4.With smartphone or mobile phone and track with SMS in
none-real time bases (without decoder):
The phone set up communication to HI-601VT. Press “71” and hang
up the phone. In few seconds, the phone will receive a short
message indicating the HI-601VT current coordinates. Then, go to
Google Earth or any mapping software (in none navigation mode)
and key in the coordinates. The map will point out the exact
location.
(1) Dial the number to
HI-601VT
(2) After connection,
press “71”. then, hang up.
In few seconds,
your mobile will
receive a SMS
message reqarding
to the current
location coordinate.
(1)
(2)
15
15
HI-601VT
Key in the coordinates into the Google Earth
or any mapping software for the location
Key in
latitude and
longitude data
received from
SMS
16
16
Use HI-601VT unit as a regular GPS receiver:
By connecting different kinds of optional accessory cables from
the side of HI-601VT mini1394 connector, the HI-601VT can
also be all kind regular GPS receivers.
For instance, HI-601VT can connect a HI-403BT cube and the
combination can be a regular Bluetooth GPS receiver for car
navigation. Or, connect an optional USB cable to become a USB
GPS receiver for laptopPC navigation.
Use HI-601VT as a regular Bluetooth GPS receiver
(with HI-403BT box and cigarette lighter)
17
17
HI-601VT
HI-601VT as a regular wired GPS mouse:
By connection different optional connecting cables, HI-601VT
can be all kinds of independent wired GPS receiver solutions.
18
18
