0 ~ 100) byte small_up_delta 5 Gain increase delta. Applied when a gain-up condition is encountered during GOOD-STATE. (0 ~ 100) byte signal_delta_gain 96 Gain scaling factor of signaling traffic. (0 ~ 200) byte pcsc_delta_gain1 64 Gain scaling factor of PCSC bit.(1-cell) (0 ~ 200) byte pcsc_delta_gain2 96 Gain scaling factor of PCSC bit.(2-cell) (0 ~ 200) byte pcsc_delta_gain3 112 Gain scaling factor of PCSC bit.(3-cell) (0 ~ 200) byte reserved_byte[32] 0 7.5.5.3. St_revpwr_data_type.dg Table 7.5-26 St_revpwr_data_type
STAREX-IS BSM Manual Page:810(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte bts_id full byte fer_id 0 ~ 1 Always Full equip word16 pnom (pwrctl_nominal) 19416 initial Eb/No(dB) word16 pmax (pwrctl_max ) 23408 Maximum Eb/No(dB) word16 pmin (pwrctl_min)) 8288 Minimum Eb/No(dB) word16 pupf (pwrctl_up_full) 3072 Up for erase in full mode(dB) short pfrr (pwrctl_full_run_reset) -2 Fulls until full mode(count value) word16 pupe (pwrctl_up_erasure) 248 Up for erase in erase run(dB) word16 pupel(pwrctl_up_erasure_little) 50 Up for erase(dB) word16 pd (pwrctl_down) 48 Down for full(dB) word16 pvd (pwrctl_var_down) 4 Down for variable(dB) word16 pfw (pwrctl_full_wait) 2 Pause between up fulls(count value) short perl (pwrctl_erasure_run_lim) 5 Erase until erase run(count value) byte reserved_byte[32] 0 7.5.5.4. St_13_revpwr_data_type Table 7.5-27 St_13_revpwr_data_type Remarks Type N a m e default (As of 2000-3-6, on;y 1% used) fer_id : 0 byte bts_id full byte fer_id 0 ~ 1 Always Full equip word16 pnom (pwrctl_nominal) 19416 Initial pwrctl threshold value. (up to 109048 at word32) word16 pmax (pwrctl_max) 34304 Maximum pwrctl threshold value. (up to 109048 at word32) word16 pmin (pwrctl_min) 8288 Minimum pwrctl threshold value. (up to 109048 at word32) word16 rpc_big_up_delta 4608 Pwrctl threshold up delta. Applied when a pwrctl-threshold-up condition is encountered during ERASURE-STATE.
STAREX-IS BSM Manual Page:811(877)Issue:1.0SMD-011-PMA210 word16 rpc_small_up_delta 2304 Pwrctl threshold up delta. Applied when a pwrctl-threshold-up condition is encountered during GOOD-STATE. byte rpc_non_erase_wait 2 Non-erasure rate waiting frame count after increasing pwrctl threshold. During the period, erasure rate frame has no effect. byte rpc_max_down_delta 48 Maximum pwrctl threshold down delta. byte rpc_min_down-delta 2 Minimum pwrctl threshold down delta. byte rpc_down_delta_inc_step 1 Increment step size of pwrctl threshold down delta up. byte rpc_cont_erase_eftv 2 Number of consecutive erasures brings about pwrctl-threshold-up. If 0, burst erasures have no effect. byte rpc_cumul_erase_eftv 3 Number of cumulative erasures during rpc_erase_meas_frames brings about pwrctl-threshold-up. If 0, non-burst erasures have no effect. word16 rpc_erase_meas_frames 450 Cumulative erasure measuring period. word16 rpc_state_chg_thresh 250 Number of consecutive good frames brings about GOOD-STATE. byte reserved_byte[34] 0 7.5.5.5. St_SlpSts_data_type Table 7.5-28 St_SlpSts_data_type Type N a m e Default Remarks BYTE SMP_ID full 0 ~ 4 SMP IDENTIFICATION BYTE SLP_ID full 0 ~ 17 SLP IDENTIFICATION BYTE SLP_STS 0 0: UNBLOCK 8: BLOCK BYTE SLAVE_STS[4] 0 0: UNBLOCK 8: BLOCK byte Rserved_byte[33] 0 7.5.5.6. St_VcpSts_data_type Table 7.5-29 St_VcpSts_data_type
STAREX-IS BSM Manual Page:812(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks BYTE VMP_ID full 0 ~ 7 VMP IDENTIFICATION BYTE VCP_ID full 0 ~ 15 VCP IDENTIFICATION BYTE SHELF_TYPE 0 0: PHASE1 1: PHASE2 BYTE VCP_STS 0 0: UNBLOCK 8: BLOCK BYTE VCP_SLAVE_STS[2] 0 0: UNBLOCK 8: BLOCK BYTE VCE_STS[8] 0 0: UNBLOCK 8: BLOCK byte reserved_byte[34] 0 7.5.5.7. St_Trunk_data_type Table 7.5-30 St_Trunk_data_type Type N a m e default Remarks BYTE VMP_ID full 0 ~ 7 VMP IDENTIFICATION BYTE VLIA_ID full 0 ~ 1 VLIA IDENTIFICATION BYTE VLIA_STS 0 0: UNBLOCK 8: BLOCK BYTE LINK_STS[16] 0 0: UNBLOCK 8: BLOCK byte ts_sts[16][32] 0 0: UNBLOCK 8: BLOCK byte ts_type[16][32] 0: Vocoder 1: NO7(ts being 16) byte reserved_byte[33] 0 7.5.5.8. St_T1_Trunk_data_type Table 7.5-31 St_T1_Trunk_data_type Type N a m e default Remarks byte btia_id 0 ~ 15 BTIA board identification (board to connect T1 link) byte T1_id 0 ~ 4 T1 link identification ( one BTIA holds 5 T1 links.) byte ts_id 0 ~ 23 Time slot identification ( 1 T1 link holds 24 Time slots.) byte type 0 ~ 1 0: used for vocoder assignment 1: current time slot is connected to STF(Signaling Terminal Function) for No.7
STAREX-IS BSM Manual Page:813(877)Issue:1.0SMD-011-PMA210 byte sbp_no 0 ~ 14 sbp number of vocoder channel that is matched to each time slot byte svc_no 0 ~ 15 svc number of vocoder channel matched to each time slot byte vce_no 0 ~ 7 vocoder channel number matched to each time slot word cic Number matched to all time slots, that is, each time slot’s own number. byte dummy byte reserved_byte[34] 0 7.5.5.9. St_Bsc_data_type Table 7.5-32 St_Bsc_data_type Type N a m e default Remarks byte dummy_key byte bsc_id 0 ~ 11 bsc identification byte trunk_type 0 : E1 (LGT) 1 : T1 (NW) word16 inactive_timer 30 MS inactive status judgement level word16 dormant_timer 10 MS dormant status judgement level byte bad_frame_time byte pkt_zone Current default: 0 byte pcp_id Current default: 0 connected PCP ID byte band_class 0(DCN) 1(1900Mgz) 4(1800Mhz) band class of candidate frequency 800Mhz: 0 1800Mhz : 4 = domestic 1900Mhz: 1 = overseas byte reserved_byte[31] 0 7.5.5.10. St_target_fer_service_type Table 7.5-33 St_target_fer_service_type
STAREX-IS BSM Manual Page:814(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte Dummy 0 byte voice_8k 1 Basic Variable Rate (8K Voice) byte loopback_8k 1 8K Loopback : IS-126 byte evrc 1 Enhanced Variable Rate Code byte async 1 Asycronous Data(9.6 Kbps) : Provides Dial Up Modem function and AT command, and subscriber uses this for end-to-end communication or accesses public data network. byte g3fax 1 Group 3 Facsimile(9.6Kbps) : It added the function of processing extension AT command for FAX to Dial Up Modem so that subscriber with FAX can exchange data with FAX accommodated in PSTN. byte sms 1 Short Message(Rate Set 1) : Exchanges SMS between external device and PCS network or between MS and Network. byte ppp_pkt 1 Paket Data(Internet/ISO Protocol Stack) PPP protocol stack is mounted on MS and Network Layer. Point-to-Point Packet Data Service byte cdpp_pkt 1 Packet Data(CDPP Protocol Stack) PPP protocol stack is mounted on MS and Network Layer. Multiple Packet Service byte loopback_13k 1 13K Loopback byte stu_iii_tr 1 byte stu_iii_ntr 1 byte async_13k 1 Asycronous Data (14.4Kbps) byte g3fax_13k 1 Group 3 Facsimile (14.4Kbps) byte sms_13k 1 Short Message (Rate Set 2) byte voice_13k 1 Basic Variable Rate (8K Voice) byte is96_voice 1 byte markov_8k 1 Markov Call ( 8Kbps) byte data 1 byte is96a_no 1 96A no quarter rate byte markov_13k 1 Markov Call (14.4Kbps)
STAREX-IS BSM Manual Page:815(877)Issue:1.0SMD-011-PMA210 byte wll_offhook 1 byte rs1_markov 1 rate set 1 Markov Call byte rs2_markov 1 rate set 2 Markov Call byte fch_fer 1 RC3 data service (0~31) byte sch_fer 1 RC3 data service (0~31) byte dcch_fer 1 RC3 data service (0~31) byte Sch_loopback 0 byte Sch_loopback2 0 byte Reserved_byte[31] 0 7.5.5.11. St_MAHHO_data_type Table 7.5-34 St_MAHHO_data_type Type N a m e default Remarks byte bts_id full byte sector_id full byte border_flag 0: Off, 1: On byte band_class 0(DCN) 1(1900Mgz) 4(1800Mhz) band class of candidate frequency 800Mhz: 0 1800Mhz : 4 = domestic 1900Mhz: 1 = overseas byte Num_cdma_freq Number of candidate frequency word16 cdma_freq[MAX_CDMA_CH] Candidate frequency (cdmach_num) byte sf_total_ec_thresh 11111(bin) As threshold of total Ec value regarding Serving Frequency, this determines whether to search candidate frequency. byte sf_total_ec_io_thresh 26 As threshold of total Ec/Io value regarding Serving Frequency, this determines whether to search candidate frequency.
