Contents
Users Manual part 10 of 10
10
159
Maintenance
Recharging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159
Inspecting and Cleaning the Monitor and Accessories . . . . . . . . . . . . . . . . . . .161
Recycling Monitor Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
Recharging the Battery
The monitor battery is recharged whenever the monitor is placed into a cradle that is
connected to a suitable power source. Recharging occurs whether the monitor is on or
off. While in a cradle that is connected to AC power, the monitor also receives operating
power from the cradle, thus preserving battery power for use when the monitor is
removed.
To Recharge the Battery
1. Confirm that the green
“power” light (the right of
two on the cradle) is on.
If it is off, plug the power
adapter into the cradle.
2. Insert the monitor into the
cradle until it clicks into
place.
3. Confirm that the green
“battery charging” light on
the cradle (the left of two on
the cradle) is on.
• If the green “battery
charging” light is off, the
monitor battery is
already fully charged.
• A steady yellow light
indicates a problem with
the battery or the cradle
(contact a qualified
service technician) or
that the monitor is not
properly seated in the
cradle.
Release button
Green: monitor is
running on cradle
power
Green: battery is
charging
Yellow: battery or
cradle fault, or monitor
is not properly seated
in the cradle
160 Maintenance Welch Allyn Propaq LT Vital Signs Monitor
4. When the battery is fully charged, the green “battery charging” light is off.
• Keep the monitor in the cradle whenever the patient is in bed. This keeps the
monitor battery at full charge, so that it is ready for use if it must be removed
from the cradle.
• You can leave the monitor in the cradle when the battery is fully charged.
Note The yellow light might flash briefly when the monitor is being inserted in the
cradle or removed from the cradle. This is normal behavior and does not indicate a
problem.
WARNING Do not incinerate, submerge, crush, disassemble, or autoclave the
lithium-ion battery.
Caution Do not remove or replace the battery unless you are a Welch Allyn
qualified service technician.
Caution Do not use the monitor while the battery is being replaced.
Directions for Use Maintenance 161
Inspecting and Cleaning the Monitor and Accessories
Before cleaning the monitor, cradle, AC power adapter, or any accessories, thoroughly
inspect them.
• Look for any signs of damage and any improper mechanical function of buttons or
connectors.
• Gently bend and flex cables, inspecting them for damage or extreme wear, exposed
wires, or bent connectors.
• Confirm that all connectors engage securely.
Immediately report any sign of damage or malfunction to your service department.
At least once per year, thoroughly inspect the cradle and the AC adapter power cord for
damage or extreme wear.
To clean the monitor, the cradle, or any accessories, follow these steps:
1. Wipe the equipment with a cloth slightly moistened (not wet) with one of the
approved cleaning solutions listed in Table 12 on page 162.
2. Thoroughly wipe off any excess cleaning solution. Do not let the cleaning solution run
into or accumulate in connector openings, latches, or crevices. If liquid gets into
connectors, dry the area with warm air, and then check the equipment to confirm that
it operates properly.
WARNING Do not autoclave the monitor, the cradle, the AC power adapter, or
any accessories.
WARNING Do not immerse the monitor, the cradle, or the AC power adapter in
liquid when cleaning. Do not immerse accessories in liquid when cleaning unless
the accessory manufacturer’s cleaning instructions explicitly instruct you to do so.
WARNING Fire and electrical shock hazard. Always unplug the AC power
adapter from the electrical power outlet before inspecting or cleaning the cradle,
the AC power adapter, or the monitor. Exposing any of these to liquids, such as
cleaning solutions, while they are connected to electrical power could result in
electrical shock or fire.
Caution Use only a cleaning solution recommended by Welch Allyn for this
equipment. Use of any other cleaning solutions which have a high acid content or
are otherwise inappropriate can cause damage to the equipment, including
cracking and deterioration of the plastic case.
Caution Always follow the mixing/diluting instructions provided by the
manufacturer of the cleaning solution.
162 Maintenance Welch Allyn Propaq LT Vital Signs Monitor
Recycling Monitor Components
Within the EU
Do not dispose of this product as ‘unsorted municipal waste’. Prepare it for reuse
or separate collection as specified by Directive 2002/96/EC of the European
Parliament and the Council of the European Union on Waste Electronic and
Electrical Equipment (WEEE).
For more specific disposal information, see www.welchallyn.com/weee, or contact Welch
Allyn Customer Service.
Outside the EU
When the monitor, the cradle, or the battery reaches end of life, recycle it locally
according to national, state, and local regulations, or return it to Welch Allyn.
Caution Never use any of the following solutions or similar products to clean
the equipment: butyl alcohol, denatured ethanol, Freon™, mild chlorine bleach
solution, isopropyl alcohol (except for the SpO2 cable), trichloroethane,
trichloroethylene, acetone, Vesphene II, Enviroquat®, Staphene®, Misty®,
Glutaraldehyde, Formula 409®, or Fantastik®.
Table 12. Cleaning Instructions and Cleaning Solutions
Equipment Cleaning Instructions Approved Cleaning Solutions
Monitora
Charging/
Communication Cradlea
a. The equipment can be disinfected to comply with OSHA requirements for cleaning and decontaminating spills of blood and other body
fluids. (Federal OSHA Standard on bloodborne pathogens: 29 CFR 1910.1030, 12/6/91.)
• Wipe with a nearly dry cloth moistened with
cleaning solution.
• Thoroughly wipe off any excess cleaning
solution. Do not let cleaning solution run into
connector openings or crevices.b
b. If liquid gets into the connectors, dry the area with warm air and then verify all monitoring functions.
Warm water, liquid soap, Coverage®,
Windex®, Ovation®, hydrogen
peroxide solution, Wex-cide®c,
T.B.Q.®c
c. Wex-cide (Wexford Labs, Inc., Kirkwood, MO) and T.B.Q. (Calgon Vestal Lab., Calgon Corp., St. Louis, MO) are disinfectants that meet
OSHA requirements, are EPA approved, and will not harm the outside of the monitor, battery, or battery charger. Wipe away
disinfectants with a water-dampened cloth after the manufacturer’s recommended period.
ECG cable, extension
cable
• Wipe gently with damp cloth moistened with a
mild detergent solution.
• Thoroughly wipe off any cleaning solution.
Mild detergent.
SpO2 cable, extension
cable
• Wipe the cable with a 70% isopropyl alcohol pad
and allow it to dry.
70% isopropyl alcohol pad.
Other accessories • Consult manufacturer’s instructions. Consult manufacturer’s instructions.
Note If the monitor, the cradle, or the battery is contaminated, this directive does not
apply.
