Safety Instructions
Use the following safety guidelines to help protect yourself and your
computer.
When Using Your Computer
CAUTION: Do not operate your portable computer for an extended
period of time with the base resting directly on your body. With
extended operation, heat can potentially build up in the base.
Allowing sustained contact with the skin could cause discomfort
or, eventually, a burn.
Do not attempt to service the computer yourself. Always follow
installation instructions closely.
Do not carry a battery in your pocket, purse, or other container where
metal objects (such as car keys) could short-circuit the battery
terminals. The resulting excessive current flow can cause extremely
high temperatures and may result in damage from burns.
Be sure that nothing rests on your AC adapter's power cable and that
the cable is not located where it can be tripped over or stepped on.
Place the AC adapter in a ventilated area, such as a desk top or on the
floor, when you use it to run the computer or to charge the battery. Do
not cover the AC adapter with papers or other items that will reduce
cooling; also, do not use the AC adapter while it is inside a carrying
case.
Do not push objects into air vents or openings of your computer. Doing
so can cause fire or electric shock by shorting out interior components.
Use only the AC adapter and batteries that are approved for use with
this computer. Use of another type of battery or AC adapter may risk
fire or explosion.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type battery recommended by
by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
Before you connect the computer to a power source, ensure that the
voltage rating of the AC adapter matches that of the available power
source.
- 115 V/60 Hz in most of North and South America and some Far
Eastern countries such as South Korea and Taiwan.
- 100 V/50 Hz in eastern Japan and 100 V/60Hz in western Japan.
- 230 V/50 Hz in most of Europe, the Middle East, and the Far East.
If you use an extension cable with your AC adapter, ensure that the
total ampere rating of the products plugged in to the extension cable
does not exceed the ampere rating of the extension cable.
第 1 頁，共 3 頁Safety Instructions
2003/6/10
file://C:\WINDOWS\TEMP\~hhCC6F.htm
To remove power from the computer, turn it off, remove the battery, and
and disconnect the AC adapter from the electrical outlet.
To help avoid the potential hazard of electric shock, do not connect or
disconnect any cables or perform maintenance or reconfiguration of this
this product during an electrical storm.
Do not dispose of batteries in a fire. They may explode. Check with
local authorities for disposal instructions.
When setting up the computer for work, place it on a level surface.
When traveling, do not check the computer as baggage. You can put
your computer through an X-ray security machine, but never put your
computer through a metal detector. If you have the computer checked
by hand, be sure to have a charged battery available in case you are
asked to turn on the computer.
When traveling with the hard drive removed from the computer, wrap
the drive in a non-conducting material, such as cloth or paper. If you
have the drive checked by hand, be ready to install the drive in the
computer. Your can put the hard drive through an X-ray security
machine, but never put the drive through a metal detector.
When traveling, do not place the computer in overhead storage
compartments where it could slide around. Do not drop your computer
or subject it to other mechanical shocks.
Protect your computer, battery, and hard drive from environmental
hazards such as dirt, dust, food, liquids, temperature extremes, and
overexposure to sunlight.
When you move your computer between environments with very
different temperature and/or humidity ranges, condensation may form
on or within the computer. To avoid damaging the computer, allow
sufficient time for the moisture to evaporate before using the computer.
NOTICE: When taking the computer from low-temperature
conditions into a warmer environment or from high-temperature
conditions into a cooler environment, allow the computer to
acclimate to room temperature before turning on power.
When you disconnect a cable, pull on its connector or on its strain relief
relief loop, not on the cable itself. As you pull out the connector, keep it
evenly aligned to avoid bending any connector pins. Also, before you
connect a cable make sure both connectors are correctly oriented and
aligned.
Before you clean your computer, turn if off, unplug it from its power
source, and remove the battery.
Handle components with care. Hold a component such as a memory
module by its edges, not its pins.
CAUTION: When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the following:
Do not use this product near water, for example, near a bathtub,
washing bowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.
Avoid using a telephone (other than a cordless type) during an electrical
第 2 頁，共 3 頁Safety Instructions
2003/6/10
file://C:\WINDOWS\TEMP\~hhCC6F.htm
electrical storm. There may be a remote risk of electric shock from
lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the power cord indicated in this manual.
第 3 頁，共 3 頁Safety Instructions
2003/6/10
file://C:\WINDOWS\TEMP\~hhCC6F.htm
Appendix: Regulatory
Notices
The FCC wants you to know
Federal Communications Commission (FCC) PART 68 Warning
REN: 0.8B
CE Notice (European Union)
CCIB Notice (China Only)
BSMI Notice (Taiwan Only)
Canadian Doc Notice
About this user's manual
The FCC wants you to know
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
Any changes or modifications made to this equipment may void the
user's authority to operate this equipment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
All external cables connecting to this basic unit must be shielded.
For cables connecting to PCMCIA cards, see the option manual or
installation instructions.
top
第 1 頁，共 5 頁Appendix: Regulatory Notices
2003/6/10
file://C:\WINDOWS\TEMP\~hh6CA6.htm
Federal Communications Commission (FCC)
PART 68 Warning
This equipment complies with Part 68 of the FCC Rules. On the bottom
of the computer is a label that contains, among other information, the
FCC Registration Number and Ringer Equivalence Number (REN) for
this equipment. You must, upon request, provide this information to your
your telephone company.
FCC Part 68 Registration Number: 6CTTAI - 25876 - FB - E
top
REN: 0.8B
The REN is useful to determine the quantity of devices you may connect
connect to your telephone and still have all of those devices ring when
your number is called. In most, but not all areas, the sum of the REN's
of all devices should not exceed five (5.0). To be certain of the number
of devices you may connect to your line, as determined by the REN, you
you should call your local telephone company to determine the
maximum REN for your calling area.
If your MODEM causes harm to the telephone network, the local
Telephone Company may discontinue your service temporarily. If
possible, they will notify you in advance.
However, if advanced notice isn't practical, you will be notified as soon
as possible. You will be informed of your right to file a complaint with the
the FCC.
Your telephone company may make changes in its facilities, equipment,
equipment, operations, or procedures that could affect the proper
functioning for your equipment. If they do, you will be notified in advance
advance to give you an opportunity to maintain uninterrupted telephone
service.
top
CE Notice (European Union)
Marking by the symbol indicates compliance of this Compal
computer to the EMC Directive and the Low Voltage Directive of the
European Union. Such marking indicates that this Compal system
meets the following technical standards:
EN 55022 - "Limits and Methods of Measurement of Radio
Interference Characteristics of Information Technology
Equipment."
EN 55024 - "Information technology equipment - Immunity
characteristics - Limits and methods of measurement."
EN 61000-3-2 - "Electromagnetic compatibility (EMC) - Part 3:
Limits - Section 2: Limits for harmonic current emissions
(Equipment input current up to and including 16 A per phase)."
EN 61000-3-3 - "Electromagnetic compatibility (EMC) - Part 3:
Limits - Section 3: Limitation of voltage fluctuations and flicker in
low-voltage supply systems for equipment with rated current up to
and including 16 A."
第 2 頁，共 5 頁Appendix: Regulatory Notices
2003/6/10
file://C:\WINDOWS\TEMP\~hh6CA6.htm
EN 60950 - "Safety of Information Technology Equipment."
NOTE: EN 55022 emissions requirements provide for two
classifications:
Class A is for typical commercial areas.
Class B is for typical domestic areas.
To determine which classification applies to your computer, examine
the FCC registration label located on the back panel of the computer. If
the label indicates a Class A rating, the following warning applies to
your computer:
RF INTERFERENCE WARNING: This is a Class A product. In a
domestic environment this product may cause radio frequency
(RF) interference, in which case the user may be required to take
adequate measures.
This Compal device is classified for use in a typical Class B domestic
environment.
A "Declaration of Conformity" in accordance with the preceding
directives and standards has been made and is on file at Compal
Computer Corporation.
top
CCIB Notice (China Only)
On Class A systems, the following warning will appear near the
regulatory label:
Warning: This is a Class A product. In a domestic environment this
this product may cause radio interference, in which case the user
may be required to take adequate measures.
top
BSMI Notice (Taiwan Only)
Most Compal computer products are classified by the Bureau of
Standards, Meteorology and Inspection (BSMI) as Class B information
technology equipment (ITE).
This Compal device is classified for use in a typical Class B domestic
environment.
top
Canadian Doc Notice
第 3 頁，共 5 頁Appendix: Regulatory Notices
2003/6/10
file://C:\WINDOWS\TEMP\~hh6CA6.htm
This digital apparatus does not exceed the Class B limits for radio noise
noise emissions from digital apparatus as set out in the Radio
Interference Regulation of the Canadian Department of
Communications.
"Le présent appareil numérique n'èmet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de la class
B prescrites dans le Règlement sur le brouillage radioélectrique édicté
par le ministère des Communications du Canada"
top
About this user's manual
This user's manual is designed to let you easily find the information you
you need to get the most from your notebook.
Chapter 1 introduces you to the features of your computer.
Chapter 2 gives you useful details on using your computer.
Chapters 3 and 5 give information on expanding your computer's
capabilities with an additional memory module, printer or PC Cards, and
and let you know how best to look after your computer.
Chapter 4 tells you how to look after your notebook computer, whether
at home or traveling.
Chapter 6 goes into more detail about power management and explains
explains how to conserve power while on the move.
Chapter 7 gives tips on solving typical problems you may run up
against.
There is no need to read the manual from the beginning to end. Simply
find your way to the section that interests you using the index, or
browse through the manual.
You will come across the following icons in the manual:
Helpful pointers and tricks to get more from your notebook
To help you note and avoid possible damage to your notebook's
hardware or software, or loss of your work
Points out possible damage to property, personal injury or death
Information in this document is subject to change without notice.
© Compal Electronics, Inc. 2002. All rights reserved.
Trademarks used in this document: Microsoft and Windows are
registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to
refer to either the entities claiming the marks and names or their
products.
top
第 4 頁，共 5 頁Appendix: Regulatory Notices
2003/6/10
file://C:\WINDOWS\TEMP\~hh6CA6.htm
The FCC wants you to know file:///C:/WINDOWS/TEMP/A-1.html
Federal Communications Commission (FCC) PART
68 Warning file:///C:/WINDOWS/TEMP/A-2.html
REN: 0.8B file:///C:/WINDOWS/TEMP/A-3.html
CE Notice (European Union) file:///C:/WINDOWS/TEMP/A-4.html
CCIB Notice (China Only) file:///C:/WINDOWS/TEMP/A-5.html
BSMI Notice (Taiwan Only) file:///C:/WINDOWS/TEMP/A-6.html
Canadian Doc Notice file:///C:/WINDOWS/TEMP/A-7.html
About this user's manual file:///C:/WINDOWS/TEMP/A-8.html
top file:///C:/WINDOWS/TEMP/Appendix.html
捷徑文字 Internet 網址
第 5 頁，共 5 頁Appendix: Regulatory Notices
2003/6/10
file://C:\WINDOWS\TEMP\~hh6CA6.htm
Introducing Your Notebook
Front
Right Side
Left Side
Back
Bottom
Front
1. Case Latch 8. Device Status Lights
2. Display 9. Floppy Disk Drive
3. Easy Buttons 10. Speaker
4. Wireless Communication Switch 11. Keyboard
5. Built-in Microphone 12. Power Button
6. Touch Pad 13. Keyboard Status
Lights
7. Touch Pad Buttons
第 1 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
Case Latch
Display
Easy Buttons
Wireless Communication Switch
Built-in Microphone
Touch Pad
Touch Pad Buttons
Device Status Lights
Floppy Disk Drive
Speaker
Keyboard
Power Button
Keyboard Status Lights
Top
Case Latch
Secures the display case to your notebook. To open the display, slide
the case latch to the right and lift the display. When you close the
display the case latch will secure it automatically.
Top
Display
Your display is either a 14.1" COLOR TFT/XGA, 15.0" TFT/XGA or
15.0" COLOR TFT/SXGA+ LCD. To find out more about the display's
functions, see the Display section in Chapter 2.
Top
Easy Buttons
These buttons launch your favorite programs.
Launches Outlook Express (or your default email program).
Launches your default Internet browser.
Top
Wireless Communication Switch
Turns the wireless communication function on or off. The wireless
communication LED on the front panel lights when the function is
activated.