STAREX-IS BSM Manual Page:816(877)Issue:1.0SMD-011-PMA210 If total Ec/Io value is lower than total threshold regarding serving frequency, it does not search the pilot of Candidate Frequency. byte diff_rx_pwr_thresh 0 As power difference threshold between received serving frequency and candidate frequency, this determines whether to search candidate frequency. byte min_total_pilot_ec_io 0 Ec/Io threshold of active set of candidate frequency byte cf_t_add 26 Threshod to add pilot to acticve set of candidate frequency. If of pilots that belondg to neighbor set of Candidate Frequency, there is a pilot that has better Ec/Io than cf_t_add, it is reported to BS through Candidate Frequency Search Report. byte tf_wait_time 30 After transition to target frequency, waiting time to receive good frame( 80ms unit) 30  2.4 second byte cf_srch_win_n 9 Basic Search Window for candidate frequency neighbor set ( it uses teg same value as that of search window to existing system parameter message) byte cf_srch_win_r 10 Basic search window for candidate frequency Remaining Set byte reserved_byte[35] 0 7.5.5.12. St_location_para_type Table 7.5-35 St_location_para_type
STAREX-IS BSM Manual Page:817(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte bts_id full byte sector_id full byte action_time_frame After set Action time, frame unit duration until first PUF probe. Before PUF pulse transfer, duration sent with nominal power byte puf_setup_size power control group unit. byte puf_pulse_size Duration that MS sends PUF pulse. Power control group unit. word16 puf_interval Interval between PUF Probes. frame unit byte puf_init_pwr Initial PUF Probe power. in units of dB byte puf_pwr_step PUF pulse power increase. in units of dB byte total_puf_probes Total PUF prove number byte max_pwr_puf Max. PUF Probe number that can be transmitted with max. Tx power byte reserved_byte[33] 0 7.5.5.13. St_pwr_cntl_para_type Table 7.5-36 St_pwr_cntl_para_type Type N a m e default Remarks byte bts_id full byte fer_id 0 ~ 30 byte pwr_cntl_step step size of forward link closed loop power control byte fpc_mode 0 operation mode of forward link closed loop power control It should be the same as fpc_punc_mode of St_Chip_pwr_cntl_para_data. byte fpc_fch_init_setpt initial Value of Forward Fundamental Channel Outer Loop Eb/Nt setpoint (hereinafter
STAREX-IS BSM Manual Page:818(877)Issue:1.0SMD-011-PMA210 FFCOLS). 0.125dB unit byte fpc_fch_min_setpt Minimum value of FFCOLS. 0.125dB unit byte fpc_fch_max_setpt FFCOLS’s Maximum value. 0.125dB unit byte fpc_dcch_init_setpt Forward Dedicated Control Channel Outer Loop Eb/Nt setpoint (hereinafter FDCCOLS) initial value. 0.125dB byte fpc_dcch_min_setpt FDCCOLS’s Minimum value. 0.125dB byte fpc_dcch_max_setpt FDCCOLS’s Maximum value. 0.125dB byte fpc_sch_init_setpt Forward Supplemental Channel Outer Loop Eb/Nt setpoint(FSCOLS) initial value. 0.125dB byte fpc_sch_min_setpt FSCOLS’s Minimum value. 0.125dB byte fpc_sch_max_setpt FSCOLS’s Maximum value. 0.125dB byte fpc_setpt_thresh Forward link Power control Setpoint Threshold Value. 0.125dB byte fpc_setpt_thresh_sch Forward Supplemental Channel Power control Setpoint Threshold Value. 0.125dB byte fch_chan_adj_gain Channel Gain adjustment value for Reverse Fundamental Channel. Complement of 2 in 0.125dB unit. byte dcch_chan_adj_gain Channel Gain adjustment value for Reverse Dedicated Control Channel. Complement of 2 in 0.125dB unit. byte sch0_chan_adj_gain Channel Gain adjustment value for Reverse Supplemental Channel 0. Complement of 2 in 0.125dB unit. byte sch1_chan_adj_gain Channel Gain adjustment value for Reverse Supplemental Channel 1. Complement of 2 in 0.125dB unit. byte rl_att_adj_gain_1500[2] index 0: not using Reverse Pilot index 1: using Reverse Pilot 20ms frame, 1500bps Reverse Link
STAREX-IS BSM Manual Page:819(877)Issue:1.0SMD-011-PMA210 Attribute Adjustment gain value. byte rl_att_adj_gain_2700[2] 20ms frame, 2700bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_4800[2] 20ms frame, 4800bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_9600[2] 20ms frame, 9600bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_1800[2] 20ms frame, 1800bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_3600[2] 20ms frame, 3600bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_7200[2] 20ms frame, 7200bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_14400[2] 20ms frame, 14400bps Reverse Link Attribute Adjustment gain value. byte norm_att_gain_9600_5ms[2] 5ms frame, 9600bps Reverse Link Attribute Adjustment gain value. byte rl_att_adj_gain_19200[2][2] 2nd index 0: 2dn index 1: Turbo Encoding 20ms frame, 19200bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_38400[2][2] 20ms frame, 38400bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_76800[2][2] 20ms frame, 76800bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_153600[2][2] 20ms frame, 153600bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_307200[2][2] 20ms frame, 307200bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_614400[2][2] 20ms frame, 614400bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_28800[2][2] 20ms frame, 28800bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_576600[2][2] 20ms frame, 576600bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_115200[2][2] 20ms frame, 115200bps Reverse Link
STAREX-IS BSM Manual Page:820(877)Issue:1.0SMD-011-PMA210 Attribute Adjustment gain byte rl_att_adj_gain_230400[2][2] 20ms frame, 230400bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_460800[2][2] 20ms frame, 460800bps Reverse Link Attribute Adjustment gain byte rl_att_adj_gain_1036800[2][2] 20ms frame, 1036800bps Reverse Link Attribute Adjustment gain byte fpc_subchan_gain byte rl_gain_adj byte rlgain_traffic_pilot byte rlgain_sch_pilot byte reserved_byte[33] 0 7.5.5.14. St_sch_param_data Table 7.5-37 St_sch_param_data Type N a m e default Remarks byte bts_id full byte sector_id full byte sch_t_add 22 Regarding MDR handoff, t_add that is only appied as to Supplemental Code Channel byte sch_t_drop 26 Regarding MDR handoff, t_drop that is only applied as to Supplemental Code Channel byte t_mulchan threshold offset of Nghbr Pilot strength. 0.5dB step from 0.5dB to 4.0dB byte begin_preamble Preamble Frame number sent at the beginning of Reverse Supplemental (Code) Channel transfer byte resume_preamble Preamble Frame number sent upon retransfer of Reverse Supplemental (Code) Channel byte ps_min_delta Parameter necessary when operating in such mode as MS sending Pilot Strength Measurement Mini Message(PSMMM) whenever
STAREX-IS BSM Manual Page:821(877)Issue:1.0SMD-011-PMA210 Active Set order changes. As threshold necessary so that MS judges PSMMM transfer, this is necessary upon such mode as MS sending PSMMM whenever the order of active set changes. byte order_interval Interval to report the difference between two pilot strengths through PSMMM. in units of 20ms byte num_pilots Parameter necessary for MS to send PSMMM. Pilot number reported through PSMMM byte periodic_interval Interval that MS sends PSMMM. in units of 20ms byte ps_floor_high Based on threshold, high water mark value set as to lower bound. byte ps_floor_low Based on threshold, low water mark valueset as to lower bound byte ps_ceiling_high Based on threshold, high water mark value set as to upper bound byte ps_ceiling_low Based on threshold, low water mark value set as to upper bound. byte threshold_interval Based on threshold, PSMMM transfer interval. in units of 20ms byte t_slotted Parameter included in In Traffic System Parameters Message byte reserved_byte[35] 7.5.5.15. St_IOS_para_data Table 7.5-38 St_IOS_para_data Type N a m e default Remarks byte dummy key byte T1 55 (0~255) Facilities Management(sec) byte T2 60 (0~255) Facilities Management(sec) byte T4 60 (0~255) Facilities Management(sec)
STAREX-IS BSM Manual Page:822(877)Issue:1.0SMD-011-PMA210 byte T5 60 (0~255) Facilities Management(sec) byte T6 75 (0~255) Facilities Management(sec) byte T7 10 (0~255) Handoff(sec) byte T9 10 (0~255) Handoff(sec) byte T10 5 (0~99) Handoff(sec) byte T12 60 (0~255) Facilities Management(sec) byte T13 55 (0~255) Facilities Management(sec) byte T16 60 (0~255) Facilities Management(sec) byte T20 5 (0~99) Call Processing(sec) byte T30 5 (0~99) Call Processing(sec) byte T40 5 (0~99) Call Processing(sec) byte T50 60 (0~255) Handoff(sec) byte T52 90 (0~255) Handoff(sec) byte T60 5 (0~99) Supplementary Services(sec) byte T61 5 (0~99) Supplementary Services(sec) byte T62 5 (0~99) Supplementary Services(sec) byte T63 5 (0~99) Supplementary Services(sec) word32 T300 1500 (0~990) Call Processing (msec) byte T301 30 (0~60) CallProcessing(sec) byte T302 5 (0~99) Call Processing(sec) byte T303 6 (0~99) Call Processing(sec) byte T306 5 (0~99) Call Processing(sec) byte T307 6 (0~99) Call Processing(sec) byte T308 5 (0~99) Call Processing(sec) byte T309 5 (0~90) Facilities Management (sec) word16 T311 1000 (0~50) Call Processing (msec) byte T312 5 (0~99) Call Processing(sec) byte T313 2 (0~99) Call Processing(sec) byte T315 5 (0~99) Call Processing(sec) byte T316 5 (0~99) Call Processing(sec) byte T325 5 (0~99) Call Processing(sec) byte T326 5 (0~99) Call Processing(sec) byte T777 90 (0~255) Handoff (sec) byte T778 15 (0~255) Handoff (sec) byte T787 90 (0~255) Handoff (sec) byte T789 10 (0~60) Handoff (sec)
STAREX-IS BSM Manual Page:823(877)Issue:1.0SMD-011-PMA210 byte T790 10 (0~60) Handoff (sec) byte T3113 5 (0~99) Call Processing (sec) byte T3210 30 (0~99) Mobility Management (sec) byte T3220 10 (0~99) Mobility Management (sec) byte T3230 5 (0~99) Call Processing (sec) byte T3240 5 (0~99) Mobility Management (sec) byte T3260 30 (0~99) Mobility Management (sec) byte T3270 5 (0~99) Mobility Management (sec) byte T3271 15 (0~99) Mobility Management (sec) byte T3272 5 (0~99) Mobility Management (sec) byte T3280 15 (0~99) Call Processing (sec) byte TA8_Setup 4 (0~99) A8,A9 Interfaces (sec) word16 Tacm 500 (0~1000) A3,A7 Interfaces (msec) word16 Talc9 500 (0~1000) A8,A9 Interfaces (msec) word16 Tald9 500 (0~1000) A8,A9 Interfaces (msec) word16 Tbstact 600 (0~1000) A3,A7 Interfaces (msec) word16 Tbstcom 100 (0~1000) A3,A7 Interfaces (msec) word16 Tchanstat 500 (0~1000) A3,A7 Interfaces (msec) word16 Tconn3 500 (1~1000) A3,A7 Interfaces (msec) word16 Tdiscon3 500 (1~1000) A3,A7 Interfaces (msec) byte Tdrptgt 5 (1~10) A3,A7 Interfaces (sec) byte Ttgtrmv 5 (1~10) A3,A7 Interfaces (sec) word16 Thoreq 1000 (0~50) A3,A7 Interfaces (msec) byte Tpaca1 5 (0~99) Call Processing (sec) byte Tpaca2 5 (0~99) Call Processing (sec) word16 Tpcm 1000 (0~20) A3,A7 Interfaces (msec) byte Tphysical 1 (0~10) A3,A7 Interface (sec) word16 Trel9 1000 (0~50) A8,A9 Interface (msec) byte reserved_byte[35] 7.5.5.16. St_Vcbu_HW_Reset_data_type Table 7.5-39 St_Vcbu_HW_Reset_data_type Type N a m e default Remarks Byte VMP_ID 0 ~ 7 VMP IDENTIFICATION
STAREX-IS BSM Manual Page:824(877)Issue:1.0SMD-011-PMA210 Byte EquipPage According to Equip status 0: Not Equip 1: Equip Byte VMP_Isolation 0 0: not_isolation 1: isolation Byte VCP_Isolation[16] 0 0: not_isolation 1: isolation Byte VLIA_Isolation[2] 0 0: not_isolation 1: isolation Byte reserved_byte[34] 0 7.5.5.17. St_Slbu_HW_Reset_data_type Table 7.5-40 St_Slbu_HW_Reset_data_type Type N a m e Default Remarks Byte SMP_ID 0 ~ 4 SMP IDENTIFICATION Byte EquipPage According to Equip status 0: Not Equip 1: Equip Byte SMP_Isolation 0 0: not_isolation 1: isolation Byte SLP_Isolation[20] 0 0: not_isolation 1: isolation Byte rserved_byte[33] 0 7.5.6. NCP ONLY 7.5.6.1. St_re_atm_node.dg Table 7.5-41 St_re_atm_node Type N a m e default Remarks byte card_id key full equip (MAX_ATM_CARD:5) byte link_id key full equip (MAX_ATM_LINK:32) byte equip As many as Node Config below Equip 1: Equip, 0:Not-Equip byte link_type 1 STM-1, STM-4, Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 Link status LINK_STS_NONE(0), LINK_STS_ACTIVE(1),
