Contents
Users Manual
1
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink, or
swimming pool).
5. Do not place this product on an unstable cart, stand, or table. The product may fall,
causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation.
To protect it from overheating, these openings must not be blocked by placing the
product on the bed, sofa, rug, or other similar surface. This product should never be
placed near or over a radiator or heat register. This product should not be placed in
a built-in installation where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
the cord will be abused by persons walking on it.
9. Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short out parts that could result in a risk of fire or
electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product. Opening or
removing cabinet parts other than specified access doors may expose you to
dangerous voltages or other risks. Incorrect assembling can cause electric shock
when the appliance is subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of fire
or electric shock.
12. Unplug this product from the wall outlet and contact VTECH under the following
conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operatinginstructions.
Adjust only those controls that are covered by the operating instructions, because
improper adjustment of other controls may result in damage and will often require
extensive work to restore the product to normal operation.
E. If the product has been dropped and the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There
may be a remote risk of electric shock from lightning.
14. Do not use this or any cordless telephone to report a gas leak in the vicinity of the
leak.
Important Safety Instructions
2
VTECH COMMUNICATIONS INC.
CUSTOMER SERVICE : 1-800-595-9511. In Canada, call VTech Electronics Ltd. At 1-800-
267-7377.
BEFORE USING YOUR 2625/2650/5825/5850 SYSTEM, CAREFULLY PEEL OFF THE
PROTECTIVE FILM, COVERING THE DISPLAYS.
SAVE THESE INSTRUCTIONS
3
This is an advanced cordless telephone, capable of supporting 2 Handsets.
This manual is designed to familiarize you with this cordless telephone. We strongly
recommend you read the manual before using your phone.
Introduction
STOP!!
If you have questions about this product, or if you’re having difficulty
with setup or operation, do not return your phone to the store. Call
our Customer Support Center at 1-800-595-9511 In Canada, call 1-800-
267-7377
4
1. Base Unit
2. Handset
3. Handset Charger
4. Base AC Power Adapter
Parts Check List
5. Telephone Line Cord
6. Belt Clip
7. Owner’s Manual
8. Battery Cells
To purchase replacement battery cells, call VTech Communications Inc.
at 1-800-595-9511. In Canada, call VTech Electronics Ltd. at 1-800-267-7377.
Note : Use only VTech batteries P/N 80-5380-00-00 or equivalent AAA NiMH rechargeable
batteries.
Base Unit
Handset
Handset Charger
Base AC Power Adapter
Telephone Line Cord
Belt Clip Owners Manual Battery Cells
5
1. Antenna
2. Volume Control
3. Soft Keys
4 . CID
5. Select (Menu)
6. On (Flash)
7. Dialing Keys (0-9, *, #)
The Handset Layout
8. Redial (Pause)
9. Mute (Delete)
10. Speakerphone
11. LCD Display
12. Headset jack (2.5mm)
13. Phonebook
14. Off (Clear)
15. Intercom
1
2
5
4
6
7
8
9
10
11
12
13
14
15
3
6
1. In Use LED
2. Charging LED
3. Message Waiting LED
4. Page key
The Base Unit Layout
2
41
3
7
MODEL: 2625
VTECH TELECOMMUNICATIONS LTD.
MANUFACTURED IN CHINA
CORDLESS TELEPHONE
VTECH TELECOMMUNICATIONS LTD.
DC 9V 300mA
CLASS 2 POWER SOURCE ONLY
COMPLIES WITH 47 CFR PART 68
REGISTRATION NO.: US: EW7WI01B80-531200
RINGER EQUIVALENCE: XXB USOC JACK: RJ11CW
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE;
AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED,INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION PRIVACY OF COMMUNICATIONS
MAY NOT BE ENSURED WHEN USING THIS PHONE
TEL. LINE
DC 9V
HAC
FCC ID: EW780-5312-00
VTech Customer Service 1-800-595-9511
www.vtechphones.com
To AC outlet
CORDLESS TELEPHONE
VTECH TELECOMMUNICATIONS LTD.
DC 9V 150mA
CLASS 2 POWER SOURCE ONLY
To AC outlet
Connecting power to Base Unit/Handset Charger
1. Plug the AC power adapter into an electrical outlet, and the DC connector into the
bottom of the Base Unit.
2. Choose the location for your Handset Charger, and plug its power supply into an
electrical outlet.
Setup
Getting Started
Installation of Battery Cells in Handset
Follow the steps below:
1. Remove the battery cover by pressing on the indent and sliding downward.
2. Place the new battery cells in the Handset with the positive and negative poles aligned
in the battery compartment.
3. Replace the battery cover by sliding it upwards.
4. If the new battery cells are not already charged, place the Handset in its Charger, and
allow it tocharge for 12 hours. After initial charge, a maintenance charge of 8 hours
should be sufficient.
12
3
4
8
Charging of the Handset Battery Cells
The Handset of your cordless telephone is powered by rechargeable battery cells. It
charges automatically whenever the Handset is in its charger.
You should charge the battery pack for 12 hours when you first receive your
phone. You’ll know the battery pack needs charging when:
• The low battery message is displayed :
• The Handset seems completely dead,
theLCD is completely clear and does not
activatewhen you press the keys.
IMPORTANT:
1. Do not dispose of battery cell in a fire, the cell may explode.
2. Do not open or mutilate the battery cell. Toxic substances may be released, causing
harm to eyes or skin.
3. Exercise care in handling battery cell in order to prevent an accidental short of the
charge contacts, potentially causing the battery pack to overheat.
4. Do not dispose of this battery cell into household garbage. Please refer to the
information concerning proper battery recycling.
5. Do not charge the battery cell with other electrical device.
Connecting to phone line
Plug one end of the telephone line cord into the jack on the back of the Base Unit. Plug
the other end of this cord into the wall jack.
Checking for dial tone
After the battery is charged, press ON on the Handset. The Phone icon will appear on
the Handset display, and you will hear dial tone. If not, see In Case of Difficulty.