第 2 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
Top
Built-in Microphone
Your computer's built-in microphone is ideal for home recording or
Internet telephony.
Top
Touch Pad
The Touch Pad works like a desktop mouse. For more information see
Keyboard and Touch Pad in Chapter 2.
Top
Touch Pad Buttons
The left and right Touch Pad buttons work like the left/right buttons on a
standard mouse. The central button is a scroll up/down button that
makes navigating through text more convenient.
Top
Device Status Lights
Indicates power on; flashing indicates standby mode.
Indicates notebook reading or writing data.
Indicates battery status. For details, see Battery.
Indicates wireless communication status.
To avoid losing your data, never turn your notebook off if this
indicator is flashing.
Top
Floppy Disk Drive
The FDD provides a means for you to import/export data and small files
into/from your computer.
Top
Speaker
To adjust the system speaker volume, look under the Sounds and Audio
Audio Devices Properties of the Control Panel. See Chapter 2 for more
第 3 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
details. Many software programs, such as multimedia applications, also
include their own volume controls.
Top
Keyboard
The keyboard includes a numeric keypad and the Microsoft®
Windows® logo key.
See Keyboard and Touch Pad in Chapter 2 for more on using
keyboard shortcuts.
Top
Power Button
Press to turn your notebook on. For more on power settings see Power
Management.
Always turn off your notebook by clicking on the Turn Off Computer icon
icon on the Windows Start men to avoid losing data.
Top
Keyboard Status Lights
Indicates uppercase letter function enabled
Indicates numeric keypad enabled
Indicates scroll lock function enabled
Top
Right Side
第 4 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
1. Audio Port
2. PC Card Slot
3. Modem Jack
4. Network Jack
5. PS/2 Jack
Audio Port
PC Card Slot
Network Jack
Modem Jack
PS/2 Jack
Top
Audio Port
You can connect a headphone or an external speaker to the port and
and a microphone to the port. The built-in speakers are disabled
when a device is connected to the port.
第 5 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
Top
PC Card Slot
Supports two type II PC Cards or one type III card. For more
information, see PC Cards in Chapter 5.
Top
Network Jack
The RJ-45 network jack allows you to connect your computer to a local
area network (LAN).
Be careful not to plug the telephone line into the slightly larger network
connector.
Top
Modem Jack
The modem jack allows you to connect your notebook to a telephone
line with a standard RJ-11 connector.
Never connect the modem jack to a digital line. The high current of a
digital line could damage the modem.
Top
PS/2 Jack
The PS/2 jack allows you to connect PS/2-compatible devices, such
as a mouse or keyboard.
PS/2-compatible devices are "hot swappable", meaning you can
install or remove them while your notebook is running. If the device
does not run, ensure that the correct device drivers are installed,
from the floppy disk or CD that came with the device. Then restart
your notebook.
Top
Left Side
第 6 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
1. CD-ROM / CD-RW / DVD-ROM Drive/Combo
CD-ROM / CD-RW / DVD-ROM Drive
Top
CD-ROM / CD-RW / DVD-ROM Drive
Your notebook supports CD-ROM, CD-RW, DVD-ROM and DVD/CD-
RW combo modules. For details on your notebook's specifications,
check with your computer dealer. For more information on using the
drive, see Playing CDs and Movies in Chapter 2.
Top
Back
1. Air Vents 6. RS-232 DB9
Connector
2. Security Cable Connector 7. TV-out Port
3. AC Power Connector 8. IEEE 1394 Port
4. External Monitor Port 9. USB Ports x 3
5. Parallel Port
Air Vents
Security Cable Connector
AC Adapter Connector
External Monitor Port
Parallel Port
RS-232 DB9 Connector
TV-out Port
IEEE 1394 Port
USB Connectors
Top
Air Vents
第 7 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
An internal fan creates airflow through the vents, preventing your
notebook from overheating.
When it gets hot, your notebook will switch on the fans, which may
make some noise. This is normal, and does not mean there is a
problem.
Never block, push objects into, or allow dust to gather in the air vents.
Doing so may damage your notebook or cause a fire.
Top
Security Cable Connector
To protect your notebook from theft, you can purchase an antitheft
device. Instructions for use are included with such devices.
Before purchasing any antitheft device, check that it will work with your
notebook's security cable connector.
Top
AC Adapter Connector
Use this connector to attach the AC adapter to your notebook. You can
connect an AC adapter when your notebook is switched on or off.
While the AC adapter works with electrical outlets worldwide, power
connectors and power strips vary from country to country. Ensure you
use compatible cable or correctly connect the cable to the power strip or
or electrical outlet. Failure to do so may cause fire or damage to
equipment.
Top
External Monitor Port
Use this port to connect an external monitor to your computer. See
Display, Chapter 2.
Top
Parallel Port
Use this port to connect parallel devices, such as a printer.
To protect your notebook, wait 5 seconds after turning it off before
disconnecting any external device.
Top
RS-232 DB9 Connector
第 8 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
This male, nine-pin RS-232 connector allows connection of serial
devices.
Top
TV-out Port
Use this port to connect a television set. See Display, Chapter 2, for
details.
Top
IEEE 1394 Port
The IEEE 1394 port allows you to connect devices that utilize IEEE
1394 technology to your computer. This technology is widely used in
consumer products such as digital cameras.
Top
USB Connectors
Use these ports to connect up to three USB devices, such as a
mouse, full-size external keyboard, or printer.
USB is a peripheral expansion standard that supports a data-transfer
rate of up to 12 Mbps. USB peripherals have a single standard for
cables and connectors. You can install and remove USB devices
while the computer is on. This is known as "hot swapping".
Top
Bottom
1. Battery Release Latch
2. Battery Latch Lock
3. Battery Pack
第 9 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
4. HDD Cover
5. Memory Module Cover
6. CPU Cover
Battery Release Latch
Battery Latch Lock
Battery Pack
HDD Cover
Memory Module Cover
CPU Cover
Top
Battery Release Latch
The battery release latch secures the battery pack. To release, simply
slide the latch across. The battery pack will pop up.
Top
Battery Latch Lock
The battery latch lock prevents the latch being released accidentally. To
To release the lock, press down.
Top
Battery Pack
With a charged battery pack installed, you can use your notebook
without connecting it to an electrical outlet. For more details, see
Battery, Chapter 6.
Top
HDD Cover
The HDD Cover should only be removed if you need to repair or replace
replace the installed HDD unit.
Top
Memory Module Cover
The memory module(s) is (are) housed beneath the memory module
cover. For more information on replacing memory modules, see
Expanding Memory, Chapter 3.
Top
CPU Cover
第 10 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
The CPU Cover should only be removed if you need to repair or replace
replace the installed CPU unit.
Top
第 11 頁，共 13 頁Introducing Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh461E.htm
Operating Your Notebook
Turning Your Notebook On and Off
Tips For Using Windows
Keyboard and Touch Pad
Personalizing Your Desktop
Display
Networks
Managing Programs
Managing Files
Playing CDs and Movies
Turning Your Notebook On and Off
Turning Your Notebook On
Turning Your Notebook Off
Logging Off
Adding User Accounts
Standby Mode
Top
Turning Your Notebook On
Ensure the diskette drive is empty before turning your notebook on.
Press the power button to turn on your notebook.
Do not turn off the computer until the operating system has loaded
completely. Turning the computer off during its initial startup will result
in an error the next time you start your notebook.
Always turn your notebook off by performing a Windows shutdown (click
(click Start -> Turn Off Computer -> Turn Off) rather than by pressing
the power button. Failure to do so may result in data loss.
Top
Turning Your Notebook Off
If your notebook is using Microsoft Windows XP Professional operating
system, there are security and networking features not available in
Windows XP Home Edition. You will see different options in some
第 1 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
windows, related to security and networking.
Save and close any open files, exit any open programs. Click Start ->
Turn Off Computer -> Turn Off.
Your notebook will automatically turn off after the shutdown process is
finished.
Top
Logging Off
With Microsoft Windows XP, multiple users can access a single
computer with their own, personal settings. Using their own password,
each user logs on to the computer, meaning other users cannot access
their settings or files. To log off:
1. Save and close any open files, exit any open programs, click Start ->
Log Off -> Log Off.
2. To switch users, click Start -> Log Off ->Switch User.
Using Fast User Switching, programs that previous users were
running remain running in the background. This means a possible
slower computer response. It may also stop multimedia programs,
including games and DVD software, from running.
Fast User Switching does not work if your notebook is running
Windows XP Professional and is a member of a computer domain or if
the notebook has less than 128 MB of memory.
Top
Adding User Accounts
Different account options are available when a computer is running the
Windows XP Professional operating system and is connected to a
domain.
With Windows XP installed, the system administrator or a user with
administrator rights can create additional user accounts:
1. Click Start -> Control Panel -> User Accounts.
2. Under Pick a task, click Create a new account.
3. Under Name the new account, enter the name of the new user. Click
Next.
4. Under Pick an account type, choose one of the following options:
Computer administrator: Can change all computer settings.
Standard (Windows XP Professional only): Can install some
programs and hardware.
Limited: Can only change your own personal settings, such as
your password. You are not able to install programs or use the
Internet.
5. Click Create Account.
第 2 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Top
Standby Mode
To find out how to conserve power using the Standby Mode, see Power
Management, Chapter 6.
Top
Tips For Using Windows
Microsoft Windows XP Help
Windows Desktop
Desktop Cleanup Wizard
Start Button
Taskbar
Notification Area (System Tray)
Recycle Bin
Control Panel
My Computer
Top
Microsoft Windows XP Help
For Microsoft Windows XP help, right click Start -> Explore.
In Windows Explorer, click the search icon then opt to search for
Information in Help and Support Center. In the Help and Support
Center you can search for specific information or click on the Home icon to
view the Help and Support Center home page.
第 3 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Top
Windows Desktop
Depending on your notebook setup and software, your desktop may have different
or additional shortcuts. See Personalizing Your Desktop, Section 2.4, for more
information.
Top
第 4 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Desktop Cleanup Wizard
The Desktop Cleanup Wizard moves programs not frequently used to a
folder 7 days after you first start your notebook and every 60 days after
that. The Start menu's appearance changes as programs are moved. To
To turn off the Desktop Cleanup Wizard:
Right-click an empty spot on your desktop -> Properties -> Desktop ->
Customize Desktop -> click Run Desktop Cleanup Wizard every 60
days to remove the check mark -> OK.
The Desktop Cleanup Wizard can be run any time by simply clicking
Clean Desktop Now under Run Desktop Cleanup Wizard every 60
days.
Top
Start Button
The Start button allows easy access to your notebook's programs.
The Start menu is designed to change, to show the programs you use
most frequently. To always keep an item on the Start menu, no matter
how often it's used, right-click the item and click Pin to Start menu.
Log Off allows the current user to log off so a new user can log on to
the notebook using their personal settings.
Turn Off Computer provides options for turning off, restarting, and
placing your notebook in power saving modes. If your notebook is
running Windows XP Professional and is connected to a domain,
different options appear in the Shut Down window.
Top
第 5 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Taskbar
The Start button is on the left and the notification area on the right.
Each time you open a program, a button for that program appears on
the taskbar. To move between programs, simply click on the relevant
button. Windows XP will group multiple instances of the same program
on a single taskbar button if more space is needed. Toolbars can be
added to or removed from the taskbar:
Right-click an empty spot on the taskbar, and select Toolbars ->
choose the toolbar you want to add.
Top
Notification Area (System Tray)
The icons in this area allow quick access to programs and computer
functions, including the clock and printer status. Windows XP hides
icons that are not used frequently. To see hidden icons, click to see
hidden icons. To prevent Windows XP from hiding icons:
Right-click an empty spot on the Taskbar -> Properties -> ensure that
Hide inactive icons is not checked.
Top
Recycle Bin
When you delete a file, it is moved to the Recycle Bin. Files can be
restored from the Recycle Bin.
By emptying the Recycle Bin, files are permanently deleted.
Top
Control Panel
第 6 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
In the Control Panel you can change how Windows looks and works.
Click the Start button and click Control Panel.
There are two interfaces - you can choose either Classic View or
Category View. You can switch interfaces in the upper left hand window
of the Control Panel window.
