HAICOM Electronics HI-601VT GPS/GSM Tracking Device - Decoder Unit User Manual Manual 4
HAICOM Electronics Corp. GPS/GSM Tracking Device - Decoder Unit Manual 4
Contents
Manual 4
1.Decoder with smart (PDA) phone:
1.The smart (PDA) phone calling or communicate
with the HI-601VT
2.Voice message to the decoder
3.Voice message was transferred into standard digital
NMEA protocol data
4.The NMEA data was transmitted back to the smart
(PDA) phone via PDA cable
HOW to USE Option#2
1
3
2
4
PDA cable
11
11
HI-601VT
HOW to USE Option#3
1.Decoder with smart (PDA) phone and
laptopPC (or desktopPC):
1.The smart (PDA) phone calling or communicate
with the HI-601VT
2.Voice message to the decoder
3.Voice message was transferred into standard digital
NMEA protocol data
4.The NMEA data was transmitted to the laptopPC via
USB cable
1
3
2
4
USB port from LaptopPC
12
12
HOW to USE Option#4
1.Decoder with mobile phone and
laptopPC (or desktopPC):
1.The mobile phone calling or communicate with the
HI-601VT
2.Voice message to the decoder
3.Voice message was transferred into standard digital
NMEA protocol data
4.The NMEA data was transmitted to the laptopPC via
USB cable
1
3
2
4
Mobile Phone
13
13
HI-601VT
HOW to USE Option#5
1.Decoder with mobile phone and
laptopPC (or desktopPC):
1.The mobile phone calling or
communicate with the HI-601VT
2.Voice message to the decoder
3.Voice message was transferred into
standard digital NMEA protocol data
4.The GPS NMEA data was
transmitted to the laptopPC via
Bluetooth® wirelessly
1
2
3
4
Bluetooth®
dongle
14
14