A
163
Specifications
ECG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Resp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
SpO2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
NIBP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Alarms and Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
Wireless Monitor (Model 802LTRN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
ECG
Table 13. Specification: ECG
Characteristic Specification
Regulatory standards Meets ANSI/AAMI EC13-2002 and EN 60601-1:1990 + A1 + A2
Connector Hypertronics 9-pin female D01 latching connector
Selectable leads
3-lead cable
5-lead cable
Displayable I, II or III
Internally provides I, II or III
Displayable I, II, III, aVR, aVL, aVF, V
Internally provides I/II, III and V
Cable type detection Automatic detection and differentiation of 3- or 5-lead cable
Lead fault indicator Displayed chest icon with flashing indicator for each electrode
ECG Size (sensitivity) 0.2, 0.5, 1, 2, 4, and 8 mV/cm
Display sweep speed 25 mm/sec
Bandwidth (monitor display) 0.5 to 40 Hz Monitor Mode, Adult
0.05 to 40 Hz Extended Mode, Adult
0.5 to 80 Hz Monitor Mode, Pediatric or Neonate
0.05 to 80 Hz Extended Mode, Pediatric or Neonate
Bandwidth (to Acuity) 0.05 to 80 Hz Monitor or Extended Mode, Adult, Pediatric, or Neonate
Notch filters 50 and 100 Hz, 60 and 120 Hz, or OFF, selectable at Acuity or at the monitor
164 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Sample rate 363.64 Hz (181.82 Hz to Acuity)
Input protection Protected against electrosurgery and defibrillator when used with ECG cables specified
in the Welch Allyn Products and Accessories guide.
Electrosurgery interference
suppression
Included on all vectors when Welch Allyn-approved cables are used.
Lead-fail sense current 70 nA DC typical for active leads
140-280 nA DC typical for reference electrode, depending on number attached.
Tall T-wave rejection Meets AAMI (USA) EC13-2002, section 4.1.2.1.c, up through 1.2 mV, using AAMI test
waveform
Common mode rejection
FILTER function OFF
FILTER function ON
< 1 mV p-p RTI for 10V rms, 50/60 Hz into unbalanced input
< 30 μV p-p RTI for 10V rms, 50/60 Hz into unbalanced input
Input impedance > 2.5 MΩ single-ended @ 60 Hz
Input range (AC) 10 mV peak-to-peak (local display)
10 mV peak-to-peak (Acuity)
Input range (DC) Up to ±500 mV
Accuracy of input signal
reproduction-impulse
response
Requires ECG bandwidth to be set to extended mode.
System noise ≤ 30 µV peak-to-peak, RTI notch filter on
Baseline recovery (trace
restore)
Automatic
QRS detector Adult or pediatric amplitude range: 0.22 to 5.0 mV (RTI)
Neonate amplitude range: 0.1 to 5.0 mV
Adult width range (duration): 70 to 120 msec
Pediatric or neonate width range (duration): 40 to 120 msec
HR range (in all patient modes) 25 to 350 beats/min (measurement)
25 to 300 beats/min (display)
Alarm limits 25 to 298 beats/min (lower)
27 to 300 beats/min (upper)
HR resolution 1 beat/min
HR alarm resolution 5 beats/min
HR meter response time Responds to change in heart rate within 13 seconds depending on physiological
waveform. (As measured per AAMI standard EC13-2002 clause 5.1.2.1 (f), including
4.1.2.1 parts f. and g. waveforms.) Includes 1-second readout update interval.
HR accuracy ±3 beats/min or 3%, whichever is greater
HR display update interval at
monitor
1 second
AAMI HR response to
“ineffectively paced QRS
pattern”
Indicates rate of 30 to 46 during AAMI EC13-2002 part 5.1.4 part (f), (g), and (h) tests.
NOTE: AAMI Test 5.1.4 part (f), (g), and (h): Accuracy is affected when QRS and pacer
spikes are nearly simultaneous as occasionally is the case during this test.
Table 13. Specification: ECG (continued)
Directions for Use Specifications 165
HR averaging method HR = 60/(latest average interval in seconds)
For higher HR, latest avg interval = 7/8 (previous avg interval) + 1/8 (latest interval).
For lower HR, latest avg interval = 3/4 (previous avg interval) + 1/4 (latest interval).
Transition rates for choice of formula include hysteresis and are 70 and 80 beats/min.
Drift tolerance (AAMI spec.
EC13-2002, 4.2.6.3)
80 beats/min indicated for 80 beats/min ECG plus drift waveform
Pacer pulse display indication Pacer indicator (dashed vertical marker) shown on screen if pacer indicator is ON; pacer
signal always shown if of sufficient amplitude.
Pacer pulse detection (i.e., for
which the monitor displays a
dashed vertical marker in
trace)
Pulses = ± 3.2 mV to ± 700 mV @ 0.1 ms and ± 2 mV to ± 700 mV @ 0.2 to 2 ms, all with
or without overshoot, in electrically quiet environment. Thresholds automatically adjust
to reject repetitive ambient noise. Pacer detector influences QRS picking even while
pacer display indication is disabled.
Pacer pulse rejection Does not count as heartbeats approximately 95% of pacemaker pulses within pacer
pulse detection range, with or without AAMI (EC 13-2002) tails of 4, 8, 15, 25, 50, 75, or
100 ms decay time constant, whose tail amplitudes meet either EC 13’s method A or
method B criteria for single pacer pulses, or A-V sequential pulses (150 ms and 250 ms
separation), all per AAMI tests 4.1.4.1 and 4.1.4.2.
Pacer pulse detector minimum
slew rate detection threshold
2.5 V/sec RTI, per EC13:2002, 4.1.4.3
ECG trace duration 3 seconds in single or double trace display
6 seconds in cascade
Response to Irregular Rhythm (AAMI specification EC13-2002, 4.1.2.1. Part e.)
Ventricular bigeminy (VB) 78 to 81 beats/min (80 beats/min expected)
Slow alternating VB 57 to 65 beats/min (60 beats/min expected)
Rapid alternating VB 118 to 123 beats/min (120 beats/min expected)
Bidirectional systole 88 to 93 beats/min (90 beats/min expected)
1 mV ventricular tachycardia 197 to 198 beats/min (206 beats/min expected)
2 mV ventricular tachycardia 193 to 197 beats/min (195 beats/min expected)
Table 13. Specification: ECG (continued)
166 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Resp
Table 14. Specification: Impedance Pneumography (Resp)
Characteristic Specification
Connector (shared with ECG) Hypertronics 9-pin, female D01 latching connector
Input protection Electrosurgery and defibrillator protected and Resp fully functional when used with
any of the ECG cables specified in Welch Allyn Products and Accessories
(810-0409-XX)
Electrosurgery interference
suppression
Yes, but not quantifiable.
Selectable Leads Ld-1 (RA-LA), or Ld-2 (RA-LL) from either 3-lead cable or 5-lead cable, when using
an ECG cable specified for this monitor in Products and Accessories (810-0409-XX).
Base impedance range (in addition
to 1K resistors in ECG cable)
Approximately 200 ohms to 1200 ohms is normal monitoring range.
Approximately 1200 –1500 ohms range produces equipment alert “Resp Fault.
Noisy signal. Check electrodes”.
Above approximately 1500 ohms produces equipment alert “Resp Fault. Lead Fail”.
Thresholds depend on ECG cable type and length.
Impedance dynamic range 20 ohms
Baseline recovery (trace restore) Automatic
Resp size (sensitivity) selections 0.5X, 1X, 2X, 4X, 8X, 16X
Signal bandwidth after detection
(Monitor display and at Acuity)
0.05 to 4.0 Hz at 3dB point
Sample rate 22.73 Hz
Cardiovascular artifact (CVA)
rejection
Presence of CVA is detected automatically. Breaths are picked in the presence of
CVA unless the breath rate is within 5% of the heart rate or a submultiple of the
heart rate.
