1X SCt4812ET Lite BTS

Optimization/ATP

Software Release 2.16.1.x

800 and 1900 MHz

CDMAS

English

Aug 2002

68P09255A69-3

PRELIMINARY

Notice

While reasonable efforts have been made to assure the accuracy of this document, Motorola, Inc. assumes no liability resulting

from any inaccuracies or omissions in this document, or from use of the information obtained herein. The information in this

document has been carefully checked and is believed to be entirely reliable. However, no responsibility is assumed for

inaccuracies or omissions. Motorola, Inc. reserves the right to make changes to any products described herein and reserves the

right to revise this document and to make changes from time to time in content hereof with no obligation to notify any person

of revisions or changes. Motorola, Inc. does not assume any liability arising out of the application or use of any product,

software, or circuit described herein; neither does it convey license under its patent rights or the rights of others.

It is possible that this publication may contain references to, or information about Motorola products (machines and

programs), programming, or services that are not announced in your country. Such references or information must not be

construed to mean that Motorola intends to announce such Motorola products, programming, or services in your country.

Copyrights

This instruction manual, and the Motorola products described in this instruction manual may be, include or describe

copyrighted Motorola material, such as computer programs stored in semiconductor memories or other media. Laws in

the United States and other countries preserve for Motorola certain exclusive rights for copyrighted material, including

the exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material.

Accordingly, any copyrighted Motorola material contained herein or in the Motorola products described in this

instruction manual may not be copied, reproduced, distributed, merged or modified in any manner without the express

written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either

directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of

Motorola, as arises by operation of law in the sale of a product.

Usage and Disclosure Restrictions

License Agreement

The software described in this document is the property of Motorola, Inc. It is furnished by express license agreement

only and may be used only in accordance with the terms of such an agreement.

Copyrighted Materials

Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by law. No part of the

software or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language or computer language, in any form or by any means, without prior written permission of Motorola, Inc.

High Risk Activities

Components, units, or third-party products used in the product described herein are NOT fault-tolerant and are NOT

designed, manufactured, or intended for use as on-line control equipment in the following hazardous environments

requiring fail-safe controls: the operation of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems,

Air Traffic Control, Life Support, or Weapons Systems (“High Risk Activities”). Motorola and its supplier(s) specifically

disclaim any expressed or implied warranty of fitness for such High Risk Activities.

Trademarks

and Motorola are registered trademarks of Motorola, Inc.

Product and service names profiled herein are trademarks of Motorola, Inc. Other manufacturers’ products or services

profiled herein may be referred to by trademarks of their respective companies.

Printed on

Recyclable Paper

REV012501

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

Aug 2002

1X SCt4812ET Lite BTS

Optimization/ATP

Table of Contents

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

ii Aug 2002

Contents

Foreword xii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FCC Requirements xv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Content xv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FCC Part 15 Requirements xv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FCC Part 68 Requirements xvi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Safety xvii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Revision History xix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Patent Notification xx. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optimization Manual Scope and Layout 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Manual Scope and Layout 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Assumptions and Prerequisites 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Document Composition 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Purpose of the Optimization 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Why Optimize? 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

What Is Optimization? 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

What Happens During Optimization? 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

When to Optimize 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

New Installations 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Site Expansion 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Periodic Optimization 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Repaired Sites 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Test Equipment and Software 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Policy 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Calibration 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Cable Calibration 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment Warm-up 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Test Equipment and Software 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optional Equipment 1-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Documents and Related Publications 1-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Documents 1-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Related Publications 1-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Terms and Abbreviations 1-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Standard and Non-standard Terms and Abbreviations 1-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BTS Equipment Identification 1-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment Overview 1-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BTS, Frame, Span, and Device Numbering 1-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cabinet Identification 1-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Major Components 1-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal Assembly Identification and Location 1-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal Assemblies and FRUs 1-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SCCP Cage Configuration and 1X Devices 1-31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BBX-1X and BBX2 Interchangeability 1-31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BTS Sector Configurations 1-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Sector Configuration 1-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 2 Preliminary Operations 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preliminary Operations: Overview 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

iii

Aug 2002

Introduction 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cell-site Types 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuration Data File 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Site Equipage Verification 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Initial Installation of Boards/Modules 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting Frame SCCP Configuration Switch 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ethernet LAN 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ethernet LAN Termination 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Initial Power-up 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Tools 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cabling Inspection 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Initial Inspection and Setup 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Power System Pre-power Application Test 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External AC Power Connection Verification 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Applying AC Power 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Power Application and Testing 2-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery Charge Test (Connected Batteries) 2-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery Discharge Test 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Removal 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Removal Procedures 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remove DC Power 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Power Removal 2-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Application - Normal Power-up 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Application Procedures 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Applying Internal AC Power 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Apply DC Power 2-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 3 Optimization/Calibration 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optimization/Calibraton - Introduction 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optimization Process Overview 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cell Site Types 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configuration Data File (CDF) 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CDF Site Equipage Verification 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BTS Software Release Download 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preparing the LMF 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overview 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LMF Installation and Update Procedures 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LMF Home Directory 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Copy CBSC CDF Files to the LMF Computer 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Software Release 2.16.0.x Hardware Binary Files 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Creating a Named HyperTerminal Connection for MMI Communication 3-8. . . . . . . . . . . . . . . . . . . . . .

Folder Structure Overview 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LMF Folder 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

cdma Folder 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

bts-nnn Folders 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

bts-nnn.cal File 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

bts-nnn.cdf File 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

cbsc File 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

loads Folder 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

version Folder 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

iv Aug 2002

code Folder 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

data Folder 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Span Lines - Interface and Isolation 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

T1/E1 Span Interface 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Isolate BTS from T1/E1 Spans 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

T1/E1 Span Isolation 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Configure Optional Channel Service Units 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm, Span Line, and RGPS Cable Pin/Signal Information 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remote GPS Distribution Punchdown Information 3-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LMF to BTS Connection 3-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connect the LMF to the BTS 3-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the LMF 3-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Basic LMF Operation 3-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The LMF Display and the BTS 3-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Logging Into a BTS 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Logging Out 3-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Establishing an MMI Communication Session 3-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Online Help 3-29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pinging the Processors 3-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pinging the BTS 3-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Download the BTS 3-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overview 3-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Verify GLI ROM Code Loads 3-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Download RAM Code and Data to MGLI and GLI 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Download RAM Code and Data to Non-GLI Devices 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BBX-1X Cards Remain OOS_ROM 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Selecting CSM Clock Source and Enabling CSMs 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Enable MCCs 3-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CSM System Time - GPS & LFR/HSO Verification 3-40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clock Synchronization Manager (CSM) Sub-system Description 3-40. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Low Frequency Receiver/High Stability Oscillator 3-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CSM Frequency Verification 3-42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Setup (GPS & LFR/HSO Verification) 3-42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPS Initialization/Verification 3-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LORAN-C Initialization/Verification 3-48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Set-up 3-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting Test Equipment to the BTS 3-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Supported Test Equipment 3-51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment Warm-up 3-54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Set Calibration 3-67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 3-67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibration Procedures Included 3-67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPIB Addresses 3-68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Selecting Test Equipment 3-68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Manually Selecting Test Equipment in a Serial Connection Tab 3-69. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Automatically Selecting Test Equipment in the Serial Connection Tab 3-70. . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Test Equipment 3-71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Cables - Overview 3-71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Test Cable Configurations with a Communications System Analyzer 3-72. . . . . . . . . . . . . . .

Calibrating TX and Duplexed RX ATP Test Cable Configurations Using a

Signal Generator and Spectrum Analyzer 3-73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Non-Duplexed RX Test Cable Configuration Using a Signal Generator

and Spectrum Analyzer 3-74. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

Aug 2002

Setting Cable Loss Values 3-76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting TX Coupler Loss Value 3-77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bay Level Offset Calibration 3-78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Purpose of Bay Level Offset Calibration 3-78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

What is BLO Calibration? 3-78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Component Verification During Calibration 3-79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

When to Calibrate 3-79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BLO Calibration Data File 3-79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Setup for RF Path Calibration 3-82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Transmit (TX) Path Calibration Description 3-83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Calibration and the LMF 3-84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Calibration 3-86. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All Cal/Audit Procedure 3-86. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Calibration Procedure 3-88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Download BLO Procedure 3-89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibration Audit Introduction 3-90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Path Audit 3-90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Audit Test 3-90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Create CAL File 3-92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS Set-up and Calibration 3-93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS Description 3-93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS Parameters 3-93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Checking and Setting RFDS Parameters 3-94. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS TSU NAM Programming 3-96. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Explanation of Parameters Used When Programming the TSU NAM 3-96. . . . . . . . . . . . . . . . . . . . . . . .

Valid NAM Ranges 3-97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Set Antenna Map Data 3-98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Set RFDS Configuration Data 3-99. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS Calibration 3-100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFDS Calibration Procedure 3-101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Program TSU NAM 3-102. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarms Testing 3-103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm Verification 3-103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm Reporting Display 3-103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm Testing Set-up 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Heat Exchanger Alarm Test 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Door Alarm 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Fail Alarm 3-105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Minor Alarm 3-105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Rectifier Alarms 3-105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Single Rectifier Failure (Three Rectifier System) 3-106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Multiple Rectifier Failure (Three Rectifier System) 3-106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Single Rectifier Failure (Four Rectifier System) 3-107. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Multiple Rectifier Failure (Four Rectifier System) 3-108. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Battery Over Temperature Alarm (Optional) 3-109. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Rectifier Over Temperature Alarm 3-111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Before Leaving the Site 3-111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 4 Automated Acceptance Test Procedures 4-1. . . . . . . . . . . . . . . . . . . . . . . . . .

Automated Acceptance Test Procedure - Introduction 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reduced ATP 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ATP Test Options 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

vi Aug 2002

ATP Prerequisites 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX/RX Antenna Connections 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Acceptance Tests - Test Set-up 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Required Test Equipment 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Acceptance Test Equipment Set Up 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Abbreviated (All-inclusive) Acceptance Tests 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All-inclusive Tests 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All TX/RX ATP Test 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All TX ATP Test 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All RX ATP Test 4-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Individual Acceptance Tests 4-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Individual Tests 4-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Spectral Purity Transmit Mask Acceptance Test 4-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Spectral Purity TX Mask Acceptance Test 4-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Waveform Quality (Rho) Acceptance Test 4-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Waveform Quality (Rho) Acceptance Test 4-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Pilot Time Offset Acceptance Test 4-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pilot Time Offset Acceptance Test 4-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Code Domain Power/Noise Floor Acceptance Test 4-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Code Domain Power/Noise Floor Test 4-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RX FER Acceptance Test 4-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FER Acceptance Test 4-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Generating an ATP Report 4-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Background 4-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ATP Report 4-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 5 Leaving the Site 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Updating Calibration Data Files 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Prepare to Leave the Site 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Removing External Test Equipment 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reset All Devices and Initialize Site Remotely 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bringing Modules into Service with the LMF 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Terminating LMF Session/Removing Terminal 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting BTS T1/E1 Spans 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Before Leaving the site 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 6 Basic Troubleshooting 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Basic Troubleshooting: Overview 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overview 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: Installation 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Log into Cell-Site 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Communicate with Power Meter 6-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Communicate with Communications System Analyzer 6-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Communicate with Signal Generator 6-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

vii

Aug 2002

Troubleshooting: Download 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Download DATA to Any Device (Card) 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot ENABLE Device 6-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LPA Errors 6-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: Calibration 6-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bay Level Offset Calibration Failure 6-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibration Audit Failure 6-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Basic Troubleshooting: RF Path Fault Isolation 6-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overview 6-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If Every Test Fails 6-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Verify BLO Checkbox 6-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Single-Sided BLO Checkbox 6-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If Faults Are Isolated 6-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fault Isolation Flowchart 6-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Flowchart Prerequisites 6-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Power Output Fault Isolation Flowchart 6-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: Transmit ATP 6-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BTS Passed Reduced ATP Tests but Has Forward Link Problem in Normal Operation 6-14. . . . . . . . .

Cannot Perform TX Mask Measurement 6-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Perform Rho or Pilot Time Offset Measurement 6-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cannot Perform Code Domain Power and Noise Floor Measurement 6-15. . . . . . . . . . . . . . . . . . . . . . . .

Cannot Perform Carrier Measurement 6-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: Receive ATP 6-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Multi-FER Test Failure 6-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: CSM Checklist 6-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Problem Description 6-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Intermittent 19.6608 MHz Reference Clock / GPS Receiver Operation 6-17. . . . . . . . . . . . . . . . . . . . . . .

No GPS Reference Source 6-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Checksum Failure 6-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPS Bad RX Message Type 6-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CSM Reference Source Configuration Error 6-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Takes Too Long for CSM to Come INS 6-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: SCCP Backplane 6-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 6-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connector Functionality 6-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SCCP Backplane Troubleshooting Procedure 6-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Digital Control Problems 6-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Power Problems 6-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX and RX Signal Routing Problems 6-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: RFDS 6-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction 6-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All Tests Fail 6-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All RX and TX Paths Fail 6-26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

All Tests Fail on a Single Antenna 6-26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Module Front Panel LED Indicators and Connectors 6-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Module Status Indicators 6-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LED Status Combinations for All Modules (except GLI2, CSM, BBXs (2, 1X),

and MCCs (8E, 24E, 1X) 6-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC/DC Converter LED Status Combinations 6-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CSM LED Status Combinations 6-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GLI2 LED Status Combinations 6-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GLI2 Pushbuttons and Connectors 6-31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

viii Aug 2002

BBX LED Status Combinations 6-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MCC LED Status Combinations 6-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LPA LED Status Combinations 6-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting: Span Control Link 6-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Span Problems (No Control Link) 6-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Set BTS Site Span Configuration 6-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix A Data Sheets A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Optimization (Pre-ATP) Data Sheets A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Verification of Test Equipment Used A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Site Checklist A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preliminary Operations A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pre-Power and Initial Power Tests A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Optimization Checklist A-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPS Receiver Operation A-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LFR Receiver Operation A-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LPA IM Reduction A-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TX Bay Level Offset / Power Output Verification for 3-Sector Configurations A-8. . . . . . . . . . . . . . . . .

TX Antenna VSWR A-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RX Antenna VSWR A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm Verification A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Site Serial Number Check List A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SCCP Shelf A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LPAs A-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix B FRU Optimization/ATP Test Matrix B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FRU Optimization/ATP Test Matrix B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Usage & Background B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Detailed Optimization/ATP Test Matrix B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix C BBX Gain Set Point vs. BTS Output C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BBX Gain Set Point vs. BTS Output C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Usage & Background C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix D CDMA Operating Frequency Information D-1. . . . . . . . . . . . . . . . . . . . . . . .

CDMA Operating Frequency Programming Information D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1900 MHz PCS Channels D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calculating 1900 MHz Center Frequencies D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

800 MHz CDMA Channels D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calculating 800 MHz Center Frequencies D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix E PN Offset/I & Q Offset Register Programming Information E-1. . . . . . . .

PN Offset Programming Information E-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PN Offset Background E-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PN Offset Usage E-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix F Test Equipment Preparation F-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Preparation F-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Purpose F-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting GPIB Addresses F-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

Aug 2002

Procedures for Verifying and Setting CDMA Support Equipment GPIB Addresses F-2. . . . . . . . . . . . .

Agilent E4406A Transmitter Tester GPIB Address F-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent E4432B Signal Generator GPIB Address F-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3267 Spectrum Analyzer GPIB Address F-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3562 Signal Generator GPIB Address F-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent 8935 Series E6380 (formerly HP 8935) Test Set GPIB Address F-6. . . . . . . . . . . . . . . . . . . . . .

Setting HP 8921A and HP 83236A/B GPIB Address F-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3465 GPIB Address F-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Motorola CyberTest GPIB Address F-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HP 437 Power Meter GPIB Address F-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Gigatronics 8541C Power Meter GPIB Address F-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RS-232 GPIB Interface Adapter F-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Test Equipment Inter-unit Connection, Testing, and Control F-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Inter-unit Connection, Testing, and Control Settings F-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HP 8921A with PCS Interface Test Equipment Connections F-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HP 8921A with PCS Interface System Connectivity Test F-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pretest Setup for HP 8921A F-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pretest Setup for Agilent 8935 F-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3465 Connection F-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

R3465 GPIB Clock Set-up F-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pretest Setup for Advantest R3465 F-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent 8932/E4432B Test Equipment Interconnection F-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent E4406A/E4432B Test Equipment Interconnection F-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3267/R3562 Test Equipment Interconnection F-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment Calibration F-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibration Without the LMF F-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent E4406A Transmitter Tester Self-alignment (Calibration) F-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating HP 437 Power Meter F-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Gigatronics 8541C Power Meter F-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Manual Cable Calibration F-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Test Cable Setup

Using HP PCS Interface (HP83236) F-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Calibrating Test Cable Setup Using Advantest R3465 F-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix G Download ROM Code G-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Downloading ROM Code G-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Exception Procedure - Downloading ROM Code G-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix H In-service Calibration H-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction H-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Purpose H-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment Stabilization and Calibration H-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1X Test Equipment Requirements H-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Delta Calibration H-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction H-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent E4406A Power Delta Calibration H-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3267 Power Delta Calibration H-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Agilent 8935 series E6380A Power Delta Calibration H-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HP8921A Power Delta Calibration H-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantest R3465 Power Delta Calibration H-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

In-Service Calibration H-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index Index-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xAug 2002

List of Figures

Figure 1-1: SC4812ET Lite BTS Starter and Companion Frame Span Cabling 1-17. . . . . . . . . . . . . . . .

Figure 1-2: SC4812ET Lite BTS Frame, Starter and Companion 1-18. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-3: Internal Assemblies and FRUs 1-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-4: 20-pair Punchblock with RGD Module 1-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-5: 50-Pair Punchblock 1-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-6: SCCP Shelf, IS-95A/B and 1X Devices 1-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-7: RF Interface Panel, Starter Frame, DRDCs Installed 1-25. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-8: RF Interface Panel, Starter Frame, TRDCs Installed 1-26. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-9: RF Interface Panel, Companion Frame, 2:1 Combiners and DRDCs 1-27. . . . . . . . . . . . . .

Figure 1-10: RF Interface Panel, Companion Frame, 2:1 Combiners and TRDCs 1-28. . . . . . . . . . . . .

