If you are using the camera for the first time, read this section.
31
1
Press the !"#$ buttons to
set the year, month, date and
time.
• Change the value with !" and
move the frame with #$.
2
In [FORMAT], choose the
date and time format.
• Select the date and time format
with !".
3
Check the display and then
press the MENU/OK button.
• The date is set.
• Pressing the DISP. button on this screen allows you to cancel
the setting.
Note ---------------------------------------------------------------------------------------------------
•If the battery is removed for more than one week, the date and time settings will be
lost. These settings must be made again.
•To retain the date and time settings, load a battery with adequate remaining power
for more than two hours.
•The set date and time can be changed later. (GP.119)
•The date and time can be inserted into images. (GP.77)
Setting the Date and Time
When the power is turned on for the first time, the date/time
setting screen appears.
Setting at shipping
L7360874_En_00_0_bookfile.book Page 31 Friday, October 13, 2006 12:56 PM
32
If you are using the camera for the first time, read this section.
Basic Shooting
Now you are ready.
1
Hold the camera with both hands and lightly press
both elbows against your body.
2
Put your finger on the shutter
release button.
Caution-----------------------------------------------------------------------------------------------
•When you are shooting, be careful not to obstruct the lens or flash with your fingers,
hair, or the strap.
•Be careful not to obstruct the Bluetooth® antenna with your fingers when
communicating. (GP.154)
Holding the Camera
Hold the camera as shown below for best results.
Shooting while viewing
the LCD monitor
Shooting while using
the viewfinder
L7360874_En_00_0_bookfile.book Page 32 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
33
Preventing Camera Shake---------------------------------------------------------------------
If you move the camera when pressing the shutter release button, the still image might
not come out clearly due to camera shake.
Camera shake tends to occur in the following cases:
•When shooting in a dark place without using the flash
•When using the zoom function
•When shooting using long time exposure (GP.73)
When the J mark appears on the LCD monitor, this indicates that camera shake
may occur. To prevent camera shake, try any of the following.
•Using the antiblur function (GP.63)
•Set the flash to [AUTO] or [FLASH ON]. (GP.39)
•Raising the ISO setting (GP.81)
•Using the self-timer (GP.45)
L7360874_En_00_0_bookfile.book Page 33 Friday, October 13, 2006 12:56 PM
34
If you are using the camera for the first time, read this section.
Quickly Shooting Pictures (Full-press)
Full-press the shutter release button for quick focusing, so as not to
miss a shooting opportunity.
1
Press the power button to turn the
camera on, and turn the mode dial to
5/K.
2
Compose your shot by looking at the LCD monitor
or through the viewfinder, make sure the subject is
centered, and gently press the shutter release
button fully.
•
The still image you have taken appears momentarily on the LCD
monitor and is recorded to the internal memory or SD memory card.
Caution-----------------------------------------------------------------------------------------------
Full-press is likely to cause the camera to shake. Hold the camera firmly with both
hands and shoot.
Note ---------------------------------------------------------------------------------------------------
You can set the time the still image you have taken appears on the LCD monitor. You
can also set the image not to appear after it is taken. (GP.116)
Shooting
The shutter release button works in two steps. You can press the
shutter release button halfway down (half-press) and press it all
the way down (full-press).
CALS
CALS
L7360874_En_00_0_bookfile.book Page 34 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
35
Checking the Focus and Shooting
(Half-press/Focus Lock)
When you press the shutter release button halfway (Half-press), the
auto-focus function is triggered to determine the focal distance.
Next, press it all the way down (Full-press) to shoot. When your
subject is not in the center of your composition, compose your photo
after focusing. (Focus Lock)
1
Press the power button to turn the
camera on, and turn the mode dial to
5/K.
2
Put the subject of your photo in the center of the
screen and press the shutter release button
halfway.
• The camera focuses on the subject
and the exposure is fixed.
• If automatic focusing fails, the frame
in the center of the LCD monitor
turns red and the auto focus/flash
lamp in the upper right of the LCD
monitor blinks in green.
• The focal distance is measured at a
maximum of five points. Green
frames appear to indicate the positions that are in focus.