Tone/Pulse selection
Your phone is preset for tone dialing. See BASE SETTINGS for details.
CAUTION: Use only the VTech power supply provided with your telephone.
IMPORTANT:
FOR MAXIMUM PERFORMANCE OF YOURCORDLESS TELEPHONE SYSTEM:
1. Choose a central location for your Base Unit.
2. Install your Base Unit and Extension Handsets way from electronic equipment, such
as personal computers, television sets and microwave ovens.
3. In locations where there are multiple cordless telephones, separate base units as
much as possible.
4. Install your telephone equipment away from heat sources and sunlight.
5. Avoid excessive moisture, dust or extreme cold.
Setup
Getting Started
9
Handset Icons
Icon Description
Handset LEDs
LED Description
Base Unit Icons
Icon Description
Base LEDs
LED Description
Basic Operation
Handset and Base Indicators
10
Making Calls
• Press ON (or, SPEAKERPHONE to use the Handset Speakerphone feature). Dial the
phone number. -OR-
• Dial the phone number first; then press ON (or SPEAKERPHONE).
• Press OFF to end your call
Answering Calls
From the Handset
• Press any key except OFF and the softkeys.
• Press OFF to end your call.
Intercom Call
Pressing INT key when the handset is idle initiates an intercom call.
- Press INT
The call is performed and when the other handset answers, the display will change to:
If the other handset is out of range, turned off or on an external call, the display will show
and a busy tone will be heard on the earpiece, or through the speaker if in handsfree mode.
An intercom call is terminated by:
- Pressing OFF or INT,
- Placing the handset in the charger
After terminating an INTERCOM CALL, the display on both handsets will show:
On the handset that did not terminate the call, a busy tone will be heard, indicating the
other handset has ended the call. After several seconds the display will return to idle
and the busy tone will stop.
Handset Operation
INTERCOM
OTHER HANDSET
UNABLE TO CALL
AT THIS TIME
INTERCOM END
CALLING
OTHER HANDSET
Basic Operation
11
The handsets share a common phone book, which is stored in the base station. This means
that entries inserted by one handset are available for both handsets, and if one deletes
a phone book entry, it will disappear from both handsets.
The phone book size will hold 50 entries, with names of a maximum length of 16 characters
and a 32-digit maximum phone number.
The phone book entries are sorted and presented to the user in alphabetical order.
Names are entered using the numerical keys. Multiple key presses of the dialing digit keys
is used to generate characters, see the table below. The cursor moves to the next position
if another numerical key is pressed or by pressing the key. The last entered character
is deleted by pressing DELETE or . The entire name is cleared by holding down DELETE.
Phone Book Operation
Characters by number of key presses
Key
123456789
space 1
ABC2 ab c
DEF 3 d e f
GHI 4 g h i
JKL5j kl
MN O6 mn o
PQRS7p q r s
TUV8t u v
WXYZ9wxyz
0
*?!/()
#' , - . &
1
2
3
4
5
6
7
8
9
0
*
#
The phone book is entered via the menu, as described below or by pressing the /\ key
in idle (quick access key) whereby the handset jumps directly to the phone book search
menu.
The phone book is accessed as follows:
1) Press SEL, to enter the menu.
2) SEL, to enter the Phone book sub-menu.
>PHONE BOOK
CALL L06
>REVIEW
STORE
Basic Operation
12
Storing a new entry
1) Press the key in idle, or scroll through the sub-menu with the and keys
and press SEL with “STORE” in the first line.
2) If the phone book is full the screen will show,
3) If the phone book is not full, the user will be prompted to enter the phone number to
be stored as shown below:
4) Enter the number, up to 32 digits. Press DELETE to backspace.
In cases the number exceeds 16 digits, the top line will be used to show the entire
number.
5) Press SEL to confirm the number. If there is duplicate number in the phone book, the
screen will show:
and the Handset will return to the ‘STORE NUMBER’ screen. If the number is unique,
you will move to the name entry screen,
6) Enter the associated name. Use 1 to add a space and DELETE to backspace.
>STORE
REVIEW
PHONE BOOK
IS FULL!
STORE NUMBER
_
STORE NUMBER
123_3457_
1234
567890121234567_
NUMBER ALREADY
IN PHONE BOOK!
STORE NAME
_
STORE NAME
John Smith_
Phone Book Operation
Basic Operation
13
7) Press SEL to confirm the name. A name must be entered, or you cannot proceed to
the next step. Unlike phone numbers, duplicate names are allowed. The new record
will be stored in the phone book.
The user can press CLEAR to return to the phone book operation screen, which will
show the last operation:
Dialing from the phone book
A number can be recalled and dialed from the phone book by:
1) Press the key in idle, or scroll through the menu with the & keys and press
SEL with “REVIEW” in the first line. The first phone book entry will be shown.
2) Scroll through the phone book entries using and keys or enter first character
of the name to be searched (using the dial digit keys) and continue navigating using
the or as scroll keys, until you reach the entry to be dialed.
3) Press ON or SPK, to dial the number.
Editing a phone book entry
1) Press the key in idle, or scroll through the menu with the & keys and press
SEL with “REVIEW” in the first line.
John Smith
<*7890121234567
>STORE
REVIEW
Kevin James
432-5434
John Smith
555-1212
ACTIVE 00:00:10
555-1212
Kevin James
432-5434
Phone Book Operation
Basic Operation
14
2) Scroll through the phone book entries using and keys or enter first character
of the name to be searched (using the dialing keys) and continue navigating using
the or as scroll keys, until you reach the entry to be edited.
3) Press SEL to enter number edit mode
4) Edit the number as required, using the following options:
When editing or storing a number, you may do any of the following:
• Enter a digit by pressing 0-9,
• Enter a pause by holding REDIAL,
• Delete a digit by pressing DELETE,
• Delete the entire string by holding DELETE,
• Position the cursor to another location by pressing or ,
• Insert a number from the redial list by pressing REDIAL.