Figure 1-11: RFDS, DRDC, and TRDC Details 1-29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-12: 2:1 Combiner Details, Companion Frame Only 1-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 1-13: SC4812ET Lite LPA Configuration with Bandpass Filters and 2:1 Combiners

(Stand-alone and Companion Frames) 1-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-1: Backplane DIP Switch Settings 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-2: External Ethernet LAN Connectors 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-3: Frame Power Subassemblies, North American and International Cabinets 2-5. . . . . . . . .

Figure 2-4: ACLC Circuit Breaker Panel - North American 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-5: ACLC Circuit Breaker Panel - International 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-6: DC PDA 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-7: ACLC Voltage Measurement Probe Points - North American 2-11. . . . . . . . . . . . . . . . . . . .

Figure 2-8: ACLC Voltage Measurement Probe Points - International 2-12. . . . . . . . . . . . . . . . . . . . . . .

Figure 2-9: Meter Alarm Panel (MAP) 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2-10: Heat Exchanger Blower Assembly and Circuit Breakers 2-17. . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-1: LMF Folder Structure 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-2: BTS Folder Name Syntax Example 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-3: CAL File Name Syntax Example 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-4: CDF Name Syntax Example 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-5: Code Load File Name Syntax Example 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-6: DDS File Name Syntax Example 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-7: Disconnecting Span Lines 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-8: Rear and Front View of CSU Shelf 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-9: 50-Pair Punchblock 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-10: 20-pair Punchblock with RGD Module Punchdowns 3-21. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-11: LMF Connection Detail 3-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-12: LMF Computer Common MMI Connections 3-29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-13: BTS Ethernet LAN Termination Diagram 3-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-14: CSM MMI Terminal Connection 3-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-15: IS- 95A/B Cable Calibration Test Setup - CyberTest, Agilent 8935,

Advantest R3465, and HP 8921A 3-55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

Aug 2002

Figure 3-16: IS-95A/B and CDMA 2000 1X Cable Calibration Test

Setup - Agilent E4406A/E4432B and Advantest R3267/R3562 3-56. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-17: CDMA2000 1X Cable Calibration Test Setup - Agilent 8935/E4432B 3-57. . . . . . . . . . . . .

Figure 3-18: TX Calibration Test Setup - CyberTest (IS-95A/B) and

Agilent 8935 (IS-95A/B and CDMA2000 1X) 3-58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-19: TX Calibration Test Setup - Using Power Meter 3-59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-20: TX Calibration Test Setup - Agilent E4406A and

Advantest R3567 (IS-95A/B and CDMA2000 1X) 3-60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-21: IS-95A/B ATP Test Set-up, TRDC Shown - CyberTest,

Advantest R3465, and Agilent 8935 3-61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-22: IS-95A/B ATP Test Setup - HP 8921A 3-62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-23: IS-95A/B and CDMA2000 1X ATP Test Setup With

DRDCs - Agilent Test Equipment 3-63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-24: IS-95A/B and CDMA2000 1X ATP Test Setup With

DRDCs - Advantest R3267/3562 Test Equipment 3-64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-25: IS-95A/B and CDMA2000 1X ATP Test Setup With TRDCs - Agilent

Test Equipment 3-65. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-26: IS-95A/B and CDMA2000 1X ATP Test Setup With TRDCs - Advantest

R3267/3562 Test Equipment 3-66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-27: Calibration Setup for TX Test Cable Configuration and Duplexed RX Test Cable

Configuration Using Signal Generator and Spectrum Analyzer 3-74. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-28: Calibration Setup for Non-Duplexed TX/RX Antenna Connection RX Test Cable

Configuration Using Signal Generator and Spectrum Analyzer 3-75. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-29: Battery Over-Temperature Sensor 3-110. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3-30: MAP Connector J8 (Rear of MAP) 3-111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4-1: SC4812ET Lite Companion Frame Diversity RX Simplified

Interconnection Diagram 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4-2: TX Mask Verification Spectrum Analyzer Display 4-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4-3: Code Domain Analyzer CD Power/Noise Floor Display Examples 4-24. . . . . . . . . . . . . . . . .

Figure 6-1: TX Output Fault Isolation Flowchart 6-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6-2: CSM Front Panel Indicators & Monitor Ports 6-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6-3: GLI2 Front Panel Operating Indicators 6-31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6-4: MCC24 and MCC-1X Front Panel LEDs and LED Indications 6-33. . . . . . . . . . . . . . . . . . . .

Figure 6-5: MGLI/GLI Board MMI Connection Detail 6-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure D-1: North America PCS Frequency Spectrum (CDMA Allocation) D-1. . . . . . . . . . . . . . . . . . . .

Figure D-2: North American Cellular Telephone System Frequency Spectrum

(CDMA Allocation). D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-1: Setting Agilent E4406A GPIB Address F-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-2: Setting Agilent E4432B GPIB Address F-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-3: Setting Advantest R3267 GPIB Address F-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-4: Advantest R3562 GPIB Address Switch Setting F-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-5: Agilent 8935 Test Set F-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-6: HP 8921A and HP 83236A/B F-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-7: R3465 Communications Test Set F-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-8: HP 437 Power Meter F-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xii Aug 2002

Figure F-9: Gigatronics 8541C Power Meter Detail F-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-10: RS232 GPIB Interface Adapter F-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-11: HP 8921A/600 Cable Connections for 10 MHz Signal and

GPIB without Rubidium Reference F-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-12: HP 8921A Cable Connections for 10 MHz Signal and

GPIB with Rubidium Reference F-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-13: Cable Connections for Test Set without 10 MHz Rubidium Reference F-19. . . . . . . . . . . .

Figure F-14: Cable Connections for Test Set with 10 MHz Rubidium Reference F-20. . . . . . . . . . . . . . .

Figure F-15: Agilent 8935/E4432B 10MHz Reference and Even Second Tick Connections F-21. . . . .

Figure F-16: Agilent 10 MHz Reference Connections F-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-17: Advantest 10 MHz Reference and Serial I/O Connections F-23. . . . . . . . . . . . . . . . . . . . . .

Figure F-18: Performing Agilent E4406A Self-alignment (Calibration) F-24. . . . . . . . . . . . . . . . . . . . . . .

Figure F-19: Power Meter Detail F-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-20: Gigatronics 8541C Power Meter Detail F-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-21: Cable Calibration Using HP8921 with PCS Interface F-31. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure F-22: Cable Calibration Using Advantest R3465 F-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-1: Delta Calibration Setup - Agilent E4432B to HP437 H-4. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-2: Delta Calibration Setup - Agilent E4432B to Agilent E4406A H-4. . . . . . . . . . . . . . . . . . . . .

Figure H-3: Delta Calibration Setup - Advantest R3562 to HP437 H-7. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-4: Delta Calibration Setup - Advantest R3562 to HP437 H-7. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-5: Delta Calibration Setup - Advantest R3562 to R3267 H-7. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-6: Delta Calibration Setup - Agilent 8935 to HP437 H-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-7: Delta Calibration Setup - Agilent 8935 to Agilent 8935 H-10. . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-8: Delta Calibration Setup - HP8921A to HP437 H-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-9: Delta Calibration Setup - HP8921A to HP8921A H-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-10: Delta Calibration Setup - R3561L to HP437 H-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-11: Delta Calibration Setup - R3561L to R3465 H-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure H-12: TX Calibration Test Setup - Agilent E4406A, Advantest R3267, and

Agilent 8935 with Option 200 or R2K (IS-95A/B and 1X CDMA 2000) H-18. . . . . . . . . . . . . . . . . . . . . . .

Figure H-13: TX Calibration Test Setup - HP 8921A/600 w/PCS

Interface (1.9 GHz), HP 8921A/600 (800 MHz), and Advantest R3465 (IS-95A/B only) H-19. . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xiii

Aug 2002

List of Tables

FCC Part 68 Registered Devices xii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1-1: Non-Standard Terms and Abbreviations 1-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1-2: SCCP Cage Module Device ID Numbers (Top Shelf) 1-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1-3: SCCP Cage Module Device ID Numbers (Bottom Shelf) 1-17. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1-4: BTS Sector Configuration 1-32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 1-5: Sector Configurations 1-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-1: Initial Installation of Boards/Modules 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-2: Initial Inspection and Setup 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-3: DC Power System Pre-Power Application Test 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-4: AC Voltage Measurements 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-5: Applying Internal AC Power 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-6: DC Power Application and Tests 2-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-7: Battery Charge Test (Connected Batteries) 2-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-8: Battery Discharge Test 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-9: DC Power Removal 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-10: AC Power Removal 2-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-11: Apply AC Power to BTS Frame 2-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2-12: Apply DC Power to BTS Frame 2-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-1: CD ROM Installation 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-2: Copying CBSC CDF Files to the LMF Computer 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-3: Verify Software Release 2.16.0.x Device Binary Files Are Installed 3-7. . . . . . . . . . . . . . . .

Table 3-4: Create HyperTerminal Connection 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-5: T1/E1 Span Isolation 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-6: Punchdown Location for Stand-alone and Companion Frame 50-Pair Punch Block 3-18. .

Table 3-7: 50-Pair Punch Block RGPS Punchdown Location for RGPS Non-Expansion

Frames (Input from RGPS Receiver) and SecondaryRGPS Expansion Frames (Input from

RGPS Expansion Primary Frame 20-pair Punchblock) 3-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-8: 50-Pair Punch Block RGPS Punchdown Location for RGPS Expansion Primary Frame

(Input from RGPS Receiver) 3-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-9: 20-Pair Punch Block RGPS EXP(ansion) 1 Punchdown Location for

RGPS Expansion Output to Secondary Frame (Input from RGPS Receiver Through

Primary Frame 50-pair Punchblock) 3-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-10: Connecting the LMF to the BTS 3-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-11: BTS GUI Login Procedure 3-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-12: BTS CLI Login Procedure 3-26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-13: BTS GUI Logout Procedure 3-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-14: BTS CLI Logout Procedure 3-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-15: Establishing MMI Communication 3-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-16: Pinging the Processors 3-31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-17: Verify GLI ROM Code Loads 3-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-18: Download and Enable MGLI and GLI Devices 3-35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xiv Aug 2002

Table 3-19: Download RAM Code and Data to Non-GLI Devices 3-36. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-20: Select CSM Clock Source 3-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-21: Enable CSMs 3-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-22: Enable MCCs 3-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-23: Test Equipment Setup (GPS & LFR/HSO Verification) 3-42. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-24: GPS Initialization/Verification 3-44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-25: LORAN-C Initialization/Verification 3-48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-26: IS-95A/B-only Test Equipment Interconnection 3-52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-27: CDMA2000 1X/IS-95A/B Test Equipment Interconnection 3-53. . . . . . . . . . . . . . . . . . . . . . .

Table 3-28: Selecting Test Equipment Manually in the Serial Connection Tab 3-69. . . . . . . . . . . . . . . . .

Table 3-29: Selecting Test Equipment Using Auto-Detect 3-70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-30: Test Equipment Calibration 3-71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-31: Test Cable Configuration Calibration with a Communications System Analyzer 3-72. . . . .

Table 3-32: Calibrating the TX Test Cable Configuration or the Duplexed RX Test

Cable Configuration Using Signal Generator and Spectrum Analyzer 3-73. . . . . . . . . . . . . . . . . . . . . . . .

Table 3-33: Calibrating Non-Duplexed RX Test Cable Configuration Using a Signal

Generator and Spectrum Analyzer 3-74. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-34: Setting Cable Loss Values 3-76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-35: Setting TX Coupler Loss Values 3-77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-36: BLO bts-#.cal File Array Branch Assignments 3-80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-37: SC4812ET Lite bts-#.cal File Array (By BBX/Sector) 3-81. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-38: Set Up Test Equipment for RF Path Calibration 3-82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-39: Test Patterns with Channels and Gain Settings Used 3-85. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-40: All Cal/Audit Procedure 3-87. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-41: TX Calibration Procedure 3-88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-42: Download BLO 3-89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-43: TX Path Audit 3-91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-44: Create CAL File 3-92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-45: RFDS Parameter Settings 3-94. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-46: Definition of Parameters 3-96. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-47: Valid NAM Field Ranges 3-97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-48: Set Antenna Map Data 3-98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-49: Set RFDS Configuration Data 3-99. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-50: RFDS TSIC Calibration Channel Frequencies 3-100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-51: RFDS Calibration 3-101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-52: Program NAM Procedure 3-102. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-53: Alarm Testing Preparation 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-54: Heat Exchanger Alarm 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-55: ACLC and Power Entry Door Alarm 3-104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-56: AC Fail Alarm 3-105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-57: Minor Alarm 3-105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-58: Single Rectifier Fail or Minor Alarm, Single-Carrier System 3-106. . . . . . . . . . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

Aug 2002

Table 3-59: Multiple Rectifier Failure or Major Alarm, Single-Carrier System 3-106. . . . . . . . . . . . . . . . . .

Table 3-60: Single Rectifier Fail or Minor Alarm, Two-Carrier System 3-107. . . . . . . . . . . . . . . . . . . . . . . .

Table 3-61: Multiple Rectifier Failure or Major Alarm, Two-Carrier System 3-108. . . . . . . . . . . . . . . . . . .

Table 3-62: Battery Over-Temperature Alarm 3-109. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3-63: Rectifier Over-Temperature Alarm 3-111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-1: To Perform Companion Frame Diversity RX FER, Inter-frame RX Cables Connected

(Set Multi-Channel Preselector to MPC) 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-2: To Perform Companion Frame Diversity RX FER, Inter-frame RX Cables Disconnected

(Set Multi-Channel Preselector to EMPC) 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-3: Set Up Test Equipment - TX Output Verify/Control Tests 4-6. . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-4: Additional Diversity RX Test Set-up for Companion Frames 4-7. . . . . . . . . . . . . . . . . . . . . .

Table 4-5: All TX/RX ATP Test Procedure 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-6: All TX ATP Test Procedure 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-7: All RX ATP Test Procedure 4-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-8: Test Spectral Purity Transmit Mask 4-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-9: Test Waveform Quality (Rho) 4-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-10: Test Pilot Time Offset 4-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-11: Test Code Domain Power/Noise Floor 4-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-12: Test FER 4-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4-13: Generating an ATP Report 4-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-1: Copying CAL Files to a Diskette 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-2: Copying CAL Files from Diskette to the CBSC 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-3: Remove External Test Equipment 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-4: Reset BTS Devices and Remote Site Initialization 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-5: Bring Modules into Service 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-6: Remove LMF 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-7: Connect T1 or E1 Spans 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 5-8: Check Before Leaving the Site 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-1: Login Failure Troubleshooting Procedures 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-2: Force Ethernet LAN A to Active State as Primary LAN 6-2. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-3: GLI IP Address Setting 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-4: Troubleshooting a Power Meter Communication Failure 6-5. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-5: Troubleshooting a Communications System Analyzer Communication Failure 6-6. . . . . . .

Table 6-6: Troubleshooting a Signal Generator Communication Failure 6-6. . . . . . . . . . . . . . . . . . . . . .

Table 6-7: Troubleshooting Code Download Failure 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-8: Troubleshooting Data Download Failure 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-9: Troubleshooting Device Enable (INS) Failure 6-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-10: LPA Errors 6-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-11: Troubleshooting BLO Calibration Failure 6-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-12: Troubleshooting Calibration Audit Failure 6-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-13: Troubleshooting Forward Link Failure (BTS Passed Reduced ATP) 6-14. . . . . . . . . . . . . . .

Table 6-14: Troubleshooting TX Mask Measurement Failure 6-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xvi Aug 2002

Table 6-15: Troubleshooting Rho and Pilot Time Offset Measurement Failure 6-14. . . . . . . . . . . . . . . . .

Table 6-16: Troubleshooting Code Domain Power and Noise Floor Measurement Failure 6-15. . . . . . .

Table 6-17: Troubleshooting Carrier Measurement Failure 6-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-18: Troubleshooting Multi-FER Failure 6-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-19: CSM Reference (Clock) Sources by GPS Type and Kit Number 6-18. . . . . . . . . . . . . . . . . .

Table 6-20: No GLI Control Through LMF (All GLIs) 6-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-21: No GLI Control Through Span Line Connection (Both GLIs) 6-21. . . . . . . . . . . . . . . . . . . . .

Table 6-22: MGLI Control Good - No Control Over Co-located GLI 6-21. . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-23: MGLI Control Good - No Control Over AMR 6-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-24: MGLI Control Good - No Control over Co-located BBXs 6-22. . . . . . . . . . . . . . . . . . . . . . . .

Table 6-25: BBX Control Good - No (or Missing) Span Line Traffic 6-22. . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-26: No MCC-1X/MCC24E/MCC8E Channel Elements 6-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-27: No DC Input Voltage to Power Supply Module 6-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-28: No DC Input Voltage to any SCCP Shelf Module 6-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-29: TX and RX Signal Routing Problems 6-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-30: RFDS Fault Isolation - All Tests Fail 6-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-31: RFDS Fault Isolation - All Tests Fail on Single Antenna Path 6-26. . . . . . . . . . . . . . . . . . . .

Table 6-32: Troubleshoot Control Link Failure 6-34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6-33: Set BTS Span Parameter Configuration 6-36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-1: Verification of Test Equipment Used A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-2: Site Checklist A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-3: Preliminary Operations A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A3a: Pre-power Checklist A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A3b: General Optimization Checklist A-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-4: GPS Receiver Operation A-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-5: LFR Receiver Operation A-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-6: LPA IM Reduction A-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-7: TX BLO Calibration (3-Sector: 1-Carrier and 2-Carrier Non-adjacent Channels) A-8. . . .

Table A-8: TX Bay Level Offset Calibration (3-Sector: 2-Carrier Adjacent Channels) A-9. . . . . . . . . .

Table A-9: TX Antenna VSWR A-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-10: RX Antenna VSWR A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table A-11: CDI Alarm Input Verification A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table B-1: SC 4812ET Lite BTS Optimization and ATP Test Matrix B-2. . . . . . . . . . . . . . . . . . . . . . . . . .

Table C-1: BBX Gain Set Point vs. Actual BTS Output (in dBm) C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table D-1: 1900 MHz TX and RX Frequency vs. Channel D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table D-2: 800 MHz TX and RX Frequency vs. Channel D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table E-1: PnMaskI and PnMaskQ Values for PilotPn E-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-1: Verify and Change Agilent E4406A GPIB Address F-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-2: Verify and Change Agilent E4432B GPIB Address F-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-3: Verify and Change Advantest R3267 GPIB Address F-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-4: Verify and/or Change Agilent 8935 (formerly HP 8935) GPIB Address F-6. . . . . . . . . . . . . .

