76 RA51/52/53/54/55 INSTRUCTION MANUAL – 05
Scanner unit
RB715A
Display unit
RF720A
Scanner unit
RB716A
Display unit
RF720A
Appendix
1. RA51 General System Diagram
2. RA52 General System Diagram
Inter Connection Cable
(10 m standard)
Power supply cable
DC power supply
24 VDC (Nominal)
(10.2 to 41.6 VDC)
NMEA I/F for
Navigation
Equipment
Inter Connection Cable
(10 m standard)
Power supply cable
DC power supply
24 VDC (Nominal)
(10.2 to 41.6 VDC)
NMEA I/F for
Navigation
Equipment
Radar signal output
Radar signal input
NMEA0183 input
NMEA0183 output
Compass signal input
External buzzer
Radar signal output
Radar signal input
NMEA0183 input
NMEA0183 output
Compass signal input
External buzzer
RA51/52/53/54/55 INSTRUCTION MANUAL – 05
77
Scanner unit
RB717A
Scanner unit
RB718A
Display unit
RF720A
Display unit
RF720A
3. RA53 General System Diagram
4. RA54 General System Diagram
Radar signal output
Radar signal input
NMEA0183 input
NMEA0183 output
Compass signal input
External buzzer
Radar signal output
Radar signal input
NMEA0183 input
NMEA0183 output
Compass signal input
External buzzer
Inter Connection Cable
(10 m standard)
Power supply cable
DC power supply
24 VDC (Nominal)
(10.2 to 41.6 VDC)
NMEA I/F for
Navigation
Equipment
Inter Connection Cable
(10 m standard)
Power supply cable
DC power supply
24 VDC (Nominal)
(10.2 to 41.6 VDC)
NMEA I/F for
Navigation
Equipment
78 RA51/52/53/54/55 INSTRUCTION MANUAL – 05
Scanner unit
RB719A
Display unit
RF720B
5. RA55 General System Diagram
Radar signal output
Radar signal input
NMEA0183 input
NMEA0183 output
Compass signal input
External buzzer
Inter Connection Cable
(15 m standard)
Power supply cable
DC power supply
24 VDC (Nominal)
(18.0 to 41.6 VDC)
NMEA I/F for
Navigation
Equipment
RA51/52/53/54/55 INSTRUCTION MANUAL – 05
79
6. Interconnection Diagram
SCAN–RDM PCB (X11): RA51
SCAN–OPN PCB (X11): RA52
No.
Color Function
1
17 VIOLET +250 V
2
NC
3
17 YELLOW GND
4
34 RED SHIP’S+
5
34 YELLOW SHIP’S+
6
34 GREEN SHIP’S-
7
34 BLUE SHIP’S-
SCAN–RDM PCB (X12): RA51
SCAN–OPN PCB (X12): RA52
No.
Color Function
1
17 BLUE +24V
2
NC
3
34 ORANGE +12V
4
Braid of RED DAT-R
5
RED DAT
6
Braid of BROWN BP/SHF-R
7
BROWN BP/HG
8
Braid of GRAY V/TRG-R
9
GRAY V/TRG
POWER PCB (X3): RA51/RA52
No.
Color Function
1
17 VIOLET +250 V
2
17 BLUE +24V
3
34 ORANGE +12V
4
17 YELLOW GND
5
Braid of RED DAT-R
6
RED DAT
7
NC
8
BROWN BP/SHF
9
Braid of BROWN BP/SHF-R
10
GRAY V/TRG
11
NC
12
34 RED SHIP’S+
13
34 YELLOW SHIP’S+
14
Braid of GRAY V/TRG-R
15
34 GREEN SHIP’S-
16
34 BLUE SHIP’S-
DISPLAY
UNIT
SCANNER
UNIT
80 RA51/52/53/54/55 INSTRUCTION MANUAL – 05
E41-100A PCB (J1): RA53
E41-101A PCB (J1): RA54
E48-100A PCB (J1): RA55
No.
Color Function
1
17 VIOLET +250 V
2
NC
3
17 YELLOW GND
4
34 RED +40 V
5
34 YELLOW +40 V
6
34 GREEN +40 V - R
7
34 BLUE +40 V - R
E41-100A PCB (J2): RA53
E41-101A PCB (J2): RA54
E48-100A PCB (J2): RA55
No.
Color Function
1
17 BLUE +24V
2
NC
3
34 ORANGE +12V
4
Braid of RED DAT-R
5
RED DAT
6
Braid of BROWN BP/SHF-R
7
BROWN BP/HG
8
Braid of GRAY V/TRG-R
9
GRAY V/TRG
E43-600A PCB (J1): RA53/RA54
E43-6100 PCB (J1): RA55
No.
Color Function
1
17 VIOLET +250 V
2
17 BLUE +24V
3
34 ORANGE +12V
4
17 YELLOW GND
5
Braid of RED DAT-R
6
RED DAT
7
NC
8
BROWN BP/SHF
9
Braid of BROWN BP/SHF-R
10
GRAY V/TRG
11
NC
12
34 RED +40 V
13
34 YELLOW +40 V
14
Braid of GRAY V/TRG-R
15
34 GREEN +40 V - R
16
34 BLUE +40 V - R
DISPLAY
UNIT
SCANNER
UNIT