STAREX-IS BSM Manual Page:825(877)Issue:1.0SMD-011-PMA210 LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3) byte connect_type End-User’s own ID connected to Link(see Appendix Connection ID) byte fabric_no Fabric is a serial number of APC. Index(0~8) of total APCs 0 : ASCA APC0, 1 : ASIA0 APC0, 2 : ASIA0 APC1, 3 : ASIA1 APC0, 4 : ASIA1 APC1, 5 : ASIA2 APC0, 6 : ASIA2 APC1, 7 : ASIA3 APC0, 8 : ASIA3 APC1 byte reserved[7] 7.5.6.2. St_re_slb_node.dg Table 7.5-42 St_re_slb_node Type N a m e default Remarks byte smp_id key full equip MAX_SLB:5 byte link_id key full equip (MAX_SUB_LINK:32) byte equip smp number As many as Node Config below, Equip 1: Equip, 0:Not-Equip byte link_type 1 STM-1, STM-4, Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 Link status LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3) byte connect_type End-User’s own ID connected to Link (see Appendix Connection ID) byte fabric_no 0 Index(0~8) of total APCs 0 : SLMA APC0 byte reserved[7] 7.5.6.3. St_re_vcb_node.dg Table 7.5-43 St_re_vcb_node
STAREX-IS BSM Manual Page:826(877)Issue:1.0SMD-011-PMA210 Type N a m e Default Remarks byte vmp_id Key full equip MAX_VCB:8 byte link_id key full equip (MAX_SUB_LINK:32) byte equip Vmp number As many as Node Config below, Equip 1: Equip, 0:Not-Equip byte link_type 1 STM-1, STM-4, Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 Link status LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3) byte connect_type End-User’s own ID connected to Link (see Appendix Connection ID) byte fabric_no 0 Index(0~8) of total APCs 0 : VCMA APC0 byte reserved[7] 7.5.6.4. St_re_alb_node.dg Table 7.5-44 St_re_alb_node Type N a m e default Remarks byte alma_id key full equip (MAX_ALMA:2) byte link_id key full equip (MAX_ALS_LINK:16) byte equip As many as Node Config below, Equip 1: Equip, 0:Not-Equip byte link_type 1 STM-1, STM-4, Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 Link status LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3)
STAREX-IS BSM Manual Page:827(877)Issue:1.0SMD-011-PMA210 byte connect_type End-User’s own ID connected to Link (see Appendix Connection ID) byte fabric_no 0 Index(0~8) of total APCs 0 : ALMA APC0 byte reserved[7] 7.5.6.5. St_re_bs_atm_node.dg Table 7.5-45 St_re_bs_atm_node Type N a m e default Remarks byte Bs_id key full equip MAX_BS:48 byte link_id key full equip (MAX_SUB_LINK:32) byte equip bs number As many as Node Config below, Equip 1: Equip, 0:Not-Equip byte link_type 1 STM-1, STM-4, Cell Bus (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 Init/Active/Block LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3)) byte connect_type End-User’s own ID connected to Link (see Appendix Connection ID) byte Fabric_no 0 index(0~8) of total APCs 0 : BCRA APC0 byte reserved[7] 7.5.6.6. St_re_rnc_bs_trunk.dg Table 7.5-46 St_re_rnc_bs_trunk Data Type N a m e default Remarks byte alma_id key full equip MAX_ALMA: 2
STAREX-IS BSM Manual Page:828(877)Issue:1.0SMD-011-PMA210 byte alpa_id key full equip MAX_ALPA: 5 byte link_id key full equip MAX_ALS_LINK: 16 byte equip BS dependent LINK_NOT_EQUIP(0), LINK_EQUIP(1) byte link_type 1 E1, T1, STM-1 (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1),LINK_TYPE_STM12(2), LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte link_status 1 LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3) byte bs_id Link Peer BS/BTS ID byte alloc_type 1 PVC Active/PVC Standby/SVC - ALLOC_NONE(0),ALLOC_PVC_ACT(1), ALLOC_PVC_STB(2), ALLOC_SVC(3)) byte peer_lica_no BS Lica Index (0, 1, 2) byte peer_lica_link_no BS Lica Link Index (0~15) byte peer_status Init/Active/Block LINK_STS_NONE(0), LINK_STS_ACTIVE(1), LINK_STS_ONL_BLOCK(2), LINK_STS_MMC_BLOCK(3)) word32 aal2_vpci AAL2 VPI/VCI word32 reserved 7.5.6.7. St_re_rnc_addr.dg St_re_rnc_addr Type N a m e default Remarks byte shelf_id key full equip (MAX_RNC_SHELF: 20) byte slot_id key full equip (MAX_RNC_SLOT: 22) byte equip ‘0’ Equit/Not Equip byte Bd_type Processor/Device Board Type(TBD) byte No_sub Number of processors to be mounted byte reserved Not Used
STAREX-IS BSM Manual Page:829(877)Issue:1.0SMD-011-PMA210 word32 addr[8] Each Processor IP Address 7.5.6.8. St_re_bs_addr.dg St_re_bs_addr Type N a m e default Remarks byte bs_id key full equip MAX_BS: 48 byte shelf_id key full equip (MAX_BS_SHELF: 12) byte slot_id key full equip (MAX_BS_SLOT: 22) byte equip ‘0’ Equit/Not Equip byte bd_type Processor/Device Board Type(TBD) byte no_sub Number of processors mounted byte reserved Not Used word32 addr[8] Each Processor IP Address 7.5.6.9. St_re_atm_pvc.dg Table 7.5-47 St_re_atm_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~4096) word16 reserved byte equipage[4096] Equip Flag byte node_a[4096] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[4096] Peer1 Logical Info byte node_b[4096] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[4096] Peer2 Logical info byte no_vc[4096] Number of VC to be used between Allocated VC Number Peers byte link_type[4096] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[4096] 0x100 VC Link Bandwidth
STAREX-IS BSM Manual Page:830(877)Issue:1.0SMD-011-PMA210 (Cell Bandwidth(~0x40) to be assigned to Link) word32 vpci_a[4096] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[4096] Peer2 VPI/VCI (Egress VPCI) 7.5.6.10. St_re_slb_pvc.dg Table 7.5-48 St_re_slb_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~512) word16 reserved byte equipage[512] byte node_a[512] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[512] Peer1 Logical Info byte node_b[512] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VC to be used between Allocated VC Number Peers byte link_type[512] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[512] 0x100 VC Link Bandwidth (Cell Bandwidth(~0x40) to be assigned to Link) word32 vpci_a[512] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI (Egress VPCI) 7.5.6.11. St_re_vcb_pvc.dg Table 7.5-49 St_re_vcb_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~512)
STAREX-IS BSM Manual Page:831(877)Issue:1.0SMD-011-PMA210 word16 reserved byte equipage[512] byte node_a[512] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[512] Peer1 Logical Info (measns final peer connection) byte node_b[512] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VC to be used between Allocated VC Number Peers byte link_type[512] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[512] 0x100 VC Link Bandwidth (Cell Bandwidth(~0x40) to be assigned to Link) word32 vpci_a[512] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI (Egress VPCI) 7.5.6.12. St_re_alb_pvc.dg Table 7.5-50 St_re_alb_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~512) word16 reserved byte equipage[512] byte Node_a[512] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[512] Peer1 Logical Info byte Node_b[512] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VC to be ysed between Allocated VC Number Peers byte Link_type[512] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 Link_bw[512] 0x100 VC Link Bandwidth
STAREX-IS BSM Manual Page:832(877)Issue:1.0SMD-011-PMA210 word32 vpci_a[512] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI (Egress VPCI) 7.5.6.13. St_re_loc_bs_pvc.dg Table 7.5-51 St_re_loc_bs_pvc Type N a m e default Remarks byte dummy key word16 no_entry # of Valid Entries, defined PVC information number (~512) word16 reserved byte equipage[512] byte node_a[512] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[512] Peer1 Logical Info byte node_b[512] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VC to be used between Allocated VC Number Peers byte link_type[512] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[512] 0x100 VC Link Bandwidth word32 vpci_a[512] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI (Egress VPCI) 7.5.6.14. St_re_out_bs_pvc.dg Table 7.5-52 St_re_out_bs_pvc Type N a m e default Remarks byte bs_id key full equip MAX_BS : 48 word16 no_entry # of Valid Entries (~512) word16 reserved byte equipage[512] According to bs equip, out_bs_pvc.inf
STAREX-IS BSM Manual Page:833(877)Issue:1.0SMD-011-PMA210 byte node_a[512] Peer1 connection ID (Ingress Node Conn. ID) byte sub_a[512] Peer1 Logical Info byte node_b[512] Peer2 Connection ID (Egress Node Conn. ID) byte sub_b[512] Peer2 Logical info byte no_vc[512] Number of VC to be used between Allocated VC Number Peers byte link_type[512] Link LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2) word16 link_bw[512] 0x100 VC Link Bandwidth word32 vpci_a[512] Peer1 VPI/VCI (Ingress VPCI) word32 vpci_b[512] Peer2 VPI/VCI (Egress VPCI) 7.5.6.15. St_re_atm_svc.dg Table 7.5-53 St_re_atm_svc Type N a m e default Remarks byte Dummy key word16 no_entry # of Valid Entries (~4096) byte no_hdr Header Address Length (Upper ATM Address Length) byte reserved byte addr_hdr[20] ATM Upper Address Id byte equipage[512] Equip Flag byte a_mask1[512][10] Peer1 Address Mask byte addr1[512][10] Peer1 Address byte a_mask2[512][10] Peer2 Address Mask byte addr2[512][10] Peer2 Address byte no_vc[512] Allocated VC Number word32 atm_id1[512] Peer1 VC Ids’ List word32 atm_id2[512] Peer2 VC Ids’ List byte link_type[512] Link Usage (LINK_AAL2(0), LINK_AAL5(1), LINK_TEST(2)) word16 link_bw[512] Cell Bandwidth(~0x40) to be assigned to VC
STAREX-IS BSM Manual Page:834(877)Issue:1.0SMD-011-PMA210 Link BandWidth(TBD,Link) 7.5.6.16. St_re_rnc_net_cfg.dg Table 7.5-54 St_re_rnc_net_cfg Type N a m e default Remarks byte rnc_net_shelf_id key full equip (MAX_RNC_NET_SHELF: 2) byte rnc_net_slot_id key full equip (MAX_RNC_SLOT: 22) byte Equip ‘0’ byte bd_type Network Board Type byte no_sub # of Sub Device byte no_link # of Physical Link byte hw_ctrl HW Reset : 0(Init), 1, 2, 3 added byte link_type[MAX_LINK] 1 Physical Link Type : STM1, E1,...(MAX_LINK: 64) (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1), LINK_TYPE_STM12(2),LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte sub_type[MAX_SUB] Sub Device Type (MAX_SUB : 16) (SBTYPE_NONE(0), SBTYPE_APC(1), SBTYPE_APPD(2)) byte sub_id[MAX_SUB] Sub Device ID:Device Serial Number (MAX_SUB : 16) 7.5.6.17. St_re_bs_net_cfg.dg Table 7.5-55 St_re_bs_net_cfg Type N a m e default Remarks byte bs_id key full equip MAX_BS: 48 byte bs_net_slot_id key full equip (MAX_BS_SLOT: 22) byte Equip ‘0’ Equip Flag byte bd_type Network Board Type byte no_sub # of Sub Device byte no_link # of Physical Link
STAREX-IS BSM Manual Page:835(877)Issue:1.0SMD-011-PMA210 byte link_type[MAX_LINK] 1 Physical Link Type : STM1, E1,...(MAX_LINK: 64) (LINK_TYPE_NONE(0),LINK_TYPE_STM1(1), LINK_TYPE_STM12(2),LINK_TYPE_STM14(3), LINK_TYPE_E1(4), LINK_TYPE_T1(5)) byte sub_type[MAX_SUB] Sub Device Type (MAX_SUB : 16) (SBTYPE_NONE(0), SBTYPE_APC(1), SBTYPE_APPD(2)) byte sub_id[MAX_SUB] Sub Device ID:Device Serial Number (MAX_SUB : 16) 7.5.6.18. St_re_rnc_net_data.dg Table 7.5-56 St_re_rnc_net_data Type N a m e Default Remarks byte dummy Key byte msc_id msc_no Core Network ID byte rnc_id bsc_no My RNC ID byte can_equip can_eqp CAN Equipage byte no_addr_hdr ATM Address Header Len byte rnc_equip[MAX_RNC] rnc_eqp RNC Equipage (MAX_RNC : 12) byte bs_equip[MAX_BS] bs_eqp BS Equipage (MAX_BS : 48) byte smp_equip[MAX_SLBU] smp_eqp SLBU Equipage (MAX_SLBU : 5) byte reserved[3] word32 bs_svc_id[MAX_BS] BS SSCF-UNI Signalling VC ID (MAX_BS : 48) byte atm_addr_hdr[20] ATM Address Header byte cn_conn_type[2] 11 12 CN Connection ID byte can_conn_type[2] 9 10 CAN Connection ID In IS-2000 0 : CAN, 1 : CAN-D In IMT-2000 0 : CAN0, 1 : CAN1 byte slb_conn_type[MAX_SLBU] 16~20 SLBU Connection ID (MAX_SLBU : 5) byte vcb_conn_type[MAX_V 21~28 VCBU Connection ID
STAREX-IS BSM Manual Page:836(877)Issue:1.0SMD-011-PMA210 CBU] byte als_conn_type[4] 5~8 ALSU Connection ID byte pip_conn_type[8] 29~36 PIP Connection ID byte cmp_conn_type 15 CMP connection ID byte reseved[6] word32 ccp_addr CCP IP Address word32 alp_addr ALP IP Address word32 cnp_addr[2] CNP/CNP-D IP Address 0 : CNP Address, 1 : PNP Address word32 smp_addr[MAX_SLBU] SMP IP address (MAX_SLBU : 5) word32 asmu_addr[16] 2 ~ 17 ASMU Device Network Addr (for HDLC) 0: ASCA_A, 1: ASCA_B, 2: ASIA0_A, 3: ASIA0_B, 4: ASIA1_A, 5: ASIA1_B, 6: ASIA2_A, 7: ASIA2_B, 8: ASIA3_A, 9: ASIA3_B, 10: AOTA0, 11: AOTA1, 12: AOTA2, 13: AOTA3, 14: ATSA0, 15: ATSA1 7.5.6.19. St_re_rnc_iur_con.dg Table 7.5-57 St_re_rnc_iur_con ‘Type N a m e default Remarks byte Dummy key word32 start_aal2_vc_id[MAX_RNC] *1 below AAL2 Start VC Id (MAX_RNC : 12) word16 no_aal2_vc 32 Number of AAL2 VCs word16 Reserved ‘ 7.5.6.20. St_re_rnc_iub_con.dg Table 7.5-58 St_re_rnc_iub_con Type N a m e default Remarks byte bs_id key MAX_BS : 48