Table of Contents

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xvii

Aug 2002

Table F-5: Verify and/or Change HP 8921A and HP 83236A GPIB Addresses F-7. . . . . . . . . . . . . . . .

Table F-6: Verify and/or Change Advantest R3465 GPIB Address F-8. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-7: Verify and/or Change Motorola CyberTest GPIB Address F-9. . . . . . . . . . . . . . . . . . . . . . . .

Table F-8: Verify and/or Change HP 437 Power Meter GPIB Address F-10. . . . . . . . . . . . . . . . . . . . . . .

Table F-9: Verify and/or Change Gigatronics 8541C Power Meter GPIB Address F-11. . . . . . . . . . . . . .

Table F-10: HP 8921A/600 Communications Test Set Rear Panel Connections

Without Rubidium Reference F-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-11: HP 8921A/600 Communications Test Set Rear Panel Connections

With Rubidium Reference F-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-12: System Connectivity F-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-13: Pretest Setup for HP 8921A F-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-14: Pretest Setup for Agilent 8935 F-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-15: Advantest R3465 Clock Setup F-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-16: Pretest Setup for Advantest R346 F-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-17: Perform Agilent E4406A Self-alignment (Calibration) F-24. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-18: HP 437 Power Meter Calibration Procedure F-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-19: Calibrate Gigatronics 8541C Power Meter F-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table F-20: Calibrating Test Cable Setup (using the HP PCS Interface) F-28. . . . . . . . . . . . . . . . . . . . . .

Table F-21: Procedure for Calibrating Test Cable Setup Using Advantest R3465 F-32. . . . . . . . . . . . . .

Table G-1: Download ROM and RAM Code to Devices G-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-1: Agilent E4406A Power Delta Calibration Procedure H-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-2: Advantest R3267 Power Delta Calibration Procedure H-5. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-3: Agilent 8935 Power Delta Calibration Procedure H-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-4: HP8921A Power Delta Calibration Procedure H-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-5: Advantest Power Delta Calibration Procedure H-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table H-6: In-Service Calibration H-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Foreword

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xviii Aug 2002

Foreword

Scope of manual

This manual is intended for use by cellular telephone system

craftspersons in the day-to-day operation of Motorola cellular system

equipment and ancillary devices. It is assumed that the user of this

information has a general understanding of telephony, as used in the

operation of the Public Switched Telephone Network (PSTN), and is

familiar with these concepts as they are applied in the cellular

mobile/portable radiotelephone environment. The user, however, is not

expected to have any detailed technical knowledge of the internal

operation of the equipment.

This manual is not intended to replace the system and equipment

training offered by Motorola, although it can be used to supplement or

enhance the knowledge gained through such training.

Text conventions

The following special paragraphs are used in this manual to point out

information that must be read. This information may be set-off from the

surrounding text, but is always preceded by a bold title in capital letters.

The three categories of these special paragraphs are:

NOTE Presents additional, helpful, non-critical information that you can

use.

Bold-text notes indicate information to help you avoid an

undesirable situation or provides additional information to

help you understand a topic or concept.

CAUTION Presents information to identify a situation in which equipment

damage could occur, thus avoiding damage to equipment.

WARNING Presents information to warn you of a potentially hazardous

situation in which there is a possibility of personal injury.

Foreword

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xix

Aug 2002

The following typographical conventions are used for the presentation of

software information:

SIn text, sans serif BOLDFACE CAPITAL characters (a type style

without angular strokes: i.e., SERIF versus SANS SERIF) are used to

name a command.

SIn text, typewriter style characters represent prompts and the

system output as displayed on an operator terminal or printer.

SIn command definitions, sans serif boldface characters represent those

parts of the command string that must be entered exactly as shown and

typewriter style characters represent command output responses

as displayed on an operator terminal or printer.

SIn the command format of the command definition, typewriter

style characters represent the command parameters.

Changes to manual

Changes that occur after the printing date are incorporated into your

manual by Cellular Manual Revisions (CMRs). The information in this

manual is updated, as required, by a CMR when new options and

procedures become available for general use or when engineering

changes occur. The cover sheet(s) that accompany each CMR should be

retained for future reference. Refer to the Revision History page for a list

of all applicable CMRs contained in this manual.

Receiving updates

Technical Information Products and Services (TIPS) maintains a

customer database that reflects the type and number of manuals ordered

or shipped since the original delivery of your Motorola equipment. Also

identified in this database is a “key” individual (such as Documentation

Coordinator or Facility Librarian) designated to receive manual updates

from TIPS as they are released.

To ensure that your facility receives updates to your manuals, it is

important that the information in our database is correct and up-to-date.

Therefore, if you have corrections or wish to make changes to the

information in our database (i.e., to assign a new “key” individual),

please contact Technical Information Products and Services.

MOTOROLA, INC.

Technical Information Products and Services

Phone:

Within U.S.A. and Canada 800-872-8225. . . . .

Outside of U.S.A. and Canada +1-847-435-5700. .

FAX: +1-847-435-5541. . . . . . . . . . . . . . . . . . . . . .

Reporting manual errors

In the event that you locate an error or identify a deficiency in your

manual, please take time to write to us at the address above. Be sure to

include your name and address, the complete manual title and part

number (located on the manual spine, cover, or title page), the page

number (found at the bottom of each page) where the error is located,

and any comments you may have regarding what you have found. We

appreciate any comments from the users of our manuals.

Foreword 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xx Aug 2002

24-hour support service

If you have any questions or concerns regarding the operation of your

equipment, please contact the Customer Network Resolution Center for

immediate assistance. The 24 hour telephone numbers are:

Arlington Heights, IL 800-433-5202. . . . . . . . . .

Arlington Heights, International +1-847-632-5390. .

Cork, Ireland 44-1793-565444. . . . . . . . . . . . . . . . .

Swindon, England 44-1793-565444. . . . . . . . . . . . .

FCC Requirements

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxi

Aug 2002

FCC Requirements

Content

This section presents Federal Communications Commission (FCC)

Rules Parts 15 and 68 requirements and compliance information for the

SCt4812T/ET/ET Lite series Radio Frequency Base Transceiver

Stations.

FCC Part 15 Requirements

Part 15.19a(3) - INFORMATION TO USER

NOTE This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including

interference that may cause undesired operation.

Part 15.21 - INFORMATION TO USER

CAUTION Changes or modifications not expressly approved by Motorola

could void your authority to operate the equipment.

15.105(b) - INFORMATION TO USER

NOTE This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment

OFF and ON, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician

for help.

FCC Requirements 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxii Aug 2002

FCC Part 68 Requirements

This equipment complies with Part 68 of the Federal Communications

Commission (FCC) Rules. A label on the GLI3 board, easily visible

with the board removed, contains the FCC Registration Number for this

equipment in the format < US: IHEXDNANGLI3-1X>. If requested,

this information must be provided to the telephone company.

FCC Part 68 Registered Devices

Device FCC Part 68 ID

Group Line Interface (GLI3) * US: IHEXDNANGLI3-1X

Cisco Model 1900-27 US: 5B1DDNDN0006

ADC KENTROX Model 537 US: F81USA-31217-DE-N

* NOTE: The BTS equipment is always equipped with the GLI3, < US:

IHEXDNANGLI3-1X>, and may be used in conjunction with one or

both of the listed registered CSU devices, or another registered CSU

device not listed above.

The telephone company may make changes in its facilities, equipment,

operations, or procedures that could affect the operation of your T1. If

this happens, the telephone company will provide advance notice so that

you can modify your equipment as required to maintain uninterrupted

service.

If this equipment causes harm to the telephone network, the telephone

company will notify you in advance that temporary discontinuance of

service may be required. If advance notice is not practical, the telephone

company will notify you as soon as possible. Also, you will be advised

of your right to file a complaint with the FCC if you believe it is

necessary.

If you experience trouble operating this equipment with the T1, please

contact:

Global Customer Network Resolution Center (CNRC)

1501 W. Shure Drive, 3436N

Arlington Heights, Illinois 60004

Phone Number: (847) 632-5390

for repair and/or warranty information. You should not attempt to repair

this equipment yourself. This equipment contains no customer or

user-serviceable parts.

Changes or modifications not expressly approved by Motorola could

void your authority to operate this equipment.

General Safety

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxiii

Aug 2002

General Safety

Remember! . . . Safety

depends on you!!

The following general safety precautions must be observed during all

phases of operation, service, and repair of the equipment described in

this manual. Failure to comply with these precautions or with specific

warnings elsewhere in this manual violates safety standards of design,

manufacture, and intended use of the equipment. Motorola, Inc. assumes

no liability for the customer’s failure to comply with these requirements.

The safety precautions listed below represent warnings of certain dangers

of which we are aware. You, as the user of this product, should follow

these warnings and all other safety precautions necessary for the safe

operation of the equipment in your operating environment.

Ground the instrument

To minimize shock hazard, the equipment chassis and enclosure must be

connected to an electrical ground. If the equipment is supplied with a

three-conductor ac power cable, the power cable must be either plugged

into an approved three-contact electrical outlet or used with a

three-contact to two-contact adapter. The three-contact to two-contact

adapter must have the grounding wire (green) firmly connected to an

electrical ground (safety ground) at the power outlet. The power jack and

mating plug of the power cable must meet International Electrotechnical

Commission (IEC) safety standards.

Do not operate in an explosive

atmosphere

Do not operate the equipment in the presence of flammable gases or

fumes. Operation of any electrical equipment in such an environment

constitutes a definite safety hazard.

Keep away from live circuits

Operating personnel must:

Snot remove equipment covers. Only Factory Authorized Service

Personnel or other qualified maintenance personnel may remove

equipment covers for internal subassembly, or component

replacement, or any internal adjustment.

Snot replace components with power cable connected. Under certain

conditions, dangerous voltages may exist even with the power cable

removed.

Salways disconnect power and discharge circuits before touching them.

Do not service or adjust alone

Do not attempt internal service or adjustment, unless another person,

capable of rendering first aid and resuscitation, is present.

Do not substitute parts or

modify equipment

Because of the danger of introducing additional hazards, do not install

substitute parts or perform any unauthorized modification of equipment.

Contact Motorola Warranty and Repair for service and repair to ensure

that safety features are maintained.

General Safety 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxiv Aug 2002

Dangerous procedure

warnings

Warnings, such as the example below, precede potentially dangerous

procedures throughout this manual. Instructions contained in the

warnings must be followed. You should also employ all other safety

precautions that you deem necessary for the operation of the equipment

in your operating environment.

WARNING Dangerous voltages, capable of causing death, are present in this

equipment. Use extreme caution when handling, testing, and

adjusting.

Revision History

68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxv

Aug 2002

Revision History

Manual Number

68P09255A69-3

Manual Title

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

Version Information

The following table lists the manual version, date of version, and

remarks on the version. Revision bars printed in page margins (as shown

to the side) identify material which has changed from the previous

release of this publication.

Version

Level Date of Issue Remarks

1Jun 2002 Initial draft to support R2.16.1.x CDMA2000 1X and packet operation

BTS optimization and acceptance testing. Initial draft will cover circuit

operation only.

2Jul 2002 Preliminary

3Aug 2002 Preliminary, incorporate engineering markups.

Patent Notification 68P09255A69-3

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

xxvi Aug 2002

Patent Notification

Patent numbers

This product is manufactured and/or operated under one or more of the

following patents and other patents pending:

4128740 4661790 4860281 5036515 5119508 5204876 5247544 5301353

4193036 4667172 4866710 5036531 5121414 5204977 5251233 5301365

4237534 4672657 4870686 5038399 5123014 5207491 5255292 5303240

4268722 4694484 4872204 5040127 5127040 5210771 5257398 5303289

4282493 4696027 4873683 5041699 5127100 5212815 5259021 5303407

4301531 4704734 4876740 5047762 5128959 5212826 5261119 5305468

4302845 4709344 4881082 5048116 5130663 5214675 5263047 5307022

4312074 4710724 4885553 5055800 5133010 5214774 5263052 5307512

4350958 4726050 4887050 5055802 5140286 5216692 5263055 5309443

4354248 4729531 4887265 5058136 5142551 5218630 5265122 5309503

4367443 4737978 4893327 5060227 5142696 5220936 5268933 5311143

4369516 4742514 4896361 5060265 5144644 5222078 5271042 5311176

4369520 4751725 4910470 5065408 5146609 5222123 5274844 5311571

4369522 4754450 4914696 5067139 5146610 5222141 5274845 5313489

4375622 4764737 4918732 5068625 5152007 5222251 5276685 5319712

4485486 4764849 4941203 5070310 5155448 5224121 5276707 5321705

4491972 4775998 4945570 5073909 5157693 5224122 5276906 5321737

4517561 4775999 4956854 5073971 5159283 5226058 5276907 5323391

4519096 4797947 4970475 5075651 5159593 5228029 5276911 5325394

4549311 4799253 4972355 5077532 5159608 5230007 5276913 5327575

4550426 4802236 4972432 5077741 5170392 5233633 5276915 5329547

4564821 4803726 4979207 5077757 5170485 5235612 5278871 5329635

4573017 4811377 4984219 5081641 5170492 5235614 5280630 5339337

4581602 4811380 4984290 5083304 5182749 5239294 5285447 D337328

4590473 4811404 4992753 5090051 5184349 5239675 5287544 D342249

4591851 4817157 4998289 5093632 5185739 5241545 5287556 D342250

4616314 4827507 5020076 5095500 5187809 5241548 5289505 D347004

4636791 4829543 5021801 5105435 5187811 5241650 5291475 D349689

4644351 4833701 5022054 5111454 5193102 5241688 5295136 RE31814

4646038 4837800 5023900 5111478 5195108 5243653 5297161

4649543 4843633 5028885 5113400 5200655 5245611 5299228

4654655 4847869 5030793 5117441 5203010 5245629 5301056

4654867 4852090 5031193 5119040 5204874 5245634 5301188

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-1

Chapter 1

Introduction

Optimization Manual Scope and Layout 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-2

Optimization Manual Scope and Layout

Manual Scope and Layout

This document provides information pertaining to the optimization and

audit tests of the Motorola SC4812ET Lite Radio Frequency (RF) Base

Transceiver Station (BTS) equipment frame and its associated internal

and external interfaces in stand-alone and companion frame

installations. The following subjects are addressed: preliminary

background information; optimization and alarm/redundancy tests;

Acceptance Test Procedures (ATP) to verify site operation and regulation

compliance; site turnover; troubleshooting.

Most applications use the same test procedure for all equipment

variations. However, decision break points are provided throughout the

procedure when equipment-specific tests are required. For example,

when tests using external test equipment are performed instead of those

using the RFDS, additional test procedures and illustrations are provided

to cover both applications.

This optimization procedure consists of a group of task-oriented tests.

Each major test category (Audit, Initial power-up, Calibration, etc.) is

described in chapters which are broken down into multi-page

information “maps.”

Each “map” contains the information necessary to perform the test or

operation. Included are all required input levels, output levels, Local

Maintenance Facility (LMF) application software commands, and test

point identification. Also described are important test process concepts

and equipment operation which should be understood by the operator.

Whenever possible, graphics, flowcharts, or written examples

complement the information or procedural steps.

Assumptions and Prerequisites

This document assumes that the BTS frames and cabling have been

installed per the Frame Mounting Guide Analog/CDMA/TDMA;

68P09226A18, which covers the physical “bolt down” of all SC series

equipment frames, and the SC4812ET Lite Installation; 68P09253A36,

which covers BTS-specific cabling configurations.

Optimization Manual Scope and Layout68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-3

Document Composition

This document covers the following major areas:

SIntroduction, consisting of preliminary background information (such

as component and subassembly locations and frame layouts) to be

considered by the Cellular Field Engineer (CFE) before performing

optimization or tests.

SPreliminary Operations, consisting of jumper configuration of BTS

sub-assemblies, pre-power-up tests, initial application of power to

the BTS equipment frames, and initial power-up tests.

SOptimization/Calibration, consisting of procedures for downloading

all BTS processor boards, test equipment set-up, RF path verification,

BLO calibration and calibration audit, and Radio Frequency

Diagnostic System (RFDS) calibration.

SAcceptance Test Procedures (ATP), consisting of automated ATP tests,

executed by the LMF, and used to verify all major transmit (TX) and

receive (RX) performance characteristics on all BTS equipment. This

chapter also covers generating an ATP report.

SPrepare to Leave the Site, discussing site turnover after ATP is

completed.

SBasic Troubleshooting, consisting of procedures to perform when an

ATP fails, as well as when incorrect results are obtained during logon,

test equipment operation, calibration, and Global Positioning System

(GPS) operation.

SAppendices that contain a module replacement test matrix; test

equipment set-up information; ROM code download procedures;

in-service calibration procedures; pertinent PN offset, frequency

programming, and output power data tables; and additional data sheets

that are filled out manually by the CFE at the site.

Purpose of the Optimization 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-4

Purpose of the Optimization

Why Optimize?

Proper optimization and calibration ensures that:

SAccurate downlink RF power levels are transmitted from the site.

SAccurate uplink signal strength determinations are made by the site.

What Is Optimization?

Optimization compensates for the site-specific cabling and normal

equipment variations. Site optimization guarantees that the combined

losses of the new cables and the gain/loss characteristics and built-in

tolerances of each BTS frame do not accumulate and cause improper site

operation.

What Happens During Optimization?

Overview - During optimization, the accumulated path loss or gain is

first determined for each RF transmit path in the BTS. These transmit

path loss or gain values are then stored in a database along with RF

receive path default values.

RF path definitions - For definitions of the BTS transmit (TX) and

receive (RX) paths, see “What is Bay Level Offset Calibration?” in the

Bay Level Offset Calibration section of Chapter 3.

RF paths and transceiver optimization - Six of the seven Broad Band

Transceiver (BBX) boards in each SCCP shelf are optimized to specific

RX and TX antenna connectors. The seventh BBX board acts in a

redundant capacity for BBX boards 1 through 6, and is optimized to all

antenna connectors. A single optimization value is generated for each

complete path. This eliminates the accumulation of error that would

occur from individually measuring and summing the gain and loss of

each element in the path.

Using RF path gain/loss values - BTS equipment factors in the derived

optimization values internally to adjust transceiver power levels, leaving

only site-specific antenna feedline loss and antenna gain characteristics

to be factored in by the CFE when determining required site Effective

Radiated Power (ERP) output power levels.

When to Optimize68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-5

When to Optimize

New Installations

The following operations and optimization/test actions should be

accomplished for a new BTS or frame installation:

1. After the initial site installation, the BTS must be prepared for

operation. This preparation includes verifying hardware installation,

initial power-up, downloading of operating code, verifying GPS

operation, and verifying transmit and receive paths.