Under Pick a Category, choose the category of the task you wish to
complete, click, then choose the task in the next window.
Top
My Computer
My Computer allows you to see the contents of your notebook's drives.
drives. The My Computer icon appears on your Desktop. To see the
contents of a drive or folder, click on the My Computer icon then
double-click the icon for the drive or folder you want to view (for
example, drive C).
You can also use Windows Explorer to see the contents of your
notebook and find files. To open Windows Explorer, right-click the
Start button and click Explore. Find the drive or folder that you want to
view. To find out more about My Computer and Windows Explorer,
see the Help and Support Center.
Top
Keyboard and Touch Pad
Numeric Keypad
Keyboard Shortcuts
Windows Logo Key Functions
第 7 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Easy Buttons
Touch Pad
Customizing the Touch Pad
Using an External Mouse
Top
Numeric Keypad
Keypad numbers and symbols are marked in green on the right of the
keypad keys.
To enable the numeric keypad, press .
The indicator will light when the numeric lock is on.
To disable the numeric keypad, press again.
To use the primary function of a dual-function key when the numeric
keypad is enabled, press and the desired key.
When Num Lock and Scroll lock are disabled, you can move the cursor
using the key with the u, o, 8, and k keys.
Top
Keyboard Shortcuts
Switches Display Mode (LCD->CRT->Simultaneous). Switches
the video image to the next display in the following sequence:
the integrated display, an external monitor, and both displays
simultaneously
Number Lock
Scroll Lock
Brightness Up
Brightness Down
When using an external PS/2 keyboard, the Fn key can be
simulated by using the left-Ctrl + left-Alt keys. USB keyboards do
do not support this function.
Top
Windows Logo Key Functions
opens Windows Explorer
第 8 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
opens the Run dialog box
opens the Search Results dialog box
opens the Search Results - Computers dialog box (when
your notebook is connected to a network)
opens the System Properties dialog box
To adjust keyboard operation, including character repeat
rate, in the Control Panel click Printers and Other
Hardware -> Keyboard.
The Application key (to the right of the Windows key)
works in the same way as the right button on the touch
pad or a mouse.
Top
Easy Buttons
The Easy Buttons are designed to give you fast access to the mail and
Internet browser program.
The key launches your default email program.
The key launches your default Internet browser.
StickyKeys
The StickyKeys function lets you use the SHIFT, CTRL, ALT, FN keys
or the Windows logo key (referred to as modifier keys) in conjunction
with other keys by pressing one key at a time instead of simultaneously.
simultaneously.
To activate StickyKeys mode, press the Shift key five times and then
click OK.
Alternatively, you can click on Start -> Control Panel -> Accessibility
Options and check Use StickyKeys before clicking OK.
第 9 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
To further customize StickyKeys, click on Settings in either of the
above dialogue boxes. The following dialogue box will appear.
Click Use shortcut to enable the listed shortcut to activate StickyKeys
mode.
第 10 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
By checking Press modifier key twice to lock, pressing the SHIFT,
CTRL, ALT, FN or the Windows logo key twice will 'lock' the key until it
is pressed again. This allows you to perform multiple commands with
these keys in succession without having to press the modifier key again
each time.
Check Turn StickyKeys off if two keys are pressed at once to have
StickyKeys automatically disable whenever any two keys are pressed
simultaneously.
If Make sounds when modifier key is pressed is checked, a tone will
be heard each time a modifier key is pressed. Different tones are heard
when activating and deactivating modifier keys.
Check Show StickyKeys status on screen to display the StickyKeys
icon in your toolbar whenever the StickyKeys mode is activated. The
icon will change to indicate which modifier key, if any, is currently
active.
Click on OK to confirm your changes, or Cancel to exit the dialogue box
box without making any changes.
Top
Touch Pad
The touch pad responds to the movements and pressure of your finger,
finger, allowing you to move the cursor around the screen, in the same
way you would with a mouse.
Place your fingers on the keyboard in the normal typing position.
You can use the touch pad by moving either your right or left thumb off
the space bar and on to the touch pad.
Gently move your thumb across the touch pad in the direction you want
want the cursor to move. The pad detects the change in pressure and
moves the cursor in the corresponding direction.
The touch pad buttons have essentially the same function as mouse
buttons. Clicking these buttons makes selections, drags objects, or
performs a variety of other functions depending on the software. To
select an object, first move the pointer over the object you want to
select, and then press the left button one time and release it. The
functionality of these buttons depends on your software.
Double-clicking is a common technique for selecting objects or
launching programs. Move the pointer over the object you wish to select
select then quickly press the left button twice.
第 11 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
You may also select object or execute applications from icons by
double-tapping. This is similar to double-clicking, but instead of pressing
pressing the touch pad buttons, you tap the touch pad itself.
The central mouse button allows you to scroll easily through windows.
Press the upper part of the button to move your cursor upwards, press
the lower part of the button to move the cursor down the window.
Be patient, it may take a little practice to master the touch pad.
Top
Customizing the Touch Pad
To adjust touch pad settings, use the Mouse Properties window, which
you can open by clicking Control Panel—>Printers and Other
Hardware—>Mouse.
Select the desired settings and click Apply.
Click OK to save the settings and close the window.
Top
Using an External Mouse
You can connect a mouse or trackball as an option to using your
notebook's touch pad. Your notebook supports PS/2-compatible
pointing devices.
When a mouse or trackball is connected, you can still use your
notebook's touch pad.
1. Attach the PS/2 mouse cable to the PS/2 port. If the mouse is not
responding, you may need to adjust your BIOS settings. For BIOS set
up information, refer to the BIOS help field by pressing F2 while your
notebook is booting up.
2. For additional steps, refer to your mouse documentation.
To connect more than one PS2 device at a time, such as a keyboard
and mouse, you will need to purchase a Y-cable.
Top
Personalizing Your Desktop
Choosing Wallpaper
Choosing a Screen Saver
Choosing a Desktop Theme
Creating a Shortcut on the Desktop
Top
Choosing Wallpaper
To make your notebook reflect your style, you can set background
第 12 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
colors and patterns, the wallpaper, on the desktop.
Control Panel -> Appearance and Themes -> Pick a task -> Change
the desktop background.
The Display Properties window offers a choice of wallpapers. Choose
the name of the wallpaper you want to display, or click (None) if you
prefer not to use a wallpaper image.
You can also choose your own images by choosing Browse and
Top
Choosing a Screen Saver
Control Panel -> Appearance and Themes -> Pick a task -> Choose
a screen saver.
Select a screen saver from the Screen Saver pull-down menu, or click
click (None) if you prefer not to activate a screen saver.
You can customize your screen saver by choosing Settings. To check
your selections, choose Preview.
To accept the settings, click OK and close the Display Properties
window.
Top
Choosing a Desktop Theme
Desktop themes changes the appearance of your desktop and add
sound effects:
Control Panel -> Appearance and Themes -> Pick a task -> Change
the computer's theme.
Select a theme from the Theme pull-down menu in the Display
Properties Window, then click OK.
Top
Creating a Shortcut on the Desktop
A shortcut is an icon that is placed on the desktop let you quickly access
access programs, files, folders, and drivers. To create a shortcut:
Open My Computer or Windows Explorer, and highlight the file or
program you want to create a shortcut to.
Click and hold down the right touch pad button, drag the highlighted
item to the Windows desktop, and then release the right touch pad
button to display a pop-up menu.
Click Create Shortcut(s) Here.
An icon will appear on your desktop - double-click to activate the
shortcut.
Top
Display
第 13 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Adjusting Brightness
Using an External Monitor or Television
Setting Display Resolution
Top
Adjusting Brightness
To conserve power when running your notebook from the battery, set
the brightness to the lowest comfortable setting using the keyboard
shortcuts.
Top
Using an External Monitor or Television
When you start your notebook with an external display device such as
an external monitor or television attached and turned on, the image may
may appear on either the display or the external device. Alternatively,
you can
Press to switch the video image to the display only, the
display and the external device simultaneously, or the external device
only.
Top
Setting Display Resolution
To view a program at a specific resolution, both the video controller and
display must support the program and the necessary video drivers must
must be installed.
Before changing any of the original display settings, note the original
settings for future reference.
Start -> Control Panel -> Pick a category -> Appearance and
Themes.
Under Pick a task..., click the area you want to change, or under or
pick a Control Panel icon, click Display.
You can try different settings for Color quality and Screen resolution.
If you choose a resolution or color palette that is higher than the display
supports, the settings will automatically adjust to the closest possible
setting.
Top
Networks
To access a network:
At the office, you can access a network via the built-in PCI LAN. For
specific information about connecting to the LAN or WAN, consult your
systems administrator.
第 14 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
If you are working from home or while traveling, you need a dial-up
connection. Ask your system administrator for the telephone number of
the network.
To set up the connection, go to Start->Control Panel->Network and
Internet Connections (in Classic Interface, Network Connections).
Enter the details for your connection and click OK.
Top
Managing Programs
Running Programs
Adding Software
Removing Software
Top
Running Programs
Programs are any software that process data - like a word processing
program or an email program. They require an operating system - like
Windows XP - to run on.
To run a program, click Start -> Programs.
Click the program you want to run.
On the right side of the title bar in the window of any open program,
there are three icons:
minimizes the program. That is, it is removed from the screen, but is
is still running. It will appear as a button on your bottom taskbar. To
restore the program, simply click the button.
enlarges (maximizes) the window to fill your entire screen. When
the window is maximized, the button switches to , which will reduce
the size of the window when clicked.
closes the program or document.
Top
Adding Software
To check what software is already installed on your computer, click
Start -> All Programs. If a program is listed in the All Programs menu
menu or the Start menu, the software is already installed.
Before installing software, check the software's technical requirements
to ensure that it is compatible with your notebook and that there is
enough memory and hard drive space for installation and operation.
Temporarily disable your notebook's antivirus software before installing
software. See the documentation that came with the antivirus software
for detailed procedure.
Be sure to enable your antivirus software once you have installed any
第 15 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
new software.
Insert the software installation CD into the CD drive and follow the
instructions that came with the software to help you respond to the
prompts on the screen.
If the software installation CD does not automatically run, click Start ->
Run. In the dialogue box, type x:\setup.exe (where x is the letter of your
your CD drive [usually D or E]). Then click OK and follow the prompts
on your screen.
Top
Removing Software
Once you've begun removing software, do not interrupt the process. To
do so may result in data loss and corruption of your operating system.
Start -> Control Panel -> Add or Remove Programs -> Change or
Remove Programs.
Select the program that you want to remove and click the
Change/Remove button. Instructions for removing programs will
appear on the screen.
Some programs may not be listed and cannot be removed via this
window. In this case, check the documentation that came with the
specific program.
Top
Managing Files
Updating Antivirus Software
Backing Up Files
Finding Files
Copying a File on the Hard Drive
Copying a File to a Floppy Disk
Moving Files
Renaming Files
Deleting Files
Emptying the Recycle Bin
Retrieving Files From the Recycle Bin
Top
Updating Antivirus Software
There are thousands of known viruses, and more appear all the time.
Installing antivirus software is the only way to protect your data,
software and hardware. Regular updates are necessary to ensure
第 16 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
protection.
Your computer dealer can advise you regarding purchasing antivirus
Before installing any software from unlicensed sources, scan for
viruses. Regularly backup your data to safeguard against loss if your
notebook is infected.
Top
Backing Up Files
Regularly backing up your files will protect you from losing data from
accidental file deletion, viruses or hard drive failure. Programs can be
reinstalled, but unless you have backed up your work, you will lose your
your data files.
The most convenient way to back up your files is to a CD-RW drive,
although for smaller files, you can use a floppy disk.
Top
Finding Files
Right click on Start -> Search.
In the search window, type either All or part of the file name or A
word or phrase in the file.
Specify where you want the system to look by specifying a drive or
folder in the Look in pull-down menu.
Windows will search the entire hard drive (or drive C partition) if the
default setting of C: is unchanged.
Click Search to begin searching.
Files found that match your search criteria are listed in the Search
Results window.
Top
Copying a File on the Hard Drive
From the Desktop, select My Computer.
Locate the file you want to copy, and click the file to select (highlight) it.
Under File and Folder Tasks -> Copy this file.