5) Press SEL to confirm the number and enter name edit mode.
6) Edit the name as required, using the following options:
• Enter characters using the keys 0-9, * and # (See the key/characters table),
• Press DELETE to delete the character under the cursor, or to the left if at the end of
the string.
• Hold DELETE to delete the entire string,
• Press and to position move to another character
7) Press SEL to confirm change.
John Smith
555-1212
EDIT NUMBER
123-4567_
EDIT NAME
John Smith_
John Smith
555-1212
Phone Book Operation
Basic Operation
15
Delete a phone book entry
1) Press the key in idle, or scroll through the sub-menu with the & keys and
press SEL with “REVIEW” in the first line.
2) Scroll through the phone book entries using and keys or enter first character
of the name to be searched (using the dial digit keys) and continue navigating using
the or as scroll keys, until you reach the entry to be removed.
3) Press DELETE to delete the entry. The phone returns to the previous entry, or the
next entry if the first entry was the entry that was deleted.
Additional note on long phone numbers.
When reviewing the phone book the second line of the display will display phone number
up to 16 digits. For numbers larger than 16 digits only the last 13 digits will be displayed,
as shown in the following example:
The “<*” indicates there are additional digits to the left, and the * key can be pressed to
scroll the display over to see them.
“<“ and “>” indicate additional digits of the left or right side respectively, and the keys
“*” or “#” can be used to scroll the phone number to see the additional digits,
Kevin James
432-5434
John Smith
555-1212
Kevin James
432-5434
John Smith
<* 1234567890123
John Smith
<* 7890123456 #>
Phone Book Operation
Basic Operation
16
All incoming calls with valid caller ID number are stored in a call log. Name and time/date
information is also stored in the call log if the central office sends it out.
The number of entries stored in the call log is indicated in idle mode:
The number of unanswered calls (new), if any, is indicated:
The new call indication is removed when all calls in the call log have been reviewed. The
NEW icon indicates, in all screens, that there are new calls log entries that have not been
reviewed. The call log is entered via the menu, as described below or by pressing the
key in idle (quick access key) whereby the handset jumps directly to the call log review.
The call log is reviewed as follows:
1) Press SEL, to enter the menu.
2) Press to get to the call log option
3) SEL, to enter the CALL LOG menu.
4) The caller name is shown in the first line of the display, and the number in the second
line. If time and date information is contained in the CID and there are three lines in
the display, it is shown in the third line.
The name contained in the received CID is replaced by the name in the phone book, if the
phone book contains a matching number, i.e. the phone book name takes precedence.
5) Scroll through the Call Log entries using and keys.
The following actions are possible from the Call Log:
• Dialing the caller displayed by pressing the ON or SPK keys.
• Deleting the caller displayed by pressing the DELETE key. The phone returns to call
log review.
Calls Log (Caller ID – Call Waiting)
VTECH
5 NEW CALLS
_
VTECH
23 CALLS/5 NEW
_
>PHONE BOOK
CALL L06
>CALL LOG
QUICK DIAL
John smith
123-4567
2/2311:59
A Person
555-1212
2/2311:57
Basic Operation
17
• Deleting all entries in the call log by pressing and holding DELETE. After this, you will
be asked for confirmation by either accepting the deletion with SEL (= yes) or
canceling it with OFF (= no).
If you press SEL, all entries in the call log will be deleted and the handset indicates the
call log is
empty and then returns to the idle state. If you select OFF, the phone returns to the last
viewed entry.
• Storing the caller displayed in the phone book by pressing the SEL key. If the call log
entry has a name and a number it will be added to the phone book and the screen
will show:
before returning the call log entry.
If the phone number already exists in the
phone book, the entry will not be stored,
and the screen will show:
If there is no room in the phone book for the
new entry, the display will show:
DELETE CALL
CALL LOG?
ADDED TO
PHONE BOOK
NUMBER ALREADY
IN PHONE BOOK!
PHONE BOOK
IS FULL!
If the call log entry is missing a name or number, you will be prompted to enter one before
the item is stored in the phone book.
If both a name and number is missing, for example as in a private listing, the request will
be rejected with the message:
• Exit the Call Log review by pressing the OFF key.
• ‘!’-character in the right hand side of the first line indicates that the call has not
previously been reviewed. The ‘!’-character is cleared when stepping to the next
entry in the log or when leaving the call log.
• The maximum length of the name shown in the first line is 16 characters. If the name
as received is longer, only the first 16 characters will be seen.
• The incoming calls are sorted by the order of arrival; the latest is shown first. Calls
from the same number will each have separate call log entries.
If the call log is full, the oldest entry is deleted to make room for the new call. If the call
log is empty when the user tries to enter to Call log review, a message the following
message is displayed:
It is possible to change the number format in the call log before storing the name/number
in the phone book or dialing the caller. Pressing the ‘#’ key will toggle the number format.
The available number formats depend on the number of digits received number.
>PHONE BOOK
CALL L06
Calls Log (Caller ID – Call Waiting)
Basic Operation
18
Up to 10 ‘quick dial ‘numbers may be entered into each handset. It is possible to ‘quick
dial’ numbers with just a single key press.
The quick dial list in each handset is unique to that handset and is not shared with the
other handset.
Entering a Quick Dial number
1) Press SEL when the handset is idle to enter the menu system
2) Move down to the quick dial option by pressing the key,
3) Then press SEL to enter the quick dial sub menu.
4) Select a quick dial key location using the 0-9 keys. If that location is empty the screen
will show,
where ‘x’ is the location that was selected (0-9). At this point pressing OFF will return
you to the quick dial select screen as shown in Step 2, or pressing SEL will allow you
enter a phone number into the selected location. The user will then be prompted to enter
a phone number to be dialed, as shown,
A phone number can be entered in much the same way as the phonebook. The following
options are also available, if the displayed number has no digits:
• Press to select an entry from the phone book. You are presented with the phone
book review screen. You can navigate to a desired entry as described in the phone
book section. Pressing SEL will copy the stored number to the quick dial number.