Resp channel noise ≤ 50 milliohms peak-to-peak typical
Breath detection threshold 0.14 ohms or 2x CVA, whichever is greater, set automatically
Resp rate (RR) range 2 to 150 breaths/min (adult/pediatric mode)
3 to 150 breaths/min (neonate mode)
RR alarm limits 2 to 148 breaths/min (lower, adult/pediatric)
4 to 150 breaths/min (upper, adult/pediatric)
3 to 148 breaths/min (lower, neonate)
5 to 150 breaths/min (upper, neonate)
Resp rate resolution 1 breath/min
Resp rate alarm resolution 1 breath/min
Breath rate accuracy ± 2 breaths/min or 2%, whichever is greater
Motion artifact rejection Not rejected
Obstructive apnea Not detected
RR display update interval at
monitor
1 second
Excitation signal characteristics 65.16 kHz, pseudosine wave, 65 µA RMS ± 5%
Display sweep speed 6.25 mm/sec
Directions for Use Specifications 167
SpO2
Table 15. Specification: Pulse Oximetry (SpO2)
Characteristic Specification
Saturation (% SpO2)
Range
Resolution
1% to 100%, but limited by sensors and by sensor manufacturers’ technology
1%
Alarm limits 50% to 98% (lower)
52% to 100% (upper)
Probe accuracy (adult, pediatric,
neonate)
Accuracy for saturation levels below 70% is unspecified. See Table 16,
“Specification: Pulse Oximetry (SpO2) Nellcor Sensor” on page 167 for sensor
accuracy.
Pulse rate alarm limits 25 to 298 beats/min (lower)
27 to 300 beats/min (upper)
Pulse rate accuracy ± 3 beats/min typical; varies with sensor model
Display update interval at the monitor 1 second
Alarm hold-off period 10 seconds; resets if the sensor reports levels within limits before 10 seconds
elapses.
Circuitry Microprocessor controlled
Automatic self-test of oximeter when powered on
Automatic setting of default parameters
Automatic alarm messages
Electrosurgery interference suppression Yes
Sensor compatibility Compatible only with Nellcor sensors listed in Table 16, “Specification: Pulse
Oximetry (SpO2) Nellcor Sensor” on page 167.
Sensor lights
Red wavelength
Infrared wavelength
660 nm (nominal)
920 nm (nominal)
Table 16. Specification: Pulse Oximetry (SpO2) Nellcor Sensor
Sensor Application Site(s) Measurement
RangeaAccuracyb
(digits)
Single Use - OxiMax
MAX-A Adult Finger, thumb or toe 70% to 100% ± 2% c
MAX-AL Adult (36” cable) Finger, thumb or toe 70% to 100% ± 2% c
MAX-N Adult Finger 70% to 100% ± 2% c
MAX-N Neonatal Foot 70% to 100% ± 3% c
MAX-P Pediatric Finger, thumb or toe 70% to 100% ± 2% c
MAX-I Infant Great toe or thumb 70% to 100% ± 2% c
MAX-FAST Adult Forehead 70% to 100% ± 2%
MAX-R Adult Nose 70% to 100% ± 3.5%
168 Specifications Welch Allyn Propaq LT Vital Signs Monitor
NIBP
Single Use - OxiCliq
OxiCliq A Adult Finger, thumb or toe 70% to 100% ± 2.5%
OxiCliq P Pediatric Finger, thumb or toe 70% to 100% ± 2.5%
OxiCliq N Adult Finger 70% to 100% ± 2.5%
OxiCliq N Neonate Foot or hand 70% to 100% ± 3.5%
OxiCliq I Infant Great toe or thumb 70% to 100% ± 2.5%
Reusable
D-YS DURA-Y, Multisite (with D-YSE, Earclip
for use with D-YS)
Ear lobe or pinna 70% to 100% ± 3.5%
D-YS Neonate Ear lobe or pinna 70% to 100% ± 4%
D-YS Infant to Adult Ear lobe or pinna 70% to 100% ± 3%
DS-100A DURASENSOR Adult Index finger 70% to 100% ± 3%
OXI-A/N OXIBAND Adult Finger, thumb or toe 70% to 100% ± 3%
OXI-A/N OXIBAND Neonatal Foot or hand 70% to 100% ± 4%
OXI-P/I Pediatric Finger, thumb or great toe 70% to 100% ± 3%
OXI-P/I Infant Great toe 70% to 100% ± 3%
a. Probe accuracy for saturation levels below 70% is unspecified.
b. When sensors are used on neonatal subjects as recommended, the specified accuracy range is increased by ± 1 digit as compared to
adult usage, to account for the theoretical effect on oximeter measurements of fetal hemoglobin in neonatal blood. For example,
MAX-N accuracy on neonates is ± 3 digits, rather than ± 2 digits for adults.
c. The accuracy specification under motion conditions is ± 3.
Table 16. Specification: Pulse Oximetry (SpO2) Nellcor Sensor (continued)
Table 17. Specification: Noninvasive Blood Pressure (NIBP)
Characteristic Specification
Method Oscillometric
Regulatory standards Meets AAMI SP10:2002, IEC 60601-1:1990, IEC 60601-2-30:1999(E);
EN 1060-1:1996, EN 1060-3:1997
Control Automatic (at selected intervals), turbo, and manual
Auto intervals 1, 2, 3, 5, 10, 15, 30, and 60 minutes
Smartcuf (Available in 2006) Available when ECG is used on adult patients
Reported pressures Systolic, diastolic, and mean plus real-time manometer pressure
Pressure resolution 1 mmHg
Directions for Use Specifications 169
Systolic range
Alarm limits
Adult 30 to 260 mmHg
Pediatric 30 to 160 mmHg
Neonate 25 to 120 mmHg
Adult low 30 to 258 mmHg high 32 to 260 mmHg
Pediatric low 30 to 158 mmHg high 32 to 160 mmHg
Neonate low 25 to 118 mmHg high 27 to 120 mmHg
Diastolic range
Alarm limits
Adult 20 to 235 mmHg
Pediatric 15 to 130 mmHg
Neonate 10 to 105 mmHg}
Adult low 20 to 233 mmHg high 22 to 235 mmHg
Pediatric low 15 to 128 mmHg high 17 to 130 mmHg
Neonate low 10 to 103 mmHg high 12 to 105 mmHg
Mean range
Alarm limits
Adult 20 to 255 mmHg
Pediatric 15 to 140 mmHg
Neonate 10 to 110 mmHg
Adult low 20 to 253 mmHg high 22 to 255 mmHg
Pediatric low 15 to 138 mmHg high 17 to 140 mmHg
Neonate low 10 to 108 mmHg high 12 to 110 mmHg
Pulse rate range
Alarm limits
30 to 220 beats/min, in adult, pediatric, and neonate modes
Low 25 to 298 beats/min
high 27 to 300 beats/min
Static manometer accuracy 0-300mmHg ±3 mmHg or 2% of reading, whichever is greater. Can be checked
in the field, but no adjustments are provided (or needed).