In the Copy Items window, select the location where you want to copy
the file.
Click Copy.
Top
Copying a File to a Floppy Disk
Insert a floppy disk into the floppy drive.
From the Desktop, select My Computer.
第 17 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Locate the file you want to copy, and click the file to select (highlight) it.
Under File and Folder Tasks -> Copy this file -> Copy Items -> 3½
Floppy (A:).
Top
Moving Files
Never move files that are part of an installed program. Doing so may
make the program unusable.
From the Desktop, select My Computer.
Locate the file you want to move, and click the file to select (highlight)
it.
Click Move this file.
In the Move Items window, click the location where you want to move
the file.
Click Move.
Top
Renaming Files
Use Windows Explorer or My Computer to locate the file you want to
rename, and click the file to select (highlight) it.
Click the File menu and click Rename.
Never change a file's extension (the last three characters after the
period). Doing so may render the file unusable.
Type the new filename and press Enter.
Top
Deleting Files
Never delete files that are part of an installed program. Doing so may
render the file unusable.
Use Windows Explorer or My Computer to locate the file you want to
delete, and click the file to select (highlight) it.
Click the File menu and click Delete.
Click Yes to send the file to the Recycle Bin.
If you accidentally delete a file, see Retrieving Files From the
Recycle Bin.
Top
Emptying the Recycle Bin
Files remain in the Recycle Bin and take up space on the hard drive
until you empty them from the Recycle Bin.
第 18 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Files deleted from a floppy disk or from a network are permanently
Double-click the Recycle Bin icon.
The Recycle Bin window appears and lists all deleted files, their
previous locations, and the date you deleted them.
Click the File menu, and click Empty Recycle Bin.
When the confirmation dialog box appears, click Yes to delete all file
(s).
All files disappear from the Recycle Bin and are removed from your
notebook.
Top
Retrieving Files From the Recycle Bin
Deleted files are moved to the Recycle Bin and remain there until you
empty the Recycle Bin. If you delete a file in error, you can retrieve it
from the Recycle Bin:
Double-click the Recycle Bin icon .
The Recycle Bin window will appear, listing all deleted files, their
previous locations, and the dates you deleted them.
Select the file you want to retrieve, click the File menu, and then click
Restore.
The file disappears from the Recycle Bin and is moved to its original
location.
Top
Playing CDs and Movies
Inserting Discs
Adjusting Volume
Adjusting Picture
Top
Inserting Discs
Be careful not to press down on the drive tray when opening or closing
it. When the drive is not in use, keep the tray closed.
Do not move the computer when playing CDs or DVDs.
Press the eject button on the front of the drive.
Pull the tray out.
With the label side up, place the disc in the center of the tray.
Snap the disc onto the spindle.
第 19 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Gently push the tray back into the drive.
If your notebook has a CD-RW/DVD or DVD, you can watch movies.
For more information on playing CDs or watching movies, click Help
on the CD player software or DVD player software.
Top
Adjusting Volume
If you do not hear anything when playing a CD or DVD, check that the
speakers are not muted.
Start -> All Programs -> Accessories -> Entertainment -> Volume
Control.
In the Volume Control window, click and drag the bar in the Volume
Control column and slide it up or down to increase or decrease the
volume.
Top
Adjusting the Picture
If you receive an error message that the current resolution and color
depth are using too much memory and preventing DVD playback, adjust
adjust the display properties:
Start -> Control Panel -> Pick a category -> Appearance and
Themes -> Pick a task... -> Change the screen resolution.
In the Display Properties window, click and drag the bar in Screen
resolution to change the setting to 1024 x 768 pixels.
Click the pull-down menu under Color quality -> Medium (16 bit) ->
OK.
Top
第 20 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Turning Your Notebook On and Off file:///C:/WINDOWS/TEMP/2-1.html
Tips For Using Windows file:///C:/WINDOWS/TEMP/2-2.html
Keyboard and Touch Pad file:///C:/WINDOWS/TEMP/2-3.html
Personalizing Your Desktop file:///C:/WINDOWS/TEMP/2-4.html
Display file:///C:/WINDOWS/TEMP/2-5.html
Networks file:///C:/WINDOWS/TEMP/2-6.html
Managing Programs file:///C:/WINDOWS/TEMP/2-7.html
Managing Files file:///C:/WINDOWS/TEMP/2-8.html
Playing CDs and Movies file:///C:/WINDOWS/TEMP/2-9.html
Turning Your Notebook On file:///C:/WINDOWS/TEMP/2-1-1.html
Turning Your Notebook Off file:///C:/WINDOWS/TEMP/2-1-2.html
Logging Off file:///C:/WINDOWS/TEMP/2-1-3.html
Adding User Accounts file:///C:/WINDOWS/TEMP/2-1-4.html
Standby Mode file:///C:/WINDOWS/TEMP/2-1-5.html
Top file:///C:/WINDOWS/TEMP/Chapter%202.html
Microsoft Windows XP Help file:///C:/WINDOWS/TEMP/2-2-1.html
Windows Desktop file:///C:/WINDOWS/TEMP/2-2-2.html
Desktop Cleanup Wizard file:///C:/WINDOWS/TEMP/2-2-3.html
Start Button file:///C:/WINDOWS/TEMP/2-2-4.html
Taskbar file:///C:/WINDOWS/TEMP/2-2-5.html
Notification Area (System Tray) file:///C:/WINDOWS/TEMP/2-2-6.html
Recycle Bin file:///C:/WINDOWS/TEMP/2-2-7.html
Control Panel file:///C:/WINDOWS/TEMP/2-2-8.html
My Computer file:///C:/WINDOWS/TEMP/2-2-9.html
Numeric Keypad file:///C:/WINDOWS/TEMP/2-3-1.html
Keyboard Shortcuts file:///C:/WINDOWS/TEMP/2-3-2.html
Windows Logo Key Functions file:///C:/WINDOWS/TEMP/2-3-3.html
Easy Buttons file:///C:/WINDOWS/TEMP/2-3-4.html
Touch Pad file:///C:/WINDOWS/TEMP/2-3-5.html
Customizing the Touch Pad file:///C:/WINDOWS/TEMP/2-3-6.html
Using an External Mouse file:///C:/WINDOWS/TEMP/2-3-7.html
Choosing Wallpaper file:///C:/WINDOWS/TEMP/2-4-1.html
Choosing a Screen Saver file:///C:/WINDOWS/TEMP/2-4-2.html
Choosing a Desktop Theme file:///C:/WINDOWS/TEMP/2-4-3.html
Creating a Shortcut on the Desktop file:///C:/WINDOWS/TEMP/2-4-4.html
Adjusting Brightness file:///C:/WINDOWS/TEMP/2-5-1.html
Using an External Monitor or Television file:///C:/WINDOWS/TEMP/2-5-2.html
Setting Display Resolution file:///C:/WINDOWS/TEMP/2-5-3.html
Running Programs file:///C:/WINDOWS/TEMP/2-7-1.html
捷徑文字 Internet 網址
第 21 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
Adding Software file:///C:/WINDOWS/TEMP/2-7-2.html
Removing Software file:///C:/WINDOWS/TEMP/2-7-3.html
Updating Antivirus Software file:///C:/WINDOWS/TEMP/2-8-1.html
Backing Up Files file:///C:/WINDOWS/TEMP/2-8-2.html
Finding Files file:///C:/WINDOWS/TEMP/2-8-3.html
Copying a File on the Hard Drive file:///C:/WINDOWS/TEMP/2-8-4.html
Copying a File to a Floppy Disk file:///C:/WINDOWS/TEMP/2-8-5.html
Moving Files file:///C:/WINDOWS/TEMP/2-8-6.html
Renaming Files file:///C:/WINDOWS/TEMP/2-8-7.html
Deleting Files file:///C:/WINDOWS/TEMP/2-8-8.html
Emptying the Recycle Bin file:///C:/WINDOWS/TEMP/2-8-9.html
Retrieving Files From the Recycle Bin file:///C:/WINDOWS/TEMP/2-8-10.html
Inserting Discs file:///C:/WINDOWS/TEMP/2-9-1.html
Adjusting Volume file:///C:/WINDOWS/TEMP/2-9-2.html
Adjusting Picture file:///C:/WINDOWS/TEMP/2-9-3.html
捷徑文字 Internet 網址
第 22 頁，共 22 頁Operating Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hh84F9.htm
The BIOS Setup Program
Introduction
Navigating through the BIOS Setup Program
The Main Menu
The System Devices Menu
The Security Menu
The Boot Menu
The Information Menu
The Exit Menu
Introduction
The BIOS (Basic Input and Output System) Setup program is a menu
driven utility that enables you to make changes to the system
configuration and tailor the operation of your Notebook to your individual
individual work needs. A ROM-based configuration utility displays the
system's configuration status and provides you with a tool to set system
parameters. These parameters are stored in nonvolatile battery backed
backed-up CMOS RAM, which saves this information even when the
power is turned off. When the computer is turned back on, the system is
is configured with the values found in CMOS. Using easy-to-use menus,
menus, you can configure such items as:
Hard drives, diskette drives and peripherals
Video display options
Password protection from unauthorized use
Boot devices
The settings made in the Setup program intimately affect how the
Notebook performs. It is important, therefore, first to try to understand all
all the available options, and second, to make settings appropriate for
the way you use the Notebook. This chapter will guide you through the
Setup program by providing clear explanations for all Setup options.
A standard configuration has already been set in the Setup program by
the factory technicians, so you will very likely have little to worry about
for now. However, eventually you may want to customize your system to
to suit your own performance needs. It is recommended that you read
this chapter and become familiar with the adjustments that can be made
made in the BIOS.
The next section explains how to move around in the Setup program, as
as well as how to specify and save your new settings. A brief discussion
discussion of the optional settings among the different submenus
follows.
第 1 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Top
Navigating through the BIOS Setup Program
The Setup program has been designed to make it as easy to use as
possible. It is a menu driven program, which means you can scroll
through the various directories and make your selections among the
various predetermined choices. If you accidentally make a setting and
do not know which one to switch back to, use the BIOS hot keys to
return to the previous value. The hot keys are discussed in more detail
later in this chapter.
When turning on the Notebook for the first time you may get a message
message prompting you to run the BIOS Setup program. A warning
message may appear on the screen if the hardware configuration is
changed or the POST fails. This message will inform you of any errors
or invalid settings and prompt you to run the Setup program to correct
the problem.
Even if you are not prompted by a message instructing you to use the
Setup program, at some time in the future you may want to change the
configuration of your computer. For example, you may want to make
changes to the display option settings or enable the Notebook's
password function for security purposes. It will then be necessary to
reconfigure your system using the Setup program so that the computer
can recognize these changes.
The list below gives a few examples of reasons why you may want or
need to run the BIOS Setup program.
You have set up the computer for the first time and you got a message
stating that you should run the BIOS Setup program.
You want to redefine the communication ports to prevent any conflicts.
You want to change the password or make other changes to the
security setup.
The few examples listed above are by no means a complete list.
Accessing the BIOS Setup program
Launching submenus
General Help
Saving Changes and Exiting the Setup Program
Top
Accessing the BIOS Setup program
To access the BIOS Setup program, press the F2 key after the
Notebook has run through its POST.
The Menu Bar
The top of the Setup screen has a menu bar with the following
selections:
Main Use this menu to make changes to the basic
system configuration.
第 2 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
System Devices Use this menu to enable and make changes to the
advanced features available on your system.
Security Use this menu to set System and Boot passwords.
Boot Use this menu to specify the order in which the
Notebook is to check for a device to boot the
system.
Info This menu lists hardware information about your
system. The items cannot be modified.
Exit Use this menu to specify how to exit the Setup
program.
To move between menu bar items, use the [ ] and [ ] arrow keys
until the desired item is highlighted. For example, if you want to move
from the Main menu to the System Devices menu, press the right arrow
key [ ] once. The System Devices menu item should now be
highlighted.
The Legend Bar
At the bottom of the Setup screen, you will notice a legend bar. The
keys in the legend bar allow you to navigate through the various
individual setup menus. The following table lists the keys found in the
legend bar with their corresponding functions:
Legend Key Function
[Fl] or [Alt] +
[H] Displays the General Help window.
[Esc] Exits the current menu and moves you to the Exit
menu.
