ZTE VICKI Wireless Netbook User Manual 00 C DC for XP

ZTE Corporation Wireless Netbook 00 C DC for XP

user manual pt3

There are several power options can be set for the
notebook. You can also set up the alarm methods
for battery condition.
Click [Start] → [Control Panel] → [Performance
and Maintance] → [Power Options].
Click “Alarms”.
Click and check the selection box.
Set Up Battery Alarm
Click [Alarm Action].
Set up the actions that the notebook will do after
the alarm.
Set Up Low Battery Alarm Action
Click [OK] after complete the setting.
①Notification
Select the method of warning notification
・It is possible also to select both notification methods.
・When you mute the speaker, the sound alarm will not
come out, even the sound alarm is set.
②Operation of the notebook after the alarm
Decide how the notebook works after the warning
notification selected appears.
Tip
4
3
2
1
Set Warning Alarm for Battery Condition
①
②
20
Ensure the notebook is powered off before doing battery
exchange. ( )
Before removing the battery, ensure the notebook
is powered off.
Move the battery lock switch to the right (unlock
position).
①Slide and hold the battery release latch
②Remove the battery
Slide the battery into the slot. Press it into place
gently but firmly until the latch locks it into place.
・Ensure the battery lock switch is unlocked then insert the
battery firmly.
Slide the battery lock to switch back to the locked
position.
Battery Lock Switch
5
Tip
4
Battery Release Latch
① ②
3
Battery Lock Switch
2
1
Removing and Installing the Battery
Attention
・DO NOT use the AC adapter not included in
the package. Use of another type of adapter
may risk fire or explosion.
Do not connect the positive (+) and negative
(-) terminals with a metal object such as wire.
Short-circuiting may occur leading the battery
pack to leak acid, overheat, emit smoke, burst
and/or ignite. DO NOT throw the battery in fire.
・Please refer to the safety precautions in
this manual. （Page 5~6）
Connecting AC Adapter and Charging Battery
Please ensure The battery LED is off.
21
Before Operating Your Notebook
Using Touchpad
Left Button
The left button has the same function as mouse left button.
Making selections, dragging objects, or double clicking.
Touchpad
Move the pointer over the icon you wish to execute, press the
left button or tap the pad twice in rapid succession, and the system
launches the corresponding program. If the interval between the
clicks or taps too long, the operation will not be executed.
Right Button
The right button has the same function as mouse right button.
When clicking the right button, the shortcut menu is indicated.
Scroll Operation
Using the fingertip to slide up or
down on the grey area of the
touchpad to scroll a window up
or down.
Introducing the Touchpad
Attention
・DO NOT use something like the nib or pointed object
to touch the touchpad. It may cause touchpad damage.
・DO NOT operate the touchpad with wet finger.
Sometimes, the touchpad doesn't function normally
with the sebum and the soiling of the fingertip.
Please clean your fingertip if necessary.
・Just touch and move the pointer gently, when finger
touch the touchpad with the power above necessity
or operate in unreasonable gesture, it may hurt your
finger or wrist.
22
Before Operating Your Notebook
Using Keyboard
Windows Logo Key
Pressing the key in combination with other keys allows
invoking many common functions through the keyboard.
+Open “Help and Support Center”
in Windows XP
+Minimize the Window
+To Switch Between Active Windows
+To open Run Dialog
+To open My Computer
+To open Search
+To Open System Properties
+ + To open Search For Computers program
Explanation of the Keys on a standard Windows keyboard
Application Key
The Application Key functions as same as
the right button on touchpad or mouse.
The Function Keys at the top of the keyboard
provide shortcuts to do things in the Windows
operating system. If you are using a program
such as a word processing application or
spreadsheet, the function keys can have
different uses in the program.
Function Keys
E
F
F1
M
Tab
R
Pause
Ctrl F
23
The following defines the hot keys on the keyboard.
The commands can only be accessed by first pressing
and holding the Fn key while pressing a key with
a icon.
Power Saving Function
+Places the notebook in suspend mode
(Save-to-RAM).
（refer to Page 19）
Press the power button to return
from suspend mode(Page 10)
Wireless LAN Function
+Toggles the internal wireless LAN ON or
OFF.
（Page 29~31）
LCD/External Monitor Display Function
+Toggles between the notebook’s LCD
display and an external monitor in this
sequence:
①notebook LCD only
②CRT(External Monitor) only
③LCD+CRT Clone
LCD Brightness Adjust Function
+Decrease and Increase the display
brightness
Speaker Mute Function
+Mute the speaker
Speaker Down/Up Function
+Decrease and Increase the speaker
volume
LCD Display ON/OFF Function
+Turns off the display backlight
Fn Key
6
7
3
8
9
10
24