2. Next, the optimization is performed. Optimization includes

performance verification and calibration of all transmit and receive

RF paths, and download of accumulated calibration data.

3. A calibration audit of all RF transmit paths may be performed any

time after optimization to verify BTS calibration.

4. After optimization, a series of manual pre- Acceptance Test

Procedure (ATP) verification tests are performed to verify

alarm/redundancy performance.

5. After manual pre-ATP verification tests, an ATP is performed to

verify BTS performance. An ATP is also required to demonstrate

regulation compliance before the site can be placed in service.

Site Expansion

Optimization is required after expansion of a site with additional BTS

frames.

Periodic Optimization

Periodic optimization of a site may also be required, depending on the

requirements of the overall system.

Repaired Sites

NOTE Refer to Appendix B for a detailed FRU Optimization/ATP Test

Matrix outlining the minimum tests that must be performed any

time a BTS RF subassembly or cable associated with an RF path

is replaced.

Required Test Equipment and Software 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-6

Required Test Equipment and Software

Policy

To ensure consistent, reliable, and repeatable optimization test results,

test equipment and software meeting the following technical criteria

should be used to optimize the BTS equipment. Test equipment can, of

course, be substituted with other test equipment models if the equipment

meets the same technical specifications.

It is the responsibility of the customer to account for any measurement

variances and/or additional losses/inaccuracies that can be introduced

as a result of these substitutions. Before beginning optimization or

troubleshooting, make sure that the test equipment needed is on-hand

and operating properly.

Test Equipment Calibration

Optimum system performance and capacity depend on regular equipment

service and calibration prior to BTS optimization. Follow the original

equipment manufacturer (OEM) recommended maintenance and

calibration schedules closely.

Test Cable Calibration

Test cables can make critical differences in optimization accuracy. It is

recommended that cable calibration be run at every BTS with the

complete test equipment set. This method compensates for test cable

insertion loss within the test equipment itself. No other allowance for

test cable insertion loss needs to be made during the performance of

tests.

Another method to account for cable loss is by entering it into the LMF

during the optimization procedure. This method requires accurate test

cable characterization using shop test equipment. Characterized cables

should be tagged with the characterization information, and the

measured losses entered into the LMF before field optimization.

Equipment Warm-up

After arriving at a site, test equipment should be plugged in and turned

on immediately to provide the longest possible time for warm up and

stabilization. The following pieces of test equipment must be warmed up

for a minimum of 60 minutes prior to use for BTS optimization or RFDS

calibration:

SCommunications test set.

SRubidium time base.

SPower meter.

Required Test Equipment and Software68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-7

Required Test Equipment and Software

The following test equipment and software is required for the

optimization procedure. Common assorted tools such as screwdrivers

and frame keys are also needed. Read the owner’s manual for all of the

test equipment to understand its individual operation before using the

tool in the optimization.

NOTE Always refer to specific OEM test equipment documentation for

detailed operating instructions.

LMF Hardware Requirements

An LMF computer platform that meets the following requirements (or

better) is recommended:

SNotebook computer

S266 MHz (32 bit CPU) Pentium processor

S4 GB internal hard disk drive

SSVGA 12.1-inch active matrix color display with 1024 x 768

(recommended) or 800 x 600 pixel resolution and capability to display

more than 265 colors

SMemory requirements:

- Minimum required RAM: 96 MB

- Recommended RAM:

-- 128 MB for Windows 98 SE

-- 256 MB for Windows 2000

S20X CD-ROM drive

S3 1/2 inch floppy drive

S56kbps V.90 modem

SSerial port (COM 1)

SParallel port (LPT 1)

SPCMCIA Ethernet interface card (for example, 3COM Etherlink III)

with a 10BaseT-to-coax adapter

SMSr Windows 98R Second Edition (SE) or Windows 2000 operating

system

NOTE If 800 x 600 pixel resolution is used, the LMF window must be

maximized after it is displayed.

Required Test Equipment and Software 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-8

LMF Software

The Local Maintenance Facility (LMF) application program is a

graphical user interface (GUI)-based software tool. This product is

specifically designed to provide cellular communications field personnel

with the capability to support the following CDMA Base Transceiver

Station (BTS) operations:

SInstallation

SMaintenance

SCalibration

SOptimization

Ethernet LAN Transceiver (part of

CGDSLMFCOMPAQNOV96)

SPCMCIA Ethernet Adpater + Ethernet UTP Adapter

3COM Model - Etherlink III 3C589B

used with

STransition Engineering Model E-CX-TBT-03 10BaseT/10Base2

Converter (or equivalent)

NOTE Xircom Model PE3-10B2 or its equivalent can also be used to

interface the LMF Ethernet connection to the RFM frame.

Ethernet LAN External In/Out Port Adapter

Trompeter Electronics, Inc., ADBJ20-E1-PL75 or equivalent BNC (F)

to TRB (M) adapter is required if it is necessary to connect the LMF

computer to the LAN external interface triaxial connectors located in the

power entry compartment.

RS-232 to GPIB interface

SNational Instruments GPIB-232-CT with Motorola CGDSEDN04X

RS232 serial cable or equivalent; used to interface the LMF to the test

equipment.

SA standard RS-232 cable can be used with the following

modifications:

- Pin 8 (CTS) does not have to be jumpered/shorted to the others as it

is a driver output. The DTR is already a driver output signal. The

other pins are to receivers. Short pins 7, 1, 4, 6 on each cable end:

Required Test Equipment and Software68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-9

9-pin D (female) 9-pin D (female)

GND 5 5 GND

RX 3

3 RXTX 2

2 TX

RTS 7 7 RTS

RSD/DCD 1 1 RSD/DCD

DTR 4 4 DTR

DSR 6 6 DSR

Model SLN2006A MMI interface kit

SMotorola Model TRN9666A null modem board. Connectors on

opposite sides of the board must be used as this performs a null

modem transformation between cables. This board can be used for

25-pin to 8-pin, 25-pin to 25-pin, and 10-pin to 10-pin conversions.

SMotorola 30-09786R01 MMI cable or equivalent; used to interface

the LMF computer serial port connection to the Group Line Interface

(GLI), Clock Synchronization Manager (CSM), External Trunked

Interface Board (ETIB), and module debug serial ports.

Communications system analyzer CDMA/analog

IS-95A/B-only test capability - The following communications system

analyzers which provide only IS-95A/B test capability are supported by

the LMF:

SMotorola CyberTest

SAdvantest R3465 spectrum analyzer with R3561L signal generator

SHewlett Packard Model HP 8921A/600 Analyzer including 83203B

CDMA Interface, manual control system card, and, for 1900 MHz

BTSs, 83236A/B PCS Interface

CDMA2000 1X and IS-95A/B test capability - The following

communications system analyzers which provide both CDMA2000 1X

and IS-95A/B test capability are supported by the LMF:

SAgilent 8935 series E6380A communications test set (formerly HP

8935) with option 200 or R2K for CDMA2000 1X support

SAgilent E4406A

SAdvantest R3267 spectrum analyzer

A combination of test equipment supported by the LMF may also be

used during optimization and testing of the RF communications portion

of BTS equipment when the communications system analyzer does not

perform all of the following functions:

SFrequency counter

SDeviation meter

SRF power meter (average and code domain)

Required Test Equipment and Software 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-10

SRF signal generator (capable of DSAT/CDMA modulation)

SAudio signal generator

SAC voltmeter (with 600-ohm balanced audio input and high

impedance input mode)

SNoise measurement meter

SC-Message filter

SSpectrum analyzer

SCDMA code domain analyzer

GPIB cables

Hewlett Packard 10833A or equivalent; one or two meters long, used to

interconnect test equipment and LMF computer.

CDMA2000 1X signal generators

SAgilent E4432B signal generator (required for use with Agilent

E4406A when performing Frame Erasure Rate acceptance testing)

SAdvantest R3562 signal generator (required for use with Advantest

R3267 when performing Frame Erasure Rate acceptance testing)

Power meter

SHewlett Packard Model HP437B with HP8481A power sensor capable

of measuring from -30 dBm to 20 dBm

SGigatronics 8542B power meter

Timing reference cables

STwo Huber & Suhner 16MCX/11BNC/K02252D or equivalent; right

angle MCX-male to standard BNC-male RG316 cables; 10 ft. long

are required to interconnect the communications system analyzer to

SGLN4132A and SGLN1145A CSM board timing references

STwo BNC-male to BNC-male RG316 cables; 3 meters (10 feet) long,

used to interconnect the communications system analyzer to

SGLN4132B and SGLN1145B (and later) CSM front panel timing

references in the RF Modem Frame

Digital multimeter

Fluke Model 8062A with Y8134 test lead kit or equivalent; used for

precision DC and AC measurements to four decimal places.

Directional coupler

Narda Model 3020A 20 dB coupler terminated with two Narda Model

375BN-M loads, or equivalent.

RF attenuators

S20 dB Fixed attenuator, 20 Watt (Narda 768-20), used in conjunction

with calibration of test cables or during general troubleshooting

procedures.

Required Test Equipment and Software68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-11

S10 dB Fixed attenuator, 20 Watt (Narda 768-10), for cable calibration

with a Cybertest CDMA analyzer.

Clamp-on DC current probe

Amprobe CT600, or equivalent, 600 A capability with jaw size which

accommodates 2/0 cable. Used with the DMM for back-up battery

charging testing.

Miscellaneous RF adapters, loads, etc.

As required to interface test cables and BTS equipment and for various

test setups. Should include at least (2) 50 Ohm loads (type N) for

calibration and (1) RF short.

RF load

100W non-radiating RF load used (as required) to provide dummy RF

loading during BTS transmit tests.

High-impedance conductive wrist strap

Motorola Model 42-80385A59; used to prevent damage from ESD when

handling or working with modules.

Driver bit for tamper-resistant fasteners

Star fastener tamper-resistant insert bit set, Grainger 5F530 or

equivalent, to remove tamper-resistant fasteners securing the frame rear

access cover.

Optional Equipment

This section provides a list of additional equipment that might be

required during maintenance and troubleshooting operations.

NOTE Not all optional equipment specified in this section will be

supported by the LMF in automated tests.

Duplexer

Filtronics Low IM Duplexer (Cm035-f2) or equivalent; used during

Spectral Purity Receive band noise tests.

Frequency counter

Stanford Research Systems SR620 or equivalent; used if direct

measurement of the 3 MHz or 19.6608 MHz references is required.

Spectrum analyzer

Spectrum Analyzer (HP8594E with CDMA personality card) or

equivalent; required for manual tests other than standard Receive band

spectral purity tests performed by the LMF.

LAN tester

Model NETcat 800 LAN troubleshooter (or equivalent); used to

supplement LAN tests using the ohm meter.

Required Test Equipment and Software 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-12

Span line (T1/E1) verification equipment

As required for the local application.

RF test cable (if not provided with test equipment)

Motorola Model TKN8231A; used to connect test equipment to the BTS

transmitter output during optimization or during general troubleshooting

procedures.

Oscilloscope

Tektronics Model 2445 or equivalent; used for waveform viewing,

timing, and measurements, or during general troubleshooting procedures.

2-way splitter

Mini-Circuits Model ZFSC-2-2500 or equivalent; used to provide the

diversity receive input to the BTS.

CDMA subscriber mobile or portable radiotelephone

Safco Model 2136-150 with power supply and antenna; used to provide

test transmission and reception during BTS maintenance and

troubleshooting. Do not substitute other models that do not feature

special test modes. Two radios will be required for system and

drive-around testing after optimization and BTS ATP are completed.

RF circulator

Circulator (FERROCOM 5809866C01) or equivalent; can substitute for

a duplexer during Receive sensitivity Frame Erasure Rate (FER) testing

in conjunction with Safco CDMA mobile.

High stability 10 MHz rubidium standard

Stanford Research Systems SR625 or equivalent. Required for CSM and

Low Frequency Receiver (LFR)/High Stability Oscillator (HSO)

frequency verification.

Required Documents and Related Publications68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-13

Required Documents and Related Publications

Required Documents

The following documents are required to perform optimization of the

cell site equipment:

SSite Document (generated by Motorola Systems Engineering), which

includes:

- General site information

- Floor plan

- RF power levels

- Frequency plan (includes Site PN and operating frequencies)

- Channel allocation (paging, traffic, etc.)

- Board placement

- Site wiring list

-Site-specific CDF file

SDemarcation Document (Scope of Work Agreement)

SEquipment manuals for non-Motorola test equipment

Related Publications

Additional, detailed information about the installation, operation, and

maintenance of the SC4812ET Lite BTS and its components is included

in the following publications:

SCDMA RFDS User’s Guide; 68P64114A51

SLMF Help function on-line documentation

SLMF CLI Reference; 68P09253A56

SCDMA RFDS Hardware Installation; 68P64113A93

SSC4812ET Lite Installation; 68P09253A36

SSC4812ET Lite Field Replaceable Units; 68P09253A49

SSC4812T/ET/ET Lite Troubleshooting; 68P09253A65

SFrame Mounting Guide Analog/CDMA/TDMA; 68P09226A18

SCellular Glossary of Terms and Acronyms; 68P09213A95

SM-PATHt T1 Channel Service Unit User’s Guide, Kentrox part

number 65-77538101

SM-PATH T1 Channel Service Unit Installation Guide, Kentrox part

number 65-77538001

SM-PATH E1 Channel Service Unit User’s Guide, Kentrox part number

1174139

SM-PATH E1 Channel Service Unit Installation Guide, Kentrox part

number 1174662

S2-Slot Universal Shelf Installation Guide, Kentrox part number

65-78070001

Terms and Abbreviations 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-14

Terms and Abbreviations

Standard and Non-standard Terms and Abbreviations

Standard terms and abbreviations used in this manual are defined in

Cellular Glossary of Terms and Acronyms; 68P09213A95. Any

non-standard terms or abbreviations included in this manual are listed in

Table 1-1.

Table 1-1: Non-Standard Terms and Abbreviations

Term or Abbreviation Definition

1X One of two bandwidths currently defined in the IS-2000 CDMA specification,

which extends the capability of the IS-95A and B specifications. 1X bandwidth

provides wireless packet voice and data transmission capability at up to 144

Mbps.

ACLC AC Load Center. An SC4812ET Lite RF Base Transceiver Station (BTS)

subassembly which provides the frame interface for external AC power

connection and internal AC circuit control and protection.

BBXR The redundant BBX for a CCP shelf or cage. In the SC4812ET Lite BTS SCCP

cage, the BBX installed in slot BBX-R1 (Figure 1-6).

BBX-1X Broad Band Transceiver, 1X. Third generation BBX card with CDMA2000 1X

packet as well as IS-95A/B capability.

BBX2 Broad Band Transceiver, second generation, card

CCD Clock Combining and Distribution. SC4812-series BTS CDMA Channel

Processor (CCP) shelf module which accepts timing signals from the active

source and distributes them to other CCP shelf modules.

CIO Combiner Input/Output

companion frame A BTS frame configured to operate at the same site with another companion

frame. Companion frames may share antenna signals, but are not inter-connected

on the same LAN. Companion frames are managed as separate BTSs in the Base

Station System (BSS).

DLM DownLoad Manager. Software application resident on the GLI card which permits

download of software upgrades from the Centralized Base Station Controller

(CBSC) to BTSs without the need for a site visit.

DMAC Digital Metering, Alarm, Control. Part of the Meter Alarm Panel (MAP) which

provides control of and status information for the AC power rectifiers as well as

back-up battery monitoring and test capability. Term is used interchangeably with

MAP (see below).

DPLL Digital Phase-Locked Loop

DRDC Duplexer, Receive Filter, Dual Directional Coupler. Provides duplexing of BTS

transmit and receive signals to a single antenna and antenna signal sampling in

either the forward (transmit) or reflected (receive) direction for use by an RF

Diagnostic Subsystem (RFDS).

EMPC Expansion Multi-coupler Preselector Card. BTS expansion frame MPC module

which is used to receive, amplify, and distribute RX signals from the starter frame

MPC.

. . . continued on next page

Terms and Abbreviations68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-15

Table 1-1: Non-Standard Terms and Abbreviations

Term or Abbreviation Definition

ETIB External Trunked Interface Board. Module providing status indicators and MMI

interface connections for Linear Power Amplifiers (LPA) in SC4812ET and

SC4812ET Lite BTS frames.

GLI2 Group Line Interface card, second generation

HSO High Stability Oscillator. Module providing backup timing source for a BTS when

the timing signal from the GPS or Remote GPS module is unavailable.

HSO2 HSO card, second generation

HSOX HSO Expansion. Module used in a BTS expansion frame to interface with the

starter frame HSO or LFR and distribute the timing signals to the expansion frame

CSM modules.

ISC In-Service Calibration. Technique for performing calibration sector by sector on a

BTS to avoid completely removing the site from service.

LPAC Linear Power Amplifier Controller

LFR2 Low Frequency Receiver, second generation. Low-cost LFR card with capability

to distribute synchronization signals to multiple RF modem frames.

MAP Meter Alarm Panel. SC4812ET Lite Field Replaceable Unit (FRU) which

contains the functions of both the Temperature Compensation Panel (TCP) and

the DMAC. Term is used interchangeably with DMAC.

MCC8E Multichannel CDMA Card supporting 8 IS-95A/B channels.

MCC24E Multichannel CDMA Card supporting 24 IS-95A/B channels.

MCC-1X Multichannel CDMA Card supporting 16 or 48 CDMA2000 1X or (with Software

Release 2.16.0.84.3 and higher) IS-95A/B channels.

MPC Multi-coupler Preselector Card. BTS CCP shelf module used to amplify and

distribute RX signals to BBX modules.

OLF Object List File. File containing a list of the ROM and RAM code versions which

should be operating on every device installed in a BTS. The file is resident on the

Central Base Station Controller (CBSC) Mobility Manager (MM) and is passed to

the GLI after a DLM job is invoked. The GLI uses the OLF to determine which

devices require code download to meet the OLF-specified version.

PDA Power Distribution Assembly. Assembly in an SC4812ET Lite BTS providing

internal DC power distribution and circuit protection.

R16.0 Motorola BSS Software Release 2.16.0.x. The version of the software which must

be loaded on BSS equipment to upgrade it to software release 2.16.0.x and

support initial 1X capability.

RFMF RF Modem Frame

RGD Remote Global Positioning System (GPS) Distribution. Module which provides

distribution of digital timing information to up to four BTS RF modem frames

(RFMFs) from a single Remote GPS receiver.

