Teklogix 9150 Wireless Gateway User Manual Chapter 7 Specifications

Teklogix 9150 Wireless Gateway User Manual 143
SPECIFICATIONS 7
7.1 Specifications For The 9150 Wireless Gateway .........145
7.1.1 PC Card Radios . . . . . . . . . . . . . . . . . . 145
7.1.2 Power Requirements................146
7.1.3 Physical Description................146
7.1.4 Processor And Memory . . . . . . . . . . . . . . 147
7.1.5 Environmental Requirements . . . . . . . . . . . 147
7.1.6 Network Interfaces . . . . . . . . . . . . . . . . . 147
7.1.7 SLIM Cards....................147
7.1.8 Approvals .....................147
Teklogix 9150 Wireless Gateway User Manual 145
Chapter 7: Specifications
Specifications For The 9150 Wireless Gateway
Note: Performance specifications are nominal and subject to change
without notice.
7.1 Specifications For The 9150 Wireless Gateway
7.1.1 PC Card Radios
Important: For sites in Canada, Lucent WaveLAN 802.11 and Proxim Range-
LAN 802.11 radios require a radio licence, unless they are installed
totally within a building. (The user shall obtain this licence from
Industry Canada.)
TRX7370 Narrow Band DSP
Transmit Power 2.0 Watts (North America)
0.5 to 2.0 Watts (International)
Frequency Range 403 to 512 MHz
Data Rate 9600 bps
No. of Channels 20
TekLAN 902 MHz DS Spread Spectrum (TRX7410)
Transmit Power 0.25 Watts (United States)
1.0 Watts (Canada and Australia)
Frequency 902 MHz
Data Rate 122 kbps
No. of Channels 7
TekLAN 2.4 GHz DS Spread Spectrum (TRX7425)
Transmit Power 0.1 Watt
Frequency Range 2.412 to 2.462 GHz
Data Rate 1 Mbps
No. of Channels 7
Chapter 7: Specifications
Power Requirements
146 Teklogix 9150 Wireless Gateway User Manual
Proxim RangeLAN802 IEEE 802.11 FHSS 2.4 GHz (TRX7440)
Transmit Power 100 mW, 400 mW (XR)
Frequency 2.4 GHz
Data Rate 2 Mbps
No. of Channels 79 (FCC, ETSI) 35 (FR)
23 (JP) 27 (SP)
Lucent WaveLAN IEEE 802.11 DSSS 2.4 GHz (TRX7430)*
Transmit Power 32 mW
Frequency Range 2.4 to 2.4835 GHz
Data Rate 2 Mbps
No. of Channels 11 (FCC) 13 (ETSI)
4 (FR) 1 (JP)
2 (SP)
* For regulatory information concerning the Lucent WaveLAN PC Card, please
see page 148.
7.1.2 Power Requirements
Input voltage 100 - 240 V
Frequency 50/60 Hz
Current 1.0 A
7.1.3 Physical Description
Enclosure Bayer Makroblend EL-700 (PC/PET
blend), jet black in colour, texture to
MT-11030 or equivalent
Dimensions Nominal 36.3 x 26.2 x 7.4 cm (14.3 x 10.3 x 2.9 in.)
Maximum 36.8 x 26.7 x 7.6 cm (14.5 x 10.5 x 3.0 in.)
Weight Nominal 2.9 kg (6.5 pounds)
Maximum 3.2 kg (7.0 pounds)
Teklogix 9150 Wireless Gateway User Manual 147
Chapter 7: Specifications
Processor And Memory
7.1.4 Processor And Memory
Power PC 860DC, 40 MHz Processor
16 MB DRAM
2 MB Flash ROM
7.1.5 Environmental Requirements
Operating Temperature 0°C to 50°C (32°F to 122°F)
Operating Rel. Humidity 10% to 90% (Non-condensing)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Dust and Rain IEC 529 IP42
7.1.6 Network Interfaces
On-Board Ethernet 10Base5
10Base2
10Base-T
Token Ring Madge Token Ring Smart 16/4 Ringnode
Adapter Type II PC card, 4 or 16 Mbps
7.1.7 SLIM Cards
Options RS-232/20 mA Current Loop
Optically isolated RS-232 Plus
7.1.8 Approvals
FCC Part 15, subpart B, Class B
Electrical Safety: CSA/NRTL, TÜV, CB Scheme
CE Mark
ETS 300 113
ETS 300 086
ETS 300 220
ETS 300 328
Chapter 7: Specifications
Approvals
148 Teklogix 9150 Wireless Gateway User Manual
Lucent WaveLAN PC Card Regulatory Information
The IEEE 802.11 WaveLAN PC Card must be installed and used in strict accor-
dance with the manufacturer’s instructions. This device complies with the following
radio frequency and safety standards.
Canada - Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
Europe - EU Declaration of Conformity
This device complies with the specifications listed below, following the provisions
of the EMC Directive 89/336/EEC:
•ETS 300-826 General EMC requirements for Radio equipment.
•ETS 300-328 Technical requirements for Radio equipment.
USA - Federal Communications Commission (FCC)
This device complies with Part 15 of FCC Rules. Operation of the devices in a
WaveLAN System is subject to the following two conditions:
•This device may not cause harmful interference.
•This device must accept any interference that may cause
undesired operation.
Important: Exposure to Radio Frequency Radiation.
The radiated output power of the IEEE 802.11 WaveLAN PC Card is far
below the FCC radio frequency exposure limits. Nevertheless, the
WaveLAN PC Card shall be used in such a manner that the potential for
human contact during normal operation is minimized. When using this
device in combination with WaveLAN Outdoor Antenna products, a
certain separation distance between antenna and nearby persons has to be
kept to ensure RF exposure compliance. Refer to the Regulatory State-
ments as identified in the documentation that comes with those products
for additional information.
Teklogix 9150 Wireless Gateway User Manual 149
Chapter 7: Specifications
Approvals
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy. If not
installed and used in accordance with the instructions, it may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encour-
aged to try and correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and the receiver.
•Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Lucent Technologies is not responsible for any radio or television interference
caused by unauthorized modification of the devices included with this IEEE 802.11
WaveLAN Kit, or the substitution or attachment of connecting cables and equip-
ment other than specified by Lucent Technologies.
The correction of interference caused by such unauthorized modification, substitu-
tion or attachment will be the responsibility of the user.
For country-specific approvals, please consult the flyer “Radio Certification Infor-
mation” that is included with the 9150 Wireless Gateway.