STAREX-IS BSM Manual Page:837(877)Issue:1.0SMD-011-PMA210 word32 aal2_vc_id [MAX_LICA][MAX_LICA_LINK] AAL2 Start VC Id. MAX_LICA : 3, MAX_LICA_LINK : 16 7.5.6.21. St_re_rnc_slb_con.dg Table 7.5-59 St_re_rnc_slb_con Type N a m e default Remarks byte Dummy key Applied to all SMPs in the same way word32 start_aal5_vc_id[20] AAL5 Start VC Id 20VPs word16 no_aal5_vc 1024 Number of AAL5 VCs 20VPs word16 Reserved 7.5.6.22. St_re_rnc_vcb_con.dg Table 7.5-60 St_re_rnc_vcb_con Type N a m e default Remarks byte Dummy key Applied to all VMPs in the same way word32 start_aal5_vc_id[20] AAL5 Start VC Id 20VPs word16 no_aal5_vc 128 Number of AAL5 VCs 20VPs word16 reserved 7.5.6.23. St_re_rnc_alsu5_con.dg Table 7.5-61 St_re_rnc_alsu5_con Type N a m e default Remarks byte Dummy key word32 start_aal5_vc_id[MAX_ALMA][MAX_ALPA][2] AAL5 Start VC Id 20VPs (MAX_ALMA : 2,MAX_ALPA : 5) word16 no_aal5_vc 2048 Number of AAL5 VCs 20VPs word16 Reserved 7.5.6.24. St_re_bs_net_data.dg Table 7.5-62 St_re_bs_net_data
STAREX-IS BSM Manual Page:838(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte bs_id key full equip MAX_BS : 48 byte msc_id msc_no Core Network ID byte rnc_id rnc_no My RNC ID byte bs_id bs_no My BS ID byte no_addr_hdr ATM Address Header Len byte atm_addr_hdr[20] ATM Address Header byte lica_conn_type[3] 146 147 148 LICA Connection ID byte reserved word32 svc_id [4/37] = 0x40025 BS SSCF-UNI Signalling VC word32 crp_addr CRP IP Address word32 banu_addr[5] BANU Device Network Addr 7.5.6.25. St_re_bs_iub_con.dg Table 7.5-63 St_re_bs_iub_con Type N a m e default Remarks byte bs_id key MAX_BS: 48 word32 aal2_vc_id [MAX_LICA][MAX_LICA_LINK] AAL2 VC Id MAX_LICA: 3 MAX_LICA_LINK:16 7.5.6.26. St_re_bs_rcu5_con.dg Table 7.5-64 St_re_bs_rcu5_con Type N a m e default Remarks byte bs_id key full equip MAX_BS: 48 word32 start_aal5_vc_id[MAX_RCU_NODE][MAX_LICA] AAL5 Start VC ID (MAX_RCU_NODE : 10, MAX_LICA:3) word16 no_aal5_vc[MAX_LICA] 512 Number of AAL5 VCs word16 reserved 7.5.6.27. St_re_rnc_als_net_data.dg Table 7.5-65 St_re_rnc_als_net_data
STAREX-IS BSM Manual Page:839(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte dummy key byte msc_id msc_no MSC ID byte rnc_id rnc_no RNC/BSC ID byte reserved word32 ncp_addr NCP Network Address word32 alsu_addr[16] ALS Device Network Addr 7.5.6.28. St_re_rnc_cmp5_con.dg Table 7.5-66 St_re_rnc_cmp5_con Type N a m e default Remarks byte dummy key word32 start_aal5_vc_id [10/32] = 0xA0020 AAL5 Start VC Id. word16 no_aal5_vc 1024 #of AAL5 VCs word16 reserved 7.5.7. SCP ONLY 7.5.7.1. St_Lnit_dataSL.dg Table 7.5-67 St_Lnit_dataSL Type N a m e default Remarks byte dummy word16 act_cspu 1: CSPU_P(Primary) 2: CSPU_S(Secondary) int own_pc 3(bsc00) Local signaling point code int adj_pc 0x050f : PCS 0x040f : DCN Remote signaling point code word16 tot_slk 4 Total number of Available Signal link word16 link_st[16] 0~3 : 1 rest: 0 Signaling link status (0: unavailable 1:available) word16 slc_no[16] 0 : slc_no[0] Signaling link code
STAREX-IS BSM Manual Page:840(877)Issue:1.0SMD-011-PMA210 1 : slc_no[1] 2 : slc_no[2] 3 : slc_no[3] 255 : rest word16 vmp_no[16] 0 : vmp_no[0] 0 : vmp_no[1] 0 : vmp_no[2] 0 : vmp_no[3] 255 : rest word16 trk_no[16] 16:trk_no[0] 48: trk_no[1] 80: trk_no[2] 112: trk_no[3] 0xffff: rest Signal data link code byte reserved_byte[35] 0 7.5.7.2. St_Lnit_dataST.dg Table 7.5-68 St_Lnit_dataST Type N a m e default Remarks byte dummy word16 tot_st 4 Total number of signal terminal word16 st_st[16] 1: st_st[0~3] 2: st_st[4~15] Signal terminal state ( 0: unavailable 1: available 2: Not Equip ) word16 sl_no[16] 0 : sl_no[0] 1 : sl_no[1] 2 : sl_no[2] 3 : sl_no[3] 255 : rest Signal link number linked to signal terminal byte reserved_byte[34] 0 7.5.7.3. St_MLtwo_timer.dg Table 7.5-69 St_MLtwo_timer
STAREX-IS BSM Manual Page:841(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte dummy 0 key word16 T1 45000(msec) Timer “alignment ready”(40~50sec) word32 T2 0xffff(msec) Timer “not aligned”(5~150sec) word16 T3 1250(msec) Timer “aligned”(1-2sec) word16 T4n 8000(msec) Normal proving period at 64 kbit/s(7.5~9.5sec) word16 T4e 500(msec) Emergency proving period at 64kbit/s(400~600 msec) word16 T5 100(msec) Timer “sendig SIB”(80~120 msec) word16 T6 4500(msec) Timer “remote congestion”(3~5sec) word16 T7 1250(msec) Timer “excessive delay of an acknowledgement”(0.5~2sec) byte reserved[20] 0 7.5.7.4. St_MLthree_timer.dg Table 7.5-70 St_MLthree_timer Type N a m e default Remarks byte dummy 0 key word16 T1 1000(msec) Delay time of 500-1200 msec to prevent message mis-sequencing upon changeover word16 T2 2000(msec) 700-2000 msec that waits changeover ack word16 T3 1000(msec) 1. Although implemented in code, it is not used. 2. delay time of 500-1200 msec to prevent message mis-sequencing upon changeback by MTP restart (Time controlled diversion procedures) word16 T4 1000(msec) Time of 500-1200 msec to wait changeback ack word16 T5 1000(msec) 500-1200 msec to wait changeback ack word16 T12 1000(msec) 800-1500 msec that waits uninhibit ack word16 T13 1000(msec) 800-1500 msec that waits force uninhibit word16 T14 2000(msec) 2000-3000 msec that waits inhibition ack word16 T17 5000(msec) 800-5000 msec from Initial alignment failure
STAREX-IS BSM Manual Page:842(877)Issue:1.0SMD-011-PMA210 to next initial alignment command word16 T22 240(sec) Local inhibit test timer3-6 minutes word16 T23 240(sec) Remote inhibit test timer3-6 minutes word16 SLTackT 5(sec) Time to wait for signal link test answer, with range of 4sec~12sec byte reserved[20] 0 7.5.7.5. St_SCCP_timer.dg Table 7.5-71 St_SCCP_timer Type N a m e default Remarks byte dummy 0 key word16 T_conne_est 20(sec) 1-2 minutes to wait connection confirm word16 T_ias 300(sec) Delay time of 5-10 minutes used to conduct inactivity test on connection section word16 T_iar 660(sec) Waiting time of 11-21 minutes to receive message on connection section byte T_rel 10(sec) Waiting time of 10-20 sec to receive release complete message word16 T_int 10(sec) 1. although implemented in source, it is not used. 2. upon connection release, it is the time to freeze corresponding LRN for a certain time to prevent the use of the same LRN Extending to 1 minutes word16 T_stat_info 30(sec) Interval that requests Subsystem status information Increasing value, 5-10 sec ~ 10-20 min byte reserve[20] 0 7.5.8. CCP/BSP COMMON 7.5.8.1. St_bts_data_type.dg Table 7.5-72 St_bts_data_type
STAREX-IS BSM Manual Page:843(877)Issue:1.0SMD-011-PMA210 Type N a m e default Remarks byte bts_id full byte EquipPage Equip dependent 0 : Not Equip 1 : Equip word16 Sid 0x08ae As System Identification Number, 0 ~ 32767(215 -1) word16 Nid 15 As Netword Identification Number, Network is system subset. word16 base_id 0 Base Station Identification Number(BTS’s own number) byte bts_class (base_class) 0(DCN) 1(PCS) Base Station Class Upon ‘0000’, Public Micorcelluar System(800Mhz) Upon ‘0001’, Public PCS System(1900Mhz or 1800Mhz) byte sys_type 0 : LGT PCS 1 : NW PCS 2 : JT PCS 3 : GIGA PCS 4 : CHINA PCS 5 : BRAZIL PCS 6 : WLL PCS 7 : RUSSIA PCS byte bts_type 1 ~ 9 bts type identification (STANDARD: 1) byte Sector_range 6 MAX Sector number of current system word16 reg_zone 0 As Registration zone (SID+NID+ZONE_ID), Network Subset. byte pkt_zone 0 Zone ID for PCF Data call Int32 ltm_off 18 Offset of local time from System time. Offset of local time from UTC current local time = SYS_TIME - LP_SEC + ltm_off ltm_off = 18 ( 30 minutes per unit, i.e., 9 hour difference) * LP_SEC : Number of Leap seconds that occurred since the start of System Time. boolean day_lt 0 Daylight saving time flag (Summer time) 1 : day lighting saving time 0 : standard time word16 CDMA_FREQ 425 Primary CDMA Channel Number. – Sync Msg
STAREX-IS BSM Manual Page:844(877)Issue:1.0SMD-011-PMA210 word16 EXT_CDMA_FREQ 525 Upon use of RC3 or more or QPCH, see this field. byte Prat 0 paging channel data rate byte no_ccp 0 equipage information of CCP 0 = equip , 1 = Not equip int32 base_lat 0 BS latitude int32 base_long 0 BS longitude byte pilot_inc Pilot_PN_Offset value increases byte turbo_encode_flag 0 0 : Turbo Encoding not used 1 : Turbo Encoding used byte reverse_pwr_flag 1 0 : Reverse Link Power Control not used 1 : Rerverse Link Power Contorl used byte reserved_byte 0 7.5.8.2. St_sector_data_type.dg Table 7.5-73 St_sector_data_type Type N a m e default Remarks byte bts_id full BTS Identification byte sector_id full Sector Identification byte EquipPage 0 : Not Equip 1 : Equip byte num_of_cdma_ch CDMA channel insertion number ( 1 ~ 8 ) word16 pilot_pn_offset offset of Pilot Pn from zero shifted PN byte sector_cai_rev 6 CAI (Common Air Interface) revision supported by base station current BS S/W Version 1: IS95(Cellular),J-STD-008(PCS) 2: IS95A(Cellular) 3: TSB74(Cellular) 4,5: IS95B(Cellular,PCS) 6: IS-2000(Cellular,PCS) byte sector_cai_min_rev 1 CAI Minumum revision supported by base station minimum version that BS can support to MS byte call_control_para 0 Upon call congestion, by changing CAI
STAREX-IS BSM Manual Page:845(877)Issue:1.0SMD-011-PMA210 revision, it can increase the number of calls that can be provided. Enable/disable flag of corresponding function. byte reserved_byte[32] 0 7.5.8.3. St_cdmach_data_type.dg Table 7.5-74 St_cdmach_data_type Type N a m e default Remarks byte bts_id full BTS Identification byte cdmach_id full CDMA Channel Identification byte EquipPage 0 : Not Equip 1 : Equip word16 freq_band 1800 Frequency Bandwidth word16 cdmach_num number of cdmach channel byte tce_reserved_4ho 20 Handoff preparatory traffic channel ratio ( %) byte MAX_SCH_ALLOC_RATE 50 Parameter to determine the upper limit of supplemental channel byte reserve[2] byte reserved_byte[34] 0 7.5.8.4. St_sys_param_msg_data_type.dg Table 7.5-75 St_sys_param_msg_data_type Type N a m e default Remarks byte bts_id full BTS Identification byte sector_id full Sector Identification byte cdmach_id full CDMA Channel Identification byte total_zones 2 Number of Registration Zones As the number of location registration to be held for use in Zone_based Registration, it can be saved up to 7EA, and if components more than it reside in ZONE_ LIST, MS removes the oldest component. byte zone_timer 2 When executing Zone-Based Registration, it
STAREX-IS BSM Manual Page:846(877)Issue:1.0SMD-011-PMA210 holds ZONE_LIST, and it is a field to determine duration that an entry in ZONE_LIST is removed from list. That is, the loggest entry from ZONE_LIST is the priority. 000(1 min),001(2 min),010(5 min),011(10 min), 100(20 min),101(30 min),110(45 min),111(60 min) boolean home_reg 1 As Home registration ID, to enable auto location registration, set this field to ‘1’, and to disable that, set that to ‘0’. Boolean mult_sids 0 multiple SID save indicator If several elements that hold different SID in SID_NID_LIST are saved, set that to ‘1’, and in other case, set that to ‘0’. A maximum of 4EA can be saved. Boolean mult_nids 0 multiple NID save indicator If several elements that hold different NID in SID_NID_LIST are saved, set that to ‘1’, and in other case, set that to ‘0’. byte max_sci 3 maximum slot cycle index BS sets the length of allowed maximum slot cycle to SLOT_CYCLE_INDEX. The length of the slot cycle(T) = 2i where i is the slot cycle index. Slot mode operation : method to monitor only 1slot or 2slot assigned to corresponding MS for one slot_cycle boolean for_nid_reg 1 NID roamer location registration indicator boolean for_sid_reg 1 SID roamer location registration indicator boolean power_up_reg 1 Upon personal station registration, if it is registered right before power ON, set that to ‘1’, and if not, set that to ‘0’. boolean power_down_reg 1 Upon personal station registration, if it is registered right before power OFF, set that to ‘1’, and if not, set that to ‘0’.
