Teklogix 9150 Wireless Gateway User Manual Appendix B

Teklogix 9150 Wireless Gateway User Manual B-1
APPENDIX B
MAC BRIDGE PROTOCOL FILTERS AND OUIS
B.1 Ethernet II Types (RFC 1700)
B.1.1 Listing by Description
DESCRIPTION TYPE (HEX VALUES)
3Com Corporation 0x6010-0x6014
3Com(Bridge) loop detect 0x9003
3Com(Bridge) TCP-IP Sys 0x9002
3Com(Bridge) XNS Sys Mgmt 0x9001
Advanced Encryption System 0x823E-0x8240
Aeonic Systems 0x8036
Allen-Bradley 0x80E0-0x80E3
Alpha Micro 0x814A
Apollo Computer 0x80F7
Apollo Computers 0x8019
Appletalk 0x809B
AppleTalk AARP (Kinetics) 0x80F3
Applitek Corporation 0x80C7
Apricot Computers 0x81CC-0x81D5
ARAI Bunkichi 0x81A4
ARP 0x0806
Artisoft 0x81D6-0x81DD
Ascom Banking Systems 0x8221-0x8222
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-2 Teklogix 9150 Wireless Gateway User Manual
AT&T 0x8008
AT&T 0x8046
AT&T 0x8047
AT&T 0x8069
Athena Programming 0x827F-0x8282
ATOMIC 0x86DF
Autophon 0x806A
Banyan Systems 0x0BAD
Banyan Systems 0x80C4
Banyan Systems 0x80C5
BBN Simnet 0x5208
BBN VITAL-LanBridge cache 0xFF00
Berkeley Trailer encap/IP 0x1001-0x100F
Berkeley Trailer nego 0x1000
BIIN 0x814D
BIIN 0x814E
Bridge Communications 0x8132-0x8136
Cabletron 0x7034
Chaosnet 0x0804
Charles River Data System 0x8164-0x8166
Charles River Data System 0x8263-0x826A
ComDesign 0x806C
Computer Network Tech 0x869E-0x86A1
Computer Protocol Pty Ltd. 0x815C-0x815E
Computgraphic Corp. 0x806D
Comsat Labs 0x81F0-0x81F2
DESCRIPTION TYPE (HEX VALUES)
Teklogix 9150 Wireless Gateway User Manual B-3
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
Counterpoint Computers 0x8062
Counterpoint Computers 0x8081-0x8083
Cronus Direct 0x8004
Cronus VLN 0x8003
Dansk Data Elektronik 0x807B
Datability 0x809C-0x809E
Datability 0x80E4-0x80F0
DCA Data Exchange Cluster 0x80C0-0x80C3
DEC Customer Protocol 0x6006
DEC DECNET Phase IV Route 0x6003
DEC Diagnostic Protocol 0x6005
DEC Ethernet Encryption 0x803D
DEC LAN Traffic Monitor 0x803F
DEC LANBridge 0x8038
DEC LAT 0x6004
DEC LAVC, SCA 0x6007
DEC MOP Dump/Load 0x6001
DEC MOP Remote Console 0x6002
DEC Unassigned 0x6008-0x6009
DEC Unassigned 0x8039-0x803C
DEC Unassigned 0x803E
DEC Unassigned 0x8040-0x8042
DEC Unassigned (Exp.) 0x6000
Delta Controls 0x86DE
DLOG 0x0660
DLOG 0x0661
DESCRIPTION TYPE (HEX VALUES)
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-4 Teklogix 9150 Wireless Gateway User Manual
ECMA Internet 0x0803
Evans & Sutherland 0x805D
Excelan 0x8010
ExperData 0x8049
Gateway Communications 0x86A3-0x86AC
General Dynamics 0x8068
Harris Corporation 0x80CD-0x80CE
Hayes Microcomputers 0x8130
HP Probe 0x8005
IBM SNA Service on Ether 0x80D5
Idea Courier 0x8694-0x869D
Inst Ind Info Tech 0x829A-0x829B
Integrated Solutions TRFS 0x80DE-0x80DF
Intergraph Corporation 0x80C8-0x80CC
Internet IP (IPv4) 0x0800
Invisible Software 0x8A96-0x8A97
ISC Bunker Ramo 0xFF00-0xFF0F
Kinetics 0x80F4-0x80F5