. . . continued on next page

Terms and Abbreviations 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-16

Table 1-1: Non-Standard Terms and Abbreviations

Term or Abbreviation Definition

RGPS Remote Global Positioning System. GPS receiver and signal distribution

subsystem which provides digital timing information for up to four BTS RFMFs

at a cell site.

RGPS expansion

primary frame BTS frame where the RGD is located and which serves as the distribution point

for RGPS digital timing signals to other (secondary) BTS frames at a cell site.

RGPS expansion

secondary frame BTS frame which receives RGPS digital timing signals distributed from the

primary RGPS expansion frame at a cell site.

RHSO Remote High-Stability Oscillator. Subsystem which generates and distributes

synchronization signals from a single HSO to up to four RF modem frames.

SCCP Small CDMA Channel Processor. The type of CCP shelf used in the SC4812ET

Lite BTS.

test equipment set The LMF computer, communications test set, directional couplers, attenuators,

termination loads, associated test cables, and adapters needed for the complete

calibration and acceptance testing of a BTS. The test equipment set is calibrated

and maintained as a unit. When one component of a set is replaced, the complete

set must be recalibrated to ensure measurement errors are not introduced during

BTS optimization and ATP.

stand-alone frame See starter frame

starter frame A BTS frame which can operate as a stand-alone BTS or serve as the initial frame

in a companion frame installation. After an SC4812ET Lite starter frame is

modified to operate with a companion frame, its configuration is identical to the

added companion frame.

TCP Temperature Compensation Panel. A function of the SC4812ET Lite MAP which

provides the capability to adjust DC voltage output of the rectifiers to compensate

for variations resulting from temperature changes.

TRDC Transmit & Receive Dual Directional Coupler (Non-duplexed, Receive Filter).

TRDCs contains separate transmit and receive paths and bandpass filters which

are not connected electrically. Transmit and receive antenna signals are not

duplexed and must be handled by separate antennas. Each RF path contains a dual

directional coupler on the antenna port which allows sampling of antenna signals

in the forward (transmit) and reflected (receive) directions for use by an RFDS.

BTS Equipment Identification68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-17

BTS Equipment Identification

Equipment Overview

Frame - The SC4812ET Lite BTS frame consists of a single, outdoor,

weatherized cabinet containing RF and power components. The BTS is

functionally similar to the two-cabinet SC4812ET, but provides more

flexibility in site selection because of its smaller footprint and lower

weight. The BTS is powered by 208/240 Vac (North American frame) or

230 Vac (International frame), rectified internally to +27 Vdc, and can

support up to two carriers in a 3-sector configuration. Six-sector

operation is not supported with any SC4812ET Lite configuration.

Frame Configurations - The SC4812ET Lite is available in starter and

companion frame configurations. Following are brief descriptions of

each:

1. Starter - This frame configuration is available with one- and

two-carrier capability with separate antenna sets for each carrier. It

can operate as a stand-alone BTS, or can be modified in the field to

the companion frame configuration.

2. Companion - This frame configuration is available with one- and

two-carrier capability using 2:1 TX combiners and a single antenna

set for the frame. It operates with another SC4812ET Lite

companion frame which has its own antennas and different carriers.

Companion frames share RX signals to provide diversity RX for the

opposite frame. Companion frames allow equipping a single

SC4812ET Lite site with up to four carriers. Each companion frame

is managed in the Base Station System (BSS) as a separate BTS.

Internal components - The BTS frame houses the fan modules, RF

compartment heat exchanger, Small CDMA Channel Processor (SCCP)

shelf, RF Linear Power Amplifier (LPA) modules, LPA trunking

modules, bandpass filters or 2:1 combiners, and Duplexer Directional

Couplers (DRDC) or Triplexer Directional Couplers (TRDC). Power

system components include an AC Load Center (ACLC), rectifiers, a

+27 Vdc Power Distribution Assembly (PDA), backup batteries, battery

heaters, and one duplex GFCI 115 Vac utility outlet.

BTS, Frame, Span, and Device Numbering

BTS and frame numbering - An SC4812ET Lite is a single-frame

BTS. Within a BTS, all RF Modem Frames (RFMF) are identified as

parts of a single, numbered BTS (for example, BTS-812) . Each RFMF

is assigned a unique frame number. SC4812ET Lite BTSs consisting of

either a starter or a companion frame have a single RFMF. Because of

this, each frame is numbered as a BTS -1 frame of its own unique BTS

number. As an example, at a site with two frames in a companion

configuration, each frame would have a different BTS number, such as

BTS-812 and BTS-813 . Each frame would be numbered as frame -1 of

its BTS: BTS-812-1 and BTS-813-1 .

Span numbering - Figure 1-1 shows the frame span configuration for a

BTS consisting of an SC4812ET Lite starter or companion frame. The

figure also shows the BTS-to-CBSC Transcoder span configurations

which can be employed with an SC4812ET Lite BTS.

BTS Equipment Identification 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-18

Figure 1-1: SC4812ET Lite BTS Starter and Companion Frame Span Cabling

BTSSPAN 1

TO XC

BTSSPAN 2

TO XC

(Optional)

Frame 1

FEDC

BTSSPAN 9

TO XC

(Optional)

BTSSPAN

TO XC

(Optional)

BTSSPAN

TO XC

(Optional)

BTSSPAN

TO XC

(Optional)

NOTE:

The SC4812ET Lite BTS has

the capability to connect to up

to six spans; however, the

internal CSUs only support a

maximum of two spans.

SCCP shelf card/module device ID numbers - All Ethernet

LAN-addressable modules in the BTS starter and companion frames at a

single site are also identified with device ID numbers. Refer to

Table 1-2, Table 1-3, and Figure 1-6 for specific device ID numbers.

Table 1-2: SCCP Cage Module Device ID Numbers (Top Shelf)

Frame Module ID Number (Left to Right)

#Power

(PS-1) Power

(PS-2) AMR

-1 GLI-

1MCC BBX BBX-R MPC/

EMPC

-1

1 - - 1 1 1 2 1 2 3 R1 -

Table 1-3: SCCP Cage Module Device ID Numbers (Bottom Shelf)

Frame Module ID Number (Left to Right)

#HSO/

LFR CSM

-1 CSM

-2 CCD

ACCD

BAMR

-2 GLI- 2 MCC BBX SW MPC/

EMPC

-2

1 - 1 2 - - - 2 2 3 4 4 5 6 - -

Cabinet Identification68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-19

Cabinet Identification

Major Components

Figure 1-2 illustrates the external features of the BTS frame, the single

major component of the Motorola SC4812ET Lite. The frame cabinet is

identical for stand-alone (starter) and companion frames.

Figure 1-2: SC4812ET Lite BTS Frame, Starter and Companion

Battery Compartment Door

(Can only be opened after Main Door is open) RF Interface Panel

SCCP Shelf Backplane

Rear Access Panel

Power Entry

and

Network Interface Compartment

SC4812ETL0001-2

Main Door

with Heat Exchanger

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-20

Internal Assembly Identification and Location

Internal Assemblies and FRUs

Figure 1-3 shows the location of the internal assemblies and Field

Replaceable Units (FRU). A brief description of each item is found in

the following paragraphs.

Figure 1-3: Internal Assemblies and FRUs

NOTE Cabinet doors not shown for clarity.

LPAs

SCCP Fans

LPA Trunking

Module

RFDS

SCCP Shelf

Filter/Combiner

Shelf (Bandpass

filters shown)

ETIB

DRDC/TRDC

Shelf

CSU Shelf

MAP

DC PDA

GFCI Utility

Outlet

LPAC

Back-up Batteries

(Heaters underneath batteries)

External

Blower

Assembly

SC4812ETL0002-5

ACLC

Span I/O

ASpan I/O

CSUs

ESD Grounding

Jack

Rectifiers

(Rectifier #1

indicated)

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-21

20-pair Punchblock with Remote GPS Distribution

Module

Assembly installed in the RGPS expansion primary BTS frame which

enables distribution of digital GPS timing signals to other (RGPS

expansion secondary)) BTS frames located at the same cell site. The

assembly is located on the left-hand side of the power entry

compartment (Figure 1-4) at the rear of the frame, opposite the 50-pair

punchblock.

Figure 1-4: 20-pair Punchblock with RGD Module

Rear of Frame

(Power Entry Compartment

Door Open)

Section of Power Entry Compartment

Left-hand Panel (Rotated 30_ Left)

20-pair

Punchblock

(Interconnect

cabling not

shown for

clarity)

RGD

(All interconnect cabling

not shown for clarity.)

ETL0031-1

2:1 Combiners

In the SC4812ET Lite BTS, one 2:1 combiner is used per sector to

combine the trunked LPA-amplified TX signals for two carriers into one

signal for input to the applicable sector DRDC or TRDC.

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-22

50-pair Punchblock

The 50-pair punchblock (Figure 1-5) is the interface between the frame

and the T1/E1 span lines. It is located on the right-hand side of the

power entry compartment at the rear of the frame. The punchblock

provides the initial interconnection between the spans and the

Customer-defined I/O, alarms, multi-frame timing source (Remote GPS

and HSO), and pilot beacon control (optional).

Figure 1-5: 50-Pair Punchblock

Rear of Frame

(Power Entry Compartment

Door Open)

Section of Network Interface Panel

(Rotated 30_ Right)

50-pair

Punchblock

(Cabling not

shown for

clarity)

SC4812ETL0024-2

AC Load Center (ACLC)

The ACLC is the frame entry point for AC power. It incorporates AC

power control, distribution, and surge protection (Figure 1-3). Two

versions are available, depending on the type of AC input power

available at the operating site:

1. International

2. North American

Back-up Batteries

The batteries (Figure 1-3) provide +24 Vdc back-up for the frame should

AC power be interrupted. The frame can accommodate a total of 12 12V

batteries grouped in six strings. Each string consists of two batteries

connected in series for 24 Vdc output. The six strings are connected in

parallel to meet the current-draw requirements of the frame. The

maximum time duration of the back-up capability depends on system

configuration.

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-23

Battery Heaters

The battery heater pads warm the batteries to provide improved

cold-weather performance. A separate heater pad is required for each

battery string and is located between each battery string and its

respective support shelf.

Channel Service Units (CSU) (Optional)

The SC4812ET Lite can be equipped with up to two M-PATH 537 CSU

modules for T1 spans or two M-PATH 437 CSU modules for E1 spans.

These modules install in the CSU shelf (Figure 1-3). The CSUs allow

monitoring of span performance and provide capability for remote

network management.

CSU Shelf

The CSU shelf is an ADC Kentrox 2-slot Universal Shelf which can

accommodate two M-PATH 537 or two M-PATH 437 CSU modules.

When the optional CSU modules are not installed, cover plates are

installed over the CSU card slots (Figure 1-3).

DC Power Distribution Assembly (PDA)

Both rectifier output voltage and back-up battery voltage are routed to

the PDA (Figure 1-3) where they are combined into system DC bus

voltage. The PDA provides distribution of DC power and system DC

bus protection from the loads with MAIN BREAKER and the smaller

post-distribution circuit breakers. MAIN BREAKER permits removal of

all frame loading from the bus. The 13 post-distribution circuit breakers

permit removal of individual loads.

Duplexer, Receive filter, Dual Directional Coupler

(DRDC)

DRDCs permit duplexing of sector transmit and receive signals on a

single antenna. The DRDCs also incorporate a receive bandpass filter

and dual directional couplers which permit signal monitoring by the RF

Diagnostic Subsystem.

ET Interface Board (ETIB) and LPA Control (LPAC)

Board

The ETIB is an interconnect module with status LEDs, MMI receptacles,

and secondary surge protection for the LPA modules. The LPAC board

provides the interface for the LPA connections (Figure 1-3).

Filter/Combiner Shelf (Bandpass Filters or 2:1

Combiners)

The filter/combiner shelf (Figure 1-3) holds the transmit bandpass filters

or 2:1 combiners, depending on system configuration.

Heat Exchanger

The heat exchanger provides cooling to the frame RF compartment. The

fan speed of the heat exchanger adjusts automatically with temperature.

The heat exchanger is located in the frame main door (Figure 1-2).

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-24

Rectifiers

The rectifiers (Figure 1-3) convert AC power supplied to the frame to

+27.4 Vdc which powers the frame and maintains the charge of the

back-up batteries. Rectifier positions are numbered 1 through 4 from left

to right when facing the frame. Single-carrier frames are equipped with

three rectifiers installed in positions 1, 2, and 3. Two-carrier frames are

equipped with four rectifiers. The number of rectifiers supplied with

each configuration provides N+1 redundancy.

RF Diagnostic Subsystem (RFDS)

The RFDS (Figure 1-6) provides capability for remotely monitoring the

status of the SC4812ET Lite transmit and receive paths. For IS-95A/B

operation, the RFDS is a COBRA model. To support 1X operation, the

RFDS must the 1X-capable COBRA-II.

Small CDMA Channel Processor (SCCP) Shelf

The SCCP shelf has provisions for the following types and quantities of

modules (Figure 1-3 and Figure 1-6):

SAlarm Monitoring and Reporting (AMR) cards (2)

SBroad Band Transceiver, second generation or 1X, (BBX2 or

BBX-1X) cards, primary (6)

SBBX2 or BBX-1X card, redundant (1)

SCDMA Clock Distribution (CCD) cards (2)

SClock Synchronization Manager (CSM) on two cards (one with GPS

receiver, if ordered)

SCombiner Input/Output (CIO) card (1)

SFan modules (2)

SFiller panel (as required)

SGroup Line Interface, second generation, (GLI2) cards (2)

SHigh Stability Oscillator (HSO)/Low Frequency Receiver (LFR) card

(Optional) (1)

SMulti-coupler Preselector Cards (MPC) (2 per starter frame; 1 per

companion frame)

SExpansion Multi-coupler Preselector Card (EMPC) (1 per companion

frame)

SMulti-Channel CDMA (MCC8E, MCC24E, or MCC-1X) cards (4)

SPower supply cards (2)

SSwitch card (1)

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-25

Figure 1-6: SCCP Shelf, IS-95A/B and 1X Devices

FILLER POWER 1 POWER 2

HSO/LFR CSM 1 CSM 2 CCD AMR GLI

1 2

3 4

MCC

1 2 3

4 5 6

BBX R1

SWITCH

MPC

MPC, EMPC

CSM

Power Supply

MPC

CSM

CCDCCD

AMR

HSO

AMR

GLI2 GLI2

BBX2, BBX-1X

SWITCH

19mm Filler Panel

MCC8 E, MCC24E, MCC-1X

SC4812ETL0003-6

NOTES:

1. MCCs may be MCC8Es, MCC24Es,

or MCC-1Xs

2. BBXs may be BBX2s or BBX-1Xs

3. EMPC cards are used in slot MPC 2 in

companion frames to receive RX

diversity signals provided by the other

companion frame.

MCC8 E, MCC24E, MCC-1X

BBX2, BBX-1X

FRAME 1

(starter and companion)

CIO

Span I/O Boards

The two span I/O boards, Span I/O A and Span I/O B (Figure 1-3),

provide the span line interface from the punchblock or the CSU

modules, if equipped, to the SCCP backplane.

Transmit & receive, non-duplexed, Receive filter, Dual

Directional Coupler (TRDC)

TRDCs provide separate, bandpass-filtered sector transmit and receive

paths. When TRDCs are used, separate transmit and receive antennas are

required for each sector. As with DRDCs, dual directional couplers for

each antenna path are incorporated in TRDCs to permit signal

monitoring by the RFDS.

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-26

Figure 1-7: RF Interface Panel, Starter Frame, DRDCs Installed

GROUND

1A 2A 3A 1B 2B 3B

ANTENNAS

TX OUT

123

SC4812ETL0018-3

TX IN

123

REMOTE ASU

1A 2A 3A 1B 2B 3B

RX EXPANSION

DUPLEXED TX &

RX PORTS

NOTES:

1. CARRIER 1:

TX AND RX MAIN

USE ANTENNA

PORTS 1A, 2A, 3A.

RX DIVERSITY USES

PORTS 1B, 2B, 3B.

2. CARRIER 2:

TX AND RX

DIVERSITY USE

ANTENNA PORTS

1B, 2B, 3B.

RX MAIN USES

PORTS 1A, 2A, 3A.

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-27

Figure 1-8: RF Interface Panel, Starter Frame, TRDCs Installed

GROUND

1A 2A 3A 1B 2B 3B

REMOTE ASU

1 2

TX OUT

1 2 3 1A 2A 3A 1B 2B 3B

RX EXPANSION

RX PORTS

TX PORTS

NOTES:

1. CARRIER 1

TX USES TX PORTS 1A,

2A, 3A;

RX MAIN USES RX

PORTS 1A, 2A, 3A;

RX DIVERSITY USES

RX PORTS 1B, 2B, 3B

2. CARRIER 2:

TX USES TX PORTS 1B,

2B, 3B;

RX MAIN USES RX

PORTS 1A, 2A, 3A;

RX DIVERSITY USES

RX PORTS 1B, 2B, 3B

SC4812ETL0019-4

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-28

Figure 1-9: RF Interface Panel, Companion Frame, 2:1 Combiners and DRDCs

TX IN

123

1A 2A 3A 1B 2B 3B

RX EXPANSION

NOTES:

1. CARRIER 1:

TX AND RX MAIN USE

ANTENNA PORTS 1A, 2A,

RX DIVERSITY

RECEIVED FROM

COMPANION FRAME

THROUGH RX

EXPANSION PORTS 1B,

2B, 3B.

2. CARRIER 2:

TX AND RX MAIN USE

ANTENNA PORTS 1A, 2A,

CARRIER 2 RX

DIVERSITY RECEIVED

FROM COMPANION

FRAME THROUGH RX

EXPANSION PORTS 1B,

2B, 3B.

3. COLLOCATED

COMPANION FRAME

CARRIER 1 & 2 RX

DIVERSITY PROVIDED

THROUGH RX

EXPANSION PORTS 1A,

2A, 3A.