• Press to select an entry from the call log. You are presented with the call log review
screen. You can navigate to a desired entry as describe in the call log section.
Pressing SEL will copy the phone number shown into the quick dial number.
• Press RDL to select an entry from the redial list. You are presented with the call log
review screen. You can navigate to a desired entry as describe in the call log section.
Pressing SEL will copy the phone number shown into the quick dial number.
Quick Dialing
>PHONE BOOK
CALL L06
>QUICK DIAL
RING VOLUME
SELECT QUICK
DIAL NUMBER
QUICK DIAL X
IS EMPTY!
STORE NUMBER
_
Basic Operation
19
If all cases, while reviewing phone book, call log or redial list to copy to the quick dial,
pressing OFF will return the user to the quick dial number entry screen.
5) The user presses SEL to confirm the number.
Once confirmed, a quick dial number cannot be edited, only dialed or deleted.
Reviewing quick dial numbers
1) Press SEL when the handset is idle to enter the menu system
2) Move down to the quick dial option by pressing the key,
3) Then press SEL to enter the quick dial sub menu.
4) Select a quick dial key location using the 0-9 keys. If that location has a number
assigned to it, it will be displayed as follows:
or
At this point, you have the following options:
• Press OFF to return to the main menu.
• Press 0-9 to review another quick dial location.
• Press SEL to edit the currently shown location. The procedure to edit the number is
the same as for editing a phone book number.
• Press DEL to delete the currently shown location. The following will be shown:
>PHONE BOOK
CALL L06
>QUICK DIAL
RING VOLUME
SELECT QUICK
DIAL NUMBER
John Smith
1-234-567-8901
555-1212
CONFIRM DELETE
QUICK DIAL X
Quick Dialing
Basic Operation
20
Where x is the quick dial location number. Pressing OFF will return to the quick dial review
as shown above. Pressing SEL will confirm the deletion and
will be shown, indicating the location has been deleted.
• Press ON or SPK to dial the displayed number.
Dialing a Quick Dial number
A quick dial number can be dialed in two ways.
1. While reviewing the quick dial numbers as previously shown.
2. While the handset is idle or in pre-dial, as follows:
While the handset is idle the user can perform a quick dial by holding down the desired
quick dial location key (0-9). If the location is empty then
will be shown for a few seconds before returning to the idle or pre-dial screen.
If the location does have an entry, then that number will be added to any pre-dialed digits
and the phone will go off-hook and begin dialing.
QUICK DIAL X
IS EMPTY!
QUICK DIAL
NOT ASSIGNED!
Quick Dialing
Basic Operation
21
Audio Volume
Audio volume is adjusted during an active call by the following key sequence:
Pressing the volume or keys on the side of the unit. Separate volume settings are
maintained for normal, handsfree and headset modes. When the volume keys are pressed
during a call the screen will show:
As the volume is increase the number of blocks shown will increase. As the volume is
decreased fewer blocks will be shown.
Ring Volume
The volume of the ringer signal can be adjusted by the following key sequence:
1) Press SEL
2) Press the key until the following is shown on the display.
3) Press SEL to enter the ring volume sub-menu.
4) Enter volume 0 - 6, or adjust using and keys. The current ring tone/melody is
played each time the setting is adjusted.
5) Press SEL to confirm the setting.
With no bars displayed (Volume Level 0), the ringer has been turned OFF.
Handset Settings
>PHONE BOOK
CALL L06
>RINGE VOLUME
RINGE TONE
VOLUME
RINGE VOLUME
>RINGE VOLUME
RINGE TONE
RINGE VOLUME
Basic Operation
22
A “ringer off” ICON
is shown in the display when the ringer has been switched off.
Ring tone
The ring tone of an incoming external/intercom call can be changed by the following key
sequence:
1) Press SEL
2) Press the or keys until the RING TONE option is shown as follows:
3) Press SEL, to enter the ring pattern menu.
4) Press the & keys followed by the SEL key to choose either OUTSIDE or
INTERCOM ring tone setting.
or
5) Enter setting 0 - 9, or adjust using and keys. When changed the indicated ring
tone will be played in the speaker.
6) Press SEL, to confirm the setting.
VTECH
>PHONE BOOK
CALL L06
>RINGE TONE
KEY CLICK
OUTSIDE RINGE
1
INTERCOM RINGE
1
INTERCOM CALL
OUTSICE CALL
Handset Settings
Basic Operation
23
Key Click (preset to ON)
When you press a key on the Handset, you hear a confirmation ‘click’. You can turn this
feature Off and On by doing the following:
1) Press SEL
2) Press the or key until the KEY CLICK option is shown as follows:
3) Press SEL, to enter the key click sub-menu.
4) Enable key click by pressing 1 or , or disable key click by pressing the 0 or key.
5) Press SEL, to confirm the setting.
Handset Name
It is possible to gives each handset its own unique name. The name is shown in the first
line during idle replacing the “VTECH”, normally shown when the Handset is idle.
The name can be a maximum of 16 characters in length.
The handset naming procedure is as follows:
1) Press SEL
2) Press the or keys until the HANDSET NAME option is shown as follows:
>PHONE BOOK
CALL L06
>KEY CLICK
HANDSET NAME
>KEY CLICK
IS ON
>KEY CLICK
IS OFF
>KEY CLICK
HANDSET NAME
>PHONE BOOK
CALL L06
>HANDSET NAME
LANGUAGE
Handset Settings
Basic Operation
24
3) Press SEL, to enter the handset name sub-menu.
4) Enter Handset name (characters are entered in the same way as for the phone book).
5) Press SEL, to confirm the setting.
When returning to idle the display shows:
Language (preset to English)
You can change the language on the Handset display:
1) Press SEL
2) Press the or key until the LANGUAGE option is shown as follows:
3) Press SEL, to enter the language selection menu. The current language is shown in
the second line. Select Spanish, French or English by pressing or key.