STAREX-IS BSM Manual Page:847(877)Issue:1.0SMD-011-PMA210 boolean parameter_reg 1 Parameter-change registration indicator byte reg_prd 64 This is used for the calculation of MAX value counted to execute Timer based registration, and Timer based registration is executed when counter reaches REG_COUNT_MAX, and REG_COUNT_MAX is calculated as follows: REG_COUNT_MAX = [ 2reg_prd/4 ] word16 reg_dist 0 registration distance 0 : Personal Stations are not to perform distance based registration. Other than 0: Personal Stations are to perform distance based registration. ref : means 7.8m per unit. byte srch_win_a 7 search window size for the active set byte srch_win_n 9 search window size for the nghbr set byte srch_win_r 10 search window size for the Remaining set byte nghbr_max_age 1 Maximum age for retention of Neighbor set member byte pwr_rep_thresh 4 power control reporting threshold As power control report threshold, set thi snumber before MS measures TOT_FRAMES and BAD_FRAMES and reports corresponding message to BTS to transmit this value to BTS. byte pwr_rep_frames 7(frames) power control reporting frame count. Num fwd tc frames for Total count pwr_rep_frames = 2**(pwr_rep_frames/2) *5 boolean pwr_thresh_enable 0 Threshold report mode indicator if (1) then pwr_rep_thresh = 00000 If MS frame error rate reaches to threshold, it reports statistics. if (0) then it prevents that from its transmitting to MS. Boolean pwr_period_enable 0 Periodic report mode indicator if (0) then it prevents that from its sending periodic power measuremtn msg to to MS. if (1) then MS reports frame error rate at
STAREX-IS BSM Manual Page:848(877)Issue:1.0SMD-011-PMA210 certain intervals. byte pwr_rep_delay 5 power report mode delay(min time between power requests) time from MS report to reattempt. boolean rescan 0 After receiving this system parameter, for reinitialization or system reobtaining, set this fiel to ‘1’, and if not, set that to ‘0’. byte t_add 26 As pilot detection threshold, this is used to determine whether to transmit Pilot Strength Measurement Messag. BTS sets this field as pilot detection threshold. byte t_drop 30 As pilot release threshold, this is used to run Handoff release timer. BS sets this field as pilot release threshold. byte t_comp 5 As a comparative threshold, MS, if candidate group pilot strength is lager than pilot strength of active group by more than this field, transmits Pilot Strength Measurement Message. byte t_tdrop 2 As release timer value, if pilot strength falls below T_DROP, this is timer value until certain activation. This is managed by MS and managed regarding each pilot of active group and candidate group. byte ext_sys_parameter 1 Is there another sys_parameter? byte ext_nghbr_list DCN: 0 PCS:1 BS sets this filed to ‘1’ to indicate transmission of Extended Neighbor List Message. byte GEN_NGHBR_LIST 1 Field to check if BS uses General NGHBR_LIST Msg through Paging Channel Message byte global_redirect 0 Global Service Redirection Message indicator BS, to transmit Global Redirection Message, sets this field to 1, and if not, set that to 0. At areas where both Amps and CDMA are used,
STAREX-IS BSM Manual Page:849(877)Issue:1.0SMD-011-PMA210 only one side should be used ( 0 : not changed 1 : change subject to message ) byte PRI_NGHBR_LIST Field for BS to check the status of Private NGHBR_LIST Msg through Paging Channel Message byte USER_ZONE_ID Field to check the status of User_zone_id Msg through Paging Channel Message byte EXT_GLOBAL_REDIRECT Field to check the status of Ext_global_redirection Msg through Paging Channel Message byte EXT_CHAN_LIST 1 Field to check the status of Ext_channel_list Msg through Paging Channel Message byte reserved_byte[32] 0 7.5.8.5. St_ext_sys_param_msg_data_type.dg Table 7.5-76 St_ext_sys_param_msg_data_type Type N a m e default Remarks byte bts_id full BTS Identification byte sector_id full Sector Identification byte cdmach_id full CDMA Channel Identification byte pref_msid_type 3 Preferred Access Channel Personal Station Identifier Type 010 : IMSI 011 : IMSI and ESN 110 : TMSI(valid TMSI is assigned) IMSI(TMSI not assigned) 111 : TMSI(valid TMSI is assigned) IMSI and ESN(TMSI not assigned) Other value is reserved. word16 mcc 349 Mobile Country Code byte imsi_11_12 99 imsi : International Mobile Station Identity imsi_11_12 is 11th, 12nd digits of imsi. byte tmsi_zone_len 4 TMSI(Temporary Mobile Station Identity) As temporary personal station identifier, it
STAREX-IS BSM Manual Page:850(877)Issue:1.0SMD-011-PMA210 consists of tmsi_zone and tmsi_code. BS sets this field as the number of octet included in tmsi_zone. Byte tmsi_zone[8] 0 Length : 8*tmsi_zone_len byte bcast_index 6 To enable periodic broadcast paging, BS sets this field to ‘1~7’, and if not, set that to ‘0’. byte IMSI_T_SUPPORTED byte P_REV (8bit) 6 Protocol revision level BS sets this filed to ‘00000110’. 0 : 95 1 : JSTD-008 (PCS) 2 : 95A 3 : TSB74 4,5: 95B(based on completion ratio) – DCN, PCS byte MIN_P_REV (8bit) 1 Minimum protocol revision level. Sets protocol revision level that BS can offer to the minimum. Band Class0 : 2 , Band Class1 : 1 byte SOFT_SLOPE (6bit) Included in the formaula used upon Add/Drop of pilot to Active Set. BS sets this filed as unsigned. byte ADD_INTERCEPT (6) The intercept in the inequality criterion for adding a pilot to the Active Set BS sets this filed as complement of 3 in dB unit. byte DROP_INTERCEPT (6) The intercept in the inequality criterion for dropping a pilot to the Active Set BS sets this filed as complement of 3 in dB unit. byte MAX_NUM_ALT_SO (3) Maximum number of alternative service options. BS makes MS set the number that includes Origination Message or Page Response Message to this field. byte RESELECT_INCLUDED System reselection parameters included. If BS includes system reselection parameters,
STAREX-IS BSM Manual Page:851(877)Issue:1.0SMD-011-PMA210 (1) set this field to ‘1’, and if not, set this field to ‘0’. byte EC_THRESH (0 or 5) Pilot power threshold. If RESELECT_INCLUDED is set to ‘1’, BS includes this field and sets that as follows: (pilot_power_threshold + 115) pilot_power_threshold measns pilot power(Ec), and MS performs system reselection if the output of corresponding pilot is below this filed. byte EC_IO_THRESH (0 or 5) Pilot Ec/Ic threshold. If RESELECT_INCLUDED is set to ‘1’, BS includes this filed and sets that as follows: -20 * log10(pilot threshold) pilot threshold means pilot Ec/Io. MS, if Ec/Io is below this field, executes system reselection. byte PILOT_REPORT (1) Pilot reporting indicator. If this field is set to ‘1’, MS reports corresponding pilot information. If it is set to ‘0’, it only reports that to Originationmessage and Page Responsemesage. byte NGHBR_SET_ENTRY_IN FO (1) Neighbor Set access entry handoff information included indicator. If BS includes Neighbor Set access entry handoff information, set this field to ‘1’, and if not, set that to ‘0’. byte ACC_ENT_HO_ORDER (0 or 1) Access entry handoff permitted indicator. If NGHBR_SET_ENTRY_INFO field is ‘0’, omit this field, and if ‘1’, it allows MS access entry handoff while MS, In idle state, executes Mobile Station Order and Message Processing Operation. byte NGHBR_SET_ACCESS_INFO (1) Neighbor Set access handoff included indicator. If BS includes Neighbor Set access handoff or access probe handoffinfo, set this field to ‘1’,
STAREX-IS BSM Manual Page:852(877)Issue:1.0SMD-011-PMA210 and if not, set this field to ‘0’. byte ACCESS_HO (0 or 1) Access handoff permitted indicator. If NGHBR_SET_ACCESS_INFO is ‘0’, omit this field, and if ‘1’, it allows MS access handoff. It sets this filed to ‘1’, and if not, it sets that to ‘0’. byte ACCESS_HO_MSG_RSP (0 or 1) Access handoff permitted for message response indicator. If ACCESS_HO is ‘0’, omit this field, and if ‘1’, it sets this field to 1 and if not it sets this field to 0. byte ACC_PROBE_HO (0 or 1) Access probe handoff permitted indicator. If NGHBR_SET_ACCESS_INFO is ‘0’, omit this field, and if ‘1’ and it allows MS access probe handoff, it sets this field to ‘1’, and if not, set that to ‘0’. byte ACC_HO_LIST_UPD (0 or 1) Access handoff list update permitted indicator. If ACCESS_PROBE_HO is ‘0’, omit this field, and if ‘1’, and it allows update of access handoff list, it sets this field to ‘1’, and if not, it sets that to ‘0’. byte ACC_PROBE_HO_OTHER_MSG (0 or 1) Access probe handoff permitted for messages other than the Origination Message and the Page Response Message. If ACCESS_PROBE_HO is ‘0’, it omits this field, and if ‘1’, and it allows access probe handoff, it sets this field to ‘1’, and if it allows that only to Origination Message and Page Response Message, set this field to ‘0’. byte MAX_NUM_PROBE_HO (0 or 3) Maximum number of times that the mobile station is permitted to perform an access probe handoff. If ACCESS_PROBE_HO is ‘0’, omit this field, and if ‘1’, set the maximum number so that MS executes access probe handoff. byte BROADCAST_GPS_ASST (1) Broadcast GPS Assist Indicator. If BS supports Broadcast GPS Assist, set this field to ‘1’, or not, set that to ‘0’.