[ ] or [ ] Selects a different menu bar item.
[ ] or [ ] Moves the cursor up and down between fields.
[F5] / [-] Scrolls backwards through the values for the
highlighted field.
[F6] / [+] /
[Space]
Scrolls forward through the values for the
highlighted field.
[F9] Sets the parameters to their default values.
[Fl0] Saves any changes and exits Setup.
[Enter] Executes commands or selects a submenu.
Top
Launching submenus
A submenu contains additional options for a field parameter. To call up
a submenu, simply move the highlight to the desired field and press the
[Enter] key. The submenu will then immediately appear. Use the legend
keys to enter values and move from field to field within a submenu just
as you would within a menu.
If you are a first time user or are not familiar with BIOS Setup programs,
programs, it is highly recommended that you take a few minutes to
familiarize yourself with each of the legend keys and their corresponding
corresponding functions. Practice navigating through the various menus
menus and submenus. If you accidentally make unwanted changes to
第 3 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
the current configuration, pressing the function key [F9] will return the
activated menu to its factory set values.
Note that on the right side of each of the BIOS screens there is a
section labeled Item Specific Help. While moving around through the
Setup program, explanations for the currently highlighted field appear
in the Item Specific Help window.
Top
General Help
In addition to the Item Specific Help window, the BIOS Setup program
also provides a General Help screen. This screen can be called up from
from any menu by simply pressing the function key [Fl], or the [Alt] + [H]
combination. The General Help screen lists the legend keys with their
corresponding alternates and functions.
When a scroll bar appears to the right of a help window, this indicates
that there is more information to be displayed that will not fit in the
window. Use the [Page Up] and [Page Down] keys or the up and down
arrow keys [ ] [ ] to scroll through the entire help document. Press
[Home] to display the first page. Press [End] to go to the last page. To
exit the help window, press the [Enter] or the [Esc] key.
Top
Saving Changes and Exiting the Setup Program
Refer to the Exit Menu section of this chapter for detailed information on
on saving changes and exiting the Setup program.
Top
The Main Menu
When the Setup program is accessed, the Information screen appears. Use the [ ]
key to select the Main Menu.
第 4 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Figure 3-1: The Setup Main Menu
Enter the Main Menu of the BIOS setup program to make changes to the Notebook's
basic system configuration. Each of the fields displayed in this menu is covered below
below in detail.
System Time
Sets your system to the time that you specify (usually the current time). The format is
hour, minute, and second, using the 24-hour clock. Insert the appropriate information.
information. Use the tab key to move between the hour, minute, and second fields.
System Date
Sets your system to the date that you specify (usually the current date). The format is
is month, day, year. Type in the appropriate information. Use the tab key to move
between the month, day, and year fields.
Floppy Disk Drive
The Floppy Drive status is auto detected by the system.
Internal Hard Disk
The hard disk types and capacity are auto detected and set by the system. If there is
no hard disk present or unknown type, "None" should be shown on this field,
otherwise the capacity should be shown.
ATAPI Device
The CD-ROM, DVD-ROM or CD-RW is auto detected and set by the system. If there
is no ATAPI Device present or unknown type, "None" should be shown on this field,
otherwise the model name should be shown.
第 5 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Boot Display Device
This field allows you to specify display type options. They are:
Auto-Selected
Both
Auto-Selected: During the power on process, the system will detect if any display
device is connected on the external video port. If any external display device is
connected, the power on display will be in CRT (or projector) only mode. Otherwise it
will be in LCD only mode. will automatically select the external display if a CRT
monitor is connected to the Notebook.
Both allow you to simultaneously view the Notebook's LCD display and an external
CRT monitor display or projector.
The default value for this field is: Both
Screen expansion
This field allows you to enlarge the LCD viewing area when you operate in lower
resolution. There are two possible settings:
Enabled
Disabled
The default value for this field is: Enabled
Television Type
This field allows you to select the television system mode. There are two possible
settings:
NTSC
PAL
The default setting for this field is: NTSC
VGA Memory
This field displays the amount of shared memory available for the Video Graphics
Array. There are three possible settings: 16MB, 32MB and 64 MB. The default value
for this field is 16MB.
NOTE: The sub-items under each device will not be shown if the device control is set
to disable or auto. This is because the user is not allowed to control the settings in
these cases.
Top
The System Devices Menu
Selecting System Devices from the menu bar displays the System Devices Menu.
Please see Figure 2-2.
第 6 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Figure 3-2: The System Devices Menu
This menu allows you to configure the Notebook's PS/2 pointing devices, and serial
and parallel ports options. Each field on this menu is covered below.
PS/2 Pointing Device
This field allows you to select whether the internal pointing device is enabled or
disabled when an external PS/2 mouse is present. Available options for this field are:
are:
Auto-Selected
Both
Auto-Selected mode will automatically disable the internal pointing device if an
external PS/2 mouse is present.
Both will allow both internal pointing device and external PS/2 mouse to be used
simultaneously.
The default value for this field is: Both
Serial Port
This field allows you to configure the Notebook's Serial Port. The following options
are available:
Enabled: configuration set by user
Disabled: no configuration
Auto: BIOS or OS chooses configuration
The default value for this field is: Enabled
第 7 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Changing the default address and IRQ settings for the Serial and Parallel Port can
cause conflicts with other system devices or installed peripherals
Base I/O address
When the Serial Port field is set to Enabled, the "Base I/O address" field becomes
available and you can set the serial port's I/O address. The following I/O options are
available:
3F8
2F8
3E8
2E8
The default value for this field is: 3F8
Interrupt
When the Serial Port field is set to Enabled, the "Interrupt" field becomes available
and you can set the serial port's IRQ value. The following IRQ options are available:
IRQ 4
IRQ 3
The default value for this field is: IRQ 4
Parallel Port
This field allows you to configure the Notebook's Parallel Port. The following options
are available:
Enabled: configuration set by user
Disabled: no configuration
Auto: BIOS or OS chooses configuration
The default value for this field is: Enabled
Changing the default address and IRQ settings for the Serial and Parallel Port can
cause conflicts with other system devices or installed peripherals
Mode
This field allows you to configure the Notebook's Parallel Port transmission mode.
The following options are available:
Normal
Bi-directional
ECP
EPP
EPP and ECP are bi-directional modes, allowing both data input and output. The
第 8 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
EPP and ECP modes are only supported with EPP- and ECP-aware peripherals.
The default value for this field is: ECP Mode
Base I/O address
When the Parallel Port field is set to Enabled, and the mode to Normal, Bi-directional
directional or ECP, the "Base I/O address" field becomes available and you can set
the parallel port's I/O address. The following I/O options are available:
378
278
3BC
The default value for this field is: 378
Interrupt
When the Parallel Port field is set to Enabled, the "Interrupt" field becomes available
and you can set the parallel port's IRQ value. The following IRQ options are
available:
IRQ 7
IRQ 5
The default value for this field is: IRQ 7
DMA Channel
This field is only available when the Parallel Port Mode field is set to ECP. It allows
you to configure the Parallel Port's DMA Channel for ECP mode. The following
options are available:
DMA 1
DMA 3
The default value for this field is: DMA 3
Top
The Security Menu
The Notebook's advanced system of security allows you to set a password to
prevent unauthorized access to system resources, data, and the BIOS Setup
program. This section covers each parameter of the Security Menu. Selecting
Security from the menu bar displays the following menu:
第 9 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Figure 3-3: The Security Menu
Each field of the Security Menu is covered in detail below.
A Note about Passwords
The BIOS Setup program allows you to specify passwords in the Security menu. The
The passwords control access to the BIOS and certain Security menu options during
during system startup.
The passwords are not case sensitive. In other words, a password can be entered
using either upper or lower case letters; it makes no difference.
Passwords should be composed of characters A-Z, 0-9 and not exceed eight
characters in length.
The administrator password controls access to the setup utility. The administrator
password must be set before the user password can be set.
The user password controls access to the system at bootup. The format of the
password is as follows:
User Password Is / Administrator Password Is
This field will show Set when you have set a System Password as described below.
If you have not set the System Password, the field will show Clear. This is a display
only field.
Set User Password… / Set Administrator Password…
This field allows you to set the System Password. The System Password allows full
access to the BIOS Setup menus. To set the administrator password, highlight this
field and press the [Enter] key. The following dialog box appears:
Set Administrator Password
第 10 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Enter New Password [ ]
Confirm New Password [ ]
Type the password and press the [Enter] key. You can type up to eight alphanumeric
alphanumeric characters. Symbols and other keys are ignored. To confirm the
password, type the password again and press the [Enter] key. The System password
password is now set. Note that the "Administrator Password is" field automatically
changes to Set.
To change or clear a password, highlight this field and press the [Enter] key.
The following dialog box appears:
Set Administrator Password
Enter Current Password [ ]
Enter New Password [ ]
Confirm New Password [ ]
Enter the current password, then enter the new password, and finally confirm the
new password. To clear the password, enter the current password, then press the
[Enter] key twice. The password is now cleared and the "System Password is" field is
is automatically set to Clear.
When changing or clearing the password a "Setup Notice" will inform you that
changes have been saved.
Setup Notice
Changes have been saved.
[ continue]
Press the [Enter] key to register your changes.
If the current password entered does not match the actual current password the
following message will appear:
Setup Warning
Invalid password
Re-enter Password
[ continue]
If the new password and confirm new password strings do not match this message
will appear:
Setup Warning
Password do not match
Re-enter Password
Password Required to Boot
When this field is enabled, the system will require the password before the system
can bootup. This option is only available once an administrator password has been
set. The options for this field are:
Enabled
Disabled
第 11 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
The default setting for this field is: Disabled
Top
The Boot Menu
The Boot Menu allows the user to specify the order in which the Notebook is to
check for a device to boot the system. To make changes, select Boot from the menu
menu bar. The following screen appears:
Figure 3-4: The Boot Menu
Boot Sequence
The Boot Menu allows you to alter the priority the system uses to search for the boot
boot device on system power up according to numerical order.
Use the up and down arrow keys [ ] [ ] to select a device, then press:
[F6] to move a device up the list
[F5] to move a device down the list
Press [Esc] to exit the menu.
Top
The Information Menu
The information menu displays static system information. The fields are read only.
第 12 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Figure 3-5: The Information Menu
System Memory
This field displays the amount of conventional memory detected by the system
during bootup. You do not need to make changes to this field. This is a display only
field.
Extended Memory
This field displays the amount of extended memory detected by the system during
bootup. You do not need to make changes to this field. This is a display only field.
Extended Memory size = Total memory size - 1 MB
Top
The Exit Menu
Once you have made all of your selections from the various menus in the Setup
program, you should save your changes and exit Setup. Select Exit from the menu
bar to display the following menu:
第 13 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Figure 3-6: The Exit Menu
Pressing the [Esc] key does not exit this menu. You must select one of the options
from this menu or a menu bar item to exit this menu.
Each of the options on this menu is described below.
Save Changes and Exit
Once you are finished making your selections, choose this option from the Exit Menu
Menu to ensure the values you selected are saved to Non-Volatile RAM. Changes
you made to the Setup program must be changed to Non-Volatile RAM in order to
make them operative. Non-Volatile RAM differs from standard RAM memory in that it
it is sustained by an on-board battery and stays on even when the Notebook is
turned off.
Once your selections have been saved, the Setup program displays the following
message:
Setup Confirmation
Save configuration changes and exit now?
[Yes] [No]
System will reboot if Yes is selected and will stay in Setup if No is selected.
The next time you bootup the Notebook, the BIOS will attempt to load the values you
you saved in Non-Volatile memory. If these values cause the system boot to fail,
reboot and press [F2] to enter the Setup program. Once in Setup, you can try to
change the values that caused the system boot to fail. If the problem persists, load
the default values (see Get Default Values below).
If you attempt to exit the Setup program without saving your changes, the program
will prompt you with a message asking if you want to save your changes before
exiting.
第 14 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Discard Changes and Exit
This option should only be used if you do not want to save the changes you have
made to the Setup program. The default is set to No. If you have made changes to
the fields other than system date, system time and password, the system will ask for
for confirmation when choosing Exit Discarding Changes.
Warning
Configuration has not been saved!
Save before exiting?
[Yes] [No]
The system will reboot after either selection.