KTI 0x8139-0x813D
Landis & Gyr Powers 0x86E0-0x86EF
Landmark Graphics Corp. 0x806E-0x8077
Little Machines 0x8060
Logicraft 0x8148
Loopback 0x9000
LRT 0x7020-0x7029
Matra 0x807A
DESCRIPTION TYPE (HEX VALUES)
Teklogix 9150 Wireless Gateway User Manual B-5
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
Merit Internodal 0x807C
Motorola 0x8700-0x8710
Motorola Computer 0x818D
NBS Internet 0x0802
Nestar 0x8006
Network Computing Devices 0x8149
Nixdorf Computers 0x80A3
Novell, Inc. 0x8137-0x8138
Pacer Software 0x80C6
PCS Basic Block Protocol 0x4242
Planning Research Corp. 0x8044
Polygon 0x81E6-0x81EF
Proteon 0x7030
Protocol Engines 0x817D-0x818C
PUP Addr Trans 0x0A01
Qualcomm 0x8151-0x8153
Qualcomm 0x819A-0x81A3
Quantum Software 0x8203-0x8205
RAD Network Devices 0x81A5-0x81AE
Rational Corp 0x8150
Retix 0x80F2
Reverse ARP 0x8035
Rosemount Corporation 0x80D3-0x80D4
SAIC 0x81F3-0x81F5
SECTRA 0x86DB
SGI bounce server 0x8016
DESCRIPTION TYPE (HEX VALUES)
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-6 Teklogix 9150 Wireless Gateway User Manual
SGI diagnostics 0x8013
SGI network games 0x8014
SGI reserved 0x8015
Siemens Gammasonics Inc. 0x80A4-0x80B3
SNMP 0x814C
Spider Systems Ltd. 0x809F
Stanford V Kernel exp. 0x805B
Stanford V Kernel prod. 0x805C
Symbolics Private 0x081C
Symbolics Private 0x8107-0x8109
Taurus Controls 0x829C-0x82AB
Taylor Instrument 0x80CF-0x80D2
Technically Elite Concept 0x814F
Tigan, Inc. 0x802F
Tymshare 0x802E
Ungermann-Bass dia/loop 0x7002
Ungermann-Bass download 0x7000
Ungermann-Bass net debugr 0x0900
Univ. of Mass. @ Amherst 0x8065
Univ. of Mass. @ Amherst 0x8066
Valid Systems 0x1600
Varian Associates 0x80DD
Veeco Integrated Auto. 0x8067
VG Analytical 0x81F6-0x81F8
VG Laboratory Systems 0x8131
Vitalink Communications 0x807D-0x807F
DESCRIPTION TYPE (HEX VALUES)
Teklogix 9150 Wireless Gateway User Manual B-7
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
Vitalink TransLAN III 0x8080
Walker Richer & Quinn 0x82AC-0x8693
Wellfleet Communications 0x80FF-0x8103
X.25 Level 3 0x0805
X.75 Internet 0x0801
Xerox IEEE802.3 PUP 0x0A00
XEROX NS IDP 0x0600
XNS Compatibility 0x0807
Xyplex 0x0888-0x088A
Xyplex 0x81B7-0x81B9
DESCRIPTION TYPE (HEX VALUES)
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-8 Teklogix 9150 Wireless Gateway User Manual
B.1.2 Listing By Type (Hexadecimal)
TYPE (HEX VALUES) DESCRIPTION
0x0600 XEROX NS IDP
0x0660 DLOG
0x0661 DLOG
0x0800 Internet IP (IPv4)
0x0801 X.75 Internet
0x0802 NBS Internet
0x0803 ECMA Internet
0x0804 Chaosnet
0x0805 X.25 Level 3
0x0806 ARP
0x0807 XNS Compatibility
0x081C Symbolics Private
0x0888-0x088A Xyplex
0x0900 Ungermann-Bass net debugr
0x0A00 Xerox IEEE802.3 PUP
0x0A01 PUP Addr Trans
0x0BAD Banyan Systems
0x1000 Berkeley Trailer nego
0x1001-0x100F Berkeley Trailer encap/IP
0x1600 Valid Systems
0x4242 PCS Basic Block Protocol
0x5208 BBN Simnet
0x6000 DEC Unassigned (Exp.)
