With the exception of the SETUP configuration program, which is part of the
system firmware, this manual does not explain any of the software or devices
used with the system. Supplemental manuals or text-based documents on the
hard disk supply information about any software included with the system.
Audience
All operators using the notebook in or out of the field should read and become
familiar with this manual.
Organization
This manual has three chapters.
Chapter 1 introduces the notebook pointing out its major features.
Chapter 2 explains daily operation.
Chapter 3 gives detailed information about configuring the notebook.
Chapter 4 introduces the notebook Maintenance.
Supplemental Reading
For further information about this computer and computing in general, use these
references:
• A760T Series Service Manual for detailed troubleshooting and repair
instructions for serious hardware problems associated with the A760T Series
notebook.
• Various software manuals offer detailed instructions about individual
programs run on the notebook.
Rev. 00 f
800
X
600
R
esou
l
at
i
on
2. 13.3-inch color LCD, XVGA TFT,
1024 x 768 Resoulation
Readable
Input Devices • 87-key shower proof and dust-
proof rubber keyboard
• Embedded two-button Track Pad
• Microphone Port
Backlight Keyboard option
Output Device • Speaker Port
Expansion Unit
• optional easy installed
expansion unit (max.
20watts) for two 3/4 size
ISA bus cards; or 3/4 size
ISA bus card & one
CD-ROM (same module
as the one in Bay 1)
Communication
ports • One RS-232 serial port
• One Centronics parallel port,
support EPP/ECP
• One external monitor port
• One external PS/2 Keyboard/
Mouse port
• One Port Replicator port
• One external power supply port
• One infrared port, IrDA compliance
• One USB port
Rev.00 g
• Vout 19V, -2%~+3%, CV mode
• Vout 23.5V~10V, 2.1A~3.5A,
CP mode
• 22.8-32 VDC external car
adaptor/charger
Operating
system
• W indows 98
• Windows NT
Temperature • Operating: 0°C to +45°C • Option: -20°C to +50°C
(tested)
Storage
devices • Removable shock proof damaped
2.5” IDE HDD, capacity > 2.1GB
• Optional removable 3.5” 1.44MB
FDD, to install in Bay 1 internally
• Removable shock proof
damaged 2.5” IDE HDD,
capacity > 4.0, 6.4GB
• (swap with either CD-ROM
module or Bay 1 battery
pack); connected to parallel
port with optional cable
externally
• Optional CD-ROM module
to be installed in Bay 1
Open Size:
(With Rubber
Bumper)
310mm (31 cm) W
68mm (6.8 cm) H
255mm (25.5 cm) D
Weight 12.01 lbs (5.4kg)
Rev. 00 h
gp p j p , ,
next to the system unit.
5. Use only batteries supplied with the system.
6. Make sure any external power source connected to the adapter or system
conforms with adaptor or system ratings.
7. The external power adapter has a two-pronged grounding plug. If an adapter
is needed to plug the system into a power source, make sure the system is
properly grounded.
8. Arrange all cables so that they are out of traffic and unobstructed by
personnel or equipment.
9. Avoid using extension cords with this product. If an extension cord is needed,
make sure it is rated for at least 10 amperes.
10. Make sure amperage drawn by all items plugged into an outlet with this
system does not exceed 15 amperes.
11. Do not put any objects except those designed for use with this system inside
the computer.
12. Observe proper electrical safety precautions when performing system
maintenance.
13. Replace any cables with identically rated cables as those included with the
original equipment.
14. Improper handling of the battery can cause personal injury or fires. Do not
attempt to disassemble or replace individual cells in the battery pack. Do not
expose the battery to open flames. Do not short the positive and negative
ends together even if the battery is fully discharged. Keep the battery away
from children.
Rev. 00 i
Rev. 00 i
