CG2400 users manual Front pages
i
CG 2400
User Guide
For the Ericsson® CG 2400
PC Cordless Phone System
Brea, California
ii ii
CG 2400 User Guide for the Ericsson PC Cordless Phone System
Part Number EN/LZTU 104 07 R1A
© 1999 by Ericsson, Inc. All rights reserved.
First printing September 1999
Printed in the United States of America
This document contains proprietary information that is protected
by copyright. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or by any
information storage and retrieval system, or translated into
another language, without prior written consent of
Ericsson, Inc., U.S.A.
NOTICE
The information in this document is subject to change without
notice.
ERICSSON MAKES NO WARRANTY OF ANY KIND WITH REGARD TO
THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Ericsson shall not be held liable for errors
contained herein nor for incidental or consequential damages in
connection with the furnishing, performance or use of this
material.
TRADEMARKS
Ericsson and CyberGenie are registered trademarks of Ericsson
Inc. in the U.S.A. and other countries.
Microsoft and Windows are trademarks or registered trademarks of
Microsoft Corporation. Other brands and their products are
trademarks or registered trademarks of their respective holders
and should be noted as such.
Published by Ericsson Inc., 40 Pointe Drive, Brea, CA 92821-3698
iii
Please follow the
installation
instructions for this
product
Do not attach the base station to your PC until you
are instructed to do so during the software
installation process.
Because the drivers for your new hardware are not
preloaded into Windows®98, connecting the base
station to your PC before the drivers are loaded by
the installation procedure will prevent the PC from
recognizing the base station hardware.
Ericsson Products
Year 2000 Compliant
Ericsson mobile terminal products with date and/or
calendar functions are designed to handle the
century turn as a normal change of date and year. On
January 1, 2000, at 00.00, year denotations written
as 1999 will change to 2000, and denotations written
as 99 will change to 00. No drops of data,
presentation or irrelevant year denotations or any
other function disorder should be expected.
Terminals and software will function normally after
the turn of the century.
This information is valid for all Ericsson mobile
terminal products, regardless of system, including all
mobile phones, pagers, data products and software
that support date and/or calendar functions.
iv
iv
Safety Information a. Safety Standards conformance: UL 1950 Third Edition
b. CSA C22.2 No. 950-95 Third Edition
EMC Regulations:
a. FCC, CFR Title 47, Subchapter 15, Subpart C
b. Industry Canada (IC) RSS-210
Telecommunication Regulation:
a. FCC, CFR Title 47, Subchapter 68
b. IC CS 03 Parts I, II, V, VI, VII & VIII
Manufacture’s Declaration of Conformity (DoC)
Ericsson Inc.
40 Pointe Drive
Brea, California 92821-3698
U.S.A.
We declare under our sole responsibility that the CG 2400 system
(Base Station Model DA 202, Handset Model DG 200 and Handset
Charger Model XA 200) conforms to the following specifications:
The limits for Class B digital device, pursuant to Part 15 of FCC
Rules and IC RSS-210, operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC Part 68 and IC CS-03:
This equipment complies with FCC Rules Part 68 and Industry of
Canada IC CS-03. Located on the back of the base station is the
FCC registration number and ringer equivalence number (REN).
You must provide this information to the phone company if
requested.
The REN is useful to determine the number of devices you may
legally connect to your telephone line and still have all of those
devices ring when your telephone number is called. In most areas,
but not all areas, the sum of the RENs of devices connected to one
line should not exceed five (5). To be certain of the number of
devices you may have connected to your line, as determined by
the REN, you should contact your local telephone company to
determine the maximum RENs for your calling area.
Hearing-aid wearers: The CG 2400 system is compatible with
inductively coupled hearing aids.
UL/cUL:
This equipment is UL-listed and cUL-listed for use with UL-listed
personal computers and complies with UL 1950/CSA C22.2 No.
950-95 Third Edition.
The Handset
v
The Handset
Indicator light
Earpiece
Volume controls
YES / off-hook
Menu / up
Handset display CyberGenie key
Headset jack
On / off / NO / on-hook
Menu / down
Clear / mute
Flash hook
Microphone
The Base Station
vi
vi
The Base Station
Indicator Light
States
Green Base station
is successfully
connected to the PC
and software is
running.
Green blinking
Firmware download is
in progress.
Amber Base station
is running in stand-
alone mode (PC not
on, software not
loaded or USB cable
unplugged).
Amber blinking
Hardware is
initializing.
Red If red for a few seconds, base station is
initializing. If red persists, indicates base station
failure.
Off Base station is not connected to power source.
Base station bottom
connectors
Line 2 socket Line 1 socket
Power socket
Optional fax/modem socket
USB connection
Indicator light