CALS
CALS
Auto Focus/Flash Lamp
Frame
L7360874_En_00_0_bookfile.book Page 35 Friday, October 13, 2006 12:56 PM
36
If you are using the camera for the first time, read this section.
3
To take a picture with the subject in the foreground
in focus against a background, half-press the
shutter release button to focus on the subject, and
then compose your shot.
4
Gently press the shutter
release button all the way.
• The still image you have taken
appears momentarily on the LCD
monitor and is recorded to the internal
memory or SD memory card.
Focusing---------------------------------------------------------------------------------------------
The frame in the center of the LCD monitor and the auto focus/flash lamp indicate
whether the subject is in or out of focus.
Note ---------------------------------------------------------------------------------------------------
•Press the shutter release button gently to prevent camera shake.
•The J mark indicates that camera shake may occur. Hold the camera still and
focus the camera again. You can also turn on the antiblur function to minimize
blurring. (GP.63)
•The flash fires twice to increase the AE/AF (Auto Exposure/Auto Focus) accuracy.
Focus Status Frame Color Auto Focus/Flash Lamp
Before focusing White Off
Subject in focus Green On (green)
Subject not in focus Blinks (red) Blinks (green)
Shooting range
Subject to be focused on
L7360874_En_00_0_bookfile.book Page 36 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
37
1
With the camera ready to
shoot, press the Z (Wide-
angle) button or the z
(Telephoto) button.
• You can check the zoom status on
the zoom bar of the LCD monitor.
2
Compose your picture and
half-press the shutter
release button.
3
Full-press the shutter
release button.
Using the Digital Zoom -------------------------------------------------------------------------
Digital zooming enables you to enlarge the subject more than the maximum
magnification of the optical zoom (3.0×) specified by pressing the z (Telephoto)
button (up to 4.0×).
For digital zooming, release the z button once when the zoom reaches the limit on
the z (Telephoto) end on the zoom bar, and then hold the z button down again.
Using the Zoom Function
Pressing the Z (Wide-angle) button allows you to take a wide-
angle picture. Pressing the z (Telephoto) button allows you to
take a close-up picture of the subject.
Wide-angle Telephoto
L7360874_En_00_0_bookfile.book Page 37 Friday, October 13, 2006 12:56 PM
38
If you are using the camera for the first time, read this section.
1
With the camera ready to
shoot, press the N (Macro)
button.
•N is displayed momentarily at the
center of the LCD monitor and
then a N is displayed at the top of
the screen.
2
Compose your picture and half-press the shutter
release button.
3
Full-press the shutter
release button.
• To cancel macro mode, press the
N (Macro) button again.
Note ---------------------------------------------------------------------------------------------------
•When using the zoom, you can shoot close-ups within the following distances:
•The AF target shift function enables you to lock the focus for macro shooting with the
simple touch of a button without moving the camera. This function is useful for
shooting on a tripod. (GP.58)
•To take a further close-up picture during macro shooting, use [ZOOM MACRO] in
scene mode. (GP.40)
Shooting Close-Ups (Macro Shooting)
Using the N (Macro) button allows you to take a tight close-up of
the subject. (Macro shooting)
This is good for shooting small subjects because you can shoot
up to approximately 5 mm (0.2 in.) (from the very front of the
camera) away.
Distance Shooting range
Wide-Angle About 5 mm
(from the very front of the camera)
Approx. 27 mm × 20 mm
Telephoto About 10 cm
(from the very front of the camera)
Approx. 51 mm × 38 mm
(when digital zoom is not used)
Approx. 12.8 mm × 9.5 mm
(when 4.0× digital zoom is used)
L7360874_En_00_0_bookfile.book Page 38 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
39
Flash Modes
1
Turn the mode dial to 5/K.
2
Press the F (Flash) button to
change the flash mode.
• The flash mode mark is displayed
momentarily at the center of the
LCD monitor and then a smaller
mark is displayed at the upper left
of the screen.
• The auto focus/flash lamp blinks
while the flash charges. Once the flash is charged, the lamp
turns off and the camera is ready to shoot.