Manometer baselining (zeroing) Automatic
Atmospheric pressure compensation Automatic
Minimum inflation pressure Adult 100 mmHg
Pediatric 80 mmHg
Neonate 50 mmHg
Maximum inflation pressure Adult 270 mmHg
Pediatric 170 mmHg
Neonate 132 mmHg
Default inflation pressure Adult 160 mmHg
Pediatric 120 mmHg
Neonate 90 mmHg
Normal overpressure limit Adult 280 mmHg
Pediatric 200 mmHg
Neonate 141 mmHg
Single fault overpressure limit Adult 308 mmHg
Pediatric 220 mmHg
Neonate 154 mmHg
Table 17. Specification: Noninvasive Blood Pressure (NIBP) (continued)
170 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Alarms and Alerts
Leak rate
(manufacturing spec)
After a 1-minute settling period, not more than 1 mmHg per second at 200
mmHg when connected to a volume of at least 15 cc.
Rapid exhaust (dump) time 3 seconds typical to drop pressure in a 500 cc volume
from 300 mmHg to < 10 mmHg
Cuff inflation time 7-8 seconds typical to 270 mmHg into a 500 cc volume in adult mode at sea
level
Maximum determination time
(without retries)
Adult 3 minutes
Pediatric 2 minutes
Neonate 1.5 minutes
Minimum time between automatic
measurements
30 seconds (Auto Mode)
2 seconds (Turbo Mode)
Allowable retries Two in each patient mode
Electrosurgery interference
suppression
Included
Table 17. Specification: Noninvasive Blood Pressure (NIBP) (continued)
Characteristic Specification
Visual alarm indicator at the monitor
Patient alarm Flashing red 0.3 seconds on, 0.3 seconds off
Equipment alert Flashing yellow 1.0 seconds on, 1.0 seconds off
Any alarm limit disabled Continuous yellow
Visual alarm indicator at Acuity
(when connected)
See Acuity Directions For Use.
Alarm indicators Red lights
Alert indicators Yellow lights
Audible alarm location Monitor
Acuity (when connected)
Audio tone frequency
(at the monitor)
1024 Hz
Audio tone volume (d = 1 meter)
(Can be configured with distinct tone
volume settings for standalone and
networked operation.)
High
Medium
Low
Off
67 dB typical (A)
60 dB typical (A)
53 dB typical (A)
Audio alarm indicator at the monitor
Patient alarm
high-priority limit violation
[100 ms on, 80 ms off, 100 ms on, 80 ms off, 100 ms on, 260 ms off, 100 ms
on, 80 ms off, 100 ms on, 1 sec off, 100 ms on, 80 ms off, 100 ms on, 80 ms
off, 100 ms on, 260 ms off, 100 ms on, 80 ms off, 100 ms on, 4 sec off];
repeat.
Equipment alert
medium priority
[160 ms on, 200 ms off, 160 ms on, 200 ms off, 160 ms on, 3.96 sec off];
repeat.
Directions for Use Specifications 171
Limits Settable on all parameters
Separate adult/pediatric/neonate mode settable limits
Alarm control Automatic preset or manual settings
Alarm priority High
Medium
Low
Patient alarms (Life-threatening)
Equipment alerts
Alarm off
Alarm on tachycardias Most tachycardias alarm in less than 8 seconds. These include AAMI 3.1.2.1
part f. waveforms. Certain multifocal tachycardias can initially alarm as “low
rate.”
Alarm hold-off period HR/PR
% SpO2
RR
3 seconds
10 seconds
5 seconds
To keep false alarms to a minimum, the monitor briefly delays or “holds off”
triggering audible and visual alarms for limit violations for these vital signs.
After the hold-off period begins, if the monitor detects that the vital sign has
returned to acceptable limits, the monitor cancels the alarm. The next time a
limit is violated, the monitor starts a new hold-off.
Audio alarm hold-off with Acuity When a monitor is connected to Acuity, the audio alarms at the monitor can
be delayed up to 4 minutes and 15 seconds. The delay time is selected in
Acuity software at the time of Acuity installation. Visual alarm indications
are not delayed.
Acuity has a default audio alarm hold-off of 11 seconds.
Alarms suspend When ‘alarms suspend’ is enabled, the monitor alarm tones for all
parameters can be suspended on the floor for a configurable period: 90
seconds, 2 minutes, 3 minutes, 4 minutes (default), 5 minutes, 10 minutes, 15
minutes, or 60 minutes.
Patient out-of-range;
transmitter failure
When a monitor is used with Acuity, an equipment alert is generated
whenever the monitor fails to communicate with Acuity after a connection
has been successfully established. In addition, the ‘No Acuity’ icon is
displayed on the monitor.
Battery failure An equipment alert is generated before the monitor battery becomes
exhausted.
Snapshot/event mark When is pressed, the monitor records a Snapshot. If the monitor is
connected to Acuity, the monitor also sends a message to Acuity so Acuity
can mark and print it.
Table 18. Specification: Default Alarm Limits
Characteristic Specification
Upper Lower
HR/PR Adult 120 beats/min
Pediatric 150 beats/min
Neonate 150 beats/min
Adult 50 beats/min
Pediatric 50 beats/min
Neonate 50 beats/min
Resp Adult 30 breaths/min
Pediatric 45 breaths/min
Neonate 60 breaths/min
Adult 5 breaths/min
Pediatric 10 breaths/min
Neonate 10 breaths/min
SpO2Adult 100%
Pediatric 100%
Neonate 98%
Adult 90%
Pediatric 90%
Neonate 85%
172 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Wireless Monitor (Model 802LTRN)
NIBP Systolic Adult 220
Pediatric 145
Neonate 100
Adult 75
Pediatric 75
Neonate 50
NIBP Diastolic Adult 110
Pediatric 100
Neonate 70
Adult 35
Pediatric 35
Neonate 30
NIBP MAP Adult 120
Pediatric 110
Neonate 80
Adult 50
Pediatric 50
Neonate 35
Table 19. Specification: Display
Characteristic Specification
Type Color transflective; LCD module
Resolution 320 x 240 pixels Quarter VGA
Active viewing area > 3.5” (8.9 cm) diagonal
Pixel pitch 0.2235 mm X 0.2235 mm
Viewing angle ± 40° from normal, horizontal and vertical; Contrast ratio > 2
Daylight viewable Daylight viewable with backlight off
Back light Display back light can be turned on or off
Brightness (back light full on) 50 cd/m2 typical
Contrast ratio 80 typical (Back light on)
Display colors 256
Table 18. Specification: Default Alarm Limits (continued)
Table 20. Specification: Wireless (Radio)
Characteristic Specification
FlexNet™ Network 2.4 GHz frequency-hopping spread-spectrum (FHSS) wireless local area network (WLAN)
and 10/100 base-T Ethernet network
Frequency 2.402 to 2.480 GHz (subject to country-specific variations within this range)
Modulation GPSK
Output power 100 mW
IEEE 802.11 compliant Yes
Monitors per access point 15 (max.)
Directions for Use Specifications 173
Environmental
Physical
Caution The monitor might not meet performance specifications if it is not used
or stored within these environmental specifications.
Note The specifications apply when the battery is installed and the battery cover is in
place.
Table 21. Specification
Characteristic Specification
Operating temperature 0° to 40° C
Shipping and storage temperature -20° to 60° C for monitor and cradle.