0x6001 DEC MOP Dump/Load
0x6002 DEC MOP Remote Console
Teklogix 9150 Wireless Gateway User Manual B-9
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
0x6003 DEC DECNET Phase IV Route
0x6004 DEC LAT
0x6005 DEC Diagnostic Protocol
0x6006 DEC Customer Protocol
0x6007 DEC LAVC, SCA
0x6008- DEC Unassigned
0x6009 DEC Unassigned
0x6010-0x6014 3Com Corporation
0x7000 Ungermann-Bass download
0x7002 Ungermann-Bass dia/loop
0x7020-0x7029 LRT
0x7030 Proteon
0x7034 Cabletron
0x8003 Cronus VLN
0x8004 Cronus Direct
0x8005 HP Probe
0x8006 Nestar
0x8008 AT&T
0x8010 Excelan
0x8013 SGI diagnostics
0x8014 SGI network games
0x8015 SGI reserved
0x8016 SGI bounce server
0x8019 Apollo Computers
0x802E Tymshare
0x802F Tigan, Inc.
TYPE (HEX VALUES) DESCRIPTION
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-10 Teklogix 9150 Wireless Gateway User Manual
0x8035 Reverse ARP
0x8036 Aeonic Systems
0x8038 DEC LANBridge
0x8039-0x803C DEC Unassigned
0x803D DEC Ethernet Encryption
0x803E DEC Unassigned
0x803F DEC LAN Traffic Monitor
0x8040-0x8042 DEC Unassigned
0x8044 Planning Research Corp.
0x8046 AT&T
0x8047 AT&T
0x8049 ExperData
0x805B Stanford V Kernel exp.
0x805C Stanford V Kernel prod.
0x805D Evans & Sutherland
0x8060 Little Machines
0x8062 Counterpoint Computers
0x8065 Univ. of Mass. @ Amherst
0x8066 Univ. of Mass. @ Amherst
0x8067 Veeco Integrated Auto.
0x8068 General Dynamics
0x8069 AT&T
0x806A Autophon
0x806C ComDesign
0x806D Computgraphic Corp.
0x806E-0x8077 Landmark Graphics Corp.
TYPE (HEX VALUES) DESCRIPTION
Teklogix 9150 Wireless Gateway User Manual B-11
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
0x807A Matra
0x807B Dansk Data Elektronik
0x807C Merit Internodal
0x807D-0x807F Vitalink Communications
0x8080 Vitalink TransLAN III
0x8081-0x8083 Counterpoint Computers
0x809B Appletalk
0x809C-0x809E Datability
0x809F Spider Systems Ltd.
0x80A3 Nixdorf Computers
0x80A4-0x80B3 Siemens Gammasonics Inc.
0x80C0-0x80C3 DCA Data Exchange Cluster
0x80C4 Banyan Systems
0x80C5 Banyan Systems
0x80C6 Pacer Software
0x80C7 Applitek Corporation
0x80C8-0x80CC Intergraph Corporation
0x80CD-0x80CE Harris Corporation
0x80CF-0x80D2 Taylor Instrument
0x80D3-0x80D4 Rosemount Corporation
0x80D5 IBM SNA Service on Ether
0x80DD Varian Associates
0x80DE-0x80DF Integrated Solutions TRFS
0x80E0-0x80E3 Allen-Bradley
0x80E4-0x80F0 Datability
0x80F2 Retix
TYPE (HEX VALUES) DESCRIPTION
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
B-12 Teklogix 9150 Wireless Gateway User Manual
0x80F3 AppleTalk AARP (Kinetics)
0x80F4-0x80F5 Kinetics
0x80F7 Apollo Computer
0x80FF-0x8103 Wellfleet Communications
0x8107-0x8109 Symbolics Private
0x8130 Hayes Microcomputers
0x8131 VG Laboratory Systems
0x8132-0x8136 Bridge Communications
0x8137-0x8138 Novell, Inc.