Get Default Values
This option allows you to load the default values for each of the parameters on the
Setup Menus. When this option is selected, the following message is displayed:
Setup Confirmation
Load default configuration now?
[Yes] [No]
The system will remain in Setup after either selection.
You can now select Exit Saving Changes or make other changes before saving the
values to Non-Volatile RAM.
Top
第 15 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Introduction file:///C:/WINDOWS/TEMP/3-1.html
Navigating through the BIOS Setup Program file:///C:/WINDOWS/TEMP/3-2.html
The Main Menu file:///C:/WINDOWS/TEMP/3-3.html
The System Devices Menu file:///C:/WINDOWS/TEMP/3-4.html
The Security Menu file:///C:/WINDOWS/TEMP/3-5.html
The Boot Menu file:///C:/WINDOWS/TEMP/3-6.html
The Information Menu file:///C:/WINDOWS/TEMP/3-7.html
The Exit Menu file:///C:/WINDOWS/TEMP/3-8.html
Top file:///C:/WINDOWS/TEMP/Chapter%203.html
Accessing the BIOS Setup program file:///C:/WINDOWS/TEMP/3-2-1.html
Launching submenus file:///C:/WINDOWS/TEMP/3-2-2.html
General Help file:///C:/WINDOWS/TEMP/3-2-3.html
Saving Changes and Exiting the Setup Progr
Program file:///C:/WINDOWS/TEMP/3-2-4.html
捷徑文字 Internet 網址
第 16 頁，共 16 頁The BIOS Setup Program
2003/6/10
file://C:\WINDOWS\TEMP\~hh98BD.htm
Expanding Memory
Memory
Memory
Installing a Memory Module
Removing a Memory Module
Your notebook has 128MB/256MB/512MB DDR-266 installed. You can
extend the memory up to 1GB. The available memory modules are
128MB, 256MB and 512MB.
Read through the information below carefully before you begin. If you
don't feel completely confident installing a memory module yourself,
contact your notebook dealer.
For problems with memory, see Chapter 7, Troubleshooting.
Avoid touching the connectors on the memory module or your
notebook. Grease or dirt on the connectors can cause memory access
problems.
Static electricity can damage the memory module. Before you handle
the module, touch a grounded metal surface to discharge any static
electricity you may have.
Before purchasing new memory for your notebook, check with your
computer dealer for recommended memory modules.
Installing a Memory Module
Removing a Memory Module
Top
Installing a Memory Module
If you are adding a memory module after you have started to use the
computer, begin at step 1. Otherwise, skip to step 3.
1. If the computer is on, click Start.
2. In the Shut Down Windows dialog box, select Shut Down -> OK.
3. Remove all cables connected to the computer.
第 1 頁，共 4 頁Expanding Memory
2003/6/10
file://C:\WINDOWS\TEMP\~hhC8CC.htm
4. Close the display panel and turn the computer upside down.
5. Remove the battery.
6. Remove the screw securing the memory module cover, then remove the
the cover.
7. Hold the memory module by its edges at 45 degrees, so that the
goldfinger connector bar fits into the rear slot, then push and press the
module gently into the socket.
8. Position the memory module cover on the computer and secure it with
the screw.
9. Turn your notebook right side up.
10. Reconnect any cables you disconnected.
11. Turn on your notebook and verify that it correctly recognizes the amount
amount of memory currently installed in the computer
Top
Removing a Memory Module
1. If the computer is on, click Start.
2. In the Shut Down Windows dialog box, select Shut Down -> OK.
3. Remove all cables connected to the computer.
4. Close the display panel and turn the computer upside down.
5. Remove the battery.
6. Remove the screw securing the memory module cover, then remove the
the cover.
7. Release the memory module by gently pushing the latches on both
sides of the memory socket outward. The module will then pop up.
第 2 頁，共 4 頁Expanding Memory
2003/6/10
file://C:\WINDOWS\TEMP\~hhC8CC.htm
8. Remove the memory module.
9. Position the memory module cover and secure it with the screw.
10. Turn your notebook right side up.
11. Reconnect any cables you disconnected.
12. Turn on your notebook and verify that it correctly recognizes the amount
amount of memory installed.
Top
第 3 頁，共 4 頁Expanding Memory
2003/6/10
file://C:\WINDOWS\TEMP\~hhC8CC.htm
Memory file:///C:/WINDOWS/TEMP/4-1.htm
Installing a Memory Module file:///C:/WINDOWS/TEMP/4-1-1.html
Removing a Memory Module file:///C:/WINDOWS/TEMP/4-1-2.html
Top file:///C:/WINDOWS/TEMP/Chapter%204%20.ht
20.htm
捷徑文字 Internet 網址
第 4 頁，共 4 頁Expanding Memory
2003/6/10
file://C:\WINDOWS\TEMP\~hhC8CC.htm
Caring For Your Notebook
Caring For Your Notebook
Traveling
Caring For Your Notebook
Never spray cleaning products directly onto your notebook's case or
display. Only use products designed for cleaning computer displays.
Cleaning Your Notebook and Keyboard
Cleaning the Display
Cleaning the Touch Pad
Cleaning the Diskette Drive
Cleaning the CD/DVD Drive
Precautions
Top
Cleaning Your Notebook and Keyboards
Shut your notebook down, turn it off and disconnect it from the electrical
electrical outlet and any external devices, such as a printer.
1. Remove batteries.
2. Using the brush attachment of your vacuum cleaner, gently remove dust
dust from your notebook's openings and keyboard.
3. Using a slightly moistened soft, lint-free cloth, wipe your notebook and
第 1 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
keyboard. Use only water or a recommended computer cleaner.
Top
Cleaning the Display
1. Shut your notebook down, turn it off and disconnect it from the electrical
electrical outlet and any external devices, such as a printer.
2. Remove batteries.
3. Using a slightly moistened soft, lint-free cloth, wipe your notebook's
display. Use only water or a recommended computer cleaner.
Top
Cleaning the Touch Pad
1. Shut your notebook down, turn it off and disconnect from the electrical
outlet and any external devices, such as a printer.
2. Remove batteries.
3. Using a slightly moistened soft, lint-free cloth, carefully wipe the touch
pad, being careful not to allow any moisture into the gaps. Use only
water or a recommended computer cleaner.
Top
Cleaning the Diskette Drive
Use only commercial cleaning kits to clean your diskette drive.
Top
Cleaning the CD/DVD Drive
Never touch the lens. Use only compressed air to clean the lens.
If you experience problems playing CDs or DVDs, including skipping,
clean the unlabelled side of the disc with a soft, lint-free cloth or using a
a commercial product.
Top
第 2 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
Precautions
Don't spill liquids on the keyboard. If liquid is spilt on the keyboard, turn
your notebook off immediately. Leave off overnight to let it completely
dry out before using it again.
Don't turn off your notebook if a drive light indicates a drive is active.
Turning off your notebook while it is reading from or writing to a disk
may damage the disk, the drive, or both.
Keep your notebook and disks away from objects that generate strong
magnetic fields, such as stereo speakers. Information on disks is stored
magnetically. Placing a magnet too close to a disk can erase important
files.
Scan all new files for viruses. This precaution is especially important for
files you receive via email, disk or download from the Internet. You will
need a special program to scan for viruses. For further information, talk
to your computer dealer.
Top
Traveling
Identifying Your Notebook
Packing Your Notebook
Setting a Password
Travel Tips
If Your Notebook Is Lost or Stolen
Top
Identifying Your Notebook
Attach a name tag or business card to your notebook, or use a
permanent marker or stencil to write a unique identifying mark (such as
your driver's license number) on the case.
Write down your service tag sequence and store it in a safe place away
from the notebook or carrying case. Use the service tag sequence if you
you need to report a loss or theft to law enforcement officials.
Create a file on the Desktop called if found. Place information such as
your name, address, and telephone number in this file.
Contact your credit card company, and ask if it offers coded
identification tags.
第 3 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
Top
Packing Your Notebook
Remove any external devices attached to the computer and store them
in a safe place. Remove any cables attached to installed PC Cards, and
and remove any extended PC Cards.
Fully charge the main battery and any spare batteries you plan to carry
with you.
Turn off the computer or put the computer into hibernate mode.
Disconnect the AC adapter.
Remove any extraneous items, such as paper clips, pens, and paper,
from the keyboard and then close the display.
Pack your notebook and accessories in their carrycase.
Avoid packing the computer with items such as shaving cream,
colognes, perfumes, or food.
Protect the computer, the batteries, and the hard drive from hazards
such as extreme temperatures and dirt, dust, liquids, or overexposure to
to sunlight.
Pack the computer so that it does not slide around in the trunk of your
car or in an overhead storage compartment.
When traveling by air, never check your notebook as baggage.
Top
Setting a Password
To provide extra protection for your data and documents, it is advisable
to set a password.
As your notebook is booting (starting up), press F2 to take you to the
BIOS Setup Utility. Use the right arrow key to highlight Security.
Use the down arrow key to select: Set Supervisor Password…
[Enter]. Press Enter.
Type your password, press Enter and re-type to confirm. Press Enter.
Your changes will be saved. Press Enter to continue.
To enable password protection, use the down key to select Password
Required to Boot. Press Enter. To turn on password protection, use
the down key to select Enabled; to turn password protection off, select
Disabled. Press Enter.
Use the right arrow key to select Exit. Your notebook will now boot as
normal.
Top
Travel Tips
If you are traveling internationally, carry proof of ownership-or of your
第 4 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
right to use the computer if it is company-owned-to speed your passage
passage through customs. Investigate the customs regulations of the
countries you plan to visit and consider acquiring an international carnet
carnet (also known as a merchandise passport) from your government.
Ensure that you know which electrical outlets are used in the countries
you will visit, and have appropriate power adapters.
Check with your credit card company for information about the kinds of
emergency travel assistance it offers to users of portable computers.
When traveling by air, ensure that you have a charged battery available
available in case you are asked to turn on the computer.
Before you use the computer on an airplane, verify that such usage is
permitted. Some airlines forbid the use of electronic devices during the
flight. All airlines forbid the use of electronic devices during takeoff and
landing.
Never walk your notebook through a metal detector. Send it through an
X-ray machine, or have it manually inspected.
Top
If Your Notebook Is Lost or Stolen
Call a law enforcement agency to report your notebook lost or stolen.
Include the service tag sequence in your description of the notebook.
Ask that a case number be assigned and write down the number, along
with the name, address, and telephone number of the law enforcement
agency. If possible, obtain the name of the investigating officer.
If the notebook belongs to a company, notify the security office of the
firm.
Top
第 5 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
Caring For Your Notebook file:///C:/WINDOWS/TEMP/5-1.htm
Traveling file:///C:/WINDOWS/TEMP/5-2.htm
Cleaning Your Notebook and Keybo
Keyboard file:///C:/WINDOWS/TEMP/5-1-1.htm
Cleaning the Display file:///C:/WINDOWS/TEMP/5-1-2.htm
Cleaning the Touch Pad file:///C:/WINDOWS/TEMP/5-1-3.htm
Cleaning the Diskette Drive file:///C:/WINDOWS/TEMP/5-1-4.htm
Cleaning the CD/DVD Drive file:///C:/WINDOWS/TEMP/5-1-5.htm
Precautions file:///C:/WINDOWS/TEMP/5-1-6.htm
Top file:///C:/WINDOWS/TEMP/Chapter%205.h
205.htm
Identifying Your Notebook file:///C:/WINDOWS/TEMP/5-2-1.htm
Packing Your Notebook file:///C:/WINDOWS/TEMP/5-2-2.htm
Setting a Password file:///C:/WINDOWS/TEMP/5-2-3.htm
Travel Tips file:///C:/WINDOWS/TEMP/5-2-4.htm
If Your Notebook Is Lost or Stolen file:///C:/WINDOWS/TEMP/5-2-5.htm
捷徑文字 Internet 網址
第 6 頁，共 6 頁Caring For Your Notebook
2003/6/10
file://C:\WINDOWS\TEMP\~hhFD60.htm
Peripherals
PC Cards
Printers
PC Cards
PC Card Types
Extended PC Cards
Installing a PC Card
Removing a PC Card
Top
PC Card Types
The PC Card slot supports two Type II or one Type III cards. The PC
Card slot supports CardBus technology and extended PC Cards. "Type"
"Type" refers to the card's thickness, not what it does.