SC4812ETL0025-2

GROUND

2A 3A 1B 2B 3B

ANTENNAS

TX OUT

123

REMOTE ASU

RX DIVERSITY

IN FROM

COLLOCATED

COMPANION

FRAME

DUPLEXED

TX & RX

PORTS

RX MAIN EXPANSION

OUTPUTS (TO RX

DIVERSITY EXPANSION

INPUTS OF COLLOCATED

COMPANION FRAME)

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-29

Figure 1-10: RF Interface Panel, Companion Frame, 2:1 Combiners and TRDCs

TX IN

123

1A 2A 3A 1B 2B 3B

RX EXPANSION

SC4812ETL0026-2

GROUND

2A 3A 1B 2B 3B

ANTENNAS

TX PORTS

TX OUT

123

REMOTE ASU

RX PORTS

NOTES:

1. CARRIER 1:

TX USES TX PORTS 1A,

2A, 3A;

RX MAIN USES RX PORTS

1A, 2A, 3A;

RX DIVERSITY RECEIVED

FROM COLLOCATED

COMPANION FRAME

THROUGH RX EXPANSION

PORTS 1B, 2B, 3B.

2. CARRIER 2:

TX USES TX PORTS 1A,

2A, 3A;

RX MAIN USES RX PORTS

1A, 2A, 3A;

RX DIVERSITY RECEIVED

FROM COLLOCATED

COMPANION FRAME

THROUGH RX EXPANSION

PORTS 1B, 2B, 3B.

3. COLLOCATED

COMPANION FRAME

CARRIER 1 & 2 RX

DIVERSITY PROVIDED

THROUGH RX EXPANSION

PORTS 1A, 2A, 3A.

RX DIVERSITY

IN FROM

COLLOCATED

COMPANION

FRAME

RX MAIN EXPANSION

OUTPUTS (TO RX

DIVERSITY EXPANSION

INPUTS OF COLLOCATED

COMPANION FRAME)

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-30

Figure 1-11: RFDS, DRDC, and TRDC Details

BTS

CPLD

ANT

CPLD

DRDC

TRDC

TX BTS

CPLD

RX BTS

CPLD

TX ANT

CPLD

RX ANT

CPLD

DUPLEXED

TX & RX ANTENNA

ANTENNA

1A1B 2A2B3B 3A

DRDC/TRDC

ANTENNA CONNECTOR

ASSIGNMENTS

RFDS

SC4812ETL0005-4

Internal Assembly Identification and Location68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-31

Figure 1-12: 2:1 Combiner Details, Companion Frame Only

DRDC/TRDC

ANTENNA CONNECTOR

ASSIGNMENTS

SC4812ETL0027-1

2:1 Combiner

Retaining

Screw

Handle

Output Connector

(To DRDC/TRDC

TX Input)

2:1 COMBINER-TO-

DRDC/TRDC

ASSIGNMENTS BY

ANTENNA CONNECTOR

Two Blind-mate Input

Connectors on Rear

Panel

(Amplified TX RF from

LPA Trunking Modules)

Internal Assembly Identification and Location 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-32

SCCP Cage Configuration and 1X Devices

SC4812ET Lite frames have one SCCP cage which will support up to

four MCC cards and six BBX cards.

MCC Cards

A BTS may be configured with a mix of MCC-8E, MCC-24E, and

MCC-1X cards. Any SCCP cage MCC card slot will support any of the

three MCC types. For 1X capability under R16.0, at least one MCC card

must be an MCC-1X which can be installed in any MCC card slot. In a

BSS operating with Software Release 2.16.0.84.3 and higher, MCC-1X

cards will support IS-95A and B traffic as well as CDMA2000 1X.

When operating with Software Release 2.16.0.5x.x, the MCC-1X cards

do not support IS-95A/B operation. For additional software release

compatibility and capability information, contact the local Motorola

account team.

BBX Cards

Up to six BBX cards of mixed BBX2s and BBX-1Xs can also be

supported. SCCP cage BBX2 card slots 1 through 6 are carrier- and

sector-dependent. As a result, the BBX slots dedicated to the sectors for

one carrier should be populated with the same type of cards. Refer to

Table 1-5 for BBX card slot carrier and sector correlations.

The SCCP cage R1 card slot is dedicated to the redundant BBX. This

slot will support either a BBX2 or a BBX-1X. If a cage has BBX-1X

carriers, the redundant BBX (BBXR) must be a BBX-1X card to provide

1X redundancy.

BBX-1X and BBX2 Interchangeability

In a BSS operating with R16.0 software, BBX-1X cards can be used as

direct replacements for BBX2 cards; however, different types of BBXs

should not be mixed on the same carrier. Therefore, if a BBX2 card is

replaced with a BBX-1X, all remaining BBX2 cards for the carrier

supported by the replaced card must also be replaced with BBX-1X

cards.

BTS Sector Configurations68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-33

BTS Sector Configurations

Sector Configuration

There are a number of ways to configure the BTS frame. Table 1-4

outlines the basic requirements. For more detailed information also see

Table 1-5 and Figure 1-13. Bandpass filters are used for single-carrier

configurations and two-carrier systems when carriers are either adjacent

or not adjacent

Table 1-4: BTS Sector Configuration

Number of

Carriers Number of

Sectors Channel Spacing Filter Requirements

1 3 N/A Bandpass Filter or 2:1 Combiner

2 3 Adjacent or

Non-adjacent Bandpass Filter

2 3 Non-adjacent 2:1 Combiner

The matrix in Table 1-5 shows the correlation between the various sector

configurations and BBX cards.

BTS Sector Configurations 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-34

Table 1-5: Sector Configurations

Configuration Description

3-Sector / 1 Carrier

The configuration below maps RX and TX with bandpass filters for a 3-sector/1-carrier frame.

ANT 1A ANT 2A ANT 3A ANT 1B ANT 2B ANT 3B

1TX1 / RX1A TX2 / RX2A TX3 / RX3A RX1B RX2B RX3B Carrier #

BBX-1 BBX-2 BBX-3 BBX-1

(diversity

RX)

BBX-2

(diversity

RX)

BBX-3

(diversity

RX)

3-Sector / 1 Carrier

The configuration below maps RX and TX with 2:1 combiners for 3-sector/1-carrier frames in

companion configuration.

ANT 1A ANT 2A ANT 3A ANT 1B ANT 2B ANT 3B

TX1 / RX1A TX2 / RX2A TX3 / RX3A Carrier #

BBX-1 BBX-2 BBX-3 1

2NOTE

Diversity RX (RX1B, 2B, and 3B) is received from the opposite companion frame through RX

EXPANSION connectors 1B, 2B, and 3B (see Figure 1-9 or Figure 1-10).

Diversity RX is provided to the opposite companion frame from antenna connectors 1A, 2A, and 3A

through RX EXPANSION connectors 1A, 2A, and 3A.

3-Sector / 2-ADJACENT or 2-NON-ADJACENT Carriers

The configuration below maps RX and TX with bandpass filters for 3-sectors/2-carriers for both

adjacent and non-adjacent channels.

ANT 1A ANT 2A ANT 3A ANT 1B ANT 2B ANT 3B

TX1 / RX1A TX2 / RX2A TX3 / RX3A TX4 / RX1B TX5 / RX2B TX6 / RX3B Carrier #

3BBX-1 BBX-2 BBX-3 BBX-1

(diversity

RX)

BBX-2

(diversity

RX)

BBX-3

(diversity

RX)

BBX-4

(RX) BBX-5

(RX) BBX-6

(RX) BBX-4

(TX &

diversity

RX)

BBX-5

(TX &

diversity

RX)

BBX-6

(TX &

diversity

RX)

3-Sector / 2-NON-ADJACENT Carriers

The configuration below maps RX and TX with 2:1 combiners for 3-sectors/2-carriers for

non-adjacent channels for frames in companion configuration.

ANT 1A ANT 2A ANT 3A ANT 1B ANT 2B ANT 3B

TX1 & 4 /

RX1A & 4A TX2 & 5 /

RX2A & 5A TX3 & 6 /

RX3A & 6A Carrier #

BBX-1 BBX-2 BBX-3 1

4BBX-4 BBX-5 BBX-6 2

NOTE

Diversity RX (RX1B, 2B, 3B and RX4B, 5B, 6B) is received from the opposite companion frame

through RX EXPANSION connectors 1B, 2B, and 3B (see Figure 1-9 or Figure 1-10).

Diversity RX is provided to the opposite companion frame from antenna connectors 1A, 2A, and 3A

through RX EXPANSION connectors 1A, 2A, and 3A.

BTS Sector Configurations68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-35

Figure 1-13: SC4812ET Lite LPA Configuration with Bandpass Filters and 2:1 Combiners

(Stand-alone and Companion Frames)

Table 1-5

Configuration Numbers 1 and 3

Stand-alone Frames

3-Sector

Bandpass Filters

CARRIER 1

SECTOR 1, 2, 3

CARRIER 2

SECTOR 1, 2, 3

SC4812ETL0011-4

Table 1-5

Configuration Numbers 2 and 4

Companion Frames

3-Sector

2:1 Combiners

CARRIER 1

SECTOR 1, 2, 3

CARRIER 2

SECTOR 1, 2, 3

BTS Sector Configurations 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

1-36

Notes

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-1

Chapter 2

Preliminary Operations

Preliminary Operations: Overview 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-2

Preliminary Operations: Overview

Introduction

This section first verifies proper frame equipage against the site-specific

documentation supplied for each BTS application.. This includes

verifying module placement, jumper, and dual in-line package (DIP)

switch settings. Next, pre-power up and initial power-up procedures are

presented. Finally, power-down and normal power-up procedures are

covered.

Cell-site Types

Sites are configured as 3-sector with one or two carriers. Each type has

unique characteristics and must be optimized accordingly.

Configuration Data File

The Configuration Data File (CDF), also called Cell-site Data File,

contains site type and equipage data information. The LMF application

program reads data directly from the CDF during optimization. The

number of BTS frames, number and types of BBX and MCC boards, and

linear power amplifier assignments are some of the equipage data

included in the CDF.

Site Equipage Verification

Review the site documentation. Match the site engineering equipage data

to the actual boards and modules shipped to the site. Physically inspect

and verify the equipment provided for the frame.

CAUTION Always wear an approved anti-static wrist strap while handling

any circuit card/module to prevent damage by ESD. After

removal, the card/module should be placed on a conductive

surface or back into the anti-static packaging in which it was

shipped.

Initial Installation of Boards/Modules

Table 2-1: Initial Installation of Boards/Modules

Step Action

1Refer to the site documentation and, if it was not previously done, slide all boards and modules into

the appropriate shelves as required. DO NOT SEAT the boards and modules at this time.

2As the actual site hardware is installed, record the serial number of each module on a “Serial Number

Checklist” in the site logbook.

Preliminary Operations: Overview68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-3

Setting Frame SCCP Configuration Switch

The backplane configuration switch is located behind the frame rear

access panel. It must be set for the frame type as shown in Figure 2-1.

The switch setting must be verified and set before power is applied to the

BTS equipment.

Figure 2-1: Backplane DIP Switch Settings

REAR ACCESS

PANEL

T-27 BUTTON HEAD OR

T-30 PAN HEAD

TAMPER-RESISTANT

FASTENER (14) SC4812ETL0022-1

OFF

STARTER

OR COMPANION

FRAME SETTING

(FRAME 1)

Ethernet LAN 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-4

Ethernet LAN

Ethernet LAN Termination

For proper operation, each end of the primary and redundant BTS

Ethernet Local Area Networks (LAN) must be terminated with a

50-ohm load. For a BTS consisting of a stand-alone or a companion

frame, this is done by placing 50-ohm triaxial terminations on the LAN

A and B external IN and OUT connectors located in the power entry

compartment (Figure 2-2).

Check the LAN A and B external IN and OUT connectors in the power

entry compartment of each frame, and be sure terminations are installed

on all the uncabled external LAN connectors.

Figure 2-2: External Ethernet LAN Connectors

Rear of Frame

(Power Entry Compartment

Door Open)

Section of Network Interface Panel

(Rotated 30_ Right)

LAN A OUT

LAN B OUT

LAN A IN

LAN B IN

SC4812ETL0024-2

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-5

Initial Power-up

Introduction

The following information is used to check for any electrical short

circuits and to verify the operation and tolerances of each frame at the

site before applying power for the first time. It contains instructional

information on the proper initial power up procedures for the SC4812ET

Lite stand-alone and companion frames for both the North American

version and the International version. If directions are different for either

version, they are called out within the procedure. Please pay attention to

all cautions and warning statements in order to prevent accidental injury

to personnel.

NOTE Unless otherwise noted, all procedures in this section are to be

followed for each frame at a site.

Required Tools

The following tools are used in the procedures.

SClamp-on DC current probe (600 A capability with jaw size to

accommodate 2/0 cable).

SDigital Multimeter (DMM) with standard 2mm (.080”) tip probes

SHot Air Gun - (optional for part of the Alarm Verification)

Cabling Inspection

Using the site-specific documentation generated by Motorola Systems

Engineering, verify that the following cable systems are properly

connected:

SReceive RF cabling - up to six RX cables

STransmit RF cabling - up to six TX cables

SFor companion frame installations, inter-frame RX diversity cabling -

six RX cables

NOTE For DC power applications (+27 V):

SThe positive power cable is red.

SThe negative power cable is black. (The black power cable is

at ground potential.)

Initial Inspection and Setup

CAUTION Ensure all battery shelf circuit breakers (Figure 2-3) for unused

battery positions are set to OFF (pulled out) before and during

the entire power up process. Leave these breakers in the OFF

position when leaving the site.

Table 2-2: Initial Inspection and Setup

Step Action

1Be sure that the facility circuit breaker controlling external AC power supplied to the frame is set to

OFF.

2Be sure that all AC Load Center (ACLC) (Figure 2-4 or Figure 2-5), all DC Power Distribution

Assembly (PDA) (Figure 2-6), and all battery shelf circuit breakers (Figure 2-3) are set to OFF.

. . . continued on next page

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-6

Table 2-2: Initial Inspection and Setup

Step Action

3Confirm that the Meter Alarm Panel (MAP) POWER switch and all LEDs (Figure 2-9) are OFF. If

any LEDs are lighted, re-check and turn OFF all battery shelf circuit breakers.

4If a heat source was placed in the RF compartment to prevent condensation prior to BTS power-up,

turn off the heat source and remove it and any associated cabling from the BTS before proceeding.

5Verify that the external AC power supply is correctly connected to the ACLC input by performing the

procedure in Table 2-4.

Figure 2-3: Frame Power Subassemblies, North American and International Cabinets

LPAs

SCCP Fans

RFDS

SCCP Shelf

ETIB

Meter Alarm

Panel (MAP)

With TCU

DC PDA

Backup Batteries

(Heaters underneath batteries)

External Blower

Assembly

SC4812ETL0002-4

Battery Shelf

Circuit Breakers

(Between Bus Bar

and Cabinet Wall)

Utility

Outlet

ACLC Circuit Breaker

Access Door

NOTE:

GFCI capability is built into the Utility Outlet of the North American Cabinet.

GFCI capability is built into the circuit breakers of the International Cabinet

Rectifier

#2 Rectifier

#3 Rectifier

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-7

Figure 2-4: ACLC Circuit Breaker Panel - North American

LEDs

SC4812ETL0008-1

ATTENTION

CAUTION

LIVE TERMINALS

RECT. 1/3 RECT. 2/4 GFIHEATERMAIN

Figure 2-5: ACLC Circuit Breaker Panel - International

ATTENTION

CAUTION

LIVE TERMINALS

LEDs

SC4812ETL0008-29

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-8

Figure 2-6: DC PDA

SC4812ETL0009-3

LPA

1B 1D 3B 3D

1A 1C 3A 3C PS1 PS2

ETIB

OPTIONS

25 25

HEAT EXCHANGER

CAUTION

SHUT OFF BOTH BREAKERS

ONLY DURING HEAT EXCHANGER

MAINTENANCE OR REPAIR

LPA

BLOWERS

PUSH BUTTON

TO RESET

LPA BLOWERS

MAIN BREAKER

300

50 5010 1530 30 30 30 15

PILOT

BEACON

DC Power System Pre-power Application Test

Before applying any power to the BTS frame, follow the procedure in

Table 2-3 to verify there are no shorts in the DC power distribution

system.

NOTE The procedure in Table 2-3 is required only on initial frame

power-up or following maintenance when any major power

components (e.g., ACLC, DC PDA, Meter Alarm Panel) were

replaced or internal DC power cables were disconnected.

Table 2-3: DC Power System Pre-Power Application Test

Step Action

1Physically verify all ACLC front-panel circuit breakers (Figure 2-4) are OFF (down), all DC PDA

circuit breakers (Figure 2-6) are set to OFF (pulled out), and all battery shelf circuit breakers

(Figure 2-3) are OFF (pulled out).

2Visually ensure that all AC rectifier modules (Figure 2-3) are not powered (DC, PWR, and bar graph

LEDs are not lighted), that the MAP power switch (Figure 2-9) is OFF, and that no LEDs on the

MAP are lighted.

3Inside the battery compartment, measure the voltage between the + (red) and - (black) battery bus

bars. There should be no 27 Vdc present.

4NOTE

Do not unseat the AC rectifier modules in the following step.

Perform the following:

4a - In the frame RF compartment, unseat all circuit boards/ modules (except CCD and CIO cards) in

the SCCP shelf, but leave them in their respective slots.

4b - In the frame LPA compartment, disconnect the Linear Power Amplifier (LPA) cables from the

compartment bulkhead feed-through connector.

5Set the DMM to measure resistance, and inside the battery compartment, measure the resistance

between the + (red) and - (black) battery bus bars. The resistance should measure > 1 ΜΩ.

6Leave the DMM set to measure resistance, and insert the probes into the MAP VOLT and AMP TEST

POINTS (Figure 2-9). Place the (+) DMM probe into the (-) AMP TEST POINT. Place the (-) DMM

probe into the (-) VOLT TEST POINT. Resistance should measure greater than 750 Ω.

. . . continued on next page

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-9

Table 2-3: DC Power System Pre-Power Application Test

Step Action

7On the DC PDA, set the MAIN BREAKER to the ON position by pushing it in. Resistance between

the MAP (-) VOLT TEST POINT and the (-) AMP TEST POINT should measure between 300 Ω.

minimum 900 Ω. maximum.

8Before proceeding, be sure the SCCP shelf power/converter modules PS1 and PS2 are correct by

verifying that the locking/retracting tabs appear as follows:

- (in +27 volt systems)

! CAUTION

Using the incorrect type of power/converter modules will damage the module, the SCCP shelf, and

other modules installed in the SCCP shelf.

9NOTE

In the following steps, if the DMM reads between 300 Ω minimum and 900 Ω maximum after

inserting any board/module, a low impedance problem probably exists in that board/module. Replace

the suspect board/module and repeat the test. If test still fails, isolate the problem before proceeding.

Insert and lock the PS1 DC-DC converter module into its slot, and and turn ON the PS1 DC circuit

breaker on the DC PDA.