Note ---------------------------------------------------------------------------------------------------
•The flash mode setting is saved until you press the F (Flash) button again.
•The flash does not fire when shooting movies or in Multi-shot mode.
•The flash fires a pre-flash to increase the AE/AF (Auto Exposure/Auto Focus) accuracy.
•When shooting close-ups with the flash, there may be a shadow in the lower left part
of the picture due to the convex lens.
Using the Flash
Press the F (Flash) button to change the flash mode. At the time
of purchase, the camera is set to [FLASH OFF].
From the front edge of the lens, the flash light reaches about 0.2
to 10.0 m (7.9 in. to 32.8 ft.) (Wide-angle) or about 0.2 to 6.5 m (7.9
in. to 21.3 ft.) (Telephoto) when the ISO setting is set to [AUTO].
FLASH OFF The flash will not fire.
AUTO The flash fires automatically when the subject is poorly
lit or backlit.
RED-EYE FLASH Reduces the red-eye phenomenon, in which people’s
eyes appear red in pictures.
FLASH ON The flash fires regardless of the lighting conditions.
FLASH SYNCHRO. The flash fires with the shutter speed slowed. This is
useful when taking portrait pictures in a nightscape.
Camera shake may occur, so the use of a tripod is
recommended.
L7360874_En_00_0_bookfile.book Page 39 Friday, October 13, 2006 12:56 PM
40
If you are using the camera for the first time, read this section.
Scene Modes
Note ---------------------------------------------------------------------------------------------------
For information on Shooting Setting menu items and function restrictions in scene
mode, see “Appendices”. (GP.240)
Shooting with Optimal Settings According
to Shooting Conditions
You can use scene mode to select from among five still image
modes and shoot with settings automatically optimized for
shooting conditions.
HIGH SENS
Use when taking pictures in dimly lit places. The LCD monitor also
becomes brighter.
FIREFIGHTING
Use to capture images under difficult conditions such as the scene of
a fire. The focal length is fixed to 2.5 m, allowing you to take clear
pictures in a situation where the auto focus would normally produce
blurred images due to flames, smoke and water vapor. Increasing the
ISO sensitivity extends the range of the flash, and prevents camera
shake by controlling the shutter speed even when the flash is not
used. The sharpness level is also increased in this mode and the
LCD monitor becomes brighter and is suited for firefighting.
SKEW COR MODE
Use to straighten a rectangular object, such as a message board or
business card, shot at an angle to make it look as if it were shot
squarely. For detailed operations, see P.42.
In skew correction mode, choose from [F1280], [N1280], and [N640]
for [PIC QUALITY/SIZE]. (GP.61)
TEXT MODE
Use when capturing text images, for example notes written on a
whiteboard at a meeting.
You can also change the shading of text. (GP.57)
You can set the image size to either 3264 × 2448 or 2048 × 1536
pixels. (GP.61)
ZOOM MACRO
Use when taking a further close-up picture during macro shooting.
Using the digital zoom allows you to take a larger close-up than with
normal macro shooting. For detailed operations, see P.43.
The optical zoom cannot be used in this mode.
You can shoot close-ups within the following distances.
When digital zoom is not used: About 5 mm from the very front of the
camera
(Shooting range: Approx. 27 mm × 20 mm)
When 4.0× digital zoom is used: About 5 mm from the very front of
the camera
(Shooting range: Approx. 6.8 mm × 5 mm)
L7360874_En_00_0_bookfile.book Page 40 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
41
1
Turn the mode dial to
5
.
2
Press the SCENE button.
• The scene mode selection screen
appears.
3
Press the !" buttons to
select the scene mode.
4
Press the MENU/OK button.
• The scene mode type is displayed
at the top of the LCD monitor.
5
Press the shutter release
button to shoot the picture.
Changing Scene Mode
Press the SCENE button to display the scene mode selection
screen, and select a different scene mode.
Returning to Normal Shooting Mode
1
Press the SCENE button to display the scene mode
selection screen.
2
Press the !" buttons to select [NRML SHT].