4) Press SEL, to confirm the setting. The phone returns to the previous menu.
Message Waiting
Your telephone can detect a Visual Message Waiting signal, generated by many telephone
service providers. If you subscribe to Voice Mail service from your local telephone
company (fee required), and a Visual Message Waiting signal is provided, the Handset
will display MESSAGES WAITING, alerting you to new messages.
HANDSET NAME
_
HANDSET NAME
Kitchen_
>HANDSET NAME
LANGUAGE
Kitchen
>PHONE BOOK
CALL L06
>LANGUAGE
CLR MSG WAITING
LANGUAGE
ENGLISH
Handset Settings
Basic Operation
25
Once you have reviewed all new messages, the Messages Waiting alert will automatically
be turned off.
Clear Message Waiting
If, after reviewing all new voice mail messages, the Messages Waiting alert still remains
on the screen, the Messages Waiting indication can be manually removed from the display
by the following sequence:
1) Press SEL
2) Press the or keys until the CLR MSG WAITING option is shown as follows:
3) Press SEL, to enter the message menu.
4) Confirm clearing of the message waiting indication by pressing SEL (= yes), or cancel
clearing by pressing OFF (= no). After this the phone returns to the previous menu.
Dial Method (preset to DTMF-Tone)
It is possible to change the method of dialing between DTMF (Tone) and pulse dialing, if
your local phone company requires pulse dialing in your area:
1) Press SEL
2) Press the or keys until the DIAL TYPE option is shown as follows:
3) Press SEL, to enter the dial sub-menu.
>PHONE BOOK
CALL L06
> CLR MSG WAITING
DIAL TYPE
> CLEAR MSG WAIT
CONFIRM?
> CLR MSG WAITING
DIAL TYPE
>PHONE BOOK
CALL L06
>DIAL TYPE
PHONE BOOK
>DIAL TYPE
DTMF
Handset Settings
Basic Operation
26
4) Press or to choose the method of dialing , the display looks like the one below
5) Alternately the user can select pulse dialing by pressing 1 or . Select DTMF dialing
by pressing 0 or .
6) Press SEL to confirm the setting.
Temporary Tone
When the phone is set for pulse dial mode, it is possible to switch to temporary DTMF-
Tone mode during an ongoing call by pressing * . Once pressed, DTMF will be used for
the rest of the call. After you hang up, the phone will return to pulse dialing for the next
call.
>DIAL TYPE
PULSE
>DIAL TYPE
PHONE BOOK
Handset Settings
Basic Operation
27
SENDING CALL TO
OTHER HANDSET
OTHER HANDSET
NOT AVAILABEL
Call Forward & Call Transfer
An external call can be forwarded or transferred from one handset to the other handset.
The difference between forward and transfer depends on if the sending handset needs
to talk with the receiving handset, before the external call is actually sent to the other
handset.
Call Forward
A handset on an external call can forward it to the other handset by holding down the
INT key.
The display will initially show:
If the base can connect to the other handset, the display will change to:
And then return to the idle display.
If the base cannot find the other handset as a result of it being out of range or powered
off, the display will show:
And the external will ‘call back’ to the handset.
Call Transfer
An external call is transferred by:
1. Press INT key (the external call is put on hold)
2. Destination handset will ring, showing an intercom call.
3. Pressing the ON key on the destination handset will answer the intercom call.
4. Inform the person using the destination handset that they have a call on hold.
5. Press OFF, on the first handset, to transfer external call to other handset.
If there is no answer on the destination handset, the first handset can reconnect to the
held call by pressing INT to reconnect to the external call.
Call Back
After forwarding a call, a CALL BACK is generated in the forwarding handset if the
forwarded call is not answered within 30 seconds. When a call is returned to a handset,
it will show the following while ringing:
If the returned call is not answered within 30 seconds, the phone automatically goes on
hook, dropping the external call.
Handset Operation
Basic Operation
CALL BACKL
28
Conference
It is possible to establish a conference between two handsets and the external line.
If a handset already has a connection to the external line, and another handset goes off-
hook, a conference is immediately established. Both handsets will show:
Both handsets connected to the external line are allowed to transmit DTMF digits / dialing
pulses to the line.
If a handset is on the process of transferring a call to the other handset it is possible to
conference with both calls by holding down the INT key. Holding INT when connected
to either party, when transferring, or call toggling, will immediately conference both
handsets and external line.
A handset can leave the conference by going on-hook, by pressing OFF, or placing the
handset on the base or charging cradle. The connection continues between the remaining
handset and the external party.
Redial at On-Hook state
Pressing REDIAL while the handset is idle or pre-dialing will access the last dialed number.
Subsequent
presses of REDIAL will access previously dialed numbers. After the fifth number the
redial list will cycle back to the most recently dialed number. Alternately, you can use the
and keys to scroll through the 5 previously dialed numbers.
Pressing OFF will cancel the redial list review.
Pressing ON or SPK will add the shown redial number to any pre-dialed digits, go off-hook
and start dialing.
Pressing SEL add just add the shown redial to any pre-dialed digits.
Redial at Off-Hook state
Pressing REDIAL when on an external call will display the last dialed number. After two
second the shown number will be automatically dialed. If during this time, REDIAL is
pressed again the display will return to the external call presentation, and the number will
not be dialed.
Flash
During an ongoing external call, press the FLASH/ON key to flash the line (to respond to
a Call Waiting signal, for example).
Mute
It is possible to mute the microphone during a conversation by pressing the DELETE/MUTE
key. The microphone is un-muted by pressing DELETE/MUTE again.
In case the external line is muted, when establishing an intercom connection, the line is
un-muted automatically after the intercom call is terminated. The line is also un-muted after
the FLASH feature is used.
CONF. 00:00:20
555-1212
Handset Operation
Basic Operation
29
A text message in the display indicates when the microphone is first muted.
The MUTE icon will also be shown whenever the microphone is muted.
