Users Manual Appendix A
Parts Order Information
Communication Base Station Model Number
The CBS’s twelve-digit model number is located on its name plate. The
model number contains important information used to ensure that a
replacement CBS will match the site’s requirements.
The twelve-digit model number is defined in following illustration.
14098
7710 10 90 9000
Language Code
Major Model Code
Class Number
Sub Model Code
Power Code
Major Model Code
The major model code 10 represents feature F001.
Major Model Code Description
10 CBS Cabinet and Related Mechanical/Electrical
Components
Sub Model Code
The following sub model codes identify the CBS.
Sub Model Code Description
00 CBS, U.S. (old version)
01 CBS, International version
02 CBS, U.S. (new version)
03 CBS, Netherlands version
A
A-2 Parts Order Information
Power Code
The following is the power code.
Power Code Description
90 The CBS does not have an internal power supply.
It receives +60V DC from external Power Supply
7710-K100.
Language Code
The following is the language code.
Language Code Description
90 No Language Characteristics
Parts Order Information A-3
Kit Numbers
The following kits support DecisioNet System installations.
Category Kit No. Kit Name
CBS 7710-K040 Transmit Antenna and Antenna Cable
for U.S.
7710-K050 Receive Antenna and Antenna Cable
for U.S.
7710-K051 Patch Antenna and Antenna Cable
for U.S.
7710-K100 CBS Central Power Supply for U.S.
7710-K105 CBS Central Power Supply,
International (bare wire plug)
7710-K300 CBS Mounting Bracket Kit
Converter 7710-K130 RS232/RS422 Converter Kit, Domestic
7710-K131 RS232/RS422 Converter Kit,
International
SmarTalker 7710-K202 8-character, standard size,
without overlay (36 pieces)
7710-K200 8-character, standard size,
without overlay (360 pieces)
7710-K222 8-character, small size,
without overlay (36 pieces)
7710-K220 8-character, small size,
without overlay (360 pieces)
7710-K298 SmarTalker Removal Tool
Note: Refer to Appendix B for detailed cable information.
A-4 Parts Order Information
Category Kit No. Kit Name
SmarTalker II 7710-K203 8-character, standard size,
without overlay (36 pieces)
7710-K204 8-character, standard size,
without overlay (360 pieces)
7710-K213 8-character, standard size,
with overlay (36 pieces)
7710-K214 8-character, standard size,
with overlay (360 pieces)
7710-K205 2x6-character, standard size,
without overlay (36 pieces)
7710-K206 2x6-character, standard size,
without overlay (360 pieces)
7710-K215 2x6-character, standard size,
with overlay (36 pieces)
7710-K216 2x6-character, standard size,
with overlay (360 pieces)
7710-K223 2x4-character, small size,
without overlay (36 pieces)
7710-K224 2x4-character, small size,
without overlay (360 pieces)
7710-K233 2x4-character, small size,
with overlay (36 pieces)
7710-K234 2x4-character, small size,
with overlay (360 pieces)
7710-K225 2x5-character, small size,
without overlay (36 pieces)
7710-K226 2x5-character, small size,
without overlay (360 pieces)
7710-K235 2x5-character, small size,
with overlay (36 pieces)
7710-K236 2x5-character, small size,
with overlay (360 pieces)
Parts Order Information A-5
Category Kit No. Kit Name
7710-K241 1x6-character, signage,
(24 pieces)
A-6 Parts Order Information
Other Items
SmarTalker and SmarTalker II tags may require shelf rail attachments
that must be purchased separately from the manufacturer.
Item Manufacturer Order Number
Shelf Rail w/
front cover Fasteners For
Retail Order numbers are site-
specific. Contact your NCR
representative for additional
information.
SmarTalker II tags may require C-channel clips. The clips are available
through NCR in three versions: 0 degree, 25 degree, and 40 degree. The
same clips are used for standard-size and small size tags. The security
screw is optional.
Item Manufacturer Order Number
C-channel Clip
0 degrees NCR 7710-K271 (240 pieces)
C-channel Clip
25 degrees NCR 7710-K273 (240 pieces)
C-channel Clip
40 degrees NCR 7710-K275 (240 pieces)
Security Screw NCR 7710-K297 (2,500 pieces)
Parts Order Information A-7