3
Press the MENU/OK button.
4
L7360874_En_00_0_bookfile.book Page 41 Friday, October 13, 2006 12:56 PM
42
If you are using the camera for the first time, read this section.
Using the Skew Correction Mode
1
Turn the mode dial to 5.
2
Press the SCENE button.
• The scene mode selection screen appears.
3
Press the !" buttons to select [SKEW COR
MODE].
4
Press the MENU/OK button.
5
Press the shutter release button to shoot the
picture.
• The display indicates that the image is being corrected and the
area recognized as the correction range is displayed with an
orange frame. Up to five areas can be recognized.
• If the target area cannot be detected, an error message appears.
The image before correction remains recorded.
• To select another correction area, move the orange frame to the
target area by pressing the $ button.
• To cancel skew correction, press the ! button. Even if you
cancel skew correction, the image before skew correction
remains recorded.
6
Press the MENU/OK button.
• The display indicates that the image is being recorded and the
corrected image is recorded. The image before correction is also
recorded.
Caution-----------------------------------------------------------------------------------------------
When [SKEW COR MODE] is selected, note the following:
•To shoot the subject as large as possible, position it so that the entire portion of the
subject is visible on the LCD monitor.
•The camera may fail to recognize the subject in the following cases:
•When the image is out of focus
•When four edges of the subject are not clearly visible
•When it is hard to distinguish between the subject and background
•When the background is complicated
•Two images, one before correction and the other after correction, are recorded. If the
number of remaining shots is less than two, you cannot shoot the subject.
L7360874_En_00_0_bookfile.book Page 42 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
43
Shooting in Zoom Macro Mode
1
Turn the mode dial to 5.
2
Press the SCENE button.
• The scene mode selection screen appears.
3
Press the !" buttons to select [ZOOM MACRO].
4
Press the MENU/OK button.
5
Press the Z (Wide-angle) or z (Telephoto) button.
• The zoom level appears on the LCD monitor.
6
Compose your picture and half-press the shutter
release button.
7
Full-press the shutter release button.
L7360874_En_00_0_bookfile.book Page 43 Friday, October 13, 2006 12:56 PM
44
If you are using the camera for the first time, read this section.
1
Turn the mode dial to K.
• The symbol appears on the
screen.
2
Press the shutter release button to shoot the
picture.
• Images are recorded with [PIC QUALITY/SIZE] set to [N1280].
• When the mode dial is set to a mode other than K, [PIC
QUALITY/SIZE] returns to the setting in the previous mode.
Note ---------------------------------------------------------------------------------------------------
When shooting with S-CONT or M-CONT in CALS mode, [PIC QUALITY/SIZE] is fixed
at [N3264] (Normal 3264 × 2448).
Shooting in CALS Mode
In CALS mode, [PIC QUALITY/SIZE] is fixed at [N1280] (Normal
1280 × 960) suitable to be submitted as official public works
pictures (based on Japanese standards).
With simple operation of the mode dial, you can shoot photos in a
construction environment without being distracted by setting the
picture quality mode or image size.
CALS
CALS
L7360874_En_00_0_bookfile.book Page 44 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
45
1
Turn the mode dial to 5/K.
2
Press the t (Self-timer)
button.
• The Self-timer symbol appears on
the screen.
• The [10] to the right of the symbol
indicates the number of seconds.
In this case, if you press the
shutter release button, the camera
will shoot after 10 seconds.
• Each press of the t (Self-timer) button changes the self-timer
setting in the following order: 10 sec, 2 sec, and Self-timer Off.
3
Press the shutter release button.
• The focus is locked, and the AF auxiliary light blinks when the
self-timer starts.
Note ---------------------------------------------------------------------------------------------------
•Once the picture is taken, the self-timer turns off.
•When the self-timer is set to 2 seconds, the AF auxiliary light does not blink.
t Using the Self-Timer
You can set the Self-timer to shoot after either two or ten seconds.
A setting of two seconds is useful for preventing camera shake.
L7360874_En_00_0_bookfile.book Page 45 Friday, October 13, 2006 12:56 PM
46
If you are using the camera for the first time, read this section.