See Table 25, “Specification: Monitor Battery” on page 175 for details about
long-term storage of the internal monitor battery.
Operating altitude -2,000 to 15,000 ft (-610 to 4,572 m)
Shipping and storage altitude -2,000 to 40,000 ft (-610 to 12,192 m)
Operating relative humidity 5% to 95%, noncondensing per MIL STD 810E, Procedure
1-natural
Shipping and storage relative humidity 5% to 95%, noncondensing per MIL STD 810E, Procedure
1-natural
Water resistance IPX1
Drop 2 meter onto vinyl tile over concrete per EN60601-1
(Cosmetic damage is not considered a failure.)
Shock 75 g, 11 ms half sine waveform, three shocks per face for a total of 18 shocks.
Vibration, random 0.02g2/Hz from 10 to 500 Hz, ramping down to 0.002g2/Hz at 2000 Hz.
Superimposed sine frequencies of 30 Hz at 2.5 g and 60, 90, and 120 Hz at 1.5
g. Operating 1 hour per axis, 3 hours per test.
Electromagnetic compatibility (EMC) EN 60601-1-2: 2001, Emission Class A for monitor with Large Color Display
Interface, Emission Class B for monitor without Large Color Display Interface
Table 22. Specification
Characteristic Specification
Protection Classifications, all Configurations
Type of protection against electric shock—
monitor (connected to internal battery power
source or to cradle.)
Battery operation or connection to isolated cradle. Battery must be
charged in the monitor while the monitor is in the cradle.
Degree of protection against electric shock, for
parts applied to patients
See monitor labels. Type CF, defibrillator protected.
174 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Power
Method of cleaning Not suitable for autoclaving. See “Inspecting and Cleaning the
Monitor and Accessories” on page 161.
Flammable anesthetics Not suitable for use with flammable anesthetics.
Physical Dimensions
Monitor height 5.4 in (13.71 cm)
Monitor width 7.5 in (19.05 cm)
Monitor depth 2.1 in (5.33 cm)
Monitor weight (including battery and radio card) approximately 32 oz (0.9 kg)
Table 22. Specification (continued)
Table 23. Specification: Monitor Power
Characteristic Specifications
Operating Times on Battery for Ambient Temperature ≥ 20º C
Standalone
Continuous monitoring with minimal display use
(defined as 5 minutes display use per hour)
ECG and Resp only: 24 hrs
ECG, Resp, SpO2. NIBP every 15 min.: 8 hours
Acuity connected (Model 802LTRN)
In communication, with continuous monitoring and
minimal display use (5 min display use/hour)
ECG and Resp only: 24 hrs
ECG, Resp, SpO2. NIBP every 15 min.: 8 hours
Table 24. Specification: Power Adapter
Characteristic Specification
Input 100-240 volts AC, 50/60 Hz, 700 mA max
Output 15 volts DC ± 5% no load to 2A load
Output ripple 200 mV p-p maximum (90 VAC RMS, 50 Hz, 24-watt load)
Power 24 watts minimum
Holdup time 1/2 sine-wave cycle, full load, 115 V/60 Hz, 230 VAC/50 Hz, per IEC EN 61000-4-11
Overvoltage protection Built in
Overcurrent protection Built in
Efficiency 80% minimum at full load, 115 VAC input
Dielectric withstanding
voltage
4.8 KV for 1 sec or 4.0 KV for 60 sec (mains) input to DC output
Directions for Use Specifications 175
Patient leakage current 10 μA maximum, normal condition type CF per IEC EN 60601-1
50 μA maximum, single-fault condition type CF per IEC EN 60601-1
Enclosure leakage current 100 μA maximum, per IEC EN 60601-1
Protection against harmful
ingress of water
IPX1 when the LED faces up
IPX0 otherwise
Humidity 95% per MILT-28800 Par 4.5.5.1
Strain-Relief Strength 30 N per UL/IEC EN 60950-1 and UL/IEC EN 60601
Weight ≤ 0.8 lb
Insulation class (transformer) UL Rated 105° C
Width 2.68 in (68 mm)
Height 1.54 in (39 mm)
Length 4.13 in (105 mm)
Weight 10.6 oz (300 g)
AC input connector IEC 60320-C8, 2.5 A rated input housing
DC output connector Hypertronics DO2-size latching 3-pin male
Output cable length 8 feet for IEC power cord
Table 25. Specification: Monitor Battery
Characteristic Specification
Type 7.4 V, rechargeable, lithium ion. Field-replaceable by service technician.
Capacity > 1800 mA-hr minimum
Charger Contained in the cradle. Batteries are charged in place in the monitor.
Fuse rating 5A, 125V – User cannot access the fuse.
Note: Internal electronic overload circuitry is used as the primary method of protection. This
circuit resets itself when an overload is removed.
Recharge time ≤ 3 hours at 25° C (typical), with monitor either on or off.
Storage < 30 days -4°F to 122°F -20°C to 50°C
30 days to 90 days -4°F to 104°F -20°C to 40°C
> 90 days -4°F to 86°F -20°C to 30°C
NOTE: For best charge retention during extended storage, remove the battery from the monitor.
Cycle life 300 full charge/discharge cycles @ 20° C (to 70% of initial capacity)
Table 24. Specification: Power Adapter (continued)
176 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Cradle
Table 26. Specification: Cradle
Characteristic Specification
Functional
Capacity One monitor with internal battery.
Mounting Tabletop or bed rail use. Can be attached to walls, IV poles, etc. with third-party
mounting brackets.
Protection Classifications
Duty cycle Continuous
Type of protection against electric
shock
Type CF isolation exists between the monitor installed in the cradle and the
cradle DC power input, regardless of type of DC power input.
The line-operated power adapter accessory is a type CF medical-grade power
supply.
Type CF isolation exists between the monitor installed in the cradle and the
cradle USB connector.
Degree of protection against harmful
ingress of water
IPX1
Method of cleaning Not suitable for autoclaving. See “Inspecting and Cleaning the Monitor and
Accessories” on page 161.
Flammable anesthetics Not suitable for use with flammable anesthetics.
Environmental
Operating temperature 0° to 40° C
Shipping and storage temperature -20° to 60° C
Operating altitude -500 to 15,000 feet (-152 to 4,572 m)
Shipping and storage altitude -2,000 to 40,000 feet (-610 to 12,192 m)
Operating relative humidity 5% to 95%, noncondensing
Shipping, storage relative humidity 5% to 95%, noncondensing
Shock 50 g
Vibration, random 0.02g2/Hz from 10 to 500 Hz, ramping down to 0.002g2/Hz at 2000 Hz.
Superimposed sine frequencies of 30 Hz at 2.5 g and 60, 90, and 120 Hz at 1.5 g.
Operating 1 hour per axis, 3 hours per test.
Electromagnetic compatibility (EMC) with USB option EN60601-1-2:2001 Class A
without USB option EN60601-1-2:2001 Class B
Physical
Depth 6.0 in (15.24 cm)
Width 7.6 in (19.3 cm)
Height 5.7 in (14.48 cm) including feet
Weight 16 oz (0.45 kg)
Directions for Use Specifications 177
Electrical
Rated input 12V to 28V DC, 22 W max, current is inversely proportional to input voltage.