0x8139-0x813D KTI
0x8148 Logicraft
0x8149 Network Computing Devices
0x814A Alpha Micro
0x814C SNMP
0x814D BIIN
0x814E BIIN
0x814F Technically Elite Concept
0x8150 Rational Corp
0x8151-0x8153 Qualcomm
0x815C-0x815E Computer Protocol Pty Ltd
0x8164-0x8166 Charles River Data System
0x817D-0x818C Protocol Engines
0x818D Motorola Computer
0x819A-0x81A3 Qualcomm
0x81A4 ARAI Bunkichi
0x81A5-0x81AE RAD Network Devices
TYPE (HEX VALUES) DESCRIPTION
Teklogix 9150 Wireless Gateway User Manual B-13
Appendix B: MAC Bridge Protocol Filters and OUIs
Ethernet II Types (RFC 1700)
0x81B7-0x81B9 Xyplex
0x81CC-0x81D5 Apricot Computers
0x81D6-0x81DD Artisoft
0x81E6-0x81EF Polygon
0x81F0-0x81F2 Comsat Labs
0x81F3-0x81F5 SAIC
0x81F6-0x81F8 VG Analytical
0x8203-0x8205 Quantum Software
0x8221-0x8222 Ascom Banking Systems
0x823E-0x8240 Advanced Encryption System
0x827F-0x8282 Athena Programming
0x8263-0x826A Charles River Data System
0x829A-0x829B Inst Ind Info Tech
0x829C-0x82AB Taurus Controls
0x82AC-0x8693 Walker Richer & Quinn
0x8694-0x869D Idea Courier
0x869E-0x86A1 Computer Network Tech
0x86A3-0x86AC Gateway Communications
0x86DB SECTRA
0x86DE Delta Controls
0x86DF ATOMIC
0x86E0-0x86EF Landis & Gyr Powers
0x8700-0x8710 Motorola
0x8A96-0x8A97 Invisible Software
0x9000 Loopback
0x9001 3Com(Bridge) XNS Sys Mgmt
TYPE (HEX VALUES) DESCRIPTION
Appendix B: MAC Bridge Protocol Filters and OUIs
DSAP/SSAP Types
B-14 Teklogix 9150 Wireless Gateway User Manual
B.2 DSAP/SSAP Types
0x9002 3Com(Bridge) TCP-IP Sys
0x9003 3Com(Bridge) loop detect
0xFF00 BBN VITAL-LanBridge cache
0xFF00-0xFF0F ISC Bunker Ramo
DSAP/SSAP
(HEX VALUES) DESCRIPTION
0x0404 SNA Path Control
0x0505 SNA
0x0606 reserved (DOD IP)
0x0808 SNA
0x0C0C SNA
0x0E0E PROWAY-LAN network management and initialization (ISA-S72)
0x4242 MAC Bridge Spanning Tree Protocol (IEEE 802.1D-1993)
0x4E4E MAP messaging service (EIA RS-511)
0x5E5E ISI IP
0x8E8E PROWAY-LAN active station list maintenance (ISA-S72)
0xAAAA Subnetwork Access Protocol (SNAP)
0xE0E0 Novell Netware
0xF0F0 NetBIOS
0xFEFE ISO network layer protocol (ISO CLNS DIS 8473)
TYPE (HEX VALUES) DESCRIPTION
Teklogix 9150 Wireless Gateway User Manual B-15
Appendix B: MAC Bridge Protocol Filters and OUIs
OUI Values
B.3 OUI Values
A few important OUI values:
OUI (HEX VALUES) DESCRIPTION
0x000000 RFC 1042 encapsulation
0x0000F8 Bridge-Tunnel encapsulation
0x0020A6 Proxim Inc.
0x00601D Lucent Technologies
0x00C0AF Teklogix Inc.

Navigation menu