Playing Back Images
1
In shooting mode, press the
Q (Quick Review) button.
• The last image you took is
displayed on the LCD monitor.
Note ---------------------------------------------------------------------------------------------------
•Once the power is turned off, the image you took cannot be displayed in still image
mode even if you press the Q (Quick Review) button.
•If you use Quick Review to view the image taken in [TEXT MODE] of scene mode
(GP.40), the displayed image may have a slightly lower quality than the recorded
one.
Reviewing the Image You Just Took
(Quick Review)
You can view the image you just took on the LCD monitor. If you
are not pleased with the way the photo came out, you can delete
it then and there.
In Quick Review
Q Button Returns to shooting mode.
8 Button Enlarges the displayed still image.
You can move the displayed still image by pressing the
!"#$ buttons.
9 Button Reduces the displayed still image enlarged by pressing the
8button.
MENU/OK
Button
Enlarges the displayed still image enlarged by pressing the
8button to the maximum available magnification.
Pressing this again returns the still image to its original size.
D Button Deletes the currently displayed file. When the D button is
pressed, a warning message about deleting the file appears.
Select [DELETE] and press the MENU/OK button.
L7360874_En_00_0_bookfile.book Page 46 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
47
1
Press the 6 (Playback)
button.
• The camera switches to playback
mode and the last still image you
took is displayed.
• You can view your pictures in
order by using the #$ buttons.
• To switch the camera from
playback mode to shooting mode (or voice memo mode), press
the 6 (Playback) button again.
Turning on the camera in playback mode------------------------------------------------
When the camera is off, pressing the 6 (Playback) button for more than one second
turns the camera on. (The camera starts up in playback mode.)
When the camera has been turned on with the 6 (Playback) button, pressing the 6
(Playback) button again switches playback mode to shooting mode.
Where images are played back from-------------------------------------------------------
When no SD memory card is loaded, the camera plays back from the internal memory.
When an SD memory card is loaded, it plays back from the SD memory card.
Viewing Your Images
In playback mode, you can check still images you have taken. You
can also delete or zoom in on the images.
To previous image To next image
L7360874_En_00_0_bookfile.book Page 47 Friday, October 13, 2006 12:56 PM
48
If you are using the camera for the first time, read this section.
The playback screen changes as follows:
1
Press the 6 (Playback)
button.
• The last image you took is
displayed.
2
Press the 9 (Thumbnail
Display) button.
• The screen changes to three-
frame view. The large frame at the
center of the screen displays the
currently selected still image.
Three-frame View/List View
(Thumbnail Display)
When playing back images on the LCD monitor, the playback
screen can be divided into three frames (three-frame view) or 12
frames (list view). The three-frame view and list view allow you to
select a still image to enlarge or delete.
L7360874_En_00_0_bookfile.book Page 48 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
49
3
Press the 9 (Thumbnail
Display) button again during
three-frame view.
• The screen is divided into 12
frames and the list of still images is
displayed.
Switching to Single-Picture Display
In three-frame view
1
Press the #$ buttons to select a still image.
2
Press the 8 (Enlarged View) button or the MENU/
OK button.
In list view
1
Press the !"#$ buttons to select a still image.
2
Press the 8 (Enlarged View) button twice.
Note ---------------------------------------------------------------------------------------------------
If any of the following operations is performed in the three-frame view, the display
returns to the ordinary playback screen (single-picture display) and the operation is
executed.
•Deletion (GP.51)
•Menu display (GP.88)
•Movie playback (GP.85)
•Sound playback (GP.87)
Selected still image
L7360874_En_00_0_bookfile.book Page 49 Friday, October 13, 2006 12:56 PM
50
If you are using the camera for the first time, read this section.
1
Press the 6 (Playback) button.
• The last image you took is displayed.
2
Press the #$ buttons to display the still image you
want to enlarge.
3
Press the 8 (Enlarged View)
button.
• The still image is enlarged.
Note ---------------------------------------------------------------------------------------------------
•Enlarged view is also available in the quick review mode.
•Movies cannot be enlarged.