Rated fuse (externally accessible) 3A, 250V, 2AG size, type T3A.
Rated output to cradle connector Monitor power = 2 Adc max @ 8.2V - 8.6V, depending on the battery charge level.
(See Charge Scheme, below.)
Charge scheme Constant current ≈ 900 mA.
Constant current for preconditioning ≈ 180 mA for pack voltage of 4.3V - 6.2V.
Constant voltage = 8.4V ± 0.06V total at the battery cells.
Charge termination triggers Charge current ≈ 90 mA.
Total charge timeout ≈ 4 hours.
Precondition charge timeout ≈ 1 hour.
Charge time (with monitor on or off) ≤ 3 hours typical for battery fully discharged but not exhausted.
The cradle can precondition most exhausted batteries, which adds to the total
charge time.
Charging terminates when the battery is fully charged or when a fault is
detected.
Charge time required on a dead
battery before NIBP can be used.
NIBP can be used as soon as monitor is powered by the cradle.
Output overcurrent Electronic overload protection. If overload occurs, monitor must be removed and
reinserted to reset the charger.
Cradle-to-monitor connector Hypertronics L-Series Module D,17-pin male
Power input connector Hypertronics Panel Mount D02 size latching 3-pin female
Status Indicators
Status light yellow Battery or cradle fault (time out, temperature out of range, a cell is overcharged,
cradle latch button is pressed, monitor not seated in the cradle, overload, no
battery or nonrejuvenatable battery in monitor.)
Status light green Monitor connected and battery charging
Status light off Monitor not connected, or monitor connected and battery fully charged
Power light green DC input power is being applied to the cradle.
Both lights off Cradle not powered, cradle fuse is blown, or cradle has shut itself down.
Communications Functions
Cradle to attached PC
communications
Per USB 1.1 (not fully compliant)
USB device type Vendor-defined class, Full-Speed Communications (12 MBPS)
USB ID Vendor: 0x0770
Device: 0x0802
USB connector USB type B female (device)
Table 26. Specification: Cradle (continued)
178 Specifications Welch Allyn Propaq LT Vital Signs Monitor
B
179
EMC Compliance
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Monitor, Battery-Operated. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180
Charging/Communication Cradle with Monitor . . . . . . . . . . . . . . . . . . . . . . . . .184
Monitor and Cradle with Large Color Display Interface . . . . . . . . . . . . . . . . . . .188
Overview
Special precautions concerning electromagnetic compatibility (EMC) must be taken for all
medical electrical equipment.
• All medical electrical equipment must be installed and put into service in
accordance with the EMC information provided in this document.
• Portable and mobile RF communications equipment can affect the behavior of
medical electrical equipment.
Propaq LT Series monitors and accessories comply with all applicable and required
standards for electromagnetic interference.
• They do not normally affect nearby equipment and devices.
• They are not normally affected by nearby equipment and devices.
• It is safe to operate them in the presence of high-frequency surgical equipment;
however, it is good practice to avoid using the monitors near other equipment.
180 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Monitor, Battery-Operated
Guidance and manufacturer’s declaration—electromagnetic emissions
The battery-operated Propaq LT Series monitor is intended for use in the electromagnetic environment specified below.
The customer or the user of the monitor should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment—guidance
RF emissions
CISPR 11
Group 1 The battery-operated Propaq LT Series monitor uses RF
energy only for its internal function.a Therefore, its RF
emissions are very low and are not likely to cause any
interference in nearby electronic equipment.
a. The battery-operated Propaq LT Series monitor contains a 2.4-GHz frequency-hopping spread-spectrum transmitter for the purpose
of wireless communication. The radio is operated according to the requirements of various agencies, including FCC 47 CFR 15.247 and
R&TTE Directive (1995/5/EC). The radio is excluded from the EMC requirements of 60601-1-2:2001, but should be considered when
addressing possible interference issues between this and other devices.
RF emissions
CISPR 11
Class B The battery-operated Propaq LT Series monitor is suitable for
use in all establishments, including domestic establishments
and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
No connection to mains
(battery-operated)
Voltage fluctuations/flicker
emissions
IEC 61000-3-3
No connection to mains
(battery-operated)
Directions for Use EMC Compliance 181
Guidance and manufacturer’s declaration—electromagnetic immunity
The battery-operated Propaq LT Series monitor is intended for use in the electromagnetic environment specified below.
The customer or the user of the monitor should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic
environment—guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete,
or ceramic tile. If floors are
covered with synthetic material,
the relative humidity should be at
least 30%.
Electrical fast transient/
burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
lines
No connection to mains
(battery-operated). No
other cables requiring
EFT/Burst testing.
Since there is no connection to the
mains, there is no requirement for
mains quality.
Surge
IEC 61000-4-5
±1 kV differential mode
±2 kV common mode
No connection to mains
(battery-operated).
Voltage dips, short
interruptions, and voltage
variations on
power-supply input lines
IEC 61000-4-11
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
No connection to mains
(battery-operated).
Power frequency (50/60
Hz) magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment.
Note Ut is the AC mains voltage prior to application of the test level.
182 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Guidance and manufacturer’s declaration—electromagnetic immunity
The battery-operated Propaq LT Series monitor is intended for use in the electromagnetic environment specified below.
The customer or the user of the monitor should assure that it is used in such an environment.
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic environment—guidance
Portable and mobile RF communications equipment should
be used no closer to any part of the battery-operated Propaq
LT Series monitor, including cables, than the recommended
separation distance calculated from the equation applicable
to the frequency of the transmitter.
Recommended separation distance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms d = 1.2
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m d = 1.2 80 MHz to 800 MHz
d = 2.3 800 MHz to 2.5 GHz
where P is the maximum output power rating of the
transmitter in watts according to the transmitter
manufacturer and d is the recommended separation distance
in meters.
Field strengths from fixed RF transmitters, as determined by
an electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interference may occur in the vicinity of equipment marked
with the following symbol:
Note 1 At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured
field strength in the location in which the battery-operated Propaq LT Series monitor is used exceeds the applicable RF compliance
level above, the battery-operated Propaq LT Series monitor should be observed to verify normal operation. If abnormal performance
is observed, additional measures may be necessary, such as reorienting or relocating the battery-operated Propaq LT Series monitor.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P
Directions for Use EMC Compliance 183
Recommended separation distances between portable and mobile RF communications equipment
and the battery-operated Propaq LT Series monitor
The battery-operated Propaq LT Series monitor is intended for use in an electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the battery-operated Propaq LT Series monitor can help
prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the battery-operated Propaq LT Series monitor as recommended below,
according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d = 1.2
80 MHz to 800 MHz
d = 1.2
800 MHz to 2.5 GHz
d = 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.21.22.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (w) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
P P P
184 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Charging/Communication Cradle with Monitor
Guidance and manufacturer’s declaration—electromagnetic emissions
The Charging/Communication Cradle with Propaq LT Series monitor is intended for use in the electromagnetic
environment specified below. The customer or the user of the Charging/Communication Cradle with Propaq LT Series
monitor should assure that it is used in such an environment.