STAREX-IS BSM Manual Page:853(877)Issue:1.0SMD-011-PMA210 byte QPCH_SUPPORTED (1) 1 Quick Paging Channel Supported Indication. If BS supports Quick Paging Channel operation, set this field to ‘1’, or not, set that to ‘0’. byte NUM_QPCH (0 or 2) 1 Number of Quick Paging Channels. If QPCH_SUPPORTED is ‘0’, omit this field, and if ‘1’, BS sets this field as many as the number of Quick Paging Channel over CDMA Channel. BS will not set this field to ‘0’. byte qpch_rate 0 data rate over radio section Range : 0~1(0:9600bps, 1:4800bsp) Same as data_rate of qpch_data byte QPCH_POWER_LEVEL_PAGE (0 or 3) Quick Paging Channel paging indicator transmit power level. If QPCH_SUPPORTED is ‘0’, it omits this field, and if ‘1’, BS sets this field in accordance with Table 3.7.2.3..2.13-3. byte QPCH_CCI_SUPPORTED (0 or 1) Quick Paging Channel configuration change indicator supported If QPCH_SUPPORTED is ‘0’, omit this field, and if ‘1’, and BS supports configuration change indicators, it sets this field to ‘1’, or not it sets this field to ‘0’. byte QPCH_POWER_LEVEL_CONFIG (0 or 3) Quick Paging Channel configuration Change indicator trasmit power level. If QPCH_CCI_SUPPORTED is ‘0’, it omits this field, and if ‘1’, it sets this field in accordance with Table 3.7.2.3.2.13-3. byte SDB_SUPPORTED (1) Short Data Burst supported indicator. If MS can send Short Data Burst, BS sets this field to ‘1’, or not sets that to ‘0’. byte MAC_CF_SUPPORTED (1) MAC (Medium Access Control) control function supported indicator. If BS supports MAC control functions, BS sets this field to ‘1’, or not, it sets that to ‘0’. byte RLGAIN_TRAFFIC_PILOT Gain adjustment of the Reverse Traffic Channel relative to the Reverse Pilot Channel for Radio
STAREX-IS BSM Manual Page:854(877)Issue:1.0SMD-011-PMA210 (6) Configurations greater than 2. BS sets this field with reverse traffic channel power value. byte reserved_byte[33] 0 7.5.8.6. St_nghbr_list_msg_data_type.dg Table 7.5-77 St_nghbr_list_msg_data_type Type Name Default Remarks byte bts_id full BTS Identification byte sector_id full Sector Identification byte nghbrs_in_msg nghbr_list number held by one sector byte nghbr_srch_mode Parameter included in GNLM byte use_timing If Nghbr Base station transmits pilot in DTX mode, it indicates the use of timming information. byte global_timing_incl When use_timing is set to ‘1’, this indicates whether all neighbors use the same timing information. byte global_tx_duration As Pilot Transmission duration of Neighbor Base Station, it is valid only if all neighbors use the same value. byte global_tx_period Valid only if all neighbors use the same value with DTX cycle of Pilot Transmission of Neighbor Base Station. byte srch_offset_incl byte nghbr_config[ ] When the value of this field is as follows: 000 : upon handoff The personal station shall begin monitering the Paging Channel of the new base station, using the same Code Channel. 001 : The personal station shall begin monitergin the primary paging channel of the new base station. 010 : The nghbr base station has a different number of frequencies having Paging Channels as
STAREX-IS BSM Manual Page:855(877)Issue:1.0SMD-011-PMA210 the current station. word16 nghbr_pn[ ] pilot_pn_offset pf sector word16 nghbr_sid[ ] system identification value of BS to which a sector belongs word16 nghbr_nid[ ] Network identification value of BS to which corresponding sector belongs word16 nghbr_base_id[ ] base_id value of neighbor BS byte nghbr_msc_id[] msc_id value byte nghbr_bsc_id[] bsc_id value byte nghbr_bts_id[ ] bts_id value Byte nghbr_sect_id[ ] Sector id value byte nghbr_msc_type[] 0 0 : local MSC 1 : remote MSC Necessary to determine Soft, Hard H/O upon H/O. For local MSC, Soft H/O is possible, and for remote MSC, Hard H/O is attempted. byte nghbr_bsc_type[] 0 0 : local BSC 1 : remote BSC Necessary to determine Soft, Hard H/O upon H/O. For local MSC, Soft H/O is possible, and for remote MSC, Hard H/O is attempted. byte nghbr_beacon_pn[] 0 indicator byte search_priority[] the search priority for the Pilot Channel corresponding to NGHBR_PN. Value Search Priority Value Search Priority 00 Low 01 Medium 02 High 11 Very high byte freq_incl[] Frequence included indicator. That is, if this field is 1, upon handiff, it uses channels on nghbr_band and nghbr_freq and if 0 , it uses current channel as is. byte nghbr_band[] If freq_incl field is set to ‘1’ band class of candidate frequency 800Mhz: 0 1800Mhz : 4 = domestic 1900Mhz: 1 = overseas
STAREX-IS BSM Manual Page:856(877)Issue:1.0SMD-011-PMA210 word16 nghbr_freq[] If freq_incl field is set to ‘1’ this field to the CDMA channel Number freq_incl field is set to ‘0’ disregarded byte timing_incl[] B : MS moves at 2FA -> 5FA B is the value on 3,4,5FA. It is held by 5FA BS. If each Nghbr Sector transmits pilot in DTX mode, it indicates timing information. byte nghbr_tx_offset[] Transmission start offset value of each nghbr sector byte nghbr_tx_duration[] Pilot Transmission time value of each Nghbr Sector byte nghbr_tx_period[] Pilot DTX cycle value of each Nghbr Sector. byte srch_set[] To indicate the status of each Nghbr Pilot. byte add_pilot_rec_incl [] Indicates the status of additinal record regarding each Nghbr Pilot. byte nghbr_pilot_rec_type [] Additional Record Type(Information Type) Identification of each Nghbr Pilot byte td_pilot_otd_pwr[] OTD Transmit Power Level of each Nghbr Pilot byte srch_offset_nghbr[] Search Window offset value regarding each Neighbor Pilot byte access_entry_ho[] Should be repeated as many as NGHBR_SET_SIZE. Access entry handoff permitted when entering the System Access State. If before MS receives message through Paging Channel in idle state, and for response, it transits to System Access State, BS sets this field to 1 or not it sets that to 0 if access entry handoff is allowed. The order of ACCESS_ENTRY_HO is the same as that of Neighbor List Message, Extended Neighbor List Message or General Neighbor List Message. byte access_ho_allowed[] Should be repeated as many as NGHBR_SET_SIZE. Access handoff and access probe handoff
STAREX-IS BSM Manual Page:857(877)Issue:1.0SMD-011-PMA210 permitted for the corresponding pilot while in the System Access State. If MS is in System Access State, BS sets this field to 1 or not it sets that to 0 if MS access handoff or access probe handoff is allowed. The order of ACCESS_HO_ALLOWED is the same as that of Neighbor List Message, Extended Neighbor List Message or General Neighbor List Message. byte reserved_byte[34] 0 7.5.8.7. St_Qos_param_data Table 7.5-78 St_Qos_param_data Type N a m e default Remarks byte bts_id full byte max_sch_rate byte reserved_byte[106] 72 + 34 7.5.9. BSP Layer 7.5.9.1. St_pwr_mgt_param_type.dg Table 7.5-79 St_pwr_mgt_param_type Type N a m e default Remarks byte sector_id full Sector Identification (0 ~ 2) byte cdmach_id full CDMA Channel Identification(0 ~ 7) byte T_rx_filter 0 Received total power filter update rate. Ms units, 1/2 step, 20/2 ~ 255 range byte G_rx_filter 0 Received total power filter delay contant. 1/256 step. 0/256 ~ 255/256 range byte G_tx_filter 0 Transmit power filter delay constant 1/256 step. 0/256 ~ 255/256 range
STAREX-IS BSM Manual Page:858(877)Issue:1.0SMD-011-PMA210 byte Gh_tx_filter 0 Pilot Channel gain int16 R_tx_pilot 0 Minimum trasmit pilot power to transmit total power ratio for sector j. 1/16 step, -255/16 ~ 0/16 byte flnk_call_blk_thresh 0 call blocking threshold. Nuit : % byte flnk_handoff_blk_thresh 0 Handoff blocking threshold. Unit : % byte flnk_gain_scaling_thresh 0 traffic gain scaling threshold byte rlnk_call_blk_thresh 0 call blocking threshold byte rlnk_handoff_blk_thresh 0 handoff blocking threshold byte A_tx_max 0 Maximum transmit gain byte delta_A_tx 0 Maximum transmit gain rate of chagne 1/16 step. 1/16 ~ 255/16 range byte K_level 0 Breathing equation level byte K_slope 0 Breathing equation level 1/128 step, 1/128 ~ 128/128 range byte K_delta 0 Breathing equation level 1/16 step, 0/16 ~ 255/16 range byte delta_T 0 General update rate, ms unit byte P_tx_max 0 Maximum transmit total power. DBmW unit byte initial_calib 1 0: Overhead_ch Calibration Enabled 1: Blossoming Enabled byte periodic_calb 1 0: Overhead_ch Calibration Enabled 1: TPTL Calibration Enabled byte breathing_flag 0 0: Breathing Disable 1: Breathing Enable byte pwr_est_flag 0 0: Forward/Reverse Link Power estimation Enabled 1: Forward/Reverse Link Power estimation Disabled byte overpwr_limit 1 0: HPA Over Power Limitation Disabled 1: HPA Over Power Limitation Enabled byte flnk_cap_limit 0 0: Forward Link Excess Capacity Limitation Disabled 1: Forward Link Excess Capacity Limitation
STAREX-IS BSM Manual Page:859(877)Issue:1.0SMD-011-PMA210 Enabled byte rlnk_cap_limit 0 0: Reverse Link Excess Capacity Limitation Enabled 1: Reverse Link Excess Capacity Limitation Disabled byte reserved_byte[33] 0 7.5.9.2. St_txms_param_data.dg Table 7.5-80 St_txms_param_data Type N a m e default Remarks byte sector_id full Sector Identification byte cdmach_id full CDMA Channel Identification word16 ovhdch_erp 170(1.7W) Overhead Channel Effectiver Radiation Power and 170 means 1.7W(32dBm). word16 delta_erp No-use ERP calibration value word16 delta_sign No-use Calibration value symbol (0: PLUS, 1:MINUS) byte reserved_byte[32] 0 7.5.9.3. St_tic_data_type.dg Table 7.5-81 St_tic_data_type Type N a m e default Remarks byte sector_id full Sector Identification byte cdmach_id full CDMA Channel Identification byte primary_function 1 word16 tx_gain 0x900(2304) Overall sector transmit gain setting byte rx_a_atten No-use 255 Noise attenuator setting for the receiver A paths in 0.5 dB steps(0~63.5dB) byte rx_b_atten No-use 255 Noise attenuator setting for the receiver B paths in 0.5dB steps(0~63.5dB)
STAREX-IS BSM Manual Page:860(877)Issue:1.0SMD-011-PMA210 byte tx_atten No-use 255 Noise attenuator setting for the transmit paths in 0.5 dB steps(0~63.5dB) boolean breathing No-use 0 Whether cell power “breathing” enabled. byte expected_db No-use 16 Cell breathing threshold in db. word16 power_upper_bound No-use 20 TICrecerse power threshold upper bound word16 power_lower_bound No-use 15 TICrecerse power threshold upper bound byte reserved_byte[33] 0 7.5.9.4. St_acc_param_data_type.dg Table 7.5-82 St_acc_param_data_type Type N a m e default Remarks byte sector_id full Sector Identification(0 ~ 2) byte cdmach_id full CDMA Channel Identification(0 ~ 7) byte pc_id full Paging Channel Identification(0 ~ 7) byte nom_pwr 0 Power control value for Open loop Power Control byte init_pwr 0 Initial power offset for access Power control value for Open Loop Power Control for MS Access Channelinitial transmission byte pwr_step 3 Power increment Power amount value increased by MS between continuous probes at Access Probe Sequence byte num_step 6 Number of access probe As the number of Access Probe, this is the value that is smaller by 1 than maximum access probe number transmitted from one Access Probe Sequence. byte max_cap_sz 3 Max Access Channel message capsule size As value that indicates maximum access channel message capsule size, BS sets this field to value that is smaller by 3 than access channel frame number. byte pam_sz 3 Access Channel preamble length As the length of access channel preamble, BS sets value that is smaller by 1 than access
STAREX-IS BSM Manual Page:861(877)Issue:1.0SMD-011-PMA210 channel frame number transmitted from access 채channel preamble. byte psist_0_9 0 As value on access overload grade(0~9), if access pverload grade allows 0~9 MS to transmit request to access channel, BS sets that as continuous value to use this field and if not, it sets that to ‘111111’. byte psist_10 0 If test MS with access overlaod grade of 10 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte psist_11 0 If emergency MS with access overlaod grade of 11 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte psist_12 0 If MS with access overlaod grade of 12 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte psist_13 0 If MS with access overlaod grade of 13 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte psist_14 0 If MS with access overlaod grade of 14 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte psist_15 0 If MS with access overlaod grade of 15 is allowed to transmit requests to access channel, BTS sets that as continuous value to use this field, and if not, it sets that to ‘111’. byte msg_psist 0 As continuous transformer used to attempt accesschannel for message transfer, MS multiples [2-MSG_PSIST] to transmission probability.