MUTEMUTE
MUTEMUTE
MUTE
When mute is disabled, this message will briefly be shown:
And the MUTE icon will turn off.
Page
The page function is used as an aid to locate the handsets. It can be only done from the
Base.
To activate paging the user presses the PAGE button on the base.
All handsets not currently active on a call will show:
and start the paging sound.
Either handset can cancel the page by pressing any of the PHONE, 0-9, *, # or SPK keys.
Or, press PAGE at the Base to cancel the page.
ACTIVE 00:00:12
MICROPHONE MUTED
MUTEMUTE
MUTEMUTE
MUTE
ACTIVE 00:00:12
555-1212
MUTEMUTE
MUTEMUTE
MUTE
ACTIVE 00:00:12
MICROPHONE ON!
MUTEMUTE
MUTEMUTE
MUTE
ACTIVE 00:00:12
555-1212
MUTEMUTE
MUTEMUTE
MUTE
BASE IS
PAGING!
Handset Operation
Basic Operation
30
Your cordless telephone is equipped with a 2.5mm Headset Jack for use with an optional
accessory Headset for hands-free operation. If you choose to use the Headset option,
you must obtain an optional accessory Headset, which is compatible with this product.
To purchase a Headset, call VTECH Customer Service at 1-800-595-9511.
Once you have a compatible 2.5mm Headset, locate the Headset Jack on the Handset.
Connect the plug on the Headset cord to the jack on the cordless Handset. The plug should
fit securely. Do not force the connection.
Advanced Operation
Headset Operation
NOTE:
Whenever a compatible Headset is connected
to the cordless Handset, the microphone on the
Handset will be muted. This is done to limit the
effect of background noise.
Belt Clip
The phone is also equipped with a detachable
belt clip. Align the pins on the inside edge of the
clip with the notches on the sides of the Handset.
The belt clip should snap securely into place. Do
not force the connection.
31
Taking Care Of Your Telephone
Your cordless telephone contains sophisticated electronic parts, so it must be treated
with care.
Avoid rough treatment
Place the Handset down gently. Save the original packing materials to protect your
telephone if you ever need to ship it.
Avoid water
Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the
rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub or
shower.
Electrical storms
Electrical storms can sometimes cause power surges harmful to electronic equipment.
For your own safety, use caution when using electric appliances during storms.
Cleaning your telephone
Your telephone has a durable plastic casing that should retain its luster for many years.
Clean it only with a soft cloth slightly dampened with water or a mild soap. Do not use
excess water or cleaning solvents of any kind.
Additional Information
Maintenance
Remember that electrical appliances can cause serious injury if used when you are
wet or standing in water. If your Base Unit should fall into water, DO NOT RETRIEVE
IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM
THE WALL. Then pull the unit out by the unplugged cords.
32
If you have difficulty operating your phone, the suggestions below should solve the
problem. If you still have difficulty after trying these suggestions, call VTECH
Communications at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-267-
7377.
The Phone Doesn’t Work At All
• Make sure the Power Cord is plugged in.
• Make sure the telephone line cord is plugged firmly into the Base Unit and the telephone
wall jack.
• Make sure the batteries are properly charged. If the ‘LOW BATTERY’ message is
shown, the battery pack needs charging.
No Dial Tone
• First check all the suggestions above.
• If you still don’t hear a dial tone, disconnect the Base Unit from the telephone jack and
connect a different phone. If there is no dial tone on that phone either, the problem
is in your wiring or local service. Contact your local telephone company.
You Get Noise, Static, Or A Weak Signal Even When You’re Near The
Base Unit
• Household appliances plugged into the same circuit as the Base Unit can sometimes
cause interference.
Try moving the appliance or the Base Unit to another outlet.
You Get Noise, Static, Or A Weak Signal When You’re Away From
The Base Unit
• You may be out of range. Either move closer to the Base, or relocate the Base Unit.
• The layout of your home may be limiting the range. Try moving the Base Unit to another
position.
The Handset Does Not Ring When You Receive A Call
• Make sure you have the ringers activated. To set the ringer, see HANDSET SETTINGS
• Make sure the telephone line cord is plugged firmly into the Base Unit and the
telephone jack. Make sure the power cord is plugged in.
• You may be too far from the Base Unit.
• You may have too many extension phones on your telephone line to allow all of them
to ring. Try plugging some of the other phones.
You Hear Other Calls While Using Your Phone
• Disconnect your Base Unit from the telephone jack, and plug in a regular telephone.
If you still hear other calls, the problem is probably in your wiring or local service. Call
your local telephone company.
You Hear Noise In The Handset, And None Of The Keys Or Buttons
Work
• Make sure the power cord is plugged in.
In Case Of Difficulty
Additional Information
33
Common Cure For Electronic Equipment
If the unit does not seem to be responding normally, then try putting the Handset in the
cradle. If it does not seem to respond, do the following (in the order listed):
1. Disconnect the power to the Base.
2. Disconnect the Handset battery, and spare battery pack, if applicable.
3. Wait a few minutes.
4. Connect power to the Base.
5. Re-install the battery pack (s)
6. Watch for Handset to display: “FOUND BASE”.
FOUND BASE
In Case Of Difficulty
Additional Information
34
What does this limited warranty cover?
• The manufacturer of this VTECH product, VTECH Communications, warrants to the
holder of a valid proof of purchase (“Consumer” or “you”) that the product and all
accessories provided by VTECH in the sales package (“Product”) are free from
material defects in material and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in accordance with operation
instructions, This limited warranty extends only to the Consumer for Products
purchased and used in the United States of America.
What will VTECH Communications do if the Product is not free from
material defects in materials and workmanship during the limited
warranty period (“Materially Defective Product”)?
• During the limited warranty period, VTECH’s authorized service representative will
repair or replace at VTECH’s option, without charge, a Materially Defective Product.