A PC Card is not a bootable device.
Top
Extended PC Cards
An extended PC Card is longer than a standard PC Card. When using
extended PC Cards, follow these precautions:
第 1 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
Protect the exposed end of an installed card. If the end of the card is
struck, the system board may be damaged.
Always remove an extended PC Card before packing your notebook in
its carry case.
Top
Installing PC Cards
PC Cards may be 'hot-swapped', which means you can install a card
while your notebook is running. The card will be detected automatically.
Usually PC Cards have a mark or symbol to show which end to insert
into the slot. Cards are keyed to prevent incorrect insertion. Check the
documents that came with your card if the orientation is unclear.
1. Hold the card with its orientation symbol pointing into the slot and the
top side of the card facing up. The push-button latch may need to be in
before inserting the card.
2. Slide the card into the slot until it clicks into the connector.
3. If you encounter too much resistance, do not force the card. Check the
card orientation and try again.
Your notebook will recognize most PC Cards and automatically load the
the appropriate device driver. If the configuration program tells you to
第 2 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
load the manufacturer's drivers, use the floppy disk or CD that came
with the PC Card.
Top
Removing PC Cards
Before removing a PC Card, stop it running from the configuration utility
utility on the taskbar. Failure to do so could result in data loss. Never try
try to remove a PC Card by pulling on its cable, if one is attached.
第 3 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
1. Press the release latch.
2. Press the latch again to eject the card.
3. Remove the card.
Top
Printers
Check the printer documentation to check your printer has a parallel
interface. If the printer can be switched between both, choose parallel
as it is faster.
If your printer did not come with a suitable printer cable, you can
purchase one from a computer or electronics store.
These instructions are for a parallel printer, the most common type of
interface.
1. Turn off your notebook.
2. Connect the printer cable to the printer and to your notebook's parallel
port.
3. Plug the printer's power cable into an electrical outlet.
For further steps, refer to the documentation that came with your printer.
printer.
If you started your computer with a printer connected and turned on, it
may have been detected automatically (Plug and Play). If not, then you
may have to install the printer driver for your printer, either using the
instructions provided with your printer, or in Windows XP via Start ->
Control Panel -> Pick a Category… -> Printers or Other Hardware -
> Pick a task… -> Add a Printer -> Add Printer Wizard or in the
Control Panel Classic Interface, Printers and Faxes -> Add a Printer -
> Add Printer Wizard.
The Add Printer Wizard interface will take you through the steps to
connect your notebook and printer.
Top
第 4 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
第 5 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
PC Cards file:///C:/WINDOWS/TEMP/6-1.htm
Printers file:///C:/WINDOWS/TEMP/6-2.htm
PC Card Types file:///C:/WINDOWS/TEMP/6-1-1.htm
Extended PC Cards file:///C:/WINDOWS/TEMP/6-1-2.htm
Installing a PC Card file:///C:/WINDOWS/TEMP/6-1-3.htm
Removing a PC Card
Card file:///C:/WINDOWS/TEMP/6-1-4.htm
Top file:///C:/WINDOWS/TEMP/Chapter%206.h
206.htm
捷徑文字 Internet 網址
第 6 頁，共 6 頁Peripherals
2003/6/10
file://C:\WINDOWS\TEMP\~hh81E2.htm
Driver Installation
This chapter covers the installation of device drivers in the Windows XP
environment. The step-by-step instructions provided in this chapter will
help you install and configure the following drivers:
1. Video Adapter
2. Sound Controller
3. Network Adapter
4. PCMCIA Controller
5. Mouse (Touchpad)
6. Modem
7. Combo (Modem + Wireless Network (IEEE 802.11b) Adapter)
You can also perform a BIOS Update from the driver CD.
Insert the driver CD into the CD-ROM drive. The Driver Installation
Guide will appear automatically. Follow the instructions in the Guide, or
those below, to install the driver you want.
Video Adapter
Sound (Audio) Adapter
Network Adapter
PCMCIA Controller - Cardbus Controller
PCMCIA Controller - ATA Patch
Mouse (Touchpad)
Modem (for modem-only mini-PCI card equipped CY-25)
Combo (Modem + Wireless Network (IEEE 802.11b) Adapter) (for
combo mini-PCI card equipped CY-25)
BIOS Update
Video Adapter
1. Click the link in the Driver Installation Guide. The following dialog box
will appear.
第 1 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
2. Click Open.
3. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
4. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
Sound (Audio) Adapter
1. Click the link in the Driver Installation Guide. The following dialog box
will appear.
2. Click Open.
3. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
第 2 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
4. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
Network Adapter
1. Open "System Properties" by right clicking "My Computer" and choosing
choosing "Properties".
2. Open the "Hardware" tab.
3. Click "Device Manager".
4. Open the "Network adapters" catalogue.
5. Right click "Realtek RTL8139 Family PCI Fast Ethernet NIC" and select
"Update Driver..."
6. Select "Install from a list or specific location (Advanced)" and click
"Next".
第 3 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
7. Uncheck "Search removable media (floppy, CD-ROM...) and check
"Include this location in the search:". Then click "Next".
8. Click "Finish" when prompted to complete the installation
第 4 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
Top
PCMCIA Controller - Cardbus Controller
1. Click the link in the Driver Installation Guide for the CardBus Controller.
The following dialog box will appear.
2. Click Open.
3. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
4. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
PCMCIA Controller - ATA Patch
1. Users will receive the following window when clicking the link from
Driver Installation Guide:
第 5 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
2. Double click ENECBPTH.EXE (not the one marked as "System file") to
setup. Users will be receiving a dialog (listed as below). Click "OK" to
restart computer and the installation is end then.
Top
Mouse (Touchpad)
3. Click the link in the Driver Installation Guide for the Mouse (Touchpad)
Controller. The following dialog box will appear.
第 6 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
4. Click Open.
5. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
6. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
Modem (for modem-only mini-PCI card equippe
equipped CY-25)
1. Click the link in the Driver Installation Guide for the Modem (Touchpad)
Controller. The following dialog box will appear.
2. Click Open.
3. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
4. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
Combo (Modem + Wireless Network (IEEE
802.11b) Adapter) (for combo mini-PCI card equipped
CY-25)
1. Click the link in the Driver Installation Guide for the Mouse Combo
第 7 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
Controller. The following dialog box will appear.
2. Click Open.
3. The setup program will launch. Follow the screen-by-screen instructions
instructions to install the driver.
4. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new driver properly installed.
Top
BIOS Update
1. Insert a bootable floppy diskette into the FDD.
2. Click on the Start menu and select Windows Explorer.
3. Select "My Computer".
4. Open the Bios folder on the CD-ROM.
5. Select each of the files in the BIOS folder. Right click Send To and then
then choose 3½ Floppy.
6. Boot laptop computer from the floppy diskette mentioned in Step 1.
7. Make sure the AC adapter is connected and run the CBIOS rom_file
from the DOS prompt.
8. The program will start to update BIOS and reboot automatically.
9. Press F2 to enter BIOS Setup Menu then press F9 to load default
settings of factory. Press F10 to save settings and exit.
If, for some reason, you cannot access the Driver Installation Guide,
you can also launch any of the setup programs in the following way:
第 8 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
1. Make sure the driver CD is in the CD-ROM drive.
2. Click the Start button on the Windows desktop, then select Run…
3. Either: Use Browse to locate the setup file for the driver you want. The
The setup files for each driver are stored in the driver's separate
directory on the disk. Assuming the CD-ROM Drive letter is "D", the
setup file locations are:
D:\Audio\Setup.exe
D:\Combo\Setup.exe
D:\Modem\WinXP\Setup.exe
D:\PCMCIA\Cardbus\Setup.exe
D:\PCMCIA\ATAPatch\enecbpth.exe
D:\Touchpad\Setup.exe
D:\Video\Setup.exe
Or: Type in the setup file location.
4. Now click OK. The setup program will launch. Follow the screen-by-
screen instructions to install the driver.
5. When prompted, select "Yes, I want to restart my computer now." Click
Finish to complete the installation. Your computer will restart with the
new video driver properly installed.
Top
第 9 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
Video Adapter file:///C:/WINDOWS/TEMP/7-1.htm
Sound (Audio) Adapter file:///C:/WINDOWS/TEMP/7-2.htm
Network Adapter file:///C:/WINDOWS/TEMP/7-3.htm
PCMCIA Controller - Cardbus Controller file:///C:/WINDOWS/TEMP/7-4.htm
PCMCIA Controller - ATA Patch file:///C:/WINDOWS/TEMP/7-5.htm
Mouse (Touchpad) file:///C:/WINDOWS/TEMP/7-6.htm
Modem (for modem-only mini-PCI card equipped CY
CY-25) file:///C:/WINDOWS/TEMP/7-7.htm
Combo (Modem + Wireless Network (IEEE 802.11b)
Adapter) (for combo mini-PCI card equipped CY-25) file:///C:/WINDOWS/TEMP/7-8.htm
BIOS Update file:///C:/WINDOWS/TEMP/7-9.htm
Top file:///C:/WINDOWS/TEMP/Chapter%
207.htm
捷徑文字 Internet 網址
第 10 頁，共 10 頁Driver Installation
2003/6/10
file://C:\WINDOWS\TEMP\~hhD724.htm
The Power System
Power Management
Battery
Power Management
Managing Your Notebook's Power
Power Management Modes
Power Options Properties
SpeedStep
Top
Managing Your Notebook's Power
See Battery for more information on getting the best performance from
battery packs.
Use your notebook connected to an electrical outlet as often as
possible, as battery life expectancy is affected by the number of times it
it is charged.
When leaving your notebook unattended for long periods, place it in
standby or hibernate mode. You can exit either power management
mode by pressing the power button.
Top
Power Management Modes
Standby Mode
Hibernate Mode
Top
Standby Mode
This mode conserves power by switching off the hard drive and display
第 1 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
after a preset period of inactivity (a time-out). When standby mode is
exited, your notebook will return to the same operating state it was in
before entering standby.
If your notebook loses power from both the electrical outlet and the
battery while in standby mode, data may be lost.
To enter standby mode in Windows XP:
Start -> Turn off computer -> Stand By.
or
You can set your notebook to go to Standby Mode:
When you close the lid of your notebook
When you press the power button
via the Advanced tab settings in Power Options Properties
(accessed via Start -> Control Panel -> Pick a category ->
Performance and Maintenance -> Power Options).
To exit standby mode, press the power button. You can exit standby
mode by pressing a key or touching the touch pad. For more
information on standby mode, see Turning Your Notebook On and Off,
Chapter 2.
Top
Hibernate Mode
In Hibernate mode, power is conserved by system data being copied to
the hard drive, and your notebook completely turning off. When
hibernate mode is exited, your notebook will return to the same
operating state it was in before entering hibernate mode.
Hibernate Mode can be enabled/disabled in the Power Options
Properties window.
If enabled, your notebook will go into hibernate mode if the battery
charge level becomes critically low.
Depending on how you set the Power Management Options on the
Advanced tab in the Power Options Properties window, use one of the
following methods to enter hibernate mode:
When you close the lid of your notebook
When you press the power button
Start -> Turn Off Computer -> Hibernate (if the Hibernate option
does not show, press Shift, and the Standby option will switch to
Hibernate).
If the Hibernate option is not available for these methods, Hibernate
mode has not been enabled. Check the Enable Hibernation box on the
the Hibernate tab of the Power Options Properties window and click
Apply to enable Hibernation.
If your PC Cards do not operate correctly after exiting hibernate mode,
第 2 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
remove and reinsert the card or restart your notebook.
To exit hibernate mode, press the power button. You cannot exit
hibernate mode by pressing a key or touching the touch pad. For more
information on hibernate mode, see Turning Your Notebook On and Off,
Off, Chapter 2.
Top
Power Options Properties
To access the Windows Power Options Properties window:
Start -> Control Panel -> Pick a category -> Performance and
Maintenance -> Power Options
Power Schemes Tab
Alarms Tab
Power Meter Tab
Advanced Tab
Hibernate Tab
Top
Power Schemes Tab
The Power Schemes pull-down menu in the Power Options Properties
displays the selected preset power scheme.