Magnifying Images
You can enlarge a still image displayed on the LCD monitor.
Image Size Enlarged View (maximum magnification)
3264 × 2448, 2592 × 1944, 2048 × 1536 8 times
1280 × 960 6.7 times
640 × 480 3.4 times
In Enlarged View
8 Button Enlarges the displayed still image.
You can move the displayed still image by pressing the
!"#$ buttons.
9 Button Returns the enlarged still image to its original size.
MENU/OK
Button
Displays the still image at the maximum magnification.
Pressing this again returns the still image to its original size.
L7360874_En_00_0_bookfile.book Page 50 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
51
Deleting Files
You can delete unwanted or failed files from the SD memory card
or internal memory.
1
Press the 6 (Playback)
button.
2
Press the #$ buttons to
display the file you want to
delete.
3
Press the D (Delete) button.
4
Press the !" buttons to
select [DELETE ONE].
• You can change the image for
deletion with the #$ buttons.
5
Press the MENU/OK button.
• The display indicates that the files
are being deleted; once finished, it
returns to the screen in Step 4.
1
Press the 6 (Playback)
button.
2
Press the D (Delete) button.
Deleting a File
Deleting All Files
L7360874_En_00_0_bookfile.book Page 51 Friday, October 13, 2006 12:56 PM
52
If you are using the camera for the first time, read this section.
3
Press the !" buttons to
select [DELETE ALL].
4
Press the MENU/OK button.
• You will be prompted to confirm
that you want to delete all images.
If so, press the $ button to select
[YES], and then press the MENU/
OK button.
Note ---------------------------------------------------------------------------------------------------
You can also delete files by pressing the D (Delete) button during three-frame view
(GP.48).
1
Press the 6 (Playback)
button.
2
Press the 9 (Thumbnail
Display) button twice.
• The screen is divided into 12
frames and thumbnails are
displayed.
3
Press the !"#$ buttons to
select the file you want to
delete and press the D
(Delete) button.
• The trash symbol is displayed in
the upper left corner of the file.
4
Repeat Step 3 to select all
the files you want to delete.
• If you selected a file by mistake, you can deselect it by selecting
the file and pressing the D (Delete) button.
5
Press the MENU/OK button.
Deleting Multiple Files at One Time
L7360874_En_00_0_bookfile.book Page 52 Friday, October 13, 2006 12:56 PM
If you are using the camera for the first time, read this section.
53
6
Press the #$ buttons to
select [YES] and then press
the MENU/OK button.
• The display indicates that the files
are being deleted; once finished, it
returns to the thumbnail display
screen.
L7360874_En_00_0_bookfile.book Page 53 Friday, October 13, 2006 12:56 PM
54
If you are using the camera for the first time, read this section.
Changing the Display with
the DISP. Button
Pressing the DISP. button allows you to change the screen display
mode and toggle the information displayed on the LCD monitor.
Each time you press the DISP. button, the display changes in the
following order: Grid Guide, No Display, LCD Monitor Off, and
Normal Symbol Display.
Grid Guide ------------------------------------------------------------------------------------------
This displays auxiliary lines on the LCD monitor to help you compose your picture.
These lines are not recorded with images.
Synchro-Monitor Mode -------------------------------------------------------------------------
This turns the LCD monitor off except when the camera is operated. This mode is
effective for saving power consumption. In this mode, pressing the shutter release button
halfway turns the LCD monitor on. Subsequently, pressing the shutter release button
fully displays the shot image on the LCD monitor and then turns the LCD monitor off.
Hold the DISP. button down to maximize the display brightness.
When the brightness is at the maximum setting, holding the DISP.
button down returns the brightness to the level set in [LCD
BRIGHTNESS] (GP.111).
Maximizing the LCD Monitor Brightness
Normal Symbol Display
No Display
Grid Guide
LCD Monitor Off
(Synchro-Monitor Mode)
L7360874_En_00_0_bookfile.book Page 54 Friday, October 13, 2006 12:56 PM
Advanced
Operations
Read this section
when you want to
learn more about the
different camera
functions.