If we repair this product, we may use new or refurbished replacement parts. If we
choose to replace this product, we may replace it with a new or refurbished product
of the same or similar design. VTECH will return repaired or replacement products
to you in working condition. VTECH will retain defective parts, modules, or equipment.
Repair or replacement of Product, at VTECH’s option, is your exclusive remedy. You
should expect the repair or replacement totake approximately 30 days.
How long is the limited warranty period?
• The limited warranty period for the product extends for ONE(1) YEAR from the date
of purchase if we repair or replace a Materially Defective Product under the terms
of this limited warranty. This limited warranty also applies to repaired or replacement
Products for a period of either (a) 90 days from the date the repaired or replacement
Product is shipped to you or (b) the time remaining on the original one-year warranty;
whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover
1. Product that has been subjected to misuse, accident, shipping or other physical
damage, improper installation, abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration or modification by anyone
other than an authorized service representative of VTECH; or
3. Product to the extent that the problem experienced is caused by signal conditions,
network reliability or cable or antenna systems; or
4. Product to the extent that the problem is caused by use with non-VTECH electrical
accessories; or
5. Product whose warranty/quality stickers, Product serial numbers plates or electronic
serial numbers have been removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair from outside the united
States, or used for commercial or institutional purposes (including but not limited to
Products used for rental purposes); or
7. Product returned without valid proof of purchase (see 2 below); or
Warranty Statement
Additional Information
35
8. Charges for installation or set up, adjustment of customer controls, and installation
or repair of systems outside the unit.
How do you get warranty service?
• To obtain warranty service in the United States of America, call 1 800-595- 9511 for
instructions regarding where to return the Product. Before calling for service, please
check the user’s manual. A check of the Product controls and features may save you
a service call.
• Except as provided by applicable law, you assume the risk of loss or damage during
transit and transportation and are responsible for delivery or handling charges
incurred in the transport of Product(s) to the service location. VTECH will return
repaired or replaced product under this limited warranty to you,transportation,
delivery or handling charges prepaid. VTECH assumes no risk for damage or loss of
the Product in transit.
• If the Product failure is not covered by this limited warranty, or proof of purchase does
not meet the terms of this limited warranty, VTECH will notify you and will request that
you authorize the cost of repair and return shipping costs for the repair of Products
that are not covered by this limited warranty.
What must you return with the Product to get warranty service?
1. Return the entire original package and contents including the Product to the VTECH
service location along with a description of the malfunction or difficulty;
2. Include “valid proof of purchase” (sales receipt) identifying the Product purchased
(Product model) and the date of purchase or receipt; and
3. Provide your name, complete and correct mailing address, and telephone number.
Other Limitations
• This warranty is the complete and exclusive agreement between you and VTECH.
It supersedes all other written or oral communications related to this Product. VTECH
provides no other warranties for this product. The warranty exclusively describes
all of VTECH’s responsibilities regarding the product. There are no other express
warranties. No one is authorized to make modifications to this limited warranty and
you should not rely on any such modification.
State Law Rights: This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state.
Limitations: Implied warranties, including those of fitness for a particular purpose
and merchantability (an unwritten warranty that the product is fit for ordinary use)
are limited to one year from date of purchase. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
• In to event shall VTECH be liable for any indirect, special, incidental, consequential,
or similar damages (including, but not limited to lost profits or revenue, inability to use
the product, or other associated equipment, the cost of substitute equipment, and
claims by third parties) resulting from the use of this product, some states do not allow
the exclusion or limitation of incidental or consequential damages, so theabove
limitation or exclusion may not apply to you.
Warranty Statement
Additional Information
36
This equipment complies with Parts 15 of the Federal Communications Commission (FCC)
rules for the United States. It also complies with regulations RSS210 and CS-03 of Industry
and Science Canada. Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of thedevice.
A label is located on the underside of the Base Unit containing either the FCC registration
number and Ringer Equivalence Number (REN) or the IC registration number and Load
Number. You must, upon request, provide this information to your local telephone
company.
This equipment is compatible with inductively coupled hearing aids. Should you
experience trouble with this telephone equipment, please contact:
VTech Communications Inc
CUSTOMER SERVICE. at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-
267-7377. For repair/warranty information. The telephone company may ask you to
disconnect this equipment from the line network until the problem has been corrected.
FCC Part 15
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment. The
equipment has been tested and found to comply with part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try and correct the interference by oneor
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet or on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Part 68 and ACTA
If this equipment was approved for connection to the telephone network prior to July 23,
2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules.
If the equipment was approved after that date, it complies with the Part 68 rules and with
Technical Requirements for Connection of Equipment to
the Telephone Network adopted by the Administrative Council for Terminal Attachments
(ACTA). We are required to provide you with the following information.
1. Product identifier and REN information
The label on the back or bottom of this equipment contains, among other things, an identifier
indicating product approval and the Ringer Equivalence Number (REN). This information
FCC, ACTA and IC Regulations
Additional Information
37
must be provided to your local telephone company upon request. For equipment approved
prior to July 23, 2001, the product identifier is preceded by the phrase “FCC Reg No.” and
the REN is listed separately. For equipment approved after that date, the product identifier
is preceded by “US” and a colon (:), and the REN is encoded in the product identifier without
a decimal point as the sixth and seventh characters following the colon. For example, the
product identifier US:AAAEQ03T123XYZ would indicate an REN of 0.3. The REN is used
to determine how many devices you may connect to your telephone line and still have
them ring when you are called. In most, but not all areas, the sum of all RENs should be
five (5.0) or less. You may want to contact your local telephone company for more
information.
2. Connection and use with the nationwide telephone network
The plug and jack used to connect this equipment to the premises wiring and the telephone
network must comply with the applicable Part 68 rules and technical requirements adopted
by ACTA. A compliant telephone cord and modular plug is provided with this product. It
is designed to be connected to a compatible modular jack that is also compliant. An RJ11
jack should normally be used for connecting to a single line and an RJ14 jack for two lines.