To maximize battery power, use the Portable/Laptop power scheme.
In Windows XP the processor's performance level depends on the
power scheme you select. You do not need to make any further
adjustments to set the performance level. Each preset power scheme
has different time-out settings for entering standby mode, hibernate
mode, turning off the display, and turning off the hard drive. For more
information on power management options, see the Help and Support
Center.
Top
Alarms Tab
Enable audible alarms by clicking each Alarm Action button and
selecting Sound alarm.
The Low battery alarm and Critical battery alarm settings alert you when
when the battery charge falls below a certain percentage.
When you receive your notebook, the Low battery alarm and Critical
battery alarm check boxes are selected. See Battery (Section 6.2) for
more information on low-battery warnings.
Top
Power Meter Tab
第 3 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Displays the current power source, battery status and charge amount.
Top
Advanced Tab
With the Advanced tab you can:
Set power icon and standby mode password options.
Depending on your operating system, program the following
functions by clicking an option from the corresponding pull-down
menu, and then clicking OK.
>Set the computer to Stand by/Hibernate/Do nothing when you
close the laptop lid.
>Set the computer to Ask me what to do/Stand by/Hibernate/Shut
down/Do nothing when you press the power button.
Top
Hibernate Tab
The Hibernate tab lets you enable hibernate mode by clicking the
Enable hibernation check box.
Top
SpeedStep
Your notebook is equipped SpeedStep technology to better manage
power consumption. It changes the processor speed to find the best
balance between your computing performance and power consumption
needs. Higher speeds enjoy better performance, while slower speeds
conserve more power.
In Windows XP, the processor's performance level depends on the
Power Scheme you select (see Power Options Properties, section
6.1.3). You do not need to make any further adjustments to set the
performance level. Each preset power scheme has different time-out
settings for entering standby mode, hibernate mode, turning off the
display, and turning off the hard drive. For example, the
Portable/Laptop mode automatically changes SpeedStep modes
depending on if you are running the computer on AC power or batteries
in order to prolong battery usage while still providing optimal
performance. You can also individually alter and save each of these
settings and schemes if desired.
第 4 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Windows XP automatically chooses the SpeedStep mode to find the
most appropriate speed for your processor according to the Power
Scheme you choose and your current system demands.
Top
Battery
Battery Performance
Checking the Battery Charge
Power Meter
Low-Battery Warning
Charging the Battery
Removing a Battery
Installing a Battery
Storing a Battery
Working With Extra Battery Packs
Maximizing Battery Life
Top
第 5 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Battery Performance
Using a battery lets you work with your notebook without connecting it
to an electrical outlet. Your notebook comes with one 8-cell Li-Ion
battery pack installed, which will give you more than 300
charging/discharging cycles.
The performance of the battery can vary, depending on operating
conditions. Your battery may last less time if you are running power-
intensive programs, playing CDs or DVDs, using PC cards or have high
high display-brightness settings.
The Power Management Options can be set to alert you when the
battery charge is low.
Ensure any battery you use is compatible. Failure to do so may risk fire
or explosion. For more details on purchasing compatible batteries, talk
to your notebook retailer.
Batteries should never be disposed of with household waste. Contact
your local waste disposal or environmental agency for advice on
disposing of used lithium-ion batteries.
Top
Checking the Battery Charge
Battery Status Indicator behavior
Charging blinks green
Fully Charged solid green
Discharging off
Low Battery
(10%) solid amber -> approximately 12 minutes left
Critical Low blinks amber -> approximately 3 minutes left;
system beeps
Top
Power Meter
The power meter indicates the remaining battery charge. When
your notebook is running on battery power, you can check the remaining
remaining battery charge, doubleclick the icon on the taskbar. For more
details, including how to make the icon appear on the taskbar if it is
is not already, see Power Management, section 6.1.
Top
Low-Battery Warning
第 6 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
After a low-battery warning, save your work immediately, then connect
your notebook to an electrical outlet. Hibernate mode will begin
automatically if the battery runs completely out of power.
You will hear the low-battery warning when the battery charge is
approximately 90 percent depleted. Your notebook will beep once,
indicating approximately 10 to 15 minutes of battery operating time
remain. If you do not connect your notebook to alternative power source
source during that time, there will be a periodic beep. Your notebook
will automatically enter hibernate mode if the battery charge reaches a
critically low level. For more information, see Power Management,
section 6.1.
Top
Charging the Battery
When connected to an electrical outlet, a completely discharged battery
battery will charge in 3 to 5 hours (depending on whether your notebook
notebook is on or off and what programs, if any, are running). You can
leave the battery in your notebook as long as you like. The battery's
internal circuitry prevents the battery from overcharging.
Before using the battery for the first time it must be charged. Connect
the computer to an electrical outlet and allow the battery to fully charge,
charge, indicated by the battery indicator light on the front panel of the
notebook.
Once a battery pack is fully charged for the first time, use your notebook
notebook on battery power until the battery discharges completely. This
This will extend battery life, and helps ensure accurate monitoring of
battery capacity.
If necessary, the battery will be charged whenever your notebook is
connected to an electrical outlet.
The battery will not be charged if it or your notebook is too hot, either
from use or being in a hot environment. If this occurs the battery
indicator will light red. Disconnect your notebook from any electrical
outlet, and allow it and the battery to cool to room temperature. You can
can then reconnect your notebook to the electrical outlet and charge the
the battery. The battery indicator will also light red if the battery is bad
bad and needs replacing.
Top
Removing the Battery
Before removing the battery, ensure your notebook is turned off.
1. Unlock the battery by pressing the battery latch lock
2. Slide and hold the battery release latch
3. Remove the battery
第 7 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Top
Installing a Battery
1. Slide the battery into the bay
2. Press it into place gently but firmly until the latch locks it into place
Top
Storing a Battery
If storing your notebook for an extended period of time, remove the
battery. Fully charge the battery before using your notebook again.
Top
Working With Extra Battery Packs
If you spend a lot of time traveling, working without connecting your
notebook to an electrical outlet, it may be a good idea to carry additional
additional battery packs so you can quickly replace a discharged battery
battery and continue working.
Top
Maximizing Battery Life
A battery can be recharged many times, but over time it will lose its ability
to hold a charge. To maximize battery life:
Don't leave your notebook plugged in and unused for more than a few
few hours. Overcharging may shorten battery life.
If you will not be using your notebook for a long period, remove the
battery.
If you have a spare battery pack, alternate the batteries.
Ensure your notebook is off when replacing the battery.
Store spare battery packs in a cool, dry place, out of direct sunlight.
Top
第 8 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Power Management file:///C:/WINDOWS/TEMP/8-1.htm
Battery file:///C:/WINDOWS/TEMP/8-2.htm
Managing Your Notebook's Power file:///C:/WINDOWS/TEMP/8-1-1.html
Power Management Modes file:///C:/WINDOWS/TEMP/8-1-2.html
Power Options Properties file:///C:/WINDOWS/TEMP/8-1-3.html
SpeedStep file:///C:/WINDOWS/TEMP/8-1-4.html
Top file:///C:/WINDOWS/TEMP/Chapter%208.html
Standby Mode file:///C:/WINDOWS/TEMP/8-1-2-1.html
Hibernate Mode file:///C:/WINDOWS/TEMP/8-1-2-2.html
Advanced tab file:///C:/WINDOWS/TEMP/8-1-3-4.html
Power Schemes Tab file:///C:/WINDOWS/TEMP/8-1-3-1.html
Alarms Tab file:///C:/WINDOWS/TEMP/8-1-3-2.html
Power Meter Tab file:///C:/WINDOWS/TEMP/8-1-3-3.html
Hibernate Tab file:///C:/WINDOWS/TEMP/8-1-3-5.html
Battery Performance file:///C:/WINDOWS/TEMP/8-2-1.html
Checking the Battery Charge file:///C:/WINDOWS/TEMP/8-2-2.html
Power Meter file:///C:/WINDOWS/TEMP/8-2-3.html
Low-Battery Warning file:///C:/WINDOWS/TEMP/8-2-4.html
Charging the Battery file:///C:/WINDOWS/TEMP/8-2-5.html
Removing a Battery file:///C:/WINDOWS/TEMP/8-2-6.html
Installing a Battery file:///C:/WINDOWS/TEMP/8-2-7.html
Storing a Battery file:///C:/WINDOWS/TEMP/8-2-8.html
Working With Extra Battery Packs file:///C:/WINDOWS/TEMP/8-2-9.html
Maximizing Battery Life file:///C:/WINDOWS/TEMP/8-2-10.html
捷徑文字 Internet 網址
第 9 頁，共 9 頁The Power System
2003/6/10
file://C:\WINDOWS\TEMP\~hhF1B5.htm
Troubleshooting
Troubleshooting
Finding Additional Help
Troubleshooting
Your Notebook Does Not Respond
A Program Stops Responding
Top
Your Notebook Does Not Respond
If your notebook 'locks' and does not respond to your pressing keys or
touching the touch pad, hold the power button until the notebook turns
off (this may take at least four seconds). Press the power button again
to restart your notebook. Any unsaved data may be lost when your
notebook is not shutdown via Windows.
Top
A Program Stops Responding
Press and hold the Ctrl, Shift, Esc keys or Ctrl, Alt, Delete keys.
When the Windows Task Manager dialog box appears, select the
program that is not responding.
Click the End Task button.
If you need to restart your notebook, you can do so from the Windows
Task Manager window. First close all programs to ensure you do not
lose unsaved work, then click Shut Down to reveal a drop-down menu.
Top
Finding Additional Help
Updates
Microsoft Windows Help
第 1 頁，共 4 頁Troubleshooting
2003/6/10
file://C:\WINDOWS\TEMP\~hhC7A0.htm
Microsoft Windows Guide
Devices and Programs
CD-ROM, DVD, CD-RW or CD-RW/DVD HELP
Top
Updates
Documentation updates may be included with your notebook. These
describe changes to your notebook or software. Always read these
updates before consulting any other documentation, as they contain
the most up-to-date information.
Readme files, which may be installed on your hard drive or found on
CDs, provide last-minute updates about technical changes to your
notebook, or advanced technical material intended for experienced
users or technicians.
Top
Microsoft Windows Help
Click Start -> Help and Support or, if that option is not available, right
click Start -> Search -> Information in Help and Support.
Top
Microsoft Windows Guide
For more information on using the Windows operating system, see the
Microsoft Windows documentation that came with your computer.
Top
Devices and Programs
For help on using your computer's devices (such as a modem) and
options you purchase separately from your notebook, refer to the
accompanying documentation.
Top
CD-ROM, DVD, CD-RW or CD-RW/DVD HELP
Depending on the CD-ROM, DVD, CD-RW or CD-RW/DVD Drive
installed on your computer, you will be supplied with accompanying
software (for example, Easy CD Creator, for writing CDs; WinDVD for
playing movies). Refer to the separate documentation appropriate to
your configuration.
第 2 頁，共 4 頁Troubleshooting
2003/6/10
file://C:\WINDOWS\TEMP\~hhC7A0.htm
Top
第 3 頁，共 4 頁Troubleshooting
2003/6/10
file://C:\WINDOWS\TEMP\~hhC7A0.htm
Troubleshooting file:///C:/WINDOWS/TEMP/9-1.htm
Finding Additional Help file:///C:/WINDOWS/TEMP/9-2.htm
Your Notebook Does Not Respond file:///C:/WINDOWS/TEMP/9-1-1.html
A Program Stops Responding file:///C:/WINDOWS/TEMP/9-1-2.html
Top file:///C:/WINDOWS/TEMP/Chapter%209.h
209.html
Updates file:///C:/WINDOWS/TEMP/9-2-1.html
Microsoft Windows Help file:///C:/WINDOWS/TEMP/9-2-2.html
Microsoft Windows Guide file:///C:/WINDOWS/TEMP/9-2-3.html
Devices and Programs file:///C:/WINDOWS/TEMP/9-2-4.html
CD-ROM, DVD, CD-RW or CD-RW/DVD
HELP file:///C:/WINDOWS/TEMP/9-2-5.html
捷徑文字 Internet 網址
第 4 頁，共 4 頁Troubleshooting
2003/6/10
file://C:\WINDOWS\TEMP\~hhC7A0.htm

Navigation menu