10 Resistance between the MAP (-) VOLT TEST POINT and the (-) AMP TEST POINT should

typically increase as capacitors charge, finally measuring between 300 Ω minimum and 900 Ω.

maximum.

11 Repeat steps 9 and 10 for the PS2 converter module/circuit breaker and all other remaining modules in

the SCCP shelf.

12 On the DC PDA, set the LPA 1A-1B circuit breaker to the ON position by pushing it in, and repeat

step 10.

13 Repeat step 12 for each of the three remaining LPA circuit breakers.

14 Carefully reconnect each LPA cable one at a time. Repeat step 10 after reconnecting each cable.

- A typical response is that the ohmmeter will steadily climb in resistance as module input

capacitors charge, finally indicating between 300 Ω minimum and 900 Ω. maximum.

15 Set the Pilot Beacon, both Heat Exchanger, ETIB, and Options circuit breakers to ON one at a time.

Repeat step 10 after pushing in each circuit breaker.

16 Set all DC PDA circuit breakers to OFF (pulled out).

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-10

External AC Power Connection Verification

Following verification of frame DC power system integrity, external AC

power connections must be verified. To accomplish this, the series of AC

voltage measurements specified in Table 2-4 is required.

CAUTION Failure to properly connect the external AC power cable will

damage the surge protection module inside the ACLC.

Table 2-4: AC Voltage Measurements

Step Action

1NOTE

This procedure is required only after external AC power wiring has been initially connected or

removed and reconnected to the frame.

n WARNING

Ensure the frame is unpowered by setting the facility circuit breaker controlling external AC power

supplied to the frame to OFF.

Physically verify all DC PDA circuit breakers are set to OFF (pulled out), and all battery shelf circuit

breakers are OFF (pulled out).

2Open the ACLC circuit breaker access door, and set all ACLC circuit breakers to OFF (down).

3Remove the four screws securing the ACLC front panel assembly, and remove the ACLC front panel

assembly to gain access to the AC circuit breaker input terminals (Figure 2-8).

4Apply external AC power to the frame by setting the facility circuit breaker to ON.

5n WARNING

Do not perform the following steps while wearing an anti-static wrist strap. Serious personal injury

can result from accidently shorting high voltage or high current circuits to ground.

! CAUTION

North AMERICAN Cabinet only:

If the AC voltages measured in the following steps exceed 120 V when measuring from terminals L1

or L2 to neutral or ground, STOP and DO NOT proceed until the cause of the higher voltages are

determined. The frame will be damaged if the Main breaker is turned on with excessive voltage on the

inputs.

Measure the AC voltage from terminal L1 to neutral.

North American Cabinet:

- Voltage should be in the nominal range of 115 to 120 Vac.

International Cabinet:

- Voltage should be in the nominal range of 210 to 240 Vac.

6Measure the AC voltage from terminal L1 to ground.

North American Cabinet:

- Voltage should be in the nominal range of 115 to 120 Vac.

International Cabinet:

- Voltage should be in the nominal range of 210 to 240 Vac.

7Steps 7a through 7c apply to the North American cabinet only. If working on a International cabinet

continue to step 8.

. . . continued on next page

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-11

Table 2-4: AC Voltage Measurements

Step Action

7a - Measure the AC voltage from terminal L2 to neutral on the North American cabinet.

-- Voltage should be in the nominal range of 115 to 120 Vac.

7b - Measure the AC voltage from terminal L2 to ground on the North American cabinet.

-- Voltage should be in the nominal range of 115 to 120 Vac.

7c ! CAUTION

If the AC voltages measured (on the North American cabinet) in the following step exceeds 240 V

when measuring between terminals L1 and L2, STOP and DO NOT proceed until the cause of the

higher voltages are determined. The frame will be damaged if the Main breaker is turned on with

excessive voltage on the inputs.

- Measure from terminal L1 to terminal L2.

-- Voltage should be in the nominal range from 208 to 240 Vac.

8Remove external AC power from the frame by setting the facility circuit breaker to OFF.

9Install the ACLC front panel assembly and secure with the four screws removed in step 1.

10 Apply external AC power to the frame by setting the facility circuit breaker to ON.

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-12

Figure 2-7: ACLC Voltage Measurement Probe Points - North American

G= Ground

N = Neutral

L1 = Line 1

L2 = Line 2

L2 L1

(ACLC front panel assembly

removed.)

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-13

Figure 2-8: ACLC Voltage Measurement Probe Points - International

G= Ground

N = Neutral

L1 = Line 1

(ACLC front panel assembly

removed.)

Applying AC Power

Once the external AC power connections are verified, AC power may be

applied internally to the frame. Table 2-5 provides the procedure for

applying internal AC power.

Table 2-5: Applying Internal AC Power

Step Action

1Be sure the requirements of Table 2-4 for AC input power connection verification have been met.

2Be sure all DC PDA circuit breakers are set to OFF (pulled out), all ACLC front-panel circuit

breakers are OFF (down), and all battery shelf circuit breakers are OFF (pulled out).

3Be sure the MAP power switch, TCP switch, and BATT TEST switch are all set to OFF.

. . . continued on next page

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-14

Table 2-5: Applying Internal AC Power

Step Action

4If it has not already been done, set the facility circuit breaker supplying AC power to the frame

to ON.

5Set the ACLC MAIN circuit breaker ON.

- For the North American cabinet:

Observe that all eight (8) green LEDs on the front of the ACLC are illuminated (Figure 2-4).

- For the International cabinet:

Observe that all four (4) green LEDs on the front of the ACLC are illuminated (Figure 2-5).

6On the ACLC, set RECT. 1/3 and then RECT. 2/4 branch circuit breakers ON. All the installed

rectifier modules (Figure 2-3) will start up, and the green DC and PWR LEDs should light on each.

7Set the MAP power switch to ON. The MAP VOLT display should read 27.4 + 0.2 VDC with the

TCP switch OFF.

! CAUTION

Once power is applied to the MAP, be careful not to short either of the VOLT TEST POINTS to

ground. Failure to comply will result in severe damage to the MAP.

8On the MAP, set the TCP switch (Figure 2-9) to ON. Verify no alarm LEDs are lighted on the MAP.

NOTE

Depending on battery compartment temperature, the rectifier voltage displayed on the MAP VOLT

indicator may change by as much as +1.5 V when the TCP is set to on.

9Check the rectifier current bar graph displays (green LED display on the rectifier module). None

should be lighted at this time.

10 If batteries are fitted, set the ACLC HEATER circuit breaker to ON.

NOTE

The GFCI AC circuit breaker should remain OFF unless the GFCI outlet is in use.

Figure 2-9: Meter Alarm Panel (MAP)

POWER

SWITCH

POWER

INDICATOR

TCP

SWITCH VOLT TEST

POINTS

25_C SET

MASTER

VOLTAGE

ADJ.

BATT TEST

SWITCH

SC4812ETL0015-2

TO DISABLE

SENSOR FAIL

SENSOR 2

SENSOR 1

COMM

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-15

DC Power Application and Testing

Table 2-6 lists the step-by-step instructions for applying DC power and

ensuring the DC power system components are correctly functioning.

Table 2-6: DC Power Application and Tests

Step Action

1Be sure all DC PDA and battery shelf circuit breakers are OFF (pulled out).

2Be sure the procedures in Table 2-3 (if applicable) and Table 2-5 have been performed.

3! CAUTION

When measuring voltage at the VOLT TEST POINTS, be careful not to short either of the test points

to ground. Failure to comply will result in severe damage to the MAP.

Measure voltage at the MAP VOLT TEST POINTS while pressing the 25° C SET button

(Figure 2-9). The voltage should read 27.4 + 0.2 Vdc. Adjust with the MASTER VOLTAGE ADJ. on

the MAP, if necessary, to obtain an indicated 27.4+0.2 Vdc. Release the 25° C SET button.

4Depending on the ambient temperature, the voltage reading may now change by up to + 1.5 V

compared to the reading just measured. If it is cooler than 25_C, the voltage will be higher, and if it is

warmer than 25_C, the voltage will be lower.

5Inside the battery compartment, measure the voltage between the cable connection point at the bottom

of the + (red) battery bus bar and chassis ground, observing that the polarity is correct. The voltage

should be the same as the measurement in step 4.

6Measure the voltage between the + (red) and - (black) battery bus bars in the battery compartment.

Place the probe at the bottom of the bus bars where the cables are connected. The DC voltage should

measure the same as in step 4.

7Close (push in) DC PDA MAIN BREAKER.

8On the DC PDA(Figure 2-6), set the PS1 and PS2 circuit breakers to the ON position by pushing

them in one at a time while observing the rectifier output current indicated on the MAP AMP display.

- The display should indicate between 20 and 60 amps.

9On the DC PDA), set the remaining circuit breakers to the ON position by pushing them in one at a

time in the following sequence:

1. LPA (four circuit breakers, labeled 1A-1B through 3C-3D ).

2. HEAT EXCHANGER (two circuit breakers)

3. ETIB

4. PILOT BEACON

5. OPTIONS

10 Confirm that the MAP AMP display continues to indicate between 20 and 60 amps during the initial

power application.

NOTE

No battery charging or heavy RF loading is present at this point.

11 If the frame is not equipped with the pilot beacon option, set the PILOT BEACON circuit breaker

to OFF.

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-16

Battery Charge Test (Connected Batteries)

Table 2-7 lists the step-by-step instructions for testing the battery

charging performance.

Table 2-7: Battery Charge Test (Connected Batteries)

Step Action

1Close the battery shelf circuit breakers (Figure 2-3) for connected batteries only. This process should

be completed quickly to avoid individual battery strings drawing excess charge current

NOTE

If the batteries are sufficiently discharged, the battery circuit breakers may not engage individually

due to the surge current. If this condition occurs, disconnect the batteries from the 27Vdc bus by

setting the MAP power switch to OFF, and then engage all the connected battery circuit breakers.

The MAP power switch should then be turned ON.

2Using the clamp-on DC current probe and DMM, measure the current in each of the battery string

connections to the battery bus bars. The charge current may initially be high but should quickly

reduce in a few minutes if the batteries have a typical new-battery charge level.

NOTE

The MAP AMP display will indicate the total current output of the rectifiers during this procedure.

As an alternative, the bar graph meters on the AC rectifier modules can be used as a rough estimate of

the total battery charge current. Each rectifier module bar graph has eight (8) LED elements to

represent the output current. Each illuminated LED element indicates that approximately 12.5% (1/8

or 8.75 Amps) of an individual rectifier’s maximum current output (70 Amps) is flowing.

RECTIFIER BAR GRAPH EXAMPLE:

Question: A system fitted with three (3) rectifier modules each have three bar graph LED elements

illuminated. What is the total output current into the batteries?

Answer: Each bar graph is indicating approximately 12.5% of 70 amps, therefore, 3 x 8.75 equals

26.25 amps per rectifier. As there are three rectifiers, the total charge current is equal to (3 x 26.25 A)

78.75 amps.

This charge current calculation is only valid when the RF and LPA compartment electronics are not

powered on, and the RF compartment heat exchanger is turned off. This can only be accomplished if

the DC PDA MAIN BREAKER is set to OFF.

3The current in each string should be approximately equal (within + 5 amps).

4Allow a few minutes to ensure that the battery charge current stabilizes before taking any further

action. Recheck the battery current in each string. If the batteries had a reasonable charge, the current

in each string should reduce to less than 5 amps.

5Recheck the DC output voltage. It should remain the same as measured in step 4 of the frame DC

Power Application and Test (Table 2-6).

NOTE

If discharged batteries are installed, the MAP AMP display may indicate approximately 288 amps for

a two-carrier frame (four rectifiers) or 216 amps for a single-carrier frame (three rectifiers).

Alternately, all bar graph elements may be lighted on the rectifiers during the charge test. Either

indication shows that the rectifiers are at full capacity and are rapidly charging the batteries. It is

recommended in this case that the batteries are allowed to charge and stabilize as in the above step

before commissioning the site. This could take several hours.

Initial Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-17

Battery Discharge Test

Perform the test procedure in Table 2-8 only when the battery current is

less than 5 Amps per string. Refer to Table 2-7 on the procedures for

checking current levels.

Table 2-8: Battery Discharge Test

Step Action

1Turn the BATT TEST switch on the MAP ON (Figure 2-9). The rectifier output voltage and current

should decrease by approximately 10% as the batteries assume the load. Alarms for the MAP may

occur.

2Measure the individual battery string current using the clamp-on DC current probe and DMM. The

battery discharge current in each string should be approximately the same (within + 5 amps).

3Turn BATT TEST switch OFF.

CAUTION Failure to turn off the MAP BATT TEST switch before leaving

the site will result in low battery capacity and reduce battery life.

Initial Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-18

Figure 2-10: Heat Exchanger Blower Assembly and Circuit Breakers

Core

Heat Exchanger

Assembly

Blower

Power

Cord

Bottom (Ambient) Blower

Fan Module

T-30 Screw

Mounting

Bracket

DC PDA

Mounting

Bracket

T-30 Screw

Top (Internal) Blower

Fan Module

Blower

Power

Cord

OUT=OFF

IN=ON

Heat Exchanger

Blower Assembly

Circuit Breaker

Side View SC4812ETL0016-3

LPA

1B 1D 3B 3D

1A 1C 3A 3C PS1 PS2

ETIB

OPTIONS

25 25

HEAT EXCHANGER

CAUTION

SHUT OFF BOTH BREAKERS

ONLY DURING HEAT EXCHANGER

MAINTENANCE OR REPAIR

LPA

BLOWERS

PUSH BUTTON

TO RESET

LPA BLOWERS

MAIN BREAKER

300

50 5010 1530 30 30 30 15

PILOT

BEACON

Power Removal68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-19

Power Removal

Power Removal Procedures

Power removal from an SC4812ET Lite BTS frame is accomplished in

the following two-stage sequence:

1. DC power removal

2. AC power removal

Some maintenance, upgrade, or other activities may only require

removing DC power. In those situations where all power must be

removed from a frame, shutting down AC power will also be required.

Remove DC Power

If it becomes necessary to remove DC power from the frame, refer to

Figure 2-6 and follow the procedure in Table 2-9.

Table 2-9: DC Power Removal

Step Action

1Set all DC PDA circuit breakers to OFF (pulled out) in the following sequence:

1. LPA (four circuit breakers, labeled 1A-1B through 3C-3D )

2. PILOT BEACON

3. HEAT EXCHANGER (two circuit breakers)

4. ETIB

5. OPTIONS

6. PS1 and PS2

7. MAIN BREAKER

2n WARNING

The surge capacitors in the DC PDA will store a large electrical charge for long periods of time.

Failure to discharge these capacitors as specified in this step could result in serious personal injury or

damage to equipment.

On the DC PDA, set the PS1 and PS2 circuit breakers to ON (pushed in), and wait at least 30

seconds.

3Set the DC PDA PS1 and PS2 circuit breakers to OFF.

4Set the MAP power switch to OFF.

Power Removal 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-20

AC Power Removal

If it is necessary to remove all power from a frame, refer to Figure 2-4 or

Figure 2-5, and follow the procedure in Table 2-10.

Table 2-10: AC Power Removal

Step Action

1Remove DC power from the frame by following the procedure in Table 2-9.

2Set all ACLC circuit breakers to OFF (down) in the following sequence:

1. GFI

2. HEATER

3. RECT. 2/4

4. RECT. 1/3

5. MAIN

3Set the facility circuit breaker controlling external power to the frame to OFF.

Power Application - Normal Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-21

Power Application - Normal Power-up

Power Application Procedures

After the first power application, applying power to a BTS frame does

not require performing the voltage and resistance measurements called

out in the initial power-up procedure. The only exception to this is after

maintenance when any major power system components were replaced.

Major power system components include:

SACLC

SDC PDA

SMAP

SInternal DC power cables

Normal power application to a BTS frame is accomplished in the

following two-stage sequence:

1. AC power application

2. DC power application

Applying Internal AC Power

To apply AC power to a BTS frame, refer to Figure 2-4 or Figure 2-5,

and follow the procedure in Table 2-11.

Table 2-11: Apply AC Power to BTS Frame

Step Action

1If the external AC power leads for the BTS frame were disconnected and reconnected, perform the

procedure in Table 2-4 before proceeding further.

2Be sure all DC PDA circuit breakers are set to OFF (pulled out), all ACLC front-panel circuit

breakers are OFF (down), and all battery shelf circuit breakers are OFF (pulled out).

3Be sure the MAP power switch, TCP switch, and BATT TEST switch are all set to OFF (Figure 2-9).

4If it has not already been done, set the facility circuit breaker supplying AC power to the frame

to ON.

5Set the ACLC MAIN circuit breaker ON.

- For the North American cabinet:

Verify that all eight (8) green LEDs on the front of the ACLC are illuminated (Figure 2-4).

- For the International cabinet:

Verify that all four (4) green LEDs on the front of the ACLC are illuminated (Figure 2-5).

6On the ACLC, set RECT. 1/3 and then RECT. 2/4 branch circuit breakers ON.

- All the installed rectifier modules (Figure 2-3) will start up, and the green DC and PWR LEDs

should light on each.

NOTE

In a BTS configured for single-carrier operation (rectifier #4 not installed), a minor alarm may be

generated if the RECT. 2/4 circuit breaker is engaged before the RECT. 1/3 circuit breaker.

. . . continued on next page

Power Application - Normal Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-22

Table 2-11: Apply AC Power to BTS Frame

Step Action

7Set the MAP power switch to ON.

- The MAP VOLT display should read 27.4 + 0.2 VDC with the TCP switch set to OFF.

! CAUTION

Once power is applied to the MAP, be careful not to short either of the VOLT TEST POINTS to

ground. Failure to comply will result in severe damage to the MAP.

8On the MAP, set the TCP switch (Figure 2-9) to ON.

- Verify no alarm LEDs are lighted on the MAP.

NOTE

Depending on battery compartment temperature, the rectifier voltage displayed on the MAP VOLT

indicator may change by as much as +1.5 V when the TCP is set to on.

9Check the rectifier current bar graph displays (green LED display on the rectifier module).

- None should be lighted at this time.

10 If batteries are fitted, set the ACLC HEATER circuit breaker to ON.

NOTE

The GFCI AC circuit breaker should remain OFF unless the GFCI outlet is in use.

Apply DC Power

Refer to Figure 2-6 and follow the procedure in Table 2-12 to apply DC

power to a BTS frame.

Table 2-12: Apply DC Power to BTS Frame

Step Action

1Be sure all DC PDA and battery shelf circuit breakers are OFF (pulled out).