1 Various Shooting
Functions .......................56
2 Shooting/Playing Back
Movies ............................83
3 Recording/Playing Back
Sound .............................86
4 Other Playback
Functions .......................88
5 Direct Printing................ 98
6 Changing Camera
Settings ........................106
7 Downloading Images to
Your Computer ............128
8 Using the Bluetooth®
Function .......................154
9 Using the GPS
Function .......................180
10 Using the Wireless LAN
Function (Only for Caplio
500SE-W)...................... 191
11 Appendices .................. 221
1
2
3
4
5
6
7
8
9
10
11
L7360874_En_00_0_bookfile.book Page 55 Friday, October 13, 2006 12:56 PM
56
Various Shooting Functions
1
1 Various Shooting Functions
You can use the ADJ. button to adjust the exposure compensation, white
balance, and other settings with fewer operations. Two functions other
than exposure compensation and white balance can also be assigned to
the ADJ. button. Use the SETUP menu to assign functions to the ADJ.
button. (
G
P.112) By assigning a frequently used function to the ADJ.
button, you can more easily set that function with fewer button operations.
The settings that can be made with the ADJ. button differ among
scene mode, movie mode and still image mode. The following
settings can be made with the ADJ. button.
Functions That Can Be Assigned to the ADJ. Button
ISO (ISO SETTING), QUALITY (PIC QUALITY/SIZE), FOCUS,
SHARP (SHARPNESS), METERING (PHOTOMETERY), CONT MDE
(CONT.MODE), ANTIBLUR (Default setting for [ADJ BTN.SET.1])
Using the ADJ. Button
Settings by Mode
Mode Available Settings
Still Image Mode Exposure compensation, white balance,
functions assigned to the ADJ. button
Movie Mode White balance
Scene Mode ([TEXT MODE]) Text density
Scene Mode (other than [TEXT MODE]) Exposure compensation, white balance
The screenshots above are examples of the screen display when functions
are assigned to [ADJ BTN. SET.1] and [ADJ BTN. SET.2]. Press the ADJ.
button until the screen with the desired function appears. Adjust the settings
with the !" buttons and press the MENU/OK button to set.
Exposure Compensation
Setting White Balance Setting
ADJ BTN. SET.2 ADJ BTN. SET.1
L7360874_En_00_0_bookfile.book Page 56 Friday, October 13, 2006 12:56 PM
57
Various Shooting Functions
1
Note ----------------------------------------------------------------------------------------------
When using a camera memo, the settings on P.56 cannot be set with the ADJ. button.
(G “Software User Guide”)
You can change the shading of text for shooting with [TEXT MODE]
(GP.40) in scene mode.
You can select from [DEEP], [NORMAL] and [LIGHT].
1
Turn the mode dial to 5.
2
Press the SCENE button.
• The scene mode selection screen appears.
3
Press the !" buttons to select
[TEXT MODE] and then press
the MENU/OK button.
4
Press the ADJ. button.
• The text density menu appears.
5
Press the !" buttons to select
the desired density setting.
• You can also press the shutter release
button to shoot the picture.
6
Press the MENU/OK button.
• The text density setting does not appear on the screen.
Changing the Text Density (SCENE)
To change the setting, use the Shooting Setting menu or the ADJ. button. This section
explains easy ways to change the shading setting with the ADJ. button.
To use the Shooting Setting menu, see “Using the Menu” (GP.60) and “Shooting Setting
Menu Items by Scene Mode” (GP.240).
L7360874_En_00_0_bookfile.book Page 57 Friday, October 13, 2006 12:56 PM
58
Various Shooting Functions
1
You can press the ADJ. button during macro shooting and then use
the !"#$ buttons to shift the AF target without moving the
camera. You can then lock the focus (GP.35) at the position of the
AF target and shoot the picture. This function is useful for shooting
on a tripod.
1
With the camera ready to shoot, press the N (Macro)
button.
• The macro symbol appears on the screen.
2
Press the ADJ. button.
3
Press the #$ buttons until the
AF target shift function screen
(cross-mark in the middle of
the screen) appears.