See Installation Instructions in the user’s manual. This equipment may not be used with
Coin Telephone Lines or with Party Lines. If you have specially wired alarm dialing
equipment connected to your telephone line, ensure the connection of this equipment
does not disable your alarm equipment. If you have questions about what will disable alarm
equipment, consult your telephone company or a qualified installer.
3. Repair instructions
If this equipment is malfunctioning, it must be unplugged from the modular jack until the
problem has been corrected. Repairs to this telephone equipment can only be made by
the manufacturer or its authorized agents. For repair procedures, follow the instructions
outlined under the Limited Warranty.
4. Rights of the telephone company
If this equipment is causing harm to the telephone network, the telephone company may
temporarily discontinue your telephone service. The telephone company is required to
notify you before interrupting service. If advance notice is not practical, you will be notified
as soon as possible. You will be given theopportunity to correct the problem and the
telephone company is required to inform you of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equipment, operation, or
procedures that could affect the proper functioning of this product. The telephone
company is required to notify you if such changes are planned.
5. Hearing aid compatibility
If this product is equipped with a corded or cordless handset, it is hearing aid compatible.
6. Programming/testing of emergency numbers
If this product has memory dialing locations, you may choose to store police, fire
department and emergency medical service telephone numbers in these locations. If you
do, please keep three things in mind:
a We recommend that you also write the telephone number on the directory card, so
that you can still dial the emergency number manually if the memory dialing feature
doesn’t work.
FCC, ACTA and IC Regulations
Additional Information
38
b This feature is provided only as a convenience, and the manufacturer assumes no
responsibility for customer reliance upon the memory feature.
c Testing the emergency telephone numbers you have stored is not recommended.
However, if you do
make a call to an emergency number:
• You must remain on the line and briefly explain the reason for the call before hanging
up.
• Programming/testing of emergency numbers should be performed during off-peak
hours, such as in the early morning or late evening, when the emergency services
tend to be less busy.
IC (Industry Canada)
This telephone is registered for use in Canada.
The term “IC:” before the radio certification number only signifies that Industry Canada
technical specifications were met.
Notice:
This equipment meets the applicable Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration number. The abbreviation, IC, before
the registration number signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical specifications were met. It does
not imply that Industry Canada approved the equipment.
Notice:
The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN assigned
to each terminal equipment provides an indication of the maximum number of terminals
allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Numbers of all the devices does not exceed five. Before installing this
equipment, users should ensure that it is permissible to be connected to the facilities of
the local telecommunications company. The equipment must also be installed using an
acceptable method of connection. The customer should be aware that compliance with
the above conditions may not prevent degradation of services in some situations. Repairs
to certified equipment should be made by an authorized Canadian maintenance facility
designated by the supplier. Any repairs or alterations made by the user to this equipment,
or equipment malfunctions, may give the telecommunications company cause to request
the user to disconnect the equipment. Users should ensure for their own protection that
the electrical ground connections of the power utility, telephone lines and internal metallic
water pipe system, if present, are connected together. This precaution may be particularly
important in rural areas.
Caution:
Users should not attempt to make such connections themselves, but should contact the
appropriate electrical inspection authority, or electrician, as appropriate.
Your phone is designed to operate at the maximum power allowed by the FCC and IC.
This means your Handset and Base Unit can communicate only over a certain distance
- which will depend on the location of the Base Unit and Handset, weather, and the
construction and layout of your home or office.
FCC, ACTA and IC Regulations
Additional Information
39
The RBRC® Seal on the
nickel-metal-hydride
battery indicates that
VTech Communications,
Inc. is voluntarily
participating in an industry program to
collect and recycle these batteries at the
end of their useful lives, when taken out of
service within the United States and
Canada. The RBRC® program provides a
convenient alternative to placing used
nickel-metal-hydride batteries into the trash
or municipal waste, which may be illegal in
your area. VTech’s participation in RBRC®
makes it easy for you to drop off the spent
battery at local retailers participating in the
RBRC® program or at authorized VTech
product service centers. Please call 1-
800-8-BATTERY for information on Ni-MH
battery recycling and disposal bans/
restrictions in your area. VTech’s
involvement in this program is part of its
commitment to protecting our environment
and conserving naturalresources.
RBRC® is a registered trademark of
Rechargeable Battery Recycling
Corporation.
The RBRC® Seal
FREQUENCY CONTROL
Crystal controlled
PLL synthesizer
TRANSMIT FREQUENCY
Base : 5744.736 - 5825.952 MHz
Handset: 2401.056 - 2482.272 MHz
RECEIVE FREQUENCY
Base: 2401.056 - 2482.272 MHz
Handset : 5744.736 - 5825.952 MHz
CHANNELS
95 Channels
NOMINAL EFFECTIVE RANGE
Maximum power allowed by FCC and IC.
Actual operating range may vary according
to environmental conditions at the time of
use.
SIZE
Handset : 193mm x 52mm x 40mm
(including antenna)
Base : 192mm x 143mm x 91mm
Charger: 77mm x 69mm x 54mm
WEIGHT
Handset : 138 grams
(excluding Battery Pack)
Base : 396 grams
Charger : 216 grams
POWER REQUIREMENTS
Handset : 2.4V 1400mAh NiMH
Battery Pack
Base : 7 VDC @ 900mA
Charger : 6 VDC @ 300mA
MEMORY
Speed Dial: 50 Memory locations; up to 32
digits per location
CID : Alphanumeric Display 50 Memory
locations
SPECIFICATIONS ARE TYPICALAND
MAY CHANGE WITHOUTNOTICE.
Technical Specifications
(this part will change accordingly)
Additional Information
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.
Distributed in the U.S.A. by VTech Communications Inc.; Beaverton, Oregon.
Distributed in Canada by VTech Electronics Canada Ltd., Suite 200, 7671 Alderbridge
Way, Richmond, B.C. V6X 1Z9.
Copyright 2003 for VTECH TELECOMMUNICATIONS LTD.
Printed in China
91-XXXX-10-00
ISSUE 0