STAREX-IS BSM Manual Page:862(877)Issue:1.0SMD-011-PMA210 byte reg_psist 0 MS multiplies [2-MSG_PSIST] to transmission probability. byte probe_pn_ran 0 As a field related to time random for access channel probe, BS sets value of 0~9 so that the range of time random value is 2PROBE_PN_RAN-1 chip. byte acc_tmo 6 Answer time excessive value. byte probe_bkoff 0 Backoffrange of accesws channel probe byte bkoff 1 As access channel probe sequence backoff range, BS sets this field with the value that is lower by 1 than the number of slots that are delayed owing to backoff. byte max_req_seq 2 BS should set that with value greater than 0. byte max_rsp_seq 2 BS should set that with value greater than 0. byte auth 0 If MS includes standard authentication data inaccess channel nmessage, BTS sets this field to ‘01’, and if not it sets that to ‘00’. word32 rand 0 If auth field value is ‘01’, BTS sets this field to random attempt value to be used upon authentication and if different value, it is omitted. byte nom_pwr_ext 0(DCN) 1(PCS) extended nominal transmit power open loop power stimate: -24dB ~ -9dB if this field is ‘1’, -8dB ~ 7dB if this field is ‘0’ byte reserved_byte[35] 0 7.5.9.5. St_pc_global_redirect_msg_type.dg Table 7.5-83 St_pc_global_redirect_msg_type Type N a m e default Remarks byte sector_id full Sector Identification word16 redirect_accolc 65535 redirect ACCess OverLoad Class indicator byte return_if_fail 1 1: If personal system fails to redirect to other system, it allows entry to original
STAREX-IS BSM Manual Page:863(877)Issue:1.0SMD-011-PMA210 system. 0 : No return byte delete_tmsi 0 Delete TMSI Indicator byte EXCL_P_REV_MS Indicator to apply Global Service redirection Message(GSRM) to MOB_P_REV 6 or above. byte REDIRECT_P_REV_INCL Indicator to divide the application scope of EGSRM according to MOB_P_REV value. byte EXCL_P_REV_INCL Indicator to exclude the application of GSRM regarding MS that has corresponding MOB_P_REV. byte REDIRECT_P_MIN 6 MOB_P_REV Minimum value of MS that will apply and exclude GSRM byte REDIRECT_P_MAX 6 MOB_P_REV Maximum value of MS that will apply and exclude GSRM byte record_type 2 00000001: Redirection to an analogue system as defined in IS95 00000010: Redirection to an CDMA system as defined in IS95 byte record_len 3 The base station shall set this field to the number of octets in the type-specific fields of this redirection record. Word16 expected_a_sid 0 If Base station has personal station redirected to specific system, insert sid# of specific system. 0 : no use of specific system byte ignore_cdma 1 1: when personal station is redirected to analog system, CDMA Capability Msg is disregarded. 0: if personal station receives CDMA Capability Msg, it may not receive service from redirected system. Byte sys_ordering 3 Determines where to redirect (see STD-008 p 3-175) byte band_class 0(DCN) 1(1900Mg If record_type is ‘00000010’ for redirection, Band class of redirected
STAREX-IS BSM Manual Page:864(877)Issue:1.0SMD-011-PMA210 z) 4(1800Mhz) system should be filled. 800Mhz: 0 1800Mhz : 4 = domestic 1900Mhz: 1 = overseas Word16 expected_sid 0 If Base station has personal system redirected to other system, this sets this field to SID of redirected system. Word16 expected_nid 0 If Base station has personal system redirected to other system, this sets this field to NID of redirected system. Byte num_chans 0 The number of occurence of cdma_chan FIELD word16 cdma_chan[10] 0 For each CDMA Channel on which the personal station is to attempt to acquire a CDMA system, the base station shall include one occurrence of this field specifying the associated CDMA Channel number. byte reserved_byte[34] 0 7.5.9.6. St_bts_cfg_type Table 7.5-84 St_bts_cfg_type Type N a m e default Remarks byte dummy_key full BYTE OVHD_MODE 0 0: Dynamic 1: Fix byte pa_type 2 RF type 0: PA_NEQ 1: HPA 2: LPA(MPD) 3:LPA(MILCOM) byte ant_type 0 ~ 3 0 : Standard 1 : OTA 2 : DAI 3 : DAI_OAI BYTE TX_DIVERSITY 0 ~ 1 0: Not Tx Diversity 1: Tx Diversity byte rx_duplex 0 ~ 1 0: Simplex_antenna 1: Duplex_antenna byte rx_diversity 0 ~ 1 current ‘1’ 0: Non_Diversity 1: Diversity rx_diversity:0, St_chip_config_data diversity_scale_2000:0 byte lna_type 0 : Not_Equip 1 : Equip
STAREX-IS BSM Manual Page:865(877)Issue:1.0SMD-011-PMA210 When MIC C, D are used for subway, this file is set to ‘0’. byte ttrf_type[12] 0 0 : Not_Equip, 1 : Equip, 2 : Equip and Blocked. 4EA per sector among 12EA. byte fa_use 0: 1FA-6Sec 1; 2FA-3Sec byte risa_eqp 1 0: not equip, 1: equip byte reserved_byte[34] 0 Reserved Field 7.5.9.7. St_dru_chc_data_type Table 7.5-85 St_dru_chc_data_type Type N a m e default Remarks byte proc_id full 0~9 Processor Identification byte EquipPage 0:Not Equip 1:Equip BYTE CHC_STATE[MAX_CHC] Not_equip/Block/Unblock BYTE CHIP_STATE[MAX_CHC][MAX_CHIP] 0 Chip status per channel card Not_equip/Block/Unblock byte reserved_byte[33] 0 7.5.9.8. St_chip_config_data Table 7.5-86 St_chip_config_data Type N a m e default Remarks byte DUMMY full 0 byte num_chip_per_chc 2 word16 sector_gain[MAX_SECTORS] 208 sector gain(Normal Path) Range : 0~4095 word16 tx_div_sector_gain[MAX_SECTORS] 0 sector gain(Tx Diversity Path) Range : 0~4095 word16 sector_timing_adv[MAX_SECTORS] 320 Timing advance (Normal Path) Max : 1264
STAREX-IS BSM Manual Page:866(877)Issue:1.0SMD-011-PMA210 word16 tx_div_timing_adv[MAX_SECTORS] 0 Timing advance (Tx Diversity Path) Max : 1264 byte sector_tx_io_format 0 (6 path or below) 2 (3 path or below) 0:tx_output_chipx1, 1: tx_output_chipx1_fir 2: tx_output_chipx2_fir word16 cell_radius 511 in units of PN chip byte rev_input_format 1 (6 path or below) 0 (3 path or below) 0:chipx8_rate_input, 1: chipx2_rate_input byte ant_enable[MAX_ANTENNAS] MAX_ANTENNAS = 12 byte ant_source[MAX_ANTENNAS] ? byte rev_cell_mode ? byte max_rach_fraction 10 MAX=32 word32 max_rach_separation 80 MAX=512 byte max_reach_fraction 10 MAX=32 word32 Max_reach_separation 80 MAX=512 byte enable_srch_win_adj 1 byte max_finger_per_chan95 6 MAX=6 byte max_finger_per_chan2000 8 MAX=8 byte usefully_rate_likely No-use 1 byte finger_thresh_adj_enable No-use ? byte channel_finger_limit No-use ? byte csm_mode 1 0:non_backward_compatible, 1: backward_compatible byte diversity_scale_2000 3 Range : 0~3 int min_search_energy_rach No-use 150 int min_search_energy_rc1 No-use 200 int min_search_energy_rc2 No-use 200 int min_search_energy_rc3 No-use 40 int min_search_energy_rc4 No-use 40 int min_search_energy_rc5 No-use int min_search_energy_rc6 No-use int override_search_energy_rach No-use
STAREX-IS BSM Manual Page:867(877)Issue:1.0SMD-011-PMA210 int override_search_energy_rc1 No-use int override_search_energy_rc2 No-use int override_search_energy_rc3 No-use int override_search_energy_rc4 No-use int override_search_energy_rc5 No-use int override_search_energy_rc6 No-use word16 turbo_dtx_threshold No-use 240 word16 conv_dtx_threshold No-use 392 byte bin_size No-use byte integration_period No-use word16 srch_win_len[MAX_SECTORS] 1(traffic) Range : 1~32 byte reserved_byte[32] 0 7.5.9.9. St_hpbch_data Table 7.5-87 St_hpbch_data Type N a m e default Remarks BYTE SECTOR_ID 0 ~ 2 BYTE PILOT_GAIN pilot channel gain BYTE NUM_CDMA_CH number of cdma channel of hopping beacon WORD16 CDMA_FREQ[MAX_CDMACH] CDMA Channel Number for Hopping Beacon. BYTE BEACON_TX_OFFSET[MAX_CDMACH] Pilot beacon transmit time offset . Reading the value from Neighbor_list_msg_data.dg for setting. BYTE BEACON_TX_DURATION[MAX_CDMACH] Pilot beacon transmit time duration . Reading the value from Neighbor_list_msg_data.dg and setting. BYTE BEACON_TX_PERIOD[MAX_CDMACH] Pilot beacon transmit time . Reading the value from Neighbor_list_msg_data.dg and setting. byte reserved_byte[32] 0
STAREX-IS BSM Manual Page:868(877)Issue:1.0SMD-011-PMA210 7.5.9.10. St_pich_data_type (Pilot Channel) Table 7.5-88 St_pich_data_type (Pilot Channel) Type N a m e default Remarks BYTE SECTOR_ID 0 ~ 2 BYTE CDMACH_ID 0 ~ 7 BYTE PROC_ID PILOT CHANNEL PROCESSOR NUMBER (RCP) BYTE SLOT PILOT CHANNEL SLOT NUMBER BYTE PILOT_GAIN 234 pilot channel gain. in unit of dB BYTE PILOT_TD_GAIN piot tx_diversity channel gain. byte reserved_byte[34] 0 7.5.9.11. St_synch_data_type (Sync Channel) Table 7.5-89 St_synch_data_type (Sync Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE PROC_ID SYNCH PROCESSOR NUMBER (RCP) BYTE SLOT SYNCH SLOT NUMBER BYTE SYNC_GAIN 159 sync channel gain. in unit of dB byte reserved_byte[35] 0 7.5.9.12. St_pch_data_type (Paging Channel) Table 7.5-90 St_pch_data_type (Paging Channel) Type N a m e default Remarks byte sector_id full 0 ~ 2 byte cdmach_id full 0 ~ 7 byte pc_id full 0 ~ 6 byte equipage Actual pc equip state byte num_ac Access channel number per Paging Channel Access Para AccChan
STAREX-IS BSM Manual Page:869(877)Issue:1.0SMD-011-PMA210 byte proc_id Paging channel processor number (RCP) byte slot Paging channel slot number BYTE PC_GAIN 217 Paging channel tx gain. in unit of dB byte frame_duration 2 Packet frame size. (5ms/20ms) Range : 0~4 (2:20ms) byte data_rate 0 data rate. Range : 0~1(0:9600bps, 1:4800bsp) byte encoding_rate No-use 1 Convolutional channel coding rate. byte reserved_byte[34] 0 7.5.9.13. St_qpch_data_type (Quick Paging Channel) Table 7.5-91 St_qpch_data_type (Quick Paging Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE QPCH_ID full 0 ~ 2 byte equipage BYTE PROC_ID QPCH PROCESSOR NUMBER (RCP) BYTE SLOT QPCH SLOT NUMBER BYTE INDICATOR_GAIN Paging indicator part gain BYTE CCI_GAIN CCI(Configuration Change Indicator) Gain byte frame_duration 2 Packet frame size. (5ms/20ms) byte data_rate 0 data rate. byte encoding_rate No-use Convolutional channel coding rate. byte reserved_byt[34] 0 7.5.9.14. St_ach_data_type (Access Channel) Table 7.5-92 St_ach_data_type (Access Channel) Type N a m e default Remarks