4
Shift the cross-mark to the
subject you want the camera to
focus on with the !"#$
buttons.
5
Press the MENU/OK button.
6
Half-press the shutter release
button.
• The camera focuses on the area at the position of the cross-mark.
7
Gently press the shutter release button all the way.
• The AF target shift function automatically focuses the camera on the
set position until macro mode is canceled.
Shifting the AF Target (Macro)
When the AF target
is shifted to the left
with the # button
L7360874_En_00_0_bookfile.book Page 58 Friday, October 13, 2006 12:56 PM
59
Various Shooting Functions
1
Press the MENU/OK button in shooting mode to display the
Shooting Setting menu. The Shooting Setting menu can be used to
set the following shooting settings.
When Mode Dial is Set to 5/K
• The settings that can be selected during scene mode are
restricted. (GP.240).
When Mode Dial is Set to 3
Note ----------------------------------------------------------------------------------------------
The SETUP menu (GP.106) and EXP SET menu (GP.155) can be accessed from
within the Shooting Setting menu.
Shooting Setting Menu
Setting Options [Default Settings] Refer to
PIC QUALITY/SIZE F3264(8M), N3264(8M), N2592(5M), N2048(3M),
F1280(1M), [N1280(1M)], N640(VGA)
P.61
ANTIBLUR [OFF], ON P.63
FOCUS [MULTI AF], SPOT AF, MF, SNAP, AP.64
PHOTOMETRY [MULTI], CENTER, SPOT P.67
SHARPNESS SHARP, [NORMAL], SOFT P.68
CONT. MODE [OFF], S-CONT, M-CONT P.69
COLOR DEPTH VIVID, [NORMAL], NEUTRAL, B&W P.72
TIME EXPOSURE [OFF], 1 SEC., 2 SEC., 4 SEC., 8 SEC. P.73
INTERVAL [0 s], 30 seconds to 3 hours P.74
IMAGE WITH SOUND [OFF], ON P.76
DATE IMPRINT [OFF], DATE, TIME P.77
EXPOSURE COMP. -2.0 to +2.0 P.78
WHITE BALANCE [AUTO], (OUTDOORS), (CLOUDY),
(INCANDESCENT LAMP), (INCANDESCENT
LAMP2), (FLUORESCENT LAMP),
(MANUAL SETTINGS)
P.79
ISO SETTING [AUTO], ISO 64, ISO 100, ISO 200, ISO 400,
ISO 800, ISO 1600
P.81
RESTORE DEFAULTS P.82
Setting Options [Default Settings] Refer to
MOVIE SIZE [320], 160 P.61
FRAME RATE [30FPS], 15FPS P.84
FOCUS [MULTI AF], SPOT AF, MF, SNAP, AP.64
WHITE BALANCE [AUTO], (OUTDOORS), (CLOUDY),
(INCANDESCENT LAMP), (INCANDESCENT
LAMP2), (FLUORESCENT LAMP),
(MANUAL SETTINGS)
P.79
L7360874_En_00_0_bookfile.book Page 59 Friday, October 13, 2006 12:56 PM
60
Various Shooting Functions
1
This explains how to make the settings.
Use the
!"$
buttons and MENU/OK button to select and set an item.
1
Press the MENU/OK button in
shooting mode.
• The Shooting Setting menu is
displayed.
2
Press the !" buttons to select
the desired menu item.
• Press the " button at the bottom item
to display the next screen.
3
Press the $ button.
• The menu item settings are displayed.
4
Press the !" buttons to
select the setting.
5
Press the MENU/OK button, or
# button and press the MENU/
OK button.
• The setting is set.
• The Shooting Setting menu disappears and the camera is ready to
shoot.
Changing the display ----------------------------------------------------------------------
•You can select a screen by the screen number:
1 Press the # button to select a screen
number on the left of the screen.
2 Press the !" buttons to change screens.
3 Press the $ button to return to menu item
selection.
Using the Menu
The menu items are
provided on three screens.
L7360874_En_00_0_bookfile.book Page 60 Friday, October 13, 2006 12:56 PM