Note: The EMC specifications on pages 184-187 apply to the following:
• Charging/Communication Cradle alone
• Propaq LT Series monitor with Charging/Communication Cradle
• Propaq LT Series monitor with Charging/Communication Cradle in communication via USB cable with personal
computer
Emissions test Compliance Electromagnetic environment—guidance
RF emissions
CISPR 11
Group 1 The Charging/Communication Cradle with Propaq LT Series monitor
uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference
in nearby electronic equipment.
RF emissions
CISPR 11
Class B The Charging/Communication Cradle with Propaq LT Series monitor
is suitable for use in all establishments, including domestic
establishments and those directly connected to the public
low-voltage power supply network that supplies buildings used for
domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
Directions for Use EMC Compliance 185
Guidance and manufacturer’s declaration—electromagnetic immunity
The Charging/Communication Cradle with Propaq LT Series monitor is intended for use in the electromagnetic
environment specified below. The customer or the user of the monitor should assure that it is used in such an
environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment—
guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete, or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be at
least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
lines
±2 kV for power
supply lines
±1 kV for input/output
lines
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
IED 61000-4-5
±1 kV differential mode
±2 kV common mode
±1 kV differential
mode
±2 kV common mode
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions, and
voltage variations on
power-supply input
lines
IEC 61000-4-11
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the Charging/Communication
Cradle with Propaq LT Series monitor
requires continued operation during a power
mains interruption, it is recommended that
the Charging/Communication Cradle with
Propaq LT Series monitor be powered from
an uninterruptible power supply or battery.
Power frequency (50/
60 Hz) magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be
at levels characteristic of a typical location in
a typical commercial or hospital
environment.
Note Ut is the AC mains voltage prior to application of the test level.
186 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Guidance and manufacturer’s declaration—electromagnetic immunity
The Charging/Communication Cradle with Propaq LT Series monitor is intended for use in the electromagnetic
environment specified below. The customer or the user of the monitor should assure that it is used in such an
environment.
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic environment—guidance
Portable and mobile RF communications equipment should
be used no closer to any part of the Charging/Communication
Cradle with Propaq LT Series monitor, including cables, than
the recommended separation distance calculated from the
equation applicable to the frequency of the transmitter.
Recommended separation distance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms d = 1.2
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m d = 1.2 80 MHz to 800 MHz
d = 2.3 800 MHz to 2.5 GHz
where P is the maximum output power rating of the
transmitter in watts according to the transmitter
manufacturer and d is the recommended separation distance
in meters.
Field strengths from fixed RF transmitters, as determined by
an electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interference may occur in the vicinity of equipment marked
with the following symbol:
Note 1 At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured
field strength in the location in which the Charging/Communication Cradle with Propaq LT Series monitor is used exceeds the
applicable RF compliance level above, the Charging/Communication Cradle with Propaq LT Series monitor should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or
relocating the Charging/Communication Cradle with Propaq LT Series monitor.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P
Directions for Use EMC Compliance 187
Recommended separation distances between portable and mobile RF communications equipment
and the Charging/Communication Cradle with Propaq LT Series monitor
The Charging/Communication Cradle with Propaq LT Series monitor is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled. The customer or the user of the Charging/Communication
Cradle with Propaq LT Series monitor can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment (transmitters) and the Charging/Communication Cradle
with Propaq LT Series monitor as recommended below, according to the maximum output power of the communications
equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d = 1.2
80 MHz to 800 MHz
d = 1.2
800 MHz to 2.5 GHz
d = 1.2
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.21.22.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (w) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
P P P
188 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Monitor and Cradle with Large Color Display Interface
Guidance and manufacturer’s declaration—electromagnetic emissions
The Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface is intended for use
in the electromagnetic environment specified below. The customer or the user of the The Propaq LT Series monitor with
Charging/Communication Cradle and Large Color Display Interface should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment—guidance
RF emissions
CISPR 11
Group 1 The Propaq LT Series monitor with Charging/Communication Cradle
and Large Color Display Interface uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not likely
to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class A The Propaq LT Series monitor with Charging/Communication Cradle
and Large Color Display Interface is suitable for use in all
establishments other than domestic and those directly connected to
the public low-voltage power supply network that supplies buildings
used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
Directions for Use EMC Compliance 189
Guidance and manufacturer’s declaration—electromagnetic immunity
The Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface is intended for use
in the electromagnetic environment specified below. The customer or the user of the The Propaq LT Series monitor with
Charging/Communication Cradle and Large Color Display Interface should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment—
guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete, or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be at
least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
lines
±2 kV for power
supply lines
±1 kV for input/output
lines
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
IED 61000-4-5
±1 kV differential mode
±2 kV common mode
±1 kV differential
mode
±2 kV common mode
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions, and
voltage variations on
power-supply input
lines
IEC 61000-4-11
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
<5% Ut
(>95% dip in Ut)
for 0.5 cycle
40% Ut
(60% dip in Ut)
for 5 cycles
70% Ut
(30% dip in Ut)
for 25 cycles
<5% Ut
(>95% dip in Ut)
for 5 sec
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the The Propaq LT Series
monitor with Charging/Communication
Cradle and Large Color Display Interface
requires continued operation during a power
mains interruption, it is recommended that
the The Propaq LT Series monitor with
Charging/Communication Cradle and Large
Color Display Interface be powered from an
uninterruptible power supply or battery.
Power frequency (50/
60 Hz) magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be
at levels characteristic of a typical location in
a typical commercial or hospital
environment.
Note Ut is the AC mains voltage prior to application of the test level.
190 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
Guidance and manufacturer’s declaration—electromagnetic immunity
The Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface is intended for use
in the electromagnetic environment specified below. The customer or the user of the Propaq LT Series monitor with
Charging/Communication Cradle and Large Color Display Interface should assure that it is used in such an environment.
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic environment—guidance
Portable and mobile RF communications equipment should
be used no closer to any part of the Propaq LT Series monitor
with Charging/Communication Cradle and Large Color
Display Interface, including cables, than the recommended
separation distance calculated from the equation applicable
to the frequency of the transmitter.
Recommended separation distance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms d = 1.2
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m d = 1.2 80 MHz to 800 MHz
d = 2.3 800 MHz to 2.5 GHz
where P is the maximum output power rating of the
transmitter in watts according to the transmitter
manufacturer and d is the recommended separation distance
in meters.
Field strengths from fixed RF transmitters, as determined by
an electromagnetic site surveya, should be less than the
compliance level in each frequency rangeb.
Interference may occur in the vicinity of equipment marked
with the following symbol:
Note 1 At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured
field strength in the location in which the Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display
Interface is used exceeds the applicable RF compliance level above, the Propaq LT Series monitor with Charging/Communication
Cradle and Large Color Display Interface should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as reorienting or relocating the Propaq LT Series monitor with Charging/
Communication Cradle and Large Color Display Interface.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
P
P
P
Directions for Use EMC Compliance 191
Recommended separation distances between portable and mobile RF communications equipment
and the Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface
The Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface is intended for use
in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the
Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display Interface can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the Propaq LT Series monitor with Charging/Communication Cradle and Large Color Display
Interface as recommended below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d = 1.2
80 MHz to 800 MHz
d = 1.2
800 MHz to 2.5 GHz
d = 1.2
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.21.22.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (w) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
P P P
192 EMC Compliance Welch Allyn Propaq LT Vital Signs Monitor
193
Limited Warranty
This product is sold by Welch Allyn under the warranties set forth in the following
paragraphs. These warranties are extended only to the end user with respect to the
original purchase of this product directly from Welch Allyn or from Welch Allyn’s
authorized distributors.