2If it has not already been done, apply AC power to the frame by following the procedure in

Table 2-11.

3Close (push in) DC PDA MAIN BREAKER.

4On the DC PDA(Figure 2-6), set the PS1 and PS2 circuit breakers to the ON position by pushing

them in one at a time while observing the rectifier output current indicated on the MAP AMP display.

- The display should indicate between 20 and 60 amps.

5On the DC PDA), set the remaining circuit breakers to the ON position by pushing them in one at a

time in the following sequence:

1. LPA (four circuit breakers, labeled 1A-1B through 3C-3D )

2. HEAT EXCHANGER (two circuit breakers)

3. ETIB

4. (If Pilot Beacon option is installed) PILOT BEACON

5. OPTIONS

. . . continued on next page

Power Application - Normal Power-up68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-23

Table 2-12: Apply DC Power to BTS Frame

Step Action

6Confirm that the MAP AMP display continues to indicate between 20 and 60 amps during power

application.

NOTE

No battery charging or heavy RF loading is present at this point.

7If the frame is equipped with back-up batteries, close (push in) the battery shelf circuit breakers

(Figure 2-3) for connected batteries only. This process should be completed quickly to avoid excess

charge current draw by individual battery strings.

NOTE

If the batteries are sufficiently discharged, the battery circuit breakers may not engage individually

because of surge current. If this condition occurs, disconnect the batteries from the 27Vdc bus by

setting the MAP power switch to OFF, and then engage all the connected battery circuit breakers. The

MAP power switch should then be turned ON.

Power Application - Normal Power-up 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

2-24

Notes

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-1

Chapter 3

Optimization/Calibration

Optimization/Calibraton - Introduction 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-2

Optimization/Calibraton - Introduction

Introduction

This chapter provides procedures for downloading system operating

software, set up of the supported test equipment, CSM reference

verification/optimization, and transmit/receive path verification.

NOTE Before using the LMF, use a text editor to view the ”CAVEATS”

section of the ”readme.txt” file in the c:\wlmf folder for any

applicable information.

Optimization Process Overview

After a BTS is physically installed and the preliminary operations, such

as power up, have been completed, the LMF is used to optimize the

BTS. Companion frames must be optimized individually as separate

BTSs. The basic optimization process consists of the following:

SDownload MGLI (GLI-bts#-1) with application code and data and

then enable MGLI.

SUse the LMF status function and verify that all of the installed devices

of the following types respond with status information: CSM, BBX,

GLI, MCC8, and, if RFDS is installed, TSU or RFDS-1X RPROC. If

a device is installed and powered up but is not responding and is

colored gray in the BTS display, the device is not listed in the CDF

file. The CDF file must be corrected before the device can be accessed

by the LMF.

SDownload device application code and data to all devices of the

following types:

- CSM

- BBX

- Remaining GLI (GLI-bts#-2)

- MCC

SDownload the RFDS TSIC or RFDS-1X RPROC (if installed).

SVerify the operation of the GPS and HSO signals.

SEnable the following devices (in the order listed):

- Secondary CSM (slot CSM 2)

- Primary CSM (slot CSM 1)

- All MCCs

SUsing the LMF test equipment selection function, select the test

equipment to be used for the calibration.

SCalibrate the TX and RX test cables if they have not previously been

calibrated with the LMF computer and software build which will be

used for the optimization/calibration. Cable calibration values can be

entered manually, if required.

SConnect the required test equipment for a full optimization.

SSelect all of the BBXs and all of the MCCs and use the full

optimization function. The full optimization function performs TX

Optimization/Calibraton - Introduction68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-3

calibration, BLO download, TX audit, all TX tests, and all RX tests

for all selected devices.

SIf the TX calibration fails, repeat the full optimization for any failed

paths.

SIf the TX calibration fails again, troubleshoot and correct the problem

causing the failure, and repeat the full optimization for the failed path.

SIf the TX calibration and audit portion of the full optimization passes

for a path but some of the TX or RX tests fail, troubleshoot and

correct the problem causing the failure, and run the individual tests as

required until all TX and RX tests have passed for all paths.

Cell Site Types

Sites are configured as Omni/Omni or Sector/Sector (TX/RX).

Sector/Sector sites are the three-sector configuration. The SC4812ET

Lite does not support six-sector operation. Each cell site type has unique

characteristics and must be optimized accordingly.

Configuration Data File (CDF)

NOTE Before using the LMF for optimization/ATP, the correct

bts-#.cdf and cbsc-#.cdf files for the BTS must be obtained

from the CBSC and put in a bts-# folder in the LMF. Failure to

use the correct CDF files can cause unreliable or improper site

operation.

The Configuration Data File (CDF), also called the Cell-site Data File,

includes the following information:

SDownload instructions and protocol

SSite specific equipage information

SSCCP shelf allocation plan

- BBX equipage (based on cell-site type) including IS-95A/B or

CDMA2000 1X capability and redundancy

- CSM equipage including redundancy

- Multi Channel Card 24E, 8E, or -1X (MCC24E, MCC8E, or

MCC-1X) channel element allocation plan. This plan indicates how

the SCCP shelf is configured, and how the paging, synchronization,

traffic, and access channel elements (and associated gain values) are

assigned among the (up to 4) MCC24Es, MCC8Es, and/or

MCC-1Xs in the shelf.

SEffective Rated Power (ERP) table for all TX channels to antennas

respectively. Motorola System Engineering specifies the ERP of a

transmit antenna based on site geography, antenna placement, and

government regulations. Working from this ERP requirement, antenna

gain and antenna feed line loss can be combined to calculate the

required transmit power at the frame antenna connections. The

corresponding BBX output power required to achieve that power level

on any channel/sector can then be determined based on Bay Level

Offset (BLO) data established during the optimization process.

Optimization/Calibraton - Introduction 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-4

NOTE Refer to the Figure 3-1 and the LMF Help function on-line

documentation for additional information on the layout of the

LMF directory structure (including CDF file locations and

formats).

The CDF should be obtained from the CBSC. It can be provided on a

DOS-formatted diskette, or, if the LMF computer has file transfer

protocol (ftp) capability, through an ftp download. Refer to the LMF

Help function on-line documentation for more information.

CDF Site Equipage Verification

If it has not already been done, review and verify the site equipage data

in the CDF with the actual site hardware and the site engineering

documentation. Use a text editor to view the CDF contents.

CAUTION - Use extreme care not to make any changes to the CDF

content while viewing the file. Changes to the CDF can

cause the site to operate unreliably or render it incapable of

operation.

- Always wear an approved anti-static wrist strap while

handling any circuit card/module to prevent damage by

ESD. Extreme care should be taken during the removal and

installation of any card/module. After removal, the

card/module should be placed on a conductive surface or

back into the anti-static packaging in which it was shipped.

BTS Software Release Download

The correct device initialization code (ROM code) for the Software

Release being used by the Base Station System (BSS) (for example

R16.0.x) must be successfully downloaded to the BTS processor boards

before optimization can be performed. Device initialization code is

normally downloaded to the processor boards from the CBSC using the

DownLoad Manager (DLM). For optimization, device application code

(RAM code) and data is loaded at the cell site from the LMF computer.

Preparing the LMF68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-5

Preparing the LMF

Overview

Before optimization can be performed, the LMF application software

must be installed and configured on a computer platform meeting

Motorola-specified requirements (see Recommended Test Equipment

and Software in Chapter 1).

NOTE For the LMF graphics to display properly, the computer platform

must be configured to display more than 256 colors. See the

operating system software instructions for verifying and

configuring the display settings.

Software and files for installing and updating the LMF are provided on

CD ROM disks. The following items must be available:

SLMF application program on CD ROM

SConfiguration Data File (CDF) for each supported BTS (on floppy

disk or CD ROM)

SCBSC File for each supported BTS (on floppy disk or CD ROM)

The following section provides information and instructions for

installing and updating LMF software and files.

LMF Installation and Update Procedures

NOTE First Time Installation Sequence:

1. Install Java Runtime Environment (JRE)

2. Install U/WIN K-shell emulator

3. Install LMF application programs

4. Install/create BTS folders

Follow the procedure in Table 3-1 to install the LMF application

program using the LMF CD ROM.

Table 3-1: CD ROM Installation

Step Action

1Insert the LMF CD ROM disk into your disk drive and perform the following as required:

1a - If the Setup screen appears, follow the instructions displayed on the screen.

1b - If the Setup screen is not displayed, proceed to Step 2.

2Click on the Start button

3 Select Run.

4Enter d:\autorun in the Open box and click OK.

NOTE

(If applicable, replace the letter d with the correct CD ROM drive letter.)

5Follow the directions displayed in the Setup screen.

Preparing the LMF 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-6

LMF Home Directory

NOTE The LMF installation program creates the default home directory

c:\wlmf when the LMF is installed.

The LMF installation program creates the default home directory

c:\wlmf, and installs the application files and subdirectories (folders)

in it. Because this can be changed at installation, the LMF home

directory will be referred to with the generic convention of:

Where:

<x> = the LMF computer drive letter where the LMF home directory

is located

<lmf home directory> = the directory path or name where the LMF is

installed

Copy CBSC CDF Files to the LMF Computer

Before logging on to a BTS with the LMF computer to execute

optimization/ATP procedures, the correct bts-#.cdf and

cbsc-#.cdf files must be obtained from the CBSC and put in a

bts-# folder in the LMF computer. This requires creating versions of

the CBSC CDF files on a DOS-formatted floppy diskette and using the

diskette to install the CDF files on the LMF computer.

NOTE When copying CDF files, comply with the following to prevent

BTS login problems with the Windows LMF:

SThe numbers used in the bts-#.cdf and cbsc-#.cdf

filenames must correspond to the locally-assigned numbers

for each BTS and its controlling CBSC.

SThe generic cbsc-1.cdf file supplied with the Windows LMF

will work with locally numbered BTS CDF files. Using this

file will not provide a valid optimization unless the generic

file is edited to replace default parameters (e.g., channel

numbers) with the operational parameters used locally.

Preparing the LMF68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-7

The procedure in Table 3-2 lists the steps required to transfer the CDF

files from the CBSC to the LMF computer. For further information, refer

to the LMF Help function on-line documentation.

Table 3-2: Copying CBSC CDF Files to the LMF Computer

Step Action

1Login to the CBSC workstation.

2Insert a DOS-formatted floppy diskette in the workstation drive.

3 Type eject -q and press the Enter key.

4 Type mount and press the Enter key.

NOTE

SLook for the “floppy/no_name” message on the last line displayed.

SIf the eject command was previously entered, floppy/no_name will be appended with a number.

Use the explicit floppy/no_name reference displayed when performing step 7.

5Change to the directory, where the files to be copied reside, by typing cd <directoryname>

(e.g., cd bts-248) and pressing the Enter key.

6 Type ls and press the Enter key to display the list of files in the directory.

7 With Solaris versions of Unix, create DOS-formatted versions of the bts-#.cdf and cbsc-#.cdf files on

the diskette by entering the following command:

unix2dos <source filename> /floppy/no_name/<target filename>

(e.g., unix2dos bts-248.cdf /floppy/no_name/bts-248.cdf).

NOTE

SOther versions of Unix do not support the unix2dos and dos2unix commands. In these cases, use

the Unix cp (copy) command. The copied files will be difficult to read with a DOS or Windows text

editor because Unix files do not contain line feed characters. Editing copied CDF files on the LMF

computer is, therefore, not recommended.

SUsing cp, multiple files can be copied in one operation by separating each filename to be copied

with a space and ensuring the destination directory (floppy/no_name) is listed at the end of the

command string following a space (e.g., cp bts-248.cdf cbsc-6.cdf /floppy/no_name).

8Repeat steps 5 through 7 for each bts-# which must be supported by the LMF computer.

9When all required files have been copied to the diskette type eject and press the Enter key.

10 Remove the diskette from the CBSC drive.

11 If it is not running, start the Windows operating system on the LMF computer.

12 Insert the diskette containing the bts-#.cdf and cbsc-#.cdf files into the LMF computer.

13 Using MS Windows Explorer, create a corresponding bts-# folder in the <x>:\<lmf home

directory>\cdma directory for each bts-#.cdf /cbsc-#.cdf file pair copied from the CBSC.

14 Use MS Windows Explorer to transfer the cbsc-#.cdf and bts-#.cdf files from the diskette to the

corresponding <x>:\<lmf home directory>\cdma\bts-# folders created in step 13.

Preparing the LMF 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-8

Software Release 2.16.0.x Hardware Binary Files

Follow the procedure in Table 3-3 to make certain the correct R16.0

ROM and RAM code files and device data files are loaded on the LMF

computer.

Table 3-3: Verify Software Release 2.16.0.x Device Binary Files Are Installed

Step Action

1If it has not been done previously, install the LMF software on the LMF computer in accordance with

Table 3-1.

2If it is not running, start the MS Windows operating system on the LMF computer. If the computer is

running and the LMF is logged into a BTS, logout and exit the program.

3 Start MS Windows Explorer from the Windows desktop by selecting Start > Programs > Windows

Explorer.

4In the left-hand pane of MS Windows Explorer, locate the <lmf home directory> folder on x:\ drive

(installation default is c:\wlmf), and expand it (click on the “+” symbol next to the folder) to display

the cdma and help folders.

5Expand the cdma folder, locate the loads folder, and expand it.

6Determine if there is a 2.16.0.x.x folder with final numbers as specified for the software release used

in the BSS (for example, 2.16.0.84.4).

- If no folder of the correct revision level exists, obtain the latest Software Release 2.16.0.x.x

device binary files from Motorola and copy them onto the LMF computer in the <x>:\<lmf home

directory\cdma\loads\<codeload#> directory.

- If a <codeload#> folder of the correct revision level exists, proceed to step 7.

7Expand the 2.16.0.x.x folder to display the code and data folders.

8In the left-hand pane, click on the code folder, and in the right-hand pane look for the following files,

as applicable to the devices with which the BTS is equipped:

Sgli_ram.bin.0103 (RAM code file for GLI2 devices)

Sgli_rom.bin.0103 (ROM code file for GLI2 devices)

Sbbx_ram.bin.605 (RAM code for BBX2 devices)

Sbbx_rom.bin.605 (ROM code for BBX2 devices)

Sbbx_ram.bin.060A (RAM code for 800 MHz and 1.9 GHz BBX-1X devices)

Sbbx_rom.bin.060A (ROM code for 800 MHz and 1.9 GHz BBX-1X devices)

Smcp_ram.bin.0c01 (RAM code for MCC8/MCC24E devices)

Smcp_rom.bin.0c01 (ROM code MCC8/MCC24E devices)

Smcp_ram.bin.0c04 (RAM code for MCC-1X devices)

Smcp_rom.bin.0c04 (ROM code for MCC-1X devices)

. . . continued on next page

Preparing the LMF68P09255A69-3

Aug 2002 1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-9

Table 3-3: Verify Software Release 2.16.0.x Device Binary Files Are Installed

Step Action

9In the left-hand pane, click on the data folder, and in the right-hand pane look for the following file,

as applicable to the installed GLIs:

Sgli.dds.0103 (data file for GLI2 devices)

Sbbx.dds.0605 (data file for BBX2 devices)

Sbbx.dds.060A (data file for BBX-1X devices)

Smcp.dds.0c01 (data file for MCC8/MCC24E devices)

Smcp.dds.0c04 (data file for MCC-1X devices)

10 If the required code and data files are not located on the LMF computer, obtain them from the network

administrator and install them as outlined in the LMF Help function.

11 Close MS Windows Explorer.

Creating a Named HyperTerminal Connection for MMI Communication

Confirming or changing the configuration data of certain BTS Field

Replaceable Units (FRU) requires establishing an MMI communication

session between the LMF computer and the FRU. Using features of the

Windows operating system, the connection properties for an MMI

session can be saved on the LMF computer as a named Windows

HyperTerminal connection. This eliminates the need for setting up

connection parameters each time an MMI session is required to support

optimization.

Once the named connection is saved, a shortcut for it can be created on

the Windows desktop. Double-clicking the shortcut icon will start the

connection without the need to negotiate multiple menu levels.

Follow the procedures in Table 3-4 to establish a named HyperTerminal

connection and create a Windows desktop shortcut for it.

Table 3-4: Create HyperTerminal Connection

Step Action

1From the Windows Start menu, select:

Programs > Accessories

2 Select Communications, double click the Hyperterminal folder, and then double click on the

Hypertrm.exe icon in the window which opens.

NOTE

SIf a Location Information Window appears, enter the required information, then click on the

Close button. (This is required the first time, even if a modem is not to be used.)

SIf a You need to install a modem..... message appears, click on NO.

3When the Connection Description box opens:

- Type a name for the connection being defined (e.g., MMI Session) in the Name: window,

- Highlight any icon preferred for the named connection in the Icon: chooser window, and

- Click OK.

. . . continued on next page

Preparing the LMF 68P09255A69-3

Aug 2002

1X SCt4812ET Lite BTS Optimization/ATP Software Release 2.16.1.x

PRELIMINARY

3-10

Table 3-4: Create HyperTerminal Connection

Step Action

NOTE

For LMF computer configurations where COM1 is used by another interface such as test equipment

and a physical port is available for COM2, select COM2 in the following step to prevent conflicts.

4From the Connect using: pick list in the Connect To box displayed, select Direct to Com 1 or Direct

to Com 2 for the RS-232 connection port, and click OK.

5In the Port Settings tab of the COM# Properties window displayed, configure the RS-232 port

settings as follows:

SBits per second: 9600

SData bits: 8

SParity: None

SStop bits: 1

SFlow control: None

6 Click OK.

7Save the defined connection by selecting:

File > Save

8Close the HyperTerminal window by selecting:

File > Exit

9Click the Yes button to disconnect when prompted.

10 If the Hyperterminal folder window is still open, proceed to step 12.

11 Select Communications and double click the Hyperterminal folder.

12 Highlight the newly-created connection icon by clicking on it.

13 Right click and drag the highlighted connection icon to the Windows desktop and release the right

mouse button.

14 From the popup menu which appears, select Create Shortcut(s) Here.

15 If desired, reposition the shortcut icon for the new connection by dragging it to another location on the

Windows desktop.

16 Close the Hyperterminal folder window by selecting:

File > Close

Nokia Solutions and Networks T5CS1 Cellular CDMA Base Station User Manual IHET5SC1 GLI3 1 of 4

Nokia Solutions and Networks Cellular CDMA Base Station IHET5SC1 GLI3 1 of 4

Contents

IHET5SC1 GLI3 User Manual 1 of 4

Navigation menu

Namespaces

Views

Navigation