STAREX-IS BSM Manual Page:870(877)Issue:1.0SMD-011-PMA210 BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE PC_ID full 0 ~ 6 BYTE AC_ID full 0 ~ 31 byte equpage BYTE PROC_ID ACCESS CHANNEL PROCESSOR NUMBER (RCP) BYTE SLOT ACCESS CHANNEL SLOT NUMBER. byte pam_int_prd No-use 2 As integer between 2~4(Walsh symbols), 8-pam _int_prd(Walsh symbol), when detecting access probe preamble, is dector integration period. word16 pam_win_len No-use 1800 As searching window size when detecting access probe preamble, it is integer between 6~4048(1/8 chip/unit). word16 pam_pn_offset No-use 1920 As preamble searching start pn offset value of access probe, it is integer between 8 ~ (4092 - pam_win_ len)(1/8 PN chip/unit). byte mul_int_prd No-use 6 As integer between 2 ~ 6(Walsh symbols), 8-mul_int_prd(Walsh symbol) is the integration period of detector when searching multipathingredients while modulating access probe data protion signal. byte mul_win_len No-use 128 As searching window size when searching nultipath ingredients while modulating access probe data protion signal, it is integer between 96~4048(1/8 PN chip/unit), which should be lower than pam_win_len. byte multipath_gain No-use 1 factor used to decide whether to move the finger during demod stage based on the result of multipath search word16 nolock_thresh No-use 156 As threshold, it is integer between 0~65535. word16 lock_thresh No-use 156 As threshold, it is integer between 0~65535. word16 combine_thresh No-use 156 Threshold used to enable combining of a finger when it is in LOCK state. WORD16 SRCH_START_OFFSET 0 Search Start Offset. in units of chipx8 Range : 0~4096(Chipx8 units)
STAREX-IS BSM Manual Page:871(877)Issue:1.0SMD-011-PMA210 WORD16 SRCH_WIN_SIZE 4(access) Search Window Size. in units of 64PN chip. Range : 1~32(64 PN Chips units) byte reserved_byte[35] 0 7.5.9.15. St_apich_data_type (Auxiliary Pilot Channel) Table 7.5-93 St_apich_data_type (Auxiliary Pilot Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE PROC_ID APICH PROCESSOR NUMBER (RCP) BYTE SLOT APICH SLOT NUMBER byte reserved_byte[32] 0 7.5.9.16. St_bcch_data_type (Broadcast Channel) Table 7.5-94 St_bcch_data_type (Broadcast Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE BCCH_ID full 0 ~ 6 byte equipage BYTE PROC_ID Broad CHANNEL PROCESSOR NUMBER (RCP) BYTE SLOT Broad CHANNEL SLOT NUMBER byte TX_GAIN byte SPREADING_RATE byte OTD byte SR1_BCN byte SR1_BRAT byte SR1_NON_OTD_INCL byte SR1_CDMA_FREQ_NON_OTD byte SR1_BCCH_RATE_NON_OTD
STAREX-IS BSM Manual Page:872(877)Issue:1.0SMD-011-PMA210 byte SR1_OTD_INCL byte SR1_CDMA_FREQ_OTD byte SR1_BCCH_RATE_OTD byte SR3_CAP_IND byte SR3_CDMA_FREQ byte SR3_BCN byte SR3_BRAT byte frame_duration Packet frame size. (5ms/20ms) byte data_rate data rate. byte radio_configuration (encoding_rate) Convolutional channel coding rate. Radio configuration byte reserved_byte[34] 0 7.5.9.17. St_cpch_data_type (Common Power Control Channel) Table 7.5-95 St_cpch_data_type (Common Power Control Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE CPCH_ID full 0 ~ 6 byte equipage BYTE PROC_ID CPCH PROCESSOR NUMBER (RCP) BYTE SLOT CPCH SLOT NUMBER byte frame_duration Packet frame size. (5ms/20ms) byte data_rate data rate. byte radio_configuration (encoding_rate) Convolutional channel coding rate. Radio configuration byte reserved_byte[32] 0
STAREX-IS BSM Manual Page:873(877)Issue:1.0SMD-011-PMA210 7.5.9.18. St_cach_data_type (Common Assignment Channel) Table 7.5-96 St_cach_data_type (Common Assignment Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE CACH_ID full 0 ~ 6 byte equipage BYTE PROC_ID CACH PROCESSOR NUMBER (RCP) BYTE SLOT CACH SLOT NUMBER byte frame_duration Packet frame size. (5ms/20ms) byte data_rate data rate. byte radio_configuration (encoding_rate) Convolutional channel coding rate. Radio configuration byte reserved_byte[32] 0 7.5.9.19. St_fccch_data_type (Forward Common Control Channel) Table 7.5-97 St_fccch_data_type (Forward Common Control Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE FCCCH_ID full 0 ~ 6 byte equipage BYTE PROC_ID FCCCH PROCESSOR NUMBER (RCP) BYTE SLOT FCCCH SLOT NUMBER byte frame_duration Packet frame size. (5ms/20ms) byte data_rate Data rate. byte radio_configuration (encoding_rate) Convolutional channel coding rate. Radio configuration byte reserved_byte[32] 0
STAREX-IS BSM Manual Page:874(877)Issue:1.0SMD-011-PMA210 7.5.9.20. St_each_data_type (Enhanced Access Channel) Table 7.5-98 St_each_data_type (Enhanced Access Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE FCCCH_ID or CACH_ID full 0 ~ 6 BYTE EACH_ID full 0 ~ 31 byte equipage BYTE DUPLEX_ID 0 ~ 1 Redundancy BYTE PROC_ID EACH PROCESSOR NUMBER (RCP) BYTE SLOT EACH SLOT NUMBER BYTE reserved_byte[33] 0 7.5.9.21. St_rccch_data_type (Reverse Common Control Channel) Table 7.5-99 St_rccch_data_type (Reverse Common Control Channel) Type N a m e default Remarks BYTE SECTOR_ID full 0 ~ 2 BYTE CDMACH_ID full 0 ~ 7 BYTE FCCCH_ID or CACH_ID full 0 ~ 6 BYTE RCCH_ID full 0 ~ 31 byte equipage BYTE PROC_ID EACH PROCESSOR NUMBER (RCP) BYTE SLOT EACH SLOT NUMBER BYTE reserved_byte[34] 0 7.5.9.22. St_sector_cdmach_data_type Table 7.5-100 St_sector_cdmach_data_type type Name default Remarks byte sector_id full
STAREX-IS BSM Manual Page:875(877)Issue:1.0SMD-011-PMA210 byte cdmach_id full byte ocns_enable 0 0: Ocns Enabled 1: Ocns Disabled byte num_of_ocns_ch 0 Ocns Call Number ( 0 ~ 20 ) byte ocns_test_data 5 Test Data Rate ( 0 ~ 5 ) ( B, 1/8, 1/4, 1/2, 1, V) word16 ocns_so 0x801f Service Option [ Markov(8002, 801f), LB(2,9) ] byte block_state 0 0: Unblock, 1: Block If current sector FA is ‘block’, MS regards no FA residing in channel list. byte reserved_byte[32] 0 7.5.9.23. St_HW_reset_type Table 7.5-101 St_HW_reset_type type Name default Remarks byte dummy_key 0 byte shlf_pwr[20] CSD : BSBB(0), RCBB0(1), RCBB1(2), RCBB2(3), RCBB3(4) COU : BCCB0(5), BCCB1(6), BCCB2(7), BCCB3(8) 9 ~ 19 : Reseved byte bspa[4][2] 0 byte lica[4] 0 byte aria[4] 0 byte bada 0 byte risa 0 byte bota 0 byte dran 0 byte rcpa[4][2] 0 byte mcpa[4][10] 0 byte buda[4][6] 0 byte paca[4] 0 byte pa[6][6] 0 byte bcra[2] 0
STAREX-IS BSM Manual Page:876(877)Issue:1.0SMD-011-PMA210 byte bppa byte reserved_byte[23] 0 7.5.9.24. St_Chip_pwr_cntl_para_data( 0:FCH , 1:SCH, 2:SCCH, 3:DCCH ) Table 7.5-102 St_Chip_pwr_cntl_para_data Type N a m e default Remarks byte Dummy 0 byte Channel_pwr[MAX_CH_TYPE(4)] 224 Forward Traffic Channel Tx Power 0(-63.5dB) ~ 127(0dB). 0.5dB step byte Data_gain No-use Data Gain to be added to the Channel Power -31.75dB ~ 31.75dB. 0.5dB step byte Pwr_cntl_gain No-use Power Control Sub-channel Gain to be added to the Channel. –31.75dB ~ 31.75dB, 0.5dB step. byte Min_gain[MAX_CH_TYPE(4)] 150 Forward Traffic Channel Power Minimum Value byte max_gain[MAX_CH_TYPE(4)] 224 Forward Traffic Channel Power Maximum Value byte step_up_size 4 Forward Traffic Channel Power Control step up size. 0(0dB) ~ 15(3.75dB), 0.25dB step byte step_dn_size 4 Forward Traffic Channel Power Control step down size. 0(0dB) ~ 15(3.75dB), 0.25dB step byte fpc_punc_mode 0 FPC(Forward Power Control) Puncture Mode. Same as fpc_mode of St_pwr_cntl_para_type byte rpc_punc_mode 0 RPC(Reverse Power Control) Puncture Mode. byte pwr_cntl_set_point 219 RPC Set Point(Threshold) 0(-63.75dB) ~ 255(0dB), 0.25dB step byte pwr_cntl_pattern 3 Power Control Up/Down pattern to be used when no fingers are combining byte Reserved_byte[32]
STAREX-IS BSM Manual Page:877(877)Issue:1.0SMD-011-PMA210 7.6. Abbreviations Table 7.6-1 Abbreviations in IS-2000 system Abbreviations Description ABID Alarm Buffer Inerface Daughter board ACBB AAL 2 Control Back Board ALP ATM Low speed subs. Processor AUBB ATM low speed sUbscriber Back Board AXBB ATM Switch Back Board BABB BTS ATM Network BackBoard BADA Base Station Analyze & Diagnostic Assembly BANU BTS ATM Network Unit BCRA BTS Cell Router Board Assembly BMS Base station Management System BPPA BTS Peripheral Processor Board Assembly BSC Base Station Controller BSM Base Station Manager BSS CAN Network control Processor BSPU BTS Signaling Processor Unit BTGU BTS Timing Generation Unit BTS Base Station Tranceiver Subsystem BUDA Base Station Sector conversion&Up/Down Converter Assembly CAN Central ATM Network CBBB Control and Protocol Block BackBoard CCP Call Control Processor CDMB Configuration & Data Management Block CNP CAN Network control Processor CRP Cell Router Control Processsor DBPA Digital BaseBand Processing Board Assembly DCBU Digital Channel Bank Unit DCIB Data Communication Interface Block FER Fault Error Rate
STAREX-IS BSM Manual Page:878(877)Issue:1.0SMD-011-PMA210 FERA Fast Ethernet Routing Board Assembly FETD Fast Ethernet Termination Board Assembly GPS-D global Positioning System - Distribution GPS-R Global Positioning System - Receiver GUI Graphic User Interface HDLC High-level Data Link Control LICA Line Interface Controller Board Assembly LPA Linear Power Amplifier MAC Medium Access Control MMI Man Machine Interface NCP Network Control Processor OCNS Orthogonal Channel Noise Simulator PACA Power Adjustment Control Assembly PCP Protocol Control Processor RCCA Radio channel Processing Board Assembly RCMD Remote Control Module Daughter Board RNS Radio Network Subsystem SEBB Selecter bank Back Board SMP Selector bank Master Processor STMB Status Management Block TRMB TRouble Mamagement Block UCPA Universal Contrl Processor Board Assembly VCBB VoCoder bank Back Board VMP Vocoder bank Master Processor

Navigation menu