For two years (one year for remanufactured monitors) from the date of the original
delivery to the buyer, the Propaq LT Monitor and the Propaq LT Monitor Charging/
Communications Cradle are warranted to be free from functional defects in materials and
workmanship and to conform in all material respects to the description of the product
contained in the directions for use and other labeling of the product.
This warranty is valid only under the following conditions:
• The product is properly operated under conditions of normal use in accordance with
applicable safety and regulatory requirements;
• The product is configured, modified, adjusted and repaired only by Welch Allyn or by
persons expressly authorized by Welch Allyn, in accordance with Welch Allyn’s
service procedures; and
• The product has not been damaged by misuse, negligence, or accident.
For a period of 90 days, unless otherwise specified, this same warranty is made for any
accessories provided by Welch Allyn.
Under the above warranties, Welch Allyn’s sole and exclusive obligation and buyer’s sole
and exclusive remedy is limited to the repair or replacement, at the discretion of Welch
Allyn, free of charge, of products found to be defective during the warranty period.
Warranty claims must be made, not more than seven days after expiration of the warranty
period, by calling the customer service number shown below to obtain a returned material
authorization number (RMA), and returning the product with the RMA documentation,
transportation charges prepaid, to the address specified by Welch Allyn customer service.
Welch Allyn
8500 S.W. Creekside Place
Beaverton, Oregon 97008-7107 USA
Telephone: (503) 530-7500 or (800) 289-2500
Facsimile: (503) 526-4200
Welch Allyn shall not be otherwise liable for any damages, including but not limited to
incidental, consequential, or special damages.
No express or implied warranties extend beyond the warranties defined in this document.
Welch Allyn makes no warranty of merchantability or fitness for a particular purpose.
194 Limited Warranty Welch Allyn Propaq LT Vital Signs Monitor
195
Index
A
accessories,11
action,32
Acuity
communication,45, 77
configuration parameters defined by,113
disconnecting,83
indicators on the monitor display,19
marking snapshot events at,171
monitor data stored at,95
overriding monitor settings,111
patients, arrhythmia-prone (warning),5
reconnecting a patient,83
responding to alarms at,91
silencing alarms at,87
values imposed on monitor settings,113
adult
term defined,52
alarm
defined,85
responding,91
alarm limits
changing quickly with ParamSet,90
customizing,89
disabled,170
range,164, 166, 167, 169
alert
defined,85
messages,91
responding to,90
anemia and SpO2,66
anesthetics (warning),5
arterial occlusion and SpO2,66
B
back light
lock-out,23
time out,23
battery
alert message, responding to,93
charging cradle,10, 16
conserving charge,23
failure,171
fault indicator,177
recharging,159
recycling,162
status indicators,3, 9, 91
blood pressure
see NIBP
button
monitor release,18
snapshot,96
using,32
Button Stuck,91, 92
C
cardiac arrest and SpO2,66
configuration
adjusted for individual patients,113
default settings,111
download using the cradle,17
imposed by Acuity,111
must include a waveform display,22
temporary,111
configuration author,157
connectors,9
control
lock-out,23
cradle,16
cuff
equipment alerts,92
placement,65, 70
target inflation pressure,69
customizing the monitor,111
D
Defective SpO2 Sensor,91, 92
defibrillation (warning),5
Demo mode,41
display
alert messages,91
lock-out,23
time out,23
196 Index Welch Allyn Propaq LT Vital Signs Monitor
Dual Waveform display,21
E
ECG
changing waveform scale,60
lead placement,58
electrosurgery (warning),5
equipment alert
messages,91
error detection,45
F
FlexNet network,1
H
hazards
general warnings,5
heart rate (HR)
vs. pulse rate (PR),20
high-frequency ventilation and Resp,57
highlight,32
HIPAA considerations,12
hypotension and SpO2,66
hypothermia and SpO2,66
I
icons,2
indicator
Lead fault,163
pacemaker,61
indicators see status indicators
intended use,1
interface box,24
changing waveform view,26
installing,27
L
language, selecting,15
Large Color Display Interface,24
Large Numerics display,21
learning mode see Demo mode
lock-out,23
M
maintenance
operator,159
manometer,73
messages for alerts,91
monitor
transporting with the patient,46
monitoring
blood pressure,69
ECG,55
new patient,50
NIBP
,69
paced patients,60
respiration rate (Resp),55
SpO2,64
motion artifact,71
motion interference and SpO2,66
N
navigation,32
neonatal
term defined,52
network
see also Acuity
NIBP
cuff and hose selection,69
cuff placement,69
monitoring,69
warnings,69
while monitoring SpO2,65
noninvasive blood pressure
see NIBP
No SpO2 Sensor Detected,91, 92
O
operator maintenance,159
P
pacemaker
and ECG monitoring,60
rate meters (warning),5
patient mode,19
changing,38, 52
warning,5, 56
pediatric
term defined,52
power
AC, supplied by cradle,16
interruption (warning),5
on/off button,8
source, filtering to reduce interference,62
power-up sequence,13
pulse
amplitude,20
and NIBP measurement accuracy,71
Directions for Use Index 197
pulse rate
effect on SpO2 readings,64
pulse rate (PR)
vs. heart rate (HR),20
pulse rejection, pacemaker (warning),6
pulse tone
adjusting volume of,68
R
reconnecting a patient,83
release button,18
Resp
high-frequency ventilation,57
review patient data
at a PC,101
at the Acuity Central Station,101
creating a PDF,109
routine maintenance,159
S
safety
and ECG/Resp monitoring,55
and NIBP monitoring,69
and SpO2 monitoring,64
and wireless monitoring,77
general warnings and cautions,5
settings
controlled by Acuity,113
defined by Acuity,113
overridden by Acuity,111
shock and SpO2,66
Single Waveform display,21
Smartcuf
improved NIBP accuracy,71
SpO2
and anemia,66
and arterial occlusion,66
and cardiac arrest or shock,66
and hypotension,66
and hypothermia,66
and light interference,65
and motion interference,66
and vasoconstriction,66
monitoring,64
while monitoring NIBP,65
spot check,66
status indicators,8
battery,91
cradle,17, 177
network connection,78
strap
patient carry,47
transport stretcher,47
wearable,46
symbols,2
T
Tabular Trends display,21
Tabular Trends with Single Waveform display,21
teaching mode see Demo mode
time out,23
transporting
monitor and patient,46
U
Unrecognized SpO2 Sensor,91, 92
V
vasoconstriction and SpO2,66
ventilation, high-frequency, and Resp,57
W
warnings
ECG monitoring,55
general,5
monitoring paced patients,61
NIBP monitoring,69
SpO2 monitoring,64
wireless monitoring,77
waveform display
and monitor configuration,22
wireless operation
warnings about limitations of,5
198 Index Welch Allyn Propaq LT Vital Signs Monitor
